In this paper, a generic computational framework, based on the generalized-mode approach, is developed for the fully coupled time-domain aero-hydro-servo-elastic analysis of Hybrid Offshore Wind and Wave Energy Systems (HOWiWaESs), consisting of a Floating Offshore Wind Turbine (FOWT) and several wave energy converters (WECs) mechanically connected to it. The FOWT’s platform and the WECs of the HOWiWaES are modeled as a single floating body with conventional rigid-body modes, while the motions of the WECs relative to the FOWT are described as additional generalized modes of motion. A numerical tool is established by appropriately modifying/extending the OpenFAST source code. The frequency-dependent exciting forces and hydrodynamic coefficients, as well as hydrostatic stiffness terms, are obtained using the traditional boundary integral equation method, whilst the generalized-mode shapes are determined by developing appropriate 3D vector shape functions. The tool is applied for a 5 MW FOWT with a spar-type floating platform and a conic WEC buoy hinged on it via a mechanical arm, and results are compared with those of other investigators utilizing the multi-body approach. Two distinctive cases of a pitching and a heaving WEC are considered. A quite good agreement is established, indicating the potential of the developed tool to model floating HOWiWaESs efficiently. Full article

Floating offshore wind turbines (FOWTs) unlock superior wind resources and reduce operational barriers. The dynamics of FOWT platforms present added engineering challenges and opportunities. While the motion of the floating platform due to wind and wave disturbances can worsen power quality and increase structural loading, certain movements of the floating platform can be exploited to improve power capture. Consequently, active FOWT platform control methods using conventional and innovative actuation systems are under investigation. This paper develops a novel framework to design nonlinear control laws for six degrees-of-freedom platform motion. The framework uses simplified rigid-body analytical models of the FOWT. Lyapunov’s direct method is used to develop actuator-agnostic unconstrained control laws for platform translational and rotational control. A model based on the NREL-5MW reference turbine on the OC3-Hywind spar-buoy platform is utilized to test the control framework for an ideal actuation scenario. Possible applications using traditional and novel turbine actuators and future research directions are presented. Full article

For floating wind turbines, one of the most interesting and challenging issues is that the movement of the rotor is strongly related to its floating platform, which results in corresponding variations in the wake characteristics of the turbine. Because the aerodynamic efficiency of the downstream turbines is affected by the wake characteristics, the power output will consequently vary depending on the different types of floating wind turbines and floating wind farms used. In this study, the rotor movement, wake characteristics, and corresponding wind farm power output are analyzed using a numerical method for three typical floating wind turbines: the semisubmersible type, spar buoy type, and tension leg platform type with a 5 MW configuration. A fixed-bottom monopile wind turbine is adopted as a benchmark. The simulation results show that of the three floating wind turbines, the rotor position and wake center are most dispersed in the case of the spar buoy type, and its wake also has the lowest impact on downstream wind turbines. Additionally, the power output of the corresponding spar buoy type wind farm is also the highest at different wind speeds, followed by the semisubmersible type, tension leg platform type, and then the fixed-bottom type. In particular, at low wind speeds, the wake effects differ significantly among the various types of wind turbines. Full article

This is a new installment in the series of publications that describe the mathematical modeling of the Floating Hybrid Generator Systems Simulator (FHYGSYS) tool. This work presents an improved mathematical model of the turbines of the floating hybrid system—consisting of an “OC3-Hywind” wind turbine and two marine current turbines—presented by the authors in previous publications. In this third installment, the modeling of the three turbines of the floating hybrid system is described using the Blade Element Momentum (BEM) theory. This modeling allows one to replace the one based on the One-Dimensional theory used in previous installments. For the operation of modeling with BEM, it has been considered necessary to implement a continuous feedback control system. In this case, two PID (proportional–integral–derivative) controllers have been implemented in each of the turbines. The first controls the torque on the turbine generator and the second controls the collective pitch angle of the blades. The results obtained are presented and validated through a code-to-code comparison with simulations carried out with FASTv8 under the same conditions and with the operating results of marine current turbines that exist in the literature. This improvement in the mathematical model offers the possibility of implementing other types of controllers that allow for the testing of different strategies of the floating hybrid control system, with the aim of maximizing energy production while ensuring the structural stability of the floating hybrid system. Full article

