Search Results (24)

Search Parameters:
Keywords = time-lapse geophysics

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
21 pages, 4359 KiB
Article
Identification of NAPL Contamination Occurrence States in Low-Permeability Sites Using UNet Segmentation and Electrical Resistivity Tomography
by Mengwen Gao, Yu Xiao and Xiaolei Zhang
Appl. Sci. 2025, 15(13), 7109; https://doi.org/10.3390/app15137109 - 24 Jun 2025
Viewed by 236
Abstract
To address the challenges in identifying NAPL contamination within low-permeability clay sites, this study innovatively integrates high-density electrical resistivity tomography (ERT) with a UNet deep learning model to establish an intelligent contamination detection system. Taking an industrial site in Shanghai as the research [...] Read more.
To address the challenges in identifying NAPL contamination within low-permeability clay sites, this study innovatively integrates high-density electrical resistivity tomography (ERT) with a UNet deep learning model to establish an intelligent contamination detection system. Taking an industrial site in Shanghai as the research object, we collected apparent resistivity data using the WGMD-9 system, obtained resistivity profiles through inversion imaging, and constructed training sets by generating contamination labels via K-means clustering. A semantic segmentation model with skip connections and multi-scale feature fusion was developed based on the UNet architecture to achieve automatic identification of contaminated areas. Experimental results demonstrate that the model achieves a mean Intersection over Union (mIoU) of 86.58%, an accuracy (Acc) of 99.42%, a precision (Pre) of 75.72%, a recall (Rec) of 76.80%, and an F1 score (f1) of 76.23%, effectively overcoming the noise interference in electrical anomaly interpretation through conventional geophysical methods in low-permeability clay, while outperforming DeepLabV3, DeepLabV3+, PSPNet, and LinkNet models. Time-lapse resistivity imaging verifies the feasibility of dynamic monitoring for contaminant migration, while the integration of the VGG-16 encoder and hyperparameter optimization (learning rate of 0.0001 and batch size of 8) significantly enhances model performance. Case visualization reveals high consistency between segmentation results and actual contamination distribution, enabling precise localization of spatial morphology for contamination plumes. This technological breakthrough overcomes the high-cost and low-efficiency limitations of traditional borehole sampling, providing a high-precision, non-destructive intelligent detection solution for contaminated site remediation. Full article
Show Figures

Figure 1

29 pages, 33650 KiB
Article
Comparison of Time-Lapse Ground-Penetrating Radar and Electrical Resistivity Tomography Surveys for Detecting Pig (Sus spp.) Cadaver Graves in an Australian Environment
by Victoria Berezowski, Xanthé Mallett, Dilan Seckiner, Isabella Crebert, Justin Ellis, Gabriel C. Rau and Ian Moffat
Remote Sens. 2024, 16(18), 3498; https://doi.org/10.3390/rs16183498 - 20 Sep 2024
Cited by 1 | Viewed by 2919 | Correction
Abstract
Locating clandestine graves presents significant challenges to law enforcement agencies, necessitating the testing of grave detection techniques. This experimental study, conducted under Australian field conditions, assesses the effectiveness of time-lapse ground-penetrating radar (GPR) and electrical resistivity tomography (ERT) in detecting pig burials as [...] Read more.
Locating clandestine graves presents significant challenges to law enforcement agencies, necessitating the testing of grave detection techniques. This experimental study, conducted under Australian field conditions, assesses the effectiveness of time-lapse ground-penetrating radar (GPR) and electrical resistivity tomography (ERT) in detecting pig burials as simulated forensic cases. The research addresses two key questions: (1) observability of graves using GPR and ERT, and (2) changes in geophysical responses with reference to changing climatic conditions. The principal novelty of this research is its Australian focus—this is the first time-lapse GPR and ERT study used to locate clandestine graves in Australia. The results reveal that both GPR and ERT can detect graves; however, ERT demonstrates greater suitability in homogeneous soil and anomalously wet climate conditions, with the detectability affected by grave depth. This project also found that resistivity values are likely influenced by soil moisture and decomposition fluids; however, these parameters were not directly measured in this study. Contrastingly, although GPR successfully achieved 2 m penetration in each survey, the site’s undeveloped soil likely resulted in inconsistent detectability. The findings underscore the significance of site-specific factors when employing GPR and/or ERT for grave detection, including soil homogeneity, climate conditions, water percolation, and body decomposition state. These findings offer practical insights into each technique’s utility as a search tool for missing persons, aiding law enforcement agencies with homicide cases involving covert graves. Full article
(This article belongs to the Special Issue Remote Sensing: 15th Anniversary)
Show Figures

