Search Results (218)

Search Parameters:
Keywords = scaled wind tunnel testing

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
9 pages, 36201 KB
Proceeding Paper
Pre-Experimental Aerodynamic Design Study for a High-Lift Wing FSI Benchmark Model Using the Lattice Boltzmann Method
by Malav Soni, Roland Ewert, Christian Jente and Jan Delfs
Eng. Proc. 2026, 133(1), 199; https://doi.org/10.3390/engproc2026133199 - 16 Jun 2026
Viewed by 89
Abstract
A numerical design study is carried out to support the setup of a wind tunnel experiment for the flap cover seal, which will serve as a benchmarking reference database for Fluid–Structure Interaction (FSI) in aeronautics. To this end, 3-D scale-resolving unsteady Large Eddy [...] Read more.
A numerical design study is carried out to support the setup of a wind tunnel experiment for the flap cover seal, which will serve as a benchmarking reference database for Fluid–Structure Interaction (FSI) in aeronautics. To this end, 3-D scale-resolving unsteady Large Eddy Simulation (LES) with the Lattice Boltzmann Method (LBM) is carried out using the simulation software ProLB. A new aerodynamic layout for the chosen F15LS (Large-Scale) high-lift wing model is established to fit the high-lift wing in the DLR-AWB tunnel. The design process involves variations in the leading-edge nose contour’s streamwise length and camber lines (inducing a negative S-shape) to reduce the leading-edge suction peak, thereby lowering the absolute lift while preserving the flap operating conditions. Initial simulations utilize a simplified periodic LES slice and a theory of the method of images to model wind tunnel jet flow deflection, culminating in a full-span 3-D WM-LES-LBM simulation of the entire wind tunnel installation, including free shear layers, to confirm the designed performance of the modified F15LS. This simulation serves to make informed decisions on model settings such as the boundary layer fence and model-nozzle distance. The successful experimental validation of critical performance characteristics, including angle-of-attack requirements and flow deflection, confirms the fidelity of the pre-test WM-LES-LBM evaluation. Full article
Show Figures

Figure 1

54 pages, 16296 KB
Article
Optimization of a Sand Control System Using Wind Tunnel Simulations
by Ashraf A. Ramadan and Ali Al-Dousari
Sustainability 2026, 18(11), 5716; https://doi.org/10.3390/su18115716 - 4 Jun 2026
Viewed by 215
Abstract
Sand stabilization techniques include mechanical, biological, and chemical methods. Integrated systems combine these approaches in varying proportions. This study tested a sand control system developed by the Kuwait Institute for Scientific Research using a 1/100-scale model in an aeolian sand transport wind tunnel. [...] Read more.
Sand stabilization techniques include mechanical, biological, and chemical methods. Integrated systems combine these approaches in varying proportions. This study tested a sand control system developed by the Kuwait Institute for Scientific Research using a 1/100-scale model in an aeolian sand transport wind tunnel. Experiments employed boundary layer pressure measurements and salti-phone sand transport quantification to examine effects of wind speed, fence height, and tree configuration. Boundary layer velocity was primarily affected by fan speed, with fence height, tree configuration, and measurement location playing minor roles. Sand transport correlated directly with wind speed. Fence height showed inverse proportionality to centerline velocity but direct proportionality off-center velocity. The optimal configuration, i.e., C6 tree spacing (the central row was 35 m from the upwind fence, and subsequent rows were at 5 m and 10 m intervals, using Tamarix aphylla and Prosopis juliflora and with an H2 fence height (1.8 m)), achieved a 68.9% mean sand transport reduction. The graduated vegetation density provided superior momentum absorption versus uniform spacing, while a 1.8 m fence height balanced particle capture against flow blockage. A preliminary economic analysis demonstrates favorable cost–benefit ratios with 2–3-year payback periods. System costs ($185,000/km) are substantially lower than sand removal expenses, providing validated design guidelines for Kuwait and similar arid environments. Full article
Show Figures

