Search Results (32)

Two outstanding problems of particle physics and cosmology, namely the strong-CP problem and the nature of dark matter, can be solved with the discovery of a single new particle, the axion. The modular high magnetic field and flux hybrid magnet platform of LNCMI-Grenoble, which was recently put in operation up to 42 T, offers unique opportunities for axion/axion-like particle search using Sikivie-type haloscopes. In this paper, the focus will be on the 350–600 MHz frequency range corresponding to the 1–3 μeV axion mass range requiring a large-bore RF-cavity. It will be built by DMAG and integrated within the large-bore superconducting hybrid magnet outsert, providing a central magnetic field up to 9 T in 812 mm warm bore diameter. The progress achieved by Néel Institute in the design of the complex cryostat with its double dilution refrigerators to cooldown below 50 mK the ultra-light Cu RF-cavity of 650 mm inner diameter and the first stage of the RF measurement chain are presented. Perspectives for the targeted sensitivity, assuming less than 2-year integration time, are recalled. Full article

Particle accelerators are powerful tools in fundamental research, medicine, and industry that provide high-energy beams that can be used to study matter and to enable advanced applications. The state-of-the-art particle accelerators are fundamentally constructed from superconducting radio-frequency (SRF) cavities, which act as resonant structures for the acceleration of charged particles. The performance of such cavities is governed by inherent superconducting material properties such as the transition temperature, critical fields, penetration depth, and other related parameters and material quality. For the last few decades, bulk niobium has been the preferred material for SRF cavities, enabling accelerating gradients on the order of ~50 MV/m; however, its intrinsic limitations, high cost, and complicated manufacturing have motivated the search for alternative strategies. Among these, sputter-deposited superconducting thin films offer a promising route to address these challenges by reducing costs, improving thermal stability, and providing access to numerous high-T_c superconductors. This review focuses on progress in sputtered superconducting materials for SRF applications, in particular Nb, NbN, NbTiN, Nb₃Sn, Nb₃Al, V₃Si, Mo–Re, and MgB₂. We review how deposition process parameters such as deposition pressure, substrate temperature, substrate bias, duty cycle, and reactive gas flow influence film microstructure, stoichiometry, and superconducting properties, and link these to RF performance. High-energy deposition techniques, such as HiPIMS, have enabled the deposition of dense Nb and nitride films with high transition temperatures and low surface resistance. In contrast, sputtering of Nb₃Sn offers tunable stoichiometry when compared to vapour diffusion. Relatively new material systems, such as Nb₃Al, V₃Si, Mo-Re, and MgB₂, are just a few of the possibilities offered, but challenges with impurity control, interface engineering, and cavity-scale uniformity will remain. We believe that future progress will depend upon energetic sputtering, multilayer architectures, and systematic demonstrations at the cavity scale. Full article

This article presents a preliminary study on the potential application of artificial intelligence methods for assessing the durability of HTS tapes in superconducting fault current limiters (SFCLs). Despite their importance for the selectivity and reliability of power networks, these devices remain at the prototype testing stage, and the phenomena occurring in HTS tapes during their operation—particularly the degradation of tapes due to cyclic transitions into the resistive state—are difficult to model owing to their highly non-linear and dynamic nature. A concept of an engineering decision support system (EDSS) has been proposed, which, based on macroscopically measurable parameters (dissipated energy and the number of transitions), aims to enable the prediction of tape parameter degradation. Within the scope of the study, five approaches were tested and compared: Gaussian process regression (GPR) with various kernel functions, k-nearest neighbours (k-NN) regression, the random forest (RF) algorithm, piecewise cubic hermite interpolating polynomial (PCHIP) interpolation, and polynomial approximation. All models were trained on a limited set of experimental data. Despite the quantitative limitations and simplicity of the adopted methods, the results indicate that even simple GPR models can support the detection of HTS tape degradation in scenarios where direct measurement of the critical current is not feasible. This work constitutes a first step towards the construction of a complete EDSS and outlines directions for further research, including the need to expand the dataset, improve validation, analyse uncertainty, and incorporate physical constraints into the models. Full article

