Underactuated robotic systems are appealing for industrial use due to their reduced actuator number, which lowers energy consumption and system complexity. Underactuated systems are, however, often affected by residual vibrations. This paper addresses the challenge of generating energy-optimal trajectories while imposing theoretical null residual (and yet practical low) vibration in underactuated systems. The trajectory planning problem is cast as a constrained optimal control problem (OCP) for a two-degree-of-freedom revolute–revolute planar manipulator. The proposed method produces energy-efficient motion while limiting residual vibrations under motor torque limitations. Experiments compare the proposed trajectories to input shaping techniques (ZV, ZVD, NZV, NZVD). Results show energy savings that range from 12% to 69% with comparable and negligible residual oscillations. Full article

In this paper, a robust tracking control problem for underactuated underwater vehicles in horizontal motion is investigated. The presented control scheme that performs the trajectory tracking task is a combination of the backstepping technique and the integral sliding mode control method using the inertial quasi velocities (IQVs) resulting from the inertia matrix decomposition. Unlike many known solutions, the proposed approach allows not only trajectory tracking, but also, due to the fact that IQV includes dynamic and geometric model parameters, allows us to obtain additional information about changes in vehicle behavior during movement. In this way, some insight into its dynamics is obtained. Moreover, the control strategy takes into account model inaccuracies and external disturbances, which makes it more useful from a technical point of view. Another advantage of this work is to indicate problems occurring during the implementation of trajectory tracking in algorithms with a dynamics model containing a diagonal inertia matrix, i.e., without inertial couplings. The theoretical results are illustrated by simulation tests conducted on two models of underwater vehicles with three degrees of freedom (DOF). Full article

This paper aims to solve the spatial trajectory tracking control problem of underactuated autonomous underwater vehicles (AUVs) in the presence of system parameter uncertainties and complex external disturbances. To accomplish this goal, a model–data-driven learning adaptive robust control (LARC) strategy is introduced for AUVs. Firstly, a serial iterative learning control (ILC) approach is introduced as feedforward compensation, and then the corresponding trajectory tracking error dynamics model, the Feedforward Compensation–Line of Sight (FFC-LOS) guidance law, and the feedforward compensation-based kinematics controller are designed. Secondly, the dynamics controller is designed for AUVs, which consists of a linear feedback term, a nonlinear robust feedback term, an adjustable model compensation term, and a fast dynamic compensation term. In this control framework, the robust control and fast dynamic compensation parts are utilized to deal with nonlinear uncertainties and disturbances, the projection-type adaptive control part solves the influence caused by the uncertainty of system parameters, and the serial ILC part that is a data-driven learning method can further improve the trajectory tracking accuracy for repetitive tasks. Finally, comparative simulations under different scenarios and different types of disturbances are performed to verify the effectiveness of the proposed control strategy for AUVs. Full article

Autonomous Underwater Vehicles (AUVs) have shown significant promise across various underwater applications, yet face challenges in dynamic environments due to the limitations of traditional motion planning methods while Artificial Potential Field (APF)-based control barrier functions focus solely on obstacle proximity and distance-based methods oversimplify obstacle geometries, and both fail to ensure safety and satisfy turning radius constraints for under-actuated AUVs in intricate environments. This paper proposes a robust Model Predictive Control (MPC) framework integrating an enhanced fast marching control barrier function, specifically designed for AUVs equipped with fully directional sonar systems. The framework introduces a novel improvement for moving obstacles by extending the control barrier function field propagation along the obstacle’s movement direction. This enhancement generates precise motion plans that ensure safety, satisfy kinematic constraints, and effectively handle static and dynamic obstacles. Simulation results demonstrate superior obstacle avoidance and motion planning performance in complex scenarios, with key outcomes including a minimum safety margin of 1.86 m in cluttered environments (vs. 0 m for A* and FMM) and 1.76 m in dynamic obstacle scenarios (vs. 0.13 m for MPC-APFCBF), highlighting the framework’s ability to enhance navigation safety and efficiency for real-world AUV deployments in unpredictable marine environments. Full article

