The role of weirs in flow regulation in water resources infrastructure and flood control is well known. In the meantime, the study of full-width plate weirs (FWPW), due to their wide application and lacking findings, is of great importance. In this study, experimental models were conducted at Babol Noshirvani University of Technology to investigate flow passing through FWPWs with five different heights (p = 0.07, 0.09, 0.11, and 0.15 m) under eight discharge conditions (Q = 1.4 to 6.3 L/s). The experiments were carried out in a flume measuring 4 m in length, 0.6 m in width, and 0.2 m in height. The discharges were measured with a calibrated flowmeter, and the water depths upstream of the weir (h) and the tailwater depths (h₁) were measured with a point gauge with an accuracy of 0.1 mm. For each test, the discharge coefficient (C_d), relative residual energy (E₁/E₀), and relative energy dissipation ((E₀ − E₁)/E₀) were computed. The proposed equation for calculating discharge achieved good accuracy with RMSE = 0.0002, MAE=0.0002, and R² = 0.997. Results show a reducing trend of C_d by increasing h/P, which is compatible with previous results. It was observed that at a constant discharge, relative residual energy reduces by an average of 47% by increasing weir height, and at a constant P, increasing flow discharge increases it a little. A novel accurate equation for relative energy dissipation in FWPW was proposed based on h/P that provided specific constant coefficients for each p value. Full article

The article investigates the development of local scour downstream of a damming structure, emphasizing the dynamic equilibrium of river morphology influenced by both natural processes and human interventions like the construction of weirs. It distinguishes between clear-water and live-bed conditions, discussing how sediment transport interacts with hydraulic forces to shape the riverbed. The introduction of a damming structure disrupts sediment flow and initiates local scour formation, which varies depending on stream conditions. In the experimental section, a physical model of a damming weir was tested under controlled conditions. The laboratory model was inspired by an existing damming weir on the Radomka River in Poland. Granulometric analysis and eleven flow series were conducted to assess scour evolution over time. The results showed the fastest erosion in the first hours, followed by stabilization in scour depth but continued elongation of the scour hole. The analysis identified four phases of scour development: initiation, intensive growth, stabilization, and equilibrium. Despite depth stabilization, scour length continued to increase, indicating that full equilibrium had not been reached. The study highlights the complexity of predicting scour behavior and recommends incorporating both depth and length evolution into design analyses to improve the resilience of such damming structures. The innovative aspect of the present study lies in the inclusion of coarse sediment transport, previously accumulated in the upstream reach due to the weir’s impoundment effect, into the scour development process. This specific effect has not been addressed in the studies cited by other authors. This research provides crucial insights for the sustainable design of hydraulic structures and effective sediment management strategies, contributing to the long-term stability and safety of riverine infrastructure. Full article

Climate-change-induced increases in extreme rainfall events necessitate the enhancement of discharge capacity in aging dam infrastructures. Piano Key Weirs (PKWs), with their compact footprint and efficient discharge performance, present a promising option for improving the discharge efficiency of existing spillways. This study introduces an innovative composite Piano Key Weir (CPKW), which integrates both rectangular and trapezoidal layouts. Numerical simulations were performed to systematically compare the flow field and discharge performance between conventional trapezoidal PKW and composite configurations. Results show that the composite structure significantly improves the discharge capacity of the reference trapezoidal model by up to 16%. This enhancement is primarily attributed to the extended crest length and reduced local submergence, resulting in a more efficient discharge distribution. For the specific composite configurations studied, the optimal key width ratio that effectively balances the inflow efficiency and the adverse effects of nappe interference is found to range between 0.89 and 1.01. Additionally, a relative upstream head of 0.2–0.3 is identified as a critical threshold, beyond which the intense local submergence starts to affect the downstream trapezoidal side-wall section, limiting the contribution of the entire side wall to the total discharge and resulting in decreased overall efficiency. Full article

In the 20-year period from 2003 to 2022, water runoff and suspended sediment load in a forested gully system with a total length of 7.5 km was recorded. The branching gully system cuts through an agricultural catchment of 1.24 km² located within the loess plateau of the Nałęczów Plateau (E Poland). A rain gauge was installed close to the watershed and in the gully mouth water runoff was monitored using a limnigraph, installed with a water gauge on a Thomson triangular weir. To determine suspended sediment concentrations during erosion episodes, water was sampled at a frequency dependent on the rate and duration of the runoff. The aim of the monitoring studies was to specify the relationship between flow rate and suspended concentration for different water runoff conditions, which were used to calculate sediment load. The contribution of propluvial and pronivial runoff to gully development was assessed, particularly in the transport of sediment out of the catchment, and unit denudation rates were calculated as less than 1000 Mg km⁻² year⁻¹, average 173 Mg km⁻² year⁻¹, and during a single event as a maximal 900 Mg km⁻². Full article

