Search Results (46)

Search Parameters:
Keywords = tank capacitor

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 4802 KB
Article
Wirelessly Interrogated, Implantable Capacitive MEMS Sensors for Continuous Intraocular Pressure Monitoring
by Liguan Li, Adnan Zaman, Ramesh Ayyala and Jing Wang
Sensors 2026, 26(9), 2806; https://doi.org/10.3390/s26092806 - 30 Apr 2026
Viewed by 1418
Abstract
This work presents wirelessly interrogated microelectromechanical system (MEMS) capacitive sensors for continuous intraocular pressure (IOP) monitoring. The sensor uses a passive inductor–capacitor (LC) tank circuit comprising a fixed, on-chip spiral inductor and a pressure-sensitive, variable-gap capacitor with parallel-plate membrane electrodes and side anchors. [...] Read more.
This work presents wirelessly interrogated microelectromechanical system (MEMS) capacitive sensors for continuous intraocular pressure (IOP) monitoring. The sensor uses a passive inductor–capacitor (LC) tank circuit comprising a fixed, on-chip spiral inductor and a pressure-sensitive, variable-gap capacitor with parallel-plate membrane electrodes and side anchors. The membrane is designed with dimensions of 500 µm × 500 µm × 2 µm and a capacitive transducer gap of 2.5 µm. Applied pressure deflects the top membrane, producing a corresponding capacitance variation that changes the frequency and phase response of the LC tank circuit, enabling real-time and continuous IOP monitoring over a target detection range of 0–50 mmHg and beyond. Mutual inductive coupling between the sensor and the external readout coil is investigated as a reliable readout mechanism. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

21 pages, 4622 KB
Article
A Mutual Inductance–Capacitance IPOS-Type Self-Balancing LLC Resonant Converter
by Jin Li, Ao Liu and Weiyi Tang
Energies 2026, 19(7), 1731; https://doi.org/10.3390/en19071731 - 1 Apr 2026
Viewed by 539
Abstract
In low-voltage-input, high-voltage-output applications, the input-parallel output-series (IPOS) LLC resonant converter experiences voltage and current imbalances due to parameter mismatches in resonant tank components. To address this issue, a self-balancing IPOS LLC resonant converter based on a shared inductance–capacitance (shared L-C) network is [...] Read more.
In low-voltage-input, high-voltage-output applications, the input-parallel output-series (IPOS) LLC resonant converter experiences voltage and current imbalances due to parameter mismatches in resonant tank components. To address this issue, a self-balancing IPOS LLC resonant converter based on a shared inductance–capacitance (shared L-C) network is proposed. This topology achieves passive voltage and current self-equalization with an interconnection network of resonant inductors and capacitors between modules that does not need additional active components or complex control strategies. An analytical model based on the fundamental harmonic approximation (FHA) is developed to quantitatively assess the balancing performance, and a comparison is made with traditional structures and IPOS structures with only shared inductance. A 1.25 kW two-phase LLC resonant converter prototype is built for experimental validation. The results demonstrate that the balancing errors of the traditional structure and the shared inductance structure reach up to 25.43% and 17.63%, respectively, whereas the proposed structure significantly reduces the balancing error to only 0.43%. This study confirms that this structure provides a simple and reliable solution for voltage and current equalization in high-gain DC–DC conversion systems. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

19 pages, 5485 KB
Article
Spiking Neuron with Sensing Coil Based on a Volatile Memristor
by Timur Karimov, Vyacheslav Rybin, Vasiliy Pchelko, Alexander Mikhailov, Yulia Bobrova and Denis Butusov
Sensors 2026, 26(7), 2144; https://doi.org/10.3390/s26072144 - 31 Mar 2026
Viewed by 511
Abstract
The convergence of sensing and processing is a critical frontier in the development of energy-efficient spiking edge intelligence. This paper presents a novel hardware implementation of a sensory neuron evolving from the leaky integrate-and-fire (LIF) model by coupling a volatile memristor with an [...] Read more.
The convergence of sensing and processing is a critical frontier in the development of energy-efficient spiking edge intelligence. This paper presents a novel hardware implementation of a sensory neuron evolving from the leaky integrate-and-fire (LIF) model by coupling a volatile memristor with an LC tank circuit. The proposed memristor–resistor–inductor–capacitor (MRLC) neuron embeds electromagnetic sensing directly into neuronal dynamics, enabling direct transduction of proximity information into spike trains. We demonstrate that the circuit functions as a metal-sensitive proximity sensor with spiking output in both simulation and physical experiments. Moreover, the MRLC neuron exhibits rich dynamical regimes, including regular spiking, bursting with 2–5 spikes per burst, and quasi-chaotic behavior, as well as sensing memory provided by hysteresis-like multistability, which is a notable advancement over simple rate-encoding LIF neurons. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

