Impellers are critical components in industrial applications, requiring smooth surfaces and precise dimensions. Traditional investment casting methods are often time-consuming and costly. Fused filament fabrication (FFF), an additive manufacturing (AM) technology, offers a faster, more cost-effective alternative. FFF produces 3D-printed sacrificial patterns directly from a CAD file, making it ideal for low-volume and complex patterns. Unlike wax patterns, which can shrink or distort, 3D-printed patterns offer precise tolerances and allow for thin-walled geometries. FFF also eliminates the need for tooling, reducing capital investment. However, achieving the desired surface finish and accuracy remains a challenge. In this study, a semi-open, single-shrouded centrifugal pump impeller was fabricated using FFF with acrylonitrile butadiene styrene (ABS). A Taguchi L9 (3³) design of experiments was employed to investigate the influence of layer thickness (0.08–0.24 mm), extrusion temperature (260–280 °C), and infill density (30–70%) on dimensional accuracy and surface roughness. Dimensional deviations were evaluated for critical features, including outer diameter (OD), inner diameter (ID), blade thickness (BT), shroud thickness (ST), and blade height (BH). Results show that small and thin features (BT, ST, BH) exhibited deviations with standard deviations below 0.08 mm, whereas OD was the most affected feature with a maximum standard deviation of 0.362 mm due to dominant shrinkage effects. The optimal parameter combination for minimum dimensional deviation was identified as 0.08 mm layer thickness, 280 °C extrusion temperature, and 70% infill density. Surface roughness analysis revealed that layer thickness was the most significant factor, with Ra values ranging from 4 to 7 µm, which falls within acceptable limits for investment casting. Surfaces parallel to the XY plane demonstrated superior surface quality compared with XZ/YZ planes, highlighting the feasibility of FFF-printed ABS patterns for investment casting of complex impellers. Full article

In firefighting operations, the efficiency of centrifugal fire pumps is crucial for effective fire suppression. Designs aiming for lower shaft power enhance not only the pump’s energy efficiency and reliability but also lead to a reduction in size and weight. This research targets a single-stage centrifugal fire pump with a specific speed of 44.5, employing numerical simulations alongside orthogonal experiments to primarily focus on reducing shaft power. Based on a prototype, an L₁₆(4⁴) orthogonal experiment was conducted on four critical parameters: blade outlet angle, wrap angle, outlet width, and blade count. The study analyzed the impact of these parameters on pump performance, clarifying their influence on the hydraulic performance and proposing an optimal power-efficiency scheme. The optimized design successfully reduced the motor power from 18.5 kW to 15 kW, improved the impeller’s internal flow, minimized flow losses, and effectively managed the hump phenomenon. Operating at 1.5 Q_n, the optimized pump’s power decreased by 2.67 kW, meeting head requirements while boosting efficiency, reducing resonance frequency, and lowering the pressure amplitude at the tongue. The optimized pump’s blade frequency distribution was more regular than the original, with the first-order mode’s average deformation decreasing from 3.6 mm to 3.3 mm, and average entropy production at rated flow dropping from 424.118 [W·m⁻³·K⁻¹] to 384.957 [W·m⁻³·K⁻¹]. These outcomes offer theoretical insights and practical guidance for designing low-shaft-power single-stage centrifugal fire pumps, significantly impacting energy efficiency and operational costs. Full article

This study investigates the transient behavior of a single-blade centrifugal pump under variable frequency speed regulation, with the objective of enhancing both pump efficiency and operational stability under variable frequency conditions. By integrating numerical simulations, external characteristic tests, and Particle Image Velocimetry (PIV) flow field experiments, the research provides a comprehensive analysis of the dynamic performance of the pump. The accuracy of the numerical simulations is first validated through a comparison between CFD results and experimental data, both at rated and variable speeds. This study then explores the transient external performance, internal flow patterns, and radial force characteristics of the pump under various speed-change schemes. In the process of acceleration, the variation trend of the centrifugal pump head and speed is basically the same, and Scheme 3 shows better stability; Scheme 2 minimizes the fluctuation of shaft power; with the increase in speed, the pressure and flow field in the pump will appear to be unstable. In the deceleration process, the Scheme 3 head fluctuates less, the change in shaft power is the most stable, and the more uniform pressure distribution and stable flow field can be maintained. The radial force increases with the increase in speed, but the degree of radial force fluctuation is different among different schemes. These findings offer valuable insights into the dynamic performance of centrifugal pumps under variable speed conditions and provide a foundation for optimizing both pump design and operational strategies. Full article

