Search Results (22)

Due to the influence of the complex underwater environment, the initial alignment method for Doppler velocity log (DVL)-aided strap-down inertial navigation systems (SINS) often suffer from performance degradation, especially when DVL measurements are contaminated by outliers. In this paper, an outlier-resistant Initial Alignment method with interference suppression for SINS/DVL integrated navigation system is proposed, by which, by constructing an improved Mahalanobis distance anomalous detection criterion, the anomaly of the residual vector composed of observation vectors is judged, and an adaptive weighting factor is introduced into the observation matrix to suppress the abnormal interference in the alignment process. Simulation and experimental results show that, compared with existing initial alignment methods, the proposed method achieves higher alignment accuracy in the presence of outliers, which is more suitable for the SINS/DVL integrated navigation system. Full article

The Stewart platform based bumper is essential for the strap-down inertial navigation system (SINS) to attenuate the vibration excitation from base to SINS. Displacement transmissibility is the most important performance indicator to quantify the vibration isolation effectiveness of the bumper. In this paper, considering the structural complexity and dynamic coupling of the bumper in parallel mechanism shape, a novel method of displacement transmissibility analysis for the bumper under base vibration excitation is proposed. Firstly, a lumped parameter model is established for the bumper by defining dynamic matrices, which includes stiffness matrix, damping matrix and mass matrix. Secondly, coupled dynamic equations of the bumper under base vibration excitation are derived based on the proposed model, and the coupled dynamic equations are transferred to decoupled dynamic equations by decoupling method. Thirdly, a calculation flowchart of the vibration isolation performance for the bumper is proposed based on the deduced decoupled dynamic equations, and theoretical results for displacement transmissibility are obtained by the calculation flowchart. Finally, the proposed analysis approach of displacement transmissibility for the bumper is validated by vibration experiments as the maximum quantitative gap between theoretical and experimental results is 3.6%. Full article

The integration of strap-down inertial navigation systems (SINSs) and ultra-short baseline (USBL) systems has become a mainstream navigation approach for unmanned underwater vehicles (UUVs). In shallow-sea environments, USBL measurements are frequently affected by complex non-Gaussian disturbances. Under such challenging conditions, traditional Kalman filters often exhibit limited performance in maintaining navigation accuracy. A novel adaptive Kalman filter is proposed to address this issue. The proposed method demonstrates significant robustness to complex non-Gaussian noise through the construction of an advanced regression model, the development of an adaptive free-parameter optimization scheme, and the implementation of a recursive filtering architecture incorporating entropy-based error correction. Comprehensive validation via numerical simulations and field experiments in offshore SINS/USBL integrated navigation scenarios demonstrates the superior robustness of the proposed method in complex underwater non-Gaussian noise environments. Full article

This paper proposes an improved initial alignment method for a strap-down inertial navigation system/global navigation satellite system (SINS/GNSS) integrated navigation system with large misalignment angles. Its methodology is based on the three-dimensional special Euclidean group and extended Kalman filter (SE₂(3)/EKF) and aims to overcome the challenges of achieving fast alignment under large misalignment angles using traditional methods. To accurately characterize the state errors of attitude, velocity, and position, these elements are constructed as elements of a Lie group. The nonlinear error on the Lie group can then be well quantified. Additionally, a group vector mixed error model is developed, taking into account the zero bias errors of gyroscopes and accelerometers. Using this new error definition, a GNSS-assisted SINS dynamic initial alignment algorithm is derived, which is based on the invariance of velocity and position measurements. Simulation experiments demonstrate that the alignment method based on SE₂(3)/EKF can achieve a higher accuracy in various scenarios with large misalignment angles, while the attitude error can be rapidly reduced to a lower level. Full article

The operation of underwater vehicles in deep waters is a very challenging task. The use of AUVs (Autonomous Underwater Vehicles) is the preferred option for underwater exploration activities. They can be autonomously navigated and controlled in real time underwater, which is only possible with precise spatio-temporal information. Navigation and positioning systems based on LBL (Long-Baseline) or USBL (Ultra-Short-Baseline) systems have their own characteristics, so the choice of system is based on the specific application scenario. However, comparative experiments on AUV navigation and positioning under both systems are rarely conducted, especially in the deep sea. This study describes navigation and positioning experiments on AUVs in deep-sea scenarios and compares the accuracy of the USBL and LBL/SINS (Strap-Down Inertial Navigation System)/DVL (Doppler Velocity Log) modes. In practice, the accuracy of the USBL positioning mode is higher when the AUV is within a 60° observation range below the ship; when the AUV is far away from the ship, the positioning accuracy decreases with increasing range and observation angle, i.e., the positioning error reaches 80 m at 4000 m depth. The navigational accuracy inside and outside the datum array is high when using the LBL/SINS/DVL mode; if the AUV is far from the datum array when climbing to the surface, the LBL cannot provide accurate position calibration while the DVL fails, resulting in large deviations in the SINS results. In summary, the use of multi-sensor combination navigation schemes is beneficial, and accurate position information acquisition should be based on the demand and cost, while other factors should also be comprehensively considered; this paper proposes the use of the LBL/SINS/DVL system scheme. Full article

