A two-phase closed thermosyphon (TPCT), a gravity-assisted heat pipe, is a highly efficient heat transmitter involving liquid–vapor phase change. It is used in many applications, including heat spreading, thermal management and control, and energy saving. The main objective of this study is to investigate the effects of the operating conditions for a thermosyphon used in solar water heaters. The study particularly focuses on the influence of the inclination angle. Thus, a comprehensive simulation model is developed using the volume of fluid (VOF) approach. Complex and related phenomena, including two-phase flow, phase change, and heat exchange, are taken into account. To implement the model, an open-source CFD toolbox based on finite volume formulation, OpenFOAM, is used. The model is then validated by comparing numerical results to the experimental data from the literature. The obtained results show that the simulation model is reliable for investigating the effects of various operating conditions on the transient and steady-state behavior of the thermosyphon. In fact, bubble creation, growth, and advection can be tracked correctly in the liquid pool at the evaporator. The effects of the designed operating conditions on the heat transfer parameters are also discussed. In particular, the optimal tilt angle is shown to be 60° for the intermediate saturation temperature (<50 °C) and 90° for the larger saturation temperature (>60 °C). Full article

Ground temperature conditions are key factors affecting the stability of cast-in-place pile foundations for transmission towers in permafrost regions. With global climate warming, the ground temperature environment in permafrost regions has undergone significant changes, leading to an increasing risk of disasters for these pile foundations. However, research on the prevention and control of pile foundation diseases caused by permafrost degradation is relatively limited, and engineering practices are insufficient. To address this, this study proposes embedding a two-phase closed thermosyphon (TPCT) inside a concrete pile foundation to create a composite structural system with both load-bearing and cooling functions. A mathematical model is developed to focus on the cooling performance and temperature control efficiency of the composite structure. The results indicate that: (1) The TPCT can alleviate, to some extent, the downward shift of the permafrost table around the transmission tower foundation due to climate warming. The cooling effect of the TPCT slows the rate of permafrost degradation, but its control effect on the permafrost table is limited. (2) The performance of the cast-in-place piles with an embedded TPCT is closely related to temperature, with an effective operational period from early October to late March each year. (3) This device effectively mitigates the impact of permafrost degradation due to climate change, significantly lowering the risk of foundation-related issues in transmission towers. The findings of this study are crucial for maintaining ground temperature stability in cast-in-place pile foundations for transmission projects in high-latitude permafrost areas, as well as enhancing the theoretical framework for pile foundation design. Full article

In comparison to borehole heat exchangers that rely on forced convection, super-long thermosyphons offer a more efficient approach to extracting shallow geothermal energy. This work conducted field tests on a super-long flexible thermosyphon (SFTS) to evaluate its heat transfer characteristics. The tests investigated the effects of cooling water temperature and the inclination angle of the condenser on the start-up characteristics and steady-state heat transfer performance. Based on the field test results, the study proposed a dynamic heat transfer modeling method for SFTSs using the equivalent thermal conductivity (ETC) model. Furthermore, a full-scale 3D CFD model for geothermal extraction via SFTS was developed, taking into account weather conditions and groundwater advection. The modeling validation showed that the simulation results aligned well with the temperature and heat transfer power variations observed in the field tests when the empirical coefficient in the ETC model was specified as 2. This work offers a semi-empirical dynamic heat transfer modeling method for geothermal thermosyphons, which can be readily incorporated into the overall simulation of a geothermal system that integrates thermosyphons. Full article

Given that two-phase closed thermosiphons (TPCT) are a prevalent and efficacious means of heat transfer. However, non-condensable gas (NCG) may potentially impact the heat transfer performance of the aforementioned devices. Nevertheless, the theoretical analysis of heat transfer in TPCT containing NCG is not fully comprehensive and therefore requires further supplementation by means of relevant experiments. This paper presents the development and experimental investigation of a theoretical heat transfer model for a TPCT containing NCG. The research encompasses the optimal fluid-filling ratio of R22 and R410a working fluid and the impact of NCG on heat transfer in the condenser section of TPCT. Experimental findings indicate that TPCT with R22 and R410a working fluids at a fluid-filling ratio of 60% and 50%, respectively, demonstrate excellent isotherm and heat transfer efficiency. The presence of NCG affects the condenser section heat transfer process of the vapor, leading to a 2 °C decrease in the average temperature of the condenser section of the TPCT (T_ca). In comparison with the TPCT without NCG, it was observed that an increase in the mass of NCG from 0.0097 to 0.0197 mol resulted in a reduction in the effective length of the condenser section (L_a) and effective heat transfer rate (κ) of R22 TPCT. The decrease in L_a was 75.1 mm, while the decrease in κ was 15.02%. Furthermore, at the same NCG mass, the effective heat transfer rate of R410a TPCT is evidently superior to that of R22 TPCT. The NCG in the TPCT can be removed by using a check valve. Nevertheless, this will result in a reduction in the fluid-filling ratio of the TPCT. The temperature of the R410a TPCT containing 0.0197 mol NCG with a fluid-filling ratio of 50% is comparable to that observed in fluid-filling ratio of 40% after the NCG is exhausted. Full article