The characteristics of pressure pulsations in centrifugal pumps have attracted considerable attention. In this study, principal component analysis is used to discuss the pressure pulsations in a centrifugal pump with a low specific speed, and the primary causes for these pressure pulsations are analyzed in conjunction with experimental results. The results indicate that principal component analysis effectively separates the primary modes that influence the flow field characteristics. An excessive wrap angle results in the formation of a backflow vortex on the working face of the blade. Obvious stratification of the zero-order modal pressure indicates that the geometric structure of the impeller is rational and that the transient flow field is stable. The second- and third-order modes are conjugates, and their dominant frequency coincides with the dominant rotating frequency of the impeller, indicating that the pulsations of a single channel are the primary component of the pressure pulsations. The primary frequency (148.54 Hz) of the pressure pulsations at monitoring points distributed across the volute is three times the rotational frequency (49.51 Hz) of the impeller. The different positions and sub-frequencies of the monitoring points mean that the principal component analysis can effectively identify the impeller-induced sub-frequency difference. Full article

Solid–liquid two-phase centrifugal pumps are important fluid transport components in production and life. Most of the studies about the influence of solid-phase parameters on fluid transport mostly focus on single-component solid particles. In this work, two kinds of glass beads with particle sizes of 2 mm and 0.4 mm were used to study the effect of the binary mixed particle volume concentration on the internal flow and wear characteristics of a centrifugal pump. The flow distribution of the binary mixed particles in a centrifugal pump and the interactions between the particles and flow components at different volume concentrations (C_v = 5%, C_v = 7.5%, C_v = 10%, C_v = 12.5%, C_v = 15%) were studied using a Computational Fluid Dynamics-Discrete Element Method (CFD-DEM). The research results show that with the increase in particle volume concentration, the head and efficiency of the pump decrease. Additionally, the distributions of the particles with different concentrations in the impeller flow passage were obtained. Moreover, the coupling force of the flow field acting on the particles decreases with the increase in particle concentration and the time it takes to convey small particles decreases with the increase in concentration, while that of large particles decreases first and then increases. Furthermore, the contact force between the particles and the blade changes periodically with time, and the wear of the centrifugal pump is mainly concentrated on the pressure surface of the blade and the wall of the volute outlet side; the wear rate increases as the particle concentration increases. Full article

The acoustic properties of a single-stage centrifugal pump with low specific speed are investigated by means of compressible 3D CFD simulations (URANS) and experiments. In order to determine the pump’s acoustic transmission and excitation characteristics, a four-pole approach in the frequency domain is used. The transmission parameters determined by simulation are compared to experiments in water and air as functions of the Helmholtz number. The results indicate that the acoustic transmission characteristics within the experiments are significantly influenced by the structural compliance of the volute casing in terms of a fluid–structure interaction (FSI). A modelling approach for a one-dimensional representation of the centrifugal pump’s acoustic transmission characteristics in the time and frequency domains is applied to the current pump. As one model parameter, the effective speed of sound in the 1D model needs to be reduced to 607 $\mathrm{m}{\mathrm{s}}^{-1}$ to account for the FSI. The agreement of the simulation results and the experiments underlines the above statement about the influence of the FSI. In a last step, the acoustic excitation parameter, depicted as monopole and dipole amplitudes, at two different blade-passing frequencies ($f_{BP}\approx [111;169]$ Hz) are determined for several operating points. Especially for dipole amplitudes, a good agreement between experiments and simulations can be seen. The monopole amplitudes are also of similar orders of magnitude, but show stronger deviations. The cause of discrepancies between the 3D CFD simulations and experiments is believed to be the neglected influence of the FSI and surface roughness as well as the inaccurate reproduction of flow separation at the volute’s tongue due to the use of wall functions. A final important observation made during the numerical investigations is that the excitation mechanisms at the blade-passing frequency are probably independent of the piping system’s acoustic impedance. Full article

Vertical centrifugal pumps play a crucial role in numerous water conservancy projects. However, their continuous operation can lead to the development of cracks or even fractures in some centrifugal pump blades, resulting in a substantial adverse impact on the operation of the pumping station unit and jeopardizing safe production. This study employs the fluid-structure interaction method to comprehensively investigate the modal characteristics of the impeller, both in an air environment and immersed in water. Furthermore, the analysis of static and dynamic stress attributes is conducted. The natural frequency of the impeller when submerged in water is significantly lower than its frequency in an air medium, typically accounting for approximately 0.35 to 0.46 of the air-based natural frequency. There are conspicuous stress concentrations at specific locations within the system, specifically at the rounded corners of the blade back exit edge, the impeller front cover, the middle of the blade inlet edge, and the junction where the blade interfaces with the front and back cover. It is crucial to underscore that when the system operates under high-flow or low-flow conditions, there is a pronounced stress concentration at the interface between the impeller and the rear cover plate. Any deviation from the intended design conditions results in an escalation of equivalent stress levels. Through dynamic stress calculations during a single rotational cycle of the impeller, it is discerned that the cyclic nature of stress at the point of maximum stress is primarily influenced by the number of blades and the rotational velocity of impeller. This research carries significant implications for effectively mitigating blade fractures and cyclic fatigue damage, thereby enhancing the operational reliability of vertical centrifugal pumps in water conservancy applications. Full article