Figure 1

34 pages, 7926 KiB
Article
An Integrated Hydrogeophysical Approach for Unsaturated Zone Monitoring Using Time Domain Reflectometry, Electrical Resistivity Tomography and Ground Penetrating Radar
by Alexandros Papadopoulos, George Apostolopoulos and Andreas Kallioras
Water 2024, 16(18), 2559; https://doi.org/10.3390/w16182559 - 10 Sep 2024
Cited by 4 | Viewed by 1534
Abstract
Continuous measurements of soil moisture in the deeper parts of the unsaturated zone remain an important challenge. This study examines the development of an integrated system for the continuous and 3-D monitoring of the vadose zone processes in a cost- and energy-efficient way. [...] Read more.
Continuous measurements of soil moisture in the deeper parts of the unsaturated zone remain an important challenge. This study examines the development of an integrated system for the continuous and 3-D monitoring of the vadose zone processes in a cost- and energy-efficient way. This system comprises TDR, ERT and GPR geophysical techniques. Their capacities to adequately image subsurface moisture changes with continuous and time-lapse measurements are assessed during an artificial infiltration experiment conducted in a characteristic urban site with anthropogenic fills and much compaction. A 3-D array was designed for each method to expand the information of a single TDR probe and obtain a broader image of the subsurface. Custom spatial TDR probes installed in boreholes made with a percussion drilling instrument were used for soil moisture measurements. Moisture profiles along the probes were estimated with a numerical one-dimensional inversion model and a standard calibration equation. High conductivity water used during all infiltration tests led to the detection of the flow by all techniques. Preferential flow was present throughout the experiment and imaged sufficiently by all methods. Overall, the integrated approach conceals each method’s weaknesses and provides a reliable 3-D view of the subsurface. The results suggest that this approach can be used to monitor the unsaturated zone at even greater depths. Full article
Show Figures

Figure 1

23 pages, 8230 KiB
Article
Feasibility Study and Results from a Baseline Multi-Tool Active Seismic Acquisition for CO2 Monitoring at the Hellisheiði Geothermal Field
by Fabio Meneghini, Flavio Poletto, Cinzia Bellezza, Biancamaria Farina, Deyan Draganov, Gijs Van Otten, Anna L. Stork, Gualtiero Böhm, Andrea Schleifer, Martijn Janssen, Andrea Travan, Franco Zgauc and Sevket Durucan
Sustainability 2024, 16(17), 7640; https://doi.org/10.3390/su16177640 - 3 Sep 2024
Cited by 4 | Viewed by 1465
Abstract
CO2 capture and underground storage, combined with geothermal resource exploitation, are vital for future sustainable and renewable energy. The SUCCEED project explores the feasibility of re-injecting CO2 into geothermal fields to enhance production and store CO2 for climate change mitigation. [...] Read more.
CO2 capture and underground storage, combined with geothermal resource exploitation, are vital for future sustainable and renewable energy. The SUCCEED project explores the feasibility of re-injecting CO2 into geothermal fields to enhance production and store CO2 for climate change mitigation. This integration requires novel time-lapse monitoring approaches. At the Hellisheiði geothermal power plant in Iceland, seismic surveys utilizing conventional geophones and a permanent fiber-optic helically wound cable (HWC) for Distributed Acoustic Sensing (DAS) were designed to provide subsurface information and CO2 monitoring. This work details the feasibility study and active seismic acquisition of the baseline survey, focusing on optical fiber sensitivity, seismic modeling, acquisition parameters, source configurations, and quality control. Post-acquisition signal analysis using a novel electromagnetic vibrating source is discussed. The integrated analysis of datasets from co-located sensors improved quality-control performance and geophysical interpretation. The study demonstrates the advantages of using densely sampled DAS data in space by multichannel processing. This experimental work highlights the feasibility of using HWC DAS cables in active surface seismic surveys with an environmentally friendly electromagnetic source, providing also a unique case of joint signal analysis from different types of sensors in high-temperature geothermal areas for energy and CO2 storage monitoring in a time-lapse perspective. Full article
(This article belongs to the Special Issue Carbon Capture, Utilization, and Storage (CCUS) for Clean Energy)
Show Figures

