Search Results (40)

The transition to electric vehicles (EVs) has introduced new challenges in lubrication, demanding innovative solutions to ensure consistent performance. One promising approach is the use of nanoparticle additives, which have the potential to improve lubrication performance significantly. However, achieving a stable suspension of these nanoparticles in lubricating oils remains a critical challenge, as suspension stability is essential for maintaining consistent performance and maximizing the benefits of these advanced additives. In this study, carbon nanoparticles (CNPs) were modified with dodecylamine (DDA) to achieve stable suspension in nonpolar fluids. The successful functionalization was confirmed by the FTIR results, which showed characteristic peaks of various bonding. The suspension stability tests demonstrated that DDA-CNPs remained suspended for over 60 days in the Polyalphaolefin (PAO) oil, whereas unmodified CNPs were sedimented within 3–7 days. The rheological behavior was measured under different shear rates and temperatures. Viscosity measurements indicated that DDA-CNPs maintained a lower value compared to base PAO. The lubricants’ friction coefficient (COF) was also determined under various speeds and loads. The addition of DDA-CNPs at a concentration of 0.05 wt.% resulted in a significant reduction in COF, with values decreasing by 26% compared to base PAO oil under a load of 1 N. Additionally, the COF for DDA-CNPs was consistently lower than that of PAO, with reductions ranging from 15% to 18% across all tested speeds. The Stribeck curve further highlighted the improved performance of DDA-CNPs across boundary, mixed, and hydrodynamic lubrication regimes. These findings suggest that DDA-CNPs significantly improve the lubrication performance of PAO oil, making them suitable for advanced lubrication applications in automotive and industrial systems. Full article

In this study, we investigated the mechanical and tribological properties of the layer-by-layer structure of additively manufactured implant-grade Polyether Ether Ketone (PEEK) through the Material Extrusion (ME) process as a potential substitute for artificial joints. The effective elasticity modulus of the anisotropic 3D-printed PEEK was determined to be 2.505 GPa along the vertical and horizontal build orientations. The lubricated friction and wear performance were assessed using a pin-on-disk test under various loads, including 14, 30, 50, and 70 N, with a sliding speed of 50 mm/s over a total distance of 1 km at 37 °C. The contact parameters between the hemispherical steel pin and 3D-printed PEEK disks, involving contact pressures over the circle of contact, were observed to increase as the load increased. The results indicated that the wear coefficient exhibited a rise from $1.418{ \times 10}^{-5}$ to $2.089{ \times 10}^{-1}$ as the applied loads increased, signaling a shift from mild to severe wear regimes. Fetal Bovine Serum (FBS) as a lubricant exhibited a mixed mechanism, ascertained through the Stribeck curve, as well as a minimum fluid film thickness of 1.346 nm under an isoviscous–elastic regime, as calculated by the maximum load. Moreover, the mechanism governing wear during sliding, influenced by both normal axial and shear loads, primarily involved adhesion. Full article

To address the lack of reliable measurement methods for identifying wear mechanisms and predicting the state of mechanical seal tribo-parts, this study proposes a method for characterizing tribological behavior based on measuring face vibration acceleration. It aims to uncover the source mechanism of mechanical seal face vibration acceleration influenced by tribology and dynamic behavior. This research delves into the dynamic behavior characteristics and vibration acceleration of the mechanical seal stationary ring. We explored the variation pattern of face vibration acceleration root mean square (RMS) with rotation speed, sealing medium pressure, and face surface roughness. The results indicate that under constant medium pressure, an increase in rotation speed leads to a decrease in acceleration RMS and an increase in face temperature. Similarly, under constant rotation speed, an increase in medium pressure results in nonlinear changes in acceleration RMS, forming an “M” shape, along with an increase in face temperature. Furthermore, under conditions of constant medium pressure and rotation speed, an increase in the surface roughness of the rotating ring face corresponds to an increase in acceleration RMS and face temperature. Upon starting the mechanical seal, both acceleration RMS and temperature initially increase before decreasing, a trend consistent with the Stribeck curve. Full article