25 pages, 10186 KB
Article
Optimization Design Method for Full-Bridge LLC Resonant Converter Based on Fractional-Order Characteristics of Resonant Tank
by Xiaoquan Zhu, Chentao Ma and Haochi He
Fractal Fract. 2026, 10(3), 194; https://doi.org/10.3390/fractalfract10030194 - 16 Mar 2026
Viewed by 1005
Abstract
The full-bridge LLC resonant converter is one of the most suitable converters for high-power, high-efficiency applications. Although the design methodologies for full-bridge LLC resonant converters are already well-established, the development of the fractional-order domain has brought new flexibility to converter design. Based on [...] Read more.
The full-bridge LLC resonant converter is one of the most suitable converters for high-power, high-efficiency applications. Although the design methodologies for full-bridge LLC resonant converters are already well-established, the development of the fractional-order domain has brought new flexibility to converter design. Based on the fact that inductors and capacitors have fractional-order characteristics, this paper presents a de-normalized fractional-order FHA gain model, which reveals the impact of fractional-order characteristics of practical inductors and capacitors on the converter gain. By maintaining the convenience of the FHA design method, this work identifies the fractional orders of a resonant tank inductor and capacitor and incorporates them into the parameter design as part of the design requirements, making the design results more accurate than the conventional FHA design method. Specifically, compared with the conventional FHA-based design, the proposed approach improves the DC voltage gain margin of the full-bridge LLC converter by 26% and expands the ZVS operating range margin by 23.3%. Full article
Show Figures

Figure 1

19 pages, 5899 KB
Article
Small-Signal Modeling of Asymmetric PWM Control-Based Parallel Resonant Converter
by Na-Yeon Kim and Kui-Jun Lee
Electronics 2025, 14(24), 4970; https://doi.org/10.3390/electronics14244970 - 18 Dec 2025
Viewed by 627
Abstract
This paper proposes a small-signal model of a DC–DC parallel resonant converter operating in continuous conduction mode based on asymmetric pulse-width modulation (APWM) under light-load conditions. The parallel resonant converter enables soft switching and no-load control over a wide load range because the [...] Read more.
This paper proposes a small-signal model of a DC–DC parallel resonant converter operating in continuous conduction mode based on asymmetric pulse-width modulation (APWM) under light-load conditions. The parallel resonant converter enables soft switching and no-load control over a wide load range because the resonant capacitor is connected in parallel with the load. However, the resonant energy required for soft switching is already sufficient, and the current flowing through the resonant tank is independent of the load magnitude; therefore, as the load decreases, the energy that is not delivered to the load and instead circulates meaninglessly inside the resonant tank increases. This results in conduction loss and reduced efficiency. To address this issue, APWM with a fixed switching frequency is required, which reduces circulating energy and improves efficiency under light-load conditions. Precise small-signal modeling is required to optimize the APWM controller. Unlike PFM or PSFB, APWM includes not only sine components but also DC and cosine components in the control signal due to its asymmetric switching characteristics, and this study proposes a small-signal model that can relatively accurately reflect these multi-harmonic characteristics. The proposed model is derived based on the Extended Describing Function (EDF) concept, and the derived transfer function is useful for systematically analyzing the dynamic characteristics of the APWM-based parallel resonant converter. In addition, it provides information that can systematically analyze the dynamic characteristics of various APWM-based resonant converters and control signals that reflect various harmonic characteristics, and it can be widely applied to future control design and analysis studies. The validity of the model is verified through MATLAB (R2025b) and PLECS (4.7.5) switching-model simulations and experimental results, confirming its high accuracy and practicality. Full article
(This article belongs to the Special Issue New Insights in Power Electronics: Prospects and Challenges)
Show Figures