The precise identification of faults in centrifugal pumps is crucial for ensuring their safe and stable operation, given their significance as vital industrial equipment. This article aims to rigorously examine and analyze the flow characteristics of centrifugal pumps under two specific conditions: normal blade operation and a single blade breakage fault. Through systematic comparison and in-depth study, this article sheds light on distinguishing flow patterns exhibited by these pumps under both normal and fault scenarios. Utilizing validated numerical simulation methods, a thorough analysis is conducted to explore the flow condition and energy characteristics of the impeller channel following the breakage of a single blade. Additionally, the article investigates changes in the pressure pulsation characteristics of the pump volute as a result. The numerical simulation results reveal that the head of the centrifugal pump decreases at all flow points when a single blade breaks. However, there is no significant change in efficiency at small flow points. As the flow rate exceeds 0.9Q_d, efficiency experiences a substantial decrease. Furthermore, the efficiency decline becomes even more pronounced as the flow rate continues to increase. At 1.5Q_d, efficiency plummets by 14.33%. The flow pattern undergoes significant changes as well. The breakage of the blade induces noteworthy secondary flow in adjacent impeller channels, resulting in heightened turbulence dissipation. Additionally, it was observed that blade fracture causes alterations in the main frequency of pressure pulsation within the volute. This is characterized by an increase in shaft passing frequency and a decrease in blade passing frequency. Notably, near the tongue monitoring point, the shaft frequency escalates by over 20 times. Full article

Double-entry two-stage double-suction centrifugal pumps with high flow rates and high heads are used in some large water supply applications. The pressure fluctuation of the impeller is a key factor influencing the vibration in centrifugal pumps. In this paper, the pump is simulated and verified by experiments, and the pressure fluctuation distribution of two stage impellers is obtained. The study on the time domain and frequency domain of the two-stage impellers demonstrates that the pressure fluctuation of the first-stage single-suction impeller is affected by the twin volute. At 1.0 Q, the dominant frequency on the blade suction side and pressure side is twice the rotation frequency. The main frequency of pressure fluctuations at the outlet side of the blade at a low flow rate is higher than that at the design flow rate. Pressure fluctuations in the second-stage impeller are influenced by the inter-stage passage. The dominant frequency amplitudes grow incrementally along the streamlined direction. In the second-stage double-suction impeller, the dominant frequency amplitude at 0.6 Q is approximately twice that of 1.0 Q. Research in this paper can guide the design and operation of a two-stage pump. Full article

In order to improve the operation performance of the multi-stage double-suction centrifugal pump and reduce the internal energy loss of the pump, this paper proposes a single-objective optimization design method based on the non-hierarchical response surface methodology (RSM) and the multi-island genetic algorithm (MIGA). Nine parameters, such as the blade outlet width and blade wrap angle, were used as design variables, and the optimization objective was efficiency under design conditions. In total, 149 sets of valid data were obtained under the Latin hypercube sampling method (LHS), the corresponding thresholds were set for efficiency and head, and 99 sets of valid data were obtained. A cross-validation analysis of the sieved data was carried out based on non-hierarchical RSM, global optimization of the efficiency was carried out using MIGA, and numerical verification was carried out via CFD. The research results show that compared with hierarchical RSM, non-hierarchical RSM can approximate the nonlinear relationship between the objective function and the design variables with higher accuracy, and the model fitting R² value was 0.919. The efficiency was improved by 3.717% after optimization. The overall prewhirl of the impeller inlet after optimization decreased, the internal speed of the volute significantly improved, the large-area vortex at the volute and the outlet pipe was eliminated, the impact loss at the volute separating tongue disappeared, and the overall hydraulic performance of the pump was improved. The total entropy output value of the optimized pump was reduced by 4.79 (W/K), mainly concentrated on the reduction in the entropy output value of the double volute, and the overall energy dissipation of the pump was reduced. Full article

To estimate the influence of the rotation center eccentricity of the single-blade centrifugal pump impeller on the radial force on it, and to explore the effective radial force balance method, a single blade pump with a power of 2.2 kW is analyzed. The accuracy of Numerical Simulation Methods are verified by tests of external characteristics (under three rotation-speeds of 1470 r/min, 2000 r/min, and 2940 r/min) and pressure distributions. There are five models with different rotation center coordinates (model a with (0,1), model b with (−1,0), model c with (0,−1), model d with (1,0), and model e with (0,0.5)) which are analyzed. The results show that the radial force of model c and model d reduced by 8.1% and 9.8%, respectively, which means the offset of the center of the impeller to the positive direction of the x-axis and the negative direction of the y-axis can effectively reduce the radial force. At the eccentricity of the impeller (2,−2), the radial force under all operating conditions is reduced, most obviously at 1.0 Q_d, which is about 17%. The study may prove helpful to designers and pump manufacturers to find a path forward for an optimal eccentricity to minimize the radial force. Full article

