Search Results (2,126)

The growing use of weathering steel in bridge engineering has highlighted the increasing impact of fatigue damage caused by the combined effects of welding residual stress and vehicular loading. This study investigates the fatigue performance of Q500qENH weathering steel bridge decks by proposing a coupled analysis method for residual stress and fatigue crack growth, utilizing collaborative simulations with Abaqus 2023 and Franc3D 7.0. An interaction model integrating welding-induced residual stress fields and dynamic vehicular loads is developed to systematically examine crack propagation patterns in critical regions, including the weld toes of the top plate and the weld seams of the U-ribs. The results indicate that the crack propagation rate at the top plate weld toe exhibits the most rapid progression, reaching the critical dimension (two-thirds of plate thickness) at 6.98 million cycles, establishing this location as the most vulnerable failure point. Residual stresses significantly amplify the stress amplitude under tension–compression cyclic loading, with life degradation effects showing 48.9% greater severity compared to pure tensile stress conditions. Furthermore, parametric analysis demonstrates that increasing the top plate thickness to 16 mm effectively retards crack propagation, while wheel load pressures exceeding 1.0 MPa induce nonlinear acceleration of life deterioration. Based on these findings, engineering countermeasures including welding defect control, optimized top plate thickness (≥16 mm), and wheel load pressure limitation (≤1.0 MPa) are proposed, providing theoretical support for fatigue-resistant design and maintenance of weathering steel bridge decks. Full article

Welding, as a critical process for achieving permanent material joining through localized heating or pressure, is extensively applied in mechanical manufacturing and transportation industries, significantly enhancing the assembly efficiency of complex structures. However, the associated localized high temperatures and rapid cooling often induce uneven thermal expansion and contraction, leading to complex stress evolution and residual stress distributions that compromise dimensional accuracy and structural integrity. In this study, we propose a combined heat source model based on the geometric characteristics of the weld pool to simulate the arc welding process of large flange shafts made of Fe-C-Mn-Cr low-alloy medium carbon steel. Simulations were performed under different welding durations and shaft diameters, and the model was validated through experimental welding tests. The results demonstrate that the proposed model accurately predicts weld pool geometry (depth error of only 2.2%) and temperature field evolution. Meanwhile, experimental and simulated deformations are presented with 95% confidence intervals (95% CI), showing good agreement. Residual stresses were primarily concentrated in the weld and heat-affected zones, exhibiting a typical “increase–steady peak–decrease” distribution along the welding direction. A welding duration of 90 s effectively reduced residual stress differentials perpendicular to the welding direction by 19%, making it more suitable for medium carbon steel components of this scale. The close agreement between simulation and experimental data verifies the model’s reliability and indicates its potential applicability to the welding simulation of other large-scale critical components, thereby providing theoretical support for process optimization. Full article

In high-altitude corrosive environments, weathering steel is widely applied due to its excellent corrosion resistance. However, the welded joint regions, where the chemical composition and microstructure undergo changes, are susceptible to the corrosion-induced degradation of mechanical properties. This study investigates the corrosion–mechanical synergistic degradation behavior of a 16 mm thick Q500 qENH base metal and its V-type and Y-type welded joint specimens. Periodic immersion corrosion tests were conducted to simulate plateau atmospheric conditions, followed by mechanical performance evaluations. Corrosion metrics—including corrosion rate, cross-sectional loss, penetration depth, and corrosion progression speed—were analyzed in relation to mechanical indicators such as the fracture location, yield load, ultimate load, yield strength, and tensile strength at varying exposure durations. The results indicate that the corrosion process exhibits distinct layering, with a two-stage characteristic of rapid initial corrosion followed by slower progression. Welded joints consistently exhibit higher corrosion rates than the base metal, with the rate difference evolving nonlinearly in an “increase–decrease–stabilization” trend. After corrosion, the mechanical performance degradation of welded joint specimens is more severe than that of base metal specimens. Full article

Welded structures, such as offshore platforms, require robust toughness in their heat-affected zones (HAZ) to withstand low-temperature environments. The coarse-grained HAZ (CGHAZ) adjacent to the fusion boundary often exhibits reduced toughness due to grain coarsening, particularly under high heat input welding conditions aimed at enhancing productivity. To address this, high-nitrogen steels containing TiN particles were developed to suppress austenite grain growth by leveraging the thermal stability of TiN precipitates. Three high-nitrogen steels with varying carbon contents (0.09%, 0.11%, and 0.15%) were fabricated and subjected to crack tip opening displacement (CTOD) testing at −20 °C and −40 °C to evaluate low-temperature HAZ toughness. Results indicate that high-nitrogen TiN steels exhibit superior CTOD values (1.38–2.73 mm) compared to conventional 490-MPa class steels, with no significant reduction in toughness despite increased carbon content. This is attributed to the presence of stable TiN particles, which restrict austenite grain growth during welding thermal cycles, and the formation of fine ferrite–pearlite microstructures in the HAZ. These findings highlight the efficacy of high-nitrogen TiN steels in enhancing low-temperature fracture resistance for welded structures. Full article