Figure 1

19 pages, 4201 KB
Article
Implementation of an SS-Compensated LC-Thermistor Topology for Passive Wireless Temperature Sensing
by Seyit Ahmet Sis and Yeliz Dikerler Kozar
Sensors 2025, 25(20), 6316; https://doi.org/10.3390/s25206316 - 13 Oct 2025
Cited by 1 | Viewed by 1010
Abstract
This paper presents a passive wireless temperature sensor based on an SS-compensated LC-thermistor topology. The system consists of two magnetically coupled LC tanks—each composed of a coil and a series capacitor—forming a series–series (SS) compensation network. The secondary side includes a negative temperature [...] Read more.
This paper presents a passive wireless temperature sensor based on an SS-compensated LC-thermistor topology. The system consists of two magnetically coupled LC tanks—each composed of a coil and a series capacitor—forming a series–series (SS) compensation network. The secondary side includes a negative temperature coefficient (NTC) thermistor connected in series with its coil and capacitor, acting as a temperature-dependent load. Magnetically coupled resonant systems exhibit different coupling regimes: weak, critical, and strong. When operating in the strongly coupled regime, the original resonance splits into two distinct frequencies—a phenomenon known as bifurcation. At these split resonance frequencies, the load impedance on the secondary side is reflected as pure resistance at the primary side. In the SS topology, this reflected resistance is equal to the thermistor resistance, enabling precise wireless sensing. The advantage of the SS-compensated configuration lies in its ability to map changes in the thermistor’s resistance directly to the input impedance seen by the reader circuit. As a result, the sensor can wirelessly monitor temperature variations by simply tracking the input impedance at split resonance points. We experimentally validate this property on a benchtop prototype using a one-port VNA measurement, demonstrating that the input resistance at both split frequencies closely matches the expected thermistor resistance, with the observed agreement influenced by the parasitic effects of RF components within the tested temperature range. We also demonstrate that using the average readout provides first-order immunity to small capacitor drift, yielding stable readings. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

25 pages, 4440 KB
Article
PWM–PFM Hybrid Control of Three-Port LLC Resonant Converter for DC Microgrids
by Yi Zhang, Xiangjie Liu, Jiamian Wang, Baojiang Wu, Feilong Liu and Junfeng Xie
Energies 2025, 18(10), 2615; https://doi.org/10.3390/en18102615 - 19 May 2025
Cited by 3 | Viewed by 1982
Abstract
This article proposes a high-efficiency isolated three-port resonant converter for DC microgrids, combining a dual active bridge (DAB)–LLC topology with hybrid Pulse Width Modulat-Pulse Frequency Modulation (PWM-PFM) phase shift control. Specifically, the integration of a dual active bridge and LLC resonant structure with [...] Read more.
This article proposes a high-efficiency isolated three-port resonant converter for DC microgrids, combining a dual active bridge (DAB)–LLC topology with hybrid Pulse Width Modulat-Pulse Frequency Modulation (PWM-PFM) phase shift control. Specifically, the integration of a dual active bridge and LLC resonant structure with interleaved buck/boost stages eliminates cascaded conversion losses. Energy flows bidirectionally between ports via zero-voltage switching, achieving a 97.2% efficiency across 150–300 V input ranges, which is a 15% improvement over conventional cascaded designs. Also, an improved PWM-PFM shift control scheme dynamically allocates power between ports without altering switching frequency. By decoupling power regulation and leveraging resonant tank optimization, this strategy reduces control complexity while maintaining a ±2.5% voltage ripple under 20% load transients. Additionally, a switch-controlled capacitor network and frequency tuning enable resonant parameter adjustment, achieving a 1:2 voltage gain range without auxiliary circuits. It reduces cost penalties compared to dual-transformer solutions, making the topology viable for heterogeneous DC microgrids. Based on a detailed theoretical analysis, simulation and experimental results verify the effectiveness of the proposed concept. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

8 pages, 5916 KB
Article
RF Dielectric Permittivity Sensing of Molecular Spin State Switching Using a Tunnel Diode Oscillator
by Ion Soroceanu, Andrei Diaconu, Viorela-Gabriela Ciobanu, Lionel Salmon, Gábor Molnár and Aurelian Rotaru
J. Compos. Sci. 2025, 9(1), 49; https://doi.org/10.3390/jcs9010049 - 20 Jan 2025
Viewed by 1472
Abstract
We introduce a novel approach to study the dielectric permittivity of spin crossover (SCO) molecular materials using a radio frequency (RF) resonant tunnel diode oscillator (TDO) circuit. By fabricating a parallel plate capacitor using SCO particles embedded into a polymer matrix as an [...] Read more.
We introduce a novel approach to study the dielectric permittivity of spin crossover (SCO) molecular materials using a radio frequency (RF) resonant tunnel diode oscillator (TDO) circuit. By fabricating a parallel plate capacitor using SCO particles embedded into a polymer matrix as an integral part of the inductor (L) capacitor (C) LC tank of the TDO, we were able to extract the temperature dependence of the dielectric permittivity of frequency measurements for a wide selection of resonance values, spanning from 100 kHz up to 50 MHz, with great precision (less than 2 ppm) and in a broad temperature range. By making use of this simple electronic circuit to explore the frequency and temperature-dependent dielectric permittivity of the compound Fe[(Htrz)2(trz)](BF4), we demonstrate the reliability and resolution of the technique and show how the results compare with those obtained using complex instrumentation. Full article
Show Figures

