With the depletion of shallow coal resources, deep extra-thick coal seam mining has become vital for energy security, yet fully mechanized top-coal caving (FMTC) goaf-side roadways face severe challenges of excessive advanced deformation and intense strata behavior. To address this gap, this study took the 4301 tailgate of a coal mine in Shaanxi province as the engineering background, integrating field investigation, theoretical analysis, FLAC^3D numerical simulation, and industrial tests. Guided by the key stratum theory, we systematically analyzed the influence of overlying key strata fracture on strata pressure. The results show three key strata: near-field secondary key strata (KS1, KS2) with “vertical O-X” fracturing and far-field main key stratum (MKS) with “horizontal O-X” fracturing. The radial extrusion force from MKS rotational blocks is the core cause of 200 m range advanced deformation. A collaborative control scheme of near-field key strata directional fracturing roof-cutting pressure relief and high-strength bolt-cable support was proposed. Industrial verification indicates roadway deformation was significantly reduced, with roof subsidence, floor heave, and rib convergence controlled within safe engineering limits. This study fills the gap of insufficient research on far-field key strata’s impact, providing a reliable technical solution for similar extra-thick coal seam FMTC goaf-side roadway surrounding rock control. Full article

Maintaining the stability of the mine roadway is of paramount importance, as it is critical in ensuring the daily operational continuity, personnel safety, long-term economic viability, and sustainability of the entire mining operation. Significant instability can trigger serious disruptions—such as production stoppages, equipment damage, and severe safety incidents—which ultimately compromise the project’s financial returns and future prospects. Therefore, the proactive assessment and rigorous control of roadway stability constitute a foundational element of successful and sustainable resource extraction. In China, thick and extra-thick coal seams constitute over 44% of the total recoverable coal reserves. Consequently, their safe and efficient extraction is considered vital in guaranteeing energy security and enhancing the efficiency of resource utilization. The surrounding rock of gob-side roadways in typical coal seams is often fractured due to high ground stress, intensive mining disturbances, and overhanging goaf roofs. Consequently, asymmetric failure patterns such as bolt failure, steel belt tearing, anchor cable fracture, and shoulder corner convergence are common in these entries, which pose a serious threat to mine safety and sustainable mining operations. This deformation and failure process is associated with several parameters, including the coal seam thickness, mining technology, and surrounding rock properties, and can lead to engineering hazards such as roof subsidence, rib spalling, and floor heave. This study proposes countermeasures against asymmetric deformation affecting gob-side entries under intensive mining pressure during the fully mechanized caving of extra-thick coal seams. This research selects the 8110 working face of a representative coal mine as the case study. Through integrated field investigation and engineering analysis, the principal factors governing entry stability are identified, and effective control strategies are subsequently proposed. An elastic foundation beam model is developed, and the corresponding deflection differential equation is formulated. The deflection and stress distributions of the immediate roof beam are thereby determined. A systematic analysis of the asymmetric deformation mechanism and its principal influencing factors is conducted using the control variable method. A support approach employing a mechanical constant-resistance single prop (MCRSP) has been developed and validated through practical application. The findings demonstrate that the frequently observed asymmetric deformation in gob-side entries is primarily induced by the combined effect of the working face’s front abutment pressure and the lateral pressure originating from the neighboring goaf area. It is found that parameters including the immediate roof thickness, roadway span, and its peak stress have a significant influence on entry convergence. Under both primary and secondary mining conditions, the maximum subsidence shows an inverse relationship with the immediate roof thickness, while exhibiting a positive correlation with both the roadway span and the peak stress. Based on the theoretical analysis, an advanced support scheme, which centers on the application of an MCRSP, is designed. Field monitoring data confirm that the peak roof subsidence and two-side closure are successfully limited to 663 mm and 428 mm, respectively. This support method leads to a notable reduction in roof separation and surrounding rock deformation, thereby establishing a theoretical and technical foundation for the green and safe mining of deep extra-thick coal seams. Full article

