Search Results (68)

Traditional steel–wood composite formwork systems often exhibit mechanical imbalances, such as high strength with insufficient stiffness or high stiffness with low toughness, under both ultimate and serviceability limit states. To address the deficiency, this paper proposes a novel reinforced steel–wood composite formwork system (RSWC-FS). The system features a multi-layer plywood panel, ribbed cold-formed thin-walled Q235 steel secondary wales, and double-channel steel primary wales, interconnected by high-strength bolts to create a surface-to-surface bonded interface. This design enhances load transfer efficiency and mitigates stress concentration. Field testing was conducted on cast-in-place shear walls and frame columns, and corresponding finite element models were established in ANSYS for numerical analysis. The results demonstrate that the RSWC-FS delivers stable mechanical performance. The maximum stress of shear walls reaches 42.57 MPa and that of columns 49.98 MPa, while the corresponding displacements are 4.719 mm and 1.541 mm, all of which remain well within the allowable limits. Through an inverse analysis calibration process, optimal load partial factors of 1.26 for shear walls and 1.31 for columns are recommended, significantly reducing the deviation between calculated and measured values. The proposed RSWC-FS effectively resolves the mechanical imbalance inherent in traditional steel–wood composite formwork systems and demonstrates considerable potential for practical engineering application. Full article

Aircraft structures are highly susceptible to fatigue damage, particularly in thin-walled aluminum alloy components such as skin panels. Damage in the form of holes or material loss drastically reduces fatigue life and compromises structural safety, which makes effective repair strategies essential. This study presents an experimental investigation into the fatigue performance of EN AW-2024-T3 aluminum alloy plates with central openings subjected to uniform shear. Repair nodes were applied using two approaches: conventional riveted metal patches and adhesively bonded composite patches. Variants of patch geometry, thickness, and diameter were evaluated to determine their influence on load transfer, buckling response, and fatigue life. The results show that central holes significantly shorten fatigue life, with a 20 mm hole causing a 67% reduction and a 50 mm hole causing a 95% reduction when compared with undamaged plates. Riveted metal patches restored only part of the lost performance, as stress concentrators introduced by fastener holes initiated new fatigue cracks. In contrast, adhesively bonded composite patches provided a substantial improvement, extending fatigue life beyond that of the riveted solutions, improving buckling shape, and delaying crack initiation. Larger patches, particularly those combined with metallic inserts, proved most effective in restoring structural functionality. The findings confirm the effectiveness of bonded composite repairs as a lightweight and reliable method for extending fatigue life and enhancing the safety of damaged aircraft structures. The study highlights the importance of patch geometry and stiffness in the design of repair nodes. Full article

Right-angle dihedral structures produce strong, highly correlated returns that dominate radar cross-section (RCS) and image signatures. Conventional absorbers or random coding metasurfaces often lose effectiveness across wide frequency bands and angles, and cannot adequately suppress the corner-induced hot spots. We propose a wideband super-dispersion encoded surface (SDES) conformally applied to dihedral facets. The approach co-designs input-admittance for absorption with a deterministic super-dispersion phase sequence to redistribute energy spectrally and angularly, thereby decorrelating the returns. We implement SDES on a thin composite panel and evaluate it on canonical dihedral and dihedral–cylindrical hybrid configurations. Unlike diffuse or random coding schemes, SDES enforces broadband, angle-stable dispersion with a deterministic sequence that specifically addresses corner singularity scattering. We also introduce perceptual-hashing as an imaging-domain metric to link RCS control with observable radar-image changes. From 12–18 GHz, SDES reduces the average monostatic RCS by 9.6 dB on a right-angle dihedral. In dihedral–cylindrical hybrids, SDES removes the corner hot spots and drives the radar-image similarity index down to 0.31, confirming substantial alteration of scattering signatures. Full article

