Search Results (20)

Search Parameters:
Keywords = surface maximum subsidence velocity

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
33 pages, 11005 KiB
Article
Temporal and Spatial Distribution of 2022–2023 River Murray Major Flood Sediment Plume
by Evan Corbett, Sami W. Rifai, Graziela Miot da Silva and Patrick A. Hesp
Remote Sens. 2025, 17(10), 1711; https://doi.org/10.3390/rs17101711 - 14 May 2025
Viewed by 826
Abstract
This study examined a sediment plume from Australia’s largest river, The River Murray, which was produced during a major flood event in 2022–2023. This flood resulted from successive La Niña events, causing high rainfall across the Murray–Darling Basin and ultimately leading to a [...] Read more.
This study examined a sediment plume from Australia’s largest river, The River Murray, which was produced during a major flood event in 2022–2023. This flood resulted from successive La Niña events, causing high rainfall across the Murray–Darling Basin and ultimately leading to a significant riverine flow through South Australia. The flood was characterised by a significant increase in riverine discharge rates, reaching a peak of 1305 m³/s through the Lower Lakes barrage system from November 2022 to February 2023. The water quality anomaly within the coastal region (<~150 km offshore) was effectively quantified and mapped utilising the diffuse attenuation coefficient at 490 nm (Kd490) from products derived from MODIS Aqua Ocean Color satellite imagery. The sediment plume expanded and intensified alongside the increased riverine discharge rates, which reached a maximum spatial extent of 13,681 km2. The plume typically pooled near the river’s mouth within the northern corner of Long Bay, before migrating persistently westward around the Fleurieu Peninsula through Backstairs Passage into Gulf St Vincent, occasionally exhibiting brief eastward migration periods. The plume gradually subsided by late March 2023, several weeks after riverine discharge rates returned to pre-flood levels, indicating a lag in attenuation. The assessment of the relationship and accuracy between the Kd490 product and the surface-most in situ turbidity, measured using conductivity, temperature, and depth (CTD) casts, revealed a robust positive linear correlation (R2 = 0.85) during a period of high riverine discharge, despite temporal and spatial discrepancies between the two datasets. The riverine discharge emerged as an important factor controlling the spatial extent and intensities of the surface sediment plume, while surface winds also exerted an influence, particularly during higher wind velocity events, as part of a broader interplay with other drivers. Full article
(This article belongs to the Section Ocean Remote Sensing)
Show Figures

Figure 1

22 pages, 15733 KiB
Article
Monitoring Fast-Growing Megacities in Emerging Countries Through the PS-InSAR Technique: The Case of Addis Ababa, Ethiopia
by Eyasu Alemu and Mario Floris
Land 2025, 14(5), 1020; https://doi.org/10.3390/land14051020 - 8 May 2025
Viewed by 574
Abstract
In the past three decades, the city of Addis Ababa, a capital city of Africa, has grown significantly in population, facilities, and infrastructure. The area involved in the recent urbanization is prone to slow natural subsidence phenomena that can be accelerated due to [...] Read more.
In the past three decades, the city of Addis Ababa, a capital city of Africa, has grown significantly in population, facilities, and infrastructure. The area involved in the recent urbanization is prone to slow natural subsidence phenomena that can be accelerated due to anthropogenic factors such as groundwater overexploitation and loading of unconsolidated soils. The main aim of this study is to identify and monitor the areas most affected by subsidence in a context, such as that of many areas of emerging countries, characterized by the lack of geological and technical data. In these contexts, advanced remote sensing techniques can support the assessment of spatial and temporal patterns of ground instability phenomena, providing critical information on potential conditioning and triggering factors. In the case of subsidence, these factors may have a natural or anthropogenic origin or result from a combination of both. The increasing availability of SAR data acquired by the Sentinel-1 mission around the world and the refinement of processing techniques that have taken place in recent years allow one to identify and monitor the critical conditions deriving from the impressive recent expansion of megacities such as Addis Ababa. In this work, the Sentinel-1 SAR images from Oct 2014 to Jan 2021 were processed through the PS-InSAR technique, which allows us to estimate the deformations of the Earth’s surface with high precision, especially in urbanized areas. The obtained deformation velocity maps and displacement time series have been validated using accurate second-order geodetic control points and compared with the recent urbanization of the territory. The results demonstrate the presence of areas affected by a vertical rate of displacement of up to 21 mm/year and a maximum displacement of about 13.50 cm. These areas correspond to sectors that are most predisposed to subsidence phenomena due to the presence of recent alluvial deposits and have suffered greater anthropic pressure through the construction of new buildings and the exploitation of groundwater. Satellite interferometry techniques are confirmed to be a reliable tool for monitoring potentially dangerous geological processes, and in the case examined in this work, they represent the only way to verify the urbanized areas exposed to the risk of damage with great effectiveness and low cost, providing local authorities with crucial information on the priorities of intervention. Full article
(This article belongs to the Special Issue Assessing Land Subsidence Using Remote Sensing Data)
Show Figures

