Search Results (21)

With increasing electrification and the connection of more renewable resources at the transmission level, bulk interconnected electric grids need to plan network expansion with new transmission facilities. The transmission expansion planning (TEP) problem is particularly challenging because of the combinatorial, integer optimization nature of the problem and the complexity of engineering analysis for any one possible solution. Network synthesis methods, that is, heuristic-based techniques for building synthetic electric grid models based on complex network properties, have been developed in recent years and have the capability of balancing multiple aspects of power system design while efficiently considering large numbers of candidate lines to add. This paper presents a methodology toward scalability in addressing the large-scale TEP problem by applying network synthesis methods. The algorithm works using a novel heuristic method, inspired by simulated annealing, which alternates probabilistic removal and targeted addition, balancing the fixed cost of transmission investment with objectives of resilience via power flow contingency robustness. The methodology is demonstrated in a test case that expands a 2000-bus interconnected synthetic test case on the footprint of Texas with new transmission to support 2025-level load and generation. Full article

In light of the growing complexity and demand in modern power systems, there is an increasing need for reliable, efficient, and flexible power flow control mechanisms. The Unified Power Flow Controller (UPFC), as a fundamental component of Flexible AC Transmission Systems (FACTSs), has garnered considerable attention due to its exceptional capabilities in regulating power flow and maintaining voltage stability. Nevertheless, the expense associated with high-capacity UPFCs is considerable, thereby rendering their practical implementation challenging. Phase-shifting transformers are less costly but require better power flow characteristics. Therefore, this paper puts forth the proposition of an Advanced Capacity-Expansion-Type Unified Power Flow Controller (ACET-UPFC) based on a single-core phase-shifting transformer (SCPST). This proposed topology is designed to enhance the capacity of the conventional UPFC, while maintaining similar power flow characteristics, and demonstrates strong voltage regulation capabilities, enabling connections across different voltage levels, thereby rendering it more economically feasible for large-scale deployment. This paper presents a detailed analysis of the power flow characteristics of the ACET-UPFC, including a theoretical foundation, mathematical modeling, and an investigation into the impact of various design parameters. Moreover, the ACET-UPFC’s capacity expansion capability and power flow characteristics are also examined. The ACET-UPFC is subjected to further investigation through the use of the PLECS simulation platform, thereby offering a more efficient and cost-effective solution for modern power grids. Full article

This study offers a modular isolated grid-connected DC/DC medium-voltage DC aggregation converter to support offshore full DC wind farms’ need for lightweight and highly efficient power aggregation and transmission. The converter can simultaneously have a smaller transformer size and lower switching frequency during operation through the dual-voltage stabilization three-loop control strategy and phase-shift modulation strategy, which greatly reduces the space occupied by the converter and lowers the switching loss, Additionally, the use of a two-level structure at a lower switching frequency has lower loss, which effectively reduces the cost of the power device compared with the commonly used three-level converter. The input series output series connection between the converter sub-modules effectively lowers the voltage stress on each power switching device and facilitates expansion into a multi-module structure, expanding its application in high-voltage and large-capacity environments. This study analyzes the two working modes of the DC/DC converter and its control approach, in addition to providing a detailed introduction to the application scenarios of this converter. Ultimately, the efficacy and practicability of the suggested topology and control scheme are confirmed by simulations and experiments. Full article

The European Union, in pursuit of the goal of reducing emissions by at least 55% by 2030 and achieving climate neutrality by 2050, is deploying different actions, with industry decarbonization as a key strategy. However, increasing electricity demand requires an intensification of energy generation from clean technologies, and the energy system’s expansion is hindered by renewable generation’s climatic dependencies and the imperative for substantial electrical infrastructure investments. Although the transmission grid is expected to grow, flexibility mechanisms and innovative technologies need to be applied to avoid an overwhelming growth. In this context, this paper presents a thorough assessment, conducted within the FLEXINDUSTRIES project, of the flexibility potential across seven energy-intensive industries (automotive industry, biofuel production, polymer manufacturing, steel manufacturing, paper mills, pharmaceutical industry, and cement production). The methodology followed during the analysis entails reviewing the state-of-the-art existing flexibility mechanisms, industries’ energy markets engagement, and technical/operational readiness. The results highlight the feasibility of the proposed actions for enabling energy market flexibility through demand-response programs, quantifying energy opportunities, and pinpointing regulatory and technical barriers. Full article