The strap-down inertial navigation system (SINS) and Doppler velocity log (DVL) integrated navigation system are widely used for autonomous underwater vehicles (AUVs). Whereas DVL works in the water tracking mode, the velocity provided by DVL is relative to the current layer and cannot be directly used to suppress the divergence of SINS errors. Therefore, the estimation and compensation of the ocean current velocity play an essential role in improving navigation positioning accuracy. In recent works, ocean currents are considered constant over a short term in small areas. In the common KF algorithm with the ocean current as a state vector, the current velocity cannot be estimated because the current velocity and the SINS velocity error are coupled. In this paper, two virtual metrology filter (VMF) methods are proposed for estimating the velocity of ocean currents based on the properties that the currents remain unchanged at the adjacent moments. New measurement equations are constructed to decouple the current velocity and the SINS velocity error, respectively. Simulations and lake tests show that both proposed methods are effective in estimating the current velocity, and each has its advantages in estimating the ocean current velocity or the misalignment angle. Full article

Navigation and positioning of autonomous underwater vehicles (AUVs) in the complex and changeable marine environment are crucial and challenging. For the positioning of AUVs, the integrated navigation of the strap-down inertial navigation system (SINS), Doppler velocity log (DVL), and pressure sensor (PS) has a common application. Nevertheless, in the complex underwater environment, the DVL performance is affected by the current and complex terrain environments. The outliers in sensor observations also have a substantial adverse effect on the AUV positioning accuracy. To address these issues, in this paper, a novel tightly integrated navigation model of the SINS, DVL, and PS is established. In contrast to the traditional SINS, DVL, and PS tightly integrated navigation methods, the proposed method in this paper is based on the velocity variation of the DVL beam by applying the DVL bottom-track and water-track models. Furthermore, a new robust interacting multiple models (RIMM) information fusion algorithm is proposed. In this algorithm, DVL beam anomaly is detected, and the Markov transfer probability matrix is accordingly updated to enable quick model matching. By simulating the motion of the AUV in a complex underwater environment, we also compare the performance of the traditional loosely integrated navigation (TLIN) model, the tightly integrated navigation (TTIN) model, and the IMM algorithm. The simulation results show that because of the PS, the velocity and height in the up-change amplitude of the four algorithms are small. Compared with the TLIN algorithm in terms of maximum deviation of latitude and longitude, the RIMM algorithm also improves the accuracy by 39.1243 m and 26.4364 m, respectively. Furthermore, compared with the TTIN algorithm, the RIMM algorithm improves latitude and longitude accuracy by 1.8913 m and 11.8274 m, respectively. A comparison with IMM also shows that RIMM improves the accuracy of latitude and longitude by 1.1506 m and 7.2301 m, respectively. The results confirm that the proposed algorithm suppresses the observed noise and outliers of DVL and further achieves quick conversion between different DVL models while making full use of the effective information of the DVL beams. The proposed method also improves the navigation accuracy of AUVs in complex underwater environments. Full article

To improve the navigation accuracy for land vehicles during global positioning system (GPS) outages, a machine learning (ML) aided methodology to integrate a strap-down inertial navigation system (SINS) and GPS system is proposed, as follows. When a GPS signal is available, an online sequential extreme learning machine with a dynamic forgetting factor (DOS-ELM) algorithm is used to train the mapping model between the SINS’ acceleration, specific force, speed/position increments outputs, and the GPS’ speed/position increments. When a GPS signal is unavailable, GPS speed/velocity measurements are replaced with prediction output of the well-trained DOS-ELM module’s prediction output, and information fusion with the SINS reduces the degree of system error divergence. A land vehicle field experiment’s actual sensor data were collected online, and the DOS-ELM-aided methodology for the SINS/GPS integrated navigation systems was applied. The simulation results indicate that the proposed methodology can reduce the degree of system error divergence and then obtain accurate and reliable navigation information during GPS outages. Full article

