Search Results (33)

Building-integrated photovoltaic systems are essential components of smart buildings and sustainable urban infrastructure, contributing to energy efficiency and carbon footprint reduction in smart cities. Mismatch loss, particularly under partial shading, is one of the concerns in photovoltaic (PV) systems, especially in urban environments where buildings, trees, and other structures create complex shading patterns. It leads to significant power loss and poor efficiency. Several methods, such as string converters, multi-string converters, central converters, and micro-inverters/power optimizers, have been widely employed to address this issue. These methods suffer from hardware complexity and are good in certain shading patterns only; they remain ineffective otherwise. Power optimizers lead in efficiency under all the shading patterns, whereas string converters lead in hardware simplicity. We propose a novel parallel-series converter to mitigate mismatch losses in smart building applications that is as efficient as power optimizers and as simple as converters. In the proposed parallel-series converter design, multiple PV modules are connected in parallel to a very simple converter, and many such converters are then connected in series to get the final output. The proposed converter is rigorously evaluated for various shading patterns using MATLAB/SIMULINK. A prototype system of $3\times 2$ PV panels is also developed for hardware evaluation. The simulation and hardware results show that the proposed parallel-series converter dominantly competes with power optimizers with much simpler hardware and outperforms the other converters, making it particularly suitable for smart building energy systems where cost-effectiveness and reliability are critical. Full article

To avoid additional component losses while significantly improving the energy conversion efficiency of battery energy storage systems, the application of series-connected partial power converter (S-PPC) technology in battery energy storage systems is investigated in this study. In the S-PPC battery energy storage system configuration, coupling effects exist between the dc-link side and the battery-series side. The impedance modeling of a battery energy storage system is performed while taking these coupling effects into consideration. To address the instability observed during battery discharge conditions, an impedance reshaping control strategy that is suitable for the S-PPC battery energy storage system is proposed. The proposed method focuses on adjusting the input impedance of the load converter within a limited frequency band centered on the system’s oscillation frequency. This targeted approach significantly improves the stability of the system while ensuring ease of implementation and maintaining high reliability. Finally, the experimental results validate the theoretical analysis. Full article

Fuel cells (FCs) offer several operational advantages when integrated as a power source in electric vehicles (EVs). Since the voltage of these cells is typically low, usually less than 1 V, the power conversion system requires a DC–DC converter capable of providing a high voltage conversion ratio to match the input voltage of the motor propulsion system, which can exceed 400 V and reach up to 800 V. The modular DC–DC boost converter proposed in this paper is designed to achieve a high voltage step-up ratio for the input FC voltages through the use of isolated series-connecting boosting submodules connected. The power electronic topology employed in the submodules (SMs) is designed to provide a flexible output voltage while maintaining a continuous input current from the fuel cells with minimal current ripple to improve the FC’s performance. The proposed step-up modular converter provides several benefits including scalability, better controllability, and improved reliability, especially in the presence of partial faults. Computer simulations using MATLAB/SIMULINK^® software (R2024a) have been used to study the feasibility of the proposed converter when connected to a permanent magnet synchronous motor (PMSM). Also, experimental results using a 1 kW prototype composed of four SMs have been obtained to validate the performance of the proposed converter. Full article

This article proposes a photovoltaic power processor for high-voltage and high-power distribution bus, between 300 V and 900 V, to be used in future space platforms like large space stations or lunar bases. Solar arrays with voltages higher than 100 V are not available for space application, being necessary to apply power conversion techniques. The idea behind this is to use series-connected zero-voltage and zero-current unregulated and isolated DC converters to achieve high bus voltage from the existing solar arrays. Bus regulation is then achieved through low-frequency hysteretic control. Topology description, semiconductor selection, design procedure, simulation and experimental validation, including tests in vacuum and partial pressures, are presented. Full article