Fabric veneer panels were prepared using ethylene-vinyl acetate copolymer film (EVA) as the intermediate layer and poplar plywood as the substrate. Eight fabrics with different compositions were selected for evaluation to screen out fabric materials suitable for poplar plywood veneer. The fabrics were objectively analyzed by bending and draping, compression, and surface roughness, and subjectively evaluated by establishing seven levels of semantic differences. ESEM, surface adhesive properties, and peel resistance tests were used to characterize the microstructure and physical–mechanical properties of the composites. The results show that cotton and linen fabrics and corduroy fabrics are superior to other fabrics in performance, and they are suitable for decorative materials. Because the fibers of the doupioni silk fabric are too thin, and the fibers of felt fabric are randomly staggered, they are not suitable for the surface decoration materials of man-made panels. The acetate veneer surface gluing performance was 1.31 MPa, and the longitudinal peel resistance was 20.98 N, significantly exceeding that of other fabric veneers. Through the subjective and objective analysis of fabrics and gluing performance tests, it was concluded that, compared with fabrics made of natural fibers, man-made fiber fabrics are more suitable for use as surface finishing materials for wood-based panels. The results of this study provide a theoretical basis and process reference for the development of environmentally friendly decorative panels, which can be expanded and applied to furniture, interior decoration, and other fields. Full article

This paper presents the development of two solutions for sandwich panels composed of a thin-layer alkali-activated composite (AAc) layer and a thicker insulation layer, formed by extruded polystyrene foam or expanded cork agglomerate (panels named AP_XPS or AP_ICB, respectively). The AAc combined ceramic waste from clay bricks and roof tiles (75%) with ladle furnace slag (25%), activated with sodium silicate. The AAc layer was further reinforced with polyacrylonitrile (PAN) fibers (1% content). The mechanical behavior was assessed by measuring the uniaxial compressive strength of cubic AAc specimens, shear bond strength, pull-off strength between the AAc layer and the insulation material, and the flexural behavior of the sandwich panels. The thermal performance was characterized by heat flux, inner surface temperatures, the thermal transmission coefficient, thermal resistance, and thermal conductivity. Mechanical test results indicated clear differences between the two proposed solutions. Although AP_XPS panels exhibited higher tensile bond strength values, the AP_ICB panels demonstrated superior interlayer bond performance. Similar findings were observed for the shear bond strength, where the irregular surface of the ICB positively influenced the adhesion to the AAc layer. In terms of flexural behavior, after the initial peak load, the AP_XPS exhibited a deflection-hardening response, achieving greater load-bearing capacity and energy absorption capacity compared to the AP_ICB. Finally, thermal resistance values of 1.02 m² °C/W and 1.14 m² °C/W for AP_ICB and AP_XPS were estimated, respectively, showing promising results in comparison to currently available building materials. Full article

The push for sustainability in all facets of manufacturing has led to an increased interest in biomass as an alternative to non-renewable materials. Hemp bast fiber mats were produced from a bacterial retting process, named BFM, as the fiber reinforcement. The objective of this study was to evaluate the feasibility of laminating BFM with polylactic acid (PLA) for a composite panel product. Since both BFM and PLA are biodegradable, the resulting BFM-PLA composites will be 100% biodegradable. PLA pallets were processed into thin polymer sheets which served as the matrix. The BFM and PLA plates were laminated in five layers and compression-molded into composite panels. Experiments were conducted on the three BFM-to-PLA ratios (35/65, 45/55, and 50/50). Mechanical properties (tensile and bending properties) and physical properties (thickness swell and water absorption) were tested and compared to the currently commercial sheet molding compound (SMC) from fiber glass. The thermal behavior of the BFM/PLA composites was characterized using dynamic mechanical analysis (DMA) and differential scanning calorimetry (DSC). The developed BFM/PLA composite product is a sustainable alternative to existing synthetical fiber-reinforced polymer (FRP) that is biodegradable in landfill at the end of life. Full article