Underground roadway support is a critical component for ensuring safety in mining operations. In recent years, with the rapid advancement of intelligent technologies, computer vision-based automatic rock bolt detection methods have emerged as a promising alternative to traditional manual inspection. However, the underground mining environment inherently suffers from severely insufficient lighting. Images captured on-site often exhibit problems such as low overall brightness, blurred local details, and severe color distortion. To address the problem, this study proposed a novel low-light image enhancement algorithm, PromptHDR. Based on Transformer architecture, the algorithm effectively suppresses color distortion caused by non-uniform illumination through a Lighting Extraction Module, while simultaneously introducing a Prompt block incorporating a Mamba mechanism to enhance the model’s contextual understanding of the roadway scene and its ability to preserve rock bolt details. Quantitative results demonstrate that the PromptHDR algorithm achieves Peak Signal-to-Noise Ratio (PSNR) and Structural Similarity (SSIM) index scores of 24.19 dB and 0.839, respectively. Furthermore, the enhanced images exhibit more natural visual appearance, adequate brightness recovery, and well-preserved detailed information, establishing a reliable visual foundation for the accurate identification of rock bolts. Full article

To address the challenge of detecting debonding damage in glass-fiber-reinforced polymer (GFRP) rock bolt anchorage structures, this study proposes a time reversal detection method based on piezoelectric sensing and a Convolutional Neural Network–Support Vector Machine (CNN-SVM) model. Through COMSOL 6.1 numerical simulations and laboratory experiments, the influence of debonding length, location, and quantity on the characteristics of detection signals was investigated. The results indicate that an increase in debonding length leads to a rise in the amplitude of the focused signal, a reduction in the main peak frequency, and greater energy concentration around the main peak. Specifically, the amplitude increased by 10.96% (simulations) and 54.9% (experiments) for lengths from 0 to 1200 mm, while the peak frequency decreased by 3.43% (simulations) or increased slightly (experiments). When the debonding location changes, the amplitude remains stable, while the main peak frequency increases by 4.94% in simulations and shifts to higher frequencies experimentally, and the energy exhibits an increasing trend. An increase in the number of debonding points results in decreased amplitude, elevated main peak frequency, and more severe wave packet overlap. Multi-defect configurations reduced the amplitude by 16.68% (simulations) and 3% (experiments), with peak frequency increases of up to 3.35%. Based on these characteristics, a CNN-SVM evaluation model was constructed, using the wavelet time–frequency maps of experimental signals as input and the debonding state as output. The model achieved evaluation accuracy rates of 99%, 100%, and 100% under varying debonding lengths from 10 to 100 mm, different debonding positions, and increasing numbers of debonding defects, all exceeding 95%, thereby validating the reliability and high precision of the proposed method. Full article

This study follows the Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) framework, combining bibliometric mapping and mechanistic synthesis to provide a unified evidence-based review of cementitious grouts in ground support systems. The bibliometric layer quantifies global research activity, while the systematic synthesis interprets how material composition, pozzolanic chemistry, and rheology control grout performance and sustainability. This study presents a systematic review complemented by bibliometric analysis to synthesise global research trends and technical advances in grout design. A dataset of 1200 articles was screened, from which 101 journal papers met the inclusion and quality criteria and were analysed in detail. Co-occurrence mapping of author keywords was then used to identify research hotspots and collaborative structures. The bibliometric analysis revealed that Construction and Building Materials is the leading outlet. Co-authorship mapping highlighted strong international collaboration, with leading clusters centred on supplementary cementitious materials, rheology, and microstructural analysis. The technical review consolidates five interrelated themes: reinforcement mechanisms, cementitious grouts, chemical reactions and pozzolanic reactivity, fresh and hardened state properties, and microstructural development with rheological behaviour. Across these themes, supplementary cementitious materials and waste-derived binders have emerged as central to both performance enhancement and carbon reduction, while advanced experimental and modelling techniques have refined understanding of microstructural evolution and grout–rock–bolt interactions. Collectively, the findings underline that cementitious grouts are no longer passive fillers but engineered composites designed for mechanical efficiency, durability, and environmental responsibility. Key research gaps remain in the standardisation of rheological testing, long-term durability under complex field conditions, and integration of life-cycle assessment into grout development. Addressing these challenges will be critical for the design of next-generation grouts capable of meeting the dual imperatives of safety and sustainability in mining and civil engineering. Full article

