Electrification has become increasingly common in aerospace due to climate change concerns. After successful applications in general aviation aircraft, electrification is now addressing subregional (up to 19 passengers) and regional aircraft (around 80 passengers). Megawatt-class electric motors are needed both to drive propellers and to act as high-power generators in hybrid–electric propulsion systems. Power levels for this class of aircraft require a proper design of heat management systems capable of dissipating a much higher quantity of heat than that dissipated by traditional cooling systems. The technical solution here explored is based on the addition into a diathermic base liquid of nanoparticles, which can increase (by up to 30%) the thermal conductivity of the refrigerant, also providing large surface area enhancing the heat transfer capacity of base liquids. The Italian Aerospace Research Centre (CIRA), as part of the European research initiative Optimised Electric Network Architectures and Systems for More-Electric Aircraft (ORCHESTRA), developed a thermal management system (TMS) based on impinging jets technology for a 1 MW electric motor. In this work, a numerical verification of the possibility for nanofluids to improve the heat exchange efficiency of a submerged oil impinging jets TMS designed to directly cool the inner components of a 1 MW motor is conducted. Investigations aimed to analyse two nanoparticle types (alumina and graphite) added to diathermic oil with concentrations between 1% and 5% by volume. The application of nanofluids significantly increases final thermal conductivity with respect to conventional coolants, a 60% improvement in heat transfer at a fixed mass flow rate is achieved. Electric motor maximum temperatures are approximately 10% lower than those achieved with solely diathermic oil. This result is significant as a safety margin is needed in all cases where a sudden increase in power occurs. Full article

Electrification of aircraft is a very challenging task as the demand for energy and power is high. While the storage and generation of electrical energy are widely studied due to the limited specific energy and specific power of batteries and fuel cells, electric machines (power electronics and motors) which have years of experience in many industrial fields must be improved when applied to aviation: they generally have a high efficiency but the increase in power levels determines significant thermal loads which, unlike internal combustion engines (ICE), cannot be rejected with the exhaust. There is therefore a need for thermal management systems (TMSs) with the main objective of maintaining operating temperatures below the maximum level required by electric machines. Turboprop aircraft, such as the ATR 72 or the Dash 8-Q400, are commonly used for regional transport and are equipped with two gas turbine engines whose combined power is in the order of 4 MW. Electric and hybrid propulsion systems for these aircraft are being studied by several leading commercial aviation industries and start-ups, and the 1MW motor size seems to be the main option as it could be used in different aircraft configurations, particularly those that exploit distributed electric propulsion. With reference to the topics mentioned above, the present work presents the design of a TMS for a high-power motor/generator whose electrical architecture is known. Once integrated with the electrical part, the TMS must allow a weight/power ratio of 14 kW/kg (or 20 kW/kg at peak power) while maintaining the temperature below the limit temperature with reasonable safety margins. Submerged jet oil is the cooling technique here applied with a focus on diathermic oil. Parameters affecting cooling, like rotor speed and filling factor, are analysed with advanced CFD. Full article

The development of accurate methodologies for a thorough comprehension of the erosion phenomenon is a challenging and necessary task. This study entailed an exhaustive analysis, incorporating empirical data obtained from an experiment involving the impingement of a sand and water jet on a submerged stainless-steel plate and numerical simulations, employing the Oka Erosion model that was compilated in OpenFOAM. The primary focus of this study was to generate W-shaped profiles delineating the impingement zone, derived both from experimental observations and the developed numerical model. This comparative approach facilitated a robust evaluation of the model’s efficacy in replicating erosion patterns. The outcomes of this analysis revealed a concurrence between the experimental and simulated erosion contours, affirming the model’s proficiency in representing erosion phenomena. Nevertheless, a minor discrepancy was noted, characterized by a slight underestimation of erosion rate and thickness loss. Furthermore, the investigation unveiled a noteworthy time-dependent trend in mass loss from the experimental data denoting a pseudo stabilization of the erosion rate across the time. This research contributes to the refinement of erosion modeling parameters and underscores the nature of time-dependent erosion behavior, a pivotal consideration for optimizing material durability. Full article

