This study investigates the propagation of shear horizontal transverse waves in a functionally graded piezoelectric half-space (FGPHS), where the material properties vary linearly and quadratically. The analysis focuses on deriving and understanding the dispersion characteristics of such waves in in-homogeneous media. The WKB approximation method is employed to obtain the dispersion relation analytically, considering the smooth variation of material properties. To validate and study the wave behavior numerically, two advanced techniques were utilized: the Semi-Analytical Finite Element with Perfectly Matched Layer (SAFE-PML) and the Semi-Analytical Infinite Element (SAIFE) method incorporating a (1/r) decay model to simulate infinite media. The numerical implementation uses the Rayleigh–Ritz method to discretize the wave equation, and Gauss 3-point quadrature is applied for efficient numerical integration. The dispersion curves are plotted to illustrate the wave behavior in the graded piezoelectric medium. The results from SAFE-PML and SAIFE are in excellent agreement, indicating that these techniques effectively model the shear horizontal transverse wave propagation in such structures. This study also demonstrates that combining finite and infinite element approaches provides accurate and reliable simulation of wave phenomena in functionally graded piezoelectric materials, which has applications in sensors, actuators, and non-destructive testing. Full article

This study presents a high-order shear deformation theory (HSDT)-based model for evaluating the energy harvesting performance of functionally graded material (FGM) beams integrated with a piezoelectric layer and subjected to a moving concentrated load at constant velocity. The governing equations are derived using Hamilton’s principle, and the dynamic response is obtained through the State Function Method with trigonometric mode shapes. The output voltage and harvested power are calculated based on piezoelectric constitutive relations. A comparative analysis with homogeneous isotropic beams demonstrates that HSDT yields more accurate predictions than the Classical Beam Theory (CBT), especially for thick beams; for instance, at a span-to-thickness ratio of h/L = 12.5, HSDT predicts increases of approximately 6%, 7%, and 12% in displacement, voltage, and harvested power, respectively, compared to CBT. Parametric studies further reveal that increasing the load velocity significantly enhances the strain rate in the piezoelectric layer, resulting in higher voltage and power output, with the latter exhibiting quadratic growth. Moreover, increasing the material gradation index n reduces the beam’s effective stiffness, which amplifies vibration amplitudes and improves energy conversion efficiency. These findings underscore the importance of incorporating shear deformation and material gradation effects in the design and optimization of piezoelectric energy harvesting systems using FGM beams subjected to dynamic loading. Full article

This study presents a closed-form solution for the dynamic response of a sandwich beam subjected to arbitrary impact loading, with a particular focus on energy harvesting from an attached piezoelectric layer. A thin piezoelectric patch is bonded to the bottom surface of the beam to convert mechanical vibrations into electrical energy. The governing equations of motion are derived using Hamilton’s principle, considering a non-symmetric sandwich cross-section and incorporating higher-order shear deformation effects. The state–space method is employed to obtain the exact dynamic response of the beam under impact excitation. The differential equations governing the output voltage and harvested power are solved analytically based on the derived response. The natural frequencies and dynamic responses are validated against classical beam theory, highlighting the significance of shear deformation. Numerical examples are provided to evaluate the generated voltage and energy harvesting efficiency. The results demonstrate the strong potential for energy harvesting from sandwich beam vibrations and elucidate the influence of impact loading conditions, distributed load amplitude, and the geometric dimensions of the beam on the harvested output. Full article

A variational formulation and variationally consistent boundary conditions were derived for a coupled system of two boron nitride nanotubes (BNNTs), with the piezoelectric and surface effects taken into account in the formulation. The coupling between the nanotubes was defined in terms of Winkler and Pasternak interlayers. The equations governing the vibrations of the coupled system were expressed as a system of four partial differential equations based on nonlocal elastic theory. After deriving the variational principle for the double BNNT system, Hamilton’s principle was expressed in terms of potential and kinetic energies. Next, the differential equations for the free vibration case were presented and the variational form for this case was derived. The Rayleigh quotient was formulated for the vibration frequency, which indicated that piezoelectric and surface effects led to higher vibration frequencies. Next, the variationally consistent boundary conditions were formulated in terms of moment and shear force expressions. It was observed that the presence of the Pasternak interlayer between the nanotubes led to coupled boundary conditions when a shear force and/or a moment was specified at the boundaries. Full article