A novel integrated DC-DC converter is proposed for the first stage of two-stage grid connected photovoltaic (PV) systems with energy storage systems. The proposed three-port converter (TPC) consists of a buck–boost converter, interposed between the battery storage system and the DC-AC inverter, in series with PV modules. The buck–boost converter in the proposed TPC is utilized for maximum power point tracking by regulating two power switches. The output power of the proposed converter is regulated by controlling the DC-AC converter. During the battery-charging mode, partial power regulation is employed with a direct power flow path (the series-connection of the PV panel, the battery and the output). As resistances in this path are almost negligible, the power conversion efficiency is higher than existing topologies. During battery-discharging mode, the power conversion is processed through a buck–boost converter with only two active power switches and one inductor. With fewer components, higher power conversion efficiency is also achieved. The circuit operation and analysis are presented in detail. To illustrate the simplicity of the converter control, the performance of the converter is tested with a straightforward maximum power point tracking on a PV system with battery cells. Simulation and experimental tests are carried out to demonstrate circuit operation and power conversion efficiency. Full article

This study introduces an improved quantum-behavior particle swarm optimization (IQPSO), tailored for the task of maximum power point tracking (MPPT) within photovoltaic generation systems (PGSs). The power stage of the MPPT system comprises a series of buck-boost converters, while the control stage contains a microprocessor executing the biomimetic algorithm. Leveraging the series buck-boost converter, the MPPT system achieves optimal operation at the maximum power point under both ideal ambient conditions and partial shade conditions (PSCs). The proposed IQPSO addresses the premature convergence issue of QPSO, enhancing tracking accuracy and reducing tracking time by estimating the maximum power point and adjusting the probability distribution. Employing exponential decay, IQPSO facilitates a reduction in tracking time, consequently enhancing convergence efficiency and search capability. Through single-peak experiments, multi-peak experiments, irradiance-changing experiments, and full-day experiments, it is demonstrated that the tracking accuracy and tracking time of IQPSO outperform existing biomimetic algorithms, such as the QPSO, firefly algorithm (FA), and PSO. Full article

In this paper, a method based on an improved intelligent bat algorithm (IIBA) in cooperation with a voltage and current sensor was applied in maximum power point tracking (MPPT) for a photovoltaic module array (PVMA), where the power generation performance of a PVMA was enhanced. Due to the partial shading of the PVMA from climate changes or the surrounding environment, multiple peak values were generated on the power–voltage (P-V) curve, where the conventional MPPT technology could only track the local maximum power point (LMPP), hence the reduction in output power of PVMAs. Therefore, the IIBA-based MPPT was proposed in this paper to solve such issues and to ensure the capability of a PVMA in tracking the global maximum power point (GMPP) and utilization for enhancing the output power of a PVMA. Firstly, the Matlab/Simulink software was used to establish a boost converter model that simulated the actual 4-series–3-parallel PVMA under different shaded conditions, where the P-V curve with 1-peak, 2-peak, 3-peak and 4-peak values were generated. Subsequently, the tracking paces of the conventional bat algorithm (BA) were adjusted according to the gradient of the P-V curve for a PVMA. At the same time, 0.8 times the maximum power point (MPP) voltage V_mp under standard test conditions (STCs) for a PVMA was set as the initial tracking voltage. Lastly, the simulation results proved that under different environmental impacts, the proposed IIBA led to better performances in tracking both dynamic and steady responses. Full article

The Partial Power Processing (PPP) concept has garnered attention as it enables the down-sizing of converter and component ratings. Unlike conventional power processing, PPP addresses a portion of the transferred power, leading to a reduction in conversion losses. Throughout this paper, the state of the art of isolated and non-isolated DC-DC converter topologies will be revised. Partial Power Converter (PPC) systems represent one of the main streams of PPP, which, based on isolation requirements and converter connections, can further be divided into isolated converters, such as: Input-Parallel-Output-Series (IPOS), Input-Series-Output-Parallel (ISOP), and, Input-Series-Output-Series (ISOS), or non-isolated converters. This work intends to evaluate and differentiate the characteristics of each type of topology while developing analytically possible connections that may require further research and reviewing metrics that help in fair comparisons of different PPC arrangements, operating under different conditions. A thorough revision is provided for DC-DC converter topologies due to their increased importance in present-day applications, such as energy storage, Electric Vehicles (EVs), and Photo-Voltaics (PVs). Full article