As the siting of wind turbines increasingly transitions from shallow water to offshore deep-water locations, improving the platform stability of floating offshore wind turbines is becoming a growing concern. By coupling a porous shell commonly used in traditional marine structures, with a FOWT (floating wind turbine platform), a new spar-buoy with a porous shell was designed. A numerical model investigating the coupling effect of the aero-hydro-mooring system is developed, and the results of the motion response are compared with the OC3-Hywind spar. The motion response of the two platforms was simulated in the time-domain with the incident wave period varied in the range of 5~22 s. The exciting wave force with added mass and radiation damping of the spar with the porous shell is compared with the OC3-Hywind spar. The results demonstrate that the motion response amplitude of the spar with the porous shell decreases in all three main motion freedoms (i.e., surge, heave and pitch, etc.), among which the heave motions are most significantly attenuated. The study shows that the coupling of porous shells with a floating platform to achieve the reduced motion responses is feasible and can be an innovative structure for the development of deep-sea offshore floating wind turbines. Full article

This work is part of a series of publications that propose a floating hybrid system for which a simulation tool has been developed, called FHYGSYS (Floating Hybrid Generator Systems Simulator). The objective of this series of publications is to analyze the behavior and to evaluate different control strategies of the floating hybrid system. This system consists of an “OC3-Hywind” wind turbine and two marine current turbines presented by the authors in previous publications. This work completes the exposition of the mathematical model of the floating hybrid system started in a previous publication (Part I), in which the inertial, kinematic, and dynamic parts of the model were described. In this second part, the forces acting on the floating system are extensively described, and the turbines are modeled using the so-called One-Dimensional theory (or also known as Simple theory). The results obtained with the FHYGSYS simulation tool have been validated—through a code-to-code comparison—with FASTv8, both in the first part and in this second part of this work. Full article

This initial publication is part of a series of publications that will appear soon, which pursue a final objective for the proposal of a fully integrated and controlled hybrid system composed of a floating wind turbine—type “OC3-Hywind”—and two marine current turbines with the aim of increasing the energy generated by the floating installation and, at the same time, use the set of turbines as actuators as part of an integral cooperative control system of the floating hybrid system to ensure the structural stability of the floating hybrid generator system (FHGS) in harsh weather conditions, which is a key issue in this type of floating systems. A specially designed tool to design, analyze, and control this type of FHGSs was developed using Matlab^®. In this tool, named Floating Hybrid Generator Systems Simulator (FHYGSYS), several tests were carried out on the structural stability of the system considering the interactive phase of the acting forces. Working in a programming environment like Matlab^® allows design freedom and the possibility of evaluating the system with different geometries, aerodynamic airfoils, and external meteorological conditions, and also including or eliminating certain elements, etc. This versatility will be helpful in future studies aimed at evaluating this system and maximizing the production of energy. Full article

New large-scale laboratory data are presented on a physical model of a spar buoy wind turbine with angular motion of control surfaces implemented (pitch control). The peculiarity of this type of rotating blade represents an essential aspect when studying floating offshore wind structures. Experiments were designed specifically to compare different operational environmental conditions in terms of wave steepness and wind speed. Results discussed here were derived from an analysis of only a part of the whole dataset. Consistent with recent small-scale experiments, data clearly show that the waves contributed to most of the model motions and mooring loads. A significant nonlinear behavior for sway, roll and yaw has been detected, whereas an increase in the wave period makes the wind speed less influential for surge, heave and pitch. In general, as the steepness increases, the oscillations decrease. However, higher wind speed does not mean greater platform motions. Data also indicate a significant role of the blade rotation in the turbine thrust, nacelle dynamic forces and power in six degrees of freedom. Certain pairs of wind speed-wave steepness are particularly unfavorable, since the first harmonic of the rotor (coupled to the first wave harmonic) causes the thrust force to be larger than that in more energetic sea states. The experiments suggest that the inclusion of pitch-controlled, variable-speed blades in physical (and numerical) tests on such types of structures is crucial, highlighting the importance of pitch motion as an important design factor. Full article