Autonomy of underwater vehicles has become an imperative feature due to increasingly challenging deep sea mission scenarios. In particular, for trajectory-tracking problems of Autonomous Underwater Vehicles (AUVs), the use of Lyapunov theory tools in state-of-the-art methods is common practice. These often require special assumptions, according to the application considered, and ‘intuition’ for the choice of a control law, which often leads to conservative results. This article suggests a systematic analysis for the horizontal motion of an AUV which ensures global asymptotic stability for the closed loop system. A nonlinear underactuated AUV system is considered with linear and angular velocity constraints. The Takagi–Sugeno (TS) framework design is adopted for the representation of the original nonlinear system. The control law is synthesised using the standard parallel distributed compensation (PDC) control law structure and stability is guaranteed for the closed loop system. The design criteria are posed as linear matrix inequalities (LMIs) where sufficient conditions for the design of the control law are shown. The proposed approach can be easily adopted for different types of autonomous vehicles with minor modifications. Full article

With the growing adoption of Unmanned Aerial Vehicles (UAVs) in industrial and commercial sectors, the limitations of traditional under-actuated multirotors are becoming increasingly evident, particularly in manipulation tasks. Limited control over the thrust vector direction of the propellers, coupled with its interdependence on the vehicle’s roll, pitch, and yaw moments, significantly restricts manipulation capabilities. To address these challenges, this work presents a control framework for multirotor UAVs equipped with thrust-vectoring components, enabling enhanced control over the direction of lateral forces. The framework supports various actuator configurations by integrating fixed vertical propellers with horizontally mounted thrust-vectoring components. It is capable of handling horizontal thruster setups that generate forces in all directions along the x- and y-axes. Alternatively, it accommodates constrained configurations where the vehicle is limited to generating force in a single direction along either the x- or y-axis. The supported UAVs can follow transmitter commands, setpoints, or predefined trajectories, while the flight controller autonomously manages the propellers and thrusters to achieve the desired motion. Moment evaluations were conducted to assess the torsional capabilities of the vehicles by varying the angles of the thrusters during torsional tasks. The results demonstrate comparable torsional magnitudes to previously studied thrust-vectoring UAVs. Simulations with vehicles of varying inertia and dimensions showed that, even with large horizontal thruster offsets, the vehicles followed desired trajectories while maintaining stable horizontal orientation and smaller attitude variations compared to normal flight. Similar performance was observed with positive and negative vertical offsets, demonstrating the framework’s tolerance for thrusters outside the horizontal plane. Full article

Hand−tracking systems are widely employed for telemanipulating grippers with high degrees of freedom (DOFs) such as an anthropomorphic robotic hand (ARH). However, tracking human thumb motion is challenging due to the complex motion of the carpometacarpal (CMC) joint. Existing hand−tracking systems can track the motion of simple joints with one DOF, but most fail to track the motion of the CMC joint, or to do so, there is a need for expensive and intricately set up hardware systems. This research introduces and realizes an affordable and personalizable tracking device to capture the CMC joint Flexion/Extension and Abduction/Adduction motions. Tracked human thumb motion is mapped to a robot thumb in a hybrid approach: the proposed algorithm maps the CMC joint motion to the first two joints of the robot thumb, while joint mapping is established between the metacarpophalangeal and interphalangeal joints to the last two joints. When the tracking device is paired with a flex glove outfitted with bend sensors, the developed system provides the means to telemanipulate an ARH with a four-DOF thumb and one-DOF underactuated digits. A three-stage framework is proposed to telemanipulate the fully actuated robot thumb. The tracking device and framework were evaluated through a device operation and personalization test, as well as a framework verification test. Two volunteers successfully personalized, calibrated, and tested the device using the proposed mapping algorithm. One volunteer further evaluated the framework by performing hand poses and grasps, demonstrating effective control of the robot thumb for precision and power grasps in coordination with the other digits. The successful results support expanding the system and further evaluating it as a research platform for studying human–robot interaction in grasping tasks or in manufacturing, assistive, or medical domains. Full article