The conventional piano key weir (PKW), characterized by a rectangularly cranked planform, is an effective discharge structure. Its hydraulic performance is primarily influenced by several geometrical parameters, including crest length, key width, and weir height. To enhance its hydraulic efficiency, each key is modified with an isosceles triangle at both the crest and the vertical base surface. In this way, the weir crest is extended both up and downstream; the key floor is lowered accordingly, resulting in a triangular prism-shaped floor. Laboratory tests are conducted to compare the hydraulic performance of this modified weir with that of the standard design. The results demonstrate that the geometrical adjustments noticeably improve the overflow discharge. With an equilateral triangle extending the crest length by ~23%, the discharge capacity is enhanced by 16–20% within the examined flow conditions. The modified weir outperforms the conventional design in terms of hydraulic performance. The improvements can be attributed to several factors: elongated crest length enhancing the flow capacity; triangular upstream overhangs improving the inflow condition along the inlet key’s height; lowered inlet key floor increasing the flow volume, promoting better flow movement towards the crest; lowered outlet key floor reducing the submergence effect under high flow conditions; and the triangular crest of the inlet key facilitating jet spreading and promoting air entrainment. These modifications make the redesigned PKW a promising option for improved hydraulic performance in engineering applications. Full article

Designing hydraulic structures requires careful consideration of local scouring downstream. This study investigated the performance of trapezoidal labyrinth weirs in controlling flow and mitigating scour in straight channels through physical model experiments. Sixty configurations were examined, using weir apex angles of 20°, 45°, 60°, and 80°, heights of 30 cm, 35 cm, and 40 cm, and flow rates of 50–200 L/s. A linear weir served as a reference. The results showed that the 60° apex angle consistently outperformed other configurations, reducing scour depth by up to 41% and scour length by up to 50% compared to the linear weir. It also decreased deposition depth by 40% and length by 50%. Lowering weir height from 40 cm to 30 cm led to reductions of 35% in scour depth and 40% in scour length at low discharges. These improvements remained significant even at higher flow rates, with a 29% reduction in scour depth and 25% in scour length at 200 L/s. This study provides evidence-based recommendations for optimizing labyrinth weir designs to define the relationship between hydraulic efficiency and erosion control. It offers valuable insights into weir geometry, flow conditions, and the resulting scour and deposition patterns. These findings contribute to the optimization of labyrinth weir designs to minimize downstream bed configurations. The tests were conducted under limited flow conditions. Full article

Some dams globally have negatively affected downstream structures. Constructing subsidiary weirs may solve this problem. This novel study focuses on investigating the parameters of seepage beneath the original structure and the proposed subsidiary weir. Conformal mapping and finite element methods are used for the analysis. The proposed subsidiary weir consists of a sloping central apron, flat aprons on both the downstream and upstream ends, and upstream and downstream sheet piles of varying depths. The existing structure also has sheet piles of different depths at its upstream and downstream ends, with an impervious layer situated at a specific depth below both the structures. The study derives equations for the simulation of the upwards pressure on both the structures, seepage rate, and exit gradient along the downstream bed and the filter at an intermediate location. Our own developed software for the analysis and a commercial software for numerical methods named Finite Element Heat Transfer (FEHT)-version-1are used to calculate these parameters. The accuracy of the analytical and numerical methods is verified by comparing the results with experimental data, which demonstrate a good level of agreement. This study also simulates the impacts of various factors, such as sheet pile configurations, the depth of the stratum beneath the structure, the ratio of effective heads, and the length of the intermediate filter. Full article

The piano key (PK) weir is a cost-effective structure for flood discharge. Its typical layout comprises a rectangularly cranked crest in planform with up- and downstream overhangs. With the intention to enhance its hydraulic efficiency, the conventional weir is improved. The sloping floor of each key is modified with a downward semi-circle in the cross-section; each overhanging apex is thus assigned an elliptical crest. Thus, the developed crest length of the resulting weir becomes considerably extended. Experiments are performed to compare the hydraulic behaviors of the improved weir with a reference one. The models are 3D-printed to attain high manufacture precision. For the model dimensions chosen in the study, the developed crest is ~36% longer. The study demonstrates that the improvements in geometry lead to appreciably enhanced flow discharge capacity. Within the hydraulic range examined, the augment in flow discharge varies within a range from 30% to 53%. In terms of both discharge capacity and flow patterns, the improved weir clearly outperforms the conventional one. The elliptical overhang apexes noticeably extend the developed crest length. The streamlined upstream overhang without singularity and the lowered inlet key floor reduce the entrance energy loss and improve the inflow to the inlet key and the flow over the crest. The lowered floor also gives rise to extra water volume, which administers to the flow motion towards the crest. For the outlet key, its lowered floor facilitates the outflow and alleviates the liableness of local submergence at high discharges. If the footprint for spillway construction is limited or the increase in the reservoir water stage must be controlled, the use of a more effective PK weir for flood discharge has significant engineering implications. Full article

