This study investigated the aerodynamic structures generated by transverse jet injection in supersonic flows around high-speed vehicles. The unsteady evolution of these structures was analyzed using an improved delayed detached Eddy simulation (IDDES) approach based on the Reynolds stress model (RSM). The simulations successfully reproduced experimentally observed shock systems and vortical structures. The time-averaged flow characteristics were compared with the experimental results, and good agreement was observed. The flow characteristics were analyzed, with particular emphasis on the formation of counter-rotating vortex pairs in the downstream region, as well as complex near-field phenomena, such as flow separation and shock wave/boundary layer interactions. Time-resolved spectral analysis at multiple monitoring locations revealed the presence of a global oscillation within the flow dynamics. Within these regions, pressure fluctuations in the recirculation zone lead to periodic oscillations of the upstream bow shock. This dynamic interaction modulates the instability of the windward shear layer and generates large-scale vortex structures. As these shed vortices convect downstream, they interact with the barrel shock, triggering significant oscillatory motion. To further characterize this behavior, dynamic mode decomposition (DMD) was applied to the pressure fluctuations. The analysis confirmed the presence of a coherent global oscillation mode, which was found to simultaneously govern the periodic motions of both the upstream bow shock and the barrel shock. Full article

Scramjet operation requires a comprehensive understanding of the internal flowfield, encompassing fuel–air mixing and combustion. This study investigates transient flow and flame development within a HIFiRE-2 scramjet engine combustor, which features two opposing cavities and dual sets of fuel injectors—the upstream (primary) and downstream (secondary) injectors. These cavities function as flameholders, creating circulating flows with elevated temperatures and pressures. Shock waves form both ahead of fuel plumes and at the diverging and converging sections of the flowpath. Special attention is given to the interactions among these shock waves and the shear layers along the supersonic core flow as the system progresses towards a quasi-steady state. Driven by increased backpressure, bow shocks and disturbances induced by the normal, secondary fuel injection and the inclined, primary fuel injection move upstream, amplifying the cavity pressure. These shocks generate adverse pressure gradients, causing near-wall flow separation adjacent to both injector sets, which enhances the penetration and dispersion of fuel plumes. Once a quasi-steady state is achieved, a feedback loop is established between dynamic wave motions and combustion processes, resulting in sustained entrainment of reactive mixtures into the cavities. This mechanism facilitates stable combustion in the cavities and near-wall separation zones. Full article

The current study explores the flowfield and noise characteristics of an ideally expanded supersonic (Mach 1.44) rectangular jet impinging on a flat surface. The existing literature is primarily concentrated on axisymmetric jets, known for their resonance dominance, pronounced unsteadiness, and acoustic signatures. In contrast, non-axisymmetric jets remain relatively less understood, particularly those impinging on a ground surface. By employing Schlieren imaging, high-frequency pressure measurements using high-bandwidth transducers, and particle image velocimetry (PIV), this research comprehensively examines the flow-acoustic phenomena. Schlieren imaging revealed distinct, coherent structures and strong acoustic waves, while pressure measurements at the impingement surface exhibited high-amplitude fluctuations, peaking at approximately 186 dB. Acoustic analysis identified multiple high-amplitude tones with unique directional characteristics, suggesting the potential for multiple simultaneous modes in rectangular jets. Furthermore, the PIV data elucidated differences in the jet shear layer and wall jet development attributed to the nozzle orientation. These findings contribute to a deeper understanding of non-axisymmetric jet behavior, offering insights relevant to fundamental flow physics and practical applications such as vertical takeoff and landing aircraft. Full article

The mixing process and distribution characteristics of a supercritical endothermic hydrocarbon fuel (EHF) jet injected into a supersonic crossflow were investigated by experimental and numerical methods, respectively. The schlieren system and acetone planar laser-induced fluorescence (PLIF) optical system were used to capture the flow-field structural characteristics and instantaneous plume. The mixture and real gas models were employed to calculate the interaction of a transverse jet and supersonic crossflow and reveal a good accuracy with the experimental results. The mixing efficiency and total pressure loss were analyzed based on the numerical results. The results indicate that the supercritical-state EHF directly changes to a gaseous state as it enters the supersonic crossflow from the injector. The EHF jet plume boundary increases with the increasing momentum flux ratio (q). As the streamwise and spanwise distance increases, the traverse heights and expand width increase, and the EHF jet plume presents a semicircle shape in the cross-sectional plane. With the increase in the traverse direction, the concentration distribution shows a fast and then slow power exponential decreasing law; the highest concentration point starts from the near-wall region and rises in the transverse direction with the flow distance increasing. For the same injection condition, the higher the inflow Mach number, the higher the mixing efficiency. For the same Ma, the mixing efficiency is better for the case with low injection pressure and high injection temperature. The total pressure loss is greater in the higher Ma, and high injection pressure conditions cause greater total pressure loss. Full article

