As a core component in renewable energy systems for grid regulation, hydropower units are increasingly exposed to flow conditions that elevate the risk of cavitation and erosion, posing significant challenges to the safe operation of flow-passage components. In this study, model testing and computational fluid dynamics (CFD) simulations are employed to investigate the hydraulic performance and cavitation behavior of a bulb turbine operating under rated head conditions and varying cavitation numbers. The analysis focuses on how changes in cavitation intensity affect flow characteristics and efficiency within the runner region. The results show that as the cavitation number approaches its critical value, the generation, growth, and collapse of vapor cavities increasingly disturb the main flow, causing a marked drop in blade hydraulic performance and overall turbine efficiency. Cavitation predominantly occurs on the blade’s suction side near the trailing edge rim and in the clearance zone near the hub, with bubble coverage expanding as the cavitation number decreases. A periodic inverse correlation between surface pressure and the cavitation area is observed, reflecting the strongly unsteady nature of cavitating flows. Furthermore, lower cavitation numbers lead to intensified pressure pulsations, aggravating flow unsteadiness and raising the risk of vibration. Full article

Accurate prediction of cavitating flows is essential for improving the performance and durability of marine and hydrodynamic systems. This study investigates the influence of different cavitation models—Kunz, Merkle, and Schnerr–Sauer—on the numerical prediction of cavitation around a hemispherical head-form body using computational fluid dynamics (CFD). Additionally, the effects of turbulence modeling approaches, including Reynolds-averaged Navier–Stokes (RANS) and partially averaged Navier–Stokes (PANS), are examined to assess their capability in capturing transient cavitation structures and turbulence interactions. The results indicate that the Schnerr–Sauer model, which incorporates bubble dynamics based on the Rayleigh–Plesset equation, provides the most accurate prediction of cavitation structures, closely aligning with experimental data. The Merkle model shows intermediate accuracy, while the Kunz model tends to overpredict cavity closure, limiting its ability to capture unsteady cavitation dynamics. Furthermore, the PANS turbulence model demonstrates superior performance over RANS by resolving more transient cavitation phenomena, such as cavity shedding and re-entrant jets, leading to improved accuracy in pressure distribution and vapor volume fraction predictions. The combination of the PANS turbulence model with the Schnerr–Sauer cavitation model yields the most consistent results with experimental observations, highlighting its effectiveness in modeling highly dynamic cavitating flows. Full article

Cavitation is a complex multiphase flow phenomenon, and the generation of transient phase transitions between liquid and vapor during cavitation development leads to multi-scale vortex motion. The transient cavitation dynamics and centrifugal pump’s rotor–stator interaction will induce pressure fluctuations in the impeller and the volute fluid of the centrifugal pump, resulting in a complex flow field structure. Based on the Schnerr–Sauer cavitation model and SST k-ω turbulence model, this paper studies the transient characteristics of the cavitation-induced unsteady flow in the centrifugal pump and the excitation response to the pressure pulsation in the volute under different flow conditions, taking the large vertical double-volute centrifugal pump as the research object. The results indicate the following: As the impeller rotates, in the external excitation response, the jet-wake flow structure at the centrifugal pump blade outlet shows an increase in the blade frequency signal. This is evident near the measurement points of the volute tongue and separator. When severe cavitation occurs, the maximum amplitude at the blade frequency in the volute shifts from the pump tongue (30°) to the downstream of the tongue (45°). The value of f_pmax is 3.1 times that when NPSHa = 8.88 m. By applying the Omega vortex identification method, it can be seen that the interaction between the vortices at the blade trailing edge and the stable vortex in the volute tongue undergoes a process of elongation, fusion, separation, and recovery. This represents the downstream influence of the impeller on the volute. When Q = 0.9Q_d, the process of the blade passage vortex tail detaching and dissipating in the impeller flow path can be observed, demonstrating the upstream influence of the volute on the impeller. Full article