Due to their high efficiency, low heat loss and associated sustainability advantages, impinging jets have been used extensively in marine engineering, geotechnical engineering and other engineering practices. In this paper, the flow structure and impact characteristics of impinging jets with different Reynolds numbers and impact distances are systematically studied by Flow-3D based on PIV experiments. In the study, the relevant state parameters of the jets are dimensionlessly treated, obtaining not only the linear relationship between the length of the potential nucleation zone and the impinging distance, but also the linear relationship between the axial velocity and the axial distance in the impinging zone. In addition, after the jet impinges on the flat plate, the vortex action range caused by the wall-attached flow of the jet gradually decreases inward with the increase of the impinging distance. By examining the effect of Reynolds number Re on the hydraulic characteristics of the submerged impact jet, it can be found that the structure of the continuous submerged impact jet is relatively independent of the Reynolds number. At the same time, the final simulation results demonstrate the applicability of the linear relationship between the length of the potential core region and the impact distance. This study provides methodological guidance and theoretical support for relevant engineering practice and subsequent research on impinging jets, which has strong theoretical and practical significance. Full article

Transient phenomena and vortex structures throughout the mold are simulated using a lattice Boltzmann method (LBM) coupled with large eddy simulation (LES) using a free surface model under steady operating conditions. The accuracy of the LBM-LES model has been verified by comparing the simulated velocities with published experimental values. The current work focuses on the evolution of the vortex structure in internal flow inside the submerged entry nozzle (SEN) jet flow and the turbulent flow near the wall of the mold. The results show various types of vortex structures with different directions are presented during the jet impingement, including the “ring, rib, and horseshoe”-like shaped vortices in the simulation, resulting in complex turbulent flow near the wall of the mold. Vortices structures are then identified and compared by different vorticial criteria, including vortex methods (ω), Q method, λ2 method (Lambda-2), Δ method (Delta), and Ω method (Omega). The formation, development, and dissipation of the vortex structures and their effects on turbulence are investigated. The results indicate that the turbulent flow (viscosity) can reflect changes in asymmetric vortices structures and flow patterns (via crossflow), which can reflect the periodical flow in the mold. Flow oscillation frequencies are mainly concentrated in the range of 0.3 Hz in this simulation. The oscillations are not a simple combination of frequency modes of crossflow in the mold. These new studies can elucidate the mechanism of vortex structure distributions in representative flow regions of the continuous casting mold. Full article

More than 96% of steel in the world is produced via the method of continuous casting. The flow condition in the mould, where the initial solidification occurs, has a significant impact on the quality of steel products. It is important to have timely, and perhaps automated, control of the flow during casting. This work presents a new concept of using contactless inductive flow tomography (CIFT) as a sensor for a novel controller, which alters the strength of an electromagnetic brake (EMBr) of ruler type based on the reconstructed flow structure in the mould. The method was developed for the small-scale Liquid Metal Model for Continuous Casting (mini-LIMMCAST) facility available at the Helmholtz-Zentrum Dresden-Rossendorf. As an example of an undesired flow condition, clogging of the submerged entry nozzle (SEN) was modelled by partly closing one of the side ports of the SEN; in combination with an active EMBr, the jet penetrates deeper into the mould than when the EMBr is switched off. Corresponding flow patterns are detected by extracting the impingement position of the jets at the narrow faces of the mould from the CIFT reconstruction. The controller is designed to detect to undesired flow condition and switch off the EMBr. The temporal resolution of CIFT is 0.5 s. Full article

To study the influence of impinging height H/D on the flow field characteristics of oblique submerged impinging jets, the numerical calculation of an oblique submerged impinging jet was carried out based on Wray–Agarwal (W–A) turbulence model. The jet flow field structure and pressure distribution under various impinging heights (1 ≤ H/D ≤ 8) when the impinging angle was θ = 45° were analyzed. The results show that with the increase in the impinging height, the diffusion degree of the jet gradually increased and the velocity decreased when the jet reached the impingement region, and the distance between the stagnation point (SP) and the geometric center (GC) gradually increased, the flow angle φ along the jet centerline remained constant in the free-jet region and rapidly decreased in the impingement region. The impingement plate pressure distribution at various heights was similar, and the impinging pressure concentration on the upstream side of the maximum pressure point was higher. Full article