The problem considered in this work is shock wave (SW) positioning control in shock-dominated flows. Experiments are conducted to investigate the triggering effect of patterned near-surface electrical discharges on SW reflection from plane walls. In the wind tunnel, $M=4$, $P_0$ = 4 bar, a solid wedge SW generator is mounted on the upper wall. Q-DC filamentary electrical discharges were arranged on the opposite wall, so that the SW from the wedge impinged on the plasma filaments that are arranged flow-wise in either a row of three or a single central filament. Within the supersonic flow, narrow subsonic areas are actuated by electrical discharge thermal deposition, resulting in pressure redistribution, which, in turn, relocates the reflection of impinging SW to a predefined position. Mie scattering, schlieren imaging, and wall pressure measurements are used to explore the details of plasma-SW interaction. Using Mie scattering, the three-dimensional shape of the SW structure is mapped both before and after electrical discharge activation. Plasma-based triggering mechanisms are described in terms of the physical principles of flow control and a criterion for determining the effectiveness of the flowfield control. Full article

The recent improvement of technology readiness level in aeronautics and the renewed demand for faster transportation are driving the rebirth of supersonic flight for commercial aviation. However, the design of a future supersonic aircraft is still very challenging due to the complexity of several problems, such as static stability performance during the acceleration phase from subsonic speeds to supersonic speeds. Additionally, the interest of scientific community in open source numerical platform as a valid tool for a reliable and affordable aerodynamic design is considerably growing. In this framework, the present work addresses the aerodynamic performance of a Concorde-like aeroshape developed within the preliminary design of a high-speed civil transportation aircraft. Several flight conditions, ranging from subsonic to supersonic speeds, were investigated in detail by using Computational Fluid Dynamics. The aerodynamic force and moment coefficients are computed with fully three-dimensional and steady state Reynolds Average Navier-Stokes simulations, carried out in turbulent flow conditions. The effect of the Mach number variation on the shift of the aircraft aerodynamic center is detailed, by focusing on the aircraft pitching static stability. Flowfield numerical simulations are performed with both commercial (Ansys-Fluent) tool and open-source (SU2) code, which is also used extensively in multidisciplinary design procedures, for further comparisons. Particular attention is focused on the shift of the aeroshape aerodynamic center to verify that the provided wing design allows the aircraft static margin to be within 5% of the reference length, both at low-speed and high-speed flight conditions. The computed positions of the aerodynamic center are in agreement with the aeroshape surface pressure distributions and confirmed the literature results available for the Concorde aircraft. Therefore, in the view of future simulation campaigns for supersonic transportation aircraft, the present work aims to bridge the gap between previous aerodynamic design experiences, for instance matured on Concorde, and those carried out with modern CFD tools on full-scale aircraft, and on time-scales compatible with conceptual design practice. Finally, as the difference between the computed aerodynamic coefficients reflected mainly on drag computation performed with SU2, a special focus on numerical diffusion effect of the solver is also given and compared with a commercial certified CFD tool. This adds a unique further contribution to the SU2 community for aeronautics application. Full article

A majority of the eddy viscosity models for supersonic turbulent flow are based on linear relationship between Reynolds stresses and mean strain rate. The validity of these models can be improved by introducing non-linearity in relation as RANS models offer advantages in terms of reduced turnaround times typical of industry applications. With these benefits, the present work utilizes quadratic constitutive relation (QCR) with Menter’s k omega SST model to characterize the flowfield of rectangular jets. The sensitivity of this model with QCR, weighted towards diffusion, dissipation, and a combination of both, is addressed. Viscous large eddy simulations (LES) with WALE subgrid scale models are employed for qualitative comparisons using a commercial solver. Massively parallel LES are enabled by the new in-house 1088-core computing cluster at the University of Cincinnati and are also used for benchmarking. The nearfield results are validated with available experimental data and show good agreement in both fidelities. Flow characteristics, including the shear layer profiles, Reynolds stresses, and turbulence kinetic energy (TKE) and its production are compared. LES reveal higher TKE production in the regions with highest Reynolds stresses. It is comparatively lower in QCR RANS. As a special case of TKE analysis in jets, a preliminary investigation of retropropulsion is outlined for rectangular nozzles for the first time. Improved flow behavior by implementation of a non-linear relationship between Reynolds stresses and mean strain rate is demonstrated. Full article