A time-consistent upwind difference scheme with a preconditioned numerical flux for unsteady gas-liquid multiphase flows is presented and applied to the analysis of cavitating flows. The fundamental equations were formulated in general curvilinear coordinates to apply to diverse flow fields. The preconditioning technique was applied specifically to the numerical dissipation terms in the upwinding process without changing the time derivative terms to maintain time consistency. This approach enhances numerical stability in unsteady multiphase flow computations, consistently delivering time-accurate solutions compared to conventional preconditioning methods. A homogeneous gas-liquid two-phase flow model, third-order Runge-Kutta method, and the flux difference splitting upwind scheme coupled with a third-order MUSCL TVD scheme were employed. Numerical tests of two-dimensional gas-liquid single- and two-phase flows over backward-facing step with different step height and flow conditions successfully demonstrated the capability of the present scheme. The calculations remained stable even for flows with a very low Mach number of 0.001, typically considered incompressible flows, and the results were in good agreement with the experimental data. In addition, we analyzed unsteady cavitating flows at high Reynolds numbers and confirmed the effectiveness and applicability of the present scheme for calculating unsteady gas-liquid two-phase flows. Full article

This paper aims to numerically assess the cavitation damage of hydrodynamic machines and hydraulic components and its development in time, based on cavitation erosion tests with samples of used materials. The theoretical part of this paper is devoted to the numerical simulation of unsteady multiphase flow by means of computational fluid dynamics (CFD) and to the prediction of the erosive effects of the collapses of cavitation bubbles in the vicinity of solid surfaces. Compressible unsteady Reynolds-averaged Navier–Stokes equations (URANS) are solved together with the Zwart cavitation model. To describe the destructive collapses of vapor bubbles, the modeling of cavitation bubble dynamics along selected streamlines or trajectories is applied. The hybrid Euler–Lagrange approach with one-way coupling and the full Rayleigh–Plesset equation (R–P) are therefore utilized. This paper also describes the experimental apparatus with a rotating disc used to reach genuine hydrodynamic cavitation and conditions similar to those of hydrodynamic machines. The simulations are compared with the obtained experimental data, with good agreement. The proposed methodology enables the application of the results of erosion tests to the real geometry of hydraulic machines and to reliably predict the locations and magnitude of cavitation erosion, so as to select appropriate materials or material treatments for endangered parts. Full article

Tip leakage flow and induced unstable cavitation can significantly damage the performance of axial waterjet pumps. This study investigated the impact of blade numbers on cavitating conditions in an axial waterjet pump by conducting tests of performance characteristics and high-speed photography experiments on three-blade and four-blade impellers. The results showed that the critical cavitation number σ_c of the three-blade impeller was larger, while the four-blade impeller flow pattern deteriorated more rapidly after σ_c. Various cavitation structures in the tip region were observed under different conditions, including clearance cavitation, shear layer cavitation, tip leakage vortex cavitation, and suction-side-perpendicular cavitating vortices (SSPCVs). Tip cavitation maps of the test impellers were drawn based on the flow rate coefficient and cavitation number variation. The three-blade impeller exhibited a wider range of severe cavitation, particularly with an increased occurrence of SSPCVs. With the cavitation number and flow rate coefficient decreased, the SSPCV generated from triangular cavitation cloud shedding presented an increased trend in scale and quantity. Conversely, in the case of the four-blade impeller, SSPCVs were often disrupted by the adjacent blade during migration and interfered with the tip cavitation in the neighboring flow passage. Full article

The occurrence of cavitation in marine propellers is a major source of noise in ships. Consequently, the occurrence and noise characteristics of cavitation must be better understood to control this issue. This study focuses on identifying the occurrence and noise characteristics of cavitating flow around two-dimensional (2D) hydrofoils. Using the commercial computational fluid dynamics software STAR-CCM+, a numerical analysis was conducted on the partial cavity flow occurring around 2D hydrofoils at specific angles of attack. In addition, the cavitation noise characteristics were analyzed by conducting a frequency analysis using the predicted pressure data obtained via a fluctuating pressure sensor positioned vertically above the hydrofoil. Consequently, the numerical results were compared with existing experimental data to validate the accuracy of the simulation. This study identifies the limitations of the Reynolds-averaged Navier–Stokes (RANS) method by closely comparing it with the large eddy simulation (LES) method for assessing noise characteristics in unsteady cavitating flow. Although RANS has limitations in qualitatively assessing periodic behavior compared to LES, it effectively predicts cavitation extent and is valuable for relative assessments in practical applications. Full article