To address the challenge of imprecise micro-droplet formation control in piezoelectric jetting devices used in sand mold 3D printing and apply on-demand inkjet printing technology to sand mold manufacturing, this study first explains the working principle of a piezoelectric shear-mode printhead. A mathematical model of the droplet ejection process is then established based on Computational Fluid Dynamics (CFD). Building upon this model, numerical simulations of droplet generation, breakup, and flight are conducted by using the Volume of Fluid (VOF) model within the Fluent module of the Workbench 2020 R2 platform. Finally, under consistent driving conditions, the effects of key parameters—viscosity, surface tension, and inlet velocity—on the ejection process are investigated through simulation. Based on the results, appropriate ranges and recommended values for ink properties are determined. This study provides significant engineering value for improving the stability and precision of droplet formation in industrial sand mold 3D printing. Full article

This work develops a unified size-dependent shear deformation theory (SDSDT) to analyze the free vibration behavior of a functionally graded (FG) magneto-electro-elastic (MEE) microplate under fully simply supported conditions, open- or closed-circuit surface conditions, biaxial compression, magnetic and electric potentials, and uniform temperature changes based on consistent couple stress theory (CCST). The FG-MEE microplate is composed of BaTiO₃ (a piezoelectric material) and CoFe₂O₄ (a magnetostrictive material). Various CCST-based SDSDTs, considering couple stress and thickness stretching effects, can be reproduced by employing a generalized shape function that characterizes shear deformation distributions along the thickness direction within the unified SDSDT. These CCST-based SDSDTs encompass the size-dependent classical plate theory (CPT), first-order shear deformation theory (SDT), Reddy’s refined SDT, exponential SDT, sinusoidal SDT, and hyperbolic SDT. The unified SDSDT is validated by comparing its solutions with relevant three-dimensional solutions available in the literature. After validation and comparison studies, we conduct a parametric study, whose results indicate that the effects of thickness stretching, material length-scale parameter, inhomogeneity index, and length-to-thickness ratio, as well as the magnitude of biaxial compressive forces, electric potential, magnetic potential, and uniform temperature changes significantly impact the microplate’s natural frequency. Full article

In this work, lead-free (Na_0.475K_0.475Li_0.05)NbO₃ + x wt.% ZnO (NKLN, x = 0 to 0.3) piezoelectric ceramics with high piezoelectric g-coefficients were prepared by conventional solid-state synthesis method. By adding different concentrations of ZnO dopants, we aimed to improve the material properties and enhance their piezoelectric properties. The effects of the ZnO addition on the microstructure, dielectric, piezoelectric and ferroelectric properties of the proposed samples are investigated. Adding ZnO reduced the dielectric constant and improved the g-value of the samples. The properties of the samples without ZnO doping were g₃₃ = 31 mV·m/N, g₁₅ = 34 mV·m/N, k_p = 0.39, Q_m = 92, ε_r = 458, d₃₃ = 127 pC/N and dielectric loss = 3.4%. With the preferable ZnO doping of 1 wt.%, the piezoelectric properties improved to g₃₃ = 40 mV·m/N, g₁₅ = 44 mV·m/N, k_p = 0.44, Q_m = 89, ε_r = 406, d₃₃ = 139 pC/N and dielectric loss = 2.4%. Finally, ring-shaped shear mode piezoelectric accelerometers were fabricated using the optimum ZnO-doped samples. The simulated resonant frequency using ANSYS 2024 R1 software was approximately 23 kHz, while the actual measured resonant frequency of the devices was 19 kHz. The sensitivity was approximately 7.08 mV/g. This piezoelectric accelerometer suits applications requiring lower sensitivity and higher resonant frequencies, such as monitoring high-frequency vibrations in high-speed machinery, robotic arms or scientific research and engineering fields involving high-frequency vibration testing. Full article

With the development of piezoelectric-on-insulator (POI) substrates, X-cut LiNbO₃ thin-film resonators with interdigital transducers are widely investigated due to their adjustable resonant frequency (f_s) and effective electromechanical coupling coefficient ($K_{eff}^2$). This paper presents an in-depth study of simulations and measurements of laterally excited bulk acoustic wave resonators based on an X-cut LiNbO₃/SiO₂/Si substrate and a LiNbO₃ thin film to analyze the effects of electrode angle rotation ($\theta$) on the modes, f_s, and $K_{eff}^2$. The rotated $\theta$ leads to different electric field directions, causing mode changes, where the resonators without cavities are longitudinal leaky SAWs (LLSAWs, $\theta$ = 0$°$) and zero-order shear horizontal SAWs (SH₀-SAWs, $\theta$ = 90$°$) and the resonators with cavities are zero-order-symmetry (S₀) lateral vibrating resonators (LVRs, $\theta$ = 0$°$) and SH₀ plate wave resonators (PAW, $\theta$ = 90$°$). The resonators are fabricated based on a 400 nm X-cut LiNbO₃ thin-film substrate, and the measured results are consistent with those from the simulation. The fabricated LLSAW and SH₀-SAW without cavities show a $K_{eff}^2$ of 1.62% and 26.6% and a Bode-Q_max of 1309 and 228, respectively. Meanwhile, an S₀ LVR and an SH₀-PAW with cavities present a $K_{eff}^2$ of 4.82% and 27.66% and a Bode-Q_max of 3289 and 289, respectively. In addition, the TCF with a different rotated $\theta$ is also measured and analyzed. This paper systematically analyzes resonators on X-cut LiNbO₃ thin-film substrates and provides potential strategies for multi-band and multi-bandwidth filters. Full article