Safety and reliable operation is one of the most important research areas for centrifugal pump systems, due to the interaction of complex flow, large structural load, and vibration caused by the operation of the impeller. To analyze the internal flow and impeller deformation of the centrifugal pump, the single-stage single-suction centrifugal pump titled IS100-80-160 was selected as the research object. Under the principle of single variable, the turbulent flow and structural response of three impellers designed by different parameters were calculated by CFX and ANSYS Workbench. A numerical simulation of steady flow at different flow rates of the centrifugal pump was carried out, and its hydraulic performance is consistent with the corresponding experimental results. By comparing the deformation of the impeller rotor system, it was found that the closed impeller has the worst stability with the best hydraulic performance; the impeller with split blades has the worst stability with the best hydraulic performance. This study could enhance the understanding of impeller FSI on centrifugal pump stability and provide a reference for improving the operational stability of centrifugal pumps. Full article

Centrifugal pumps are the critical components in deep-sea mining. In order to investigate the particle motion in the curved channel of the impeller, three different types of curvature conform to blade profile to simplify the impeller design of pumps. A numerical study is conducted to investigate the flow field in a varying-curvature channel for solid-liquid two-phase flow. The flow of particles within the varying curvature channel is studied by combining the discrete element method (DEM) with computational fluid dynamics (CFD) and a comparison with Particle Image Velocimetry (PIV) test results. The results show that a polyhedral mesh with a small mesh number yields very accurate results, which makes it very suitable for CFD-DEM. Based on this method, the movement of a single particle is compared and analyzed, and the particle-motion law is obtained. The effects of the curvature ratio Cr and area ratio Ar on the motion law for a single particle are studied, and the simulation results are analyzed statistically. The results show that the effect of Cr on both the particle slip velocity and the turbulent kinetic energy only changes its strength, while the distribution law does not change significantly. Compared with the curvature ratio Cr, the area ratio Ar has a greater impact on the particles, and its distribution law becomes clearly different. As the area ratio Ar increases, the arc radius and length of the corresponding particle trajectory decrease. Full article

Vortex pumps have good non-clogging performance owing to their impellers being retracted into retraction cavities, but they are much less efficient than ordinary centrifugal pumps. In this paper, numerical simulations were performed on a model of the 150WX200-20 vortex pump for four different blade types, and the influence of blade structure on pump performance was determined. The simulations revealed the existence of axial vortices in the flow passage between the blades in the impeller region. The geometric characteristics of these axial vortices were more regular in two-phase solid-liquid flow than single-phase liquid flow. The presence of the solid phase reduced the vortex strength compared with the single-phase flow and suppressed the increase in size of the secondary circulation vortex. It was found, however, that the blade shape had a greater influence on the circulating flow than the presence of the solid phase. The flow state of the medium flowing out of the impeller domain had a direct effect on the circulating flow with this effect being related to the law governing the flow of the medium in the flow channel between the blades. It was found that the performance of a front-bent blade was the best and that of a curved blade the worst. This influence of blade type on the internal flow structure was used to further explain the relationship between the internal flow structure and the external characteristics of the vortex pump, the understanding of which is crucial for blade selection and hydraulic optimization. Full article

To investigate the effect of blade wrap angle on the hydrodynamic radial force of a single blade centrifugal pump, numerical simulation is conducted on the pumps with different blade wrap angles. The effect of the wrap angle on the external characteristics and the radial force of a single blade centrifugal pump was analyzed according to the simulation result. It is found that, with the increase of the blade wrap angle, the head and efficiency of the single blade centrifugal pump are improved, the H-Q curve becomes steeper, and the efficiency also increased gradually, while the high-efficiency area is narrowed. The blade wrap angle has a great effect on the radial force of the single blade centrifugal pump. When the blade wrap angle is less than 360°, the horizontal component of the radial force is negative and the value is reduced with the increase of the wrap angle of the blade. When the wrap angle is larger than 360°, the horizontal component of the radial force is positive and the value increases with the increase of the wrap angle. Under part-loading conditions, the radial force of the single blade pump is significantly reduced with the increase of the blade wrap angle. When the wrap angle is smaller than 360°, the radial force decreases with the flow rate increase. In the condition that the wrap angle is larger than 360°, the radial force increases with the flow rate increase. Full article