The reduction in PV prices and interest in energy independence accelerate the adoption of residential battery storage. This storage can support various functions of an energy system undergoing decarbonization. In this work, operative benefits of storage from the system perspective, namely, generation cost reduction and congestion mitigation, are investigated. Germany is chosen as a case study due to its strong reliance on variable renewable energy. For the analysis, an economic dispatch model with a high spatial resolution is coupled with a pan-European transmission grid model. It is shown that the system’s generation costs are highest when the assets are used only to maximize PV self-consumption, and the costs are lowest when the storage also reacts to the market dynamics. This amounts to a 6% cost reduction. Both operation strategies result in an equal level of grid congestion and infrastructure loading. This is improved with a strategy that accounts for regional peak reduction as a secondary objective. The high congestion level emphasizes that grid expansion needs to keep pace with the generation and electrification expansion necessary to decarbonize other sectors. Lastly, policymakers should enable multipurpose utilization, e.g., via the introduction of market-oriented retail electricity prices with intervention options for grid operators. Full article

Recently, the proportion of renewable energy (RE) sources in a power system has been increasing worldwide to reduce carbon emissions. To effectively accommodate renewable energy, there is a growing need to develop integrated planning strategies for both renewable energy sources and transmission lines in a power system, taking into account the location-specific characteristics of renewable energy. Economically viable and rapid system expansion plans are required to resolve the problem of delayed integration of renewable energy into existing power system, which arises due to inadequate transmission facilities. To address these problems, this paper presents an integrated economic evaluation method that considers the inherently uncertain output characteristics of renewable energy, contingent on location, the costs associated with installing transmission lines, and environmental benefits. The case study is conducted using a modified power system in Korea. In the case study, it is assumed that by integrating solar power generators in a low-demand area and wind power generators in a high-demand area, wind power plants have higher construction costs than solar power generators. However, the transmission costs for wind power plants are lower than those for solar power generators due to the regional characteristics of the power grid in the installation areas because renewable energy in high-demand areas typically requires less additional power infrastructure than in low-demand areas. The results of this study show that the net benefit for the wind power plant is estimated at USD 225.4 M, while the solar power plant yields a net benefit of USD 22.9 M in the example system. These results demonstrate the effectiveness of the proposed method, underscoring its potential to mitigate the challenges faced in the practical implementation of renewable energy projects. Full article

The US electric grid is facing operational, stability, and security challenges. Transmission system operators need some measure of visibility into distribution system renewable generation. Distribution system generation needs to support transmission system voltage. The grid is experiencing an expansion in measurement systems. How to take full advantage of this expansion and defend against attacks, both cyber and physical, poses additional challenges. This paper introduces software designed to meet these challenges. At the center of the software is an Integrated System Model (ISM) that spans from transmission to secondary distribution. The ISM is employed in real-time abnormality detection, voltage stability forecasting, and multi-mode control. The software architecture along with selected analysis modules is presented. Testing results are presented for: 1—attacks on utility infrastructure; 2—energy savings from optimal control; 3—distribution system control response during a low voltage transmission system event; 4—cyber-attacks on PV inverters, where physical inverters are used in hardware-in-the-simulation-loop studies. Contributions of this work include real-time analysis that spans from three-phase transmission through secondary distribution; an approach for detecting abnormalities that employs measurements from three independent measurement systems; and a multi-mode distribution system control that responds to cyber-attacks, physical attacks, equipment failures, and transmission system needs. Full article

