One of the important parameters of the sheet metal forming process is the coefficient of friction (CoF). Therefore, monitoring the friction coefficient value is essential to ensure product quality, increase productivity, reduce environmental impact, and avoid product defects. Conventional CoF monitoring techniques pose a number of problems, including the difficulty in identifying the features of force signals that are sensitive to the variation in the coefficient of friction. To overcome these difficulties, this paper proposes a new approach to apply unsupervised artificial intelligence techniques with unbalanced data to classify the CoF of DP780 (HCT780X acc. to EN 10346:2015 standard) steel sheets in strip-drawing tests. During sheet metal forming (SMF), the CoF changes owing to the evolution of the contact conditions at the tool–sheet metal interface. The surface topography, the contact loads, and the material behaviour affect the phenomena in the contact zone. Therefore, classification is required to identify possible disturbances in the friction process causing the change in the CoF, based on the analysis of the friction process parameters and the change in the sheet metal’s surface roughness. The Kohonen self-organising map (SOM) was created based on the surface topography parameters collected and used for CoF classification. The CoF determinations were performed in the strip-drawing test under different lubrication conditions, contact pressures, and sliding speeds. The results showed that it is possible to classify the CoF using an SOM for unbalanced data, using only the surface roughness parameter Sq and selected friction test parameters, with a classification accuracy of up to 98%. Full article

In the process of steel strip production, the accuracy of defect detection remains a challenge due to the diversity of defect types, complex backgrounds, and noise interference. To improve the effectiveness of surface defect detection in steel strips, we propose an enhanced detection model known as YOLOv8-BSPB. First, we propose a novel pooling layer module, SCRD, which replaces max pooling with average pooling. This module introduces the receptive field block (RFB) and deformable convolutional network version 4 (DCNv4) to obtain learnable offsets, allowing convolutional kernels to flexibly move and deform on the input feature map, thus, more effectively extracting multi-scale features. Second, we integrate a polarized self-attention (PSA) mechanism to improve the model’s feature representation and enhance its ability to focus on relevant information. Additionally, we incorporate the BAM attention mechanism after the C2f module to strengthen the model’s feature selection capabilities. A bidirectional feature pyramid network is introduced at the neck of the model to improve feature transmission efficiency. Finally, the WIoU loss function is employed to accelerate the model’s convergence speed and enhance regression accuracy. Experimental results on the NEU-DET dataset demonstrate that the improved model achieves a classification accuracy of 81.3%, an increase of 4.9% over the baseline, with a mean average precision of 86.9%. The model has a parameter count of 5.5 M and operates at 103.1 FPS. To validate the model’s effectiveness, we conducted tests on the Kaggle steel strip dataset and our custom dataset, where the average accuracy improved by 2.3% and 5.5%, respectively. The experimental results indicate that the model meets the requirements for real-time, lightweight, and portable deployment. Full article

Strip steel plays a crucial role in modern industrial production, where enhancing the accuracy and real-time capabilities of surface defect classification is essential. However, acquiring and annotating defect samples for training deep learning models are challenging, further complicated by the presence of redundant information in these samples. These issues hinder the classification of strip steel surface defects. To address these challenges, this paper introduces a high real-time network, ODNet (Orthogonal Decomposition Network), designed for few-shot strip steel surface defect classification. ODNet utilizes ResNet as its backbone and incorporates orthogonal decomposition technology to reduce the feature redundancies. Furthermore, it integrates skip connection to preserve essential correlation information in the samples, preventing excessive elimination. The model optimizes the parameter efficiency by employing Euclidean distance as the classifier. The orthogonal decomposition not only helps reduce redundant image information but also ensures compatibility with the Euclidean distance requirement for orthogonal input. Extensive experiments conducted on the FSC-20 benchmark demonstrate that ODNet achieves superior real-time performance, accuracy, and generalization compared to alternative methods, effectively addressing the challenges of few-shot strip steel surface defect classification. Full article

