Non-contact, non-destructive testing of surface microgeometry plays a key role in such industries as microelectronics, additive manufacturing, and precision engineering. This paper presents the development and experimental testing of a digital holographic system based on a low-coherence laser diode operating at two close wavelengths, designed to measure height differences in the micrometer range. The method is based on a Michelson interferometer and reconstruction of the complex amplitude of the object wave, which allows phase measurements with subsequent phase conversion into heights. The tests were carried out on micrometer roughness standards with a trapezoidal profile with a groove depth from 24.5 μm to 100 μm and a profile width from 65 μm to 150 μm, as well as on reference strokes with a width from 25 to 200 μm. The obtained data demonstrate the possibility of three-dimensional and two-dimensional visualization of the objects under study with a relative error in height from 5.3% to 11.6% and in width up to 18.6%. It is shown that the system allows reliable measurement of defects of metal surfaces in the range from 25 to 100 μm both vertically and horizontally. Thus, the developed method can be used for high-precision, non-destructive testing in a wide range of technological tasks. Full article

This work assesses the frictional wear of lubricated transmission chains, correlating the coefficient of friction, root mean square (RMS) acoustic emissions, and vibrations induced by friction, incorporating Industrial Internet of Things (IIoT) components. The work is divided into two phases: understanding the frictional interactions between the steel pins of commercial transmission chain and high chrome steel plate (mimicking the interaction between the pin and roller of the chain) using a reciprocating tribometer (20 N, 2.5 Hz, 15.1 stroke length) in the presence of three commercial lubricant aerosols (Grade A, Grade B, and Grade C) and analyzing the frictional wear, sound, and vibration signals generated during the tribo-tests. In the second phase, the findings from the laboratory scale are validated using a commercial transmission chain under aerosol lubrication. Results indicated that the coefficient of friction in the case of dry conditions was 41% higher than that of Grade A aerosol and Grade C aerosol and 28% higher than that of Grade B aerosol. However, the average wear scar diameter on the pin with Grade C (0.401 ± 0.129 mm) was higher than that on the pins with Grades A (0.209 ± 0.159 mm) and B (0.204 ± 0.165 mm). Grade A and Grade B aerosols exhibited similar frictional conditions, while the wear-scar diameter in Grade C was the highest among Grades A and B but still less than in dry conditions. Analyzing the sound and vibrations generated during the friction test, it can be seen that the dry condition produced approximately 60% more sound level than the Grade A and Grade B conditions, and 41% more sound than the Grade C condition. The laboratory results were validated with a real-time transmission chain using an in-house chain wear test rig. Results from the chain wear test rig indicated that the elongation of the chain with Grade B is the least amongst the aerosols and dry conditions. The surface characterizations of the steel pins also indicated intense deep grooves and surface damage in dry conditions, with Grade A exhibiting the most severe damage, followed by Grade C, and the least severe in Grade B. Additionally, dark patches were visually observed on the rollers of the lubricated commercial chains, indicating stressed areas on the rollers, while polished wear was observed on the rollers under dry conditions. Full article

Sapphire crystals, owing to their outstanding mechanical and optical properties, which are widely used in advanced optics, microelectronic devices, and medical instruments. The manufacturing precision of sapphire optical components critically affects the performance of advanced optical systems. However, the extremely high hardness and low fracture toughness of sapphire make it a typical hard-to-machine material, prone to brittle surface fractures and subsurface damage during material removal. Improving the machinability of sapphire remains a pressing challenge in advanced manufacturing. In this study, surface modification and enhanced ductility of C-plane sapphire were achieved via ion implantation, and the machinability of the modified sapphire was further improved through laser-assisted diamond machining (LADM). Monte Carlo simulations were employed to investigate the interaction mechanisms between incident ions and the target material. Based on the simulation results, phosphorus ion implantation experiments were conducted, and transmission electron microscopy observation was used to characterize the microstructural evolution of the modified layer, while the optical properties of the samples before and after modification were analyzed. Finally, groove cutting experiments verified the enhancement in ductile machinability of the modified sapphire under LADM. At a laser power of 16 W, the ductile–brittle transition depth of the modified sapphire increased to 450.67 nm, representing a 51.57% improvement over conventional cutting. The findings of this study provide valuable insights for improving the ductile machining performance of hard and brittle materials. Full article