Focused on the unsteady property of a cavitating water jet issuing from an orifice nozzle in a submerged condition, this paper presents a fundamental investigation of the periodicity of cloud shedding and the mechanism of cavitation cloud formation and release by combining the use of high-speed camera observation and flow simulation methods. The pattern of cavitation cloud shedding is evaluated by analyzing sequence images from a high-speed camera, and the mechanism of cloud formation and release is further examined by comparing the results of flow visualization and numerical simulation. It is revealed that one pair of ring-like clouds consisting of a leading cloud and a subsequent cloud is successively shed downstream, and this process is periodically repeated. The leading cloud is principally split by a shear vortex flow along the nozzle exit wall, and the subsequent cloud is detached by a re-entrant jet generated while a fully extended cavity breaks off. The subsequent cavitation cloud catches the leading one, and they coalesce over the range of $x/d\approx 1.8~2.5$. Cavitation clouds shed downstream from the nozzle at two dominant frequencies. The Strouhal number of the leading cavitation cloud shedding varies from 0.21 to 0.29, corresponding to the injection pressure. The mass flow rate coefficient fluctuates within the range of $0.59~0.66$ at the same frequency as the leading cloud shedding under the effect of cavitation. Full article

Hydraulic vibrations in Francis turbines caused by cavitation profoundly impact the overall hydraulic performance and operational stability. Therefore, to investigate the influence of cavitation phenomena under high-load conditions, a three-dimensional unsteady numerical simulation is carried out for a Francis turbine with different head operating conditions, which is combined with the SST k-w turbulence model and two-phase flow cavitation model to capture the evolution of cavitation under high-load conditions. Additionally, utilizing entropy production theory, the hydraulic losses of the Francis turbine during cavitation development are assessed. Contrary to the pressure-drop method, the entropy production theory can quantitatively reflect the characteristics of the local hydraulic loss distribution, with a calculated error coefficient τ not exceeding 2%. The specific findings include: the primary sources of energy loss inside the turbine are the airfoil cavitation and cavitation vortex rope, constituting 26% and 71% of the total hydraulic losses, respectively. According to the comparison with model tests, the vapor volume fraction (VVF) inside the draft tube fluctuates periodically under high-load conditions, causing low-frequency pressure pulsation in the turbine’s power, flow rate, and other external characteristic parameters at 0.37 Hz, and the runner radial force fluctuates at a frequency of 1.85 Hz. Full article

A numerical method using combined detached-eddy simulation (DES) and a cavitation model considering the rotation effect is used for unsteady cavitation flow field of the centrifugal pump. A closed-type pump test system was established to obtain the pump performance and pressure pulsation characteristics under different flow rates and cavitation condition, which provide boundary conditions and verification of calculations. Based on the calculation results of the unsteady flow field of the centrifugal pump cavitation, the entropy generation analysis of the flow field and an analysis of the pressure fluctuation characteristics were carried out. Then, we tried to reveal the relationship between cavitation and the deterioration of the centrifugal pump performance and the generation of the unstable operation excitation force. The internal energy loss is mainly concentrated in the impeller, volute, and pump cavity area, which accounts for more than 85% of the total entropy generation. The characteristic frequency of a Strouhal number of about 0.333 appears at the volute tongue due to the cavitation flow spread downstream. Full article

