Search Results (34)

To address the challenges in intuitive feature discrimination and precise quantitative evaluation of cable defects, this paper proposes a diagnostic methodology utilizing the Symmetrized Dot Pattern (SDP) transform and reflection coefficient spectra. The Dung Beetle Optimizer (DBO) is introduced to adaptively optimize the SDP transform parameters, employing the Structural Similarity Index Measure (SSIM) as a fitness function to maximize discriminability between deterioration states. Three quantitative features, including the number of effective pixels, the degree of red–blue aliasing, and radial dispersion, are extracted to characterize the physical degradation processes of signal energy accumulation, angular evolution, and path divergence. By incorporating a self-reference calibration mechanism for structural differences, features are fused into a Comprehensive Deterioration Index (CDI). Experimental results on coaxial cables simulating shielding damage and thermal aging demonstrate that SDP images reveal continuous evolution patterns corresponding to defect severity. A regression model based on these patterns effectively characterizes deterioration trends. Compared to complex models, this study achieves intuitive fault identification and preliminary quantitative description of degradation trends through image feature fusion. Although the current sample size is limited, the results validate the feasibility of this method in evaluating cable deterioration severity, offering an efficient new data-processing perspective for cable condition monitoring. Full article

This work addresses the challenges of inadequate data acquisition and the limited availability of labeled samples for shearer rocker arm bearing faults by developing a data augmentation methodology that synergistically incorporates the Genetic Algorithm-optimized Wavelet Transform Symmetrical Dot Pattern (GA-WT-SDP) with a Wasserstein Conditional Generative Adversarial Network (WCGAN). In the initial step, the Genetic Algorithm (GA) is employed to refine the mapping parameters of the Wavelet Transform Symmetrical Dot Pattern (WT-SDP), facilitating the transformation of raw vibration signals into advanced and discriminative graphical representations. Thereafter, the Wasserstein distance in conjunction with a gradient penalty mechanism is introduced through the WCGAN, thereby ensuring higher-quality generated samples and improved stability during model training. Experimental results validate that the proposed approach yields accelerated convergence and superior performance in sample generation. The augmented data significantly bolsters the generalization ability and predictive accuracy of fault diagnosis models trained on small datasets, with notable gains achieved in deep architectures (CNNs, LSTMs). The research substantiates that this technique helps overcome overfitting, enhances feature representation capacity, and ensures consistently high identification accuracy even in complex working environments. Full article

Fault diagnosis in axial piston pumps is key to ensuring the proper operation of a hydraulic system. Slipper wear, as a typical fault in piston pumps, is challenging to accurately diagnose because the faults are very similar for different forms and degrees of wear. The achievement of accurate fault diagnosis of different forms and degrees of wear in the slipper will greatly improve the reliability of axial piston pump operation and, at the same time, provide new ideas for research into similar fault diagnosis problems in other rotating machinery. Therefore, a method of fault diagnosis based on the following symmetric dot pattern (SDP) and multi-channel densely connected convolutional networks (DenseNet) is proposed in this paper. The method applies an SDP transformation to transform the slipper failure signal into an SDP image, which achieves the fusion of triaxial vibration signals and enriches the signal features. The inception module is improved by replacing the original structure with larger convolutional kernels in multiple branches and decomposing the larger convolutional kernels. The inception module, the convolutional block attention module (CBAM), and the DropBlock method are introduced into DenseNet to improve feature extraction capability, computational efficiency, and model generalization ability. Experiments are performed on several slipper wear fault SDP image datasets, and all the indices produced by the proposed method are higher than those of the traditional convolutional neural networks, which fully proves the effectiveness and superiority of the procedure. Full article

