The inertia control ability of photovoltaic power stations is weak. This leads to the problem that photovoltaic power stations cannot provide effective physical inertia support in the grid-connected system. In this paper, a photovoltaic power station controlled by a synchronous generator and virtual synchronous power generation is taken as the research object. A station-level dynamic inertia control model with synchronous machine and inverter control parameters coordinated is established. Firstly, the weakening of system inertia after a high-proportion photovoltaic grid connection is analyzed. Inertia compensation analysis based on an MW-level synchronous unit is carried out. According to the principle of virtual synchronous control of inverter, the virtual inertia control method and physical mechanism of a grid-connected inverter in a photovoltaic station are studied. Secondly, the inertia characteristics of the DC side of the grid-connected inverter are analyzed. The cooperative inertia control method of the photovoltaic grid-connected inverter and synchronous machine is established. Then, the influence of inertia on the system frequency is studied. The frequency optimization of the grid-connected parameter optimization of a photovoltaic station based on inertia control is carried out. Finally, aiming at the grid-connected control parameters, the inertia control parameter setting method of the photovoltaic station is carried out. The neural network predictive control model is established. At the same time, the grid-connected control model of the MW-level synchronous machine is embedded. The control system has the inertia characteristics of the synchronous generator and the fast-response dynamic characteristics of the power inverter. Full article

The transition to inverter-dominated power systems with novel control strategies has created weak grid scenarios, prompting extensive research into grid-forming (GFM) converters and advanced GFM control schemes. This study evaluates two GFM control strategies for their stabilizing effects in weakly interconnected and islanded power systems: the established Virtual Synchronous Machine (VSM) control and the newly developed Phase-Restoring Principle (PRP). The evaluation is conducted using a real-time electromagnetic transient (EMT) simulation testbed with Hardware-in-the-Loop (HiL) capabilities. The system includes a multi-terminal medium-voltage (MVDC) and high-voltage direct current (HVDC) network weakly coupled to a network equivalent, represented by a scaled synchronous machine (SynM) to replicate grid inertia. Modular multilevel converters (MMCs) model the converters, while Power Hardware-in-the-Loop (PHiL) experiments integrate real power hardware. Dynamic interactions, including islanded conditions, are emulated to assess the performance of GFM controls and their interactions in HV/MV and AC/DC systems. The results demonstrate the compatibility of diverse GFM schemes with grid-following controls and synchronous machines, emphasizing their positive contributions to system stability. This modular demonstrator, as a realistic prototype of future power systems, provides a flexible platform for testing emerging GFM strategies and hardware, supporting the development of robust and stable inverter-based grids. Full article

Variable-Speed Hydropower Plants (VSHP) are becoming more promising for stabilising power grids with the increasing integration of renewable energy sources. This research focuses on improving fault ride-through capabilities and delivering efficient ancillary services for VSHPs to support the grid by developing a comprehensive control strategy. The control system proposed integrates a machine-side controller, a Frequency Support Controller (FSC), a Virtual Synchronous Machine (VSM), a Vector Current Controller (VCC) for the grid-side converter, a turbine governor for regulating turbine speed, and a DC-link controller. PID with an anti-windup scheme and a Model Predictive Controller (MPC) were employed for the turbine governor. The MPC turbine governor results demonstrate the potential of advanced control methods for enhanced performance of the VSHP. A benchmarking between the MPC and the PID governor was made. The benchmarking results have reported that the MPC can achieve reference tracking improvements up to $99.42\%$. Tests on a diverse set of grid scenarios were conducted, and the graphical results showed significant improvements in mitigating the frequency drops through the effective governor response. The synthetic inertia provision is swift, completing within seconds of a frequency drop. Compared to the fixed-speed approach, the VSHP improves the grid’s overall stability by minimising frequency dipping and achieving steady-state recovery remarkably faster. The fixed-speed approach only begins to recover minutes after the VSHP reaches the settling time. By effectively providing critical ancillary services such as frequency support, synthetic inertia, and smooth fault ride-through capability, the VSHP can become a transformative solution for future power grids, which are estimated to be more reliant on renewable energy sources. Full article

