This study presents numerical analyses of the thermal, metallurgical, and mechanical processes involved in welding. The temperature fields were computed by solving the transient heat transfer equation using the ABAQUS/Standard 2024 finite element solver. Two types of moving heat sources were applied: a surface Gaussian distribution and a volumetric model, both implemented via DFLUX subroutines to simulate welding on butt-jointed plates. The simulation accounted for key welding parameters, including current, voltage, welding speed, and plate dimensions. The thermophysical properties of the INC 738 LC nickel superalloy were used in the model. Solidification characteristics, such as dendritic arm spacing, were estimated based on cooling rates around the weld pool. The model also calculated transverse residual stresses and applied a hot cracking criterion to identify regions vulnerable to cracking. The peak transverse stress, recorded in the heat-affected zone (HAZ), reached 1.1 GPa under Goldak’s heat input model. Additionally, distortions in the welded plates were evaluated for both heat source configurations. Full article

The oil reserves of global basement reservoirs are 248 × 10⁸ t and natural gas reserves are 2681 × 10⁸ m³; they are crucial links in the future oil and natural gas exploration field and play an irreplaceable role in increasing oil and natural gas reserves and production. Based on research on the definition and classification of basement reservoirs, this study dissected three major basement reservoirs in China (i.e., the Dongping region located in the Qaidam Basin, the Bozhong 19-6 gas field located the Bohai Bay Basin, and the Central Uplift area of the Songliao Basin). The geological conditions and controlling factors of oil and natural gas accumulation in basement reservoirs in China are summarized. The results of this study are as follows: (1) Basement reservoirs can be classified into three distinct types, namely, the weathered carapace type, weathered inner type, and weathered composite type. They are characterized by a large burial depth, strong concealment, and huge reserves and are mostly distributed at the margins of continental plates and in zones with stratum intensive tectonic activity; (2) Basement reservoirs in different basins have different controlling factors. The basement reservoir in the Dongping region, located in the Qaidam Basin, has favorable geological conditions with laterally connected sources and reservoirs. In this reservoir, oil and natural gas have transferred along faults and unconformities to accumulate in uplifted areas, forming a weathered carapace-type basement reservoir controlled by structures. The Bozhong 19-6 gas field, which is situated in the Bohai Bay Basin, has favorable multiple hydrocarbon supplies of source rocks. Under the communication of faults and cracks, oil resources form a weathered inner type basement reservoir. In the Central Uplift area of the Songliao Basin, the basement reservoir exhibits a dual-sided hydrocarbon supply condition from the uplift. In this reservoir, oil and natural gas have transferred to traps through the fault and inner fracture system and have been properly preserved thanks to the extensive overlying cap rocks. It can be concluded that, after being attenuated by millions of years of weathering and leaching, basement rocks can form large-scale and medium-scale basement reservoirs with reserves of more than 100 million barrels in the presence of favorable geological conditions, such as a multi-directional hydrocarbon supply, a high brittle mineral content in the reservoirs, diverse reservoir spaces, and high-quality cap rocks. Full article

In order to investigate the stress characteristics of ballastless track under high latitude, and multi-source and multi-field extreme temperature conditions. Based on the finite element theory and the elastic foundation beam–plate principle, a finite element model of the ballastless track considering the limit convex abutment, gel resin, and interlayer bonding is established. The mechanical characteristics of the ballastless track under the slab–CAM layer bonding state, mortar separation, freeze–thaw degradation and forced deformation of the foundation are studied. Considering the deterioration of materials, the bending moment and reinforcement of track structures in cold regions are checked and calculated. The studies show that under the action of negative temperature gradient load, the edge of the track slab is subjected to tension, and structural separation occurs at the edge of the slab. When the interface between the track slab–CAM layer is poorly bonded, the bearing capacity can be improved, and the amount of separation can be reduced by increasing the structural stiffness of the CAM layer. Under the action of freeze–thaw cycles, the material performance deteriorates seriously, the separation between the track structures intensifies, the baseplate is seriously powdered and cracked, and the maximum tensile stress exceeds 6 MPa. The CAM layer and the baseplate are weak structures, and the foundation frost heave occurs at the expansion joint of the baseplate, which is the frost heave condition. Under freeze–thaw deterioration, the original reinforcement design of the substructure structure does not meet the requirements of structural cracks and reinforcement yield stress. In severely cold areas, the structural reinforcement scheme should be reasonably determined. Full article

