Search Results (22)

In this study, a correction procedure for ship mass and its longitudinal location of center of gravity suitable for a simulation environment is proposed in OpenFOAM v6.0. The concept is implemented ensuring static equilibrium and an approximately zero-pitch moment on the ship before the simulation. The viscous flow field around the ship in calm water is simulated using the VOF (Volume of Fluid) free surface two-phase and SST (Shear Stress Transport) k–ω turbulence models. Using static mesh, the resistance error of medium and fine grids is 4%, on average, against the experimental value. As the sinkage and trim are predicted using dynamic mesh, the increasing ship’s resistance causes larger errors, except for the container ship. Through the proposed correction, the ship’s vertical motions are significantly improved, and the resistance error decreases for the dynamic simulation. For the container ship, the error of resistance and motion achieved is less than 1%. The sinkage and trim errors improve tremendously for the tanker and bulk carrier, and the resistance errors are reduced slightly, by less than 3%. In the end, the detailed flow field is analyzed, as well as the ship wave-making pattern and the nominal wake velocity distribution, and these are compared with the measurement data available. The characteristics of the flow phenomena are successfully modeled. The resistance value for each hull form satisfies the requirement of Verification and Validation, and the uncertainty values are estimated. Full article

Given the typical characteristics of self-propulsion and jack-up wind turbine installation vessels (WTIVs), including their full and blunt hull form and complex appendages, this paper combines the model test method with the RANS-based CFD numerical prediction method to experimentally and numerically study the resistance of the optimized hull at different spudcan retraction positions. The calm water resistance components and their mechanisms of WTIVs based on T-BOW were obtained. Furthermore, using the multivariate nonlinear least squares method, an empirical formula for rapid resistance estimation based on the Holtrop method was derived, and its prediction accuracy and applicability were validated with a full-scale ship case. This study indicates that the primary resistance components of such low-speed vessels are viscous pressure resistance, followed by frictional resistance and wave-making resistance. Notably, the spudcan retraction well area, as a unique appendage of WTIVs, exhibits a significant “moonpool additional resistance” effect. Different spudcan retraction positions affect the total calm water resistance by approximately 20% to 30%. Therefore, in the resistance optimization design of WTIVs, special attention should be paid to the matching design of the spudcan structure and the hull shell plate lines in the spudcan retraction well area. Full article

The ultra-high-speed aerodynamically alleviated marine vehicle (AAMV) is a high-performance vessel that combines a hydrodynamic configuration and an aerodynamic wing to reduce wave-making resistance during the high-speed planing phase. The forces of the AAMV exhibit strong nonlinear and water–air coupling characteristics, resulting in particularly complex motion characteristics. This paper presents a longitudinal and lateral stability model of the AAMV, which considers the effects of aerodynamic alleviation. Additionally, a numerical model of wind and wave turbulence forces is established, which considers viscous correction based on the potential theory. Finally, the effect of wind and wave turbulence forces on the motion stability of the AAMV under regular and irregular waves is analyzed by numerical solution. The simulation results demonstrate the influence of these disturbance forces on the stability of the AAMV under different sea states. The motion parameters of the AAMV exhibit a pronounced response to changes in sea state level. The aerodynamically alleviated effect is enhanced as speed increases, and the influence of winds and waves on the AAMV is greatly weakened, reducing the possibility of instability. During the cruising phase under class V sea state, the pitch, roll, and heave response are 0.210°, 0.0229°, and 0.0734 m, respectively. This effect can effectively improve the motion stability of the AAMV in winds and waves. Full article

A high-speed advancing ship will cause significant squats in shallow water, which could increase the risk of grounding. To this end, a program based on the Rankine higher-order boundary element method (HOBEM) is developed to investigate a high-speed displacement ship with a transom stern moving in shallow water. The nonlinear free surface condition is satisfied by adopting an iterative algorithm on the real free surface. The transom condition is considered by implementing a modified transom condition. Computations of wave-making resistance, sinkage and trim in deep water are first performed, and satisfactory agreement is achieved by comparing with the experimental results; the simulations are then extended to the shallow water case. It indicates that the present method can provide a suitable balance of practicability and robustness, which can be considered as an efficient tool for the guidance in ship design stage. Full article