This study conducts numerical analysis of fatigue crack propagation in deck-rib welded joints of orthotropic steel decks (OSDs) using linear elastic fracture mechanics. The stress intensity factor for central surface cracks under constant range bending stress is calculated, and single and multi-crack propagation are simulated by a numerical integration method. The research results show that deck geometry critically influences crack propagation behavior. Wider decks accelerate propagation of cracks after the crack depth exceeds half the deck thickness, thicker decks exhibit linearly faster propagation rates yet retain larger residual section to bear loads, and increased weld penetration reduces fatigue life. Initial defects rapidly converge to a preferred propagation path, stabilizing near $a_f/c_f\approx 0.1$ ($a_f$ is the failure crack depth and $c_f$ is the half surface crack length) regardless of initial aspect ratio. For multi-crack scenarios, defect density dominates merging, doubling density increases final cracks by 45%. Merged cracks adhere closely to the single-crack path, while total section loss escalates with defect density and deck thickness but remains stress range independent. The identified convergence preferred propagation path enables depth estimation from surface-length measurements during real bridge inspections. Full article

Ship repair is hazardous, often presenting unsuitable working areas and risks due to the ship’s configuration. Welding tasks are particularly dangerous due to the high temperatures generated, high enough to melt the metal in structural elements, bulkheads, linings, and tanks. This study investigates the consequences of temperature distribution during the welding of naval plates and proposes some accident prevention measures. Industry working conditions were reproduced, including the materials, procedures, and tools used, as well as the certified personnel employed. DH 36-grade naval steel, with a composition of C max. 0.18%, Mn 0.90–1.60%, P 0.035%, S 0.04%, Si 0.10–0.50%, Ni max 0.4%, Cr max 0.25%, Mo 0.08%, Cu max 0.35%, Cb (Nb) 0.05%, and V 0.1%, was welded via FCAW-G (Gas-Shielded Flux-Cored Arc Welding), selected for this study because it is one of the most widely practiced in the naval industry. The main sensor used in the experiments was an FLIR model E50 thermographic camera, and thermal waxes were employed. The results for each thickness case are presented in both graphical and tabular form to provide accurate and actionable guidelines, prioritizing safety. After studying the butt jointing of naval plates of various thicknesses (8, 10, and 15 mm), safe distances to maintain were proposed to avoid risks in the most unfavorable cases: 350 mm from the welding seam to avoid burn injuries to unprotected areas of the body and 250 mm from the welding seam to avoid producing flammable gases. These numbers are less accurate but easier to remember, which prevents errors in the face of hazards throughout a long working day. Full article

Passenger cars have unibody constructions, which means that their collision damage often involves key structural components. Successful repair requires the selection of appropriate technology and adherence to quality standards, which directly affects the safety of the vehicle’s continued operation. A commonly used method is a system of replacing damaged components with new ones, while repair by molding and forming is also possible—provided the original structural features are preserved. Automotive body repairs require advanced welding techniques and high precision. Methods such as MIG, TIG, as well as brazing and soldering have replaced older techniques, providing more efficient joining of HSS and HSLA components. Maintaining quality workmanship is crucial, as repair errors can weaken a vehicle’s structure and compromise passenger safety. This article presents the results of a study on the evaluation of the quality, microstructure, and mechanical properties of welded joints of a passenger car frame rail section made of high-strength, low-alloy steel—HSLA 320. The joints were made by three welding methods: MMA, MAG, and TIG, using different technological parameters. Microstructural analysis, non-destructive testing, and microhardness measurements made it possible to assess the impact of the chosen technology on the quality and strength of the joints. The best results were obtained for the TIG method, characterized by the highest repeatability and precision. Full article