Figure 1

16 pages, 2037 KB
Article
Elbow Gesture Recognition with an Array of Inductive Sensors and Machine Learning
by Alma Abbasnia, Maryam Ravan and Reza K. Amineh
Sensors 2024, 24(13), 4202; https://doi.org/10.3390/s24134202 - 28 Jun 2024
Cited by 6 | Viewed by 2103
Abstract
This work presents a novel approach for elbow gesture recognition using an array of inductive sensors and a machine learning algorithm (MLA). This paper describes the design of the inductive sensor array integrated into a flexible and wearable sleeve. The sensor array consists [...] Read more.
This work presents a novel approach for elbow gesture recognition using an array of inductive sensors and a machine learning algorithm (MLA). This paper describes the design of the inductive sensor array integrated into a flexible and wearable sleeve. The sensor array consists of coils sewn onto the sleeve, which form an LC tank circuit along with the externally connected inductors and capacitors. Changes in the elbow position modulate the inductance of these coils, allowing the sensor array to capture a range of elbow movements. The signal processing and random forest MLA to recognize 10 different elbow gestures are described. Rigorous evaluation on 8 subjects and data augmentation, which leveraged the dataset to 1270 trials per gesture, enabled the system to achieve remarkable accuracy of 98.3% and 98.5% using 5-fold cross-validation and leave-one-subject-out cross-validation, respectively. The test performance was then assessed using data collected from five new subjects. The high classification accuracy of 94% demonstrates the generalizability of the designed system. The proposed solution addresses the limitations of existing elbow gesture recognition designs and offers a practical and effective approach for intuitive human–machine interaction. Full article
(This article belongs to the Special Issue Combining Machine Learning and Sensors in Human Movement Biomechanics)
Show Figures

Figure 1

10 pages, 2548 KB
Article
Design and Analysis of Self-Tanked Stepwise Charging Circuit for Four-Phase Adiabatic Logic
by William Morell and Jin-Woo Choi
J. Low Power Electron. Appl. 2024, 14(3), 34; https://doi.org/10.3390/jlpea14030034 - 27 Jun 2024
Cited by 2 | Viewed by 1986
Abstract
Adiabatic logic has been proposed as a method for drastically reducing power consumption in specialized low-power circuits. They often require specialized clock drivers that also function as the main power supply, in contrast to standard CMOS logic, and these power clocks are often [...] Read more.
Adiabatic logic has been proposed as a method for drastically reducing power consumption in specialized low-power circuits. They often require specialized clock drivers that also function as the main power supply, in contrast to standard CMOS logic, and these power clocks are often a point of difficulty in the design process. A novel, stepwise charging driver circuit for four-phase adiabatic logic is proposed and validated through a simulation study. The proposed circuit consists of two identical driver circuits each driving two opposite adiabatic logic phases. Its performance relative to ideal step-charging and a standard CMOS across mismatched phase loads is analyzed, and new best practices are established. It is compared to a reference circuit consisting of one driver circuit for each phase along with a paired on-chip tank capacitor. The proposed driver uses opposite logic phases to act as the tank capacitor for each other in a “self-tanked” fashion. Each circuit was simulated in 15 nm FinFET across a variety of frequencies for an arbitrary logic operation. Both circuits showed comparable power consumption at all frequencies tested, yet the proposed driver uses fewer transistors and control signals and eliminates the explicit tank capacitors entirely, vastly reducing circuit area, complexity, and development time. Full article
(This article belongs to the Special Issue Ultra-Low-Power ICs for the Internet of Things (2nd Edition))
Show Figures