This paper proposes an approach for analyzing the benefits that partial-power-processing-based converters can bring to fully electric maritime applications. With the aim of making the system modular and scalable to different powers/energies, series-connected partial power converters are proposed. Serializing these converters entails significant overvoltage issues, and this paper tackles them for one series-connected module failure case. A reliability analysis has been carried out considering that the components of the battery system follow an independent and identical distribution in terms of failure probability. Furthermore, a redundancy factor has been added to allow a certain failure rate in what is known as a fault-tolerant system. Finally, to demonstrate the high efficiency of partial power converters, a 3 kW prototype is tested at different working points that model the charging process of a battery. The experimental results show a peak efficiency of 99.36%. Full article

In this paper, the simulation and design of a power converter suitable for a low-voltage photovoltaic (PV) battery energy storage converter was investigated. The converter was suitable for sources and loads with near voltage levels and were aimed at efficiency improvement. The converter was called a series partial power converter (SPPC). A continuous current and a boost SPPC topology based on an isolated Cûk converter was constructed. The operation modes of the converter were analyzed. The efficiency verification test of the SPPC in a laboratory environment was completed using an outdoor start-up test, a photovoltaic full cover test and a steady-state operation test under different power levels. The results show that the SPPC can achieve 95–98% converter efficiency within the 87 W–242 W power range. The incremental conductance method based on the SPPC can realize the dynamic MPPT under constant illumination and changing meteorological conditions. Full article

With the growing interest in owning electric vehicles due to increased environmental awareness and uncertain energy security together with the development of Li-ion batteries, quietness, and trouble-free operation, it is urgent to develop charging stations that are fast enough to supply the vehicles with energy conveniently, as in case of conventional petrol stations. The main reason that hinders the spread of fast charging stations is the installation cost, comprising the infrastructure and converter costs. In this article, a multiport DC-DC converter with differential power processing stages is proposed for Electric Vehicle (EV) fast charging stations, which results in a considerable reduction in the cost of using converters while achieving high efficiency. The proposed topology consists of two paths for the power flow (outer and inner loops) for EV battery charging with main and auxiliary DC-DC converters in the outer loop; all the ports are connected in series with the main supply, where the bulk power is being transferred. The main DC-DC converter injects a series voltage to control the power in the outer loop. The auxiliary DC-DC converters are rated at a fractional power that controls the partial power supplied to each port through the inner loops. Thanks to the fractional power processed by the auxiliary converter with the remaining power fed to the battery through the main converter, the proposed architecture enables simultaneous charging of multiple electric vehicles with better efficiency, lower cost, and the capability of providing a fault tolerance feature. A PWM control scheme for the converters to achieve bi-directional power flow in the partially rated DC-DC converters is discussed for the proposed system. Moreover, a practical down-scaled hardware prototype is designed to validate the functionality, control scheme, and effectiveness of the proposed topology in different case studies being investigated. The efficiency of the proposed converter is compared to the conventional configuration. Full article

In this paper, we propose a photovoltaic emulator (PVE) composed of a series of connected power diodes with a single constant current source, rather than a power converter-based PVE. Accordingly, this enables readily verifying the operation because a the simple hardware structure and lack of a complex control algorithm. The proposed PVE can be intuitively implemented using the proposed selection criteria for the power diode and equivalent resistances. Since there is no feedback control based on complex analog/digital controls and sensors, the control response can be very fast. In addition, the proposed PVE can be easily integrated with a PV power system such as a power optimizer, to allow testing in a simple and flexible manner. Spice simulation was performed based on the electrical characteristics provided by the solar panel manufacturer, and this was utilized to validate the applied emulator circuit model, the Norton Equivalent Circuit. During the design process, the simulation helped to manufacture the PVE within error ranges satisfying the desired I–V and P–V curves, as well as the maximum power point (MPP). Partial shading could be easily implemented through use of the multiple series connection of individual PVEs, demonstrating local MPP and global MPP. A 400 W class PVE was built through appropriate power diode selection, with a thermal design to increase the output power. Moreover, its performance and feasibility were verified through intensive experiments. The measured efficiency, transient response time, and maximum transient error of the partial shading tests were 91%, 22 μs, and 5.8%, respectively. Full article