Using the RNG k-ε turbulence model and a full cavitation model, this study numerically simulated cavitating flow-induced pressure fluctuations in a gerotor pump and analyzed the relationship between cavitating flow and pressure fluctuations. The results demonstrate that, as the inlet pressure decreases, the cavitation phenomenon in the gerotor pump intensifies, and the cavitation range in the rotor increases. Some of the vapor even spreads into the oil inlet groove, leading to high vapor content in the chamber that is in contact with the oil inlet groove. The pressure fluctuation characteristics of the flow field in the pump exhibit evident periodic changes. Under different cavitation conditions, the pressure fluctuation amplitude at the monitoring point decreases with increasing inlet pressure, whereas the main frequency of pressure fluctuation remains unaffected by cavitation conditions. The pressure fluctuation amplitude is the strongest at point O₁ of demarcation between the low-pressure and high-pressure zones in the chamber, and the volume between the oil inlet groove and the oil outlet groove serves as the main vibration source in the rotor pump. To ensure the stable and efficient operation of the gerotor pump, it is recommended to operate it at a larger NPSH. Full article

Cryogenic cavitation exhibits complexities primarily represented by the coupled interactions of thermodynamic effects, vortices, and cavities during the cavitation process. To further investigate this coupling mechanism, this study employed the DDES turbulence model and Sauer–Schnerr cavitation model to perform unsteady numerical simulations of liquid nitrogen cavitation flow around the NACA0015 Hydrofoil. Numerical validation of the model utilized a symmetrical Hord hydrofoil. The results reveal that the upstream development of the recirculation flow under inverse pressure gradients is the fundamental cause of the detachment in the primary cavitation region. At a cavitation number of 0.616, thermodynamic effects noticeably suppress the formation of cavities and alter the range of adverse pressure gradients, consequently influencing the detachment behavior in the primary cavitation region. Full article

To investigate the transient characteristics of high-speed axial flow water-jet pumps during start-up and emergency acceleration as well as to analyze how different accelerations affect the performance of internal flow, the k–ω turbulence model of the SST model and Zwart cavitation model were used to perform unsteady simulation on an impeller rotating at a speed of 1850. The steady-state numerical simulation method was verified by the experimental data, the numerical calculation results were basically consistent with the experimental data, the margin of error was within 5%, and the numerical simulation method was reliable. The results show that there was an obvious transient effect in the process of variable speed, and the thrust reached a stable state later than the speed. The buffer times for start-up times of 1 s, 2 s, and 3 s were 0.0394 s, 0.0375 s, and 0.0282 s, respectively, and the buffer times for the acceleration times of 0.5 s, 1.0 s, and 1.5 s were 0.0330 s, 0.0273 s, and 0.0230 s, respectively. The greater the acceleration, the more serious the flow rate and thrust lag behind the speed, and the greater the impact thrust. Under the same acceleration, the buffer time required in the start-up process was 19.3~22.6% longer than that in the acceleration process. During the change in speed of the high-speed water-jet pump, the vortex core area of the suction surface (SS) first appeared on the side of the shroud at the inlet, increased with the increase in the rotational speed, and developed toward the middle of the impeller. However, after the flow was stabilized, the vortex core region gradually shrank and eventually disappeared. When the rotational speed reached 0.6 times the design speed, cavitation occurred at the leading edge (LE) of the blade, and the cavitation area increased with the increase in the rotational speed. When reaching the same speed, the greater the acceleration, the more serious the cavitation. Under the design speed, that is, 6000 r/min, the cavitation volume fraction of the 1 s start-up process was 7.32%, the 2 s start-up process was 5.84%, the 3 s start-up process was 5.32%, and the 0.5 s acceleration process was 6.86%. The cavitation volume fraction of the 1 s acceleration process was 5.04%, and that of the 1.5 s acceleration process was 4.23%. Under the same acceleration, the cavitation volume fraction of the start-up process was 6.7~25% larger than that of the acceleration process. Compared with the start-up process and acceleration process under the same acceleration, the accelerated process had a smaller region of vortex core, stronger anti-cavitation ability, and more stable flow than the start-up process. During the actual operation process of the water-jet pump, it is advisable to use smaller accelerations and segmented accelerations as much as possible until the design speed is reached. The research findings serve as a foundation for future investigations into the transient characteristics of high-speed water-jet pumps operating under variable speed conditions. Full article