This paper presents an experimental study of wave motions and a global diagnostics method in a realistic aerospace-grade composite component with a complex design. Due to the frequency dependence of the velocity, wave propagation in anisotropic materials is difficult to describe quantitatively. The analysis of experimental ultrasonic wave propagation and the interactions with discontinuities in thin-walled aircraft structures can provide a plethora of information on the wave structure, the mode shapes, and stiffness reduction. An experiment is devised with a network of various omnidirectional sensor configurations to activate and measure structural responses. The measurement process can be leveraged for flaw detection in large multilayered structures. Physically, this corresponds to analyzing the dispersive behavior and scattering properties of ultrasonic waves, the shape of the waveforms, and their corresponding velocities. Ultrasonic waves are measured in a realistic CFRP fuselage panel in a pristine state and after impacts at different energy levels. Simulations do not allow the wave motion in complex and large design structures to be entirely comprehended. The sensitivity of the guided waves as a damage detection tool is proved for the fuselage structure by an extensive measurement campaign and a probabilistic imaging approach based on health indicator fusion. Full article

This paper presents a novel design of prefabricated steel–EPS foam concrete composite wall panels, which can solve issues such as long curing times, decreased impermeability and durability, easy corrosion of steel reinforcement, and difficult construction under the cold climate conditions in Northeast China. A parametric analysis of the composite wallboard was carried out using the finite-element analysis software ABAQUS 6.12. In-depth exploration was conducted on the contributions of parameters such as the density of foam concrete, the strength of cold-formed thin-walled C-section steel, and the cross-sectional height of cold-formed thin-walled C-section steel compared to the overall flexural bearing capacity of the composite wallboard as well as the impacts of these parameters on the failure modes. The mechanical properties of the composite wallboard were verified through four-point bending tests. The bearing capacity of this composite wallboard can reach up to 100.58 kN at most, and its flexural bearing capacity can reach 30.44 kN·m. Meanwhile, its ductility coefficient of 2.9 is also within the optimal range. The research results confirm the superior mechanical properties of the designed composite wallboard, providing beneficial references for the research on similar composite material structures. Full article

Fiber metal laminates (FMLs) are a novel lightweight composite material, predominantly utilized in the aerospace sector for large-scale components like skin panels and fuselages. However, research on FMLs in the microsystem domain remains limited. Additionally, they are influenced by scale effects, rendering macroscopic forming theories inadequate for microforming applications. The application of ultra-thin fiber metal laminates in the microsystem field is hindered by this constraint. This paper investigates the friction performance of ultra-thin TA1 titanium alloy/carbon fiber-reinforced plastic (CFRP) laminates at the microscale. The content of the epoxy resin used is 38.0 ± 3.0%. Friction tests on ultra-thin TA1/CFRP laminates were conducted based on the Striebeck friction theory model. The effects of factors such as the weaving method, ply angle, normal force, tensile speed, and temperature on friction performance are explored in the study. Furthermore, the influences of geometric scale and grain scale on friction performance are examined. Geometric scale effects indicate that an increase in laminate width leads to an increase in the friction coefficient. Grain-scale effects demonstrate that as grain size increases, the friction coefficient also increases, attributed to reduced grain boundaries, increased twinning, and increased surface roughness of the metal. Finally, surface morphology analysis of the metal and fiber after friction tests further confirms the influence of grain size on the friction coefficient. Through detailed experimental design, result analysis and graphical representation, this paper provides a scientific basis for understanding and predicting the friction behavior of ultra-thin TA1/CFRP laminates. Full article

