Search Results (38)

Acoustic methods are a promising direction when determining the position of buried non-metallic pipelines. Under difficult soil conditions, one of the most effective methods is the vibroacoustic method, which has a maximum range of application when acoustic waves propagate through the transported medium. However, due to limited energy input into the pipeline, signal detection at significant distances from the source becomes challenging. This article considers the mechanism of acoustic oscillations attenuation in pipes and suggests possible directions for optimization of the investigated technology. The evaluation of mathematical modeling methods for the investigated process is conducted, and the key signal attenuation relationships are presented. The analysis allowed us to establish that the vibroacoustic method has the potential of increasing the efficiency by approximately 10–20%. Full article

Background/Objectives: Intra-articularly administered hyaluronic acid (HA) products improve the mechanical properties of the synovial fluid (SF) in an osteoarthritic (OA) joint and thus improve joint motion quality. However, current diagnostic methods, used to assess the clinical effectiveness of HA-based therapy are based on subjective tools, and are unable to deliver solid data about the actual impact of this molecule on joint functioning. Consequently, the aim of this study was to objectively assess the effect of HA IA injection on joint motion quality with vibroarthrography (VAG) and the subsequent evaluation of patient clinical status. Methods: A total of 40 patients with knee OA and 50 healthy individuals as the control group were enrolled in this non-randomized clinical and were subjected to therapy consisting of a single IA administration of highly concentrated HA gel (Biolevox™ HA ONE). The therapy assessment included an evaluation of joint motion quality with the VAG method and a subsequent evaluation of the knee joint function using the WOMAC questionnaire for up to 60 days after the therapy. Results: A single IA injection of HA led to an immediate and sustained improvement of the motion quality of OA-affected synovial joints, as proven by the significant reduction in all measured vibroacoustic emissions (VMS, R4, P1, and P2). Furthermore, this was followed by a significant improvement in all WOMAC sub-scales, observed at 30 and 60 days after the therapy. Conclusions: The results of this study demonstrate that an IA-HA injection can improve the motion quality of OA-affected joints. Importantly, the observed improvement in joint motion quality is directly correlated with early recovery of joint function. These findings provide objective evidence that HA effectively enhances OA-affected joint biomechanics, contributing to a better understanding of the actual impact of this prevalent OA therapy on knee joint motion quality. Full article

The complex frequency domain assurance criterion is here applied for the comparison of a pristine to an altered state of a vibrating system. The criterion was originally proposed for the detection of defects in vibrating structures, while in later research studies it has been successfully used in musical acoustics. In this paper, we evaluate the differences in the vibrational behavior of finished and non-finished cymbals by adopting the proposed correlation criterion. Since idiophones are playable and produce sounds after any manufacturing process, the methodology presented correlates the vibrational state of a cymbal, at any stage of manufacturing, to a reference pristine cymbal. The evaluation of the cymbals is performed by the comparison of finished cymbals with semi-finished and blank 8-inch cymbals of the same material. The correlation criterion is applied to the vibrational measurements of blank, semi-finished, and finished B8 and B20 cymbals. Additionally, commercially available finished cymbals of the same material and geometrical characteristics are introduced in this correlation study. The measuring methodology and the vibration symmetry are discussed, and valuable results and conclusions are presented. The proposed methodology highlights the influence of the manufacturing processes of forming, hammering, and finishing on the vibrational behavior of cymbals, offering manufacturers and drummers a quantifiable criterion for evaluating cymbals’ vibroacoustic performance. Representative evaluations of blanks, semi-finished, and finished cymbals demonstrate the capability of the correlation criterion to monitor, identify, and visualize the vibrational state of any cymbal compared to a pristine reference. This enables the development of a novel methodology for both manufacturers and musicians. Full article

