The study introduces a novel standalone hybrid Energy Management System that combines solar PV, wind energy conversion systems, battery storage, and microturbines in order to provide reliable and efficient power under various operating conditions. The developed Quantum-Inspired Multiverse Optimization (QI-MVO) algorithm has thus far allowed for a remarkable efficiency of 99.9% and a 40% reduction in power losses when compared to conventional approaches. A rather speedy convergence to best solutions is exhibited by the methods, which take about 0.07 s for calculation, hence ensuring accurate optimization in complex energy systems. The QI-MVO-based EMS brings in improved reliability and optimal utilization of the system through balanced energy distribution and by maintaining system operational stability. In conclusion, the present work showcases QI-MVO as a sustainable and scalable energy management solution, which sets the stage for optimization strategies wherein hybrid energy management assumes a very important role. Full article

The operation and modelling of doubly fed induction generators (DFIGs) are quite different in grid-connected and stand-alone operated wind energy conversion systems (WECSs). Researchers usually simulate DFIGs in these operations using the pre-built models provided in commercial software, which are built using complex modeling techniques that most researchers in the field are unfamiliar with. In this paper, a simple and easy-to-use modeling approach based on the basic dynamic voltage equations of an induction machine (IM) is proposed to provide a more physical and practical understanding of the dynamic behavior of DFIGs, considering the difference between stand-alone and grid-connected operations. The basic theory and various dynamic models of DFIGs are reviewed and discussed to clarify the complexity of using alternative reference frame coordinates and various state variables in these models. A generic fifth-order DFIG model that is defined in an arbitrary general reference coordinate frame is considered. It is a flux-based model that allows for change in the parameters of the DFIG online and can be used only for grid-connected operations under control. In addition, this model is expanded to be used for stand-alone operation, but can also be used for grid-connected mode operation. The stand-alone model consists of a hybrid modeling approach and more closely resembles the real structure of a stand-alone DFIG system. The modeling technique used for the stand-alone DFIG provides a practical, non-mathematical way to solve the challenge of defining the dynamic equation of the stator voltage when different sizes and types of loads are connected to the stator. Many technical research problems and critical events that are challenging in DFIG-based WECSs can be studied using the proposed simulation models. As pioneering examples, several effective simulations are carried out, aiming to provide new researchers in this field with a more practical, in-depth, and intuitive understanding of the theory and operating principle of DFIGs in both stand-alone and grid-connected operations. The accuracy of the proposed stand-alone model is demonstrated by comparative simulation tests performed in parallel operation with two other pre-built models with the same conditions and power size. Furthermore, both proposed models are validated by simulating them for two different-sized DFIGs of 15 kW and 2 MW. In addition, a real experiment is conducted for the current controlled operation of a stand-alone DFIG using the introduced small-sized laboratory hardware setup. The results obtained through simulations and experiment are presented and discussed. Full article

Integrating wind turbines within urban environments, either as building-mounted units or standalone installations, represents a valuable step toward sustainable city development. Vertical axis wind turbines (VAWTs) are commonly favored in these settings due to their ability to handle turbulent winds; however, they generally exhibit lower energy conversion efficiency compared to horizontal axis wind turbines (HAWTs). Selecting optimal urban or suburban locations with favorable wind conditions opens the possibility of deploying HAWTs, leveraging their higher efficiency even at comparable wind speeds. This paper presents a methodology for designing highly efficient HAWTs for urban use, supported by computational fluid dynamics (CFD) analyses to produce power curves and evaluate the energy conversion efficiency of both bare and augmented turbine designs. Differing from prior studies, this work also incorporates a detailed economic analysis, examining how reductions in the Levelized Cost of Energy (LCOE) enhance the cost-effectiveness of small-scale distributed wind systems. The findings offer insights into the technical and economic viability of small-scale HAWT configurations for distributed energy generation across diverse urban locations with varying wind profiles. Full article