The complexity and uncertainty of power sources connected to transmission networks need to be considered. Planners need information on the sustainability and economics of transmission network expansion planning (TNEP). This work presents a newly proposed method for TNEP that considers high-penetration solar energy by using the particle swarm optimization (PSO) algorithm. The power sources, thermal and hydropower plants, and conditions of load were set in the account, including an uncertain power source and solar energy (PV). The optimal sizing and locating of the PV to be connected to the network were determined by the PSO. The PV grid code was set in the account. The new line’s investment cost and equipment was analyzed. The PV cost was considered based on the power loss, and the system’s reliability was improved. The IEEE 118 bus test system and Lao PDR’s system were requested to test the proposed practice. The results demonstrate that the proposed TNEP method is robust and feasible. The simulation results will be applied to guide the power system planning of Lao PDR. Full article

The decarbonization of the energy sector puts additional pressure on the transmission network. The main cause for this is that renewable sources are often more abundant in geographical areas far away from the main demand centers, so new transmission lines are required to connect the new renewable energy capacity. In addition, by connecting different geographical zones, the transmission network could smooth the intermittency and the variability of renewable energy production. Thus, the changing energy landscape leads to a need to reinforce the transmission network through the Network Transmission Expansion Planning. Ideally, all the idiosyncrasies of the electricity system are considered in the operation and expansion planning process. However, several critical dimensions of the planning process are routinely ignored since they may introduce parameters that are difficult to quantify and complexity that state-of-the-art planning methods cannot handle. This paper identifies the most relevant elements related to the human factor, which have been grouped around the main topics: the human behind the technical, the human at the institutional level, and the human at the individual level. This paper also provides an additional formulation that can be used to upgrade existing models to include the human element and discusses the implications of these upgrades. Full article

Hydrogen technologies have been rapidly developing in the past few decades, pushed by governments’ road maps for sustainability and supported by a widespread need to decarbonize the global energy sector. Recent scientific progress has led to better performances and higher efficiencies of hydrogen-related technologies, so much so that their future economic viability is now rarely called into question. This article intends to study the integration of hydrogen systems in both gas and electric distribution networks. A preliminary analysis of hydrogen’s physical storage methods is given, considering both the advantages and disadvantages of each one. After examining the preeminent ways of physically storing hydrogen, this paper then contemplates two primary means of using it: integrating it in Power-to-Gas networks and utilizing it in Power-to-Power smart grids. In the former, the primary objective is the total replacement of natural gas with hydrogen through progressive blending procedures, from the transmission pipeline to the domestic burner; in the latter, the set goal is the expansion of the implementation of hydrogen systems—namely storage—in multi-microgrid networks, thus helping to decarbonize the electricity sector and reducing the impact of renewable energy’s intermittence through Demand Side Management strategies. The study concludes that hydrogen is assumed to be an energy vector that is inextricable from the necessary transition to a cleaner, more efficient, and sustainable future. Full article

Social acceptance is increasingly becoming a limiting factor in implementing the energy transition in Germany. From today’s perspective, the expansion of wind energy and future transmission grids is only somewhat a technical or economic challenge rather than a social one. Since political decisions on the energy system transformation are often derived from findings of energy system modeling, it seems necessary to increasingly integrate the effects of socio-ecological aspects, such as acceptance issues in energy models. In this paper, an approach is introduced to address effects of social acceptance in energy system models by comparing the influence of different distribution scenarios of wind energy in Germany on the expansion need for future transmission lines. The results show that a socio-ecologic distribution of onshore wind installations according to a balanced burden of the German society does not reduce the grid expansion need significantly compared to an economic siting. An actual reduction of planned transmission grids could just be achieved by a more decentral scenario, including decentral market design. The sensitivity of regionalization is an opportunity to consider local acceptance issues within energy system models and should move more into focus inside the procedure of the current grid development process in Germany. Full article