Figure 1

18 pages, 28966 KiB
Article
Time Series Analysis of Mining-Induced Subsidence Using Small Baseline Subset Interferometric Synthetic Aperture Radar (Wanli Mining Area, Inner Mongolia, China)
by Xinlei Xue, Jinzhu Ji, Guoping Li, Huaibin Li, Qi Cao and Kai Wang
Appl. Sci. 2025, 15(7), 3998; https://doi.org/10.3390/app15073998 - 4 Apr 2025
Viewed by 599
Abstract
The conflict between exploitation of coal resources and environmental protection is highly pronounced in the Wanli mining area, located in the arid and semi-arid region of Inner Mongolia, China. The impact of mining operations has led to varying degrees of surface subsidence, which [...] Read more.
The conflict between exploitation of coal resources and environmental protection is highly pronounced in the Wanli mining area, located in the arid and semi-arid region of Inner Mongolia, China. The impact of mining operations has led to varying degrees of surface subsidence, which further threatens the ecological environment as coal extraction continues. The Small Baseline Subset Interferometric Synthetic Aperture Radar (SBAS-InSAR) technique offers significant advantages over traditional subsidence monitoring methods, particularly in complex terrain with vertical and horizontal valleys. This approach enables large-scale, low-cost, and all-weather monitoring. Based on 64 Sentinel-1A SAR images from 2018 to 2023, this study aims to promptly identify the location, deformation degree, and evolution characteristics of mining-induced subsidence within the study area using SBAS-InSAR techniques. The results indicate that the area affected by mining-induced subsidence covers 109.73 km2, with a maximum cumulative subsidence of 283.41 mm and a maximum subsidence velocity of 46.45 mm/y. Additionally, during the field verification, 29 ground fractures, predominantly located along the precipitous borders of subsidence areas, were identified, validating the credibility of the monitoring results. This study demonstrates that SBAS-InSAR technology remains highly effective in the erosional terrain of the Loess Plateau. The monitoring data can help in-production mining to accurately identify the characteristics and patterns of surface subsidence induced by coal mining operations. It provides reliable policymaking data support and makes significant contributions to optimize cost-efficiency and guide targeted monitoring efforts in subsequent management work of the Wanli mining area as well as other mining areas. Full article
Show Figures

Figure 1

25 pages, 7456 KiB
Article
A Method for Predicting the Surface Subsidence Duration and the Maximum Subsidence Velocity
by Yanjun Zhang, Fei Wang, Yueguan Yan, Yuanhao Zhu, Linda Dai and Jiayuan Kong
Land 2024, 13(12), 2016; https://doi.org/10.3390/land13122016 - 26 Nov 2024
Viewed by 742
Abstract
The surface subsidence duration and the maximum subsidence velocity are critical indicators to evaluate the stability and severity of surface damage. Precisely predicting them is important for guiding engineering design and protecting ground infrastructure. Traditional manual measurement methods are time-consuming and laborious, and [...] Read more.
The surface subsidence duration and the maximum subsidence velocity are critical indicators to evaluate the stability and severity of surface damage. Precisely predicting them is important for guiding engineering design and protecting ground infrastructure. Traditional manual measurement methods are time-consuming and laborious, and the existing empirical formulas have low accuracy and poor applicability. Therefore, a new prediction method was established in this paper. Measured data from 30 mining areas were used for verification. The results show that the predicted surface subsidence duration is basically consistent with the measured value. The standard deviation of the two is 61 d, and the relative standard deviation is 6.6%. The predicted surface maximum subsidence velocity is basically consistent with the measured value. The standard deviation of the two is 10.0 mm/d, and the relative standard deviation is 1.6%. The surface subsidence duration and the maximum subsidence velocity are positively correlated with the coal seam thickness, negatively and positively correlated with the mining speed, and positively and negatively correlated with the mining depth. The mining speed and mining depth have the same sensitivity to the two indicators, and the coal seam thickness is more sensitive to the surface subsidence duration. Furthermore, construction within the subsidence basin may further contribute to surface subsidence. Therefore, land reuse measures should be implemented following the predicted surface subsidence duration in this paper. This study addresses the knowledge gap in this field by deriving theoretical formulas for surface subsidence duration and maximum subsidence velocity. In the absence of sufficient measured data, engineers can calculate predicted values in combination with geological mining conditions and develop appropriate mining plans based on the extent of surface subsidence. Full article
(This article belongs to the Section Land – Observation and Monitoring)
Show Figures