Wind power systems, which are currently being constructed for the electricity worldwide market, are mostly based on Doubly Fed Induction Generators (DFIGs). To control such systems, multilevel converters are increasingly preferred due to the well-known benefits they provide. This paper deals with the control of a standalone DFIG-based Wind Energy Conversion System (WECS) by using a three-level Neutral-Point-Clamped (NPC) converter. The frequency and magnitude of the stator output voltage of the DFIG are controlled and fixed at nominal values despite the variable rotor speed, ensuring a continuous AC supply for three-phase loads. This task is achieved by controlling the DFIG rotor currents via a PI controller combined with a new Simplified Direct Space Vector Modulation strategy (SDSVM), which is applied to the three-level NPC converter. This strategy is based on the use of a line-to-line three-level converter space vector diagram without using Park transformation and then simplifying it to that of a two-level converter. The performance of the proposed SDSVM technique in terms of controlling the three-level NPC-converter-based standalone WECS is demonstrated through simulation results. The whole WECS control and the SDSVM strategy are implemented on a dSPACE DS 1104 board that drives a DFIG-based wind system test bench. The obtained experimental results confirm the validity and performance in terms of control. Full article

This work presents a control strategy for integrating an offshore wind farm into the onshore electrical grid using a high-voltage dc transmission system based on modular multilevel converters. The proposed algorithm allows the high-voltage DC system to operate in grid-connected or stand-alone modes, with the second case supplying power to local loads. In either mode, the modular multilevel rectifier works as a grid-forming converter, providing the reference voltage to the collector network. During grid-connected operation, the modular multilevel inverter regulates the DC link voltage while the generating units are controlled to maximize power extracted from the wind turbines. Conversely, in the event of grid disconnection, the onshore modular multilevel converter takes over the regulation of the AC voltage at the point of connection to the grid, ensuring energy supply to local loads. Simultaneously, the generator controller transitions from tracking the maximum power of the wind turbines to regulating the DC link voltage, preventing excessive power injection into the transmission DC link. Additionally, the turbine pitch angle control regulates the speed of the generator. Mathematical models in the synchronous reference frame were developed for each operation mode and used to design the converter’s controllers. A digital model of the wind power plant and a high-voltage dc transmission system was implemented and simulated in the PSCAD/EMTDC program. The system modeled includes two groups of wind turbines, generators, and back-to-back converters, in addition to a DC link with a rectifier and an inverter station, both based on modular multilevel converters with 18 submodules per arm, and a 320 $\mathrm{k}\mathrm{V}$/50 $\mathrm{k}\mathrm{m}$ DC cable. Aggregate models were used to represent the two groups of wind turbines, where 30 and 15 smaller units operate in parallel, respectively. The performance of the proposed control strategy and the designed controllers was tested under three distinct scenarios: disconnection of the onshore converter from the AC grid, partial loss of a wind generator set, and reconnection of the onshore converter to the AC grid. Full article

The world today is plagued with problems of increased transmission and distribution (T&D) losses leading to poor reliability due to power outages and an increase in the expenditure on electrical infrastructure. To address these concerns, technology has evolved to enable the integration of renewable energy sources (RESs) like solar, wind, diesel and biomass energy into small scale self-governing power system zones which are known as micro-grids (MGs). A de-centralised approach for modern power grid systems has led to an increased focus on distributed energy resources and demand response. MGs act as complete power system units albeit on a small scale. However, this does not prevent them from large operational sophistication allowing their independent functioning in both grid-connected and stand-alone modes. MGs provide greater reliability as compared to the entire system owing to the large amount of information secured from the bulk system. They comprise numerous sources like solar, wind, diesel along with storage devices and converters. Several modeling schemes have been devised to reduce the handling burden of large scale systems. This paper gives a detailed review of MGs and their architecture, state space representation of wind energy conversion systems & solar photovoltaic (PV) systems, operating modes and power management in a MG and its impact on a distribution network. Full article

This paper investigates maximum power extraction from a wind-energy-conversion system (WECS) with a permanent magnet synchronous generator (PMSG) operating in standalone mode. This was achieved by designing a robust adaptive nonsingular fast terminal sliding mode control (ANFTSMC) for the WECS-PMSG. The proposed scheme guaranteed optimal power generation and suppressed the system uncertainties with a rapid convergence rate. Moreover, it is independent of the upper bounds of the system uncertainties as an online adjustment algorithm was utilized to estimate and compensate them. Finally, four case studies were carried out, which manifested the remarkable performance of ANFTSMC in comparison to previous methods reported in the literature. Full article