Figure 1

16 pages, 4658 KiB
Article
Assessing the Impact of Brackish Water on Soil Salinization with Time-Lapse Inversion of Electromagnetic Induction Data
by Lorenzo De Carlo and Mohammad Farzamian
Land 2024, 13(7), 961; https://doi.org/10.3390/land13070961 - 30 Jun 2024
Viewed by 1692
Abstract
Over the last decade, electromagnetic induction (EMI) measurements have been increasingly used for investigating soil salinization caused by the use of brackish or saline water as an irrigation source. EMI measurements proved to be a powerful tool for providing spatial information on the [...] Read more.
Over the last decade, electromagnetic induction (EMI) measurements have been increasingly used for investigating soil salinization caused by the use of brackish or saline water as an irrigation source. EMI measurements proved to be a powerful tool for providing spatial information on the investigated soil because of the correlation between the output geophysical parameter, i.e., the electrical conductivity, to soil moisture and salinity. In addition, their non-invasive nature and their capability to collect a high amount of data over broad areas and in a relatively short time makes these measurements attractive for monitoring flow and transport dynamics, which are otherwise undetectable with conventional measurements. In an experimental field, EMI measurements were collected during the growth season of tomatoes and irrigated with three different irrigation strategies. Time-lapse data were collected over three months in order to visualize changes in electrical conductivity associated with soil salinity. A rigorous time-lapse inversion procedure was set for modeling the soil salinization induced by brackish irrigation water. A clear soil response in terms of an increase in electrical conductivity (EC) in the upper soil layer confirmed the reliability of the geophysical tool to predict soil salinization trends. Full article
(This article belongs to the Special Issue Salinity Monitoring and Modelling at Different Scales)
Show Figures

Figure 1

19 pages, 9035 KiB
Article
Characterization of a Contaminated Site Using Hydro-Geophysical Methods: From Large-Scale ERT Surface Investigations to Detailed ERT and GPR Cross-Hole Monitoring
by Mirko Pavoni, Jacopo Boaga, Luca Peruzzo, Ilaria Barone, Benjamin Mary and Giorgio Cassiani
Water 2024, 16(9), 1280; https://doi.org/10.3390/w16091280 - 29 Apr 2024
Cited by 1 | Viewed by 2125
Abstract
This work presents the results of an advanced geophysical characterization of a contaminated site, where a correct understanding of the dynamics in the unsaturated zone is fundamental to evaluate the effective management of the remediation strategies. Large-scale surface electrical resistivity tomography (ERT) was [...] Read more.
This work presents the results of an advanced geophysical characterization of a contaminated site, where a correct understanding of the dynamics in the unsaturated zone is fundamental to evaluate the effective management of the remediation strategies. Large-scale surface electrical resistivity tomography (ERT) was used to perform a preliminary assessment of the structure in a thick unsaturated zone and to detect the presence of a thin layer of clay supporting an overlying thin perched aquifer. Discontinuities in this clay layer have an enormous impact on the infiltration processes of both water and solutes, including contaminants. In the case here presented, the technical strategy is to interrupt the continuity of the clay layer upstream of the investigated site in order to prevent most of the subsurface water flow from reaching the contaminated area. Therefore, a deep trench was dug upstream of the site and, in order to evaluate the effectiveness of this approach in facilitating water infiltration into the underlying aquifer, a forced infiltration experiment was carried out and monitored using ERT and ground-penetrating radar (GPR) measurements in a cross-hole time-lapse configuration. The results of the forced infiltration experiment are presented here, with a particular emphasis on the contribution of hydro-geophysical methods to the general understanding of the subsurface water dynamics at this complex site. Full article
(This article belongs to the Special Issue Application of Geophysical Methods for Hydrogeology)
Show Figures

