As an important option for energy storage projects, pumping stations can also generate electricity when the upstream has surplus water and the pump system operates as a turbine (PAT mode). When it switches from pump mode to PAT mode, the pump operation state changes significantly. This study adopts a numerical simulation to investigate the flow characteristics, time-frequency domain performance and chaotic features of pressure pulsation in a vertical mixed-flow pump device when it operates in different PAT modes. The results show that, when the pump operates in PAT mode, the flow in the straight passage remains smooth, but it deteriorates in the elbow-shaped draft tube, such as developing a spiral stream in the straight section, a disordered stream in the elbow section, and vortexes and flow separation at the beginning of the diffuser section, but it gradually becomes smooth after passing through the diffuser section. Under low-head PAT conditions, circumferential circulation cross flow occurs at the impeller inlet, reducing energy conversion efficiency. Under all PAT conditions, the flow on the blade surface near the hub is stable, but obvious vortexes happen near the shroud. As the head increases, the small-scale vortexes disappear on the mid-blade surface, and the flow becomes smoother on the blade surface near the shroud of the impeller. Except at the impeller outlet, pressure pulsation of the monitoring probes exhibits clear periodicity, with dominant frequencies corresponding to the rotational frequency, and its amplitudes decreasing from shroud to hub. Pressure pulsation under all PAT conditions is chaotic, and phase trajectories exhibit ring-shaped structures consisting of the ring circle and the ring surface. Differences in the circle spacing, size, and spatial position of the ring circle phase locus and ring surface phase locus are observed, and these variations are closely related to the PAT conditions. A correlative relationship exists between the chaotic correlation dimension and flow performance, which is of great significance for the condition monitoring and fault diagnosis of pump units. These findings not only enrich the theoretical research on the PAT mode of pumps, but also provide a reference for similar engineering applications and offer new insights into condition monitoring of hydraulic machinery. Full article

Vertical axial-flow pumps with bidirectional passages are widely used in applications requiring flow reversal. However, their unique inlet geometry often leads to asymmetric impeller inflow conditions. This study investigates the internal flow behavior and pressure pulsation characteristics of a vertical bidirectional axial-flow pump under design, critical stall, and deep stall conditions using unsteady Reynolds-averaged Navier–Stokes simulations combined with Fast Fourier Transform and wavelet analysis. Results show that the pump reaches peak efficiency at the design point, with critical and deep stall occurring at 0.6 Q_des and 0.5 Q_des, respectively. The head at the deep stall condition shows a further drop of 7.51% compared to the critical stall condition. This progressive performance degradation is attributed to vortex-induced blockage: it initiates with the intensification of the tip leakage vortex and evolves into large-scale separation vortices covering the suction surface under deep stall—a mechanism distinctly influenced by the bidirectional inlet’s stagnant water zone. Inlet asymmetry, reflected by a normalized velocity coefficient (V_n) below 0.6 in the stagnant water zone under design flow, is partially mitigated during stall due to flow confinement. Pressure pulsations at the blade leading edge are dominated by the blade passing frequency (BPF), with amplitudes under critical stall about 3.2 times those at design conditions. At the impeller outlet, critical stall produces a mixed dominant frequency (shaft frequency and BPF), whereas deep stall yields the highest pulsation amplitude (BPF ≈ 4.8 × the design value) resulting from extreme passage blockage. These findings clarify how bidirectional-inlet-induced vortices modulate stall progression and provide theoretical guidance for enhancing the operational stability of such pumps under off-design conditions. Full article

The aim of this study is to compare submerged vortical structures for a pump mounted in a pump intake without any anti-vortex devices (AVDs), with a trident-like AVD or with a cone AVD. Another aim is to compare the pump characteristics (head, efficiency, power input and radial forces) of these pump arrangements via CFD simulation along with experimental measurements in a closed circuit. The numerical simulation of unsteady multiphase flow is established by means of computational fluid dynamics (CFD) and the volume of fluid (VOF) method. To predict vortical structures in the vicinity of the pump suction bell, the unsteady Reynolds-averaged Navier–Stokes equations (URANS) are solved together with the scale-adaptive simulation (SAS) turbulence model. For each AVD configuration, integral characteristics like the head, power input, efficiency and forces acting on the pump rotor are also evaluated. The numerical results show that the configuration with the cone AVD exhibits the best performance (from the point of view of both hydraulic efficiency and vorticity strength), but it requires a larger distance between the intake bottom wall and the pump bellmouth. The submerged vortices are quite stable when using an AVD, but rather unsteady without any anti-vortex tool. Full article