Permafrost spans approximately 23–25% of the land in the northern hemisphere, primarily found in Russia, Canada, USA, and China. Numerous engineering projects, particularly those related to transportation, are situated within these permafrost regions. Due to the impact of highway construction and global warming, the permafrost beneath the infrastructure is deteriorating, leading to significant damage. Two phases closed thermosyphon (TPCT) is a widely accepted green countermeasure against the problem in permafrost regions. Although it has been applied to prevent permafrost degradation, their application presents significant challenges on account of the stronger endothermic action of asphalt pavement. This paper focused on a review of the thermosyphon technology and application in the permafrost. Moreover, the article highlighted the excellent working performance of the TPCT that improves the stability of the infrastructures and prevents it degrading due its excellent efficiency in terms of heat transfer. The industrial applications of the TPCT were also summarized, along with their limitations. Ultimately, the findings presented in this paper can offer crucial insights for future TPCT design and development in permafrost areas. Full article

The two-phase closed thermosyphon (TPCT) or wickless heat pipe has been widely considered as an extremely effective and low-cost heat removal device for various applications. A computational fluid dynamics (CFD) investigation of the TPCT can provide detailed information regarding its design and development. In this study, the effect of non-uniform heat-input profiles on a vertical TPCT has been investigated. A CFD model has been built to simulate the evaporation and condensation processes within the TPCT investigated, using a solver based on OpenFOAM which has been modified and validated against experimental data reported in the open literature. Four non-uniform heating profiles of the TPCT have been investigated, and the effects these have on the internal flow field within the pipe are discussed. Simulation results show that the non-uniform heat flux profiles can impact thermal performance depending on the overall heat loading and the heat flux profile. Full article

A metallic wire mesh screen, wire diameter of approximately 50 μm, is folded into ~80 “accordion-shaped” mini-channels and placed inside the evaporator package of a novel passive thermal management device for cooling overhead light-emitting diodes (LEDs) used in factory floors and high-bay facilities. The thermal power dissipated via these devices ranges between 75 W and 171 W. The channel walls (screen) wick liquid water from the porous wick (located centrally above the screen) and facilitate its evaporation. The closed-loop tests on this device confirm that the two-phase mixture quality exiting the evaporator is approximately 0.2. This paper presents a steady-state numerical model of this separated liquid–vapor flow in a single mini-rectangular channel (900 μm × 2000 μm, 4 cm long) with wire mesh-screen walls. The primary objective of the model is to estimate the pressure drops occurring in this two-phase flow. The model initially assumes a flat liquid–vapor interface along the channel and uses an iterative approach to estimate its final meniscus shape (curvature). In addition to the temperature distribution along the screen walls, this paper also discusses the velocity and pressure distributions in both liquid and vapor regions. It also helps understand the liquid–vapor interfacial shear in this flow configuration and proposes a flow-limiting condition for the device by predicting flow reversal in the channel. Full article

This study focused on the coupling heat transfer mechanism and the cooling efficiency of L-shaped two-phase closed thermosyphons (L-shaped TPCTs) in the wide subgrade of permafrost regions. Considering the fact that time–space dynamics change the effects of the air temperature, wind speed, and geotemperature, a coupled air temperature–L-shaped TPCT–subgrade soil heat transfer model was established using the ANSYS 15.0 software platform, and the rationality of the model was verified through measured data. The heat-transfer characteristics of the L-shaped TPCTs and the long-term thermal stability of the subgrade were studied under different inclination angles of the evaporator (α = 15°, 30°, 50°, 70°, and 90°). Then, the cooling effectiveness of a composite subgrade with TPCTs and an XPS insulation board was numerically calculated. The results show that the heat flux of the L-shaped TPCT was the greatest when α = 50°, and the heat flux reached the maximum value of 165.7 W·m⁻² in January. The L-shaped TPCT had a relatively good cooling effect on the subgrade as a whole when α = 50° and 70°, but the thawing depth at the center of the subgrade with L-shaped TPCTs reached 9.0 m below the ground surface in the 30th year. The composite subgrade with L-shaped TPCTs/vertical TPCT/XPS insulation board is an effective method to protect the permafrost foundation and improve the long-term thermal stability of the wide subgrade. The maximum heat flux of evaporation section of the L-shaped TPCT is 18.8% higher than that of the vertical TPCT during the working period of the TPCTs of the composite subgrade. Full article