Figure 1

23 pages, 4373 KiB
Article
Enhancing Image Alignment in Time-Lapse-Ground-Penetrating Radar through Dynamic Time Warping
by Jiahao Wen, Tianbao Huang, Xihong Cui, Yaling Zhang, Jinfeng Shi, Yanjia Jiang, Xiangjie Li and Li Guo
Remote Sens. 2024, 16(6), 1040; https://doi.org/10.3390/rs16061040 - 15 Mar 2024
Cited by 1 | Viewed by 1685
Abstract
Ground-penetrating radar (GPR) is a rapid and non-destructive geophysical technique widely employed to detect and quantify subsurface structures and characteristics. Its capability for time lapse (TL) detection provides essential insights into subsurface hydrological dynamics, including lateral flow and soil water distribution. However, during [...] Read more.
Ground-penetrating radar (GPR) is a rapid and non-destructive geophysical technique widely employed to detect and quantify subsurface structures and characteristics. Its capability for time lapse (TL) detection provides essential insights into subsurface hydrological dynamics, including lateral flow and soil water distribution. However, during TL-GPR surveys, field conditions often create discrepancies in surface geometry, which introduces mismatches across sequential TL-GPR images. These discrepancies may generate spurious signal variations that impede the accurate interpretation of TL-GPR data when assessing subsurface hydrological processes. In responding to this issue, this study introduces a TL-GPR image alignment method by employing the dynamic time warping (DTW) algorithm. The purpose of the proposed method, namely TLIAM–DTW, is to correct for geometric mismatch in TL-GPR images collected from the identical survey line in the field. We validated the efficacy of the TLIAM–DTW method using both synthetic data from gprMax V3.0 simulations and actual field data collected from a hilly, forested area post-infiltration experiment. Analyses of the aligned TL-GPR images revealed that the TLIAM–DTW method effectively eliminates the influence of geometric mismatch while preserving the integrity of signal variations due to actual subsurface hydrological processes. Quantitative assessments of the proposed methods, measured by mean absolute error (MAE) and root mean square error (RMSE), showed significant improvements. After performing the TLIAM–DTW method, the MAE and RMSE between processed TL-GPR images and background images were reduced by 96% and 78%, respectively, in simple simulation scenarios; in more complex simulations, MAE declined by 27–31% and RMSE by 17–43%. Field data yielded reductions in MAE and RMSE of >82% and 69%, respectively. With these substantial improvements, the processed TL-GPR images successfully depict the spatial and temporal transitions associated with subsurface lateral flows, thereby enhancing the accuracy of monitoring subsurface hydrological processes under field conditions. Full article
Show Figures

Figure 1

15 pages, 48647 KiB
Article
Three-Dimensional Amplitude versus Offset Analysis for Gas Hydrate Identification at Woolsey Mound: Gulf of Mexico
by Saiful Alam, Camelia Knapp and James Knapp
GeoHazards 2024, 5(1), 271-285; https://doi.org/10.3390/geohazards5010014 - 8 Mar 2024
Cited by 4 | Viewed by 2151
Abstract
The Gulf of Mexico Hydrates Research Consortium selected the Mississippi Canyon Lease Block 118 (MC118) as a multi-sensor, multi-discipline seafloor observatory for gas hydrate research with geochemical, geophysical, and biological methods. Woolsey Mound is a one-kilometer diameter hydrate complex where gas hydrates outcrop [...] Read more.
The Gulf of Mexico Hydrates Research Consortium selected the Mississippi Canyon Lease Block 118 (MC118) as a multi-sensor, multi-discipline seafloor observatory for gas hydrate research with geochemical, geophysical, and biological methods. Woolsey Mound is a one-kilometer diameter hydrate complex where gas hydrates outcrop at the sea floor. The hydrate mound is connected to an underlying salt diapir through a network of shallow crestal faults. This research aims to identify the base of the hydrate stability zone without regionally extensive bottom simulating reflectors (BSRs). This study analyzes two collocated 3D seismic datasets collected four years apart. To identify the base of the hydrate stability zone in the absence of BSRs, shallow discontinuous bright spots were targeted. These bright spots may mark the base of the hydrate stability field in the study area. These bright spots are hypothesized to produce an amplitude versus offset (AVO) response due to the trapping of free gas beneath the gas hydrate. AVO analyses were conducted on pre-stacked 3D volume and decreasing amplitude values with an increasing offset, i.e., Class 4 AVO anomalies were observed. A comparison of a time-lapse analysis and the AVO analysis was conducted to investigate the changes in the strength of the AVO curve over time. The changes in the strength are correlated with the decrease in hydrate concentrations over time. Full article
Show Figures