Figure 1

20 pages, 5775 KiB
Article
Dynamic Prediction Model for Progressive Surface Subsidence Based on MMF Time Function
by Bang Zhou, Yueguan Yan and Jianrong Kang
Appl. Sci. 2023, 13(14), 8066; https://doi.org/10.3390/app13148066 - 10 Jul 2023
Cited by 8 | Viewed by 1688
Abstract
It is imperative to timely and accurately predict the progressive surface subsidence caused by coal mining in the context of precision coal mining. However, the existing dynamic prediction methods that use time functions still have limitations, especially in the description of the moments [...] Read more.
It is imperative to timely and accurately predict the progressive surface subsidence caused by coal mining in the context of precision coal mining. However, the existing dynamic prediction methods that use time functions still have limitations, especially in the description of the moments of initiation and maximum subsidence velocity, which hinder their wide application. In this study, we proposed the MMF (Morgan–Mercer–Flodin) time function for predicting progressive surface subsidence based on the model assumptions and formula derivations. MMF time function can resolve the limitations in the description of the moments of initiation and maximum subsidence velocity perfectly. Afterward, we established the dynamic prediction model by combining the probability integral method with the MMF time function. Finally, using the measured subsidence data of working panel 22101 as an example, the accuracy and reliability of the dynamic prediction model was verified. The average RMSE and average relative RMSE (RRMSE) of prediction progressive subsidence using MMF time function are 46.65 mm and 4.63%, respectively. The accuracy is optimal compared with other time functions (for the average RMSE, Logistic time function is 80.57 mm, Gompertz time function is 79.77 mm, and Weibull time function is 90.61 mm; for the average RRMSE, Logistic time function is 7.66%, Gompertz time function is 7.73%, and Weibull time function is 8.62%). The results show that the method proposed in this paper can fully meet the requirements of practical engineering applications, achieve accurate dynamic prediction during the coal mining process, and provide good guidance for surface deformation and building protection. Full article
(This article belongs to the Special Issue Land Subsidence: Monitoring, Prediction and Modeling - 2nd Edition)
Show Figures

Figure 1

27 pages, 9274 KiB
Article
Multi-Source SAR-Based Surface Deformation Monitoring and Groundwater Relationship Analysis in the Yellow River Delta, China
by Yilin Liu, Yi Zhang, Faqiang Zhao, Renwei Ding, Lihong Zhao, Yufen Niu, Feifei Qu and Zilong Ling
Remote Sens. 2023, 15(13), 3290; https://doi.org/10.3390/rs15133290 - 27 Jun 2023
Cited by 8 | Viewed by 2392
Abstract
Land motions are significantly widespread in the Yellow River delta (YRD). There is, however, a lack of understanding of the delta-wide comprehensive deformation mode and its dynamic mechanism, especially triggered by groundwater extraction. This paper adopts an integrated analysis of multidisciplinary data of [...] Read more.
Land motions are significantly widespread in the Yellow River delta (YRD). There is, however, a lack of understanding of the delta-wide comprehensive deformation mode and its dynamic mechanism, especially triggered by groundwater extraction. This paper adopts an integrated analysis of multidisciplinary data of image geodesy, geophysics, geology and hydrogeology to provide insights into Earth surface displacement patterns and dynamics in the YRD. Delta-scale land motions were measured for the first time using L-band ALOS images processed using multi-temporal InSAR, illustrating multiple obvious surface sinking regions and a maximum annual subsidence velocity of up to 130 mm. Then, the InSAR-constrained distributed point source model with optimal kernel parameters, a smoothness factor of 10 and a model grid size of 300 m was established and confirmed to be rational, reliable and accurate for modeling analysis over the YRD. Remarkable horizontal surface displacements, moving towards and converging on a sinking center, were recovered by means of modeling and measured using InSAR, with a maximum rate of up to 60 mm per year, which can trigger significant disasters, such as ground fissures and building damage. In addition, the annual total water storage variation at the delta scale, the most meaningful outcome, can be calculated and reaches a total of approximately 12,010 × 103 m3 in Guangrao city, efficiently filling the gap of GRACE and in situ investigations for delta-wide aquifer monitoring. Finally, a comparative analysis of time series InSAR measurements, modeling outcomes, and fault and groundwater data was conducted, and the strong agreement demonstrates that faults control aquifer distribution and hence the spatial distribution of groundwater-withdrawal-related regional land subsidence. Moreover, the obvious asymmetric displacements, demonstrating a northeasterly displacement trend, further reveal that faults control aquifer distribution and Earth surface deformation. These findings are useful for understanding the land motion patterns and dynamics, helping to sustainably manage groundwater and control disasters in the YRD and elsewhere worldwide. Full article
(This article belongs to the Special Issue InSAR Imaging of Coastal Geohazards)
Show Figures