This paper serves as a comprehensive and practical resource to guide researchers in selecting suitable metals for use as photocathodes in radio-frequency (RF) and superconducting radio-frequency (SRF) electron guns. It offers an in-depth review of bulk and thin-film metals commonly employed in many applications. The investigation includes the photoemission, optical, chemical, mechanical, and physical properties of metallic materials used in photocathodes, with a particular focus on key performance parameters such as quantum efficiency, operational lifetime, chemical inertness, thermal emittance, response time, dark current, and work function. In addition to these primary attributes, this study examines essential parameters such as surface roughness, morphology, injector compatibility, manufacturing techniques, and the impact of chemical environmental factors on overall performance. The aim is to provide researchers with detailed insights to make well-informed decisions on materials and device selection. The holistic approach of this work associates, in tabular format, all photo-emissive, optical, mechanical, physical, and chemical properties of bulk and thin-film metallic photocathodes with experimental data, aspiring to provide unique tools for maximizing the effectiveness of laser cleaning treatment. Full article

High-current electron beams can significantly enhance the productivity of variety of applications including medical radioisotope (RI) production and wastewater purification. High-power superconducting radio frequency (SRF) linacs are capable of producing such high-current electron beams due to the key advantage to operate in continuous wave (CW) mode. However, this requires an injector capable of generating electron bunches with high repetition rate and in CW mode, while minimizing beam losses to avoid damage to SRF cavities due to quenching. RF gating to the grid of a thermionic electron gun is a promising solution, as it ensures CW bunch generation at the repetition rate same as the fundamental or sub-harmonics of the accelerating RF frequency, with minimal beam loss. This paper presents detailed beam dynamics simulations demonstrating that an RF-gated gun operating at 1.3 GHz can generate bunches with 148 ps full width with 8.96 pC charge. Full article

The Polish Free-Electron Laser (PolFEL), which is currently under construction in the National Centre for Nuclear Research in Świerk near Warsaw, will comprise an electron gun and from four to six cryomodules, each accommodating two nine-cell TESLA RF superconducting resonant cavities. To cool the superconducting resonant cavities, the cryomodules will be supplied with superfluid helium at a temperature of 2 K. Other requirements regarding the cooling power of PolFEL result from the need to cool the power couplers for the accelerating cryomodules (5 K) and thermal shields, which limit the heat inleaks due to radiation (40–80 K). The machine will utilize several thermodynamic states of helium, including two-phase superfluid helium, supercritical helium, and low-pressure helium vapours. Supercritical helium will be supplied from a cryoplant by a cryogenic distribution system (CDS)—transfer line and valve boxes—where it will be thermodynamically transformed into a superfluid state. This article presents the architecture of the CDS, discusses several design solutions that could have been decided on with the use of second law analysis, and presents the design methodology of the chosen CDS elements. Full article

The so-call SQUIDs (abbreviated from superconducting quantum interference device) are very sensitive apparatuses especially built for metering very low magnetic fields. These systems have applications in various practical fields—biology, geology, medicine, different engineering areas, etc. Their features are mainly based on superconductors and the Josephson effect. They can be differentiated into two main groups—direct current (DC) and radio frequency (RF) SQUIDs. Both of them were constructed in the 1960s at Ford Research Labs. The main difference between them is that the second ones use only one superconducting tunnel junction. This reduces their sensitivity, but makes them significantly cheaper. We investigate namely the rf-SQUIDs in the present work. A number of authors devote their research to the rf-SQUIDs driven by an oscillating external flux. We aim to enlarge the theoretical base of these systems by adding new factors in their dynamics. Several particular cases are explored and simulated. We demonstrate also some specialized modules for investigating the proposed model. One application for possible control over oscillations is also discussed. It is based on the Fourier transform and, as a consequence, on the characteristic function of some probability distributions. Full article

Buffered chemical polishing (BCP) is an important and widely used polishing technique for superconducting radio-frequency (SRF) cavities made of niobium. A common problem encountered during BCP is the formation of bubbles and W-shaped pits on the cavity surface, which may severely limit the RF performance. We report a method to address the problem of W-shaped pits through optimizing the BCP acid ratio. We systematically investigate the effect of the BCP acid ratio through sample and cavity BCP experiments and determine an optimal ratio for the three acids. The new BCP recipe with the optimal acid ratio is verified through the development of niobium cavities with several different shapes, which are shown to be free of pits and demonstrate excellent RF performance; notably, several 3.9 GHz nine-cell cavities present unprecedented accelerating gradients. Furthermore, the findings suggest a simple pit-free BCP recipe that does not require ${\mathrm{H}}_3{\mathrm{PO}}_4$, using only HF and ${\mathrm{HNO}}_3$. The method proposed in this study is also appropriate for suppressing pit formation with other acid mixtures or when polishing other metal objects. Full article