Figure 1

14 pages, 3921 KiB
Article
Research on 3D Time-Lapse Electric Field Inversion Algorithm for Controlled Source Audio-Frequency Magnetotelluric Method
by Qilong Sun, Handong Tan, Wei Wan and Qixuan Hu
Appl. Sci. 2024, 14(4), 1560; https://doi.org/10.3390/app14041560 - 15 Feb 2024
Cited by 7 | Viewed by 1516
Abstract
The controlled source audio-frequency magnetotelluric method (CSAMT) stands out for its economic efficiency and widespread application in geophysical monitoring. However, the separate inversion of time-lapse monitoring data encounters challenges in comparing and identifying abnormal changes due to variations in data fitting. Furthermore, the [...] Read more.
The controlled source audio-frequency magnetotelluric method (CSAMT) stands out for its economic efficiency and widespread application in geophysical monitoring. However, the separate inversion of time-lapse monitoring data encounters challenges in comparing and identifying abnormal changes due to variations in data fitting. Furthermore, the utilization of a method akin to Cagniard apparent resistivity for inversion necessitates the simultaneous observation of at least two components of the electromagnetic field, making it unsuitable for extensive three-dimensional observations. This paper proposes a 3D time-lapse electric field inversion algorithm for CSAMT, addressing the complexities in geophysical monitoring. The algorithm introduces two regularization factors and defines an objective function with both temporal and spatial constraints. Synthetic testing reveals the stability of the 3D time-lapse electric field inversion algorithm, demonstrating its effectiveness in delineating underground variations. This solution resolves the challenges posed by the independent inversion of time-lapse monitoring data. Full article
Show Figures

Figure 1

19 pages, 7686 KiB
Article
Estimating the Specific Yield and Groundwater Level of an Unconfined Aquifer Using Time-Lapse Electrical Resistivity Imaging in the Pingtung Plain, Taiwan
by Ding-Jiun Lin, Ping-Yu Chang, Jordi Mahardika Puntu, Yonatan Garkebo Doyoro, Haiyina Hasbia Amania and Liang-Cheng Chang
Water 2023, 15(6), 1184; https://doi.org/10.3390/w15061184 - 18 Mar 2023
Cited by 5 | Viewed by 3639
Abstract
This study aims to apply geophysical methods to determine the Specific Yield (Sy) and Groundwater Level (GWL) in an unconfined aquifer of the Pingtung Plain in South Taiwan. Sy is an important hydraulic parameter for assessing groundwater potential. Obtaining specific yield [...] Read more.
This study aims to apply geophysical methods to determine the Specific Yield (Sy) and Groundwater Level (GWL) in an unconfined aquifer of the Pingtung Plain in South Taiwan. Sy is an important hydraulic parameter for assessing groundwater potential. Obtaining specific yield for a large area is impractical due to the limited coverage and the high cost of the pumping test, which limits the potential evaluation of regional groundwater. Therefore, we used time-lapse Electrical Resistivity Imaging (ERI) to determine the Sy and GWL. Seasonal variations were considered when measuring time-lapse resistivity for five different months in 2019. We calculated the Sy and GWL from inverted resistivity data using empirical formulas and the soil–water characteristic curve (SWCC). We first used Archie’s law to calculate the relative saturation change with depth for each ERI profile, and then we used the Van Genuchten (VG) and Brooks–Corey (BC) empirical equations to estimate Sy and GWL. Finally, we compared the obtained GWL to the existing observation well to verify the findings of our study. The results showed that the VG and BC are able to predict Sy and GWL; however, the BC result is less consistent with the observation well result. In the study area, the dry season GWL ranged from 24.5 m to 35.2 m for the VG results and from 25.7 m to 35.5 m for the BC results. The wet season GWL ranged from 26.5 m to 38.9 m for the VG and from 26.4 m to 38.2 m for the BC results. The spatial distribution of the GWL shows a high gradient of GWL in the northeastern region, induced by significant proximal fan recharge. The determined spatial distribution of Sy varies from 0.15 to 0.21 for the VG and 0.14 to 0.20 for the BC results, indicating the study area has significant potential for groundwater resources. Therefore, nondestructive resistivity imaging can be used to aid in the determination of hydraulic parameters. Full article
(This article belongs to the Section Hydrogeology)
Show Figures