Vertical low-permeability barriers are widely used to improve the stability and seepage resistance of flood embankments. The present study evaluates three barrier technologies—vibrating beam slurry walls (VBSWs), deep soil mixing (DSM), and low-pressure grout injection (LPG)—through a series of consolidated drained triaxial tests and permeability coefficient tests on soil samples collected from the sites where different barrier installation technologies were used. All three barrier installation methods produced substantial improvements in both mechanical and hydraulic performance: the effective angle of internal friction (φ′) increased by 3–6° in samples with a plasticity index near 3.5%, and coefficients of permeability dropped from 10⁻⁸–10⁻⁷ m/s in untreated soils to below 10⁻⁹ m/s in treated specimens. The key finding of the study is that the barrier performance varies by the technology and the soil type. According to the result, DSM is the most effective technology used in clay-rich soils (φ′ increased up to 4°); LPG achieved the lowest permeability (7 × 10⁻¹¹ m/s) in granular soils; and VBSWs balanced strength and impermeability, most effective in silty sands. Flow-pump tests further demonstrated that treated soils required much longer to stabilize under a constant flow rate and could sustain higher hydraulic gradients before reaching equilibrium. These findings show the importance of matching barrier technology to soil plasticity and liquidity characteristics and highlight saturation as essential for reliable laboratory evaluation. The results provide a scientific basis for selecting and designing vertical barriers in flood-preventing infrastructure, offering performance benchmarks for improving hydraulic and geotechnical structures. Full article

The guide vane mixed-flow pump is a crucial component in medium-to-low-head pumping stations. The guide vanes are mostly fixed in traditional designs. The efficiency of these pumps under off-design operating conditions tends to be low, leading to higher energy consumption. This study explores the design of an adjustable guide vane for the conventional guide vane of a mixed-flow pump at a certain pumping station. Through numerical simulations and two sets of three-factor, five-level orthogonal experiments, we investigate the impact of flow rate, guide vane angle, and impeller angle on efficiency. Through numerical simulation, we identify the optimal relationships between an impeller angle of ±2° and 0° and guide vane angles of ±6°, ±3°, and 0°, focusing on the entropy production rate (EPR) as a key performance metric. The results demonstrate that adjustable guide vanes significantly improve the performance of mixed-flow pumps under off-design conditions. Efficiency increases by up to 17.71% at high flow rates, and by up to 5.48% at low flow rates. Energy consumption is notably reduced. As the flow rate and impeller blade angle vary, the adjustable guide vane rotates to match with the impeller, enhancing flow adaptation, expanding the high-efficiency operating range, and reducing overall energy consumption. Full article

This study presents a numerical simulation of a pump’s performance during a power-cut event and connected hazards resulting from the failure of non-return flap valves. The vertical mixed-flow pumps with suction bells were mounted inside the suction basins of a pumping station. Different regimes of the pump operation during the time were analyzed based on the pump’s 4-quadrant characteristics and the dynamics of rotating parts in the pump, gearbox and electric engine. The resulting development of flow rates, rotor speed and forces in the course of time were used to analyze the hazards of failure of any pumping system component and the flooding of the suction object and its surroundings. The presented results show a deep insight into the flow phenomena in vertical mixed-flow pumps with suction bells during the runaway process and confirm that the developed methodology can be successfully applied to monitor the critical regimes in a pumping station in real time. The simulations were verified with some experimentally obtained data. Full article