Accurate daily photovoltaic (PV) power predictions are challenging as near-ground atmospheric processes include complicated chaotic interactions among local factors (ground temperature, cloudiness structure, humidity, visibility factor, etc.). Fluctuations in solar irradiance resulting from the cloud structure dynamics are influenced by many uncertain parameters, which can be described by differential equations. Recent artificial intelligence (AI) computational tools allow us to transform and post-validate forecast data from numerical weather prediction (NWP) systems to estimate PV power generation in relation to on-site local specifics. However, local NWP models are usually produced each six hours to simulate the progress of main weather quantities in a medium-scale target area. Their delay usually covers several hours, further increasing the inadequate operational quality required in PV plants. All-day prediction models perform better, if they are developed with the last historical weather and PV data. Differential polynomial neural network (D-PNN) is a recently designed computational method, based on a new learning approach, which allows us to represent complicated data relations contained in local weather patterns to account for irregular phenomena. D-PNN combines two-input variables to split the partial differential equation (PDE), defined in the general order k and n variables, into partition elements of two-input node PDEs of recognized order and type. The node-determined sub-PDEs can be easily converted using operator calculus (OC), in several types of predefined convert schemes, to define unknown node functions expressed in the Laplace images form Application of the inverse L-transformation formula to the L-converts results in obtaining the prime function originals. D-PNN elicits a progressive modular tree structure to assess one-by-one the optimal PDE node solutions to be inserted in the sum output of the overall expanded computing model. Statistical modular models are the result of learning schemes of preadjusted day data records from various observational localities. They are applied after testing to the rest of unseen daily series of known data to compute estimations of clear-sky index (CSI) in the 24 h input-delayed time-sequences. Full article

This paper discusses the possibility of achieving partial power processing with non-isolated DC–DC topologies. To this end, partial power converter architectures are seen as an interesting solution for reducing the power processed by the converter. We observed via simulations that single-inductor non-isolated topologies cannot achieve partial power processing since the obtained current and voltage waveforms were the same as those found in a full-power converter. However, when using double inductor non-isolated topologies, reduced current and improved efficiencies were achieved. In order to confirm the results obtained from the simulations, single- and double-inductor topologies were tested experimentally. Finally, it was concluded that a double-inductor non-isolated topology can improve its performance by using partial power processing. Full article

The output of a photovoltaic array is reduced considerably when PV panels are shaded even partially. The impact of shading causes an appreciable loss in power delivery, since the PV panels are connected in series and parallel to contribute to the required voltage and power for the load. The prevailing research on mitigating the shading impact is mostly based on complex reconfiguration strategies where the PV panels are subjected to complex rewiring schemes. On the other hand, to disperse the shading many studies in the literature defend the physical rearrangement of the panels. The available intensive reconfiguration schemes, such as the series parallel (SP), bridge link (BL), honeycomb (HC), and total cross tied (TCT) schemes, try only to mitigate the shading impact and there is no scope for compensation; as a result, a loss of output power is inevitable. In the proposed research work, both the mitigation of and the compensation for the losses incurred due to shading are studied. In this work, an optimal reconfiguration scheme is adopted to reduce the shading impact and a power electronic circuit with a battery source is designed to compensate for the shading losses in all aspects. In the optimal reconfiguration scheme, a bifurcation strategy is adopted in each column and the electrical connections of the PV panels are interchanged such that the shading impact is dispersed. The power electronic circuit consists of a half-bridge buck converter with a battery source that injects the current required by a shaded column. This setup compensates for the shaded PV array’s power and improves the efficiency of the total system. The proposed scheme was implemented in a 3200 W system and subjected to various shading patterns, including single panel shading, corner shading, long and wide shading, and random shading. The proposed scheme was simulated in the MATLAB Simulink environment and compared with static 4 × 4 PV array configurations, including the series parallel (SP), bridge link (BL), honeycomb (HC), and total cross tied (TCT) configurations. The comparative performance was assessed in terms of mismatch power loss, fill factor, and efficiency. The proposed system is suitable for all shading patterns and was proved to be very efficient even in the worst shading, where 1353 W was saved. Full article