Periodic flushing operations during moderate flood events (≤annual flood flow HQ${}_1$) are an approach to counteract problems caused by disturbed sediment continuity in rivers, which is possibly an effect of run-of-river hydropower plants (RoR-HPPs). Considering ecology, flood risk, technical, and economical reasons, discharge values of 0.7 × HQ${}_1$ are a good reference point for the initiation of gate operations. This work aimed to investigate the role of different gate opening actions on the effectiveness of such flushing measures. Physical model tests were performed, to capture bed load rates, together with 2D velocity measurements in the vicinity of two movable radial gates above a fixed weir. The length scale of the idealized model arrangement was 1:20, and a conveyor-belt sediment feeder was used to supply a heterogeneous sediment mixture. Velocities were acquired using 2D laser doppler velocimetry (LDV). Based on the LDV measurements, mean velocity profiles and Reynolds stresses were derived. The full opening of both radial gates led to the highest bed load mobility. While the flushing efficiency drastically decreased, even for slightly submerged gates, an asymmetrical gate opening initially led to the formation of a flushing cone in the vicinity of the weir, accompanied by temporarily high flushing efficiency. In conclusion, our results stress the importance of full drawdowns in successfully routing incoming bed load downstream of the HPP. However, the combination of an asymmetric gate opening followed by a full drawdown could be a promising approach to further improve the flushing efficiency of RoR-HPPs. Full article

A piano key weir (PKW), a new type of weir aiming to increase the discharge capacity of an existing dam, was recently designed. Despite a large body of research in this field, only a few studies were conducted on A-type triangular piano key weirs (TPKW) in straight channels. In this context, this present research sought to study the flow regime, stage–discharge relationship, and discharge coefficient. Experiments were carried out using nine TPKW models and three linear weirs (LW) as the control weirs. The results indicated that the triangular piano key weirs are capable of passing a higher discharge in similar laboratory conditions compared to linear key weirs due to their longer length. For a given h/P ratio (h is the water head over the weir crest, and P is the weir height) and constant length (L_e), an increase in the weir height from 0.07 m to 0.15 m decreases the discharge coefficient by approximately 20%. From sensitivity analysis, the most influential parameters for the tested TPKW models are the h/Le dimensionless ratio, followed by the P/L_e and Fr. Moreover, the discharge coefficient has a reverse trend when the dimensionless parameters h/P, h/L_e, and Froude number are increased. However, with decreasing h/L_e, the discharge coefficient of TPKW tends to that of a broad-crested weir because of local submergence. It is expected that the results obtained will be a reference for researchers who work in this field. Full article

Vortex rock weirs (VRW) are often used in natural channel design applications to maintain channel form and function, provide physical channel stability, and enhance aquatic habitats. A balanced approach is required to address (often) conflicting goals of VRWs, which include providing erosion protection and grade control while facilitating fish passage for target species. This research evaluated a sequence of modified VRWs in a small-scale watercourse in Southern Ontario, Canada. To determine passage suitability for the target fish species, the water level, water temperature, and channel geometries at 10 VRWs and 11 adjacent pools were monitored under different water level conditions. The structural dimensions and velocity at each VRW were compared to the burst swim speed of local small-bodied fish species to determine fish passage suitability and identify the best practices for VRW design and construction. The results concluded that VRWs provided suitable passage for small-bodied fish species through gap and over-weir flow pathways, particularly during low water level conditions. Further, appropriate design considerations based on the VRW gradient, VRW width, keystone size, and pool length contributed to 100% fish ‘passability’ under all water level conditions. The methodology is provided for predicting the velocity and small-bodied fish passage suitability through VRWs, informing the best practices for VRW design and construction while balancing the requirements for channel stability and fish passage, and contributing to fish population management strategies. Full article