This study addresses the stability and deformation control of the Xiling auxiliary shaft in the Sanshandao Gold Mine during excavation, under the complex geological conditions of high in situ stress, high pore pressure, and elevated geothermal gradients. A thermal–hydraulic–mechanical (THM) coupling numerical model is developed to investigate the stress distribution, deformation mechanisms, and long-term stability of the surrounding rock under multi-physical interactions. Meanwhile, the influence of excavation rate on rock stability is analyzed. The results indicate that excavation induces significant stress redistribution, with stress concentrations in high-elastic-modulus strata, where the maximum compressive and tensile stresses reach 15.9 MPa and 14.1 MPa, respectively. The maximum displacement occurs in low-stiffness rock layers (around 1400 m depth), with a total magnitude of 1139 mm, primarily resulting from unloading relaxation, pore pressure reduction, and thermal contraction. Excavation rate strongly affects the temporal evolution of deformation: faster excavation leads to greater instantaneous displacements, whereas slower excavation suppresses displacement due to the sustained influence of thermal contraction. Based on these findings, particular attention should be paid to the low-stiffness strata near 1400 m depth during the construction of the Xiling auxiliary shaft. A combined support system consisting of high-prestress rock bolts, lining, and grouting is recommended for deformation-concentrated zones, while excavation rates should be optimized to balance efficiency and safety. Furthermore, long-term monitoring of temperature, pore pressure, and displacement is essential to achieve dynamic risk control. These results provide valuable theoretical and engineering insights for the safe construction and stability management of deep mine shafts. Full article

In response to the challenges of surrounding-rock control in deep high-stress roadways, this study focuses on a synergistic support system of actively tensioned prestressed bolts and cables. Utilizing a combination of theoretical analysis, numerical simulation, and field testing, a coupled load-bearing mechanism and the methodology for determining appropriate pre-tension were systematically investigated. A mechanical model of the anchored composite system was established, revealing the synergistic support mechanism between actively tensioned prestressed bolts and cables. Theoretical calculation formulas for the load-bearing strength of the anchored composite system under both individual and combined support conditions were derived. By analyzing the in situ stress environment of the surrounding rock, a calculation method was derived for the threshold of constraint strength required for the anchored composite system to maintain roadway stability; this threshold is directly related to the magnitude of the primary rock stress. Based on this, a support design criterion was established, centered on the equilibrium relationship between the constraint strength threshold and the bearing strength of the anchored composite system. This criterion can be used to evaluate the feasibility of support schemes, assess the rationality of applied pre-tension, and determine the reasonable matching range for the pre-tension of bolts and cables through a bivariate function defining their respective thresholds. Finally, using the transportation roadway Working Face 4209 as an engineering case, the feasibility and reliability of the proposed theoretical model and design method were verified through numerical simulations and field tests, providing a theoretical basis and practical reference for the supportive design of high-stress roadways. Full article

This paper concerns the issue of selecting appropriate stress field parameters for predicting the stability of headings driven under the geological and mining conditions of Polish underground copper mines. The problem is of key importance due to strict safety requirements in mine workings that serve ventilation and transport functions. Numerical analyses were carried out for four stress field variants: the stress state determined based on Bulin’s formulas (variant 1), the hydrostatic stress state (variant 2), and stress states determined from in situ measurements conducted in the Rudna mine (variant 3 and variant 4). Numerical simulations were performed for a group of four headings, supported with fully grouted rock bolts, in the geological and mining conditions of the Rudna mine. Stability assessment was performed using the finite element method (FEM). Rock mass input parameters for the modeling were obtained with RocLab 1.0, applying the Hoek–Brown classification, while numerical analyses employed the Mohr–Coulomb failure criterion. The elastic–plastic model with softening was used to describe the rock mass behaviour. Numerical calculations were conducted in the RS2 computer program in a triaxial stress state and in a plane strain state. The range of the yielded rock mass zone in the roof of the headings was assumed as the optimal measure of the headings stability. The obtained simulation results provided a basis for recommending suitable rock bolting systems to protect the stability of headings developed under various initial stress field conditions. Full article