Figure 1

21 pages, 3572 KiB
Article
Seepage-Induced Pore Pressure Variations Beneath an Earthen Levee Measured with a Novel Seismic Tool
by Daniel Locci-Lopez and Juan M. Lorenzo
Geosciences 2023, 13(1), 20; https://doi.org/10.3390/geosciences13010020 - 12 Jan 2023
Cited by 3 | Viewed by 2465
Abstract
Shear-wave seismic reflection velocity-versus-depth models can complement our understanding of seepage pore pressure variations beneath earthen levees at locations between geotechnical sites. The seasonal variations of water level in the Mississippi River create pore pressure changes in the adjacent hydraulically connected aquifer on [...] Read more.
Shear-wave seismic reflection velocity-versus-depth models can complement our understanding of seepage pore pressure variations beneath earthen levees at locations between geotechnical sites. The seasonal variations of water level in the Mississippi River create pore pressure changes in the adjacent hydraulically connected aquifer on the protected side of artificial levees. Time-lapse shear-wave velocity analysis or repetition of seismic acquisition over an area is a non-invasive method that can detect seasonal pore pressure variations in shallow (<40 m) aquifers. The seismic reflection patterns during the seasonal pore pressure variations of the river show a distinctive change in the velocity semblance analysis, which is translated as a change in the average stress carried by the grain-to-grain contact, or simply the effective pressure. The seismic data show a greater variation of up to +140/−40 m/s or +700/−150 kPa in the confined aquifer zone, compared with the leaky confined aquifer zone of up to +46/−48 m/s or +140/−80 kPa. These relative effective pressure characteristics allow us to distinguish between confined and leaky aquifers and can be an optional approach for pressure prediction in floodplains along levees without the need to drill borings in the area to measure piezometric data. Full article
(This article belongs to the Section Geophysics)
Show Figures

Figure 1

17 pages, 8345 KiB
Article
Numerical Simulation of Hot Dry Rock Fracture Monitoring by Time-Lapse Magnetotelluric Method
by Lige Bai, Jing Li and Zhaofa Zeng
Energies 2022, 15(19), 7203; https://doi.org/10.3390/en15197203 - 30 Sep 2022
Cited by 3 | Viewed by 1766
Abstract
The spatial distribution of rock fractures during water injection in hot dry rock (HDR) geothermal is essential information for evaluating geothermal well fracturing. The rock fractures produce anisotropic electrical characteristics, which may facilitate geophysical methods for monitoring fracture distribution. This paper studies the [...] Read more.
The spatial distribution of rock fractures during water injection in hot dry rock (HDR) geothermal is essential information for evaluating geothermal well fracturing. The rock fractures produce anisotropic electrical characteristics, which may facilitate geophysical methods for monitoring fracture distribution. This paper studies the anisotropic magnetotelluric (MT) response in water injection fracturing based on the finite difference method (FEM). It uses the residual phase tensor (PT) method to calculate the characteristics of fracture strike and dip angle. The feasibility analysis of the technique under a different angle and resistivity conditions in geothermal reservoir investigation is discussed in detail. The results demonstrate that the MT can explain the characteristics of anisotropic resistivity structure changes from the water injection fracturing of HDR at the 5 km depth. The time-lapse MT monitoring method can provide a reliable scientific basis for fracture distribution direction and spreading characteristics. Full article
Show Figures