Graphical abstract

19 pages, 27954 KiB
Article
Deformation Monitoring and Analysis of Reservoir Dams Based on SBAS-InSAR Technology—Banqiao Reservoir
by Zhiguo Pang, Qingguang Jin, Peng Fan, Wei Jiang, Juan Lv, Pengjie Zhang, Xiangrui Cui, Chun Zhao and Zhengjia Zhang
Remote Sens. 2023, 15(12), 3062; https://doi.org/10.3390/rs15123062 - 12 Jun 2023
Cited by 10 | Viewed by 3759
Abstract
Most dams in China have been operating for a long time and are products of the economic and technical limitations at the time of construction. Due to decades of aging engineering and ancillary problems, these reservoirs pose great threats to the safety of [...] Read more.
Most dams in China have been operating for a long time and are products of the economic and technical limitations at the time of construction. Due to decades of aging engineering and ancillary problems, these reservoirs pose great threats to the safety of local people and the development of the surrounding economy. In this study, the surface deformation information for the Banqiao Reservoir is monitored with the small baseline subset–synthetic aperture radar interferometry (SBAS-InSAR) method using 80 Sentinel-1A images acquired from 3 January 2020 to 20 August 2022. Additionally, ground measurements from the BeiDou ground-based deformation monitoring stations were collected to validate the InSAR results. Based on the InSAR results, the spatiotemporal deformation features of the dam were analyzed in detail. The results show that the deformation in most areas, including the dam in the study area, is relatively stable, and the regional deformation velocity of the Banqiao Reservoir dam and other hydraulic engineering facilities varies between −1 mm/y and −4 mm/y. The Ru River area has a relatively obvious subsidence trend, and the maximum subsidence velocity reaches 30 mm/y. The InSAR monitoring results are consistent with the change trend in the BeiDou ground-based deformation measurement results. The monitoring results for the reservoir dam area provide a reference for local sustainable development and geological disaster prevention. Full article
Show Figures

Graphical abstract

21 pages, 5370 KiB
Article
Overlying Strata Dynamic Movement Law and Prediction Method Caused by Longwall Coal-Mining: A Case Study
by Guosheng Xu, Dehai Li, Yanbin Zhang and Huigui Li
Processes 2023, 11(2), 428; https://doi.org/10.3390/pr11020428 - 31 Jan 2023
Cited by 3 | Viewed by 1968
Abstract
The surface subsidence caused by underground mining is a spatiotemporal process. The impact of mining on surface structures (houses, highways, railways, dikes, etc.) and structures in rock strata (shafts, roadways, chambers, etc.) is a dynamic process. It is necessary to study the dynamic [...] Read more.
The surface subsidence caused by underground mining is a spatiotemporal process. The impact of mining on surface structures (houses, highways, railways, dikes, etc.) and structures in rock strata (shafts, roadways, chambers, etc.) is a dynamic process. It is necessary to study the dynamic movement law of the surface and overlying strata in the mining process of the working face to predict the extent of the impact of mining on the aforementioned structures. It provides a reference for pre-reinforcement and post-mining treatment. This paper studies the variation of surface dynamic movement based on the survey line above the working face of Peigou Coal Mine. The numerical simulation model of the overlying strata dynamic movement is established to study the dynamic movement law of rock strata with different depths, and the fitting function of surface and overlying strata dynamic movement is determined. Finally, the subsidence velocity prediction function of the major section of the surface and overlying strata in the Peigou Coal Mine is established. The accuracy of this prediction function is demonstrated by contrasting the subsidence and subsidence velocity curves of the surface subsidence basin survey line with the numerical model. In this paper, a numerical simulation method for the dynamic movement of the surface and overlying strata and a function for predicting the subsidence velocity on the strike major section are established, which provides an important theoretical reference for the dynamic protection of the structures on the surface and in the overlying strata. Full article
(This article belongs to the Special Issue Process Safety in Coal Mining)
Show Figures