The problem of electrical power delivery is a common problem, especially in remote areas where electrical networks are difficult to reach. One of the ways that is used to overcome this problem is the use of networks separated from the electrical system through which it is possible to supply electrical energy to remote areas. These networks are called standalone microgrid systems. In this paper, a standalone micro-grid system consisting of a Photovoltaic (PV) and Wind Energy Conversion System (WECS) based Permanent Magnet Synchronous Generator (PMSG) is being designed and controlled. Fuzzy logic-based Maximum Power Point Tracking (MPPT) is being applied to a boost converter to control and extract the maximum power available for the PV system. The control system is designed to deliver the required energy to a specific load, in all scenarios. The excess energy generated by the PV panel is used to charge the batteries when the energy generated by the PV panel exceeds the energy required by the load. When the electricity generated by the PV panels is insufficient to meet the load’s demands, the extra power is extracted from the charged batteries. In addition, the controller protects the battery banks in all conditions, including normal, overcharging, and overdischarging conditions. The controller should handle each case correctly. Under normal operation conditions (20% < State of Charge (SOC) < 80%), the controller functions as expected, regardless of the battery’s state of charge. When the SOC reaches 80%, a specific command is delivered, which shuts off the PV panel and the wind turbine. The PV panel and wind turbine cannot be connected until the SOC falls below a safe margin value of 75% in this controller. When the SOC goes below 20%, other commands are sent out to turn off the inverter and disconnect the loads. The electricity to the inverter is turned off until the batteries are charged again to a suitable value. Full article

Sustainable energy based hybrid microgrids are advantageous in meeting constantly increasing energy demands. Conversely, the intermittent nature of renewable sources represents the main challenge to achieving a reliable supply. Hence, load frequency regulation by adjusting the amount of power shared between subsystems is considered as a promising research field. Therefore, this paper presents a new stratagem for frequency regulation by developing a novel two stage integral-proportional-derivative with one plus integral (IPD-(1+I)) controller for multi sources islanded microgrid system (MS-IμGS). The proposed stratagem has been tested in an MS-IμGS comprising of a wind turbine, parabolic trough, biodiesel generators, solid-oxide fuel cell, and electric water heater. The proposed model under different scenarios is simulated in MATLAB environment considering the real-time recorded wind data. A recently developed sine-cosine algorithmic technique (SCA) has been leveraged for optimal regulation of frequency in the considered microgrid. To identify the supremacy of the proposed technique, comparative studies with other classical controllers with different optimization techniques have been performed. From the comparison, it is clearly evident that, SCA-(IPD-(1+I)) controller gives better performance over other considered stratagems in terms of various time domain specific parameters, such as peak deviations (overshoot, undershoot) and settling time. Finally, the robustness of the proposed stratagem is evaluated by conducting sensitivity analysis under ±30% parametric variations and +30% load demand. The lab tests results validate the operation of the proposed system and show that it can be used to regulate the frequency in stand-alone microgrids with a high penetration of renewable energy. Full article

This paper presents an improved estimation strategy for the rotor flux, the rotor speed and the frequency required in the control scheme of a standalone wind energy conversion system based on self-excited three-phase squirrel-cage induction generator with battery storage. At the generator side control, the rotor flux is estimated using an adaptive Kalman filter, and the rotor speed is estimated based on an artificial neural network. This estimation technique enhances the robustness against parametric variations and uncertainties due to the adaptation mechanisms. A vector control scheme is used at the load side converter for controlling the load voltage with respect to amplitude and frequency. The frequency is estimated by a Kalman filter method. The estimation schemes require only voltage and current measurements. A power management system is developed to operate the battery storage in the DC-microgrid based on the wind generation. The control strategy operates under variable wind speed and variable load. The control, estimation and power management schemes are built in the MATLAB/Simulink and RT-LAB platforms and experimentally validated using the OPAL-RT real-time digital controller and a DC-microgrid experimental setup. Full article