Hydrodynamic linear guides in machine tools offer a high load capacity and excellent damping characteristics, improving stability, precision, and vibration reduction. This study builds on previous research where floating heights were verified with a simulation model limited to measured floating heights. Advancements include incorporating pressure sensors into a fixed steel rail, enabling simultaneous measurement of oil film pressure and floating heights for a comprehensive understanding of lubrication conditions within the lubrication gap. The experimental results explore the effects of different lubrication methods, providing valuable insights into cavitation and lubrication adequacy. The results demonstrate the feasibility of utilizing pressure sensors to measure oil film pressure within the lubrication gap, providing a nuanced understanding of lubrication dynamics. By measuring both floating heights and pressure measurement, distinctions between hydrodynamic lubrication, mixed friction regions, and instances of lubricant deficiency become readily discernible. The variations in real-time oil film pressure and floating heights help to optimize the lubrication cycle for hydrodynamic linear guides, enhancing system performance and longevity. Full article

The effect of the microstructure of siliconized graphite on tribological properties is investigated by using a high-temperature and high-pressure water-lubricated tribometer on a self-mated ring-on-ring configuration under an applied load of 500–1500 N with a spindle speed of 100–5000 rpm in both 90 °C (5 MPa) and 25 °C (1 MPa) water environments, respectively. The Stribeck curves measurement and continuous wear tests are performed and analyzed in both water environments. The wear behaviors of the graphite, SiC, and free-silicon phases in siliconized graphite are demonstrated to explore the wear mechanism. The larger wear depths of a low-worn surface roughness on the three phases contribute to the boundary lubrication. The shallower wear depths are observed on the SiC and Si phases under the mixed lubrication, corresponding to partial contact wear of surface asperities. The wavy surface of the SiC phase and uniform flow-oriented striae of the Si phase are attributed to hydrodynamic lubrication, caused by full water film scouring the worn surface. Finally, an integrated evaluation method of G duty parameters is successfully used to identify the lubrication regimes of siliconized graphite from the boundary, mixed, to hydrodynamic lubrications for a water-lubricated thrust bearing application in the main coolant pump of a nuclear power plant. Full article

Friction behaviour is an important characteristic of dynamic seals. Surface texturing is an effective method to control the friction level without the need to change materials or lubricants. However, it is difficult to put the manual prediction of optimal friction reducing textures as a function of operating conditions into practice. Therefore, in this paper, we use machine learning techniques for the prediction of optimal texture parameters for friction optimisation. The application of pneumatic piston seals serves as an illustrative example to demonstrate the machine learning method and results. The analyses of this work are based on experimentally determined data of surface texture parameters, defined by the dimple diameter, distance, and depth. Furthermore friction data between the seal and the pneumatic cylinder are measured in different friction regimes from boundary over mixed up to hydrodynamic lubrication. A particular innovation of this work is the definition of a generalised method that guides the entire machine learning process from raw data acquisition to model prediction, without committing to only a few learning algorithms. A large number of 26 regression learning algorithms are used to build machine learning models through supervised learning to evaluate the suitability of different models in the specific application context. In order to select the best model, mathematical metrics and tribological relationships, like Stribeck curves, are applied and compared with each other. The resulting model is utilised in the subsequent friction optimisation step, in which optimal surface texture parameter combinations with the lowest friction coefficients are predicted over a defined interval of relative velocities. Finally, the friction behaviour is evaluated in the context of the model and optimal value combinations of the surface texture parameters are identified for different lubrication conditions. Full article

Ultra-precise actuation at extremely low speeds over a broad range is a major challenge for advanced manufacturing. A novel two-axis differential micro-feed system (TDMS) has been proposed recently to overcome the low-speed crawling of the worktable. However, due to the diversity of the force states of the TDMS, the methods for identification identifyingof friction parameters traditionally (like the all -components identification method, ACIM) didn’t did not perform well. And many studies on the performance of the pre-sliding phase of the TDMS are missing. Therefore, a novel whole-system identification method (WSIM) based on the TDMS was proposed in this paper to precisely identify the friction parameters under different states of motion. The generalized Maxwell sliding (GMS) friction model was also applied to improve the accurate description of the pre-sliding. A novel corrected Stribeck curve based on the TDMS (TDMSSC) was proposed under the uniqueness of the TDMS structure. Control experiments showedn that the WSIM has higher precision and stability rather thancompared torather than the ACIM, and the correction of the Stribeck curve for the TDMS makes a contribution to the performance. This method significantly improves the accuracy and stability of the machine tool drive system. Full article

