Dense and complex underground structures impose stringent requirements on shield tunneling. In the close-proximity construction of super-large-diameter shield tunnels, challenges may arise, including adverse impacts on the normal operation of existing structures, as well as difficulties in ensuring the bearing capacity and deformation control of these structures during excavation. This study, based on the stratigraphic conditions of the Chengdu area, employs FLAC3D 7.0 version software to simulate the section where the Shuanghua Road Tunnel underpasses both Metro Line 10 and the Chengdu-Guiyang High-Speed Railway. The main conclusions are as follows: (1) Tunnel underpassing induces uneven settlement in the metro tunnel, with a maximum settlement reaching 47.7 mm. The settlement trough exhibits a twin-peak morphology during dual-line construction. When a single super-large-diameter tunnel line crosses the existing structural cluster, the maximum settlement is located directly above the crossing point. During dual-line crossing, the maximum settlement shifts towards the midpoint between the two new tunnel lines. (2) As the left line of the new tunnel approaches the existing structure, the cross-sectional deformation of the existing structure is “pulled” towards the direction of the excavated new tunnel. After the new left line moves away, the cross-sectional deformation gradually recovers to a bilaterally symmetrical state. (3) The tunnel cross-section undergoes dynamic “compression-tension” convergence changes during the construction process, with a maximum longitudinal tensile convergence of −1.28 mm. (4) During the underpassing of the existing structural cluster by the super-large-diameter tunnel, the maximum torsion angle is approximately −0.016°, occurring at the moment when the shield machine head first passes directly beneath, located directly above the new tunnel. The torsion angle of the existing structure is greatest during the first underpassing event, and the maximum torsion angle during the second underpassing is lower than that during the first. This study reveals the composite deformation mode of “settlement-convergence-torsion” during the underpassing of existing structural clusters by super-large-diameter shield tunnels, providing a theoretical basis for risk control in similar adjacent engineering projects. Full article

This paper addresses the issue of stress redistribution in surrounding soil during the construction of shallow-buried, large-section loess tunnels. Using the Luochuan Tunnel as a case study, we employ the FLAC 3D numerical simulation method to investigate the effects of advanced pipe roof support on the stability of the surrounding soil. The results demonstrate that advanced pipe umbrella reduces the stress release amplitude at the vault by 50% compared to the unsupported condition, due to a “pre-support-load bearing mechanism”, while promoting orderly stress recovery. The “longitudinal beam effect” and “transverse arch effect” of soils effectively suppress the plastic zone area of the surrounding soil from 413.3 m² (unsupported) to 95.0 m², achieving a reduction exceeding 77%. Furthermore, the pipe umbrella support facilitates the formation of a more efficient “active soil arch”, which exhibits distinct symmetrical characteristics. The arch’s stress distribution and spatial structure both follow symmetrical patterns, significantly enhancing the self-stabilizing capacity of the surrounding soil. As a result, the height of the stress release zone at the tunnel excavation face and the surrounding soil stability areas is reduced by 45.9% and 63.3%, respectively, compared to the unsupported condition. This study also establishes a Pasternak elastic foundation beam model that accounts for the spatiotemporal effects of support, elucidating the mechanism of pipe umbrella support and providing a theoretical foundation for the design and construction risk control of shallow large-section loess tunnels. Full article

In order to clarify the influence of cross-section change mode of a large-span variable cross-section tunnel on the stability of the surrounding rock of a tunnel, four three-dimensional finite element models were established for four typical cross-section conversion forms: Sudden changes in the cross-section of the symmetric tunnel, Gradual changes in the cross-section of the symmetric tunnel, Sudden changes in the cross-section of the asymmetric tunnel, and Gradual changes in the cross-section of the asymmetric tunnel. The Stress characteristics and deformation laws of the surrounding rock under different cross-sectional changes were systematically analyzed. The simulation results were compared with the field monitoring results, and the construction scheme was optimized based on the results of the numerical analysis and field monitoring. The results demonstrate that the final settlement values for sudden changes in the cross-section of the symmetric tunnel and sudden changes in the cross-section of the asymmetric tunnel were 21.23 mm and 21.98 mm, respectively, representing reductions of 14.6% and 15.7% compared to gradual changes in the cross-section of the symmetric tunnel and gradual changes in the cross-section of the asymmetric tunnel. The final support stress values of sudden changes in the cross-section of the symmetric tunnel and sudden changes in the cross-section of the asymmetric tunnel were 8.59 and 7.88 MPa, respectively, representing reductions of 21.5% and 26.9% compared with gradual changes in the cross-section of the symmetric tunnel and gradual changes in the cross-section of the asymmetric tunnel. Compared with asymmetric construction, symmetrical construction is more likely to lead to a stress concentration effect on both sides of the tunnel. Considering the overall construction feasibility and economy, the asymmetric sudden-change construction scheme provides better comprehensive benefits. The research results can provide a theoretical basis and technical reference for solving engineering problems such as complex stress in a large section transition zone and difficult control of tunnel construction. Full article