With the growing share of renewable energies in the electricity supply, transmission and distribution grids have to be adapted. A profound understanding of the structural characteristics of distribution grids is essential to define suitable strategies for grid expansion. Many countries have a large number of distribution system operators (DSOs) whose standards vary widely, which contributes to coordination problems during peak load hours. This study contributes to targeted distribution grid development by classifying DSOs according to their remuneration requirement. To examine the amendment potential, structural and grid development data from 109 distribution grids in South-Western Germany, are collected, referring to publications of the respective DSOs. The resulting data base is assessed statistically to identify clusters of DSOs according to the fit of demographic requirements and grid-construction status and thus identify development needs to enable a broader use of regenerative energy resources. Three alternative algorithms are explored to manage this task. The study finds the novel Gauss-Newton algorithm optimal to analyse the fit of grid conditions to regional requirements and successfully identifies grids with remuneration needs. It is superior to the so far used K-Means algorithm. The method developed here is transferable to other areas for grid analysis and targeted, cost-efficient development. Full article

Connection of a significant amount of distributed generation, such as solar photovoltaic (PV) capacity, may lead to problems in distribution networks due to violations of distribution network hosting capacity (HC) limits. HC enhancement techniques, such as energy storage, could increase the allowable PV penetration level in the distribution network, reducing the need for transmission and large-scale generation expansion. However, current approaches for transmission and generation expansion planning do not account for distribution network HC limits. As a consequence, it is hard to quantify the impact and benefits of HC enhancement in the context of long-term grid expansion planning. This paper presents a novel integrated planning approach, combining a two-stage transmission and generation expansion planning model with a distribution network hosting capacity assessment, which allows for inclusion of detailed distribution network constraints We test this method on a stylized representation of the Malaysian grid. Our results show that distribution constraints have a significant impact on optimal transmission expansion plans and significantly increase overall system costs. HC enhancement in the form of battery storage does not significantly mitigate this but does lead to a cost decrease regardless of distribution network constraints. We also show how our approach can identify the key interactions between transmission and distribution networks in systems with high levels of renewable and storage technologies. In particular, HC enhancement with battery storage can act as a substitute or complement to line investment, depending on the renewable energy penetration, the storage location and the level of coordination in the network. Full article

The energy transition towards renewable and more distributed power production triggers the need for grid and storage expansion on all voltage levels. Today’s power system planning focuses on certain voltage levels or spatial resolutions. In this work we present an open source software tool eGo which is able to optimize grid and storage expansion throughout all voltage levels in a developed top-down approach. Operation and investment costs are minimized by applying a multi-period linear optimal power flow considering the grid infrastructure of the extra-high and high-voltage (380 to 110 kV) level. Hence, the common differentiation of transmission and distribution grid is partly dissolved, integrating the high-voltage level into the optimization problem. Consecutively, optimized curtailment and storage units are allocated in the medium voltage grid in order to lower medium and low voltage grid expansion needs, that are consequently determined. Here, heuristic optimization methods using the non-linear power flow were developed. Applying the tool on future scenarios we derived cost-efficient grid and storage expansion for all voltage levels in Germany. Due to the integrated approach, storage expansion and curtailment can significantly lower grid expansion costs in medium and low voltage grids and at the same time serve the optimal functioning of the overall system. Nevertheless, the cost-reducing effect for the whole of Germany was marginal. Instead, the consideration of realistic, spatially differentiated time series led to substantial overall savings. Full article

High penetration of renewable power requires technical, organizational, and political changes. We use Q-method, a qualitative–quantitative technique, to identify and analyze views held by key actors on challenges for large-scale diffusion of wind power in Ceará State, Brazil, an early leader in wind power with 2.05 GW installed capacity. Four quantitatively determined social perspectives were identified with regard to views on challenges for wind power expansion: (1) failing because of the grid; (2) environmental challenges; (3) planning for wind, and (4) participating in wind. Each social perspective emphasizes a different array of barriers, such as cost of new transmission lines, transformation of a hydro-thermal mental model, predictive capacity for wind energy, and the need for participatory forum. Understanding the subjective views of stakeholders is a key first step in eventually reducing these barriers to renewable power penetration through diverse policy interventions. Full article