The ocean-going environment is complex and changeable with great uncertainty, which poses a huge challenge to the navigation ability of ships working in the pelagic ocean. In this paper, in an attempt to deal with the complex uncertain interference that the environment may bring to the strap-down inertial navigation system/polarization navigation system/geomagnetic navigation system (SINS/PNS/GMNS) integrated navigation system, the multi-mode switching variational Bayesian adaptive Kalman filter (MMS-VBAKF) algorithm is proposed. To be more specific, to identify the degrees of measurement interference more effectively, we design an interference evaluation and multi-mode switching mechanism using the original polarization information and geomagnetic information. Through this mechanism, the interference to the SINS/PNS/GMNS navigation system is divided into three cases. In case of slight interference (case SI), the variational Bayesian method is adopted directly to solve the problem that the statistical characteristics of measurement noise are unknown. By the fixed-point iteration mechanism, the statistical properties of the measurement noise and the system states can be estimated adaptively in real time. In case of interference-tolerance (case TI), the estimation of the statistical characteristics of measurement noise need to weigh the measurement information at the moment and a priori value information comprehensively. In case of excessive interference (case EI), the SINS/PNS/GMNS integrated navigation system will perform mode switching and filtering system reconstruction in advance. Then, the information fusion and navigation states estimation can be completed. Consequently, the reliability, robustness, and accuracy of the SINS/PNS/GMNS integrated navigation system can be guaranteed. Finally, the effectiveness of the algorithm is illustrated by the simulation experiments. Full article

In order to improve the positioning accuracy of the pipeline inspection gauge (PIG), a pipeline positioning method, based on weld location, is proposed. The position of the welding scar is recognized by wavelet transform modulus maxima (WTMM). Equidistant welding scars provide positioning references to the strap-down inertial navigation system (SINS)/dead reckoning (DR) navigation system, which is the positioning algorithm in PIG. The following improvements have been made in relation to prior research. First, we suggest a selection strategy for the optimal mother wavelet and decomposition level; based on the strategy, WTMM can recognize the collision response between the PIG and submerged weld in the burst noise for the inertial measurement unit (IMU) output. Then, characteristic position (CP), which is the site of the weld scar, and non-holonomic constraints are utilized to decrease the position and the attitude error. By doing such, the SINS/DR/CP algorithm is proposed. The positioning error of the modified algorithm is 0.129% in the experiment, which performs better than other algorithms. Full article

In this paper, a low-cost small-sized strap-down inertial navigation system (SINS)—Gyrolab GL-VG 109—is studied. When the system is installed on an unmanned vehicle and works in autonomous mode, it is difficult to determine the navigation parameters of the unmanned vehicle. Correcting the SINS information from the Global Navigation Satellite System (GNSS) can significantly increase the determination accuracy of the navigation parameters. However, this is only available when the GNSS signals are stable. A new adaptive estimation algorithm that can automatically detect, evaluate, and process the abnormal measurements is proposed in the present work. The determination of the navigation parameters can reach the third accuracy class using the proposed method. The effectiveness of the algorithm is verified by the mathematical simulation and the experimental tests (with a real SINS GL-VG 109), which are conducted in urban environments with a GNSS signal containing 15% and 40% abnormal measurements. The results show that the proposed method can significantly reduce the impact of abnormal measurements and improve the estimation accuracy. Full article

GNSS (global navigation satellite system) and SINS (strap-down inertial navigation system) integrated navigation systems have been the apparatus for providing reliable and stable position and velocity information (PV). Commonly, there are two solutions to improve the GNSS/SINS integration navigation system accuracy, i.e., employing GNSS with higher position accuracy in the integration system or utilizing the high-grade inertial measurement unit (IMU) to construct the integration system. However, technologies such as RTK (real-time kinematic) and PPP (precise point positioning) that improve GNSS positioning accuracy have higher costs and they cannot work under high dynamic environments. Also, an IMU with high accuracy will lead to a higher cost and larger volume, therefore, a low-cost method to enhance the GNSS/SINS integration accuracy is of great significance. In this paper, multiple receivers based on the GNSS/SINS integrated navigation system are proposed with the aim of providing more precise PV information. Since the chip-scale receivers are cheap, the deployment of multiple receivers in the GNSS/SINS integration will not significantly increase the cost. In addition, two different filtering methods with central and cascaded structure are employed to process the multiple receivers and SINS integration. In the centralized integration filter method, measurements from multiple receivers are directly processed to estimate the SINS errors state vectors. However, the computation load increases heavily due to the rising dimension of the measurement vector. Therefore, a cascaded integration filter structure is also employed to distribute the processing of the multiple receiver and SINS integration. In the cascaded processing method, each receiver is regarded as an individual “sensor”, and a standard federated Kalman filter (FKF) is implemented to obtain an optimal estimation of the navigation solutions. In this paper, a simulation and a field tests are carried out to assess the influence of the number of receivers on the PV accuracy. A detailed analysis of these position and velocity results is presented and the improvements in the PV accuracy demonstrate the effectiveness of the proposed method. Full article