Stainless steel welding plays a critical role in industrial manufacturing due to its superior corrosion resistance and structural reliability. The keyhole tungsten inert gas (K-TIG) welding, renowned for its high efficiency, high precision, and cost-effectiveness, demonstrates particular advantages in medium-to-thick plate joining. In order to synergistically leverage the properties of 2205 duplex stainless steel (DSS) and 316L austenitic stainless steel (ASS), we have implemented K-TIG welding with a single variable under control: a constant current and voltage travelling speeds spanning 280–360 mm/min. Defect-free dissimilar joints were consistently achieved within the 280–320 mm/min speed window. The effects of welding speed on microstructural characteristics, mechanical properties, and corrosion behavior of the weld seams were systematically investigated. The percentage of austenite in the weld zone decreases from 84.7% to 59.9% as the welding speed increases. At a welding speed of 280 mm/min, the microstructural features in the regions near the weld seam and fusion zone were investigated. All obtained joints exhibited excellent tensile properties, with their tensile strengths surpassing those of the 316L base metal. The optimal impact toughness of 142 J was achieved at a welding speed of 320 mm/min. The obtained joints exceeded the hardness of TIG joints by 19%. Notably, the grain refinement in the weld zone not only enhanced the hardness of the welded joint but also improved its corrosion resistance. This study provides valuable process references in dissimilar stainless steel K-TIG welding applications. Full article

The occurrence of the welding heat-affected zone in Q420C steel may lead to a reduction in the toughness of the welded joint and disruption of high strength-toughness combination of Q420C. This study investigates the microstructure and mechanical properties of Q420C steel welded joints under three heat in-puts of 25 kJ/cm, 100 kJ/cm, 200 kJ/cm, and 300 kJ/cm, with high-strength matching adopted for the welded joints, Charpy impact tests at 0 °C, −20 °C, and −40 °C were conducted on the weld metal, fusion line(FL), and heat-affected zone (HAZ). The weld metal maintains high impact toughness across all tested temperatures. However, increasing the heat input leads to coarsening of the microstructure in the overheated zone of the HAZ, accompanied by the formation of ferrite. At a heat input of 300 kJ/cm, significant amounts of coarse intergranular ferrite and intragranular blocky ferrite develop in the overheated zone. These microstructural changes result in a marked reduction in the impact toughness of both the fusion zone and HAZ, and the fracture mode shifts from ductile to cleavage fracture. To ensure adequate impact toughness of Q420C welded joints, the welding heat input should be kept below 200 kJ/cm. Full article

Thermocouples can be combined into thermopiles to sense heat differences or achieve localized heating and cooling. However, integrating them into textiles using yarns is not straightforward, and chemical methods face challenges like complex processing, poor scalability, and voltage non-uniformity. This study employs conventional weaving to fabricate textile-based thermocouples and thermopiles for wearable sensing and potential cooling applications, with a focus on protective clothing. Using stainless steel and nickel-coated carbon yarns, we demonstrate a more stable thermocouple than those made with chemical or welded methods, with minimal fabric damage. Four conductive yarns, stainless steel, carbon fiber (CF), and nickel-coated carbon fiber (NiFC), were woven and laser-cut to form thermocouples using three different binding types to connect them. Inox1–NiFC was the most efficient thermocouple, achieving the highest Seebeck coefficient of 21.87 µV/K with Binding 3. Binding 3 also reduced contact resistance by 66% across all configurations. Slightly lower but comparable performance was seen with Inox1–NiFC/Binding 2 (21.83 µV/K) and Inox2–NiFC/Binding 1 (15.79 µV/K). In contrast, FC-based thermocouples showed significantly lower Seebeck values: 5.67 µV/K (Inox2–FC/Binding 2), 5.43 µV/K (Inox1–FC/Binding 3), and 5.06 µV/K (Inox2–FC/Binding 1). A woven thermopile with three junctions made with the optimal binding and thermocouple combination generated an average of 55.54 µV/K and about 500 µV at small temperature differences (4–5 °C), with a linear voltage response suitable for sensing. While thermal sensing proved effective, Peltier cooling needs further optimization. This method offers a stable, low-cost, and scalable platform for textile-integrated thermoelectric systems, with strong potential for use in uniforms and other protective garments. Full article

This study explores the development of a novel composite coating system combining the high hardness of WC and thermal conductivity of Cu, employing the plasma transfer arc welding method under ambient conditions. Utilizing an advanced welding approach, the work investigates microstructural evolution and phase formation in a WC-Cu-based coating applied to a mild steel substrate. Emphasis is placed on understanding the solidification behaviour and its influence on defects, microstructural refinement, and carbide formation. The study provides insights into the interactions between coating constituents and the underlying substrate under controlled thermal conditions. These findings demonstrate the potential for producing functionally graded coatings tailored for demanding wear and heat dissipation applications. The approach offers a pathway for enhancing the durability and performance of steel components in extreme service environments. Full article