Figure 1

15 pages, 1585 KiB
Article
Geoelectrical Measurements to Monitor a Hydrocarbon Leakage in the Aquifer: Simulation Experiment in the Lab
by Luigi Capozzoli, Valeria Giampaolo, Gregory De Martino, Mohamed M. Gomaa and Enzo Rizzo
Geosciences 2022, 12(10), 360; https://doi.org/10.3390/geosciences12100360 - 29 Sep 2022
Cited by 9 | Viewed by 2769
Abstract
Hydrocarbons represent one of the most dangerous sources of contamination for environmental resources. Petroleum contaminants released from leaking fuel storage tanks or accidental spillages represent serious worldwide problems. Knowledge of the contaminant distribution in the subsoil is very complex, and direct measurements, such [...] Read more.
Hydrocarbons represent one of the most dangerous sources of contamination for environmental resources. Petroleum contaminants released from leaking fuel storage tanks or accidental spillages represent serious worldwide problems. Knowledge of the contaminant distribution in the subsoil is very complex, and direct measurements, such as boreholes or drillings, are strongly required. Even if the direct measurements define accurate information, on the contrary, they have low spatial coverage. Geophysics can effectively support conventional methods of subsoil sampling by expanding the information obtainable, providing to analyze, with higher resolution, larger areas of investigation. Consequently, different geophysical techniques have been used to detect the presence and distribution of hydrocarbons in the subsurface. Electrical resistivity tomography is an efficient geophysical methodology for studying hydrocarbon contamination. Indeed, this methodology allows for the reduction of the number of drillings or soil samples, and several papers described its success. One of the advantages is the possibility to successfully perform analyses in time-lapse to identify the degradation of the contaminants. Indeed, natural attenuation of hydrocarbon contaminants is observed under aerobic conditions due to biodegradation, which should be the principal phenomenon of physical variations of the subsoil. Therefore, a laboratory experiment was conducted in a sandbox to simulate a spillage of common diesel occurring in the vadose zone. The sandbox was monitored for a long period (1 year, approximately) using time-lapse cross borehole electrical resistivity tomographies. Results highlight the usefulness of in-hole electrical tomography for characterizing underground hydrocarbon leakage and the variability of the subsurface physical behavior due to contaminant degradation. Therefore, the experiment demonstrates how the electrical method can monitor the biodegradation processes occurring in the subsoil, defining the possibility of using the methodology during remediation activities. Full article
(This article belongs to the Special Issue Geo-Hydrological Risks Management, Volume II)
Show Figures