Figure 1

23 pages, 2058 KB
Article
RETRACTED: Analysis of Scalable Resonant DC–DC Converter Using GaN Switches for xEV Charging Stations
by Rajanand Patnaik Narasipuram, Subbarao Mopidevi, Anton Dianov and Amit Singh Tandon
World Electr. Veh. J. 2024, 15(5), 218; https://doi.org/10.3390/wevj15050218 - 17 May 2024
Cited by 15 | Viewed by 3648 | Retraction
Abstract
In this research, an innovative electric vehicle (EV) charger is designed and presented for xEV charging stations. The key feature of our system is a scalable, interleaved inductor–inductor–capacitor (iL2C) DC-DC converter operation. The proposed system employs two parallel L2C [...] Read more.
In this research, an innovative electric vehicle (EV) charger is designed and presented for xEV charging stations. The key feature of our system is a scalable, interleaved inductor–inductor–capacitor (iL2C) DC-DC converter operation. The proposed system employs two parallel L2C converters with 8-GaN switches on the primary side and a shared rectifier circuit on the secondary side. This configuration not only amplifies the resonant tank internal currents and losses generated by the switches but also improves current sharing. A novel closed-loop technique is proposed with a constant-voltage method of operation, along with a hybrid control scheme of variable frequency + phase shift modulation (VFPSM). To examine the controller and converter’s performance, an experimental demonstration is conducted under varying load conditions, including full load, half load, and light load, where the source voltage and load voltage are maintained at constant levels of 400 Vin and 48 V0, respectively. Furthermore, line regulation is conducted and verified to accommodate a broad input voltage range of 300 Vin–500 Vin and 500 Vin–300 Vin while maintaining an output voltage of 48 V0 at 3.3 kW, 1.65 kW, and 0.33 kW with a peak efficiency of 98.2%. Full article
Show Figures

Figure 1

20 pages, 12608 KB
Article
Study of a Center Pipe Oscillating Column Wave Energy Converter Combined with a Triboelectric Nanogenerator Device
by Yan Huang, Shaohui Yang, Jianyu Fan, Zhichang Du, Beichen Lin, Yongqiang Tu and Lei Pan
J. Mar. Sci. Eng. 2024, 12(1), 100; https://doi.org/10.3390/jmse12010100 - 3 Jan 2024
Cited by 5 | Viewed by 2395
Abstract
Wave energy is one of the most widely distributed and abundant energies in the ocean, and its conversion technology has been broadly researched. In this paper, a structure that combines a traditional center pipe oscillating water column and a triboelectric nanogenerator is proposed. [...] Read more.
Wave energy is one of the most widely distributed and abundant energies in the ocean, and its conversion technology has been broadly researched. In this paper, a structure that combines a traditional center pipe oscillating water column and a triboelectric nanogenerator is proposed. Firstly, the structural characteristics and geometric parameters of the device are designed. The working process of the device is introduced, the motion equation of the device is established, and the power generation principle of the triboelectric nanogenerator is deduced and analyzed theoretically. Secondly, hydrodynamic modeling and simulation are carried out, the influence of the bottom shape of the main floating body and the structural parameters of the sag plate on the hydrodynamic force of the device is analyzed, and an electric field simulation of the generation process of the friction nanogenerator is carried out. Finally, experiments involving the wave water tank of the proposed device are conducted, including charging the capacitor of the device under different wave conditions and directly lighting the LED lamp. The performance of the proposed device under different wave conditions is discussed. According to the test results, the feasibility of the proposed device for wave energy conversion is confirmed. Full article
(This article belongs to the Topic Energy from Sea Waves)
Show Figures

Figure 1

22 pages, 7536 KB
Article
LLC Resonant Converter as a Current Source Using Simple Trajectory Control
by Tsvetana Grigorova and Aleksandar Vuchev
Energies 2023, 16(12), 4629; https://doi.org/10.3390/en16124629 - 10 Jun 2023
Cited by 3 | Viewed by 4114
Abstract
This paper discusses a simple method for controlling an LLC resonant DC-DC converter using a state space trajectory based on a linear combination of the voltage across the capacitor and the current through the inductance in the series resonant tank. An analysis of [...] Read more.
This paper discusses a simple method for controlling an LLC resonant DC-DC converter using a state space trajectory based on a linear combination of the voltage across the capacitor and the current through the inductance in the series resonant tank. An analysis of the converter using the state plane technique for the continuous current operation mode is proposed. The output, control and load characteristics of the converter, required for its design and application, are built for the different inductance ratios. They specify the limitations in the control range of the LLC resonant converter which result from the use of the control method. It is shown that under this control, the converter possesses linear control characteristics and has current source behavior. Therefore, the converter can successfully be used as a battery-charging device. Simulations of the converter’s operation, both in steady state and when the control parameter is changed significantly, are implemented. Studies using the model confirm that the considered simple trajectory control provides a fast dynamic response and stable operation of the LLC resonant converter, even in cases of a significant change in the control. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

