Monitoring coastal seabed in very shallow waters (0–5 m) is a challenging methodological issue, even though such data is of major importance to many scientific and technical communities. Over the years, Structure-from-Motion (SfM) photogrammetry has emerged as a flexible and inexpensive method able to provide both a 3D model and high-resolution imagery of the seabed (~cm level). In this study, we propose a low-cost (about USD 1500), adaptable, lightweight and easily dismantled system called POSEIDON (for Platform Operating in Shallow-water Environment for Imaging and 3D reconstructiON). This prototype combines a floating support (typically a bodyboard), two imagery sensors (here, GoPro^® cameras) and an accurate positioning system using Real Time Kinematic GNSS. Validation of this method was deployed in a macrotidal zone, comparing on the foreshore the point cloud provided by POSEIDON “SfM bathymetry” and by classical terrestrial SfM survey. Mean deviation was 5.2 cm and standard deviation was 4.6 cm. Such high-resolution SfM bathymetric surveys have a great potential for a wide range of applications: micro-bathymetry, hydrodynamics (bottom roughness), benthic habitats, ecological inventories, archaeology, etc. Full article

Wave overtopping is a critical parameter in the design of coastal defense structures. Nowadays, several empirical formulations based on small-scale experiments are available in the literature to predict the mean overtopping discharge at dikes on shallow foreshores. Although the accuracy of the predictions has improved due to each approach’s contributions, the formulations’ performance depends on their range of applicability. In engineering applications, it is important to know the performance and limitations of the different formulas. This work presents a new experimental dataset focused on very shallow and extremely shallow foreshore conditions for a range of foreshore slopes (i.e., 1/20, 1/35, 1/50, and 1/80) and relative water depths. The recent developments in wave overtopping research on very shallow and extremely shallow foreshore conditions have been reviewed using this dataset to reflect the existing uncertainties and challenges in the wave-overtopping literature. We find that predicting wave overtopping for extremely shallow foreshore conditions still requires improvement. Additional research is needed to understand the (residual) influence on the wave overtopping of the foreshore slope and relative magnitude of the infragravity wave height to the sea-swell wave height at the dike toe, especially for extremely shallow foreshore conditions. The variation in performance of the formulas for different foreshore slopes is demonstrated. Finally, some of the remaining uncertainties that need further exploration are discussed. Full article

Three open source wave models are applied in 2DV to reproduce a large-scale wave flume experiment of bichromatic wave transformations over a steep-sloped dike with a mildly-sloped and very shallow foreshore: (i) the Reynolds-averaged Navier–Stokes equations solver interFoam of OpenFOAM^® (OF), (ii) the weakly compressible smoothed particle hydrodynamics model DualSPHysics (DSPH) and (iii) the non-hydrostatic nonlinear shallow water equations model SWASH. An inter-model comparison is performed to determine the (standalone) applicability of the three models for this specific case, which requires the simulation of many processes simultaneously, including wave transformations over the foreshore and wave-structure interactions with the dike, promenade and vertical wall. A qualitative comparison is done based on the time series of the measured quantities along the wave flume, and snapshots of bore interactions on the promenade and impacts on the vertical wall. In addition, model performance and pattern statistics are employed to quantify the model differences. The results show that overall, OF provides the highest model skill, but has the highest computational cost. DSPH is shown to have a reduced model performance, but still comparable to OF and for a lower computational cost. Even though SWASH is a much more simplified model than both OF and DSPH, it is shown to provide very similar results: SWASH exhibits an equal capability to estimate the maximum quasi-static horizontal impact force with the highest computational efficiency, but does have an important model performance decrease compared to OF and DSPH for the force impulse. Full article

Due to ongoing climate change, overtopping risk is increasing. In order to have effective countermeasures, it is useful to understand overtopping processes in details. In this study overtopping flow on a dike with gentle and shallow foreshores are investigated using a non-hydrostatic wave-flow model, SWASH (an acronym of Simulating WAves till SHore). The SWASH model in 2DV (i.e., flume like configuration) is first validated using the data of long crested wave cases with second order wave generation in the physical model test conducted. After that it is used to produce overtopping flow in different wave conditions and bathymetries. The results indicated that the overtopping risk is better characterized by the time dependent h (overtopping flow depth) and u (overtopping flow velocity) instead of h_max (maximum overtopping flow depth) and u_max (maximum overtopping flow velocity), which led to overestimation of the risk. The time dependent u and h are strongly influenced by the dike configuration, namely by the promenade width and the existence of a vertical wall on the promenade: the simulation shows that the vertical wall induces seaward velocity on the dike which might be an extra risk during extreme events. Full article