A new piezoelectric sensor with a triangular shear structure was designed to conduct the deformation monitoring of geotechnical bodies in mining airspace. Firstly, a three-dimensional sensor model was developed to analyze the impact of structural parameters on resonant frequency and voltage, utilizing both finite element and experimental methods. Secondly, the NSGA-II genetic algorithm was employed to optimize the sensor’s structural parameters, focusing on resonant frequency and voltage, resulting in a Pareto optimal solution set. For the first time, the optimal parameter combination was selected by minimizing the difference method (the height of the mass block was 10.6 mm, the thickness of the piezoelectric plate was 3.29 mm, the height of the piezoelectric plate was 8.1 mm, and the height of the central column was 19 mm). The optimized sensor exhibited a 4.14% increase in resonant frequency and a 9.11% increase in voltage. Finally, the prototype was fabricated, and the effectiveness and feasibility of the design were verified through experiments. The findings indicate the sensor’s promising potential for monitoring geotechnical deformation in mining airspace regions. Full article

An important technical task is to develop methods for recording the phase transitions of water to ice. At present, many sensors based on various types of acoustic waves are suggested for solving this challenge. This paper focuses on the theoretical and experimental study of the effect of water-to-ice phase transition on the properties of Lamb and quasi shear horizontal (QSH) acoustic waves of a higher order propagating in different directions in piezoelectric plates with strong anisotropy. Y-cut LiNbO₃, 128Y-cut LiNbO₃, and 36Y-cut LiTaO₃ plates with a thickness of 500 μm and 350 μm were used as piezoelectric substrates. It was shown that the amplitude of the waves under study can decrease, increase, or remain relatively stable due to the water-to-ice phase transition, depending on the propagation direction and mode order. The greatest decrease in amplitude (42.1 dB) due to glaciation occurred for Lamb waves with a frequency of 40.53 MHz and propagating in the YX+30° LiNbO₃ plate. The smallest change in the amplitude (0.9 dB) due to glaciation was observed for QSH waves at 56.5 MHz propagating in the YX+60° LiNbO₃ plate. Additionally, it was also found that, in the YX+30° LiNbO₃ plate, the water-to-ice transition results in the complete absorption of all acoustic waves within the specified frequency range (10–60 MHz), with the exception of one. The phase velocities, electromechanical coupling coefficients, elastic polarizations, and attenuation of the waves under study were calculated. The structures “air–piezoelectric plate–air”, “air–piezoelectric plate–liquid”, and “air–piezoelectric plate–ice” were considered. The results obtained can be used to develop methods for detecting ice formation and measuring its parameters. Full article

The objective of the present paper is to demonstrate the effects of shear deformation and large deflections on the piezoelectric materials and structures which often serve as substrate layers of multilayer composite sensors and actuators. Based on a displacement-unified high-order shear deformation theory and the von Kármán geometric nonlinearity, a general theory (governing equations and associated boundary conditions) for the analysis of piezoelectric beams is developed using Hamilton’s principle. Nonlinear effects due to the coupling between extensional and bending responses in beams with moderately large rotations but small strains are included. A bending problem for a piezoelectric beam is solved analytically, and the obtained results are compared to the results available in the literature. The numerical results show that both shear deformation effects and von Kármán geometric nonlinearity have a stiffening effect and therefore reduce the displacements. The influence of geometric nonlinearity is more prominent in the case of thin beams, while the effects of shear deformation dominate in the case of thick beams. The proposed unified methodology for the analysis of bending problems is independent of the thickness of the piezoelectric beam. Full article