Due to its higher energy and smaller heating area, laser joining technology is widely used in aluminum alloy welding and other industrial fields, which meets the solder sealing requirements for electronic packaging. According to experiments, cracks were prone to occur at the corners and spot-welding positions near the weld. In this paper, the depth and width of the melt pool were measured experimentally, and the results were used to calibrate and validate the heat source model. An empirical relationship between heat source parameters and melt pool morphology is presented. The heat source model of laser deep penetration welding was established under the same experimental conditions. And the results were in agreement with the experimental results. The finite element method was used to numerically simulate the welding process of a 50%SiAl shell and a 27%SiAl cover plate. The effects of different spot-welding sequences and numbers on the residual stress and cracking possibility of laser welded samples were analyzed. The results show that under sequential spot-welding, when the amount of spot-welding is increased, the stress peak value decreases. Compared with sequential spot welding and side-by-side spot welding, the spot-welding sequence of diagonal points first, and then side-by-side spot welding, can effectively reduce the residual stress. This research enables us to provide some guidelines in terms of studying the reliability issues of microwave devices. Full article

In the current study, the effects of cracks in source field plates (SFPs) on the electrical performance of AlGaN/GaN high electron mobility transistors (HEMTs) are investigated systematically using numerical simulation. In detail, the influence of crack width and junction angle in SFPs on device performance is studied. The results indicate that the SFP structure increases the breakdown voltage of a device, but the occurrence of cracks causes premature breakdown, which is confirmed experimentally by the structural analysis of these devices after breakdown. With an increase in crack width, the electrical performance becomes worse. A beveled SFP architecture is proposed by increasing the angle at the SFP junction to reduce the probability of cracking and enhance the reliability of the device. However, with an increase in bevel angle, the modulation effect of the SFP on the channel electric field is gradually weakened. Therefore, it is necessary to balance the relationship between electrical performance and bevel angle according to the actual demands. This work provides potential support for SFP structural optimization design for AlGaN/GaN HEMTs. Full article

We propose an efficient semi-analytical method capable of modeling the propagation of flexural waves on cracked plate structures with any forms of excitations, based on the same group of vibration characteristics and validated by a non-contact scanning Laser Doppler Vibrometer (LDV) system. The proposed modeling method is based on the superposition of the vibrational normal modes of the detected structure, which can be applied to analyze long-time and full-field transient wave propagations. By connecting the vibration-based transient model to a power flow analysis technique, we further analyze the transient waves on a cracked plate subjected to different excitation sources and show the influence of the damage event on the path of the propagating waves. The experimental results indicate that the proposed semi-analytical method can model the flexural waves, and through that, the crack information can be revealed. Full article

Thick high-strength steel plates are increasingly being used for ship structures. Moreover, hydrogen enters the process of manufacturing and service, and large residual tensile stress occurs near the weld. Such stress can facilitate the diffusion and accumulation of hydrogen in the material, leading to hydrogen embrittlement fracture of the shell. Therefore, residual-stress-induced diffusion and accumulation of hydrogen in the stress concentration region of thick butt-welded high-strength steel plate structures need to be studied. In this study, manual metal arc welding was realized by numerical simulation of residual stress in a thick butt-welded high-strength steel plate model using the thermoelastic–plastic theory and a double ellipsoidal heat source model. To analyze residual stress, a set of numerical simulation methods was obtained through comparative analysis of the test results of relevant literature. Residual and hydrostatic stress distributions were determined based on these methods. Then, hydrogen diffusion parameters in each region of the model were obtained through experimental tests. Finally, the results of the residual stress field were used as the predefined field of hydrogen diffusion to conduct a numerical simulation analysis. The distribution of hydrogen diffusion under the influence of residual stress was obtained based on the theory of stress-induced hydrogen diffusion. The weak area of the welding joint was found to be near the weld toe, which exhibited high hydrostatic stress and hydrogen concentration. Further, the maximum hydrogen concentration value of the vertical weld path was approximately 6.1 ppm, and the maximum value of the path parallel to the weld centerline and 31 mm away from the weld centerline was approximately 6.22 ppm. Finally, the hydrostatic tensile stress in the vertical weld path was maximized (~345 MPa), degrading the material properties and causing hydrogen-related cracking. Hence, a reliable method for the analysis of hydrogen diffusion according to residual stress in thick high-strength steel plates was obtained. This work could provide a research basis for controlling and eliminating the adverse effects of hydrogen on the mechanical properties of ship structures and ensuring the safe service of marine equipment. Full article