The petrographic composition and grain shape variability of beach gravels in the Pogorzelica–Dziwnów coast section (363.0 to 391.4 km of coastline), southern Baltic Sea, Poland were analyzed herein to characterize the lithodynamics and trends of seashore development. Gravels were sampled at 0.25 km intervals, in the midpart of the berm, following an early-autumn wave storm and before beach nourishment. Individual variations in petrographic groups along the shore were investigated. Gravel data were compared and related to coastal morpholithodynamics, seashore infrastructure, and geology of the study area. The contribution of crystalline rock gravels (igneous and metamorphic) was observed to increase along all coast sections, whereas the amount of less resistant components (limestones, sandstones, and shales) usually declined. This effect is explained by the greater wave crushing resistance of igneous and metamorphic components, compared with sedimentary components. Similarly, the gravel grain shape (mainly elongation or flattening) was observed to change, depending on resistance to mechanical destruction, or due to the increased chemical weathering in mainly the limestones, marbles, and sandstones. Observed increase in contribution of discoid and ellipsoid grains is a potential indicator of depositional trends along the coast sections investigated. On the other hand, increased contents of spheroidal and spindle-shaped grains may be related to erosional trends, where intensive redeposition and mechanical reworking of gravels occurs. However, due to the great number of coastal embankments, the petrographic composition and shape parameters of beach gravels do not always clearly indicate the dominant direction of longshore bedload transport. Increased amount of eroded limestone located east of Pogorzelica indicate increased erosion of glacial tills. These sediments are deposited, building the shallow foreshore, with additional redeposition of morainic material towards the shore. Full article

In this paper, a Reynolds-averaged Navier–Stokes (RANS) equations solver, interFoam of OpenFOAM^®, is validated for wave interactions with a dike, including a promenade and vertical wall, on a shallow foreshore. Such a coastal defence system is comprised of both an impermeable dike and a beach in front of it, forming the shallow foreshore depth at the dike toe. This case necessitates the simulation of several processes simultaneously: wave propagation, wave breaking over the beach slope, and wave interactions with the sea dike, consisting of wave overtopping, bore interactions on the promenade, and bore impacts on the dike-mounted vertical wall at the end of the promenade (storm wall or building). The validation is done using rare large-scale experimental data. Model performance and pattern statistics are employed to quantify the ability of the numerical model to reproduce the experimental data. In the evaluation method, a repeated test is used to estimate the experimental uncertainty. The solver interFoam is shown to generally have a very good model performance rating. A detailed analysis of the complex processes preceding the impacts on the vertical wall proves that a correct reproduction of the horizontal impact force and pressures is highly dependent on the accuracy of reproducing the bore interactions. Full article

The spectral wave period ${\mathrm{T}}_{\mathrm{m}-1,0}$ at the toe of sea-dikes is a crucial parameter to predict wave overtopping discharge over sea-dikes. It is known from literature that this period quickly increases when waves reach shallow foreshores; however, sometimes the assumption is made that the wave period remains constant from offshore to near-shore, leading to an underestimation of the near-shore wave period. Several formulae have been proposed to resolve the underestimation of wave overtopping discharges for very shallow foreshores. These corrective formulations confirm the tendency of underestimating the overtopping discharges over a very gently sloping foreshore but are not validated for foreshore slopes gentler than 1:500. The “equivalent slope” method based on a recent study is inappropriate for these very gently sloping foreshores due to the breaker parameter being much smaller than seven. This study proposes an extension of the correction and finds that spectral wave periods can reach values two times those offshore. Full article