With the aim of investigating the influence of guide vane meridians on the external characteristics and internal flow field of the mixed-flow pump device, this research constructed seven guide vane meridians and applied computational fluid dynamic (CFD) and entropy production theory to investigate the spread of hydraulic loss in a mixed-flow pump. As observed, when the guide vane outlet diameter D_gvo decreased from 350 mm to 275 mm, the head and efficiency increased by 2.78% and 3.05% at 0.7 Q_des, respectively. At 1.3 Q_des, when D_gvo increased from 350 mm to 425 mm, the head and efficiency increased by 4.49% and 3.71%, respectively. At 0.7 Q_des and 1.0 Q_des, the entropy production of the guide vane increased with the increase of D_gvo due to flow separation. When D_gvo < 350 mm, at 1.0 Q_des and 1.3 Q_des, entropy production of the outlet channel increased as D_gvo decreased owing to the excessive flow rate, but at 0.7 Q_des, entropy production did not change much. When D_gvo > 350 mm, at 0.7 Q_des and 1.0 Q_des, due to the expansion of the channel section, the flow separation intensified, which resulted in an increase of the entropy production, but the entropy production decreased slightly at 1.3 Q_des. These results provide guidance for improving the efficiency of pumping stations. Full article

The main factor for the proper functioning of the thermal generator-bubble pump of the diffusion-absorption cycles is the amount of heat required to maintain the necessary vaporization for pumping fluids. An excess of heat or the opposite reduces its efficiency. The present study aims to simulate the critical heat flux (CHF) and the onset nucleate boiling heat flux (ONBHF) versus mass flow in the generator-bubble pump of absorption-diffusion machines. The bubble pump studied is a vertical heated tube of diameter range is between 4 and 12mm, in which flowing an ammonia-water mixing. To achieve our goal a new approach based on the curves of the variation of the pressure drop as a function of the mass flow rate has been adopted. The pressure drops have been simulated using the two-fluid model. The critical heat fluxes simulated as a function of mass flow rate are compared with those obtained from four correlations. A good agreement has been obtained with the correlation of Shah and Zhang et al. Simulation results allow defining the optimum range of mass flow that should be used in the same application. We found that the mass flow rate should be higher than 40kg/m².s for the diameters of the studied tubes. Full article

The lateral bathymetry in the estuary results in different degrees of tidal mixing asymmetry, which has significant impacts on the longitudinal sediment transport by changing the temporal variation of vertical eddy diffusion. This study focus on the lateral variation of tidal mixing asymmetry and longitudinal sediment transport at the landward boundary of turbidity maximum zone in the North Channel of Yangtze estuary, which is a typical time-dependent salt wedge estuary. A transect survey was carried out in December, 2018; five vertical profiles of flow velocity, salinity and suspended sediment concentration were simultaneously measured covering a spring tidal cycle. Analysis of the data revealed that, after the maximum ebb, the stratification in the main and secondary channel was stronger than that on the shoal. In the channel, during ebb tide, the stronger stratification restrained the turbulent mixing induced by vertical shear, vertical mixing during the flood tide was stronger than that during ebb tide and vertical mixing coefficients ranged from 0.06 to 0.12, showing regular tidal mixing asymmetry over a flood–ebb tidal cycle. Therefore, stronger eddy diffusion caused by vertical mixing resulted in higher suspended sediment concentrations during flood tide, the larger landward tidally averaged sediment transport rate was induced by tidal pumping with the transportation of flood tidal current and the net sediment transport over a flood–ebb tidal cycle in the channel was landward. Meanwhile, on the shoal, under the effect of vertical shear, the vertical mixing during flood tide was weaker than that during ebb tide; vertical mixing coefficients ranged from −0.27 to −0.02, showing the reversed tidal mixing asymmetry. Higher suspended sediment concentration was transported seaward by the ebb current, the tidally averaged sediment transport rate by both tidal pumping and advection was seaward and the net sediment transport was seaward. Furthermore, large river discharge increased the seaward advection sediment flux on the surface layer in the main channel, resulting in the seaward tidally averaged sediment flux. Strong resuspension increased the seaward advection sediment flux near the bottom in the main and secondary channel, resulting in the seaward tidally averaged sediment flux. Full article