Figure 1

32 pages, 34927 KiB
Article
Study on Regional Strata Movement during Deep Mining of Erdos Coal Field and Its Control
by Guojian Zhang, Zhiyang Wang, Guangli Guo, Wei Wei, Fugang Wang, Leilei Zhong and Yaqiang Gong
Int. J. Environ. Res. Public Health 2022, 19(22), 14902; https://doi.org/10.3390/ijerph192214902 - 12 Nov 2022
Cited by 11 | Viewed by 1941
Abstract
Disasters such as rock bursts and mine earthquakes became increasingly serious with the increase in mining depth in Erdos Coal Field and became serious problems that restrict high-strength continuous mining of coal mines. In this study, strata movement and energy polling distribution of [...] Read more.
Disasters such as rock bursts and mine earthquakes became increasingly serious with the increase in mining depth in Erdos Coal Field and became serious problems that restrict high-strength continuous mining of coal mines. In this study, strata movement and energy polling distribution of ultrathick weak-bonding sandstone layers were controlled by the local filling–caving multi-faces coordinated mining technique, which was based on the analysis of subsidence and overlying structural characteristics in the Yingpanhao mining area. Moreover, the influencing factors and the control effect laws were investigated. Surface subsidence and energy polling distribution control effects of different mining modes were compared, which confirmed the superiority of local filling based on the main key stratum. According to the results, the maximum surface subsidence velocity of the first mining face was 1.24 mm/d, which indicates the presence of a logistic functional relationship between the mining degree and subsidence factors. When the mining degree was close to full mining, the practical surface subsidence was smaller than the corresponding logistic functional value. The largest influencing factor for the strata movement control effect of partial filling mining based on the main key stratum was the width of the caving face, followed by the filling ratio, section pillar width, and width of the filling face, successively. With respect to the influencing degree on the energy polling distribution of partial filling mining based on the main key stratum, the order followed as section pillar width > filling ratio > caving working face > width of backfilling working face. Additionally, the comparative analysis from the perspectives of control effect, resource utilization, and cost-effectiveness demonstrated that partial filling mining based on the main key stratum was one of the techniques with high cost-effectiveness in controlling strata movement and relieving rock bursts, mining earthquakes, and subsidence disasters. Full article
Show Figures

Figure 1

23 pages, 81587 KiB
Article
Quantifying Two-Dimensional Surface Displacements Using High-Resolution Cosmo-SkyMed, TerraSAR-X and Medium-Resolution Sentinel-1 SAR Interferometry: Case Study for the Tengiz Oilfield
by Emil Bayramov, Giulia Tessari and Martin Kada
Sensors 2022, 22(17), 6416; https://doi.org/10.3390/s22176416 - 25 Aug 2022
Cited by 8 | Viewed by 3256
Abstract
The present study was aimed at comparing vertical and horizontal surface displacements derived from the Cosmo-SkyMED, TerraSAR-X and Sentinel-1 satellite missions for the detection of oil extraction-induced subsidence in the Tengiz oilfield during 2018–2021. The vertical and horizontal surface displacements were derived using [...] Read more.
The present study was aimed at comparing vertical and horizontal surface displacements derived from the Cosmo-SkyMED, TerraSAR-X and Sentinel-1 satellite missions for the detection of oil extraction-induced subsidence in the Tengiz oilfield during 2018–2021. The vertical and horizontal surface displacements were derived using the 2D decomposition of line-of-sight measurements from three satellite missions. Since the TerraSAR-X mission was only available from an ascending track, it was successfully decomposed by combining it with the Cosmo-SkyMED descending track. Vertical displacement velocities derived from 2D Decomposition showed a good agreement in similar ground motion patterns and an average regression coefficient of 0.98. The maximum average vertical subsidence obtained from the three satellite missions was observed to be −57 mm/year. Higher variations and deviations were observed for horizontal displacement velocities in terms of similar ground motion patterns and an average regression coefficient of 0.80. Fifteen wells and three facilities were observed to be located within the subsidence range between −55.6 mm/year and −42 mm/year. The spatial analyses in the present studies allowed us to suspect that the subsidence processes occurring in the Tengiz oilfield are controlled not solely by oil production activities since it was clearly observed from the detected horizontal movements. The natural tectonic factors related to two seismic faults crossing the oilfield, and terrain characteristics forming water flow towards the detected subsidence hotspot, should also be considered as ground deformation accelerating factors. The novelty of the present research for Kazakhstan’s Tengiz oilfield is based on the cross-validation of vertical and horizontal surface displacement measurements derived from three radar satellite missions, 2D Decomposition of Cosmo-SkyMED descending and TerraSAR-X ascending line-of-sight measurements and spatial analysis of man-made and natural factors triggering subsidence processes. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1