The key objective of the presented study was to use a commercially feasible and scalable approach to modifying surfaces to reduce friction. In an industrial setting, surface grinding is commercially viable and scalable as compared to other surface modifying processes like laser surface texturing, plasma, or ion beam milling. Frictional force plots are generated from the lubricated contact interface between a flat-faced aluminum pin and a reciprocating stainless steel countersurface driven by a scotch yoke follower mechanism. Using a surface grinder and selecting coated abrasive sheets, different stainless steel surface specimens, classified as P320, P1200, and mirror were prepared and tested in this study. The frictional force encountered by the pin was recorded using a data acquisition system at discrete intervals in the reciprocating path and averaged along the sliding cycles. The shape of the frictional force plots thus generated were found to be different from each other. Various mechanisms of friction prevalent at the contact were presumed to influence the shape of these frictional plots. These mechanisms were tested by varying the sliding speeds, lubricating oil viscosities, and using tribofilm-forming additives. We used Group 1 base oil of two different viscosities in our tests. At lower speeds, the frictional force plot for the mirror-finished surface seemed to conform to the Stribeck curve, while in the same scale of reference, the P1200 surface had a force plot that was nearly flat and of very low magnitude. At the contact interface, there seemed to be a fine balance existing between adhesion and abrasion phenomena, while oil retention was promoted to achieve extremely low sliding friction. Full article

Diamond-like carbon (DLC) coatings are widely used in industries that require high durability and wear resistance, and low friction. The unique characteristics of DLC coatings allow for the possibility of creating adsorption sites for lubricant additives through the doping process. In this study, the combined use of europium-doped diamond-like carbon (Eu-DLC), gadolinium-doped diamond-like carbon (Gd-DLC), and pure DLC coatings and an ionic liquid (IL) additive, namely, trihexyltetradecylphosphonium bis (2-ethylhexyl) phosphate [${\mathrm{P}}_{66614}$] [DEHP], with a 1 wt.% concentration in polyalphaolefin (PAO) 8 as a base lubricant was investigated. Higher hardness, higher thin-film adhesion, a higher ratio of hardness to elastic modulus, and a higher plastic deformation resistance factor were achieved with the Gd-DLC coating. The CoF of the Gd-DLC coating paired with the IL was superior compared to the other pairs in all lubrication regimes, and the pure DLC coating had a better performance than the Eu-DLC coating. The wear could not be quantified due to the low wear on the surface of the DLC coatings. The friction reduction demonstrates that tribological systems combining Gd-DLC thin films with an IL can be a potential candidate for future research and development efforts to reduce friction and increase the efficiency of moving parts in internal combustion engines, for instance. Full article

The mathematical and computational modeling of the lubricated contact between bearing surfaces is presented to analyze the sliding friction using a realistic 3D model on a microscopic scale. The fluid–structure interaction model evaluates the effects of lubricant film thickness on friction in hydrodynamic and mixed lubrication regimes. Higher contact pressures are seen at the peaks of asperities, especially during mixed lubrication, in which the fluid volume is smaller. Calculated friction coefficients from a homogenization procedure of shear and normal forces in the hydrodynamic and mixed lubrication, close to 0.0045 and 0.014, respectively, were accurate and within the range specified in the Stribeck curve. Results demonstrate the computational model allows examining the effects of lubrication on contact between rough surfaces. Full article

While the modification of surface contacts offers significant potential for friction reduction, obtaining an underlying consistent friction behaviour of real-life experiments and virtual simulations is still an ongoing challenge. In particular, most works in the literature only consider idealised geometries that can be parametrised with simple analytical functions. In contrast to this approach, the current work describes the establishment of a digital twin of a pin-on-disk tribometer whose virtual geometry is completely replicated from real-life post-test topography measurements and fed into a two-scale mixed lubrication solver. Subsequently, several calibration steps are performed to identify the sensitivities of the friction behaviour towards certain geometry features and enable the digital twin to robustly represent the Stribeck curve of the physical experiments. Furthermore, a derivation of the Hersey number is used to generalise the obtained friction behaviour for different dynamic viscosities and allow the validation of the presented method. Full article