Figure 1

25 pages, 3996 KB
Article
Research on Refined Design Method for Large-Diameter Hypersonic Nozzle Contours
by Chenxi Sun, Huiqi Ren, Zailin Yang and Renjie Wang
Aerospace 2026, 13(6), 507; https://doi.org/10.3390/aerospace13060507 - 29 May 2026
Viewed by 243
Abstract
With the advancement of aerospace technology, full-scale wind tunnel testing has become a crucial approach to overcoming bottlenecks in hypersonic technology. The design of ultra-large, high-performance nozzles stands out as one of the core challenges. This paper focuses on a profiling design method [...] Read more.
With the advancement of aerospace technology, full-scale wind tunnel testing has become a crucial approach to overcoming bottlenecks in hypersonic technology. The design of ultra-large, high-performance nozzles stands out as one of the core challenges. This paper focuses on a profiling design method for supersonic/hypersonic nozzles with interchangeable throats at the 6 m outlet scale, addressing issues such as significant boundary layer effects and difficulties in achieving variable Mach numbers due to the large dimensions. An empirical boundary layer correction method is proposed to efficiently compensate for viscous effects. By parameterizing and controlling the Mach number distribution along the nozzle axis using cubic B-spline curves and applying the method of characteristics for accurate inviscid supersonic flow field computation, the nozzle profile is optimized. To enable multi-Mach-number operation, a design strategy is adopted, where the high-Mach-number profile serves as the baseline, and the low-Mach-number throat section is inversely designed to ensure a smooth transition between multi-Mach nozzles and a shared expansion section. Using this approach, nozzle profiles for Mach numbers 4, 5, and 6 were successfully designed and validated through fully viscous CFD simulations. Results demonstrate that under all design conditions, a wide and uniform core flow region forms at the nozzle exit, with no strong shock waves present in the flow field. This study confirms the effectiveness and reliability of the integrated design method for large-scale interchangeable-throat nozzles, providing important theoretical foundation and technical support for the future development of advanced large-scale hypersonic wind tunnels. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

20 pages, 5076 KB
Article
Study of the Effects of Blade Surface Icing on the Aerodynamic Performance of a Small-Scale VAWT via Wind Tunnel Test and Numerical Simulation
by Guanxi Pan, Yuqi Zhang, Hao Yan and Zhiyuan Liu
Coatings 2026, 16(5), 566; https://doi.org/10.3390/coatings16050566 - 8 May 2026
Viewed by 353
Abstract
During the worldwide energy transition, wind power has become a leading development direction. Compared to large-scale horizontal-axis wind turbines (HAWTs), small-scale vertical-axis wind turbines (VAWTs) show potential, lack yaw mechanisms, adapt to wind direction changes, and are cost-effective. However, small-scale VAWTs operate in [...] Read more.
During the worldwide energy transition, wind power has become a leading development direction. Compared to large-scale horizontal-axis wind turbines (HAWTs), small-scale vertical-axis wind turbines (VAWTs) show potential, lack yaw mechanisms, adapt to wind direction changes, and are cost-effective. However, small-scale VAWTs operate in the near-surface atmospheric boundary layer and are sensitive to low-temperature and high-humidity climates, which cause blade icing. Ice buildup leads to fluctuations in aerodynamic loads, reduces power output, and diminishes stability. This study focuses on the NACA-0018 airfoil, using a low-temperature wind tunnel platform to simulate freezing durations to obtain ice characteristics on the blade surface. Based on ice profiles, numerical models were developed. Computational fluid dynamics (CFD) techniques were used to perform unsteady simulations of aerodynamic performance at various icing durations, investigating the influence on the power coefficient. The results indicate that the effect of icing duration on the average power coefficient depends on TSR. At the 5 min icing stage, the optimal tip-speed ratio decreases. Icing deteriorates aerodynamic performance at high tip-speed ratios, while producing positive optimization effects at low tip-speed ratios. This paper reveals the variation patterns of aerodynamic performance and differentiated mechanisms during the icing process of small vertical-axis wind turbine blades, providing a theoretical basis and data support for the development of surface anti-icing technologies and safe, efficient operation in low-temperature environments. Full article
Show Figures