Autonomous and accurate acquisition of the position and azimuth of the vehicle is critical to the combat effectiveness of land-fighting vehicles. The integrated navigation system, consisting of a strap-down inertial navigation system (SINS) and odometer (OD), is commonly applied in vehicles. In the SINS/OD integrated system, the odometer is installed around the vehicle’s wheel, while SINS is usually installed on the base of the vehicle. The distance along SINS and OD would cause a velocity difference when the vehicle maneuvers, which may lead to a significant influence on the integration positioning accuracy. Furthermore, SINS navigation errors, especially azimuth error, would diverge over time due to gyro drifts and accelerometer biases. The azimuth error would cause the divergence of dead-reckoning positioning errors with the distance that the vehicle drives. To solve these problems, an integrated positioning and orientation method based on the configuration of SINS and couple odometers was proposed in this paper. The proposed method designed a high precision integrated navigation algorithm, which compensated the lever arm effect to eliminate the velocity difference between SINS and odometers. At the same time, by using the measured information of couple odometers, azimuth reference was calculated and used as an external measurement to suppress SINS azimuth error’s divergence over time, thus could further improve the navigation precision of the integrated system, especially the orientation accuracy. The performance of the proposed method was verified by simulations. The results demonstrated that SINS/2ODs integrated system could achieve a positioning accuracy of 0.01% D (total mileage) and orientation accuracy of ±30″ by using SINS with 0.01°/h Fiber-Optic Gyroscope (FOGs) and 50 µg accelerometers. Full article

The optimization-based alignment (OBA) methods, which are implemented by the optimal attitude estimation using vector observations—also called double-vectors—have proven to be effective at solving the in-flight alignment (IFA) problem. However, the traditional OBA methods are not applicable for the low-cost strap-down inertial navigation system (SINS) since the error of double-vectors will be accumulated over time due to the substantial drift of micro-electronic- mechanical system (MEMS) gyroscope. Moreover, the existing optimal estimation method is subject to a large computation burden, which results in a low alignment speed. To address these issues, in this article we propose a new fast IFA method based on modified double-vectors construction and the gradient descent method. To be specific, the modified construction method is implemented by reducing the integration interval and identifying the gyroscope bias during the construction procedure, which improves the accuracy of double-vectors and IFA; the gradient descent scheme is adopted to estimate the optimal attitude of alignment without complex matrix operation, which results in the improvement of alignment speed. The effect of different sizes of mini-batch on the performance of the gradient descent method is also discussed. Extensive simulations and vehicle experiments demonstrate that the proposed method has better accuracy and faster alignment speed than the related traditional methods for the low-cost SINS/global positioning system (GPS) integrated navigation system Full article

To realize the error parameter estimation of strap-down inertial navigation system (SINS) and improve the navigation accuracy for aircraft, a hybrid improved restricted Boltzmann machine BP neural network (IRBM-BPNN) approach, which combines restricted Boltzmann machine (RBM) and BP neural network (BPNN), is proposed to forecast the inertial measurement unit (IMU) instrument errors and initial alignment errors of SINS. Firstly, the error generation mechanism of SINS is analyzed, and initial alignment error model and IMU instrument error model are established. Secondly, an unsupervised RBM method is introduced to initialize BPNN to improve the forecast performance of the neural network. The RBM-BPNN model is constructed through the information fusion of SINS/GPS/CNS integrated navigation system by using the sum of position deviation, the sum of velocity deviation and the sum of attitude deviation as the inputs and by using the error parameters of SINS as the outputs. The RBM-BPNN structure is improved to enhance its forecast accuracy, and the pulse signal is increased as the input of the neural network. Finally, we conduct simulation experiments to forecast and compensate the error parameters of the proposed IRBM-BPNN method. Simulation results show that the artificial neural network method is feasible and effective in forecasting SINS error parameters, and the forecast accuracy of SINS error parameters can be effectively improved by combining RBM and BPNN methods and improving the neural network structure. The proposed IRBM-BPNN method has the optimal forecast accuracy of SINS error parameters and navigation accuracy of aircraft compared with the radial basis function neural network method and BPNN method. Full article
