Background: Ultrasonography is commonly employed during thoracic regional anesthesia; however, its accuracy can be affected by factors such as obesity and poor penetration through the rib window. Needle-sized ultrasound transducers, known as intra-needle ultrasound (INUS) transducers, have been developed to detect the pleura and fascia using a one-dimensional radio frequency mode ultrasound signal. In this study, we aimed to use time-frequency analysis to characterize the pleural signal and develop an automated tool to identify the pleura during medical procedures. Methods: We developed an INUS system and investigated the pleural signal it measured by establishing a phantom study, and an in vivo animal study. Signals from the pleura, endothoracic fascia, and intercostal muscles were analyzed. Additionally, we conducted time- and frequency-domain analyses of the pleural and alveolar signals. Results: We identified the unique characteristics of the pleura, including a flickering phenomenon, speckle-like patterns, and highly variable multi-band spectra in the ultrasound signal during the breathing cycle. These characteristics are likely due to the multiple reflections from the sliding visceral pleura and alveoli. This automated identification of the pleura can enhance the safety for thoracic regional anesthesia, particularly in difficult cases. Conclusions: The unique flickering pleural signal based on INUS can be processed by time-frequency domain analysis and further tracked by an auto-identification algorithm. This technique has potential applications in thoracic regional anesthesia and other interventions. However, further studies are required to validate this hypothesis. Key Points Summary: Question: How can the ultrasound pleural signal be distinguished from other tissues during breathing? Findings: The frequency domain analysis of the pleural ultrasound signal showed fast variant and multi-band characteristics. We suggest this is due to ultrasound distortion caused by the interface of multiple moving alveoli. The multiple ultrasonic reflections from the sliding pleura and alveoli returned in variable and multi-banded frequency. Meaning: The distinguished pleural signal can be used for the auto-identification of the pleura for further clinical respiration monitoring and safety during regional anesthesia. Glossary of Terms: intra-needle ultrasound (INUS); radio frequency (RF); short-time Fourier transform (STFT); intercostal nerve block (ICNB); paravertebral block (PVB); pulse repetition frequency (PRF). Full article

The early detection of liver fibrosis is of significant importance. Deep learning analysis of ultrasound backscattered radiofrequency (RF) signals is emerging for tissue characterization as the RF signals carry abundant information related to tissue microstructures. However, the existing methods only used the time-domain information of the RF signals for liver fibrosis assessment, and the liver region of interest (ROI) is outlined manually. In this study, we proposed an approach for liver fibrosis assessment using deep learning models on ultrasound RF signals. The proposed method consisted of two-dimensional (2D) convolutional neural networks (CNNs) for automatic liver ROI segmentation from reconstructed B-mode ultrasound images and one-dimensional (1D) CNNs for liver fibrosis stage classification based on the frequency spectra (amplitude, phase, and power) of the segmented ROI signals. The Fourier transform was used to obtain the three kinds of frequency spectra. Two classical 2D CNNs were employed for liver ROI segmentation: U-Net and Attention U-Net. ROI spectrum signals were normalized and augmented using a sliding window technique. Ultrasound RF signals collected (with a 3-MHz transducer) from 613 participants (Group A) were included for liver ROI segmentation and those from 237 participants (Group B) for liver fibrosis stage classification, with a liver biopsy as the reference standard (Fibrosis stage: F0 = 27, F1 = 49, F2 = 51, F3 = 49, F4 = 61). In the test set of Group A, U-Net and Attention U-Net yielded Dice similarity coefficients of 95.05% and 94.68%, respectively. In the test set of Group B, the 1D CNN performed the best when using ROI phase spectrum signals to evaluate liver fibrosis stages ≥F1 (area under the receive operating characteristic curve, AUC: 0.957; accuracy: 89.19%; sensitivity: 85.17%; specificity: 93.75%), ≥F2 (AUC: 0.808; accuracy: 83.34%; sensitivity: 87.50%; specificity: 78.57%), and ≥F4 (AUC: 0.876; accuracy: 85.71%; sensitivity: 77.78%; specificity: 94.12%), and when using the power spectrum signals to evaluate ≥F3 (AUC: 0.729; accuracy: 77.14%; sensitivity: 77.27%; specificity: 76.92%). The experimental results demonstrated the feasibility of both the 2D and 1D CNNs in liver parenchyma detection and liver fibrosis characterization. The proposed methods have provided a new strategy for liver fibrosis assessment based on ultrasound RF signals, especially for early fibrosis detection. The findings of this study shed light on deep learning analysis of ultrasound RF signals in the frequency domain with automatic ROI segmentation. Full article