Figure 1

16 pages, 15763 KB
Article
Modification of a Scaled Flight Demonstrator for the Implementation and Experimental Investigation of an Energy Harvesting Powertrain in Distributed Electric Propulsion Systems
by Achim Kuhn, Eskil Jonas Nussbaumer, Jan Denzel, Dominique Paul Bergmann and Andreas Strohmayer
Aerospace 2026, 13(5), 435; https://doi.org/10.3390/aerospace13050435 - 6 May 2026
Viewed by 416
Abstract
Distributed electric propulsion (DEP) systems offer a wide range of options for arranging the propulsion units on an aircraft. In most cases, the position of the propulsion systems is optimized for one specific flight phase, e.g., takeoff or cruise. Taking advantage of the [...] Read more.
Distributed electric propulsion (DEP) systems offer a wide range of options for arranging the propulsion units on an aircraft. In most cases, the position of the propulsion systems is optimized for one specific flight phase, e.g., takeoff or cruise. Taking advantage of the high lift potential of the DEP also during descent and approach phases represents a challenge due to increased thrust. Energy harvesting propellers (EHPs) can be used to adapt the resulting thrust, by generation an additional drag force while regenerating a certain amount of energy back into the system. Therefore, the scaled flight demonstrator (SFD) e-Genius-Mod was modified to implement an energy harvesting powertrain in a DEP system. The energy harvesting wingtip propellers are integrated in a pusher configuration. It is possible to investigate different operation modes for recuperation, such as Windmilling and Opposite Pitch, by adjusting different propeller pitch angles. The electronics used for the wingtip propellers (WTPs) enable the control and measurement of the recuperation performance and furthermore to charge recuperated energy back into the battery. The energy harvesting system was tested in a wind tunnel to verify its functionality. In Windmilling mode, the maximum mean electrical power output is −25.7 W. In Opposite Pitch mode, the values were significantly higher, with a maximum mean electrical power of −184 W. This corresponds to up to seven times as much regenerated power in Opposite Pitch mode. Full article
Show Figures

Figure 1

9 pages, 1787 KB
Proceeding Paper
Flow Characterization Around a Mars Rover Model at Extremely Low Reynolds Number
by Jaime Fernández-Antón, Rafael Bardera-Mora, Ángel Rodríguez-Sevillano, Juan Carlos Matías-García and Estela Barroso-Barderas
Eng. Proc. 2026, 133(1), 33; https://doi.org/10.3390/engproc2026133033 - 22 Apr 2026
Viewed by 303
Abstract
This work presents an experimental aerodynamic study of a Mars rover model, aimed at characterizing its flow behavior under Martian environmental conditions. Due to the extremely low Reynolds numbers associated with Mars’ thin atmosphere, the experiments were conducted using a scaled model of [...] Read more.
This work presents an experimental aerodynamic study of a Mars rover model, aimed at characterizing its flow behavior under Martian environmental conditions. Due to the extremely low Reynolds numbers associated with Mars’ thin atmosphere, the experiments were conducted using a scaled model of the rover manufactured via additive techniques. The study first focuses on understanding how the geometry of the rover influences the overall flow field, identifying key aerodynamic features such as separation zones, vortical structures, and flow reattachment regions driven by the complexity of the vehicle. A comprehensive investigation of the flow around the model was performed using both a hydrodynamic towing tank with dye injection for qualitative visualization, and particle image velocimetry (PIV) for quantitative flow field analysis in wind tunnel tests. After the general flow characterization, a more detailed local analysis was conducted using laser Doppler anemometry (LDA). This phase of the study targeted precise velocity measurements at specific locations corresponding to the MEDA (Mars Environmental Dynamics Analyzer) wind sensors onboard the rover. Quantitative results indicate that the central body induces a local flow acceleration of 20% to 40% relative to the free stream while severe turbulence was recorded in specific angular sectors, with velocity fluctuations reaching up to 120% for Sensor 1 and 90% for Sensor 2. Full article
Show Figures