Naval hydrodynamics typically focus on reducing ship resistance, which can be achieved by incorporating a bulbous bow. This feature is commonly used in the merchant fleet and smaller vessels, such as fishing boats, to minimize wave-making resistance. However, it is important to note that the use of a bulbous bow may not always be necessary or effective in all ship designs. In some cases, fishing ship designs may include a bulbous bow that is not optimized due to the use of procedures and methods intended for larger merchant ships or based on past experience. This study examines the effect of different bow designs, including the bulbous bow, on ship resistance in calm water, with a focus on a typical Argentinian trawler fishing vessel. The objective of this research is to assess the hydrodynamics of various designs for a particular ship by modifying its vessel lines. Firstly, the bulbous bow is removed, and then the reduction in ship resistance achieved by the bulbous bow under different load conditions and speeds is evaluated by comparing the vessel with and without the bulbous bow. The numerical analysis is performed using OpenFOAM, and the results are validated through towing tank experiments. This research indicates that the performance of the bulbous bow varies under different conditions. Therefore, it is recommended to conduct an initial study and a full evaluation of the design and operation alternatives. Full article

The resistance of a large Pure Car Truck Carrier (PCTC) with a bulbous bow and a transom stern is evaluated in the present paper. Several cases at nine different ship speeds in calm water are simulated and results are compared with the experimental measurements. The maximum relative error is 0.93% at a Froude number (Fr) of 0.209. The total resistance coefficient of the ship in calm water shows a parabolic trend with increasing Fr, and it reaches a minimum value at Fr = 0.1794. Furthermore, the cases of the ship in regular waves with six different wavelengths and three wave heights are simulated. It is observed that the total resistance exhibits a quadratic relationship with the wavelength when the wave height is fixed. The wave-making resistance increases with the increase in wave height at any fixed wavelength, and it reaches a maximum value when the wave-length is 1.2 times the ship length (L_pp). Additionally, we also investigated the resistance in three different sea states at four different speeds. When the significant wave height of irregular waves is the same as regular waves, the wave-making resistance under irregular waves is much smaller than that of the regular waves. All of these results indicate that the bulbous bow and transom stern can reduce the wave-making and residuary resistances, which can provide a useful reference for the subsequent design and manufacturing of related ships. Full article

Hull-form optimization is a complex engineering problem. Owing to the several numerical simulations and complex design-performance spaces, hull-form optimization is considered an inefficient process, which makes determining the global optimum difficult. This study used rough set theory (RST) to acquire knowledge and reduce the design space for hull-form optimization. Furthermore, we studied one of the hull-form optimization problems by practically applying RST to the appropriate number of sampling points. To solve this problem, we proposed the RST-based sequential design-space reduction (SDSR) method that uses interval theory to calculate subspace intersections and unions, as well as test calculations to choose an appropriate stopping criterion. Finally, SDSR was used to optimize a KRISO container ship to minimize the wave-making resistance. The results were compared to those of direct optimization and one-time design-space reduction, thus proving the feasibility of this method. Full article