Surface-enhanced Raman spectroscopy (SERS) enables ultra-sensitive molecular detection and has broad analytical and biomedical applications; recent advances focus on high-performance substrates and innovative detection strategies. However, achieving controllable and reproducible substrate fabrication—particularly using natural templates such as hair—remains challenging, limiting SERS application in trace analysis and on-site detection. This study developed a single-hair in situ SERS platform using a natural hair template. Confinement within hair cuticle grooves and capillary-evaporation assembly enables dense arrangement of cetyltrimethylammonium bromide-coated Au nanorods and polyvinylpyrrolidone-coated Au nanoparticles, forming uniform plasmonic nanoarrays. Spectroscopy and microscopy analyses confirmed the regular alignment of nanostructures along the hair axis with denser packing at the edges. The platform detected crystal violet at 10⁻⁹ M, yielding clear signals, negligible background, and stable peaks after repeated washing. For p-phenylenediamine, enhancement was observed down to 10⁻⁶ M. On the platform, a concentration-dependent response appeared within 10⁻³–10⁻⁵ M, with spatial Raman imaging along the hair axis. Capillary-evaporation coupling and interfacial wettability facilitated solute enrichment from larger to smaller gap hotspots, improving signal-to-noise ratio and reproducibility. This portable, low-cost, and scalable method supports rapid on-site screening in complex matrixes, offering a general strategy for hotspot engineering and programmable assembly on natural templates. Full article

Erosion wear is a major cause of surface degradation in metallic materials exposed to harsh marine environments. In this study, the erosion wear resistance of the 18Ni300 maraging steel repaired by underwater direct metal deposition (UDMD) is investigated. Results show that UDMD is successfully applied to repair the 18Ni300 samples in underwater environment. Full groove filling and sound metallurgical bonding without cracks are achieved, demonstrating its potential for underwater structural repair. Microstructural analyses reveal good forming quality with fine cellular structures and dense lath martensite in the deposited layer, attributed to rapid solidification under water cooling. Compared to in-air DMD, the UDMD sample exhibits higher surface microhardness due to increased dislocation density and microstructural refinement. Erosion wear behavior is evaluated at 30° and 90° impingement angles, showing that wear mechanisms shift from micro-cutting and plowing at 30° to indentation, crack propagation, and spallation at 90°. The UDMD samples demonstrate superior erosion wear resistance with lower mass loss, particularly at 30°, benefiting from surface work hardening and microstructural advantages. Progressive surface hardening occurs during erosion due to severe plastic deformation, reducing wear rates over time. The combination of refined microstructure, high dislocation density, and enhanced work hardening capability makes UDMD-repaired steel highly resistant to erosive degradation. These findings confirm that UDMD is a promising technique for repairing marine steel structures, offering enhanced durability and long-term performance in harsh offshore environments. Full article

Nowadays, hydrodynamic noise reduction in hydrofoils is of great importance due to their wide applications in marine industries, submarines and water systems. One of the modern methods for reducing this noise is the use of longitudinal grooves on the surface of the hydrofoil. In this study, the effect of longitudinal grooves on the reduction in noise generated around a NACA0015 hydrofoil was investigated. For this purpose, numerical methods based on computational fluid dynamics (CFD) and acoustic analysis using ANSYS Fluent 2024 R1 software were used. The Fuchs–Williams and Hawkings (FW-H) acoustic model was used for acoustic analysis. The results obtained from the hydrofoil without grooves and the hydrofoil equipped with longitudinal grooves were compared. In total, 11 numerical noise reading stations were installed around the hydrofoil to calculate the noise in two modes with and without grooves. The results show that the use of longitudinal grooves reduces the flow turbulence in the area near the hydrofoil surface and, as a result, prevents the formation of large and unstable vortices. This leads to a significant reduction in hydrodynamic noise, especially at low and medium frequencies. This study shows that the appropriate design of longitudinal grooves on the NACA0015 hydrofoil can be used as an effective solution to reduce hydrodynamic noise. The findings of this research can be the basis for the development of quieter hydrofoils in industrial and military applications. The results show that at low frequencies (up to approximately 10 Hz), the noise intensity of the ungrooved hydrofoil is higher than that of the grooved hydrofoil, but in the frequency range of 10 to 20 Hz, the noise intensity of the grooved hydrofoil increases significantly and exceeds that of the ungrooved hydrofoil. Full article