China has built four stations in Antarctica so far, and Zhongshan Station is the largest station among them. Continuous power supply for manned stations mainly relies on fuel. With the gradual increase in energy demand at the station and cost of fuel traffic from China to Zhongshan station in Antarctica, reducing fuel consumption and increasing green energy utilization are urgent problems. This research considers a standalone renewable energy system. The polar environments and renewable energy distribution of area of Zhongshan station are analyzed. The physical model, operation principle, and mathematical modeling of the proposed power system were designed. Low-temperature performance and state of charge (SOC) estimation method of the lead–acid battery were comprehensively tested and evaluated. A temperature control strategy was adopted to prevent the battery from low-temperature loss of the battery capacity. Energy management strategy of the power system was proposed by designing maximum power point tracking (MPPT) control strategies for wind turbine and PV array. The whole power system is broadly composed of a power generator (wind turbine and PV array), an uploading circuit, a three-phase rectifier bridge, an interleaved Buck circuit, a DC/DC conversion circuit, a switch circuit, a power supply circuit, an amplifier, a driver circuit, a voltage and current monitoring, a load, battery units and a control system. A case study in Antarctica was applied and can examine the technical feasibility of the proposed system. The results of the case study reveal that the scheme of standalone renewable energy system can satisfy the power demands of Zhongshan Station in normal operation. Full article

This research work explains the practical realization of hybrid solar wind-based standalone power system with maximum power point tracker (MPPT) to produce electrical power in rural places (residential applications). The wind inspired Ant Colony Optimization (ACO)-based MPPT algorithm is employed for the purpose of fast and accurate tracking power from wind energy system. Fuzzy Logic Control (FLC) inverter controlling strategy is adopted in this presented work compared to classical proportional-integral (PI) control. Moreover, single Cuk converter is operated as impedance power adapter to execute MPPT functioning. Here, ACO-based MPPT has been implemented with no voltage and current extra circuit requirement compared to existing evolutionary algorithms single cuk converter is employed to improve conversion efficiency of converter by maximizing power stages. DC-link voltage can be regulated by placing Cuk converter Permanent Magnet Synchronous Generator (PMSG) linked rectifier and inverter. The proposed MPPT method is responsible for rapid battery charging and gives power dispersion of battery for hybrid PV-Wind system. ACO-based MPPT provides seven times faster convergence compared to the particle swarm optimization (PSO) algorithm for achievement of maximum power point (MPP) and tracking efficiency. Satisfactory practical results have been realized using the dSPACE (DS1104) platform that justify the superiority of proposed algorithms designed under various operating situations. Full article

In this paper, a novel voltage control strategy for stand-alone operation brushless doubly fed induction generators for variable speed constant frequency wind energy conversion systems was presented and discussed. Based on the model of the power generation system, the proposed direct flux control strategy employs a nonlinear reduced-order generalized integrator-based resonant sliding-mode control approach to directly calculate and regulate the output value of converter which the control winding stator requires so as to eliminate its instantaneous errors, without involving any synchronous rotating coordinate transformations. The stability, robustness and convergence capability of the proposed control strategy were described and analyzed. Owing to the fact no additional current control inner loops are involved, the system configuration is therefore simplified and the dynamic performance enhanced. A constant converter switching frequency was achieved by using space vector pulse width modulation, which reduces the harmonics of the generator terminal voltage. In addition, the feasibility and validity of the proposed scheme is verified by experiments, and excellent steady and transient performance is achieved. Full article

This paper addresses the design and analysis of a voltage and frequency control (VFC) strategy for full converter (FC)-based wind energy conversion systems (WECSs) and its applicability for the supply of an isolated load. When supplying an isolated load, the role of the back-to-back converters in the FC must change with respect to a grid-connected application. Voltage and frequency are established by the FC line side converter (LSC), while the generator side converter (GSC) is responsible for maintaining constant voltage in the DC link. Thus, the roles of the converters in the WECS are inverted. Under such control strategies, the LSC will automatically supply the load power and hence, in order to maintain a stable operation of the WECS, the wind turbine (WT) power must also be controlled in a load-following strategy. The proposed VFC is fully modelled and a stability analysis is performed. Then, the operation of the WECS under the proposed VFC is simulated and tested on a real-time test bench, demonstrating the performance of the VFC for the isolated operation of the WECS. Full article