Elastic materials include metal plates, rubber, foam, airbags and so on, which have a good buffer effect, toughness and strong recovery ability. In this paper, the deformation and thermal diffusion of $2\mathrm{D}$ and 3D thin plates are studied. Two models are established for the deformation of 2D thin plates. The bending deformation equation of rectangular and circular plates is derived, and the semi-analytical solution of the deflection function $w(x,y)$ is found through the Fourier series approximation in the polar coordinate. The consistencies of the numerical solution and the theoretical solution are verified by numerical method. Then, we find that the factors affecting the deformation are related to the Young’s modulus, load, plate length and deformation factor $\alpha$ of the material. In a separate temperature physics field, we establish a heat conduction model of $2\mathrm{D}$ graphene film. Three numerical schemes of the transient heat conduction equation of FDM-FEM are given. In contrast, this paper uses the implicit Euler method to discrete the time term. Furthermore, we compared the difference between the adiabatic condition and the convection condition by the graphical method and the curve trend. The results show that the temperature near the adiabatic boundary is higher. Finally, we proposed a 3D dynamic thermal–mechanical coupling model (3D-DTMCM) that has been established. A laser heating monocrystalline silicon sheet with periodic motion formula is given. The temperature radiation of the laser heat source has Gaussian distribution characteristics. Our proposed model can dynamically determine Young’s modulus with a variable temperature. The numerical results show that the higher the temperature is, the higher the strain energy density of the plate is. In addition, the deformation amplitude of the plates in the coupling field is larger than that in the single mechanical field. Finally, we also discussed the stress field distribution of mixed cracks under high temperature and high load. Our research provides theoretical support for the deformation of different plates, and also reflects the value of the coupled model in practical applications. Full article

In the present work an approach to weld metal microstructure prediction is proposed, based on an analytical method that allows the evaluation of the thermal fields generated during the laser beam travel on thick plates. Reference is made to AISI 304L austenitic steel as a base material, with the aim to predict the molten zone microstructure and verify the best condition to avoid hot cracking formation, which is a typical issue in austenitic steel welding. The “keyhole” full penetration welding mode, characteristic of high-power laser beam, was simulated considering the phenomenological laws of conduction by the superimposition of a line thermal source along the whole thickness and two point sources located, respectively, on the surface and at the position of the beam focus inside the joint. This model was fitted on the basis of the fusion zone profile, which was experimentally detected on a weld seam obtained by means of a CO₂ laser beam, in a single pass on two squared edged AISI 304L plates, that were butt-positioned. Then the model was applied to evaluate the thermal fields and cooling rates, the fusion zone composition and the solidification mode. Full article

The chromium coating prepared by multi-arc ion plating on the surface of zirconium alloy is easy to fall off under extremely harsh conditions due to the defects of larger particles, pores and weak adhesion between the coating and the zirconium alloy substrate. Here we apply a new composite process for the fabrication of Cr coating by laser melting multi-arc ion plating technology. The numerical model of temperature field laser melting treatment was established, and based on the analysis of the above temperature field of laser melting treatment, the laser with an energy density of 9 × 10⁴ J/cm²–18 × 10⁴ J/cm² was selected as the heat source. Laser energy density has a great influence on the diffusion behavior of Cr at the coating-substrate interface. When the energy density of laser is 9 × 10⁴ J/cm², the laser heat source cannot provide enough energy to melt the surface of the coating, however, the Cr element diffuses slightly at the membrane base interface, forming a Cr diffusion zone of about 4 μm. When the energy density of the laser increases to 13.5 × 10⁴ J/cm², the Zr element of the substrate diffused to the whole Cr coating, and the original Cr coating disappeared, forming a Zr-Cr diffusion and fusion zone of 30 μm. As the laser preparation process of the coating is a mixed sintering process of liquid phase sintering and solid phase sintering, the coating surface forms a dense zone and a loose zone respectively, resulting in the increase of porosity and particle rate. With the laser energy density increasing gradually, the Zr-Cr fusion zone is formed, and the coating surface particles were gradually refined and the pores were significantly reduced. With the further increase of laser energy density of 18 × 10⁴ J/cm², the Zr-Cr fusion zone was extended to 60 μm, and the porosity and particle rate were reduced to 0.3% and 0.4% respectively. In addition, the original stratification cracking of the film base at the fracture of the tensile specimen disappears, and the protrusion of the interface is formed. Coatings with dimple fractures were found, which indicates that the coating exhibited ductility and interfacial metallurgical bonding. Full article