A systematic study was conducted on the fatigue performance of Q500qENH weathering steel welded joints under low-temperature conditions of −40 °C in this paper. Low-temperature fatigue tests were conducted on V-groove butt joints and cross-shaped welded joints and S-N curves with a 95% reliability level were obtained. A comparative analysis with the Eurocode 3 reveals that low-temperature conditions lead to a regular increase in the design fatigue strength for both types of welded joints. Fracture surface morphology was examined using scanning electron microscopy, and combined with fracture characteristic analysis, the fatigue fracture mechanisms of welded joints under low-temperature conditions were elucidated. Based on linear elastic fracture mechanics theory, a numerical simulation approach was employed to investigate the fatigue crack propagation behavior of welded joints. The results indicate that introducing an elliptical surface initial crack with a semi-major axis length of 0.4 mm in the model effectively predicts the fatigue life and crack growth patterns of both joint types. A parametric analysis was conducted on key influencing factors, including the initial crack size, initial crack location, and initial crack angle. The results reveal that these factors exert varying degrees of influence on the fatigue life and crack propagation paths of welded joints. Among them, the position of the initial crack along the length direction of the fillet weld has the most significant impact on the fatigue life of cross-shaped welded joints. Full article

The excellent mechanical properties of AISI 201 make it well-suited for applications in industrial components, transportation, and household appliances. However, during machining, this material generates high cutting forces and temperatures, leading to rapid tool wear and high costs. To address this issue, micro-grooves were designed on the rake face in areas prone to thermal and mechanical stress concentration. Through machining experiments focusing on workpiece surface quality, it was found that micro-grooved tools produced superior surface quality, specifically manifested in lower surface roughness, reduced work hardening, and shallower hardened layer depth. Experiments demonstrate that under identical conditions, increasing the cutting speed with tool M reduces the workpiece surface roughness by 0.096 μm to 0.236 μm compared to tool O. Under identical conditions, increasing the feed rate with tool M reduces the workpiece surface roughness by 0.070 μm to 0.236 μm compared to tool O. As cutting speed varies, the absolute surface hardness of workpieces machined by tool M decreases by approximately 39.85 HV, representing a hardness reduction of 14.5%. As feed rate varies, the surface hardness of workpieces machined with tool M is suppressed to a level 10.2%–14.2% lower than that of tool O. As cutting depth varies, the surface hardness of workpieces machined with tool M is suppressed to a level 10.0%–14.7% lower than that of tool O. Additionally, micro-grooved tools demonstrated superior chip curling and breaking performance. This tool design approach, optimized for tool durability and workpiece surface quality, establishes a research foundation for tool design targeting difficult-to-machine materials. Full article