The presence of CO₂, sand, and water in oil and gas reservoirs causes erosion–corrosion leading to material degradation in pipelines and fluid handling equipment that results in increasing maintenance and repair costs and a decrease in production. While the weight loss caused by erosion–corrosion is known to depend on flow velocity, angle of impact, sand loading and size and target material properties, field operators often limit the flow rate based on a critical corrosion velocity to protect the equipment. This study investigates the effects of sand loading and flow velocity on weight loss associated with erosion–corrosion in a mild steel sample using a submerged impingement jet. The weight loss by erosion, corrosion and their interaction for a flow velocity range of 10 m/s to 20 m/s and sand loading range of 300 mg/L to 600 mg/L, in a seawater environment, are presented. The results showed that the weight loss by pure erosion and erosion–corrosion interaction increases linearly with jet velocity and sand loading, and that erosion is dominant in all cases except at low velocity and sand loading. The scanning electron microscope (SEM) images after impingement tests were analyzed. In addition, correlations for the velocity and sand loading were derived using the design of experiment method (DOE). Full article

The impinging jet is a classical flow model with relatively simple geometric boundary conditions, and it is widely used in marine engineering. In recent years, scholars have conducted more and more fundamental studies on impact jets, but most of the classical turbulence models are used in numerical simulations, and the accuracy of their calculation results is still a problem in regions with large changes in velocity gradients such as the impact zone. In order to study the complex flow characteristics of the water flow under the condition of a submerged jet impacting a stationary wall, the Wray–Agarwal turbulence model was chosen for the Computational Fluid Dynamics (CFD) numerical simulation study of the impacting jet. Continuous jets with different Reynolds numbers and different impact heights H/D were used to impact the stationary wall, and the results show that the jet flow structure depends on the impact height and is relatively independent of the Reynolds number. With the increase in the impact height, the diffusion of the jet reaching the impact area gradually increases, and its velocity gradually decreases. As the impact height increases, the maximum pressure coefficient decreases and the rate of decrease increases gradually, and the dimensionless pressure distribution is almost constant. In this paper, the flow field structure and pressure characteristics of a continuous submerged jet impacting a stationary wall are explored in depth, which is of great guidance to engineering practice. Full article

Erosion causes substantial damage in many industrial equipment such as pump components, valves, elbows, and plugged tees. In most cases, erosion is coupled with corrosion, resulting in major financial loss (nearly 3.4% of the global gross domestic product) as evidenced in oil and gas industries. In most cases, the erosion occurs in a submerged water medium. In this paper, erosion characteristics of stainless steel 316 were investigated computationally in a water-submerged jet impingement setup. The erosion profiles and patterns were obtained for various parameters over ranges of inlet velocities (3 to 16 m/s), nozzle diameters (5 to 10 mm), nozzle–target distances (5 to 20 mm), nozzle shapes (circular, elliptical, square, and rectangular), impingement angles (60° to 90°), and particle sizes (50 to 300 µm). The range of Reynolds number studied based on nozzle diameters is 21,000–120,000. The Eulerian–Lagrangian approach was used for flow field prediction and particle tracking considering one-way coupling for the particle–fluid interaction. The Finnie erosion model was implemented in ANSYS-Fluent 19.2 and used for erosion prediction. The computational model was validated against experimental data and the distributions of the erosion depth as well as the locations of the of maximum and minimum erosion points are well matched. As expected, the results indicate an increase in loss of material thickness with increasing jet velocity. Increasing the nozzle diameter caused a reduction in the maximum depth of eroded material due to decreasing the particle impact density. At a fixed fluid inlet velocity, the maximum thickness loss increases as the separation distance between the nozzle outlet and target increases, aspect ratio of nozzle shape decreases, and impingement angle increases. The erosion patterns showed that the region of substantial thickness loss increases as nozzle size/stand-off height increases and as particle size decreases. In addition, increasing the aspect ratio and impingement angle creates skewed erosion patterns. Full article

In vertical continuous casting machines the liquid steel from the tundish is poured into the mold through the Submerged Entry Nozzle (SEN). The shape and direction of the SEN exit jets affect the liquid steel dynamics inside the mold. This work quantifies the effect of the SEN pool on the principal characteristics of the jets emerging from it, precisely, the shape, the spread angles, and the mold impact point. Experimental and numerical simulations were carried out using a SEN simplified model, a square-shaped bore nozzle with square-shaped outlet ports whose length is minimal. These experiments showed two well-defined behaviors. When a single vortex dominates the hydrodynamics inside the simplified SEN, the exit jets spread out and are misaligned about the mold’s central plane. On the contrary, when the inner flow pattern shows two vortexes, the exit jets are compact and parallel to the mold wide walls. The measured difference on the jet’s falling angles is 5°, approximately, which implies that in an actual casting machine, the impingement point at the narrow mold wall would have a variation of 0.150 m. This hydrodynamic analysis would help design new SENs for continuous casting machines that improve steel quality. Full article