Advancements in underwater robotic fish have generated new requirements for diverse underwater scenarios, presenting challenges in attaining efficient and precise control, particularly in the realm of classical trajectory tracking. In response to the inherently nonlinear and underactuated characteristics of underwater robot control design, this study introduces a trajectory tracking backstepping control method for the planar motion of underactuated underwater robotic systems. The method is grounded in dung beetle optimization (DBO) backstepping control. Firstly, a dynamic model of a single-node tail-actuated robotic fish is introduced, and the model is averaged. Based on the averaged model and Lyapunov functions, the design of the backstepping control scheme is derived to ensure the stability of the control system. Subsequently, the derived backstepping control is further optimized through the application of the DBO optimization algorithm, then the optimal backstepping control (OBC) approach is presented. Finally, the proposed control scheme is applied to the simulation experiments with the robotic fish. The simulation results for straight-line tracking indicate that OBC is superior to the PID method in terms of overshoot performance, reducing the average overshoot from 0.23 to 0.02. Additionally, OBC reduces the average velocity error from 0.043 m/s (backstepping control) to 0.035 m/s, which is lower than that of the PID method, with an average velocity error of 0.054 m/s. In turn tracking, the simulation results reveal that OBC reduces the average velocity error from 0.067 m/s (backstepping control) to 0.055 m/s and demonstrates better performance than the PID method, with an average velocity error of 0.066 m/s. Under various disturbance conditions, the simulations reveal that OBC exhibits superior performance when compared to other control methods. Full article

Aiming at the uncertainty problem caused by the time-varying modeling parameters associated with ship speed in the course tracking control of underactuated surface vessels (USVs), this paper proposes a control algorithm based on the dynamic neural fuzzy model (DNFM). The DNFM simultaneously adjusts the structure and parameters during learning and fully approximates the inverse dynamics of ships. Online identification and modeling lays the model foundation for ship motion control. The trained DNFM, serving as an inverse controller, is connected in parallel with the fractional-order PI^λD^μ controller to be used for the tracking control of the ship’s course. Moreover, the weights of the model can be further adjusted during the course tracking. Taking the actual ship data of a 5446 TEU large container ship, simulation experiments are conducted, respectively, for course tracking, course tracking under wind and wave interferences, and comparison with five different controllers. This proposed controller can overcome the influence of the uncertainty of modeling parameters, tracking the desired course quickly and effectively. Full article

The aerial transportation system belongs to a symmetrical system and has recently garnered increasing attention from researchers due to its broad application range and convenient operation. The control difficulty of the aerial transportation system lies in the fact that the load is not directly actuated, posing a significant challenge for state-constrained control. Taking the motion of an unmanned aerial vehicle (UAV) suspension transportation system within complex pipelines as an example, this paper employs the the swept volume signed distance field (SVSDF) method to search for state boundaries, which is an aspect not considered or elaborated in many state-constrained control approaches. Furthermore, adaptive state-constrained control based on the radial basis function (RBF) neural network is utilized for the case of experiencing unknown air resistance. The convergence of the proposed method for underactuated and actuated state variables is theoretically demonstrated based on the Lyapunov technique. Compared with existing methods, the error integral index demonstrates that the proposed method displays better convergence capability in the simulation section when considering state constraints under disturbance and air resistance. Full article

Due to the singularity of Euler angles and the ambiguity of quaternions, to further expand the attitude reachable range of underactuated AUVs in the vertical plane, $SO\left(3\right)$ is used to represent the attitude change of underactuated AUVs. The transverse function of the attitude on $SO\left(3\right)$ is designed, and the exponential mapping method is used to construct the attitude kinematic controller of underactuated AUVs. Considering the changes in the model and ocean current during motion, interval type II fuzzy systems (IT2-FLSs) are used to estimate these changes. The backstepping method and the small gain theorem are adopted to design dynamic controllers to ensure the stability and robustness of the system. A novel saturation auxiliary system is designed to compensate for the influence of actuator saturation characteristics. Finally, the simulation results verify the effectiveness of the proposed controller and ensure the practical stabilization of the underactuated AUV attitude. Full article