Tunnels, as symmetric structures, are critical components of transportation infrastructure, particularly in mountainous regions. However, tunnel linings are prone to spalling after long-term service, posing significant safety risks. Although 3D laser scanning enables remote measurement of tunnel linings, existing surface fitting methods face challenges such as insufficient accuracy and high computational cost in quantifying spalling parameters. To address these issues, this study leverages the symmetrical geometry of tunnels to propose a curvature variance-based threshold segmentation method using limited point cloud data. First, the tunnel center axis is accurately determined via Sequential Quadratic Programming and the Quasi-Newton method. Noise and outliers are then removed based on geometric properties. Triangular meshes are constructed, and curvature variance is used as a threshold to extract spalling regions. Finally, surface reconstruction is applied to quantify spalling extent. Experiments in both laboratory and fire-damaged tunnel environments demonstrate that the method accurately extracts and quantifies lining spalling, with an average error of approximately 9.70%. This study underscores the potential of the proposed approach for broad application in tunnel inspection, as it will provide a basis for assessing the structural safety of tunnel linings. Full article

Circular deep excavations, characterized by their symmetrical geometry, are commonly employed in constructing foundations for large-span suspension bridges and as launching shafts for shield tunneling. However, the mechanical behavior of such excavations under asymmetric surface surcharge remains inadequately understood due to a paucity of relevant investigations. This study addresses this knowledge gap by establishing a three-dimensional finite element model (3D-FEA) based on the anchor deep excavation project of a specific bridge. The model is utilized to investigate the influence of asymmetric surcharge on the forces and deformations within the supporting structure. The results show that both the internal force and displacement cloud diagrams of the support structure exhibit asymmetric characteristics. The distribution of displacement and internal forces has spatial effects, and the maximum values all occur in the areas where asymmetric loads are applied. The maximum values of the displacement, axial force, and shear force of underground continuous walls increase with the increase in the excavation depth. The total displacement curves all show the feature of a “bulging belly”. The maximum displacement is 13.3 mm. The axial force is mainly compression, with a maximum value of −9514 kN/m. The maximum positive and negative values of the shear force are 333 kN/m and −705 kN/m, respectively. The bending moment diagram of different monitoring points shows the characteristics of “bow knot”. The maximum values of the positive bending moment and negative bending moment are 1509.4 kN·m/m and −2394.3 kN·m/m, respectively. The axial force of the ring beam is mainly compression, with a maximum value of −5360 kN, which occurs in ring beams 3, 4, and 5. The displacement cloud diagram of the support structure under symmetrical loads shows symmetrical characteristics. Under different load conditions, the displacement curve of the diaphragm wall shows the characteristics of “bulge belly”. The forms of loads with displacements from largest to smallest at the same position are as follows: asymmetric loads, symmetrical loads, and no loads. These findings provide valuable insights for optimizing the structural design of similar deep excavation projects and contribute to promoting sustainable urban underground development. Full article

The symmetrical Double-O-Tube (DOT) shield tunneling method, first developed in Japan in the 1980s, offers advantages in optimizing cross-sectional area and reducing construction space. While past studies have primarily focused on construction-induced settlement or empirical modeling, this study presents the first comprehensive three-dimensional seismic analysis of Taiwan’s first DOT shield tunnel, part of the CA450A contract of the Taoyuan International Airport MRT. A detailed numerical simulation is conducted using PLAXIS 3D 2024 with the Hardening Soil model, capturing both static and dynamic responses under earthquake loading. Notably, the analysis incorporates full-direction seismic input (3D) using Arias intensity-based filtering and scaling to assess the tunnel’s mechanical behavior under varying seismic intensities. Key structural responses such as displacement, axial force, shear force, and bending moment are evaluated. The findings reveal critical deformation patterns and stress concentrations in the central support structure, offering novel insights for the seismic design of complex multi-cell shield tunnels in high-risk seismic zones. Full article

The geological structure in western China is complex, and rigid catenary systems are commonly used for pantograph power supply in railway tunnel construction. Due to the space constraints within tunnels, the aerodynamic characteristics and fluid–structure interaction effects between pantographs and catenary systems directly affect train operational safety. Numerical simulation analysis of the pantograph–rigid catenary interaction in tunnels is revealed. In the pantograph, the connecting rod areas endure high pressure and are prone to fatigue damage, necessitating structural strength optimization. The rigid catenary exhibits laterally symmetric vibration with high torsional stiffness, meeting operational requirements. This study provides theoretical support for design improvements of pantograph–catenary systems in tunnel environments. Full article