Supersonic flight for commercial aviation is gaining a renewed interest, especially for business aviation, which demands the reduction of flight times for transcontinental routes. So far, the promise of civil supersonic flight has only been afforded by the Concorde and Tupolev T-144 aircraft. However, little or nothing can be found about the aerodynamics of these aeroshapes, the knowledge of which is extremely interesting to obtain before the development of the next-generation high-speed aircraft. Therefore, the present research effort aimed at filling in the lack of data on a Concorde-like aeroshape by focusing on evaluating the aerodynamics of a complete aircraft configuration under low-speed conditions, close to those of the approach and landing phase. In this framework, the present paper focuses on the CFD study of the longitudinal aerodynamics of a Concorde-like, tailless, delta-ogee wing seamlessly integrated onto a Sears–Haack body fuselage, suitable for civil transportation. The drag polar at a Mach number equal to 0.24 at a 30 m altitude was computed for a wide range of angles of attack $(0^{\circ },{60}^{\circ }$), with a steady RANS simulation to provide the feedback of the aerodynamic behaviour post breakdown, useful for a preliminary design. The vortex-lift contribution to the aerodynamic coefficients was accounted for in the longitudinal flight condition. The results were in agreement with the analytical theory of the delta-wing. Flowfield sensitivity to the angle of attack at near-stall and post-stall flight attitudes confirmed the literature results. Furthermore, the longitudinal static stability was addressed. The CFD simulation also evidenced a static instability condition arising for ${15}^{\circ }\le \alpha \le {20}^{\circ }$ due to vortex breakdown, which was accounted for. Full article

Effects of additional cavity floor injection on the ethylene ignition and combustion processes in a cavity-based scramjet combustor are investigated experimentally in a Mach 2.0 supersonic flow using flame luminosity and CH* (CH radical) spontaneous emission methods and static pressure measurements. Numerical calculation is performed to study the non-reacting flow-field structures prior to ignition. Two injection schemes, including the cavity upstream injection scheme and the combined injection scheme with an additional cavity floor injection, are compared to study the effects of the additional cavity floor injection on the ignition and combustion processes. It is found that there exists an equivalence ratio upper limit for maintaining stable combustion for the cavity upstream injection scheme. As the equivalence ratio further increases, the fuel jet penetration is improved accordingly, and thus, the interaction between the fuel jet and the cavity is weakened, which can lead to the ignition failure and flame blowout during combustion. On the contrary, although the combined injection scheme has a minor effect on combustion enhancement at the same global equivalence ratio, it can also provide a more favorable flow-field environment that enables more successful ignitions and better flame stabilizations. For the combined injection scheme, as the equivalence ratio increases, the initial flame propagations are observed to perform different routines during the ignition process, and the major combustion reaction zone tends to move further downstream the cavity shear layer. It is concluded that the advantages of the combined injection scheme with an additional cavity floor injection are more significant when the equivalence ratio is higher, as well as that the interaction between the fuel jet and the cavity becomes weaker. Full article

Herein, a supersonic combustion coherent jet is proposed based on current coherent jet technology to improve the impact capacity of a coherent jet and increase the stirring intensity of the electric arc furnace (EAF) bath. Further, numerical simulations and an experimental analysis are combined to study the supersonic combustion coherent jet characteristics, including the Mach number, dynamic pressure, static temperature, vorticity, and turbulence intensity, in the EAF steelmaking environment. The results show that the supersonic combustion coherent jet exhibits stable combustion in a high-temperature EAF steelmaking environment. The supersonic combustion flame generated by the supersonic shrouding fuel gas can envelop the main oxygen jet more effectively than current coherent jets. Furthermore, the velocity attenuation, vorticity, and turbulence intensity performances of the supersonic combustion coherent jet are better when compared with those of the current coherent jet. The velocity core length of the main oxygen jet for the supersonic combustion coherent jet is 30% longer than that of the current coherent jet, resulting in an improved impact capacity and stirring intensity of the molten bath. Full article

A practical approach for deriving the absolute density field based on the background-oriented schlieren method in a high-speed flowfield was implemented. The flowfield of interest was a two-dimensional compressible flowfield created by two supersonic streams to simulate a linear aerospike nozzle operated under a supersonic in-flight condition. The linear aerospike nozzle had a two-dimensional cell nozzle with a design Mach number of 3.5, followed by a spike nozzle. The external flow simulating the in-flight condition was 2.0. The wall density distribution used as the wall boundary condition for Poisson’s equation to solve the density field was derived by a simplified isentropic assumption based on the measured wall pressure distribution, and its validity was evaluated by comparing with that predicted by numerical simulation. Unknown coefficients in Poisson’s equation were determined by comparing the wall density distribution with that predicted by the model. By comparing the derived density field based on the background-oriented schlieren method to that predicted by the model and numerical simulation, the absolute density field was derived within an error of 10% on the wall distribution. This practical approach using a simplified isentropic assumption based on measured pressure distribution thus provided density distribution with sufficient accuracy. Full article