The distorted supply voltage degrades the control performance of a unified power quality conditioner (UPQC). This problem causes incorrect calculations in the harmonic identification and reference signal generation processes. This paper proposes a modified harmonic identification of the UPQC. The reference compensating current calculation for the shunt active power filter (shunt APF) is developed using the sliding window with the Fourier analysis (SWFA) method. In addition, the variable power angle control (PAC) is applied to operate the reference signal generation of the series APF and the shunt APF of the UPQC. Under the distorted voltage and nonlinear load conditions, the proposed approach can provide accurate reference compensating signals and successfully share the load reactive power compensation between the shunt APF and the series APF. In this work, a three-phase, three-wire power system with linear and nonlinear loads was implemented. The proposed method was validated using the processor-in-the-loop technique on an eZdsp™ F28335 board and the MATLAB/Simulink program. The testing results indicated that SWFA has excellent filtering performance and enhances harmonic identification compared to the operation without any filter or with low pass filters (LPF). With the proposed approach, the percentage of total harmonic distortion of voltage and current could be maintained within the IEEE519-2022 standard, and the magnitude of the RMS voltage across the load was in the recommended range specified by ANSI C84.1-2016. Full article

In this article, the main problem under investigation is the detection and diagnosis of short-circuit faults in power transmission lines. The proposed fault detection (FDD) approach is mainly based on principal component analysis (PCA). The proposed fault diagnosis/identification (FAI) approach is mainly based on sliding-window versions of the discrete Fourier transform (DFT) and discrete Hilbert transform (DHT). The main contributions of this article are (a) a fault detection approach based on principal component analysis in the two-dimensional scores space; and (b) a rule-based fault identification approach based on human expert knowledge, combined with a probabilistic decision system, which detects variations in the amplitudes and frequencies of current and voltage signals, using DFT and DHT, respectively. Simulation results of power transmission lines in Portugal are presented in order to show the robust and high performance of the proposed FDD approach for different signal-to-noise ratios. The proposed FDD approach, implemented in Python, that can be executed online or offline, can be used to evaluate the stress to which circuit breakers (CBs) are subjected, providing information to supervision- and condition-based monitoring systems in order to improve predictive and preventive maintenance strategies, and it can be applied to high-/medium-voltage power transmission lines as well as to low-voltage electronic transmission systems. Full article

The inertial navigation system (INS) and global satellite navigation system (GNSS) are two of the most significant systems for land navigation applications. The inertial measurement unit (IMU) is a kind of INS sensor that measures three-dimensional acceleration and angular velocity measurements. IMUs based on micro-electromechanical systems (MEMSs) are widely employed in vehicular navigation thanks to their low cost and small size, but their magnitude and noisy biases make navigation errors diverge very fast without external constraint. The zero-velocity update (ZVU) function is one of the efficient functions that constrain the divergence of IMUs for a stopped vehicle, and the key of the ZVU is the correct stationary detection for the vehicle. When a land vehicle is stopped, the idling engine produces a very stable vibration, which allows us to perform frequency analysis and a comparison based on the fast Fourier transform (FFT) and IMU measurements. Hence, we propose a stationary detection method based on the FFT for a stopped land vehicle with an idling engine in this study. An urban vehicular navigation experiment was carried out with our GNSS/IMU integration platform. Three stops for 10 to 20 min were set to analyze, generate and evaluate the FFT-based stationary detection method. The FFT spectra showed clearly idling vibrational peaks during the three stop periods. Through the comparison of FFT spectral features with decelerating and accelerating periods, the amplitudes of vibrational peaks were put forward as the key factors of stationary detection. For the consecutive stationary detection in the GNSS/IMU integration process, a three-second sliding window with a one-second updating rate of the FFT was applied to check the amplitudes of peaks. For the assessment of the proposed stationary detection method, GNSS observations were removed to simulate outages during the three stop periods, and the proposed detection method was conducted together with the ZVU. The results showed that the proposed method achieved a 99.7% correct detection rate, and the divergence of the positioning error constrained via the ZVU was within 2 cm for the experimental stop periods, which indicates the effectiveness of the proposed method. Full article