Conventional numerical models frequently neglect the effects of strain softening and the spatial variability of surrounding rock when addressing the design and construction of deep tunnels in complex geological settings, which leads to a large deviation from the actual situation and potential security risks. In this case, symmetrical and asymmetric failure of surrounding rock usually occurs. In this paper, a numerical model considering strain softening and spatial variability is established for deep tunnel excavation based on the constitutive theory and probability distribution functions, and their effects on the mechanical behavior of tunnel excavation are systematically examined using FLAC3D software. The findings indicate that symmetrical failure will occur in strain-softening rock mass, and spatial variability will lead to asymmetric failure of surrounding rock. The strain-softening behavior of the internal friction angle has a pronounced impact on the plastic zone radius and post-excavation displacement. The distribution of stress and displacement in the surrounding rock is notably influenced by the spatial variability of the elastic modulus, while the variability in the internal friction angle can cause localized stress concentrations within the tunnel, potentially triggering partial collapse and instability. The coupling effect of strain softening and the spatial variability of surrounding rock properties will aggravate the mechanical response during tunnel excavation, resulting in greater displacement and more severe stress redistribution. Based on these findings, disaster prevention and control strategies are proposed for tunnels in complex geological regions, offering valuable guidance for engineering applications. Full article

Tunnels crossing active faults frequently experience simultaneous exposure to fault dislocation and seismic action during operation. To study the damage behavior of tunnels under the combined effects of fault dislocation and seismic action, a three-dimensional nonlinear finite element model was established. This model simulates fault dislocation superimposed on seismic action in the context of tunnel engineering through active faults. The main conclusions are as follows: (1) The acceleration amplification phenomenon occurs in the tunnels after the superposition of seismic action; at the same time, the degree and scope of tunnel damage increase significantly, in which the increase in tensile damage is more significant. (2) The initial damage from fault dislocation worsens tunnel damage under seismic action, as evidenced by the energy dissipation characteristics. (3) As the initial fault displacement and peak seismic acceleration increase, the extent of lining damage also increases. Notably, compressive damage to the lining is symmetrically distributed along the fault plane, whereas tensile damage is significantly more severe within the fault rupture zone. (4) Even moderate earthquakes can cause severe damage to tunnels crossing active faults. Therefore, tunnel construction in these areas must include disaster prevention and mitigation strategies. Full article

In the construction and operation stage of urban shield tunnels, joint leakage of shield is always an urgent problem to be solved. In order to further explore the waterproof performance of elastic rubber gaskets at segment joints, the finite element software ABAQUS (2022) was used to establish a fluid-solid coupling calculation model. The dynamic simulation of the leakage process at the segment joints under water pressure revealed the whole process of leakage at the segment joints and the instant water pressure value when the waterproof system failed. The results show that during the whole process from segment assembly to joint leakage, the elastic rubber gasket has experienced four key stages: gasket compression, confined water pushing, water wedge and final leakage. When the opening amount of the gasket is 6 mm and 10 mm, the contact stress between the gasket shows a “W” symmetrical distribution of high at both ends and low in the middle, and the peak of the contact stress at both ends of the interface is about twice as much as that in the middle. The waterproof threshold of the gasket is closely related to the opening amount of the gasket, and the waterproof threshold has the same trend with the initial contact stress between the gaskets. Full article

A grouting pad is the key structure for the construction of water inrush grouting on the shaft working surface. Previous methods of calculating the bearing capacity have limitations due to a lack of understanding of the failure mode. To investigate the bearing capacity of a concrete grouting pad on the working surface of a shaft, this paper establishes a mechanical model for the punching shear failure of a grouting pad under symmetrical loading conditions. A unified solution for the bearing capacity is derived, and the influence of parameters is discussed. In addition, a new method for designing the plastic limit thickness is proposed based on this research. The results show that the reason for the grouting pads’ punching shear failure resulted from the formation of peripheral grouting holes “weak ring” caused by the reduction of the bearing capacity. When the thickness of B₀ remains constant, the bearing capacity q_u of the grouting pad is inversely proportional to the ratio of the diameter and the area of the bottom load. Therefore, following the method of “dividing, interval, and jumping holes” during grouting construction is recommended. The greater the thickness of the grouting pad, the greater the bearing capacity q_u will be. When the grouting pad diameter is 2r₂ and the thickness B₀ is constant, the bearing capacity q_u increases with the material tensile strength f_t. When designing grouting pads, following the principles of “large thickness, uniform strength theory, high strength materials” will improve bearing performance. The findings have been implemented in the design of the grouting pad thickness for the Tianshan Shengli Tunnel shaft project, which can successfully solve the problem of frequent cracking caused by the weak bearing capacity of a grouting pad. The findings can provide a theoretical basis and reference for the design and construction of grouting pads in a highway tunnel shaft. Full article