Aiming to address the problem of underactuated unmanned surface vehicles (USVs) performing fixed-point operations at sea without dynamic positioning control systems, this paper introduces an original approach to positioning control: the virtual anchor control method. This method is applicable in environments with currents that change slowly and does not require prior knowledge of current information or vessel motion model parameters, thus offering convenient usability. This method comprises four steps. First, a concise linear motion model with unknown disturbances is proposed. Then, a motion planning law is designed by imitating underlying principles of ship anchoring. Next, an adaptive disturbance observer is proposed to estimate uncertainties in the motion model. In the last step, based on the observer, a sliding-mode method is used to design a heading control law, and a thrust control law is also designed by applying the Lyapunov method. Numerical simulation experiments with significant disturbances and tidal current variations are conducted, which demonstrate that the proposed method has a good control effect and is robust. Full article

When navigating dynamic ocean environments characterized by significant wave and wind disturbances, USVs encounter time-varying external interferences and underactuated limitations. This results in reduced navigational stability and increased difficulty in trajectory tracking. Controllers based on deterministic models or non-adaptive control parameters often fail to achieve the desired performance. To enhance the adaptability of USV motion controllers, this paper proposes a trajectory tracking control algorithm that calculates PID control parameters using an improved Deep Deterministic Policy Gradient (DDPG) algorithm. Firstly, the maneuvering motion model and parameters for USVs are introduced, along with the guidance law for path tracking and the PID control algorithm. Secondly, a detailed explanation of the proposed method is provided, including the state, action, and reward settings for training the Reinforcement Learning (RL) model. Thirdly, the simulations of various algorithms, including the proposed controller, are presented and analyzed for comparison, demonstrating the superiority of the proposed algorithm. Finally, a maneuvering experiment under wave conditions was conducted in a marine tank using the proposed algorithm, proving its feasibility and effectiveness. This research contributes to the intelligent navigation of USVs in real ocean environments and facilitates the execution of subsequent specific tasks. Full article

Intelligent robots are often used to explore various areas instead of humans. However, when the driving joint is damaged, the actuated robot degenerates to an underactuated robot, and the traditional control method is not suitable for the underactuated robot. In this work, a two-stage control approach for a planar prismatic–rotational (PR) underactuated robot is introduced. Firstly, we establish the dynamic model and describe the underactuated constraint between an underactuated rotational joint and active prismatic joint. Secondly, the trajectory with multiple parameters is planned to ensure that the two joints reach the target position. Based on underactuated constraints and the evaluation function, the differential evolution algorithm (DEA) is used to optimize these parameters. After that, in stage 1, we design the controller to move the active prismatic joint to the desired position. Meanwhile, the underactuated rotational joint is rotating freely. In stage 2, we design the controller for the active prismatic joint to track the planned trajectory. By means of this strategy, both joints reach their target locations simultaneously. The final simulation result demonstrates that this strategy is effective. Full article

This study proposes a new disturbance-observer-based adaptive distributed formation control scheme for multiple underactuated surface vehicles (USVs) subject to unknown synthesized disturbances under prescribed performance constraints. A modified sliding mode differentiator (MSMD) is applied as a nonlinear disturbance observer to estimate unknown synthesized disturbances, which contain unknown environmental disturbances and system modelling uncertainties, thus enhancing the robustness of the system. Based on this, we impose the time-varying performance constraints on the position tracking error between the neighboring USVs. A novel differentiable error transformation equation is embedded in the prescribed performance control, and an adaptive prescribed performance controller is constructed by employing the backstepping method to ensure that the position tracking error remains within the prescribed transient and steady performance, and each USV realizes collision-free formation motion. Furthermore, a novel second-order nonlinear differentiator is introduced to extract the derivative information of the virtual control law. Finally, the numerical simulation results verify the effectiveness of the proposed control scheme. Full article