To address the limitations of existing fault diagnosis methods for excitation dry-type transformers, such as inadequate utilization of multi-axis vibration data, low recognition accuracy under complex operational conditions, and limited computational efficiency, this paper presents a lightweight fault diagnosis approach based on the fusion of multi-channel vibration signals and visual features. Initially, a multi-physics field coupling simulation model of the excitation dry-type transformer is developed. Vibration data collected from field-installed three-axis sensors are combined to generate typical fault samples, including normal operation, winding looseness, core looseness, and winding eccentricity. Due to the high dimensionality of vibration signals, the Symmetrized Dot Pattern (ISDP) method is extended to aggregate and map time- and frequency-domain information from the x-, y-, and z-axes into a two-dimensional feature map. To optimize the inter-class separability and intra-class consistency of the map, Particle Swarm Optimization (PSO) is employed to adaptively adjust the angle gain factor (η) and time delay coefficient (t). Keypoint descriptors are then extracted from the map using the Oriented FAST and Rotated BRIEF (ORB) feature extraction operator, which improves computational efficiency while maintaining sensitivity to local details. Finally, an efficient fault classification model is constructed using an Adaptive Boosting Support Vector Machine (Adaboost-SVM) to achieve robust fault mode recognition across multiple operating conditions. Experimental results demonstrate that the proposed method achieves a fault diagnosis accuracy of 94.00%, outperforming signal-to-image techniques such as Gramian Angular Field (GAF), Recurrence Plot (RP), and Markov Transition Field (MTF), as well as deep learning models based on Convolutional Neural Networks (CNN) in both training and testing time. Additionally, the method exhibits superior stability and robustness in repeated trials. This approach is well-suited for online monitoring and rapid diagnosis in resource-constrained environments, offering significant engineering value in enhancing the operational safety and reliability of excitation dry-type transformers. Full article

Timely and effective identification of the tool wear condition is crucial for ensuring the machining quality of CNC machine tools. In most industrial scenarios, the cost of sample collection is high, so only a small number of samples are available for model training, making it difficult for the existing tool wear condition monitoring (TCM) methods based on deep learning to achieve high performance. To address this problem, this paper proposes a TCM method based on the improved symmetric dot pattern (SDP) enhanced ResNet18. Firstly, the time series sample data is converted into grayscale matrices through SDP, the correlation coefficient between the grayscale matrices is calculated, and the optimal parameter combination of SDP is determined according to the objective of minimizing the correlation coefficient. Then, the cutting force signal is converted into a lobe diagram of the optimized SDP to enrich the sample feature information. Next, the SDP lobe diagram is input into ResNet18 for few-shot learning. The results of a series of TCM experiments demonstrate that the proposed method is significantly superior to the STFT and GAF based methods. Full article

This study employs density functional theory (DFT) and time-dependent DFT (TD-DFT) to systematically investigate the ground- and excited-state properties of hybrid systems composed of CdSe quantum dots (QDs) with graphene and boron nitride (BN). Through Multiwfn wavefunction analysis, we calculated the highest occupied molecular orbital–lowest unoccupied molecular orbital (HOMO–LUMO) gaps and density of states (DOS), revealing distinct symmetry-dependent electronic characteristics. The HOMO–LUMO gap analysis demonstrates graphene’s superior charge transfer capability compared to BN, attributed to its higher structural symmetry enabling more efficient orbital overlap. DOS analysis further confirms the enhanced electrical conductivity in symmetry-matched graphene hybrids. The independent gradient model (IGM) and reduced density gradient (RDG) analyses reveal fundamentally different interfacial interaction patterns: the graphene hybrid exhibits uniform van der Waals interactions, consistent with its hexagonal symmetry, while the BN system shows heterogeneous interactions with localized hydrogen bonding due to symmetry reduction from heteroatomic composition. Binding energy calculations indicate greater stability in the graphene-based hybrid, reflecting optimal symmetry matching at the interface. UV–Vis spectra analysis shows that graphene dominates the optical response in its hybrid system, maintaining its symmetric spectral characteristics, while CdSe QDs govern the BN hybrid’s absorption. Electrostatic potential distributions remain essentially unchanged post-hybridization, preserving the intrinsic charge symmetry of components. Two-photon absorption (TPA) characterization reveals significant nonlinear optical properties in CdSe QDs, particularly at the first excited state. This work provides the first systematic comparison of charge transfer dynamics in CdSe QDs hybridized with graphene versus BN, demonstrating how material symmetry governs optoelectronic modulation mechanisms. The findings establish symmetry–property relationships that inform the design of low-dimensional hybrid materials for photonic applications. Full article