Background: This review evaluates needle navigation technologies in minimally invasive cardiovascular surgery (MICS), identifying their strengths and limitations and the requirements for an ideal needle navigation system that features optimal guidance and easy adoption in clinical practice. Methods: A systematic search of PubMed, Web of Science, and IEEE databases up until June 2024 identified original studies on needle navigation in MICS. Eligible studies were those published within the past decade and that performed MICS requiring needle navigation technologies in adult patients. Animal studies, case reports, clinical trials, or laboratory experiments were excluded to focus on actively deployed techniques in clinical practice. Extracted data included the study year, modalities used, procedures performed, and the reported strengths and limitations, from which the requirements for an optimal needle navigation system were derived. Results: Of 36 eligible articles, 21 used ultrasound (US) for real-time imaging despite depth and needle visibility challenges. Computer tomography (CT)-guided fluoroscopy, cited in 19 articles, enhanced deep structure visualization but involved radiation risks. Magnetic resonance imaging (MRI), though excellent for soft-tissue contrast, was not used due to metallic tool incompatibility. Multimodal techniques, like US–fluoroscopy fusion, improved accuracy but added cost and workflow complexity. No single technology meets all the criteria for an ideal needle navigation system, which should combine real-time imaging, 3D spatial awareness, and tissue integrity feedback while being cost-effective and easily integrated into existing workflows. Conclusions: This review derived the criteria and obstacles an ideal needle navigation system must address before its clinical adoption, along with novel technological approaches that show potential to overcome those challenges. For instance, fusion technologies overlay information from multiple visual approaches within a single interface to overcome individual limitations. Additionally, emerging diagnostic methods like vibroacoustic sensing or optical fiber needles offer information from complementary sensory channels, augmenting visual approaches with insights into tissue integrity and structure, thereby paving the way for enhanced needle navigation systems in MICS. Full article

This study investigates the dynamic stiffness and damping characteristics of three polyurethane materials—PM, PS, and PST—using a comprehensive vibroacoustic testing approach. The aim is to examine material parameters such as dynamic stiffness, Young’s modulus, critical damping factor, and the influence of sample irregularities on the accuracy of measurements. The study employs both experimental testing, in which cuboidal and cylindrical polyurethane samples were subjected to sinusoidal excitation, and finite element modeling (FEM) to simulate the test conditions in sample without irregularities. Results indicate that sample contact surface irregularities (even as low as ~0.04 mm) significantly impact the measured dynamic stiffness, with the effect intensifying for materials with higher Young’s modulus values (above 5 MPa). Furthermore, cylindrical samples demonstrated more stable and repeatable measurements compared to cuboidal samples, where surface irregularities were tested in a more controlled environment. The findings underscore the need to consider sample geometry and irregularities in dynamic stiffness assessments to ensure better material evaluations. This work contributes valuable insights for the accurate modeling and testing of materials used in vibration isolation and sound insulation contexts. Full article

Laparoscopic access, a critical yet challenging step in surgical procedures, often leads to complications. Existing systems, such as improved Veress needles and optical trocars, offer limited safety benefits but come with elevated costs. In this study, a prototype of a novel technology for guiding needle interventions based on vibroacoustic signals is evaluated in porcine cadavers. The prototype consistently detected successful abdominal cavity entry in 100% of cases during 193 insertions across eight porcine cadavers. The high signal quality allowed for the precise identification of all Veress needle insertion phases, including peritoneum puncture. The findings suggest that this vibroacoustic-based guidance technology could enhance surgeons’ situational awareness and provide valuable support during laparoscopic access. Unlike existing solutions, this technology does not require sensing elements in the instrument’s tip and remains compatible with medical instruments from various manufacturers. Full article

A novel 3D auto-drum machine system for the generation and recording of percussion sounds is developed and presented. The capabilities of the machine, along with a calibration, sound production, and collection protocol are demonstrated. The sounds are generated by a drumstick at pre-defined positions and by known impact forces from the programmable 3D auto-drum machine. The generated percussion sounds are accompanied by the spatial excitation coordinates and the correspondent impact forces, allowing for large databases to be built, which are required by machine learning models. The recordings of the radiated sound by a microphone are analyzed using a pre-trained deep learning model, evaluating the consistency of the physical sample generation method. The results demonstrate the ability to perform regression and classification tasks when fine tuning the deep learning model with the gathered data. The produced databases can properly train machine learning models, aiding in the investigation of alternative and cost-effective materials and geometries with relevant sound characteristics and in the development of accurate vibroacoustic numerical models for studying percussion instruments sound synthesis. Full article