A labyrinth weir allows for higher discharge capacity than conventional linear weirs, especially at low hydraulic heads. In fact, this is an alternative for the design or rehabilitation of spillways. It can even be used as a strategy in problems related to dam safety. A sequential design method for a labyrinth weir is based on optimal geometric parameters and the results of discharge flow analysis using Computational Fluid Dynamics and the experimental studies reported in the literature. The tests performed were for weirs with values of H_T/P ≤ 0.8 and for angles of the cycle sidewall of 6° ≤ α ≤ 20°. The results of the discharge coefficient are presented as a family of curves, which indicates a higher discharge capacity when H_T/P ≤ 0.17. Four aeration conditions are identified with higher discharge capacity when the nappe is adhering to the downstream face of the weir wall and lower discharge capacity when the nappe is drowned. Unstable flow was present when 12° ≤ α ≤ 20°, with a greater presence when the nappe was partially aerated and drowned. The interference of the nappe is characterized and quantified, reaching up to 60% of the length between the apex, and a family of curves is presented as a function of H_T/P in this respect. Finally, a spreadsheet and a flowchart are proposed to support the design of the labyrinth type weir. Full article

The piano key (PK) weir has advanced over the labyrinth weir to increase the discharge capacity. Piano key weirs exhibit nonlinear flow behavior and are easy to place on the existing spillway or newly constructed dam with less base area. Various investigators are given equations to calculate the discharge coefficient for free and submerged flow conditions. The study focuses on reviewing the impacts of the PK weir geometry on the weir flow discharge coefficient, including weir length and height, upstream and downstream key widths, and apex overhangs. In this study, all possible aspects of PK weirs were briefly reviewed. From sensitivity analysis, it is observed that the discharge coefficient of the PK weir is more sensitive for the L/W dimensionless ratio followed by the B/P ratio. L is total length of the weir crest, W is width of the weir, B is total width of PK weir and P is height of the weir. This review paper is intended to serve as an accessible resource for hydraulic structures researchers and hydraulic engineering professionals alike interested in the hydraulics of PK weirs. Full article

One of the main reasons for the collapse of the European eel (Anguilla anguilla L.) is habitat loss resulting from the severe obstruction of rivers throughout the species’ range. Specific fish passes (i.e., eel ladders) can be installed in weirs and dams to mitigate this impact and to promote the upstream movement of eels. In the Mondego River, one of the most important basins for diadromous species in Portugal, an eel ladder was installed in 2015 at the Coimbra weir, the first obstacle to fish migration in this basin. This ladder is equipped with a monitoring trap at the upstream exit, where the eels that have successfully overcome the eel ladder are counted and measured before being released. The timing and environmental variables that promote the upstream movement of these individuals (counts at the eel trap were considered as a proxy for upstream movement activity) were assessed between January 2017 and August 2019. A total of 12,019 eels with a length ranging from 60 mm to 287 mm (median = 138 mm) used the eel ladder to move upstream the obstacle. The upstream movement occurred throughout the year, but a clear peak in activity was observed between May and June (~74%). Eels < 150 mm appeared mainly in early summer (May–June), with 64% of the total number of individuals counted in the eel trap belonging to this size class, but no differences in total body length were found between these years. Generalized Additive Models (GAMs) were used to determine the environmental factors that explained these upstream movements. Among the predictors considered (river flow, precipitation, water temperature and photoperiod), minimum water temperature had the strongest explanatory power. The results from this study are crucial for the management of the species, particularly at obstacles where no transposition equipment exists, and human intervention may be required to assist in their upstream progression. Full article

The ecological impacts of large dams on stream fish communities have been largely documented, but there is less research on the impacts of small hydropower plants (hereafter called weirs). Most of the studies that evaluate the impact of weirs have been focused on taxonomical approaches such as species richness or diversity. Size-based indicators can be used as alternative tools to evaluate the effects of several environmental changes and anthropogenic perturbations on riverine ecosystems because of the key role of body size in fish physiological rates (i.e., growth, reproduction, respiration). This work investigated the impact of 16 weirs of the upper Ter River basin (NE Iberian Peninsula) on fish community body size structure, comparing control reaches (distant from a weir) with reaches impacted by weirs (immediately downstream). We also controlled for the influence of environmental factors including altitudinal gradients, spatial connectivity, and stream depth. Additionally, we tested the usage of multiple size-based approaches under different sampling intensities from one pass to four passes with an electrofishing sampling design. The results revealed strong evidence that weirs have a negative effect on basic size metrics such as average length and median length: fish communities located in impacted sites showed smaller average and median body sizes than fish communities distant from weirs. In contrast, the size spectrum parameters and functional size diversity metrics showed weak responses to the impact of weirs. The results also showed that all size-based metrics exhibited consistent results under different sampling efforts, suggesting that one sampling pass provided a good representation of the community size structure. The results suggested that only basic size metrics such as average and median length could be useful indicators for the bioassessment of river flow alterations. Finally, size-based metrics can provide an alternative approach to characterize community fish structures by reducing the costs of fish surveys in management plans. Full article