Figure 1

24 pages, 5265 KB
Article
Experimental and Numerical Determination of Aerodynamic Characteristics of an Ogive with Canards
by Teodora Đilas, Dunja Ukšanović, Jelena Svorcan and Boško Rašuo
Aerospace 2026, 13(4), 377; https://doi.org/10.3390/aerospace13040377 - 16 Apr 2026
Viewed by 365
Abstract
This work presents an integrated experimental and numerical determination of the aerodynamic (lift) characteristics of an ogive forebody equipped with all moving canards. Experimental testing was conducted in the subsonic custom-made wind tunnel of the Vlatacom Institute at a nominal free stream velocity [...] Read more.
This work presents an integrated experimental and numerical determination of the aerodynamic (lift) characteristics of an ogive forebody equipped with all moving canards. Experimental testing was conducted in the subsonic custom-made wind tunnel of the Vlatacom Institute at a nominal free stream velocity of 32 m/s (and Mach number M = 0.09). Aerodynamic loads on the canards were measured using a custom one-component force balance, while free stream flow properties were obtained via a calibrated Pitot–Prandtl probe on the full-scale geometry model. On the numerical side, RANS simulations were performed in ANSYS Fluent using the k-ω SST turbulence model. Two geometric representations were considered: (a) a high-fidelity configuration explicitly resolving the physical gap between the canard and ogive, and (b) a simplified configuration with the gap removed. Boundary conditions, Reynolds number, and operating parameters were matched to the wind tunnel conditions to enable a strict one-to-one comparison. Particular emphasis was placed on examining the effect of geometric simplification on the predicted lift characteristics. The gap-resolved configuration reproduces the experimentally measured lift curve within approximately 10% across the investigated angle-of-attack range, satisfying conventional aerodynamic validation criteria. The results confirm both the robustness of the applied RANS approach for highly three-dimensional separated flows often found in engineering applications, as well as the reliability of the experimental measurement system. Full article
(This article belongs to the Special Issue Recent Advances in Applied Aerodynamics (2nd Edition))
Show Figures

Figure 1

19 pages, 5431 KB
Article
A Full-Scale Experimental Method for Assessing the Performance of Optical Guidance Systems in Road Vehicles
by Almerindo D. Ferreira, James Ogundiran, Behrang Chenari, José I. Barbosa and Manuel Gameiro da Silva
Machines 2026, 14(4), 437; https://doi.org/10.3390/machines14040437 - 15 Apr 2026
Viewed by 1058
Abstract
The present study proposes a full-scale experimental methodology for testing and quantifying the trajectory deviations induced in road vehicles. A full-scale articulated bus was employed in this work and tested under real operating conditions. In its foreseen exploitation use, the vehicle will, under [...] Read more.
The present study proposes a full-scale experimental methodology for testing and quantifying the trajectory deviations induced in road vehicles. A full-scale articulated bus was employed in this work and tested under real operating conditions. In its foreseen exploitation use, the vehicle will, under certain conditions, be automatically guided (to cross bridges and tunnels and to approach and stop at bus stops). A series of tests was conducted on a bridge under different transverse wind conditions. It is important to note that the deviation measured by the laser system includes both the inherent deviations of the optical guidance system (OGS) and those induced by wind. It was observed that, despite trajectory variability, when measured at high spatial resolution (±1 mm) during the approach phase upstream of the test zone, the optical guidance system corrected deviations from the ideal trajectory within a short time interval and over a short distance. The system’s response shows reasonable agreement with the manufacturer’s results reported in the OGS study. The results also show some degree of dispersion, given multiple sources of uncertainty inherent to full-scale testing under real operating conditions. The findings show that the OGS’s dynamic response is adequate to reduce disturbances to the vehicle’s trajectory caused by crosswind. Full article
(This article belongs to the Special Issue Advances in Vehicle Dynamics)
Show Figures