Monitoring blood pressure, a parameter closely related to cardiovascular activity, can help predict imminent cardiovascular events. In this paper, a novel method is proposed to customize an existing mechanistic model of the cardiovascular system through feature extraction from cardiopulmonary acoustic signals to estimate blood pressure using artificial intelligence. As various factors, such as drug consumption, can alter the biomechanical properties of the cardiovascular system, the proposed method seeks to personalize the mechanistic model using information extracted from vibroacoustic sensors. Simulation results for the proposed approach are evaluated by calculating the error in blood pressure estimates compared to ground truth arterial line measurements, with the results showing promise for this method. Full article

The paper describes the application of the numerical tool quality index for an objective evaluation of complementary frequency response analysis (FRA) and vibroacoustic method (VM) test methods. These diagnostic methods are used in the industrial practice of transformer diagnostics for the assessment of the mechanical condition of windings and a core. The quality index is based on a numerical comparison of the curve obtained from measurements and the reference curve in a frequency domain. The quality index is based on estimators for the covariance, variance, and expected values. First, both methods of analysis were applied to a group of transformers of similar construction, leading conclusions on quality index values being quickly drawn. Next, it was applied to another transformer’s FRA and VM measurement results. The results showed problems with its mechanical condition, thus confirming that the proposed methods can be used in the practical assessment of transformers with these two diagnostic methods. The assessment of transformer’s active-part mechanical condition with complementary FRA and VM methods can be performed much more easily with the proposed quality indices. Full article

The present study encompasses a thorough analysis of the vibrations in a splash musical cymbal. The analysis is performed using a hybrid methodology that combines experimental measurements with parametric computer-aided design and finite element method simulations. Experimental measurements, including electronic speckle pattern interferometry, and impulse response measurements are conducted. The interferometric measurements are used as a reference for the evaluation of finite element method modal analysis results. The modal damping ratio is calculated via the impulse response measurements and is adopted by the corresponding simulations. Two different approximations are employed for the computer-aided design and finite element method models: one using three-point arcs and the other using lines to describe the non-smooth curvature introduced during manufacturing finishing procedures. The numerical models employing the latter approximation exhibit better agreement with experimental results. The numerical results demonstrate that the cymbal geometrical characteristics, such as the non-smooth curvature and thickness, greatly affect the vibrational behavior of the percussion instrument. These results are of valuable importance for the development of vibroacoustic numerical models that will accurately simulate the sound synthesis of cymbals. Full article

Bucket elevators generally operate on a 24/7 basis, and for this reason, one of the main requirements is their high reliability. This reliability can be ensured, among other things, by assessing the technical condition of drive assemblies and working assemblies and taking appropriate measures. Carrying out diagnostic measurements enables periodical monitoring of those mechanisms. Vibroacoustic methods are usually employed in operating conditions to measure vibration velocity and acceleration at specific points, and are used as diagnostic signals. This paper presents the results of tests of the intensity of vibrations generated in the drive unit of a large industrial bucket elevator. The analysis of the results in the time domain and frequency domain served as the basis for evaluating the suitability of the drive, and thus the elevator, for long-term operation. Full article

This article provides a comprehensive analysis of the feature extraction methods applied to vibro-acoustic signals (VA signals) in the context of robot-assisted interventions. The primary objective is to extract valuable information from these signals to understand tissue behaviour better and build upon prior research. This study is divided into three key stages: feature extraction using the Cepstrum Transform (CT), Mel-Frequency Cepstral Coefficients (MFCCs), and Fast Chirplet Transform (FCT); dimensionality reduction employing techniques such as Principal Component Analysis (PCA), t-Distributed Stochastic Neighbour Embedding (t-SNE), and Uniform Manifold Approximation and Projection (UMAP); and, finally, classification using a nearest neighbours classifier. The results demonstrate that using feature extraction techniques, especially the combination of CT and MFCC with dimensionality reduction algorithms, yields highly efficient outcomes. The classification metrics (Accuracy, Recall, and F1-score) approach 99%, and the clustering metric is 0.61. The performance of the CT–UMAP combination stands out in the evaluation metrics. Full article