The study focuses on developing a fiber-reinforced composite that would exhibit good mechanical properties and climate resistance, and fire safety parameters would surpass commonly used fiber-reinforced polymers. The subject of development is a polysiloxane thermoset matrix reinforced with basalt fibers, which is processed by partial pyrolysis at 650 °C after curing. The heat release rate test showed virtually zero heat released, and the toxicity test showed only a very low amount of carbon monoxide. The flammability test showed no ignition, no radiation, and no glow. Composites for mechanical tests were prepared in three variants differing in the distribution of reinforcement. Due to the intended use of the composite for thin-walled panels or shells of buildings, the mechanical properties were compared in identical tests with fiber cement plates. The flexural strength of the composites was 3 to 10 times, and the impact energy was 10 to 100 times higher than the values measured on fiber cement, depending on the type and orientation of the composite. The flexural strength measured after 240 freeze–thaw conditioning cycles is higher than fiber cement by 1.3 to 2 times. The climate resistance of the composite should be the subject of further development. Full article

To study the lateral performance of a cold-formed steel–concrete insulation sandwich panel composite wall, two full-scale specimens with different arrangements were designed. The specimens underwent cyclic loading tests to examine the failure characteristics of the composite wall, and lateral performance aspects such as the experimental hysteresis curve, skeleton curve, and characteristic value of the whole loading process were acquired. The experimental results indicate that the failure of the composite wall system was primarily caused by the failure of the connection; the overall lateral performance of composite walls with one wall panel at the bottom and two wall panels at the top (W1) was superior to that of composite walls with two wall panels at the bottom and one wall panel at the top (W2). When loaded to an inter-story drift ratio of 1/300, the composite wall did not exhibit any significant damage. A finite element (FE) model was developed and validated by the experiments. Factors affecting the shear bearing capacity were analyzed based on the FE model, including the yield strength of diagonal braces, the thickness of the diagonal braces, the arrangement pattern of the wall panels, the dimensions of the wall panels, and the strength of the connection of the L-shaped connector and the flat connector. The FE results show that all these factors can influence the lateral performance of the composite wall. Full article

In the dynamic field of photovoltaic technology, the pursuit of efficiency and sustainability has led to continuous novelty, shaping the landscape of solar energy solutions. One of the key elements affecting the efficiency of photovoltaic cells of II^nd and III^rd generation is the presence of transparent conductive oxide (TCO) layers, which are key elements impacting the efficiency and durability of solar panels, especially for DSSC, CdTe, CIGS (copper indium gallium diselenide) or organic, perovskite and quantum dots. TCO with low electrical resistance, high mobility, and high transmittance in the VIS–NIR region is particularly important in DSSC, CIGS, and CdTe solar cells, working as a window and electron transporting layer. This layer must form an ohmic contact with the adjacent layers, typically the buffer layer (such as CdS or ZnS), to ensure efficient charge collection Furthermore it ensures protection against oxidation and moisture, which is especially important when transporting the active cell structure to further process steps such as lamination, which ensures the final seal. Transparent conductive oxide layers, which typically consist of materials such as indium tin oxide (ITO) or alternatives such as fluorine-doped tin oxide (FTO), serve dual purposes in photovoltaic applications. Primarily located as the topmost layer of solar cells, TCOs play a key role in transmitting sunlight while facilitating the efficient collection and transport of generated electrical charges. This complex balance between transparency and conductivity highlights the strategic importance of TCO layers in maximizing the performance and durability of photovoltaic systems. As the global demand for clean energy increases and the photovoltaic industry rapidly develops, understanding the differential contribution of TCO layers becomes particularly important in the context of using PV modules as building-integrated elements (BIPV). The use of transparent or semi-transparent modules allows the use of building glazing, including windows and skylights. In addition, considering the dominant position of the Asian market in the production of cells and modules based on silicon, the European market is intensifying work aimed at finding a competitive PV technology. In this context, thin-film, organic modules may prove competitive. For this purpose, in this work, we focused on the electrical parameters of two different thicknesses of a transparent FTO layer. First, the influence of the FTO layer thickness on the transmittance over a wide range was verified. Next, the chemical composition was determined, and key electrical parameters, including carrier mobility, resistivity, and the Hall coefficient, were determined. Full article