There are stringent requirements on the vertical movement of a ground surface when using artificial ground freezing method to reinforce a shield tunnel in a city. This paper focused on the tunnel of Nanjing Metro Line Two between Yixianqiao and Daxinggong. Based on the discrete element thermo-mechanical coupling theory, the horizontal freezing reinforcement project was numerically simulated. The numerical results of the soil temperature field and displacement field are approximately compatible with the field measurements. When the tunnel was frozen for 40 days, an effectively frozen soil wall was created and satisfied the construction requirements. During the freezing construction, both frost heave and thaw settlement obviously occurred. Above the tunnel, the vertical deformation of the ground surface was symmetrical about the center of the tunnel and decayed towards the ends. The maximum vertical displacement of ground surface frost heave was 8 mm, and the maximum vertical displacement of ground surface thaw settlement was 18 mm. Increasing the depth of the tunnel embedment can result in a decline in ground surface displacement. The study serves as a viable means of predicting ground surface displacements. Full article

To meet the operational requirements of a new metro line in Guangzhou, China, a complex tunneling project was undertaken in a business area surrounded by high-rise buildings and underground utility pipelines. Two large-section mine tunnels, with a maximum excavation span of 15.6 m, were constructed, crossing beneath the existing metro line 7 in close proximity. To ensure construction safety, extensive field monitoring was conducted, investigating the deformation and stress characteristics of the newly built tunnel lining structures and settlement of existing tunnels during various construction stages. The findings indicate that the structural integrity of the newly built tunnels may be compromised by the ground pressure resulting from deep-hole grouting, which is aimed at protecting the existing metro line above. The primary lining of the new tunnels is particularly susceptible to stress at the arch waist, where it experiences significantly higher stress compared to the arch crown and arch foot. While constructing the secondary lining before removing temporary diaphragm supports can be advantageous in controlling ground settlement, the stress levels within the secondary lining can fluctuate significantly once the temporary supports are removed. Once the tunnels are completed as closed loops, the stress conditions in both the primary and secondary lining tend to stabilize. The secondary lining primarily undergoes flexural stress, with internal force diagrams roughly symmetrical to the cross-section center line, and the most vulnerable position being at the left arch waist or invert. This investigation provides valuable insights for the design and construction of similar engineering projects in the future. Full article

Columnar jointed rock mass (CJRM) formed by intact rock divided by special symmetrical columnar joints is a special type of rock with poor mechanical properties, strong anisotropy, and weak self-supporting ability, severely affecting the excavation safety and stability of underground tunnels. In this study, taking the Baihetan hydropower station as the engineering background, CJRM geological numerical models with different dip angles that combined well with the natural CJRM were generated based on the geological statistical parameters of the engineering site and were verified to have high rationality and accuracy. Tunnel excavation and overloading tests were carried out on these numerical models, and the results showed that the stress and displacement distributions after excavation exhibited strong anisotropic characteristics under different dip angles, and the positions where engineering safety problems are most likely to occur are the side walls, which are prone to stress-structure-controlled failure mode. The self-supporting ability at different dip angles after excavation from weak to strong are 45°, 60°, 75°, 90°, 30°, 0°, and 15°. The safety factors assessed by overloading for CJRM with dip angles of 0–90° degrees were 2.5, 2.6, 2.6, 1.8, 2.1, and 2.2, respectively, providing a valuable reference for the construction safety and support measures of CJRM excavation. Full article

The transportation system is one of the major infrastructures in urban areas, and it serves 56% of the world’s population. Nowadays, metro lines are developing fast in urban areas. Due to the restrictions of urban fields, metro lines are usually not planned straight, and a curved line is required to connect stations in different locations in a city. As a result, small curvature tunnels are commonly constructed in urban areas. The tunneling construction in a city area may cause ground settlement, which is sensitive to surrounding buildings and underground utilities. The aim of this study is to explore the impact of curvature alignment on the ground settlement. In this paper, ground settlements induced by small curvature shield tunneling were evaluated by using a numerical analysis. A total of six cases were selected for the analysis. The results obtained from the numerical simulations were compared with Peck’s equation. It is observed that Peck’s equation can be used for the estimation of the maximum settlement. However, the ground settlements on both sides of the central axis of the curved tunnel are asymmetrical, and Peck’s equation, which provides a symmetrical settlement, may not be applicable in the case of small curvature tunnels. Full article