Impeller trimming is an economical method for broadening the range of application of a given pump, but it can destroy operational stability and efficiency. In this study, entropy production theory was utilized to analyze the variation of energy loss caused by impeller trimming based on computational fluid dynamics. Experiments and numerical simulations were conducted to investigate the energy loss and fluid-induced radial forces. The pump’s performance seriously deteriorated after impeller trimming, especially under overload conditions. Energy loss in the volute decreased after trimming under part-load conditions but increased under overload conditions, and this phenomenon made the pump head unable to be accurately predicted by empirical equations. With the help of entropy production theory, high-energy dissipation regions were mainly located in the volute discharge diffuser under overload conditions because of the flow separation and the mixing of the main flow and the stalled fluid. The increased incidence angle at the volute’s tongue after impeller trimming resulted in more serious flow separation and higher energy loss. Furthermore, the radial forces and their fluctuation amplitudes decreased under all the investigated conditions. The horizontal components of the radial forces in all cases were much higher than the vertical components. Full article

An experimental study on the flow pattern dynamics in a standard mixing vessel with radial baffles filled with water and induced by a pitched blade impeller pumping downward is presented. Investigation is mainly focused on detection and analysis of quasi-periodical or periodical low-frequency phenomenon connected with time- and length-scales considerably exceeding the Blade Passage Frequency (hereinafter BPF) and common turbulent eddies. This phenomenon, which is expressed as large-scale mean-flow variations, is generally known as flow Macro-Instability (hereinafter MI). It could break-down just below the liquid surface, or it crashes to the liquid surface and causes its Macro-Swelling (hereinafter MS). Our investigation was based on classical two-dimensional (2D) Particle Image Velocimetry (hereinafter PIV) measurement within 3 selected vertical planes in the vessel and subsequent analysis of the velocity field. The dominant frequencies evaluated in the selected points and overall analysis of the quasi-periodical macro-flow pattern behavior is to be shown. Identification of the quasi-periodical substructures appeared within the flow pattern was performed using the Oscillation Pattern Decomposition (hereinafter OPD) method. Observation of the macro-flow patterns confirmed presence of the macro-flow structures detected within flow pattern at the identical mixing pilot plant setup by previous investigations of the MIs phenomenon, i.e., the primary circulation loop and strong impeller discharge jet located in the lower vessel segment and the strong ascending wall current at the baffle, which break-down below the surface very often. A further important contribution of the presented work is the investigation of both flow pattern within the baffles vicinity and in the middle of the sector far from the baffle, showing a significant difference. Low-frequency periodical (or quasi-periodical) behavior of the investigated macro-structures was qualitatively confirmed by the presented results and it was quantified using the velocity dominant frequencies evaluation, as noted below. This frequency analysis brings insight into the supposed and detected interconnections between dynamics of the adjacent flow structures. Detected different flow patterns within the main plane near the baffles and in the inclined plane reveal a strong influence of the baffle presence to the local vertical flow, especially within the upper part of the vessel. Quite a different flow pattern appears tangentially in front of and behind the baffle, where a wake is revealed, indicating significant influence of the baffle on the local tangential flow. The new findings represent a contribution to better understanding the physical phenomena behind the standard mixing process. Full article

Some of the rivers in northern China are dried, and reclaimed water (RW) is used to restore these degraded river ecosystems, during which the RW could recharge the aquifer by river bank infiltration. From 2007 to 2018, 2.78 × 10⁸ m³ of RW has been replenished to the dried Chaobai River (Shunyi reach), Beijing, China, which is located on the edge of one depression cone in groundwater caused by groundwater over-pumping. The groundwater hydrodynamic variations and the flow path of the RW were identified by eight-year hydrological, hydrochemical, and stable isotopic data, together with multivariate statistical analysis. The RW infiltration drastically impacts the groundwater dynamics with a spatiotemporal variation. The 30-m depth groundwater levels at Perennial intake reach increased quickly around 3 m after 2007, which indicated that they were dominated by RW infiltration. Other 30-m depth groundwater levels were controlled by precipitation recharge from 2007 to 2011, showing significant seasonal variations. In 2012, with more RW transferred to the river, the hydrodynamic impact of the RW on 30-m depth aquifer expanded downstream. However, the 50-m and 80-m depth groundwater levels showed decreasing trend with seasonal variations, due to groundwater pumping. The 30-m depth aquifer was mainly recharged by RW, being evidenced by the enriched δ²H and δ¹⁸O. The depleted δ²H and δ¹⁸O of the 50-m and 80-m depth groundwater indicated that they were dominated by regional groundwater with meteoric origin. The heterogenous properties of the multi-layer alluvial aquifer offer the preferential flow path for RW transport in the aquifers. The proportion of the RW in the aquifers decreases with depth that was calculated by the chloride conservative mixing model. The increased lateral hydraulic gradient (0.43%) contributes to the RW transport in the 30-m depth aquifer. RW usage changed 30-m depth groundwater type from Ca·Mg-HCO₃ to Na·Ca·Mg-HCO₃·Cl. RW preferentially recharged the 50-m and 80-m depth aquifers by vertical leakage. Full article