This article describes the solution of two problems. First, based on the fractional diffusion equation, a boundary problem with arbitrary values of derivative indicators was formulated and solved, describing more general cases than existing solutions. Secondly, from the consideration of the probability schemes of transitions between states of the process, which can be observed in complex systems, a fractional-differential equation of the telegraph type with multiples is obtained (in time: β, 2β, 3β, … and state: α, 2α, 3α, …) using orders of fractional derivatives and its analytical solution for one particular boundary problem is considered. In solving edge problems, the Fourier method was used. This makes it possible to represent the solution in the form of a nested time series (one in time t, the second in state x), each of which is a function of the Mittag-Leffler type. The eigenvalues of the Mittag-Leffler function for describing states can be found using boundary conditions and the Fourier coefficient based on the initial condition and orthogonality conditions of the eigenfunctions. An analysis of the characteristics of time series of changes in the emotional color of users’ comments on published news in online mass media and the electoral campaigns of the US presidential elections showed that for the mathematical expectation of amplitudes of deviations of series levels from the size of the amplitude calculation interval (“sliding window”), a root dependence of fractional degree was observed; for dispersion, a power law with a fractional index greater than 1.5 was observed; and the behavior of the excess showed the presence of so-called “heavy tails”. The obtained results indicate that time series have unsteady non-locality, both in time and state. This provides the rationale for using differential equations with partial fractional derivatives to describe time series dynamics. Full article

The aim of this paper is to mine the information contained in the bridge health monitoring data as well as to improve the shortcomings of traditional identification methods. In this paper, a bridge damage identification method based on the combination of data mining and deep neural networks is introduced. Firstly, a noise reduction method based on parameter optimisation of wavelet threshold decomposition is proposed, which further removes the noise signal by introducing two adjustment parameters in the threshold function to adapt to different wavelet decomposition layers. Furthermore, the Fast Fourier Transform is used to analyse the feature pattern of the original signal in the frequency domain, and the modal frequency features that exhibit the difference in damage categories are extracted from the spectrogram through sliding windows. Finally, a large number of irrelevant variables with small weight contributions are discarded by principal component analysis, and only the sensitive features with the most informative categories are retained as the input to the deep neural networks. The experimental results show that the new metrics after the feature engineering process improve the ability of damage identification and have stronger robustness, while our damage identification scheme achieves a good balance between the model computation and recognition accuracy. Furthermore, the recognition accuracy of the deep neural networks reaches over 93% with only three feature dimensions retained. Full article

The hardware-accelerated time–frequency distribution calculation is one of the commonly used methods to analyze and present the information from intercepted radio frequency signals in modern ultra-wideband digital receiver (DRX) designs. In this paper, we introduce the piecewise constant window blocking FFT (PCW-BFFT) method. The purpose of this work is to show the generation of spectrograms (formed by a number of spectrum lines) using a very large number of samples (N) in an FFT frame for each spectrum line calculation. In the PCW-BFFT, the N samples are grouped into K consecutive time slots, and each slot has M number of samples. As soon as the M samples in the current time slot are available from a high-speed analog-to-digital convertor (ADC), the frequency information will be obtained using K M-point FFTs. Since each time the FFT frame hops one time slot for the next spectrum line calculation, the frequency information obtained from a time slot will be reused in many spectrum line calculations, as long as these spectrum lines share those samples in the time slot. Although the use of the time domain PCW introduces spikes in the frequency spectrum of the window, the levels of those spikes are still much lower than the first side lobe level of a rectangular window. Using a Gaussian window as an example, the highest spike level can be lower than the main lobe level by at least 38 dB. The PCW-BFFT method allows a DRX to produce multiple spectrograms concurrently with different analysis window widths when the time domain samples become available continuously from the ADC. This paper presents the detailed derivation process of the PCW-BFFT method and demonstrates the use of the method with simulation results. The hardware implementation process will be reported in another paper. The computer simulation results show that long signals with slowly changing frequencies over time can be depicted on the spectrograms with wide analysis windows, and short pulses and signals with rapidly changing instantaneous frequencies can be captured in the narrow analysis window spectrograms. Full article

Compared with microwave synthetic aperture radar (SAR), terahertz SAR (THz-SAR) is easier to achieve ultrahigh-resolution image due to its higher frequency and shorter wavelength. However, higher carrier frequency makes THz-SAR image quality very sensitive to high-frequency vibration error of motion platform. Therefore, this paper proposes a novel high-frequency vibration error estimation and compensation algorithm for THz-SAR imaging based on local fractional Fourier transform (LFrFT). Firstly, the high-frequency vibration error of the motion platform is modeled as a simple harmonic motion and THz-SAR echo signal received in each range pixel can be considered as a sinusoidal frequency modulation (SFM) signal. A novel algorithm for the parameter estimation of the SFM signal based on LFrFT is proposed. The instantaneous chirp rate of the SFM signal is estimated by determining the matched order of LFrFT in a sliding small-time window and the vibration acceleration is obtained. Hence, the vibration frequency can be estimated by the spectrum analysis of estimated vibration acceleration. With the estimated vibration acceleration and vibration frequency, the SFM signal is reconstructed. Then, the corresponding THz-SAR imaging algorithm is proposed to estimate and compensate the phase error caused by the high-frequency vibration error of the motion platform and realize high-frequency vibration error estimation and compensation for THz-SAR imaging. Finally, the effectiveness of the novel algorithm proposed in this paper is demonstrated by simulation results. Full article