In the competitive landscape of steel-strip production, ensuring the high quality of steel surfaces is paramount. Traditionally, human visual inspection has been the primary method for detecting defects, but it suffers from limitations such as reliability, cost, processing time, and accuracy. Visual inspection technologies, particularly automation techniques, have been introduced to address these shortcomings. This paper conducts a thorough survey examining vision-based methodologies related to detecting and classifying surface defects on steel products. These methodologies encompass statistical, spectral, texture segmentation based methods, and machine learning-driven approaches. Furthermore, various classification algorithms, categorized into supervised, semi-supervised, and unsupervised techniques, are discussed. Additionally, the paper outlines the future direction of research focus. Full article

Different types of surface defects will occur during the production of strip steel. To ensure production quality, it is essential to classify these defects. Our research indicates that two main problems exist in the existing strip steel surface defect classification methods: (1) they cannot solve the problem of unbalanced data using few-shot in reality, (2) they cannot meet the requirement of online real-time classification. To solve the aforementioned problems, a relational knowledge distillation self-adaptive residual shrinkage network (RKD-SARSN) is presented in this work. First, the data enhancement strategy of Cycle GAN defective sample migration is designed. Second, the self-adaptive residual shrinkage network (SARSN) is intended as the backbone network for feature extraction. An adaptive loss function based on accuracy and geometric mean (Gmean) is proposed to solve the problem of unbalanced samples. Finally, a relational knowledge distillation model (RKD) is proposed, and the functions of GUI operation interface encapsulation are designed by combining image processing technology. SARSN is used as a teacher model, its generalization performance is transferred to the lightweight network ResNet34, and it is conveniently deployed as a student model. The results show that the proposed method can improve the deployment efficiency of the model and ensure the real-time performance of the classification algorithms. It is superior to other mainstream algorithms for fine-grained images with unbalanced data classification. Full article

Defect classification is an important aspect of steel surface defect detection. Traditional approaches for steel surface defect classification employ convolutional neural networks (CNNs) to improve accuracy, typically by increasing network depth and parameter count. However, this approach overlooks the significant memory overhead of large models, and the incremental gains in accuracy diminish as the number of parameters increases. To address these issues, a multi-scale lightweight neural network model (MM) is proposed. The MM model, with a fusion encoding module as its core, constructs a multi-scale neural network by utilizing the Gaussian difference pyramid. This approach enhances the network’s ability to capture patterns at different resolutions while achieving superior model accuracy and efficiency. Experimental results on a dataset from a hot-rolled strip steel plant demonstrate that the MM network achieves a classification accuracy of 98.06% in defect classification tasks. Compared to networks such as ResNet-50, ResNet-101, VGG, AlexNet, MobileNetV2, and MobileNetV3, the MM model not only reduces the number of model parameters and compresses model size but also achieves better classification accuracy. Full article

Due to the shortage of defect samples and the high cost of labelling during the process of hot-rolled strip production in the metallurgical industry, it is difficult to obtain a large quantity of defect data with diversity, which seriously affects the identification accuracy of different types of defects on the steel surface. To address the problem of insufficient defect sample data in the task of strip steel defect identification and classification, this paper proposes the Strip Steel Surface Defect-ConSinGAN (SDE-ConSinGAN) model for strip steel defect identification which is based on a single-image model trained by the generative adversarial network (GAN) and which builds a framework of image-feature cutting and splicing. The model aims to reduce training time by dynamically adjusting the number of iterations for different training stages. The detailed defect features of training samples are highlighted by introducing a new size-adjustment function and increasing the channel attention mechanism. In addition, real image features will be cut and synthesized to obtain new images with multiple defect features for training. The emergence of new images is able to richen generated samples. Eventually, the generated simulated samples can be directly used in deep-learning-based automatic classification of surface defects in cold-rolled thin strips. The experimental results show that, when SDE-ConSinGAN is used to enrich the image dataset, the generated defect images have higher quality and more diversity than the current methods do. Full article