Previous studies have indicated that a basic frost layer negatively affects the heat-transfer efficiency and is difficult to remove using a single ultrasonic transducer. Herein, an ultrasonic phased array technology is proposed for evaporator coil defrosting. First, the dispersion curve of the guided wave in the vibration transfer plate and frosting fin is calculated, and the advance time of each ultrasonic vibrator and the ultrasonic near-field pressures under different velocities are determined through numerical calculations using the MATLAB software. Next, according to the advance time, ultrasonic array focusing is performed to remove the basic frost layer. Finally, the power consumption, heat-supply enthalpy difference, and coefficient of performance (COP) of the air-source heat pump (ASHP) unit are analysed. The theoretical analysis, numerical calculations, and experimental results consistently revealed that ultrasonic array focusing compensates for the energy dissipation and expends the effective defrosting area. Additionally, the perpendicular stress elicited by the Lamb wave and the differential transverse shear stress generated by the SH wave exceed the tensile strength and adhesion stress of the basic frost layer. The basic frost layer cracks and falls away, owing to the combination of the ultrasonic stress effect and the cavitation effect. The defrosting power consumption of the ASHP unit under ultrasonic array excitation decreases from −3.27% to 0.12%, whereas the heat-supply enthalpy difference increases from 4.47% to 10.86%. Therefore, the percentage increment of the COP is between 7.16% and 11.12%, and the power consumption of the reverse-cycle defrosting is 3–12 times that of ultrasonic array defrosting. Full article

The thermo-elastic fracture problem and equations are established for aluminium alloy Metal Inert Gas (MIG) welding, which include a moving heat source and a thermoelasticity equation with the initial and boundary conditions for a plate structure with a crack. The extended finite element method (XFEM) is implemented to solve the thermo-elastic fracture problem of a plate structure with a crack under the effect of a moving heat source. The combination of the experimental measurement and simulation of the welding temperature field is done to verify the model and solution method. The numerical cases of the thermomechanical parameters and stress intensity factors (SIFs) of the plate structure in the welding heating and cooling processes are investigated. The research results provide reference data and an approach for the analysis of the thermomechanical characteristics of the welding process. Full article

GMR sensors are widely used in many industrial segments such as information technology, automotive, automation and production, and safety applications. Each area requires an adaption of the sensor arrangement in terms of size adaption and alignment with respect to the field source involved. This paper deals with an analysis of geometric sensor parameters and the arrangement of GMR sensors providing a design roadmap for non-destructive testing (NDT) applications. For this purpose we use an analytical model simulating the magnetic flux leakage (MFL) distribution of surface breaking defects and investigate the flux leakage signal as a function of various sensor parameters. Our calculations show both the influence of sensor length and height and that when detecting the magnetic flux leakage of µm sized defects a gradiometer base line of 250 µm leads to a signal strength loss of less than 10% in comparison with a magnetometer response. To validate the simulation results we finally performed measurements with a GMR magnetometer sensor on a test plate with artificial µm-range cracks. The differences between simulation and measurement are below 6%. We report on the routes for a GMR gradiometer design as a basis for the fabrication of NDT-adapted sensor arrays. The results are also helpful for the use of GMR in other application when it comes to measure positions, lengths, angles or electrical currents. Full article