Automatic ship detection by Unmanned Airborne Vehicles (UAVs) and satellites is one of the fundamental challenges in maritime research due to the variable appearances of ships and complex sea backgrounds. To address this issue, in this paper, a novel multi-level ship detection algorithm is proposed to detect various types of offshore ships more precisely and quickly under all possible imaging variations. Our object detection system consists of two phases. First, in the category-independent region proposal phase, the steerable pyramid for multi-scale analysis is performed to generate a set of saliency maps in which the candidate region pixels are assigned to high salient values. Then, the set of saliency maps is used for constructing the graph-based segmentation, which can produce more accurate candidate regions compared with the threshold segmentation. More importantly, the proposed algorithm can produce a rather smaller set of candidates in comparison with the classical sliding window object detection paradigm or the other region proposal algorithms. Second, in the target identification phase, a rotation-invariant descriptor, which combines the histogram of oriented gradients (HOG) cells and the Fourier basis together, is investigated to distinguish between ships and non-ships. Meanwhile, the main direction of the ship can also be estimated in this phase. The overall algorithm can account for large variations in scale and rotation. Experiments on optical remote sensing (ORS) images demonstrate the effectiveness and robustness of our detection system. Full article

This study demonstrates the feasibility of using a seat sensor designed for occupant classification from a production passenger vehicle to measure an occupant’s respiration rate (RR) and heart rate (HR) in a laboratory setting. Relaying occupant vital signs after a crash could improve emergency response by adding a direct measure of the occupant state to an Advanced Automatic Collision Notification (AACN) system. Data was collected from eleven participants with body weights ranging from 42 to 91 kg using a Ford Mustang passenger seat and seat sensor. Using a ballistocardiography (BCG) approach, the data was processed by time domain filtering and frequency domain analysis using the fast Fourier transform to yield RR and HR in a 1-min sliding window. Resting rates over the 30-min data collection and continuous RR and HR signals were compared to laboratory physiological instruments using the Bland-Altman approach. Differences between the seat sensor and reference sensor were within 5 breaths per minute for resting RR and within 15 beats per minute for resting HR. The time series comparisons for RR and HR were promising with the frequency analysis technique outperforming the peak detection technique. However, future work is necessary for more accurate and reliable real-time monitoring of RR and HR outside the laboratory setting. Full article

Applications involving data acquisition from sensors need samples at a preset frequency rate, the filtering out of noise and/or analysis of certain frequency components. We propose a novel software architecture based on open-software hardware platforms which allows programmers to create data streams from input channels and easily implement filters and frequency analysis objects. The performances of the different classes given in the size of memory allocated and execution time (number of clock cycles) were analyzed in the low-cost platform Arduino Genuino. In addition, 11 people took part in an experiment in which they had to implement several exercises and complete a usability test. Sampling rates under 250 Hz (typical for many biomedical applications) makes it feasible to implement filters, sliding windows and Fourier analysis, operating in real time. Participants rated software usability at 70.2 out of 100 and the ease of use when implementing several signal processing applications was rated at just over 4.4 out of 5. Participants showed their intention of using this software because it was percieved as useful and very easy to use. The performances of the library showed that it may be appropriate for implementing small biomedical real-time applications or for human movement monitoring, even in a simple open-source hardware device like Arduino Genuino. The general perception about this library is that it is easy to use and intuitive. Full article

Commutation failure is a common fault for line-commutated converters in the inverter. To reduce the possibility of commutation failure, many prediction algorithms based on alternating current (AC) voltage detection have already been implemented in high voltage direct current (HVDC) control and protection systems. Nevertheless, there are currently no effective methods to prevent commutation failure due to transformer excitation surge current. In this paper, an improved commutation failure prediction algorithm based on the harmonic characteristics of the converter bus voltage during transformer charging is proposed. Meanwhile, a sliding-window iterative algorithm of discrete Fourier transformation (DFT) is developed for detecting the voltage harmonic in real time. This method is proved to be an effective solution, which prevents commutation failure in cases of excitation surge current, through experimental analysis. This method is already implemented into TianShan-ZhongZhou (TianZhong) ± 800 kV ultra high voltage direct current (UHVDC) system. Full article