23 pages, 6205 KiB
Article
Analysis of Factors Influencing Mining Damage Based on Engineering Detection and Machine Learning
by Lintian Miao, Zhonghui Duan, Yucheng Xia, Rongjun Du, Tingting Lv and Xueyang Sun
Sustainability 2022, 14(15), 9622; https://doi.org/10.3390/su14159622 - 4 Aug 2022
Cited by 7 | Viewed by 2629
Abstract
The direct results of mining damage are overburden fracture and surface subsidence, which may induce groundwater seepage and surface vegetation degradation. Therefore, it is essential to research the factors and mechanisms influencing mining damage. Based on the geological characteristics of the Xiaobaodang minefield [...] Read more.
The direct results of mining damage are overburden fracture and surface subsidence, which may induce groundwater seepage and surface vegetation degradation. Therefore, it is essential to research the factors and mechanisms influencing mining damage. Based on the geological characteristics of the Xiaobaodang minefield in the Yushen Mine area in China, the engineering detection of fractured zone height (FZH), sampling tests of rock mechanical properties, and field measurements of the surface settlement were carried out. Firstly, the factors influencing the FZH were screened by correlation analysis and partial correlation analysis. Next, a model for predicting the maximum height of the fracture zone with the BP neural network (BPNN) was established and trained with Python. Finally, the FLAC3D numerical simulation experiment was adopted to reveal the variation law of overburden stress during coal mining, and the relationship between stress and overburden fracture was analyzed. The results show the following: When the average mining thickness in the study area is 5.8 m, the maximum height of the fractured zone is 157.46 m, and the maximum surface subsidence is 3715 mm. Further, the mining thickness, mining depth, the compressive strength of overburden, the width of the working face, and the mining velocity are the main factors affecting the maximum height of the fractured zone. Additionally, the goodness of fit of the BPNN model can reach 97.22%, meaning that it can effectively predict the maximum height of the fractured zone caused by coal mining. Finally, the area where the stress changes markedly above the goaf is the area where the fractures develop rapidly. Meanwhile, there is a positive correlation between the surface subsidence and the FZH. The research results obtained provide new ideas for reducing mining damage and will be helpful for the green and sustainable development of the mine. Full article
(This article belongs to the Special Issue Deep Mining Engineering in Sustainability)
Show Figures