The numerous prepreg characteristics benefit industries like the aerospace and automotive ones, producing a wide range of high-performance components for primary or secondary applications. Parts production is usually assisted by a thermoforming process in which the prepreg is heated and reshaped employing a moulding system. The ply-ply and ply-tool sliding behaviours in the Thermoforming govern the defects generation, such as wrinkles, making its study a crucial step. This work analyses ply-ply and ply-tool friction coefficients for UD AS4/8552 Carbon/Epoxy prepreg. A pull-out test method was employed to determine the friction coefficients at different velocities, pressures, and temperatures related to the thermoforming process conditions, supplying a detalied report of friction parameters and mechanisms. The measurements of the interlaminar resin layer thickness and the surface roughness geometry resulted respectively in a range of 11–14 μm and 3–4 μm were taken into account in the Lubrication Theory approach to developing an analytical model. Based on the Stribeck curve and Reynolds equation for a viscous fluid, the developed model accurately predicts friction coefficients for prepreg composite materials in the process and contact conditions mentioned below. Full article

The loss of energy due to friction is one of the major problems industries are facing nowadays. Friction and wear between sliding components reduce the mechanical efficiency of machines and have a negative impact on the environment. In recent years, surface texturing has shown tremendous ability to reduce friction and wear. Micro-features generated on surfaces act as a secondary reservoir for lubricants and wear debris receptacles to further reduce abrasion. In addition, surface texturing boosts hydrodynamic pressure, which increases the elasto-hydrodynamic lubrication regime of the Stribeck curve, reducing friction and wear. Amongst all different techniques to texture surfaces, laser texturing is the most popular due to its advantages such as high accuracy, good consistency and celerity as compared to other techniques. This study investigated the effect of laser texturing on the tribological properties of Ti6Al4V in contact with a ceramic ball. The effect of varying the dimple density on friction and wear was studied using a ball-on-flat reciprocating tribometer under lubricated conditions. Results show that friction and wear were reduced for all the textured samples as compared to an untextured sample, with important friction and wear reductions for the samples with the highest dimple densities. For samples with intermediate dimple densities, the friction coefficient stayed low until the dimples wore out from the surface and then increased to a value similar to the friction coefficient of the untextured surface. The dimple wear-out time observed in these specimens was greatly influenced by the dimple density. Full article

This paper proposes a numerical method to investigate the frictional characteristics of a fluid film journal bearing considering the elastohydrodynamic lubrication and the asperity contact force. We solved the average Reynolds equation by utilizing the FEM to determine the hydrodynamic force developed by the lubricant of the journal bearing. We also used a modified GT model (Greenwood–Tripp model) developed by Greenwood and Tripp to decompose the asperity contact force into normal and tangential directions. Once we applied those forces to a rotor, we solved the equations of motion of a flexible shaft to determine the friction coefficient. We verified the proposed method by comparing the calculated friction coefficient with the measured one of journal bearings conducted by prior researchers. Then, the proposed method was applied to investigate the frictional characteristics of a journal bearing of a scroll compressor on which dynamic loads are applied. This paper can contribute to developing robust rotor systems supported by journal bearings. Full article

This study investigates the use of an ionic liquid obtained from fatty acids (FAIL) as an additive at 2 wt.% in two different base oils: a mineral oil (M1) and a polyol ester (E1). Physicochemical characterization of the base oil–FAIL blends confirmed the miscibility of the FAIL in the base oils. The addition of the FAIL hardly changed the density of the base oils and the viscosity slightly increased at lower temperatures. The tribological performance of the base oils and their blends with the FAIL was determined using three different tests: Stribeck curve determination and tribofilm formation tests, both under sliding/rolling motion, and reciprocating wear tests. The M1 + FAIL blend showed the lowest friction values under the mixed lubrication regime due to its higher viscosity, while the E1 + FAIL showed the lowest friction values under the elastohydrodynamic lubrication regime, which may well have been due to its higher polarity. Only the E1 + FAIL blend outperformed the antiwear behavior of the base oil, probably because it has better chemical affinity (higher polarity) for the metallic surface. SEM images showed that the predominant wear mechanism was adhesive-type with plastic deformation and XPS studies proved that the presence of increasing amounts of organic oxygen on the wear scar caused better antiwear performance when the E1 + FAIL blend was used. Full article