As a typical multi-hull ship, the pentamaran has a wider deck, higher damage stability, and low-speed seaworthiness in harsh sea conditions compared with other multi-hull types such as the catamaran and trimaran, having more potential for becoming a new type of freight merchant ship in line with the development trend of the marine economy. In this paper, on the basis of the finite volume method, the numerical simulations and detailed comparative analysis of the monohull and pentamaran in viscous flow were carried out. The resistance prediction in calm water and regular waves and the changes of each resistance component of the pentamaran were explored. The dynamic fluid body interaction (DFBI) module was used for the calculations in calm water, and the overset mesh was used for the calculations in regular waves. The results show that in calm water, the adverse effect of the side hulls on the resistance was mainly reflected in the low-speed range. In the high-speed range, the influence of the side hulls on the resistance can be ignored. At high speeds, the main hull and side hulls of the pentamaran will produce favorable wave-making interference, thereby improving the wave-making performance of the pentamaran. In regular waves, although the added resistance of the pentamaran increased most of the time, its amplitude was smaller than that of the monohull under the same wave condition. This work provides a technical basis for the research on the design and hydrodynamic performance of the pentamaran. Full article

The consideration of shallow water effects has gained in importance regarding inland operations. The interaction between the keel and the riverbed affects the hydrodynamic characteristics of marine vessels. The highly complex nature of the interference phenomenon in catamarans makes the shallow water problem more complicated as compared to monohulls. Hence, catamarans are very sensitive to speed changes, as well as to other parameters, such as the shallow water effects. This makes the design of catamarans more challenging than their monohull equivalents. At lower Froude numbers, the higher importance of the frictional resistance makes the greater wetted surface of the catamaran a disadvantage. However, at higher speeds, there is the potential to turn their twin hulls into an advantage. This study aims to investigate the wave-making resistance of a zero-carbon fast passenger ferry operating in shallow water. The URANS (unsteady Reynolds-averaged Navier–Stokes) method was employed for resistance simulations. Then, the double-body approach was followed to decompose the residual resistance into viscous pressure and wave-making resistance with the help of the form factors of the vessel calculated at each speed. The characteristics of the separated wave-making resistance components were obtained, covering low, medium, and high speeds. Significant findings have been reported that contribute to the field by providing insight into the resistance components of a fast catamaran operating in shallow waters. Full article

Due to the interference between the main hull and the outrigger of the pentamaran, resistance is greatly affected. Therefore, research on the pentamaran front outrigger inclination angle has further practical significance for reducing resistance. In this study, the pentamaran front outrigger inclination angle was analyzed by CFD method, the ship motion in waves was simulated by overlapping grid technology, and the resistance of the pentamaran in static water and waves was predicted by using the unsteady RANS equation. First, a series of validation studies were carried out for the numerical methods used in the study. Then, the influence of the front outrigger inclination angle on the pentamaran resistance performance under different working conditions is calculated and discussed. In order to analyze the influence of the change of the front outrigger inclination angle on the resistance, free surface wave-making and hull pressure are further discussed. The results show that the influence of the front outrigger inclination angle change on the resistance of the pentamaran has a certain rule, and the resistance of the pentamaran can be reduced by adjusting the front outrigger inclination angle. Full article

Kinematic analysis of leaping motions can provide meaningful insights into unraveling the efficient and agile propulsive mechanisms in dolphin swimming. However, undisturbed kinematic examination of live dolphins has been very scarce due to the restriction of close-up biological observation with a motion capture system. The main objective of this study is to quantify the leaping motion of a self-propelled bionic robotic dolphin using a combined numerical and experimental method. More specifically, a dynamic model was established for the hydrodynamic analysis of a changeable submerged portion, and experimental data were then employed to identify hydrodynamic parameters and validate the effectiveness. The effects of wave-making resistance were explored, indicating that there is a varying nonlinear relationship between power and speed at different depths. In addition, the wave-making resistance can be reduced significantly when swimming at a certain depth, which leads to a higher speed and less consumed power. Quantitative estimation of leaping motion is carried out, and the results suggest that with increase of the exiting velocity and angle, the maximum height of the center of mass (CM) increases as well; furthermore, a small exiting angle usually requires a much larger exiting velocity to achieve a complete exiting motion. These findings provide implications for optimizing motion performance, which is an integral part of underwater operations in complex aquatic environments. Full article

