Search Results (13)

This study uses the finite element (FE) software ABAQUS V 6.14to develop detailed, comprehensive numerical models of the behaviour of restrained structural subassemblies of corrugated web steel beams (SBCW) connected to concrete-filled tubular columns (CFTC) via reverse channel connection. Four different types of web corrugation profiles—trapezoidal (Trap), rectangular (Rec), sinusoidal (Sin), and triangular (Tria)—are numerically modelled and analyzed to evaluate the significance of their influence on structural behaviour. In addition, the effects of flange stiffeners at the point load and web slenderness are examined. Moreover, this study investigates the effects of using four different joint types of reverse channel connection: extended endplate, flush endplate, flexible endplate, and hybrid extended/flexible endplate on the behaviour of SBCW. It is concluded that, by means of corrugated webs for enhancing beam deformation capacity and strength, it is feasible for the beams to achieve a higher load-carrying capacity. The ultimate load of the beams with Trap and Rec corrugated web was higher than that for the flat web beam by about 22% and 18%, respectively, and with the same increase of 10.5% for Tria and Sin corrugation profiles. However, providing the corrugated web beams with flange stiffeners at the point load had a limited effect (+0.7% to +5.1% depending on profile). Moreover, increasing the web thickness to reduce the slenderness ratio (hw/tw) from 250 to 200 can be an effective solution to prolong their load-carrying capacity. In addition, using an extended or flush endplate gave the best behaviour of SBCW connected to concrete-filled tubular columns (CFTC) with an increase of (5.3–31.7%) and (25–30.9%) for flush endplate and extended endplate, respectively, compared to flexible endplate, depending on the web corrugation profile. Full article

This study investigates the mechanical behavior and fatigue performance of orthotropic steel bridge decks, with a focus on rib-to-deck welded connections and the impact of geometric symmetry on stress distribution. Two full-scale models with full-penetration butt welds were tested under static compression loads, yielding failure forces of 27 kN (experimental) and 26 kN (analytical), with only a 3% difference. Finite element simulations using ANSYS 16.1 validated these results and enabled parametric studies. Rib plate thicknesses ranging from 5 mm to 9 mm were analyzed to assess their influence on stress distribution and deformation. The geometric ratio h′/tr, which reflects the symmetry of the trapezoidal rib web, was found to be a critical factor in stress behavior. At h′/tr = 38 (tr = 7 mm), compressive and tensile stresses are balanced, demonstrating a symmetric stress field; at h′/tr = 33 (tr = 8 mm), and fatigue performance at the RDW root drops by 47%. Increasing h′/tr improves fatigue life by increasing the number of load cycles to failure. Stress contours revealed that compressive stress concentrates in the rib plate above the weld toes, while tensile stress localizes at the RDW root. The study highlights how symmetric geometric configurations contribute to balanced stress fields and improved fatigue resistance. Multiple linear regression analysis (SPSS-25) produced predictive equations linking stress values to applied load and geometry, offering a reliable tool for estimating stress without full-scale simulations. These findings underscore the importance of optimizing h′/tr and leveraging structural symmetry to enhance resilience and fatigue resistance in welded joints. This research provides practical guidance for improving the design of orthotropic steel bridge decks and contributes to safer, longer-lasting infrastructure. Full article

The rapid advancement of technology has increased our reliance on axial flux permanent magnet machines (AFPMMs), making Printed Circuit Boards (PCBs) essential for modern, lightweight designs. This study reviews PCB roles in AFPMMs for low- and high-power applications by examining research from 2019 to 2024. Using the PRISMA methodology, 38 articles from IEEE Xplore and Web of Science were analyzed. This review focuses on advancements in PCB manufacturing, defect mitigation, winding topologies, software tools, and optimization methods. A structured Boolean search strategy (“Printed Circuit Board” OR “PCB” AND “axial flux permanent magnet machine” OR “AFPM”) guided the literature retrieval process. Articles were meticulously screened using the Rayyan software for titles, abstracts, and content, with duplicate removal performed via the Mendeley software V2.120.0. Findings show significant progress in lightweight AFPMMs with PCBs, improving power quality and performance. Research activity over the 6 years showed inconsistent growth, with concentrated trapezoidal winding emerging as the dominant configuration, followed by distributed winding designs. These configurations were particularly applied in single stator double rotor (SSDR) coreless AFPM machines, characterized by minimal defects, minimal losses, and optimized single-layer winding designs utilizing tools such as ANSYS and COMSOL. Growing interest in double stator single rotor (DSSR) and multi-disk configurations highlights opportunities for innovative designs and advanced optimization techniques. Full article