In industrial devices like heat recovery systems, heat pumps, as well as symmetric and complex engineering systems, a nano fluid mixture is used. Regarding the nature of the energy sources (thermal or thermal and electrical), many physical systems could represent possible applications in manufactural activities. The presence of nanoparticles inside a solvent is of great interest in order to optimize the efficacy of the nano-technology systems. The present work deals with heat and mass transfer through a vertical channel where an alumina/water film mixture flows on one of its plates. For simulation, we use a numerical method under mixed convection during water/alumina nano fluid evaporation. We heat the flown plate uniformly while the other is dry and exchange heat with a constant coefficient. The gas mixture enters channel with a constant profile. Results show that an augmentation of the volume rate of the nanoparticle disadvantages evaporation if the heating is absent. Otherwise, if the heating exists, an increasing volume rate of the nanoparticle advantages evaporation. We found also that the film velocity behavior when the volume rate of the nanoparticle varies, independent of the heating. Full article

The model developed in this study presents a mathematical approach to the physiological transport of seminal liquid due to ciliary movements, which are attached with the lumen of the ductile efferent in the male reproductive system. The rheological properties of the seminal liquids were described using the Jeffrey liquid model. The problem described an electromagnetic mixed convective flow of a Jeffrey liquid through a vertical channel with heat and mass transfers. The effects of chemical reactions and the external heat generation were included in the formulation. The flow took place through an active porous medium (due to thick cilia mat and other deposits) and was influenced by the Lorentz magnetic force. Four basic conservation laws of mass, momentum, energy, and concentration were utilized in the mathematical modeling. These are highly nonlinear equations, which were simplified due to a physiologically valid approach known as LAT (lubrication approximation theory). Analytical solutions for temperature, concentration, and velocity profiles were evaluated. The expressions describing the pressure–volume flow rate relationships were also obtained. Analysis of various physical and geometrical factors affecting the pressure–volume (pumping) characteristics was also presented. One of the main findings of our study is that the difference between our calculated values of the flow rate and the estimated values of the flow rate in the ductile efferent was negligibly small. Moreover, our results can be implemented in the artificial cilia pumping systems in microchannels. Full article

We communicate the responses of various physiological fluids containing hemoglobin and other ionic constituents when they propagate in the presence of an electromagnetic body force field with the mechanisms of heat generation and conduction. A fully developed mixed convective flow of a Newtonian fluid takes place through a 2D vertical channel in the presence of an external magnetic field acting in the direction normal to the flow. The inner surface of the channel is carpeted with a thick mat of cilia, which propagates a sinusoidal metachronal wave travelling in the direction of flow. Coupled, nonlinear governing Naiver-Stokes and temperature equations are simplified by utilizing the creeping flow and long wavelength approximations. This enables us to formulate the exact analytical solution of the temperature distribution; whereas, the velocity distribution is evaluated from the momentum equations by using the Adomian decomposition method. In order to determine the pumping characteristics, the formulae of volume flow rate and the pressure rise are also obtained. Trapping due to the ciliary system is highlighted by graphing the stream function. The findings of the present model have significant outputs, which can be applicable in the physiological transport of human semen through the male reproduction system. Full article