This paper presents a new grid-forming strategy for hybrid AC/DC microgrids using bidirectional virtual inertia support designed to address weak grid conditions. The stability of hybrid AC/DC microgrids heavily relies on the AC mains frequency and the DC-link voltage, and deviations in these factors can lead to undesirable outcomes such as load curtailments and power system congestions and blackouts. This paper introduces a unique approach that leverages bidirectional virtual inertia support to enhance the stability and reliability of hybrid AC/DC microgrids under weak grid conditions. The proposed strategy employs virtual inertia as a buffer to mitigate rapid changes in DC-link voltage and AC frequency, thereby enhancing system stability margins. This strategy significantly contributes to a more stable and reliable grid operation by reducing voltage and frequency fluctuations. A standard hybrid AC/DC microgrid configuration is used to implement the bidirectional virtual inertia support, where a bidirectional interlinking converter control is adjusted to deliver inertia support to both the AC and DC subgrids. This converter utilizes the DC grid voltage and AC grid frequency as inputs, effectively managing active power balance and implementing auxiliary functions. Extensive simulations are conducted under weak grid conditions and standalone mode to validate the effectiveness of the proposed strategy. The simulation results demonstrate a remarkable improvement in frequency nadir, rate-of-change-of-frequency (RoCoF), and DC bus voltage deviation in the hybrid AC/DC microgrids. The bidirectional virtual inertia support substantially reduces voltage and frequency fluctuations, enhancing the microgrid stability and resilience. There is an improvement of over 45% and 25% in the frequency deviation and voltage deviation, respectively, achieved through implementing the proposed control strategy. Full article

This paper presents a proposed three-step methodology designed to enhance the performance and efficiency of industrial systems by integrating Digital Twins with particle swarm optimization (PSO) algorithms while prioritizing interpretability. Digital Twins are becoming increasingly prevalent due to their capability to offer a comprehensive virtual representation of physical systems, thus facilitating detailed simulations and optimizations. Concurrently, PSO has demonstrated its effectiveness for real-time parameter estimation, especially in identifying both standard and unknown components that influence the dynamics of a system. Our methodology, as exemplified through DC Motor and Hydraulic Actuator simulations, underscores the potential of Digital Twins to augment the self-awareness of industrial machines. The results indicate that our approach can proficiently optimize system parameters in real-time and unveil previously unknown components, thereby enhancing the adaptive capacities of the Digital Twin. While the reliance on accurate data to develop Digital Twin models is a notable consideration, the proposed methodology serves as a promising framework for advancing the efficiency of industrial applications. It further extends its relevance to fault detection and system control. Central to our approach is the emphasis on interpretability, ensuring a more transparent understanding and effective usability of such systems. Full article

In order to achieve the state of charge (SOC) balance of distributed energy storage systems (ESSs) in offshore isolated island DC microgrids and enhance the inertia and damping characteristics of DC microgrids, an SOC-based bidirectional virtual DC machine (VDCM) control is presented. The control proposed has the following three improvements. Firstly, the improved VDCM control removes the power loop and torque loop on the basis of ensuring inertia and damping characteristics. Secondly, the inertia time constant and damping constant, which are related to the bus voltage difference and the change rate of bus voltage difference, are introduced to improve bus voltage dynamic performance. The proposed method overcomes the shortcoming in that traditional VDCM control cannot adaptively suppress bus voltage oscillation according to the bus voltage fluctuation amplitude. Thirdly, an improved SOC-based VDCM virtual armature resistance (VAR) is proposed to achieve rapid SOC balance. The improved SOC-based VDCM VAR is an SOC-related function added to the initial VAR. This enables the proposed VAR to have a certain adaptive ability, which can adjust the energy absorbed or released by energy storage units according to the SOC state. Compared with other controls, the control proposed takes less time to achieve SOC balance. Finally, the effectiveness and superiority of the scheme are proven by simulation cases. Full article

This work proposes a hybrid drive controlled configuration, using a minimum emissions search algorithm, which ensures the operation of the Internal Combustion Engine (ICE) in its fuel efficiency range, minimizing CO${}_2$ emissions by controlling the power flow direction of the Electric Machine (EM). This action is achieved by means of Power Converters, in this case a bi-directional DC-DC Buck-Boost Converter in the DC-side and a DC-AC T-type Converter as the inverting stage. Power flow is controlled by means of a bi-directional Model Predictive Control (MPC) scheme, based on an emissions optimization algorithm. A novel drivetrain configuration is presented where both, the ICE and the EM are in tandem arrangement. The EM is driven depending on the traction requirements and the emissions of the ICE. The EM is capable of operates in motor and generator mode ensuring the Minimum Emission Operating Point (MEOP) of the ICE regardless of the mechanical demand at the drivetrain. Simulation and validation results using a Hardware in the Loop (HIL) virtual prototype under different operation conditions are presented in order to validate the proposed overall optimization strategy. Full article