This paper investigates the nonlinear dynamic deflection, natural frequency, and wave propagation in functionally graded (FG) porous piezoelectric microscale tubes under periodic load, hygrothermal conditions, and an external electric field. The piezoelectric material used to make the smart microtubes has pores that may be smoothly changed or uniformly distributed over the tube wall. Here, three types of porosity distribution are taken into consideration. The nonlinear motion equations are constructed using a novel shear deformation beam theory and the modified couple stress theory (MCST). The nonlinear motion equations are solved using the fourth-order Runge–Kutta technique and the Galerkin approach. The effects of various geometric parameters, porosity distribution type, porosity factor, periodic load amplitude and frequency, material length scale parameter, moisture, and temperature on the nonlinear dynamic deflection, natural frequency, and wave frequency of FG porous piezoelectric microtubes are explored through a number of parametric investigations. Full article

Climate change induces extreme effects with lower-than-designed restoration periods, imposing the necessity of strengthening the structural integrity of existing and mainly older RC structures, which are often demonstrated to be under-reinforced in terms of the shear capacity, mainly due to outdated and old design codes/standards. Thus, finding cost-effective and feasible methods to strengthen RC elements is becoming increasingly important. Thin RC layers for jacketing represent a modern advancement in repairing and retrofitting RC members. In this context, U-shaped mortar jackets were employed to strengthen three shear-critical beams. In addition, a critical aspect in the success of any jacketing method is the degree of bonding and interaction between the original member and the new jacket. Additionally, the performance of these U-shaped jackets was assessed using an Electro-Mechanical-Impedance-based (EMI-based) method using a Piezoelectric-Transducer-enabled (PZT-enabled) technique. The integration of advanced monitoring technologies in retrofitting applications offers valuable insights into the performance and longevity of the retrofit system. Therefore, this study aims to experimentally investigate the cohesion between construction materials and assess the effectiveness of U-shaped jackets. Through the proposed Structural Health Monitoring (SHM) technique, any degradation at the interface or slippage of the retrofitting jacket can be promptly detected, restraining further damage development and potential failure of the structure. Full article

By using piezoelectric materials, it is possible to convert clean and renewable energy sources into electrical energy. In this paper, the effect on the piezoelectro-elastic response of piezoelectric-fiber-reinforced nanocomposites by adding silica nanoparticles into the polyimide matrix is investigated by a micromechanical method. First, the Ji and Mori–Tanaka models are used to calculate the properties of the nanoscale silica-filled polymer. The nanoparticle agglomeration and silica–polymer interphase are considered in the micromechanical modeling. Then, considering the filled polymer as the matrix and the piezoelectric fiber as the reinforcement, the Mori–Tanaka model is used to estimate the elastic and piezoelectric constants of the piezoelectric fibrous nanocomposites. It was found that adding silica nanoparticles into the polymer improves the elastic and piezoelectric properties of the piezoelectric fibrous nanocomposites. When the fiber volume fraction is 60%, the nanocomposite with the 3% silica-filled polyimide exhibits 39%, 31.8%, and 37% improvements in the transverse Young’s modulus $E_T$, transverse shear modulus $G_{TL}$, and piezoelectric coefficient $e_{31}$ in comparison with the composite without nanoparticles. Furthermore, the piezoelectro-elastic properties such as $E_T$, $G_{TL}$, and $e_{31}$ can be improved as the nanoparticle diameter decreases. However, the elastic and piezoelectric constants of the piezoelectric fibrous nanocomposites decrease once the nanoparticles are agglomerated in the polymer matrix. A thick interphase with a high stiffness enhances the nanocomposite’s piezoelectro-elastic performance. Also, the influence of volume fractions of the silica nanoparticles and piezoelectric fibers on the nanocomposite properties is studied. Full article

Laboratory acoustic emissions (AEs) serve as small-scale analogues to earthquakes, offering fundamental insights into seismic processes. To ensure accurate physical interpretations of AEs, rigorous calibration of the acoustic system is essential. In this paper, we present an empirical calibration technique that quantifies sensor response, instrumentation effects, and path characteristics into a single entity termed instrument apparatus response. Using a controlled seismic source with different steel balls, we retrieve the instrument apparatus response in the frequency domain under typical experimental conditions for various piezoelectric sensors (PZTs) arranged to simulate a three-component seismic station. Removing these responses from the raw AE spectra allows us to obtain calibrated AE source spectra, which are then effectively used to constrain the seismic AE source parameters. We apply this calibration method to acoustic emissions (AEs) generated during unstable stick-slip behavior of a quartz gouge in double direct shear experiments. The calibrated AEs range in magnitude from −7.1 to −6.4 and exhibit stress drops between 0.075 MPa and 4.29 MPa, consistent with earthquake scaling relation. This result highlights the strong similarities between AEs generated from frictional gouge experiments and natural earthquakes. Through this acoustic emission calibration, we gain physical insights into the seismic sources of laboratory AEs, enhancing our understanding of seismic rupture processes in fault gouge experiments. Full article