A heat pipe is an energy-efficient heat transfer device that relies on evaporation and condensation processes for energy transfer. The main purpose of this study is to simulate a two-phase closed thermosyphon, at moderate temperature, that can be used in industrial applications such as steam power plants. After creating a computational network in the Gambit software, the thermosyphon is simulated in Fluent software using the VOF model. Special oil is employed as the working fluid. Based on the CFD results, the efficiency of the system reaches approximately 96%, and the thermal resistance decreases to 0.54 K/W. The contours of the boiling and evaporation process at differing filling ratios, ranging between 30–90%, is visually investigated and the best performance is obtained for 30% of the filling ratio in thermosyphon. At higher filling ratios, more giant bubbles are generated in thermosyphon, which can attach to the inner wall of the system and reduce the thermal performance. The steady-state condition is obtained 84 s after the start of the process. Full article

The Xing’anling Mountains are the second largest permafrost region in China. One of the important issues for highways in these regions is how to control the settlement during the operation period to meet the demand of road stability. This paper selects a typical permafrost embankment in the Daxing’anling Mountains permafrost region, presents the finite element models of the embankment, and verifies it using field monitoring data to study the thermal and deformation characteristics within 50 years after construction. Calculation results illustrate that the permafrost under the embankment has degraded significantly during the operation period of the highway and led to serious settlement. To prevent the degradation of permafrost, a series of models with two-phase closed thermosyphons (TPCTs) were established to analyze the cooling effect. The contribution of different factors, including install locations, depth, and shapes of the TPCTs, were assessed on their effects on cooling the permafrost and reducing the embankment settlement. Results show that the TPCTs have an excellent cooling effect on the permafrost embankment. However, as the TPCTs change the temperature distribution of the embankment, they will inevitably cause differential settlement. In order to ensure the cooling effect and reduce the differential settlement of the embankment, it is suggested that L-shaped TPCTs should be adopted in the remedial engineering. Full article

An experimental study is presented to account for the implementation of a two-phase closed thermosyphon pipe, for energy-saving purposes, in air conditioning systems in the context of COVID-19. The experimental setup consisted of a 0.5 m × 0.0127 m type L copper pipe which was employed as the body of the heat exchanger; an electric resistance heater of 0.1 m length located at the bottom; and a 0.25 m length water-cooled concentric condenser located at the top. The evaluation was conducted employing acetone, ethanol, and distilled water as working fluids; ranging the heat supplied at the evaporator from 25 to 125 W and the filling ratio from 20% to 40% of the total inner volume of the thermosyphon. From the data obtained, it was found that ethanol is the working fluid most susceptible to changes in operation conditions. Contrarily, distilled water was found to deliver consistent performance, up to a point that, for the analysed setup, it is considered to be independent of both, heat flow supplied at the evaporator and thermosyphon filling ratio. Meanwhile, acetone was found to be the only fluid tested that displays a directly proportional behaviour between heat absorption and dissipation. From compiling experimental data, response surfaces were constructed and used as direct and rough optimization tools. The information provided by this approach is considered to be particularly useful and is introduced for modelling and design purposes. Based on the results, it was found that acetone, within operation ranges of $34\%<\varphi <40\%$ and $75 \mathrm{W}<{\dot{Q}}_{Evap}<125 \mathrm{W}$, was the most suitable working fluid to use in a two-phase closed thermosyphon for energy-saving purposes in air conditioning applications. Full article