Figure 1

27 pages, 6553 KB
Article
Scaled Test Program Strategy of Skin Heat Exchanger for Thermal Management in Hybrid Electric Regional Aircraft
by Benigno J. Lázaro and Ezequiel González-Martínez
Aerospace 2026, 13(4), 353; https://doi.org/10.3390/aerospace13040353 - 10 Apr 2026
Viewed by 368
Abstract
The strategy developed to carry out a scaled test program aimed at reproducing the behavior of skin heat exchangers to alleviate the heat dissipation requirements in future hybrid electric propulsion regional aircrafts is presented. The test program is intended to reproduce the dimensionless [...] Read more.
The strategy developed to carry out a scaled test program aimed at reproducing the behavior of skin heat exchangers to alleviate the heat dissipation requirements in future hybrid electric propulsion regional aircrafts is presented. The test program is intended to reproduce the dimensionless thermal response characterizing the skin heat exchanger on a predefined nominal cruise flight operation, while conducting the tests in a wind tunnel operating at low velocities and near-standard atmospheric conditions. For that purpose, dimensional analysis is used to define the geometrical scale and approach flow conditions in the wind tunnel test program, so that the dimensionless parameters describing the skin heat exchanger thermal response resemble the ones taking place under nominal flight conditions. The validation of the scaling strategy is achieved by comparing dimensionless parameters characterizing the turbulent momentum and heat transfer processes taking place at the skin heat exchanger/airflow interface surface in the flight and wind tunnel environments, by using CFD analysis based on two-equation kϵ and SST RANS turbulence modeling. The comparison reveals that the adopted wind tunnel strategy is indeed capable of closely reproducing the heat transfer process taking place in the flight environment, thus paving the way to achieve mid TLR validation of the skin heat exchanger technology. Full article
Show Figures

Figure 1

28 pages, 8550 KB
Article
Experimental Study on Spanwise Aerodynamic Control Measures for Vortex-Induced Vibrations of a Narrow Π-Shaped Girder of a Large Span Railway Cable-Stayed Bridge
by Jianjun Liu, Zhengchun Xia, Bing Li, Ming Liu and Zhiwen Liu
Appl. Sci. 2026, 16(7), 3422; https://doi.org/10.3390/app16073422 - 1 Apr 2026
Viewed by 319
Abstract
Large-span bridges with bluff body girders are susceptible to vortex-induced vibration (VIV) due to their low frequency, light mass, and relatively low damping ratio, affecting fatigue life and serviceability. While research progress has been made on VIV mechanisms and control measures, systematic investigations [...] Read more.
Large-span bridges with bluff body girders are susceptible to vortex-induced vibration (VIV) due to their low frequency, light mass, and relatively low damping ratio, affecting fatigue life and serviceability. While research progress has been made on VIV mechanisms and control measures, systematic investigations on the application of vortex generators (VGs) to narrow Π-shaped railway girders remain scarce, and the potential synergistic effect of combining VGs with conventional aerodynamic measures has not been explored. To address this gap, wind tunnel tests were conducted on a 1:50 scale sectional model of a narrow Π-shaped steel girder for a railway cable-stayed bridge. The experimental program systematically investigated the VIV response of the original girder and evaluated the suppression effectiveness of conventional aerodynamic measures (vertical stabilizers, deflectors, modified fairings) and spanwise control using VGs. Parametric optimization of VG height (0.1 H–0.2 H, where H is the girder height), spacing (2/3 L0 and L0, where L0 = 12.5 m is the standard segment length), and installation position (upper fairing, lower fairing, girder bottom) was performed. Results show that under wind angles of attack from −5° to +5° and a damping ratio of 0.36%, the original girder exhibits pronounced vertical VIV with a maximum RMS amplitude of 0.025 m, approximately 3.15 times the code limit. Conventional measures alone fail to adequately suppress VIV. However, the optimal combination of VGs (height 0.2 H, spacing L0, installed on the lower fairing) with a 0.5 m wide, 15° inclined deflector effectively suppresses VIV under wind AOAs of 0°, ±3°, and –5°, achieving suppression below the measurable threshold. This study contributes the first comprehensive parametric investigation of VGs for narrow Π-shaped railway girders, reveals a synergistic effect when combining VGs with deflectors, and incorporates practical engineering constraints (such as aesthetic requirements) into the optimization process. Full article
(This article belongs to the Special Issue Structural Wind Engineering: Latest Advances and Applications)
Show Figures