Current measurements in the open sea are generally acquired by Acoustic Doppler Current Profilers (ADCPs). In the case of ADCPs mounted on spar buoy, current profiles require to be post-processed, to properly take into account the buoy influence: in fact, ADCP compass may reflect alterations induced by the metal structure of the buoy and apparent currents can occur due to the large displacement of the platform. Uncertainty analysis is finally required to properly consider both these effects and to compute robust velocity estimates. A new methodology is tested for a measurement station in the Ligurian Sea, where an ADCP was mounted on the surface buoy of the W1-M3A (Western 1 Mediterranean Moored Multisensor Array) oceanographic observatory, facing upwards at the depth of about 40 m. Marine current numerical models and historical data in the area have been used as a basis for comparison to test the consistency of the proposed method. A very good agreement is obtained. Only minor discrepancies are reported (e.g., monthly averages from the reference model slightly underestimate the west-east current component along the entire profile), but, in general, the application of the proposed methodology ensures that the spar buoy-mounted ADCP system is able to provide reliable measurements for oceanographic studies and validation of 3D hydrodynamic models. Full article

With increasing deployment of offshore wind farms further from shore and in deeper waters, the efficient and effective planning of operation and maintenance (O&M) activities has received considerable attention from wind energy developers and operators in recent years. The O&M planning of offshore wind farms is a complicated task, as it depends on many factors such as asset degradation rates, availability of resources required to perform maintenance tasks (e.g., transport vessels, service crew, spare parts, and special tools) as well as the uncertainties associated with weather and climate variability. A brief review of the literature shows that a lot of research has been conducted on optimizing the O&M schedules for fixed-bottom offshore wind turbines; however, the literature for O&M planning of floating wind farms is too limited. This paper presents a stochastic Petri network (SPN) model for O&M planning of floating offshore wind turbines (FOWTs) and their support structure components, including floating platform, moorings and anchoring system. The proposed model incorporates all interrelationships between different factors influencing O&M planning of FOWTs, including deterioration and renewal process of components within the system. Relevant data such as failure rate, mean-time-to-failure (MTTF), degradation rate, etc. are collected from the literature as well as wind energy industry databases, and then the model is tested on an NREL 5 MW reference wind turbine system mounted on an OC3-Hywind spar buoy floating platform. The results indicate that our proposed model can significantly contribute to the reduction of O&M costs in the floating offshore wind sector. Full article

During the past years, researchers have studied both numerically and experimentally multibody wave-wind combined energy structures supporting wind turbines and different types of Wave Energy Converters (WECs); rigid body hydrodynamic assumptions have been adopted so far for the development of their numerical models and the assessment of their produced power. In the present paper a numerical model that is based on the use of generalized modes addressing wave-structure interaction effects for the case of a multibody wave-wind combined structure is developed and presented. Afterwards, the developed numerical model is used for the assessment of the hydrodynamic response and the prediction of the produced power of different possible configurations of the updated WindWEC concept which consists of a spar supporting a wind turbine and one, two, three or four heaving type WEC buoys. The combined effects of the center-to-center distance of the WEC and spar platform, the number of the WECs and the grid configuration of spar and WECs on the hydrodynamic interaction between the different floating bodies, spar and WEC buoys, and consequently on their response and wave power production are examined for regular and irregular waves. Strong hydrodynamic interaction effects exist for small distance between spar and WECs that result to the decrease of the produced power. Power matrices of the updated WindWEC concept are presented for all examined configurations with different number of WECs. Moreover, the annual produced power of the updated WindWEC in two sites is estimated and presented. The generalized modes analysis presented in this paper is generic and can be used for the early stage assessment of wave-wind combined energy structures with low computational cost. The updated WindWEC can be used in sea sites with different environmental characteristics while extracting valuable amount of wave power. Full article

The spar buoy platform for offshore wind turbines is the most utilized type and the OC3 Hywind system design is largely used in research. This system is usually moored with three catenary cables with 120° between each other. Adding clump weights to the mooring lines has an influence on the platform response and on the mooring line tension. However, the optimal choice for their position and weight is still an open issue, especially considering the multitude of sea states the platform can be exposed to. In this study, therefore, an analysis on the influence of two such variables on the platform response and on the mooring line tension is presented. FAST by the National Renewable Energy Laboratory (NREL) is used to perform time domain simulations and Response Amplitude Operators are adopted as the main indicators of the clump weights effects. Results show that the clump weight mass is not as influential as the position, which turns out to be optimal, especially for the Surge degree of freedom, when closest to the platform. Full article