Rotating machinery is essential to modern industrial systems, where rolling bearings play a critical role in ensuring mechanical stability and operational efficiency. Failures in bearings can result in serious safety risks and significant financial losses, which highlights the need for accurate and robust methods for diagnosing bearing faults. Traditional diagnostic methods relying on single-source data often fail to fully leverage the rich information provided by multiple sensors and are more prone to performance degradation under noisy conditions. Therefore, this paper proposes a novel bearing fault diagnosis method based on a multi-level fusion framework. First, the Symmetrized Dot Pattern (SDP) method is applied to fuse multi-source signals into unified SDP images, enabling effective fusion at the data level. Then, a combination of RepLKNet and Bidirectional Gated Recurrent Unit (BiGRU) networks extracts multi-modal features, which are then fused through a cross-attention mechanism to enhance feature representation. Finally, information entropy is utilized to assess the reliability of each feature channel, enabling dynamic weighting to further strengthen model robustness. The experiments conducted on public datasets and noise-augmented datasets demonstrate that the proposed method significantly surpasses other single-source and multi-source data fusion models in terms of diagnostic accuracy and robustness to noise. Full article

Micro-motors are essential for power drive systems, and efficient fault diagnosis is crucial to reduce safety risks and economic losses caused by failures. However, the fault signals from micro-motors typically exhibit weak and unclear characteristics. To address this challenge, this paper proposes a novel fault diagnosis method that integrates jump plus AM-FM mode decomposition (JMD), symmetrized dot pattern (SDP) visualization, and an improved convolutional neural network (ICNN). Firstly, we employed the jump plus AM-FM mode decomposition technique to decompose the mixed fault signals, addressing the problem of mode mixing in traditional decomposition methods. Then, the intrinsic mode functions (IMFs) decomposed by JMD serve as the multi-channel inputs for symmetrized dot pattern, constructing a two-dimensional polar coordinate petal image. This process achieves both signal reconstruction and visual enhancement of fault features simultaneously. Finally, this paper designed an ICNN method with LeakyReLU activation function to address the vanishing gradient problem and enhance classification accuracy and training efficiency for fault diagnosis. Experimental results indicate that the proposed JMD-SDP-ICNN method outperforms traditional methods with a significantly superior fault classification accuracy of up to 99.2381%. It can offer a potential solution for the monitoring of electromechanical structures under complex conditions. Full article

To address the challenges posed by the difficulty of extracting fault features from rotating machinery with weak fault features, this paper proposes a rotating machinery structural faults feature enhancement and diagnosis method based on multi-sensor information fusion. Firstly, Savitzky–Golay filtering suppresses noise and enhances fault features. Secondly, the designed multi-sensor symmetric dot pattern (SDP) transformation method fuses multi-source information of the rotating machinery structural faults, providing more comprehensive and richer fault feature information for diagnosis. Finally, the ResNet18 model performs fault diagnosis. To validate the feasibility and effectiveness of the proposed method, two datasets verify its performance. The accuracy of the experimental results was 99.16% and 100%, respectively, demonstrating the feasibility and effectiveness of the proposed method. To further validate the superiority of the proposed method, it was compared with different 2D signal transformation methods. The comparison results indicate that the proposed method achieves the best fault diagnosis accuracy compared to other methods. Full article

The symmetrical Double-O-Tube (DOT) shield tunneling method, first developed in Japan in the 1980s, offers advantages in optimizing cross-sectional area and reducing construction space. While past studies have primarily focused on construction-induced settlement or empirical modeling, this study presents the first comprehensive three-dimensional seismic analysis of Taiwan’s first DOT shield tunnel, part of the CA450A contract of the Taoyuan International Airport MRT. A detailed numerical simulation is conducted using PLAXIS 3D 2024 with the Hardening Soil model, capturing both static and dynamic responses under earthquake loading. Notably, the analysis incorporates full-direction seismic input (3D) using Arias intensity-based filtering and scaling to assess the tunnel’s mechanical behavior under varying seismic intensities. Key structural responses such as displacement, axial force, shear force, and bending moment are evaluated. The findings reveal critical deformation patterns and stress concentrations in the central support structure, offering novel insights for the seismic design of complex multi-cell shield tunnels in high-risk seismic zones. Full article

The propeller state of unmanned aerial vehicles (UAV) is difficult to detect in real time due to trouble with laying out the sensor and multiple signal sources. To solve this problem, a fault detection method for multi-rotor UAV propellers was proposed based on a signal analysis of the built-in inertial measurement unit (IMU). Firstly, the multi-source coupled signals of the UAV flight were obtained through the ground station. Then, the picked-up signals were optimally separated according to the multi-rotor UAV propeller fault dynamics model, and signals rich in fault information were obtained. Finally, the separated signals were calculated using the symmetrized dot pattern (SDP), and then the similarity index was used to quantify the distribution of the signal in the feature plot to realize propeller fault detection. The OTSU algorithm was used to quantify the detection results, yielding a similarity of 76.2% in the z-axis direction, which is better than the values in the other two directions. The simulation and experimental analysis of the propeller failure dynamics model showed that the proposed method can effectively identify the propeller faults of multi-rotor UAVs. Full article