Additive manufacturing (AM) is an Industry 4.0 technology that assists or replaces the conventional manufacturing (CM) of complex geometries in various sectors, including transport, steel, aerospace, military, and architecture. The aim is to improve processes, reduce energy consumption, atmospheric emissions, and solid waste, and streamline stages while complying with the new environmental regulations. The main objective of this work was to carry out a cradle-to-gate Life Cycle Assessment (LCA), considering the raw material extraction, pre-processing, manufacturing, and post-processing stages, comparing two manufacturing methods for the same ER-90 metal flange part, conventional forging and wire and arc additive manufacturing (WAAM), all following the requirements and operations proposed by the ISO 14040/44 standard. WAAM is a Directed Energy Deposition (DED) technology that uses welding techniques to produce 3D objects with more complex geometries. Compared to the forging industry, which requires a lot of heat and kinetic energy in its metal part production stages, WAAM is a more sustainable and modern alternative because it does not require high temperatures and energy to produce the same parts. The environmental indicators compared in the process stages were energy consumption, greenhouse gas (GHG) emissions, and solid waste. The total energy consumption in AM was 18,846.61 MJ, the GHG emissions were 864.49 kgCO₂-eq, and the solid waste generated was 142.34 kg, which were 63.8 %, 90.5%, and 31.6% lower than the environmental indicators calculated for CM, respectively. Full article

The degree of anisotropy and heterogeneity in coarse-grained materials significantly affects ultrasonic propagation behavior and scattering. This paper proposes a vector coherent factor threshold total focusing imaging method (VCF-T-TFM) for austenitic stainless steel, based on material properties, through a combination of simulation and experimentation. Three types of austenitic stainless steel weld test blocks with varying degrees of heterogeneity were selected containing multiple side-drilled hole defects, each with a diameter of 2 mm. Full-matrix data were collected using a 32-element phased array probe with a center frequency of 5 MHz. The grain size and orientation of the material were quantitatively observed via electron backscatter diffraction (EBSD). By combining the instantaneous phase distribution of the TFM image, the coarse-grained material coherence compensation value (C_A) and probability threshold (P_T) were optimized for different heterogeneous regions, and the vector coherence imaging threshold (γ) was adjusted. The defect imaging results of homogeneous material (carbon steel) and three austenitic stainless steels with different levels of heterogeneity were compared, and the influence of coarse-grained, anisotropic heterogeneous structures on the imaging signal-to-noise ratio was analyzed. The results show that the VCF-T-TFM, which considers the influence of material properties on phase coherence, can suppress structural noise. Compared to compensation results that did not account for material properties, the signal-to-noise ratio was improved by 97.3%. Full article

This study investigated the effect of laser shock peening (LSP) treatment on the fatigue performance of Q355D steel butt-welded joints. The results demonstrate that LSP sig-nificantly enhances joint fatigue resistance through gradient hardening in surface lay-ers, introduction of high-magnitude residual compressive stress fields, and micro-structural refinement. Specifically, microhardness increased across all joint zones with gradient attenuation of strengthening effects within an approximately 700 μm depth. LSP effectively suppressed residual tensile stress concentration in regions beyond 4 mm on both sides of the weld. Fatigue tests confirmed that LSP substantially extended joint fatigue life: by 113–165% in the high-stress region (250–270 MPa) and 46–63% in the medium-low-stress region (230–240 MPa). Fractographic analysis further revealed reduced fatigue striation spacing and lower microcrack density in LSP-treated speci-mens, reflecting the synergistic effect of residual compressive stress fields and micro-structural refinement in retarding crack propagation. This work substantiates LSP as an effective method for enhancing fatigue resistance in Q355D steel welded joints. Full article

We present a comprehensive study on the femtosecond laser direct welding of glass and metal, focusing on optimizing processing parameters and understanding the influence of material properties and beam shaping on welding quality. Using microscopy, we identified optimal pulse energy, focal position, and line-spacing for achieving high-quality welds. We further investigated the effects of laser beam shaping and material property differences in various glass-to-metal pairs, including borosilicate, fused silica, and Zerodur glasses welded with mirror-polished metals such as Cu, Mo, Al, Ti, and AISI316 steel. Our results show that Ti and AISI316 steel exhibit the lowest adhesion to borosilicate and fused silica glasses, while Zerodur glass achieves good adhesion with all tested metals. To understand the weldability differences among material pairs, we employed a time-dependent finite-element method to analyze the laser heating-induced thermal stress. Our findings indicate that the welding quality is significantly influenced by the choice of materials and beam shaping, with the vortex beam showing potential for improved welding outcomes. This study provides valuable insights for optimizing glass-to-metal welding processes for various industrial applications. Full article