The present paper deals with the Life-Cycle Cost (LCC) of an offshore renewable energy farm that is currently a topic of interest for operators and investors. The LCC analysis refers to the Cost Breakdown Structure (CBS) considering all the phases of life span, and it has been carried out for floating offshore wind farms (FOWFs) and hybrid wind-wave farms (HWWFs). For HWWFs, this paper proposes a hybrid wind-wave energy system (HWWES), which provides the coupling of wave energy converter (WEC) with Tension Leg Platform (TLP) or Spar Buoy platform (SB). The LCC analysis has been carried out considering: (i) FOWF consisting of TLP floating platforms; (ii) FOWF consisting of a SB floating platforms; (iii) HWWF realized with the conceived hybrid system coupling the WEC with the TLP platform; (iv) HWWF realized with the conceived hybrid system coupling the WEC with SB platform. In addition to the LCC evaluation, the Levelized Cost of Energy (LCOE) analysis has also been carried out. The site chosen for the study is off the port of Brindisi, southern Italy. This work’s interest lies in having performed a LCC analysis for FOWF and HWWF in the Mediterranean that is an area of growing interest for offshore renewable energy, and obtained results have allowed making assessments on costs for offshore energy farms. Full article

Mathematical models are essential for the design and control of offshore systems, to simulate the fluid–structure interactions and predict the motions and the structural loads. In the development and derivation of the models, simplifying assumptions are normally required, usually implying linear kinematics and hydrodynamics. However, while the assumption of linear, small amplitude motion fits traditional offshore problems, in normal operational conditions (it is desirable to stabilize ships, boats, and offshore platforms), large motion and potential dynamic instability may arise (e.g., harsh sea conditions). Furthermore, such nonlinearities are particularly evident in wave energy converters, as large motions are expected (and desired) to enhance power extraction. The inadequacy of linear models has led to an increasing number of publications and codes implementing nonlinear hydrodynamics. However, nonlinear kinematics has received very little attention, as few models yet consider six degrees of freedom and large rotations. This paper implements a nonlinear hydrodynamic and kinematic model for an archetypal floating structure, commonplace in offshore applications: an axisymmetric spar-buoy. The influence of nonlinear dynamics and kinematics causing coupling between modes of motion are demonstrated. The nonlinear dynamics are shown to cause parametric resonance in the roll and pitch degrees of freedom, while the nonlinear kinematics are shown to potentially cause numerical instability in the yaw degree of freedom. A case study example is presented to highlight the nonlinear dynamic and kinematic effects, and the importance of including a nominal restoring term in the yaw DoF presented. Full article

The aim of this work is to develop a software to calculate the economic parameters so as to determine the feasibility of a floating offshore renewable farm in a selected location. The software can calculate the economic parameters of several types of offshore renewable energies, as follows: one renewable energy (floating offshore wind—WindFloat, tension leg platform (TLP), and spar; floating wave energy—Pelamis and AquaBuoy), hybrid offshore wind and wave systems (Wave Dragon and W2Power), and combined offshore wind and waves with different systems (independent arrays, peripherally distributed arrays, uniformly distributed arrays, and non-uniformly distributed arrays). The user can select several inputs, such as the location, configuration of the farm, type of floating offshore platform, type of power of the farm, life-cycle of the farm, electric tariff, capital cost, corporate tax, steel cost, percentage of financing, or interest and capacity of the shipyard. The case study is focused on the Galicia region (NW of Spain). The results indicate the economic feasibility of a farm of floating offshore renewable energy in a particular location in terms of its costs, levelized cost of energy (LCOE), internal rate of return (IRR), net present value (NPV), and discounted pay-back period. The tool allows for establishing conclusions about the dependence of the offshore wind resource parameters, the main distances (farm–shore, farm–shipyard, and farm–port), the parameters of the waves, and the bathymetry of the area selected. Full article