Figure 1

84 pages, 13153 KB
Review
Review of Rotary-Wing Morphing Actuation Systems
by Mars Burke and Alvin Gatto
Aerospace 2026, 13(3), 297; https://doi.org/10.3390/aerospace13030297 - 23 Mar 2026
Viewed by 21069
Abstract
A review of morphing actuation systems in relation to rotary-wing aerial platforms is presented. The research highlights an inadequate maturation of rotary actuation systems, characterised by a scarcity of (1) comprehensive full-scale experimental research relative to non-rotary (fixed-wing) systems, (2) techniques used for [...] Read more.
A review of morphing actuation systems in relation to rotary-wing aerial platforms is presented. The research highlights an inadequate maturation of rotary actuation systems, characterised by a scarcity of (1) comprehensive full-scale experimental research relative to non-rotary (fixed-wing) systems, (2) techniques used for rotary actuation systems and (3) implementation of full-chord morphing systems, with existing research only utilising partial-chord actuation techniques. Additionally, another notable shortcoming is presented to be the lack of comprehensive proportional investigation in the proposed five-step development process for rotary actuation designs. A comprehensive critical review is offered, covering the following challenges of progressing through this development process for rotary actuation systems from conceptual design to production: (1) numerical and computational studies, (2) small-scale wind-tunnel testing, (3) full-scale wind-tunnel testing, (4) demonstrator, and ultimately (5) fabrication for industrial implementation. The review examines several existing rotary actuation systems, including (but not limited to) leading-edge, trailing-edge and Gurney flaps; active twist; chord extension; variable span and camber systems. Comparisons are made between rotary morphing actuation systems and their non-morphing counterparts, highlighting the distinct difficulties encountered by rotary-wing systems due to the more complex and challenging operational conditions found in rotorcraft. The review reveals that a significant portion of existing research on rotary-wing systems has focused only on early-stage development, including computational modelling and sub-scale wind-tunnel experiments, underscoring the necessity for more comprehensive full-scale testing and prototype evaluation given that only a small number of studies have progressed to full-scale wind-tunnel testing or actual prototype evaluation, with only one example identified as having been tested on a production helicopter. In addition, a comparative Technology Readiness Level (TRL) assessment is presented for both rotary-wing and fixed-wing morphing actuation systems, enabling a structured evaluation of relative technology maturity, experimental validation depth, and proximity to operational implementation. Building upon this assessment, a morphing Actuation Concept-Transfer Feasibility (ACTF) study is also provided, examining the potential for adapting mature fixed-wing morphing actuation technologies for application in rotary-wing environments, while identifying the key structural, aerodynamic, and operational constraints that currently limit direct technology transfer. This study addresses and proposes opportunities for a novel rotary actuation system design and concludes by suggesting the potential for future research on more effectual systems to include full-chord configuration over larger spanwise blade footprints with innovative actuation mechanisms that could be utilised and progressed through all development stages from numerical studies to full-scale fabrication. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