Currently, the growing need for efficient refrigeration resources in the industrial sector has led to an increasing interest in finding technologies with a higher heat removal potential and better cooling performance. Along these lines, two-phase liquid cooling appears to be a very interesting solution, with the CLTPT (closed-loop two-phase thermosyphon) being one of the leading alternatives. Most works in the scientific literature study loop thermosyphons that work in flow boiling conditions in steady state. The present paper analyzes the transient thermal behavior of a pool boiling CLTPT gravitational channel as a passive cooling system using NOVEC 649 as working fluid. The evaporator works with two submerged cylindrical heaters that represent different heat sources located in different positions. The initial transient behavior and consequent instabilities of a laboratory-scale facility were studied, followed by a stability analysis for various power inputs. Parameters such as temperature and pressure along the experimental setup were monitored, and the effects of internal pressure and room conditions were also tested. The results show some instabilities in the process to start the flow circulation and a relative stability and quick adaptation to changes when circulation is reached. The temperature in the evaporator chamber was highly homogeneous during the whole process; however, the temperature changes in the riser and the loop top were delayed with respect to the evaporator zone. The analysis shows several pressure and temperature raises before the vapor flux reaches the condenser. When the flow circulation is established, the system becomes highly stable and thermally homogeneous, decreasing the thermal resistance when increasing the power input. The stability analysis also showed that, when the system reaches the steady state, the changes in the power input produce a transient increase in the pressure and temperature of the fluid, followed by a quick decrease of the previous steady state values. The heat transfer analysis in the evaporator shows a higher heat flux on the upper heater caused by the buoyancy flow that rises from the lower heater. It was also observed that the lower heater reaches the CHF point with a lower heat flux. Full article

With the increasing trend toward the miniaturization of electronic devices, the issue of heat dissipation becomes essential. The use of phase changes in a two-phase closed thermosyphon (TPCT) enables a significant reduction in the heat generated even at high temperatures. In this paper, we propose a modification of the evaporation–condensation model implemented in ANSYS Fluent. The modification was to manipulate the value of the mass transfer time relaxation parameter for evaporation and condensation. The developed model in the form of a UDF script allowed the introduction of additional source equations, and the obtained solution is compared with the results available in the literature. The variable value of the mass transfer time relaxation parameter during condensation r${}_c$ depending on the density of the liquid and vapour phase was taken into account in the calculations. However, compared to previous numerical studies, more accurate modelling of the phase change phenomenon of the medium in the thermosyphon was possible by adopting a mass transfer time relaxation parameter during evaporation r${}_e$ = 1. The assumption of ten-fold higher values resulted in overestimated temperature values in all sections of the thermosyphon. Hence, the coefficient r${}_e$ should be selected individually depending on the case under study. A too large value may cause difficulties in obtaining the convergence of solutions, which, in the case of numerical grids with many elements (especially three-dimensional), significantly increases the computation time. Full article

In this study, we observed the Geyser phenomenon that occurs in a small-diameter two-phase closed thermosyphon (confinement number of 0.245). This phenomenon interferes with the natural circulation of the internal working fluid and increases the thermal resistance of the system. This study attempts to improve the thermal performance of the system using cellulose nanofiber as the working fluid and hydrophilic surface modification at the inner surface of the evaporator section. As a result, the total thermal resistance showed average reduction rates of 47.51%, 36.69%, and 22.56% at filling ratios of 0.25, 0.5, and 0.75, respectively. Full article

In this paper, the influence of wettability properties on the start-up characteristics of two-phase closed thermosyphons (TPCTs) is investigated. Chemical coating and etching techniques are performed to prepare the surfaces with different wettabilities that is quantified in the form of the contact angle (CA). The 12 TPCTs are processed including the same CA and a different CA combination on the inner surfaces inside both the evaporator and the condenser sections. For TPCTs with the same wettability properties, the introduction of hydrophilic properties inside the evaporator section not only significantly reduces the start-up time but also decreases the start-up temperature. For example, the start-up time of a TPCT with CA = 28° at 40 W, 60 W and 80 W is 46%, 50% and 55% shorter than that of a TPCT with a smooth surface and the wall superheat degrees is 55%, 39% and 28% lower, respectively. For TPCTs with combined hydrophilic and hydrophobic properties, the start-up time spent on the evaporator section with hydrophilic properties is shorter than that of the hydrophobic evaporator section and the smaller CA on the condenser section shows better results. The start-up time of a TPCT with CA = 28° on the evaporator section and CA = 105° on the condenser section has the best start-up process at 40 W, 60 W and 80 W which is 14%, 22% and 26% shorter than that of a TPCT with smooth surface. Thus, the hydrophilic and hydrophobic modifications play a significant role in promoting the start-up process of a TPCT. Full article