The presented numerical investigations show an analysis of the turbulent single-phase array of ten minijets impinging a heated surface, which lead to the intensification of heat transfer between the fluid and the surface. Attention was devoted to the comparison between phenomena occurring for the heated flat and concave surface geometry. The selection of the shapes was based on the impinging jets applications. From the numerical point of view, the focus was placed on a comparison of the Reynolds Averaged Navier–Stokes (RANS) turbulence model implementations in ANSYS Fluent software, and their impact on the modeling precision of the thermal and hydrodynamic boundary layers phenomena. The 3D numerical model was based on the continuity, momentum, and energy transport equations, together with three various RANS turbulence models: k-ω SST Kato-Launder, k-ε RNG Kato-Launder, and Intermittency Transition. The water submerged minijets, characterized by three various values of Reynolds number, were considered. Average surface Nusselt number values for all analyzed cases were compared with the experimental correlations and exhibited the same tendency but differed in detail. Numerically obtained average Nusselt number values agreed with the results of two from three correlations in the range of 10–20%. The flat surface was characterized by higher heat transfer than the concave one and an influence of the cross flow, changing the symmetrical distribution of the Nusselt number, was more visible for it. A cross flow impact was found in fuzzy hexagonal or tetragonal symmetry of this distribution. Additionally, the areas of high temperature gradient values were identified in the region of the strongest jets’ interactions, which can be important for mechanical strength analysis. Full article

A water jet is a kind of high-speed dynamic fluid with high energy, which is widely used in the engineering field. In order to analyze the characteristics of the flow field and the change of law of the bottom impact pressure of the oblique submerged impinging jet at different times, its unsteady characteristics at different Reynolds numbers were studied by using the Wray–Agarwal (W-A) turbulence model. It can be seen from the results that in the process of jet movement, the pressure at the peak of velocity on the axis was the smallest, and the velocity, flow angle, and pressure distribution remain unchanged after a certain time. In the free jet region, the velocity, flow angle, and pressure remained unchanged. In the impingement region, the velocity and flow angle decreased rapidly, while the pressure increased rapidly. The maximum pressure coefficient of the impingement plate changed with time and was affected by the Reynolds number, but the distribution trend remained the same. In this paper, the characteristics of the flow field and the law of the impact pressure changing with time are described. Full article

As a kind of water jet technology with strong impinging force and simple structure, the submerged impinging water jet can produce strong scouring action on subaqueous sediments. In order to investigate the flow field characteristics and impinging pressure of submerged impinging water jets at different impinging heights, the Wray-Agarwal (W-A) turbulence model is used for calculation. The velocity distribution and flow field structure at different impinging heights (1 ≤ H/D ≤ 8), and the impinging pressure distribution at the impingement plate under different Reynolds numbers (11, 700 ≤ Re ≤ 35100) are studied. The results show that with the increase of the impinging height, the diffusion degree increases and the velocity decreases gradually when the jet reaches the impingement region. The fluid accelerates first and then decelerates near the stagnation point. The maximum impinging pressure and the impinging pressure coefficient decrease with the increase of the impinging height, but the effective impinging pressure range remains unchanged. In this paper, the distribution characteristics of the impinging pressure in the region of the impingement plate at different heights are clarified, which provides theoretical support for the prediction method of the impinging pressure. Full article

There is a lack of knowledge on the air concentration distribution in plunge pools affected by aerated jets. A set of physical experiments was performed on vertical submerged aerated jet flows impinging a plunge pool. The air concentration distribution in the plunge pool was analyzed under different inflow air concentrations, flow velocities, and discharge rate conditions. The experimental results show that the air concentration distribution follows a power-law along the jet axis, and it is independent of the initial flow conditions. A new hypothetical analysis model was proposed for air diffusion in the plunge pool, that is, the air concentration distribution in the plunge pool is superposed by the lateral diffusion of three stages of the aerated jet motion. A set of formulas was proposed to predict the air concentration distribution in the plunge pool, the results of which showed good agreement with the experimental data. Full article