19 pages, 3492 KB
Article
Design and Experimental Evaluation of Thrust-Matched Blade Model for FOWT Wind Tunnel Test
by Yangyang Gao and Lingyun Chang
J. Mar. Sci. Eng. 2026, 14(6), 581; https://doi.org/10.3390/jmse14060581 - 21 Mar 2026
Viewed by 320
Abstract
The scaled model test is currently the most reliable approach for the conceptual design and experimental validation of floating offshore wind turbines (FOWT). In current scaled model tests, the common practice of designing scaled blades using low-Reynolds airfoils fails to account for turbulent [...] Read more.
The scaled model test is currently the most reliable approach for the conceptual design and experimental validation of floating offshore wind turbines (FOWT). In current scaled model tests, the common practice of designing scaled blades using low-Reynolds airfoils fails to account for turbulent wind conditions and wind profiles identical to those of the full-scale prototype and lacks an explicit criterion for airfoil selection. This paper presents a refined design framework for scaled blade models that ensures thrust similarity to a prototype turbine within the test wind-speed range of the FOWT wind tunnel test and under the turbulent conditions and wind profiles corresponding to the prototype turbine. Applying this framework, a set of thrust-matched scaled blades for a 20 MW floating offshore wind turbine was designed, and a corresponding wind tunnel test was conducted to test the accuracy of thrust similarity in this design method. The results of the wind tunnel test show that the time-averaged thrust error between the scaled model and the prototype is less than 1.52% across the entire wind-speed range. The effectiveness of the design in reproducing target mean thrust under turbulent inflow is confirmed, providing an available framework for FOWT wind tunnel testing. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

18 pages, 7585 KB
Article
Design and Characterization of a Bench-Top Ludwieg Tube for Aerodynamic Measurements via Simultaneous Quantification of Mach Number and Velocity
by Boris S. Leonov, Richard Q. Binzley, Nathan G. Phillips, Roman Rosser, Farhan Siddiqui, Arthur Dogariu and Richard B. Miles
Fluids 2026, 11(3), 80; https://doi.org/10.3390/fluids11030080 - 15 Mar 2026
Viewed by 843
Abstract
This article presents the design and detailed characterization of a new supersonic wind tunnel at the Aerospace Laboratory for Lasers, ElectroMagnetics, and Optics of Texas A&M University, tailored for optical diagnostic development and sub-scale fundamental compressible fluid dynamics research. A Ludwieg tube tunnel [...] Read more.
This article presents the design and detailed characterization of a new supersonic wind tunnel at the Aerospace Laboratory for Lasers, ElectroMagnetics, and Optics of Texas A&M University, tailored for optical diagnostic development and sub-scale fundamental compressible fluid dynamics research. A Ludwieg tube tunnel architecture was selected due to its robustness, versatility, and low operational costs. The tunnel consists of a 50-foot-long driver tube constructed from modular Tri-Clamp spools, a Mach 4 nozzle with 3 in. exit diameter configured as a free jet, and a fast-acting valve with 14 ms opening time for high-duty-cycle operation. Such construction proved to be a robust, compact, and affordable solution for academic applications. Characterization methods consisted of simultaneous high-speed dot-schlieren, total and static pressure measurements, and femtosecond laser electronic excitation tagging. Average flow velocity for the first steady-state test time was measured via FLEET at (668.0 ± 5.7) m/s. The Mach number was calculated based on the angles of the attached oblique shocks formed near the 30° cone model. Calculated Mach number was repeatable from run to run and had small oscillations near the average value of 3.96 ± 0.03. Based on the simultaneously measured velocity and Mach number, the static temperature was calculated to be between (68.6 ± 0.3) K and (66.3 ± 0.3) K throughout the 400 ms test time, completely defining the thermodynamic state of the generated freestream flow. Full article
(This article belongs to the Special Issue High-Speed Processes in Continuous Media)
Show Figures