Owing to the remarkable development of deep learning algorithms, defect detection techniques based on deep neural networks have been extensively applied in industrial production. Most existing surface defect detection models assign equal costs to the classification errors among different defect categories but do not strictly distinguish them. However, various errors can generate a great discrepancy in decision risk or classification costs and then produce a cost-sensitive issue that is crucial to the manufacturing process. To address this engineering challenge, we propose a novel supervised classification cost-sensitive learning method (SCCS) and apply it to improve YOLOv5 as CS-YOLOv5, where the classification loss function of object detection was reconstructed according to a new cost-sensitive learning criterion explained by a label–cost vector selection method. In this way, the classification risk information from a cost matrix is directly introduced into the detection model and fully exploited in training. As a result, the developed approach can make low-risk classification decisions for defect detection. It is applicable for direct cost-sensitive learning based on a cost matrix to implement detection tasks. Using two datasets of a painting surface and a hot-rolled steel strip surface, our CS-YOLOv5 model outperforms the original version with respect to cost under different positive classes, coefficients, and weight ratios, but also maintains effective detection performance measured by mAP and F1 scores. Full article

Defect detection on the surface of the steel strip is essential for the quality assurance of the steel strip. Precise localization and classification, the two significant tasks of defect detection, still need to be completed due to the diversity of defect scales. In this paper, a residual atrous spatial pyramid pooling (RASPP) module is first designed to enrich the multi-scale information of the feature maps and increase the receptive field of the feature maps. Secondly, a double pyramid network (DPN) that combines RASPP and feature pyramid is proposed to fuse multi-scale features further so that similar semantic features are shared among the features of each layer. Finally, DPN-Detector, an automatic surface defects detection network, is proposed, which embeds the DPN module into Faster R-CNN and replaces the original detection head with a designed double head. Experiments are carried out on the steel strip surface defect dataset (NEU-DET), and the results show that the mAP of DPN-Detector is as high as 80.93%, which is 3.52% higher than that of the baseline network Faster R-CNN. The classification accuracy is 74.64%, and the detection speed reaches 18.62 FPS. The proposed method performs better robustness, classification and regression capability than other steel strip defect detection methods. Full article

Automatic defects inspection and classification demonstrate significant importance in improving quality in the steel industry. This paper proposed and developed DSTEELNet convolution neural network (CNN) architecture to improve detection accuracy and the required time to detect defects in surface steel strips. DSTEELNet includes three parallel stacks of convolution blocks with atrous spatial pyramid pooling. Each convolution block used a different dilation rate that expands the receptive fields, increases the feature resolutions and covers square regions of input 2D image without any holes or missing edges and without increases in computations. This work illustrates the performance of DSTEELNet with a different number of parallel stacks and a different order of dilation rates. The experimental results indicate significant improvements in accuracy and illustrate that the DSTEELNet achieves of 97% mAP in detecting defects in surface steel strips on the augmented dataset GNEU and Severstal datasets and is able to detect defects in a single image in 23ms. Full article

Surface-defect detection is crucial for assuring the quality of strip-steel manufacturing. Strip-steel surface-defect detection requires defect classification and precision localization, which is a challenge in real-world applications. In this research, we propose an improved PP-YOLOE-m network for detecting strip-steel surface defects. First, data augmentation is performed to avoid the overfitting problem and to improve the model’s capacity for generalization. Secondly, Coordinate Attention is embedded in the CSPRes structure of the backbone network to improve the backbone network’s feature extraction capabilities and obtain more spatial location information. Thirdly, Spatial Pyramid Pooling is specifically replaced for the Atrous Spatial Pyramid Pooling in the neck network, enabling the multi-scale network to broaden its receptive field and gain more information globally. Finally, the SIoU loss function more accurately calculates the regression loss over GIoU. Experimental results show that the improved PP-YOLOE-m network’s AP, AP${}_{50}$, and AP${}_{75}$, respectively, achieved 44.6%, 80.3%, and 45.3% for strip-steel surface defects detection on the NEU-DET dataset and improved by 2.2%, 4.3%, and 4.6% over the PP-YOLOE-m network. Further, our method has fast and real-time detection capabilities and can run at 95 FPS on a single Tesla V100 GPU. Full article