Figure 1

15 pages, 5637 KiB
Article
Influence of Open-Pit Coal Mining on Ground Surface Deformation of Permafrost in the Muli Region in the Qinghai-Tibet Plateau, China
by Hongwei Wang, Yuan Qi, Juan Zhang, Jinlong Zhang, Rui Yang, Junyu Guo, Dongliang Luo, Jichun Wu and Shengming Zhou
Remote Sens. 2022, 14(10), 2352; https://doi.org/10.3390/rs14102352 - 12 May 2022
Cited by 10 | Viewed by 3135
Abstract
The Qinghai-Tibet Plateau (QTP) is the largest mid-to low latitude and high-altitude permafrost. Open-pit coal mining and other activities have caused serious damage to the alpine ecological environment and have accelerated the degradation of permafrost on the QTP. In this study, the influence [...] Read more.
The Qinghai-Tibet Plateau (QTP) is the largest mid-to low latitude and high-altitude permafrost. Open-pit coal mining and other activities have caused serious damage to the alpine ecological environment and have accelerated the degradation of permafrost on the QTP. In this study, the influence of open-pit coal mining on the time series ground surface deformation of the permafrost in the Muli region of the QTP was analyzed from 19 January 2018 to 22 December 2020 based on Landsat, Gaofen, and Sentinel remote sensing data. The primary methods include human-computer interactive visual interpretation and the small baseline subsets interferometric synthetic aperture radar (SBAS-InSAR) method. The results showed that the spatial distribution of displacement velocity exhibits a considerably different pattern in the Muli region. Alpine meadow is the main land use/land cover (LULC) in the Muli region, and the surface displacement was mainly subsidence. The surface subsidence trend in alpine marsh meadows was obvious, with a subsidence displacement velocity of 10–30 mm/a. Under the influence of changes in temperature, the permafrost surface displacement was characteristics of regular thaw subsidence and freeze uplift. Surface deformation of the mining area is relatively severe, with maximum uplift displacement velocity of 74.31 mm/a and maximum subsidence displacement velocity of 167.51 mm/a. Open-pit coal mining had resulted in the destruction of 48.73 km2 of natural landscape in the Muli region. Mining development in the Muli region had increased the soil moisture of the alpine marsh meadow around the mining area, resulting in considerable cumulative displacement near the mining area and the acceleration of permafrost degradation. Full article
Show Figures

Figure 1

18 pages, 9423 KiB
Article
Interferometric SAR Observation of Permafrost Status in the Northern Qinghai-Tibet Plateau by ALOS, ALOS-2 and Sentinel-1 between 2007 and 2021
by Lichuan Zou, Chao Wang, Yixian Tang, Bo Zhang, Hong Zhang and Longkai Dong
Remote Sens. 2022, 14(8), 1870; https://doi.org/10.3390/rs14081870 - 13 Apr 2022
Cited by 16 | Viewed by 3120
Abstract
With global warming, permafrost is undergoing degradation, which may cause thawing subsidence, collapse, and emission of greenhouse gases preserved in previously frozen permafrost, change the local hydrology and ecology system, and threaten infrastructure and indigenous communities. The Qinghai-Tibet Plateau (QTP) is the world’s [...] Read more.
With global warming, permafrost is undergoing degradation, which may cause thawing subsidence, collapse, and emission of greenhouse gases preserved in previously frozen permafrost, change the local hydrology and ecology system, and threaten infrastructure and indigenous communities. The Qinghai-Tibet Plateau (QTP) is the world’s largest permafrost region in the middle and low latitudes. Permafrost status monitoring in the QTP is of great significance to global change and local economic development. In this study, we used 66 scenes of ALOS data (2007–2009), 73 scenes of ALOS-2 data (2015–2020) and 284 scenes of Sentinel-1 data (2017–2021) to evaluate the spatial and temporal permafrost deformation over the 83,000 km2 in the northern QTP, passing through the Tuotuohe, Beiluhe, Wudaoliang and Xidatan regions. We use the SBAS-InSAR method and present a coherence weighted least squares estimator without any hypothetical model to calculate long-term deformation velocity (LTDV) and maximum seasonal deformation (MSD) without any prior knowledge. Analysis of the ALOS results shows that the LTDV ranged from −20 to +20 mm/year during 2007–2009. For the ALOS-2 and Sentinel-1 results, the LTDV ranged from −30 to 30 mm/year during 2015–2021. Further study shows that the expansion areas of permafrost subsidence are concentrated on braided stream plains and thermokarst lakes. In these areas, due to glacial erosion, surface runoff and river alluvium, the contents of water and ground ice are sufficient, which could accelerate permafrost subsidence. In addition, by analyzing LTDV and MSD for the different periods, we found that the L-band ALOS-2 is more sensitive to the thermal collapse of permafrost than the C-band sensor and the detected collapse areas (LTDV < −10 mm/year) are consistent with the GF-1/2 thermal collapse dataset. This research indicates that the InSAR technique could be crucial for monitoring the evolution of permafrost and freeze-thaw disasters. Full article
(This article belongs to the Special Issue ALOS-2/PALSAR-2 Calibration, Validation, Science and Applications)
Show Figures