In this paper, based on bionics, a flexible multi-band antenna is designed to mimic the structure of a spider’s web, which supports various communication standards such as 4G, 5G, and GPS. The antenna lays out multiple loop branches in a limited space to achieve wideband operations from 1.31 GHz to 2 GHz (42.4%), from 3.4 GHz to 4 GHz (16.2%), and from 5.1 GHz to 5.78 GHz (12.5%). The antenna selects 40 × 50 × 0.1 mm³ polyimide as the dielectric substrate and trapezoidal coplanar waveguide feed. A simulation and experimental analyses demonstrate that the antenna exhibits consistent performance when subjected to different bending scenarios. The design scheme utilizing a flexible dielectric substrate streamlines the integration process, offering a promising avenue for deployment in smart wireless devices. The results of the consistent tests and simulations demonstrate that the device meets the requisite standards for wireless communication. Full article

This study conducted experiments to investigate the flexural behavior of steel–concrete composite beams with U-shaped sections, utilizing cold-formed lipped channels as web components. To enhance both flexural and shear performance, trapezoidal plates were added to the lower sides of the composite beams. A total of ten specimens were fabricated, with variables defined according to the following criteria: presence of bottom tension reinforcement and bottom studs, thickness of the trapezoidal side plates (6 mm and 8 mm), and the welding method. Four-point bending tests were conducted, and all specimens exhibited typical flexural failure at the ultimate state. Specimens with bottom tension reinforcement, specifically those in the H5-T6 and H5-T8 series, demonstrated increases in ultimate load of 28.8% and 33.5%, respectively, compared to specimens without tension reinforcement. The use of lipped channels enabled full composite action between the concrete and the steel web components, eliminating the need for stud anchors. Additionally, it was confirmed that the plastic neutral axis, reflecting the material test strengths, was located within the concrete slab as intended. This study also compared the design flexural strengths, calculated using the yield stress distribution method from structural steel design standards such as AISC 360 and KDS 14, with the experimental flexural strengths. The comparison was used to evaluate the applicability of current design standards. Full article

Unlike straight web I-girders, the construction industry’s demand for corrugated web steel girders is increasing due to their high shear strength without needing transverse stiffeners. Although the corrugation fabrication cost could be high, savings on material, transportation, and erection costs can compensate for the expenditures needed to build flat-plated girders with stiffeners. This study investigates the shear behavior of straight and corrugated webs with different geometries and corrugation profiles (triangular and trapezoidal) through laboratory testing. Following a detailed parametric study, the results of the experimental program were used to formulate a reliability-based design optimization (RBDO) problem to achieve target reliability. When applied to two case studies related to girders of a building and a bridge, the RBDO demonstrated that it is possible to design girders with corrugated webs to achieve economic designs in terms of material volume in the range of 20% to 40% with thinner webs and without the need for transverse stiffeners. Full article

The use of corrugated webs in steel beams has become one of the most practical ways to increase the efficiency of beams in resisting loads, natural frequencies, and their resulting displacements. Such a practice has the benefit of achieving the same efficiency as beams with a flat web with a greater thickness. Consequently, the effect of the types of corrugated webs on the flexure mode shapes and natural frequencies in the steel beams has been investigated by analyzing 23 beams with flat and corrugated webs using the finite element (FE) numerical analysis technique. Hence, two flat web steel beams with and without stiffeners were experimentally tested and compared to FE numerical modeling results. Moreover, three types (trapezoidal, rectangular, triangular) of corrugated webs were tested and studied in addition to other parameters such as thickness, width, length, and angle. The investigation results show that FE numerical analysis is very highly accurate in predicting the natural frequencies and flexure mode shape changes of beams with corrugated webs. Accordingly, a saving of at least 33% in thickness could be realized as compared to the flat type. The triangular corrugated web is more efficient in the 1st mode shape, while rectangular is better for the other modes. The effectiveness of the angle for the triangular type in resisting mode shape and frequencies was clearly noticed, and decreases of 0.60 and 0.78, respectively, were recorded. It is also perceived that the effect of thickness and angle is linear for specified cases. Full article