Under no-load conditions, the wet clutch of vehicles generates drag torque across a wide speed range, which increases power loss in the transmission system and significantly impacts its efficiency and reliability. To address the clutch drag issue over a wide speed range, this study first establishes a low-speed drag torque model that simultaneously considers the viscous friction effects in both the complete oil film region and the oil film rupture zone of the friction pair clearance. Subsequently, by solving the fluid-structure interaction dynamics model of the friction plates, the collision force between high-speed friction pairs and the resulting friction torque are determined, forming a method for calculating high-speed collision-induced drag torque. Building on this, a unified drag torque model for wet clutches across a wide speed range is developed, integrating both viscous and collision-induced drag torques. The validity of the wide-speed-range drag torque model is verified through experiments. The results indicate that as oil temperature and friction pair clearance increase, the drag torque decreases and the rotational speed corresponding to the peak drag torque is reduced, while the onset of collision phenomena occurs earlier. Conversely, with an increase in oil supply flow rate, the drag torque rises and the rotational speed corresponding to the peak drag torque increases, but the onset of collision phenomena is delayed. Finally, with the optimization objectives of minimizing the peak drag torque in the low-speed range and the total drag torque at the maximum speed in the high-speed range, an optimization design model for the surface grooves of the clutch friction plates is constructed. An optimized groove pattern is obtained, and its effectiveness in suppressing drag torque across a wide speed range is experimentally validated. Full article

Electromagnetic separators are widely used in new energy battery purification, resource recycling, and mineral processing. However, coil heating can cause a decline in separation performance and damage to coil insulation. To ensure the stable operation of electromagnetic separators, cooling plates are employed to effectively mitigate temperature rise. To explore a high-performance and economical cooling method, this paper employs CFD finite element analysis for the structural optimization of cooling plates. First, the paper investigates the flow heat characteristics of S-shaped cooling plates. Numerical simulations are performed to analyze the variation of fluid characteristics with different numbers of water channels. Regression equations linking structural parameters to performance indicators are derived, and the optimal channel number and hydraulic diameter are determined. Furthermore, to enhance heat transfer efficiency, an innovative semicircular groove structure is introduced on the cooling plate walls. An optimization strategy based on a genetic algorithm is developed to determine the optimal groove parameters. A simulation shows that the optimized cooling plate reduces coil temperature by 12.63 °C with a decrease of 15.31% compared with the original design. Finally, a prototype with optimized parameters is manufactured after the experimental results of the two test points and the simulation results reveal errors of 0.26% and 0.96%, respectively. The experimental results align well with the simulations, confirming the reliability of the experimental results and the feasibility of the optimization strategy, and providing a reference for future cooling plate designs. Full article

This study examines the incorporation of chopped glass fiber and nano-silica into epoxy, focusing on their effects on the tribological and mechanical properties. Three reinforcement ratios (1 wt.%, 3 wt.%, and 5 wt.%) were analyzed by scratch tests and profilometric analysis. The coefficient of friction (COF), scratch depth, and scratch width values of the unreinforced epoxy resin were measured as 0.45, 37.73 µm and 479 µm, respectively. The addition of glass fibers contributed to improved scratch performance by restricting material removal and stabilizing groove morphology, although higher fiber ratios caused an increase in COF. The results indicated that nano-silica increased scratch resistance with a COF of 0.42 at 5 wt.%, giving a scratch depth of 19.92 µm and a scratch width of 166 µm. Glass fiber also improved scratch performance, although there were high COF values for higher ratios, which could be due to the aggregation effect of the fibers. Statistical validation of the results was carried out through the Taguchi method and ANOVA analyses. These analyses showed that reinforcement type and ratio played an important role in scratch behavior. SEM analyses of worn surfaces showed that nano-silica can dissipate stress and minimize plastic deformation to yield improved scratch morphology. Overall, the results emphasize the complementary role of glass fiber and nano-silica reinforcements in improving the scratch resistance of epoxy resin for industrial applications. Full article

In conveyor belt drive pulleys and intermediate belt drives, the power transferred from the drive system to the belt increases together with the increasing friction coefficient between the belt surface and the pulley surface, or between the surface of the main (carrying) belt and the surface of the intermediate (drive) belt. Belt conveyors used in the mining industry are typically exposed to dust and moisture. This paper presents the method and results of laboratory tests on the friction coefficient between a conveyor belt and rubber plates with grooved and flat surfaces. The tests were performed for different mine-typical contamination conditions of these surfaces. The results demonstrate that in the case of dry friction (regardless of the presence of dust), the grooving of the surface does not significantly affect the friction coefficient of the rubber–rubber friction pair. However, grooving has a significantly positive impact in the case of wet friction. In cases where the surface is grooved in a “diamond” pattern, the measured friction coefficient values are similar for both wet and dry surfaces. The lowest friction coefficient values were obtained for surfaces contaminated with solid rock dust. Full article