21 pages, 6537 KB
Article
A Novel ZVS/ZCS Push-Pull LC Resonant DC-DC Converter for Energy Sources
by You-Kun Tai and Kuo-Ing Hwu
Energies 2023, 16(6), 2892; https://doi.org/10.3390/en16062892 - 21 Mar 2023
Cited by 7 | Viewed by 9247
Abstract
In this paper, a novel soft switching push-pull LC resonant DC-DC converter for energy sources is presented. In a high step-up converter, the input of primary side possesses low voltage and high current, so the losses caused by the current account for most [...] Read more.
In this paper, a novel soft switching push-pull LC resonant DC-DC converter for energy sources is presented. In a high step-up converter, the input of primary side possesses low voltage and high current, so the losses caused by the current account for most of the total power loss. At the same time, the high-voltage stress of the high-voltage output components on the secondary side is also a major problem. Therefore, a high-gain isolated push-pull converter with a secondary-side resonant circuit is proposed, so that the primary-side switches have zero voltage switching (ZVS) and the secondary-side diodes have zero current switching (ZCS). The push-pull structure can reduce the number of active switches, so that the total power loss on the primary side can be reduced. The converter has a resonant tank circuit arranged between the secondary side of isolation transformer and the high-voltage output rectification module. The high-voltage output rectifier module adopts a full-bridge architecture suitable for high-voltage coupling connection. The low-side power switching module adopts a push-pull architecture suitable for low-voltage and high-current applications. The resonant tank circuit uses an inductor–capacitor (LC) structure to improve the resonant tank circuit, which achieves soft switching during power transfer, increasing the efficiency of the converter and improving the electromagnetic compatibility. The main advantage of this technology is that the secondary-side leakage inductance of transformer and the resonant capacitance are connected in series to achieve ZVS for switches and ZCS for diodes. Finally, a prototype of a high-gain push-pull resonant converter was established. The converter was operated at a fixed switching frequency of 135 kHz and a duty cycle of approximately 0.5. The efficiency of the converter can reach 97.1% under experimental tests at an output voltage of 400 V and a rated output power of 500 W. Full article
Show Figures

Figure 1

20 pages, 9457 KB
Article
A Study and Implementation of Inductive Power Transfer System Using Hybrid Control Strategy for CC-CV Battery Charging
by Liangxi He, Xiaoqiang Wang and Chi-Kwan Lee
Sustainability 2023, 15(4), 3606; https://doi.org/10.3390/su15043606 - 15 Feb 2023
Cited by 12 | Viewed by 3747
Abstract
In this paper, a hybrid control strategy is studied and implemented on an Inductive Power Transfer (IPT) system to simultaneously realize zero-voltage switching (ZVS) and constant current (CC) and constant voltage (CV) battery charging. A steady-state analysis of pulse frequency modulation was conducted, [...] Read more.
In this paper, a hybrid control strategy is studied and implemented on an Inductive Power Transfer (IPT) system to simultaneously realize zero-voltage switching (ZVS) and constant current (CC) and constant voltage (CV) battery charging. A steady-state analysis of pulse frequency modulation was conducted, based on the characteristic of voltage gain versus switching frequency, and CC and CV charging modes were promised. The ZVS of the inverter was obtained by satisfying the minimum requirement of full discharge of the junction capacitor on the MOSFETs using a commutation current during the dead-time interval. Two control degrees of freedom are needed to realize the two control targets. This hybrid control strategy adopts a self-oscillating (SO) control to achieve ZVS and phase shift (PS) control and a constant output for the series–series (SS)-compensated IPT system. To validate the hybrid control strategy, a 1.6 kW prototype with 360–440 V input voltage and 250–400 V output voltage was built and the experimental results show that the peak efficiency can reach 96.1%. Compared with the conventional variable frequency (VF) control, the hybrid control method proves that an additional control variable can fulfill the control target in a more flexible manner, which makes the switching frequency close to the resonant frequency during the charging process, minimizing the reactive current in the resonant tank and improving system efficiency. Full article
Show Figures

Figure 1