The use of corrugated webs increases web shear stability and eliminates the need for transverse stiffeners in steel beams. Optimised regression learner techniques (ORLTs) are rarely used for calculating shear capacity in steel beam research. This study proposes a new approach for calculating the maximum shear capacity of steel beams with trapezoidal corrugated webs (SBCWs) by using ORLTs. A new shear model is proposed using ORLTs in accordance with plate buckling theory and previously developed formulas for predicting the shear strength of SBCWs. The proposed ORLT models are implemented using the regression learner toolbox of MATLAB software (2020b). The available data of more than 125 test results from different specimens prepared by previous researchers are used to create the model. In this study, web geometry and relevant web steel grades determine the shear capacity of SBCWs. Four regression methods are adopted. Results are compared with those of an artificial neural network model. The model output factor represents the ratio of the web vertical shear stress to the normalised shear stress. Shear capacity can be estimated on the basis of the resulting factor from the model. The proposed model is verified using two methods. In the first method, a series of tests are performed by the authors. In the second method, the results of the model are compared with the shear values obtained experimentally by other researchers. On the basis of the test results of previous studies and the current work, the proposed model provides an acceptable degree of accuracy for predicting the shear capacity of SBCWs. The results obtained using Gaussian process regression are the most appropriate because its recoded mean square error is 0.07%. The proposed model can predict the shear capacity of SBCWs with an acceptable percentage of error. The recoded percentage of error is less than 5% for 93% of the total specimens. By contrast, the maximum differential obtained is ±10%, which is recorded for 3 out of 125 specimens. Full article

Literature of Steel Beams with a thin-walled trapezoidal Corrugated Web (SBCWs) shows that the capacity of SBCWs is affected by both the fatigue cracks initiated along the inclined folds (IFs) and the maximal additional stress located in the middle of the IFs. An experimental investigation on the behaviour of hybrid SBCWs under flexure is presented in this paper. This study focuses on the effect of the welding IF between the web and flanges (IFs welded or non-welded), the horizontal-fold length (200, 260, and 350 mm), and transversal flange stiffeners on the failure mechanism of the SBCW under three line load. Accordingly, six hybrid specimens were fabricated, instrumented, and tested (five SBCW specimens and one specimen with a flat web). The test setup was designed to generate shear and a moment in the testing zone via three-point bending. The results indicated that non-welded IFs specimens with or without flange stiffeners failed owing to web tearing after web and flange local buckling. The failure mode of the specimen with continuous welding between the web and flanges was local flange buckling. Finally, the paper presents a comparison between the experimental results and the European Code to predict the capacity of the flange towards local buckling. It was concluded that the non-welding the IFs affected the inelastic behaviour and the capacity of the SBCWs. In addition, the bending resistance equations presented by EN 1993-1-5 can safely predict the test results of the non-welded inclined fold and yield a high safe variation. Full article