Weak grid conditions challenge the grid integration of offshore wind farms. Especially grids with low inertia and large grid impedance questions frequency and voltage compliance capabilities. Grid-forming wind turbines are a promising technology for weak grids due to the nature of their control strategy. This paper explains the difference in how weak grid conditions are described in the literature and shows how the voltage stability margin changes with the short-circuit ratio and X/R ratio. With that knowledge, the frequency and voltage compliance capabilities of three grid-forming controls in an offshore wind farm are investigated and benchmarked. These three controls are a droop control, a virtual synchronous machine, and a synchronverter. This was done by quantifying their performance during a frequency disturbance with sensitivity to the short-circuit ratio, X/R ratio, and the inertia constant, H. It is concluded that the virtual synchronous machine is the most compliant grid-forming control and that DC-link modeling is of great importance when testing compliance during frequency disturbances. Full article

Traditional password authentication methods have raised many issues in the past, including insecure practices, so it comes as no surprise that the evolution of authentication should arrive in the form of password-less solutions. This research aims to explore the problems that password authentication and password policies present and aims to deploy Windows Hello for Business (WHFB) on-premises. This includes creating three virtual machines (VMs) and evaluating WHFB as a password-less solution and showing how an attacker with privileged access may retrieve the end user’s domain password from the computer’s memory using Mimikatz and describing the possible results. The conducted research tests are in the form of two attack methods. This was feasible by the creation of three VMs operating in the following way. The first VM will act as a domain controller (DC) and certificate authority server (CA server). The second VM will act as an Active Directory Federation Service (ADFS). The third VM will act as the end-user device. The test findings research summarized that password-less authentication is far more secure than the traditional authentication method; this is evidenced throughout the author’s tests. Within the first test, it was possible to retrieve the password from an enrolled device for WHFB while it was still in the second phase of the deployment. The second test was a brute-force attack on the PIN of WHFB; since WHFB has measures to prevent such attacks, the attack was unsuccessful. However, even though the retrieval of the password was successful, there are several obstacles to achieving this outcome. It was concluded that many organizations still use password authentication as their primary authentication method for accessing devices and applications. Larger organizations such as Microsoft and Google support the adoption of password-less authentication for end-users, and the current usage of password-less authentication shared by both organizations is encouraged. This usually leads organizations to adopt this new solution for their IT infrastructure. This is because it has been used and tested by millions of people and has proven to be safe. This supports the findings of increased usage and the need for password-less authentication by today’s users. Full article

Ethylene-Vinyl Acetate (EVA) copolymer was synthesized from ethylene and vinyl acetate at high temperatures and ultra-high pressures. In this condition, any reactor disturbances, such as process or mechanical faults, may trigger the run-away decomposition reaction. This paper proposes a procedure for constructing a conditional health status prediction structure that uses a virtual health index (HI) to monitor the reactor bearing’s remaining useful life (RUL). The piecewise linear remaining useful life (PL-RUL) model was constructed by machine learning regression methods trained on the vibration and distributed control system (DCS) datasets. This process consists of using Welch’s power spectrum density transformation and machine learning regression methods to fit the PL-RUL model, following a health status construction process. In this research, we search for and determine the optimum value for the remaining useful life period (T_RUL), a key parameter for the PL-RUL model for the system, as 70 days. This paper uses four-fold cross-validation to evaluate seven different regression algorithms and concludes that the Extremely randomized trees (ERTs) is the best machine learning model for predicting PL-RUL, with an average relative absolute error (RAE) of 0.307 and a Linearity of 15.064. The Gini importance of the ensemble trees is used to identify the critical frequency bands and prepare them for additional dimensionality reduction. Compared to two frequency band selection techniques, the RAE and Linearity prediction results can be further improved to 0.22 and 8.38. Full article

The increase in inverter-based resources associated with the increased installation of PV sources is a concern because it reduces the inertia of the power system during peak PV generation periods. As a countermeasure to reduce grid inertia, the addition of pseudo-inertia using virtual synchronous machines can be selected, and PV generation can cooperatively contribute to the stable operation of the power system by using the suppressed output as reserve power. However, few studies have analyzed VSMs that do not use batteries and use PV as a resource (PV-VSM) in simulations, including grid interconnection and solar radiation fluctuations, and it is necessary to clarify the issues and discuss countermeasures. In this study, electromagnetic transient response analysis was applied to a VSM connected to a two-generator system, simulations were performed, and the following findings were reported and countermeasure methods for the problem were proposed. When the PV capacity is insufficient for the output required by the VSM inverter, the PV-VSM control system may become unstable. This is caused by a drop in the capacitor voltage of the DC/DC converter due to insufficient PV output. The limiter control system is designed to address this problem by combining the headroom estimation system with the current limiting algorithm. The proposed limiter control system is validated on solar radiation ramp fluctuations as a test case and found that the system was effective in supressing PV-VSM instability. In our simulation case, the PV-VSM with our limiter control can continue to operate stably even if the PV available power is 0.03 [p.u.] short of the inverter’s reference power by the solar power ramp fluctuation, as long as the inverter installation rate is less than 50%. Full article