Strip steel surface defects occur frequently during the manufacturing process, and these defects cause hidden risks in the use of subsequent strip products. Therefore, it is crucial to classify the strip steel’s surface defects accurately and efficiently. Most classification models of strip steel surface defects are generally based on convolutional neural networks (CNNs). However, CNNs, with local receptive fields, do not have admirable global representation ability, resulting in poor classification performance. To this end, we proposed a hybrid network architecture (CNN-T), which merges CNN and Transformer encoder. The CNN-T network has both strong inductive biases (e.g., translation invariance, locality) and global modeling capability. Specifically, CNN first extracts low-level and local features from the images. The Transformer encoder then globally models these features, extracting abstract and high-level semantic information and finally sending them to the multilayer perceptron classifier for classification. Extensive experiments show that the classification performance of CNN-T outperforms pure Transformer networks and CNNs (e.g., GoogLeNet, MobileNet v2, ResNet18) on the NEU-CLS dataset (training ratio is 80%) with a 0.28–2.23% improvement in classification accuracy, with fewer parameters (0.45 M) and floating-point operations (0.12 G). Full article

The surface defects of a hot-rolled strip will adversely affect the appearance and quality of industrial products. Therefore, the timely identification of hot-rolled strip surface defects is of great significance. In order to improve the efficiency and accuracy of surface defect detection, a lightweight network based on coordinate attention and self-interaction (CASI-Net), which integrates channel domain, spatial information, and a self-interaction module, is proposed to automatically identify six kinds of hot-rolled steel strip surface defects. In this paper, we use coordinate attention to embed location information into channel attention, which enables the CASI-Net to locate the region of defects more accurately, thus contributing to better recognition and classification. In addition, features are converted into aggregation features from the horizontal and vertical direction attention. Furthermore, a self-interaction module is proposed to interactively fuse the extracted feature information to improve the classification accuracy. The experimental results show that CASI-Net can achieve accurate defect classification with reduced parameters and computation. Full article

In a complex industrial environment, it is difficult to obtain hot rolled strip steel surface defect images. Moreover, there is a lack of effective identification methods. In response to this, this paper implements accurate classification of strip steel surface defects based on generative adversarial network and attention mechanism. Firstly, a novel WGAN model is proposed to generate new surface defect images from random noises. By expanding the number of samples from 1360 to 3773, the generated images can be further used for training classification algorithm. Secondly, a Multi-SE-ResNet34 model integrating attention mechanism is proposed to identify defects. The accuracy rate on the test set is 99.20%, which is 6.71%, 4.56%, 1.88%, 0.54% and 1.34% higher than AlexNet, VGG16, ShuffleNet v2 1×, ResNet34, and ResNet50, respectively. Finally, a visual comparison of the features extracted by different models using Grad-CAM reveals that the proposed model is more calibrated for feature extraction. Therefore, it can be concluded that the proposed methods provide a significant reference for data augmentation and classification of strip steel surface defects. Full article

Hot-rolled strip steel is widely used in automotive manufacturing, chemical and home appliance industries, and its surface quality has a great impact on the quality of the final product. In the manufacturing process of strip steel, due to the rolling process and many other reasons, the surface of hot rolled strip steel will inevitably produce slag, scratches and other surface defects. These defects not only affect the quality of the product, but may even lead to broken strips in the subsequent process, seriously affecting the continuation of production. Therefore, it is important to study the surface defects of strip steel and identify the types of defects in strip steel. In this paper, a scheme based on ResNet50 with the addition of FcaNet and Convolutional Block Attention Module (CBAM) is proposed for strip defect classification and validated on the X-SDD strip defect dataset. Our solution achieves a classification accuracy of 94.11%, higher than more than a dozen other compared deep learning models. Moreover, to adress the problem of low accuracy of the algorithm in classifying individual defects, we use ensemble learning to optimize. By integrating the original solution with VGG16 and SqueezeNet, the recognition rate of oxide scale of plate system defects improved by 21.05 percentage points, and the overall defect classification accuracy improved to 94.85%. Full article