The detection and location of pipeline leakage can be deduced from the time arrival leak signals measured by acoustic sensors placed at the pipe. Ongoing research in this field is primarily focused on refining techniques for accurately estimating the time delays. This enhancement predominantly revolves around the application of advanced signal processing methods. Additionally, researchers are actively immersed in the utilization of machine learning approaches on vibro-acoustic data files, to determine the presence or absence of leaks. Less attention has been given to evaluating the sensitivity, performance, and overall effectiveness of these sensors in leak detection; although acoustic methods have been successfully used for leak detection in metallic pipes, they are less effective in plastic pipes due to the high attenuation of leak noise signals. The primary thrust of this research centers on identifying sensors that not only possess sensitivity but also exhibit high efficiency. To accomplish this goal, we conducted an exhaustive evaluation of the performance of three distinct categories of acoustic sensors employed for detecting water leaks in plastic pipes: specifically, lead zirconate titanate (PZT) sensors, polyvinylidene fluoride (PVDF) sensors, and surface acoustic wave (SAW) sensors. Our evaluation encompassed the performance of PVDF and SAW sensors in leak detection, comparing them to PZT sensors under a variety of conditions, including different leak sizes, flow rates, and distances from the leak. The results showed that all three sensors, when they were placed in the same position, were able to detect water leaks in plastic pipes with different sensitivities. For small leaks (1 mm, 2 mm), the PVDF sensor showed the greatest sensitivity (0.4 dB/L/h, 0.33 dB/L/h), followed by the SAW sensor (0.16 dB/L/h, 0.14 dB/L/h), and finally the PZT (0.13 dB/L/h, 0.12 dB/L/h). Similarly, for larger leaks (4 mm, 10 mm), the PVDF sensor continued to show superior sensitivity (0.2 dB/L/h, 0.17 dB/L/h), followed by the SAW sensor (0.13 dB/L/h, 0.11), and finally the PZT sensor (0.12 dB/L/h, 0.1 dB/L/h), outperforming the PZT sensor. This suggests that SAW and PVDF sensors, have the potential to serve as valuable, cost-effective alternatives to traditional commercial leak noise transducers. The outcomes of this comparative study involving three acoustic sensors hold the potential to advance the development of robust and dependable systems for the detection of water leaks in plastic pipelines. Full article

The rapid development of electromobility is placing ever higher demands on new electric motor designs. This results in a gradual reduction in weight with a simultaneous increase in maximum torque. As a result, unfavorable phenomena, such as vibration and noise, can become apparent in the drivetrain. Modeling and evaluation of the acoustic noise sources of a traction motor are particularly important when it is used, for example, as the traction drive of an electric bus, where too high noise levels can have a negative impact on passengers. This article describes methods for analyzing and evaluating the root causes of noise that occurs in permanent magnet traction motors with a rotor in which the magnets have been placed inside the rotor (PMSM IPM). This paper presents an analysis of acoustic noise and forces acting in the air gap of a 240 kW motor with 60 stator slots and 2p = 10 (s60p20) as the number of pole pairs designed for bus and truck drives. To determine the dominant noise sources and evaluate their value, the forces acting in the air gap and their effect on the deflection of the outer surface of the stator yoke were calculated. The natural frequencies of the machine, their frequencies for the entire rotor speed range, and the frequency of vibration of the motor stator were calculated. Based on these data, the sound power level (A-SWL) was calculated at varying motor speeds. MANATEE software (EOMYS, 9, avenue de la Créativité, 59650 Villeneuve d’Ascq—FRANCE) from EOMYS was used to perform vibroacoustic calculations. The analysis results were also subjected to verification on a laboratory bench. Full article

This paper reviews the state-of-the-art approaches in defect localization and specifies the remaining questions and challenges. Furthermore, this study presents a novel defect localization methodology using the nonlinear interaction of primary Lamb wave modes and vibroacoustic modulation (VAM), combined with damage imaging, to address the current shortcomings of defect localization. The study investigates this methodology experimentally with respect to defect interpretation, resolution, and applicability. Two Lamb waves with high and low frequencies, one being continuous and the other a tone burst, were excited using two different piezoelectric sensors. The amplitude of the measured signal at the first sideband frequency was evaluated with a short-time Fourier transform (STFT) and used for damage imaging via the delay and sum method. This study also includes a discussion on identifying the source of nonlinearity reflected in the first sideband. The experimental measurements prove that the localization of defect nonlinearity is possible with high accuracy, without the need for a baseline measurement, and with a minimum number of sensors. Sensitivity measurements with respect to the required length of the high-frequency tone burst and the sensor arrangement were also conducted. Full article