Enhanced lubrication is critical for improving gear wear resistance. Current research on surface textures has overlooked the fundamental role of structural connectivity. Inspired by biological scales, a biomimetic hexagonal texture (BHT) was innovatively designed for tooth flanks, featuring dual-orientation grooves (perpendicular and inclined to the rolling-sliding direction) with bidirectional interconnectivity. This design synergistically combines hydrodynamic effects and directional lubrication to achieve tribological breakthroughs. A lubrication model for line contact conditions was established. Subsequently, the texture parameters were then optimized using response surface methodology and numerical simulations. FZG gear tests demonstrated the superior performance of the optimized BHT, which achieved a substantial 82.83% reduction in the average wear area ratio and a 25.35% decrease in tooth profile deviation variation. This indicated that the biomimetic texture can effectively mitigate tooth surface wear, thereby extending the service life of gears. Furthermore, it significantly improves thermal management by enhancing convective heat transfer and lubricant distribution, as evidenced by a 7–11 °C rise in bulk lubricant temperature. This work elucidates the dual-mechanism coupling effect of bio-inspired textures in tribological enhancement, thus establishing a new paradigm for gear surface engineering. Full article

Excessive surface friction encountered during metal-forming processes typically leads to die wear and seizure in part surfaces, which consequently shortens the die’s service lifespan and lowers the surface quality of the formed parts. To minimize surface friction, tool surface modification is required. This study focuses on reducing the sliding friction of SKH51 high-speed steel by fabricating micro-grooves with various crosshatch angles using a nanosecond pulse laser. The effects of laser texturing parameters on achieving the groove aspect ratio of 0.1 were investigated. This aspect ratio facilitates lubricant retention and enhances lubrication performance on the contact surfaces. The influence of groove crosshatch angles (30°, 60°, and 90°) on the friction in the sliding contact between a textured high-speed steel disc and an AISI304 stainless steel pin was evaluated using a pin-on-disc test with a constant load. Moreover, the contact pressure distribution and stress concentration associated with each groove pattern were numerically analyzed using the finite element method. The results demonstrated that a laser power of 20 W effectively produced groove geometries with the desired aspect ratio. Among the tested patterns, the surface textured with a 60° crosshatch angle exhibited the lowest coefficient of friction of 0.111, compared to 0.148 for the untextured surface. Finite element analysis further revealed that the 60° crosshatch pattern provided the most balanced combination of load redistribution, reduced mean pressure, and average stress, which may reduce the friction under sliding conditions. These findings confirm that laser surface texturing, particularly with an optimized crosshatch angle, can significantly reduce sliding friction and enhance the tribological performance of high-speed steel tools. Full article

We propose a dual-groove few-mode fiber surface plasmon resonance sensor that exploits the LP₁₁ mode for enhanced plasmonic sensing. The device incorporates two physically separated grooves with distinct metallic coatings, enabling dual-channel operation via wavelength-division multiplexing. Finite element method simulations show that the optimized design achieves a maximum sensitivity of 14,800 nm/RIU within the RI range of 1.33–1.40. The introduction of a TiO₂–Au bilayer enhances mode coupling and ensures complete spectral separation, thereby improving stability and reducing environmental interference. Biosensing simulations at 37 °C further confirm the practicality of the proposed architecture. Channel 1, filled with ethanol as a temperature-sensitive medium, provides temperature monitoring, while Channel 2 successfully distinguishes between normal and tumor cells, reaching a sensitivity of up to 9428.57 nm/RIU for Jurkat cells. Overall, the TiO₂-enhanced dual-channel FMF-SPR sensor combines ultra-high sensitivity, spectral independence, and biosensing capability, demonstrating strong potential for next-generation fiber-optic sensing and biomedical applications. Full article