In northern Europe, beach erosion, coastal flooding and associated damages to engineering structures are linked to mid-latitude storms that form through cyclogenesis and post-tropical cyclones, when a tropical cyclone moves north from its tropical origin. The present work analyses the hydrodynamic forcing and morphological changes observed at three beaches in the north coast of Northern Ireland (Magilligan, Portrush West’s southern and northern sectors, and Whiterocks), prior to, during, and immediately after post-tropical cyclone Katia. Katia was the second major hurricane of the active 2011 Atlantic hurricane season and impacted the British Isles on the 12–13 September 2011. During the Katia event, offshore wave buoys recorded values in excess of 5 m at the peak of the storm on the 13 September, but nearshore significant wave height ranged from 1 to 3 m, reflecting relevant wave energy dissipation across an extensive and shallow continental shelf. This was especially so at Magilligan, where widespread refraction and attenuation led to reduced shore-normal energy fluxes and very minor morphological changes. Morphological changes were restricted to upper beach erosion and flattening of the foreshore. Longshore transport was evident at Portrush West, with the northern sector experiencing erosion while the southern sector accreted, inducing a short-term rotational response in this embayment. In Whiterocks, berm erosion contributed to a general beach flattening and this resulted in an overall accretion due to sediment influx from the updrift western areas. Taking into account that the post-tropical cyclone Katia produced £100 m ($157 million, 2011 USD) in damage in the United Kingdom alone, the results of the present study represent a contribution to the general database of post-tropical storm response on Northern European coastlines, informing coastal response prediction and damage mitigation. Full article

Physical model tests were performed in a wave flume at Deltares with rock armoured slopes. A shallow foreshore was present. At deep water, the same wave conditions were used, but by applying different water levels, the wave loading on the rock armoured slopes increased considerably with increasing water levels. This allowed an assessment of the effects of sea level rise. Damage was measured by using digital stereo photography (DSP), which provides information on each individual stone that is displaced. Two test series were performed five times. This allowed for a statistical analysis of the damage to rock armoured slopes, which is uncommon due to the absence of statistical information based on a systematic repetition of test series. The statistical analysis demonstrates the need for taking the mean damage into account in the design of rock armoured slopes. This is important in addition to characterising the damage itself by erosion areas and erosion depths. The relation between damage parameters, such as the erosion area and erosion depth, was obtained from the tests. Besides tests with a straight slope, tests with a berm in the seaward slopes were also performed. A new method to take the so-called length effect into account is proposed to extrapolate results from physical model tests to real structures. This length effect is important, but is normally overlooked in the design of rubble mound structures. Standard deviations based on the presented model tests were used. Full article

Shallow foreshores in front of coastal dikes can reduce the probability of dike failure due to wave overtopping. A probabilistic model framework is presented, which is capable of including complex hydrodynamics like infragravity waves, and morphological changes of a sandy foreshore during severe storms in the calculations of the probability of dike failure due to wave overtopping. The method is applied to a test case based on the Westkapelle sea defence in The Netherlands, a hybrid defence consisting of a dike with a sandy foreshore. The model framework consists of the process-based hydrological and morphological model XBeach, probabilistic overtopping equations (EurOtop) and the level III fully probabilistic method ADIS. By using the fully probabilistic level III method ADIS, the number of simulations necessary is greatly reduced, which allows for the use of more advanced and detailed hydro- and morphodynamic models. The framework is able to compute the probability of failure with up to 15 stochastic variables and is able to describe feasible physical processes. Furthermore, the framework is completely modular, which means that any model or equation can be plugged into the framework, whenever updated models with improved representation of the physics or increases in computational power become available. The model framework as described in this paper, includes more physical processes and stochastic variables in the determination of the probability of dike failure due to wave overtopping, compared to the currently used methods in The Netherlands. For the here considered case, the complex hydrodynamics like infragravity waves and wave set-up need to be included in the calculations, because they appeared to have a large influence on the probability of failure. Morphological changes of the foreshore during a severe storm appeared to have less influence on the probability of failure for this case. It is recommended to apply the framework to other cases as well, to determine if the effects of complex hydrodynamics as infragravity waves and morphological changes on the probability of sea dike failure due to wave overtopping as found in this paper hold for other cases as well. Furthermore, it is recommended to investigate broader use of the method, e.g., for safety assessment, reliability analysis and design. Full article