The scope of the present study is to investigate the effects of various geometrical hull features, such as tunnels, spray rails and whiskers on the hydrodynamic performance of a high-speed planing hull. The criteria being tested to emphasize the boat performance are the total drag, sinkage and trim angle. In addition, the decomposition of the resistance into viscous and wave-making resistance are taken into consideration. The study starts with a validation test against experimental data in order to accentuate the capability of the Computational Fluid Dynamics CFD simulation to accurately predict the total drag and trim angle of the initial form. This is later followed by a verification study based on the Richardson Extrapolation method with a grid- and time-step-convergence test in order to predict the numerical errors during the simulation. After establishing the simulation parameters regarding the proper grid size and time step, the comparative study takes place for five hull shapes and two whisker configurations while the boat is sailing at eight different speeds. The assessment of the hydrodynamic flow parameters is evaluated compared to the initial form in order to investigate the influence of the geometry change on the hydrodynamic performances of the boat. Validation of the numerical results showed the reliability of the CFD simulation to accurately predict the drag and trim angle of the boat, while the comparative study revealed that the total drag can be reduced by up to 9%, especially at higher speeds. Full article

Drag reduction by injecting air is a promising engineering method for improving ship performance. A novel automatic air intake drag reduction strut structure based on the Venturi effect is proposed for the high-speed small water-plane area twin hull vessels in the present study. The drag reduction strut can achieve the function of automatic air intake when the vehicle is moving at high speed, and the air inhaled and the incoming flow form bubbly flows to cover the strut surface, effectively reducing the drag of the strut. Considering the longitudinal symmetry of the strut structure, a two-dimensional single-chip drag reduction strut structure is designed to facilitate analysis and a solution. The volume of fluid model is combined with the k-ω SST turbulence model, and a numerical simulation is carried out to investigate the variation of the air inflow, the air volume fraction in the bubbly flows of the strut and the drag reduction rate of the strut for different sailing speeds. The analysis result shows that when the proposed model reaches a certain speed, the external air is inhaled by the strut intake duct, and the bubbly flows are formed with the incoming flow covering the surface of the strut, thereby reducing the drag coefficient. Meanwhile, it is found that as the sailing speed increases, the drag reduction rate of the strut gradually rises and its maximum value reaches about 30%. For high sailing speeds, the drag reduction rate is affected by wave-making resistance so that it gradually declines. Full article

Basis functions are key in constructing interpolation equations in hull surface modification based on radial basis functions (RBF) interpolation. However, few have studied the selection of basis functions in depth. By comparing several typical basis functions through a theoretical analysis and two-dimensional modification examples, the Wendland ψ3,1 (W) function is selected. The advantages of hull form surface modification based on W function interpolation are further validated through a case study. Finally, the modification method is used to optimize a trimaran model. An optimal hull form with fair lines is obtained, and its wave-making resistance coefficient and total resistance are reduced by 8.3% and 3.8%, respectively, compared to those of the original model. These findings not only further illustrate that the W function is relatively suitable for hull form surface modification, but also validate the feasibility and value of the RBF interpolation-based surface modification method in engineering practice. Full article

The particle swarm optimisation (PSO) algorithm has been widely used in hull form optimisation owing to its feasibility and fast convergence. However, similar to other intelligent algorithms, PSO also has the disadvantages of local premature convergence and low convergence performance. Moreover, optimization data are not used to analyse and reduce the range of values for relevant design variables. Our study aimed to solve these existing problems in the PSO algorithm and improve PSO from four aspects, namely data processing of particle swarm population initialisation, data processing of iterative optimisation, particle velocity adjustment, and particle cross-boundary configuration, in combination with space reduction technology. The improved PSO algorithm was used to optimise the hull form of an engineering vessel at Fn = 0.24 to reduce the wave-making resistance coefficient under static constraints. The results showed that the improved PSO algorithm could effectively improve the optimisation efficiency and reliability of PSO and effectively overcome the drawbacks of the PSO algorithm. Full article