This paper proposes a hybrid algorithm combining the symmetrized dot pattern (SDP) method and a convolutional neural network (CNN) for fault detection in lithium battery modules. The study focuses on four fault types: overcharge, over-discharge, aging, and leakage caused by manual perforation. An 80.5 kHz high-frequency square wave signal is input into the battery module and recorded using a high-speed data acquisition card. The signal is processed by the SDP method to generate characteristic images for fault diagnosis. Finally, a deep learning algorithm is used to evaluate the state of the lithium battery. A total of 3000 samples were collected, with 400 samples used for training and 200 for testing for each fault type, achieving an overall identification accuracy of 99.9%, demonstrating the effectiveness of the proposed method. Full article

Traditional methods for detecting high-impedance faults (HIFs) in distribution networks primarily rely on constructing fault diagnosis models using one-dimensional zero-sequence current sequences. A single diagnostic model often limits the deep exploration of fault characteristics. To improve the accuracy of HIF detection, a new method for detecting HIFs in active distribution networks is proposed. First, by applying continuous wavelet transform (CWT) to the collected zero-sequence currents under various operating conditions, the time–frequency spectrum (TFS) is obtained. An optimized algorithm, modified empirical wavelet transform (MEWT), is then used to denoise the zero-sequence current signals, resulting in a series of intrinsic mode functions (IMFs). Secondly, the intrinsic mode functions (IMFs) are transformed into a two-dimensional spatial domain fused image using the symmetric dot pattern (SDP). Finally, the TFS and SDP images are synchronized as inputs to a hybrid convolutional neural network (Hybrid-CNN) to fully explore the system’s fault features. The Sigmoid function is utilized to achieve HIF detection, followed by simulation and experimental validation. The results indicate that the proposed method can effectively overcome the issues of traditional methods, achieving a detection accuracy of up to 98.85% across different scenarios, representing a 2–7% improvement over single models. Full article

In order to reduce the influence of environmental noise and different operating conditions on the accuracy of motor fault diagnosis, this paper proposes a capsule network method combining multi-channel signals and the efficient channel attention (ECA) mechanism, sampling the data from multiple sensors and visualizing the one-dimensional time-frequency domain as a two-dimensional symmetric dot pattern (SDP) image, then fusing the multi-channel image data and extracting the image using a capsule network combining the ECA attention mechanism features to match eight different fault types for fault classification. In order to guarantee the universality of the suggested model, data from Case Western Reserve University (CWRU) is used for validation. The suggested multi-channel signal fusion ECA attention capsule network (MSF-ECA-CapsNet) model fault identification accuracy may reach 99.21%, according to the experimental findings, which is higher than the traditional method. Meanwhile, the method of multi-sensor data fusion and the use of the ECA attention mechanism make the diagnosis accuracy much higher. Full article

Regarding the difficulty of extracting the acquired fault signal features of bearings from a strong background noise vibration signal, coupled with the fact that one-dimensional (1D) signals provide limited fault information, an optimal time frequency fusion symmetric dot pattern (SDP) bearing fault feature enhancement and diagnosis method is proposed. Firstly, the vibration signals are transformed into two-dimensional (2D) features by the time frequency fusion algorithm SDP, which can multi-scale analyze the fluctuations of signals at minor scales, as well as enhance bearing fault features. Secondly, the bat algorithm is employed to optimize the SDP parameters adaptively. It can effectively improve the distinctions between various types of faults. Finally, the fault diagnosis model can be constructed by a deep convolutional neural network (DCNN). To validate the effectiveness of the proposed method, Case Western Reserve University’s (CWRU) bearing fault dataset and bearing fault dataset laboratory experimental platform were used. The experimental results illustrate that the fault diagnosis accuracy of the proposed method is 100%, which proves the feasibility and effectiveness of the proposed method. By comparing with other 2D transformer methods, the experimental results illustrate that the proposed method achieves the highest accuracy in bearing fault diagnosis. It validated the superiority of the proposed methodology. Full article