Nb₃Sn has a superconducting transition temperature of 18.1 K and a superheating magnetic field of 420 mT, making it one of the most promising materials for superconducting radiofrequency (SRF) cavities. The surface roughness reduction and mechanical stability of Nb₃Sn films are two important issues to improve the cavity RF performance and reliability in the application of conduction-cooling accelerators. This paper presents the studies on the surface roughness of Nb₃Sn films prepared by the tin vapor diffusion method and proves the advantages of buffered electropolishing (BEP) as a pre-polishing method. The smallest mean roughness of 26 nm, with a grain size of 760 nm, was achieved by fast BEP treatment on the niobium substrate. Nb₃Sn films on flat and curved substrates with the same coating process on Nb₃Sn cavities at Peking University (PKU) were tested under different tensile and compressive stress levels. The results showed that Nb₃Sn films had severe crack risks while loading stresses, and a safe strain range of (−2.3%, 0.9%) is suggested. To study the tuning problems for Nb₃Sn cavities, 150 kHz tuning was performed on the previously obtained high-performance cavity. Full article

This paper presents a comprehensive investigation into the quantum efficiency (QE) of metallic photocathodes used in modern high-performance radio frequency (RF) and superconducting radio frequency (SRF) guns. The study specifically examines how laser cleaning treatment impacts the QE of these photocathodes, providing detailed insights into their performance and potential improvements for accelerator applications, and assesses the chemical and environmental factors affecting the surface composition of metallic laser-photocathodes used in modern high-performance radio frequency (RF) and superconducting radio frequency (SRF) electron guns. This paper overviews the photocathode rejuvenation effects of laser cleaning treatment. Laser cleaning removes the oxides and hydrides responsible for the deterioration of photocathodes, increases the photoelectron emission quantum efficiency (QE) and extends the operational lifetime of high-brightness electron injectors. QE enhancement is analyzed with the aim of parametric cleaning process optimization. This study excludes semiconductor and thermionic cathodes, focusing solely on the widely used bulk and thin-film photocathodes of Cu, Mg, Y, Pb and Nb. Laser cleaning enhancement of QE in Cu from 5 × 10⁻⁵ to 1.2 × 10⁻⁴, in Mg from 5.0 × 10⁻⁴ to 1.8 × 10⁻³, in Y from 10⁻⁵ to 3.3 × 10⁻⁴, in Pb from 3 × 10⁻⁵ to 8 × 10⁻⁵, and in Nb from 2.1 × 10⁻⁷ to 2.5 × 10⁻⁵ is demonstrated. The analysis concludes with a specialized practical guide for improving photocathode efficacy and lifetime in RF and SRF guns. Full article

This paper presents an innovative exploration of advanced configurations for enhancing the efficiency of metallic and superconducting photocathodes (MPs and SCPs) produced via pulsed laser deposition (PLD). These photocathodes are critical for driving next-generation free-electron lasers (FELs) and plasma-based accelerators, both of which demand electron sources with improved quantum efficiency (QE) and electrical properties. Our approach compares three distinct photocathode configurations, namely: conventional, hybrid, and non-conventional, focusing on recent innovations. Hybrid MPs integrate a thin, high-performance, photo-emissive film, often yttrium or magnesium, positioned centrally on the copper flange of the photo-injector. For hybrid SCPs, a thin film of lead is used, offering a higher quantum efficiency than niobium bulk. This study also introduces non-conventional configurations, such as yttrium and lead disks partially coated with copper and niobium films, respectively. These designs utilize the unique properties of each material to achieve enhanced photoemission and long-term stability. The novelty of this approach lies in leveraging the advantages of bulk photoemission materials like yttrium and lead, while maintaining the electrical compatibility and durability required for integration into RF cavities. The findings highlight the potential of these configurations to significantly outperform traditional photocathodes, offering higher QE and extended operational lifetimes. This comparative analysis provides new insights into the fabrication of high-efficiency photocathodes, setting the foundation for future advancements in electron source technologies. Full article