Figure 1

16 pages, 4381 KB
Article
Reynolds Number Effect of a Supercritical Wing Based on Cryogenic and High Reynolds Number Pressure Test
by Baobin Hou, Yanru Chen, Jinyan Cai, Xin Peng, Xin Xu and Dawei Liu
Aerospace 2026, 13(3), 265; https://doi.org/10.3390/aerospace13030265 - 11 Mar 2026
Viewed by 479
Abstract
Supercritical wings are widely used in large aircraft due to their excellent transonic performance, but their aerodynamic characteristics are highly sensitive to Reynolds number. To systematically study the influence of Reynolds number on the aerodynamic characteristics of a supercritical wing, cryogenic high Reynolds [...] Read more.
Supercritical wings are widely used in large aircraft due to their excellent transonic performance, but their aerodynamic characteristics are highly sensitive to Reynolds number. To systematically study the influence of Reynolds number on the aerodynamic characteristics of a supercritical wing, cryogenic high Reynolds number pressure measurement tests were conducted in the European Transonic Wind Tunnel (ETW). A 1:17.87 scale wing-body combination model of a typical supercritical wing was employed. The Reynolds number was increased via the pressure increase and cooling technique, covering a test Reynolds number range from 2.3 × 106 to 3.5 × 107. Model deformation effects were isolated to obtain pressure data reflecting pure Reynolds number effects. The variation patterns of pressure distribution, lift characteristics, and pitching moment characteristics with Reynolds number were analyzed. The results indicate that, at lower speeds (Ma = 0.4 and 0.6), the supercritical wing is less affected by Reynolds number; the upper surface is more significantly influenced by Reynolds number than the lower surface; the Reynolds number effect primarily manifests in the transonic regime by delaying the onset position of the shock wave on the upper wing surface, thereby affecting aerodynamic force characteristics; several aerodynamic characteristic parameters such as ΔCL, α0, and Cm exhibit a linear relationship with the logarithm of Reynolds number. Experimental results obtained at low Reynolds numbers cannot be directly extrapolated to actual flight conditions, necessitating the consideration of Reynolds number effect in the aerodynamic design optimization of large aircraft. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

24 pages, 5354 KB
Article
Integrated Aerodynamic–Propulsion Optimization for Gas-Powered Fan VTOL Systems via CFD and Genetic Algorithms
by Mohammad Javad Pour Razzaghi, Guoping Huang and Yuanzhao Zhu
Aerospace 2026, 13(2), 184; https://doi.org/10.3390/aerospace13020184 - 13 Feb 2026
Cited by 1 | Viewed by 637
Abstract
Vertical takeoff and landing (VTOL) aircraft must balance the conflicting demands of hover and cruise performance. To address the lack of integrated design methodologies in the existing literature, a unified design-optimization framework is presented, coupling high-fidelity CFD simulations with a genetic algorithm to [...] Read more.
Vertical takeoff and landing (VTOL) aircraft must balance the conflicting demands of hover and cruise performance. To address the lack of integrated design methodologies in the existing literature, a unified design-optimization framework is presented, coupling high-fidelity CFD simulations with a genetic algorithm to refine a gas-driven thrust fan (GDTF) VTOL nacelle. Key geometric parameters—fan pressure ratio pressure ratio, fan tilt, nozzle angle, tail inclination, and tip shape—were varied in a comprehensive parametric study to maximize lift-to-drag ratio and maintain constant mass flow. The optimization reveals that a nearly horizontal fan axis maximizes cruise efficiency (LD  2.98), a nozzle angle of about 22° offers the best lift-vs-drag compromise during transition, and refining the tip geometry yields a 1020% performance boost. To validate the numerical predictions, a 1:1.05 scale VTOL nacelle model (fan diameter D = 0.42 m) was fabricated and tested in a low-speed wind tunnel at 52 ms (Re  5 × 106, turbulence intensity ≈ 2%). Total-pressure probes at the intake exit plane and static taps along the inner cowl wall provided detailed pressure distributions, from which exit Mach number, velocity and the equivalent flow coefficient φ (≈0.68 under test conditions) were derived. Oil-flow visualization on the external cowl surface confirmed smooth, attached streamlines with no large separation bubbles. This dual validation combining surface-flow visualization and pressure-recovery mapping demonstrates the accuracy and reliability of the proposed simulation methodology. By successfully bridging detailed CFD with genetic-algorithm-driven design and validating against comprehensive wind-tunnel measurements, this integrated approach paves the way for next-generation VTOL configurations with longer range and lower fuel consumption. Full article
(This article belongs to the Special Issue Advanced Aircraft Structural Design and Applications)
Show Figures

Figure 1