We perform large-eddy simulations to study a cavitating flow over a two-dimensional hydrofoil section—a scaled-down profile (1:13.26) of guide vanes of a Francis turbine—using the Schnerr–Sauer cavitation model with an adaptive mesh refinement in intensive phase transition flow areas. In the test case, the guide vane is tilted at an angle of attack of $9^{°}$ to the direction of the flow, in which the Reynolds number, based on the hydrofoil chord length, equals $1.32\times {10}^6$, thus providing a strong adverse pressure gradient along the surface. The calculated time-averaged turbulence characteristics are compared with those measured by particle image velocimetry to verify that the flow is correctly reproduced in numerical simulations using the procedure of conditional averaging proposed and tested in our previous investigation. A re-entrant jet is identified as the primary source of vapor cloud shedding, and a spectral analysis of the cavitating flow over the profile midsection is conducted. Two characteristic frequencies corresponding to the cases, when an attached cavity detaches completely (as a whole) and two partially from the hydrofoil, are found in the flow. The study reveals that the natural frequency of partial cavity shedding is three times higher than that of full detachments. The examined regime exhibits an oscillatory system with two oscillation zones related to cavitation surge instability and unsteady cloud cavitation resulting from the re-entrant jet. Conditional averaging correlates cavitation structures with pressure distributions, forces, and torque on the guide vane. This modeling approach captures the fine details of quasi-periodic cavitation dynamics, providing insights into unsteady sheet/cloud cavitation and offering a method for developing control strategies. Full article

Pump-jet propellers are currently the mainstream propulsion method for underwater vehicles, and cavitation is an important factor limiting the high speed and miniaturization of pump-jet propellers. In order to explore the cavitation performance of high-speed pump-jet propellers, based on the modified SST turbulence model and the Zwart cavitation model, a three-dimensional numerical simulation of unsteady internal cavitation flow was carried out by comparing the impeller with specific speed n_s = 1920 using FLUENT 2020R2 software. At the same time, the occurrence and development process of cavitation under 0.95 Q, 1.0 Q, and 1.05 Q conditions were analyzed (Q is the mass flow), the changes in gas volume fraction in the impeller channel were captured, the distribution characteristics of cavitation under different NPSH values were explored, and the change law of cavitation with time was determined. The results show that, when NPSH dropped to 95 m, the impeller cavitation first occurred under the 1.05 Q operating condition, and the impeller cavitation volume fraction was 0.0379525. When NPSH dropped to 85 m, the impeller cavitation occurred under the 1.0 Q operating condition, and the impeller cavitation volume fraction was 0.0185164. When NPSH dropped to 80 m, the impeller cavitation occurred under the condition of 0.95 Q, and the volume fraction of the impeller cavitation was 0.013541. The high-speed pump-jet propeller had better anti-cavitation ability with a small flow rate. The cavitation distribution law under the three operating conditions was similar; cavitation was first generated on the impeller inlet edge and near the shroud, and the vacuoles with large volumes were mostly concentrated on the impeller inlet side. As the NPSH gradually decreased, the entire flow channel was gradually occupied by vacuoles. As the flow decreased, the corresponding NPSH also decreased. When NPSH dropped to 50 m, the volume fraction of the impeller under all three operating conditions reached around 0.4. As the cavitation only occurred on the suction surface, the volume fraction of the cavitation on the suction surface exceeded 0.8, at which time the impeller had already undergone severe cavitation. Within a complete cycle, bubbles first appeared at the inlet edge of the impeller (measured near the shroud) and gradually spread toward the middle and rear of the impeller, ultimately covering the suction surface of the impeller. Under the design condition, the experimental results of the model pump were consistent with the numerical simulation results, and the error was only 2.68%, thus verifying the reliability of the numerical simulation. The research results provide a reference for the in-depth study of the cavitation performance of high-speed pump-jet propellers and provide a good theoretical basis and practical significance in the engineering field for the high-speed and miniaturization process of high-speed pump-jet propellers. Full article