A liquid helium-free cryostat for radio frequency (RF) test of the superconducting cavity is designed and constructed. Gifford-Mcmahon (G-M) cryocoolers are used to provide cooling capacity, and the heat leakage at 4 K is less than 0.02 W. Vertical and horizontal tests of two Nb₃Sn cavities are carried out in the cryostat with different surface treatments outside the cavities. Both of the cavities achieve stable continuous wave (CW) operation. A novel treatment, which cold-sprayed a 3.5 mm thick Cu layer onto the outside of the cavity, enables the maintenance of an average temperature of 5.5 K in the cavity at a RF loss of 10 W, implying that the thermal stability and uniformity of the cavity has been significantly improved. Through the synergistic control of four metal film resistors, a cooling rate of 0.06 K/min near 18 K is realized, and the cavity temperature gradient is reduced to 0.17 K/m, which effectively improves the RF performance of the cavity. The maximum $E_{acc}$ of the cavity reaches 3.42 MV/m, and the $Q_0$ is 1.1 × 10⁹. An electromagnetic–thermal coupling simulation model for the superconducting cavity is established and is in good agreement with the experimental results. The simulation results show that the cavity with a Cu-spraying treatment and the thermal links of 5N Al can satisfy the $E_{acc}$ of 10 MV/m under conduction cooling. Full article

Nb₃Sn is emerging as one of the focal points in superconducting radio frequency (SRF) research, owing to its excellent superconducting properties. These properties hold significant possibilities for cost reduction and the miniaturization of accelerators. In this paper, we report the recent efforts of the Shanghai Advanced Research Institute (SARI) in fabricating high-performance Nb₃Sn superconducting cavities using the vapor diffusion method. This includes the construction of a Nb₃Sn coating system with dual evaporators and the test results of 1.3 GHz single-cell coated cavities. The coated samples were characterized, and the growth state of the Nb₃Sn films was analyzed. The first coated superconducting cavity was tested at both 4.4 K and 2 K, with different cooldown rates passing through the Nb₃Sn critical temperatures. The causes of Sn droplet spot defect formation on the surface of the first cavity were analyzed, and such defects were eliminated in the coating of the second cavity by controlling the evaporation rate. This study provides a reference for the preparation of high-performance Nb₃Sn-coated cavities using the vapor diffusion method, including the setup of the coating system, the comprehension of the vapor diffusion process, and the test conditions. Full article

In contrast to the room temperature cyclotron, the superconducting cyclotron’s high operational magnetic field and small extraction radius lead to a magnet design with a reduced radius. This limits the space available for the RF cavity in the 11 MeV superconducting cyclotron, necessitating a more compact RF cavity design. By using the transmission line theory, the complex structure of the quarter-wavelength coaxial cavity can be represented as a microwave circuit. Through relevant theoretical analytical formulas, equivalent circuit parameters can be derived. The resonant frequency of the RF cavity is then determined using the equivalent circuit method. The optimization of the RF cavity structure was achieved by creating a numerical model and conducting finite element numerical calculations on the high-frequency resonant system. The comparative results between the equivalent circuit and numerical calculations indicate that the frequency error remains within 0.1%, validating the compact RF cavity design. A multiple linear regression analysis facilitates the prediction of resonance frequency across various parameter variables. By analyzing the fitting formula, RF cavity machining error requirements are established, ensuring a prediction error within 1%, thus meeting engineering design criteria. Full article

Josephson junctions (JJs) are superconductor-based devices used to build highly sensitive magnetic flux sensors called superconducting quantum interference devices (SQUIDs). These sensors may vary in design, being the radio frequency (RF) SQUID, direct current (DC) SQUID, and hybrid, such as D-SQUID. In addition, recently many of JJ’s applications were found in spiking models of neurons exhibiting nearly biological behavior. In this study, we propose and investigate a new circuit model of a sensory neuron based on DC SQUID as part of the circuit. The dependence of the dynamics of the designed model on the external magnetic flux is demonstrated. The design of the circuit and derivation of the corresponding differential equations that describe the dynamics of the system are given. Numerical simulation is used for experimental evaluation. The experimental results confirm the applicability and good performance of the proposed magnetic-flux-sensitive neuron concept: the considered device can encode the magnetic flux in the form of neuronal dynamics with the linear section. Furthermore, some complex behavior was discovered in the model, namely the intermittent chaotic spiking and plateau bursting. The proposed design can be efficiently applied to developing the interfaces between circuitry and spiking neural networks. However, it should be noted that the proposed neuron design shares the main limitation of all the superconductor-based technologies, i.e., the need for a cryogenic and shielding system. Full article