In an attempt to limit the effects of global warming, virtually all car manufacturers have introduced in the last years Hybrid or full Electric Vehicles. The current study shows the experimental testing of a spoke-type PMSM that was developed based on the requirements of the L6e European light vehicle class. A test bench was developed for this purpose, using a DC machine fed by a bidirectional DC Power Supply that allowed the testing of the PMSM prototype both in motor and generator/brake regimes. The Worldwide Harmonized Light-Duty Vehicles Test Procedure (WLTP) was implemented on the control stage of the testing set-up, allowing an accurate estimation of the PMSM-based E-drivetrain performance. The test results validated the FEM-simulated results and provided an insight on the efficiency of the entire drive system (battery–inverter–PMSM) and the autonomy of the L6e light EV. The electric drive system was integrated and tested on a prototype vehicle in normal operating conditions, validating the results obtained on the developed test bench. Full article

As much wind power is integrated into the power grid through power electronic equipment, the use of wind power is increased rapidly. Wind power system makes the power grid lack inertia and damping, thereby reducing power grid stability; in severe cases, it may even be disconnected. virtual synchronous generator (VSG) has been put forward to enhance the anti-disturbance performance of power grid. However, conventional VSG adopts an outer power loop and inner-current loop control. The inner-current loop control needs a pulse width modulation (PWM) module and proportion integration (PI) parameter settings. In order to reduce the parameter settings and simplify control structures, in this study, model predictive control (MPC) is used instead of inner-current loop control. At the same time—for the overall stability and control flexibility of the back-to-back system—we further propose to use outer-voltage loop control (OVLC) and MPC to stabilize direct current (DC) voltage on the machine-side and to employ model predictive virtual synchronous controls to provide inertia and damping for the power grid. The proposed control method was simulated in Matlab/Simulink (MathWorks, Massachusetts, MA, 2016) and verified by experimental results. Full article

This paper presents a small-signal analysis of different grid side controllers for full power converter wind turbines with inertia response capability. In real wind turbines, the DC link controller, the drivetrain damping controller and the inertial response might present contradictory control actions in a close bandwidth range. This situation might lead to reduced control performance, increased component stress and non-compliance of connection agreements. The paper presents an analysis of the internal wind turbine dynamics by considering different grid-side converter control topologies: standard current control used in the wind industry, standard current control with inertia emulation capabilities and virtual synchronous machines. Comments are made on the similarities between each topology and the negative effects and limits, and possible remedies are discussed. Finally, the conclusion poses that the inclusion of a DC link voltage controller reduces the ability of a converter to respond to external frequency events without energy storage. The degradation increases with the DC link voltage control speed. Full article

Microgrids are about to change the architecture and the operation principles of the future power systems towards smartness and resiliency. Power electronics technologies are key enablers for novel solutions. In this paper we analyze the benefits of a “microgrid by design” architecture (MDA), using a solid-state transformer (SST) as a low-voltage grid-former and inverter-based generation only. In this context, the microgrid stability is maintained with the help of “electrostatic energy inertia” that can be provided by the capacitor connected to the DC busbar behind the SST inverter topology. This happens in a natural way, alike the mechanical inertia in power systems with synchronous machines, however without depending on frequency and without the need of a rotational inertia. This type of microgrid always operates (both fully connected to the main grid or in islanding mode) with all the necessary mechanisms needed to maintain the microgrid stable—no matter of the perturbations in the upstream of the point of common coupling (PCC). In the case of microgrids with inverter-based generation only (including the energy storage systems), there is no mechanical inertia and different stability mechanisms need to be applied compared to the stability principle of the classical power systems. Our proposed mechanism differentiates from the recently proposed stability assessments of microgrids based on virtual synchronous generators from the control theory perspective. This paper is a continuation of our previous work where the MDA was first introduced. The use-cases and scenarios are based on realistic and yet reasonable complexities, by coupling the disturbance magnitude with the voltage stability limit in power grids. The paper finds meaningful disturbances to test the electrostatic energy inertia at the boundaries of grid stability, as guidance to understand the range of voltage variation for extreme conditions. The results show that in microgrids with inverter-based generation only and passive loads (RLC type) the operation is no longer frequency dependent. The energy of the DC busbar capacitor as electrostatic energy inertia of the MDA has a role similar to that of the rotational machines in classical grids in terms of maintaining dynamic stability, however impacting two different types of stability. Full article