Figure 1

39 pages, 79946 KiB
Article
Airborne Validation of ICESat-2 ATLAS Data over Crevassed Surfaces and Other Complex Glacial Environments: Results from Experiments of Laser Altimeter and Kinematic GPS Data Collection from a Helicopter over a Surging Arctic Glacier (Negribreen, Svalbard)
by Ute C. Herzfeld, Matthew Lawson, Thomas Trantow and Thomas Nylen
Remote Sens. 2022, 14(5), 1185; https://doi.org/10.3390/rs14051185 - 27 Feb 2022
Cited by 15 | Viewed by 4181
Abstract
The topic of this paper is the airborne evaluation of ICESat-2 Advanced Topographic Laser Altimeter System (ATLAS) measurement capabilities and surface-height-determination over crevassed glacial terrain, with a focus on the geodetical accuracy of geophysical data collected from a helicopter. To obtain surface heights [...] Read more.
The topic of this paper is the airborne evaluation of ICESat-2 Advanced Topographic Laser Altimeter System (ATLAS) measurement capabilities and surface-height-determination over crevassed glacial terrain, with a focus on the geodetical accuracy of geophysical data collected from a helicopter. To obtain surface heights over crevassed and otherwise complex ice surface, ICESat-2 data are analyzed using the density-dimension algorithm for ice surfaces (DDA-ice), which yields surface heights at the nominal 0.7 m along-track spacing of ATLAS data. As the result of an ongoing surge, Negribreen, Svalbard, provided an ideal situation for the validation objectives in 2018 and 2019, because many different crevasse types and morphologically complex ice surfaces existed in close proximity. Airborne geophysical data, including laser altimeter data (profilometer data at 905 nm frequency), differential Global Positioning System (GPS), Inertial Measurement Unit (IMU) data, on-board-time-lapse imagery and photographs, were collected during two campaigns in summers of 2018 and 2019. Airborne experiment setup, geodetical correction and data processing steps are described here. To date, there is relatively little knowledge of the geodetical accuracy that can be obtained from kinematic data collection from a helicopter. Our study finds that (1) Kinematic GPS data collection with correction in post-processing yields higher accuracies than Real-Time-Kinematic (RTK) data collection. (2) Processing of only the rover data using the Natural Resources Canada Spatial Reference System Precise Point Positioning (CSRS-PPP) software is sufficiently accurate for the sub-satellite validation purpose. (3) Distances between ICESat-2 ground tracks and airborne ground tracks were generally better than 25 m, while distance between predicted and actual ICESat-2 ground track was on the order of 9 m, which allows direct comparison of ice-surface heights and spatial statistical characteristics of crevasses from the satellite and airborne measurements. (4) The Lasertech Universal Laser System (ULS), operated at up to 300 m above ground level, yields full return frequency (400 Hz) and 0.06–0.08 m on-ice along-track spacing of height measurements. (5) Cross-over differences of airborne laser altimeter data are −0.172 ± 2.564 m along straight paths, which implies a precision of approximately 2.6 m for ICESat-2 validation experiments in crevassed terrain. (6) In summary, the comparatively light-weight experiment setup of a suite of small survey equipment mounted on a Eurocopter (Helicopter AS-350) and kinematic GPS data analyzed in post-processing using CSRS-PPP leads to high accuracy repeats of the ICESat-2 tracks. The technical results (1)–(6) indicate that direct comparison of ice-surface heights and crevasse depths from the ICESat-2 and airborne laser altimeter data is warranted. Numerical evaluation of height comparisons utilizes spatial surface roughness measures. The final result of the validation is that ICESat-2 ATLAS data, analyzed with the DDA-ice, facilitate surface-height determination over crevassed terrain, in good agreement with airborne data, including spatial characteristics, such as surface roughness, crevasse spacing and depth, which are key informants on the deformation and dynamics of a glacier during surge. Full article
Show Figures

Figure 1

16 pages, 6030 KiB
Review
Time-Lapse Electrical Resistivity Tomography (TL-ERT) for Landslide Monitoring: Recent Advances and Future Directions
by Vincenzo Lapenna and Angela Perrone
Appl. Sci. 2022, 12(3), 1425; https://doi.org/10.3390/app12031425 - 28 Jan 2022
Cited by 39 | Viewed by 8729
Abstract
To date, there is a growing interest for challenging applications of time-lapse electrical resistivity tomography (TL-ERT) in Earth sciences. Tomographic algorithms for resistivity data inversion and innovative technologies for sensor networks have rapidly transformed the TL-ERT method in a powerful tool for the [...] Read more.
To date, there is a growing interest for challenging applications of time-lapse electrical resistivity tomography (TL-ERT) in Earth sciences. Tomographic algorithms for resistivity data inversion and innovative technologies for sensor networks have rapidly transformed the TL-ERT method in a powerful tool for the geophysical time-lapse imaging. In this paper, we focus our attention on the application of this method in landslide monitoring. Firstly, an overview of recent methodological advances in TL-ERT data processing and inversion is presented. In a second step, a critical analysis of the main results obtained in different field experiments and lab-scale simulations are discussed. The TL-ERT appears to be a robust and cost-effective method for mapping the water-saturated zones, and for the identification of the groundwater preferential pathways in landslide bodies. Furthermore, it can make a valuable contribution to following time-dependent changes in top-soil moisture, and the spatio-temporal dynamics of wetting fronts during extreme rainfall events. The critical review emphasizes the limits and the advantages of this geophysical method and discloses a way to identify future research activities to improve the use of the TL-ERT method in landslide monitoring. Full article
(This article belongs to the Special Issue Advances in Applied Geophysics)
Show Figures

Figure 1