In this paper, an enhanced VARTM process is proposed and its pressure effect on resin infusion behavior and composite material performance is studied to reveal the control mechanism of the fiber volume fraction and void content. The molding is vacuumized during the resin injection stage while it is pressurized during the mold filling and curing stages via a VARTM pressure control system designed in this paper. Theoretical calculations and simulation methods are used to reveal the resin’s in-plane, transverse, and three-dimensional flow patterns in multi-layer media. For typical thin-walled components, the infiltration behavior of resin in isotropic porous media is studied, elucidating the control mechanisms of fiber volume fraction and void content. The experiments demonstrate that the enhanced VARTM process significantly improves mold filling efficiency and composite’s performance. Compared to the regular VARTM process, the panel thickness is reduced by 4% from 1.7 mm, the average tensile strength is increased by 7.3% to 760 MPa, the average flexural strength remains at approximately 720 MPa, porosity is decreased from 1.5% to below 1%, and the fiber volume fraction is increased from 55% to 62%. Full article

Acoustic metamaterials (AMs) composed of periodic artificial structures have extraordinary sound wave manipulation capabilities compared with traditional acoustic materials, and they have attracted widespread research attention. The sound insulation performance of thin-walled structures commonly used in engineering applications with restricted space, for example, vehicles’ body structures, and the latest studies on the sound insulation of thin-walled metamaterial structures, are comprehensively discussed in this paper. First, the definition and math law of sound insulation are introduced, alongside the primary methods of sound insulation testing of specimens. Secondly, the main sound insulation acoustic metamaterial structures are summarized and classified, including membrane-type, plate-type, and smart-material-type sound insulation metamaterials, boundaries, and temperature effects, as well as the sound insulation research on composite structures combined with metamaterial structures. Finally, the research status, challenges, and trends of sound insulation metamaterial structures are summarized. It was found that combining the advantages of metamaterial and various composite panel structures with optimization methods considering lightweight and proper wide frequency band single evaluator has the potential to improve the sound insulation performance of composite metamaterials in the full frequency range. Relative review results provide a comprehensive reference for the sound insulation metamaterial design and application. Full article

Terahertz (THz) non-destructive testing can detect internal defects in dielectric materials. However, this technology is mainly used for detecting thin and simple structures at present, lacking validations for the detection effectiveness of internal defects in thicker and more complex structures, such as fiber-web-reinforced composite sandwich panels. In this study, samples of fiber-web-reinforced polymethacrylimide foam sandwich panels, which are, respectively, 20 mm and 30 mm thick, were made to detect the internal debonding, inclusion, pore, and crack defects by the THz time-domain spectroscopy system (THz-TDS). The peak-to-peak-imaging algorithm, maximum-amplitude-imaging algorithm, minimum-amplitude-imaging algorithm, pulse-width-imaging algorithm, and time-of-flight-imaging algorithm were used to process and image the collected THz signals. The results showed that the peak-to-peak-imaging algorithm had the best performance. To address the low imaging resolution of THz-TDS, a block-based super-resolution reconstruction method—SSSRGAN—is proposed, which can improve image resolution while maintaining the clear edge contours of defects. The defect-detection results of the samples showed that THz-TDS could detect all pore, debonding, and crack defects, with a minimum size of 3 mm for pores and debonding and a minimum thickness of 1 mm for cracks. The method showed poor detection performance for inclusions with a thickness of 0.053 mm, but could still extract the defect features. Based on the THz-TDS reflection mode measurement principle, the thickness information of the panel, foam core, and web of the samples was calculated: the measurement error was no more than 0.870 mm for Sample #1 and no more than 0.270 mm for Sample #2, demonstrating the accuracy of THz-TDS in measuring the dimensions of sandwich panel structures. In general, THz technology shows potential for detecting internal defects and performing dimensional measurements in complex structures. With the advancement of portable devices and enhancements in detection speed, real-time on-site detection is anticipated in the future. Full article