Graphical abstract

16 pages, 11207 KiB
Article
Quantitative Assessment of Vertical and Horizontal Deformations Derived by 3D and 2D Decompositions of InSAR Line-of-Sight Measurements to Supplement Industry Surveillance Programs in the Tengiz Oilfield (Kazakhstan)
by Emil Bayramov, Manfred Buchroithner, Martin Kada and Yermukhan Zhuniskenov
Remote Sens. 2021, 13(13), 2579; https://doi.org/10.3390/rs13132579 - 1 Jul 2021
Cited by 30 | Viewed by 4863
Abstract
This research focused on the quantitative assessment of the surface deformation velocities and rates and their natural and man-made controlling factors at Tengiz Oilfield in Kazakhstan using the Small Baseline Subset remote sensing technique followed by 3D and 2D decompositions and cosine corrections [...] Read more.
This research focused on the quantitative assessment of the surface deformation velocities and rates and their natural and man-made controlling factors at Tengiz Oilfield in Kazakhstan using the Small Baseline Subset remote sensing technique followed by 3D and 2D decompositions and cosine corrections to derive vertical and horizontal movements from line-of-sight (LOS) measurements. In the present research we applied time-series of Sentinel-1 satellite images acquired during 2018–2020. All ground deformation derivatives showed the continuous subsidence at the Tengiz oilfield with increasing velocity. 3D and 2D decompositions of LOS measurements to vertical movement showed that the Tengiz Oil Field 2018–2020 continuously subsided with the maximum annual vertical deformation velocity around 70 mm. Based on the LOS measurements, the maximum annual subsiding velocity was observed to be 60 mm. Cosine corrections of LOS measurements to vertical movement, however, revealed a maximum annual vertical deformation velocity of 77 mm. The vertical deformation confirmed typical patterns of subsidence caused by oil extraction. Detected east-west and north-south horizontal movements at the Tengiz field clearly indicated that the study area crossed by seismic faults is affected by natural tectonic processes. The overall RMSE of 3D decomposed vertical deformation in relationship to LOS measurements and cosine corrections were in the range of 10–13 mm and 6–8 mm, correspondingly. The results of the present research will support operators of oil and gas fields and also other types of infrastructure to evaluate the actual differences of InSAR ground deformation measurements against the required standards and the precision of measurements depending on the operational needs, timeframes and availability of radar imagery. Full article
Show Figures

Figure 1

19 pages, 3032 KiB
Article
Stability Evaluation of an Expressway Construction Site above an Abandoned Coal Mine Based on the Overlay and Index Method
by Qingbiao Guo, Guangli Guo, Yingming Li, Lei Wang and Xingwang Zhao
Sustainability 2019, 11(19), 5163; https://doi.org/10.3390/su11195163 - 20 Sep 2019
Cited by 14 | Viewed by 2887
Abstract
In recent years, more and more expressways pass through the abandoned coal mine, while the surface residual subsidence of the abandoned coal mine threatens the operation safety of the expressway. It is of significance to evaluate the stability of the construction site and [...] Read more.
In recent years, more and more expressways pass through the abandoned coal mine, while the surface residual subsidence of the abandoned coal mine threatens the operation safety of the expressway. It is of significance to evaluate the stability of the construction site and take reasonable managements for effectively guaranteeing the traffic safety. How to accurately evaluate the stability of the construction site is the primary problem. This study proposes a stability evaluation model using the overlay and index method and points out that the evaluation scores and weights of evaluation indices are key parameters to determine the reliability of evaluation results. To reasonably determine the evaluation score, the scoring criteria of qualitative indices is obtained by the equidistant method, while the scoring criteria of quantitative indices is obtained by establishing scoring functions. The weights of evaluation indices are got by adopting the FAHP (fuzzy analytic hierarchy process). Then the built model is applied to evaluate the stability of the Wuyun Expressway construction site, and the results show that the Wuyun Expressway construction site is basic stable. Finally, the sensitivity of indices weights on the evaluation result is analyzed with the maximum C k ( C m , p c ) of 5.9% far lower than the weight change of ±30%, and the average residual subsidence velocity of the maximum subsidence point is 0.0456 mm/d using a high-resolution leveling, proving the credibility of the proposed model. Research results provide new ideas and systematic technical references for the stability evaluation of the construction site above an abandoned coal mine. Full article
(This article belongs to the Section Sustainable Transportation)
Show Figures

Figure 1