Clustering is more popular than the expert knowledge approach in Interval Fuzzy Type-2 membership function construction because it can construct membership function automatically with less time consumption. Most research proposed a two-fuzzifier fuzzy C-Means clustering method to construct Interval Fuzzy Type-2 membership function which mainly focused on producing Gaussian membership function. The other two important membership functions, triangular and trapezoidal, are constructed using the grid partitioning method. However, the method suffers a drawback of not being able to represent actual data composition in the underlying dataset. Some research proposed triangular and trapezoidal membership functions construction using readily formed Fuzzy Type-1 membership functions, which means it remains unclear how the membership functions are heuristically constructed using fuzzy C-Means outputs. The triangular and trapezoidal membership functions are important because previous works have shown that they may produce superior performance than Gaussian membership function in some applications. Therefore, this paper presents a structured literature review on generating triangular and trapezoidal Interval Fuzzy Type-2 membership functions using fuzzy C-Means. Initially, 110 related manuscripts were collected from Web of Science, Scopus, and Google Scholar. These manuscripts went through the identification, screening, eligibility, and inclusion processes, and as a result, 21 manuscripts were reviewed and discussed in this paper. To ensure that the review also covers the important components of fuzzy logic, this paper also reviews and discusses another 49 manuscripts on fuzzy calculation and operation. Furthermore, this paper also discusses the contributions of the conducted review to the body of knowledge, future research directions and challenges, with the aim to motivate the future works of constructing the methods to generate Interval Fuzzy Type-2 triangular and trapezoidal membership functions using fuzzy C-Means. The methods imply flexibility in choosing membership function type, hence increasing the effectiveness of fuzzy applications through leveraging the advantages that each of the three membership function types could provide. Full article

The aim of this study is to find out the degradation of dynamic behaviour of bridge girders with trapezoidal profiled webs when subjected to different vehicle moving loads. Finite element modelling based parametric analysis is demonstrated to be desirable in capturing the dynamic deflection and stress state of critical structural details of girders. The model is validated in the modal analysis through a comparison with theoretical eigenfrequencies. The vibration characteristics are shown to be significantly affected by the corrugation details. The structural service life results of analysed bridge girders are in close agreement with experimental data. It is shown that the dynamic nodal velocity and deflection of analysed bridge girders are greatly affected by the magnitude of the load corresponding to the overload of the vehicle in contrast to the vehicle travel speed. Similar observations can be made for the fatigue life prediction analysis related to the crack initiation when unfavourable effects of the overload vehicle are concerned. Presented analytical results using a fracture mechanics approach could be taken as a good basis for the service life assessment of related bridges with the desired level of performance or functionality. Full article

This article describes the development of a mathematical model of the reverse roll coating of a thin film for an incompressible non-isothermal magnetohydrodynamics $\left(MHD\right)$ viscoplastic fluid as it passes through a small gap between two rolls rotating reversely. The equations of motion required for the fluid added to the web are constructed and simplified using the lubrication approximation theory $\left(LAT\right)$. Analytical results are obtained for the velocity profile, pressure gradient, and temperature distribution. The pressure distributions and flow rate are calculated numerically using the trapezoidal rule and regular false position method, respectively. Some of these results are presented graphically, while others are shown in a tabular form. From the present analysis, it has been observed that the magnitude of pressure distributions increases by increasing the value of the involved parameters. It is worth mentioning that the velocities ratio and Brickman’s number are controlling parameters for the temperature distributions. The results indicate the strong effectiveness of the viscoplastic parameter and velocities ratio for the velocity and pressure distributions. It is also concluded that the coating of Casson material has been remarkably affected by the magnetohydrodynamics effects. Full article

Curved composite girder bridges with corrugated steel webs (CSWs) have already been constructed around the world. However, limited work has been done on their shear behavior. In this paper, the corrugated steel web (CSW) in horizontally curved girders (HCGs) is treated as an orthotropic cylindrical shallow shell, and the analytical formula for the elastic global shear buckling stress is deduced by the Galerkin method. Calculation tables for the global shear buckling coefficient for a four-edge simple support, for a four-edge fixed support, and for the two edges constrained by flanges fixed and the other two edges simply supported are given. Then, a parametric study based on a linear buckling analysis is performed to analyze the effect of the curvature radius and girder span on the shear buckling stress. Analytical and numerical results show that the difference of shear buckling stress of CSWs between curved girders and straight girders is small, so the shear design formulas for straight girders can be applied for curved girders. Finally, a series of tests were performed on three curved box girders with CSWs. Similar to CSWs in straight girders, the shear strain distributions of CSWs in HCGs are almost uniform along the direction of the web height and the principal strain direction angles are close to 45°. For the three specimens, CSWs carry about 76% of the shear force. In the destructive test, shear buckling after yielding occurred in all specimens which is in good agreement with the theoretical prediction, which means that the analytical formulas provide good predictions for the shear buckling stress of CSWs in HCGs and can be recommended for design purposes. Full article