The rapid development of transportation infrastructure in challenging geological regions necessitates innovative tunneling methods that balance efficiency, safety, and cost. This study addresses the critical construction bottleneck of large-span soft rock tunnels under high ground stress, where conventional methods often lead to unacceptable delays. Focusing on a 24.53 m span railway tunnel in southwest China, we present the significant engineering application of a “pilot-tunnel-first” method as a strategic solution to stringent schedule pressures. The core innovation lies not only in the adoption of a large 13.2 m wide pilot tunnel but also in a synergistically enhanced support system, featuring elongated bolts (6 m and 12 m) and strengthened steel arches. Numerical simulations and field validation confirmed that this optimized approach achieves a stability comparable to the traditional double-side drift method while dramatically accelerating progress. The successful implementation shortened the construction period by 1.96 months for a key 123 m section, with a manageable cost increase of approximately Chinese Yuan (CNY) 782,000, thereby ensuring the timely opening of the entire tunnel. The primary significance of this research is to provide a proven and practical technical strategy for overcoming similar soft rock tunneling challenges where project timelines are paramount, offering a substantial value for the design and construction of modern infrastructure under complex constraints. Full article

In deep coal mines characterized by high temperature, high humidity, high-salinity water, and elevated ground stress, stress corrosion cracking (SCC) of bolts is widespread, causing frequent instability of roadway surrounding rock and hindering long-term stability. This study systematically examines the failure characteristics of anchorage materials in highly corrosive roadways and clarifies the effects of deep-mine temperature and humidity on material corrosion. Long-term corrosion tests on bolts reveal changes in mechanical properties and macroscopic morphology and elucidate the intrinsic mechanisms of SCC. The results show that with the increase in corrosion time, the yield strength, ultimate load and elongation of the anchor rod decrease by up to 11.8%, 13.6%, and 7.08%, respectively. Under high stress, localized corrosion pits form on bolt surfaces, rupturing the oxide film and initiating rapid anodic dissolution and cathodic hydrogen evolution. Interaction between corroded surfaces and microcracks produced by internal impurities leads to progressive damage accumulation and ultimate fracture of the bolts. These findings provide guidance for corrosion protection of coal mine roadway support materials and for improving the long-term performance of roadway supports. Full article

To optimize the support performance of rock bolts in high-stress environments, this study employs the ANSYS (Version 2022 R2) finite element numerical simulation method to systematically investigate the influence of bolt geometrical parameters (rib spacing, rib height, and bolt diameter) on the stress state of the anchoring system. A bolt–resin–sleeve model was established to analyze Mises equivalent stress distribution and peaks under a 150 kN pull-out load. The simulation results indicate that a rib spacing of 36 mm effectively promotes the diffusion of pre-stress into deeper regions, with peak stress in the bolt rod and resin ring increasing by 34.42% and 61.64%, respectively, compared to a spacing of 12 mm. Further increase in rib spacing provides limited enhancement in peak stress. A rib height of 1.0 mm achieves optimal system performance without excessively compromising the interfacial stress level. Increasing the diameter to 22 mm raised peak stress in the bolt, sleeve, and resin by 14.19%, 30.48%, and 50.77%, respectively, compared to 18 mm, balancing load capacity and material use efficiently. The optimal parameter set (36 mm spacing, 1.0 mm height, and 22 mm diameter) was validated in a field trial in Zhongmacun Mine’s 3903 East Transportation Bottom Drainage Roadway. Monitoring recorded maximum roof subsidence of 102.9 mm, stabilizing within 25 days (daily deformation < 0.2 mm), confirming the excellent performance of the bolt support system with this parameter combination in high-stress roadways. This study provides a theoretical basis and engineering reference for the optimal design of high-performance rock bolts. Full article

Corrosion of rock bolts in engineering exhibits random spatial distribution characteristics. To elucidate the influence mechanism of stochastic corrosion on the surface of rock bolts on the propagation behavior of ultrasonic guided waves, this study establishes a finite element model of rock bolts that incorporates stochastic corrosion characteristics. The coupled effects of corrosion depth and area ratio on guided wave propagation characteristics, time-domain response, energy distribution, and wave velocity variation are systematically investigated. Results indicate that corrosion depth and area ratio synergistically deteriorate guided wave morphology, transforming the stress field from symmetric and uniform to asymmetric and spiral. Reflections, scattering, and mode conversion induced by defects lead to a significant increase in the attenuation rate of pulse amplitude, with the two parameters governing the vertical interaction intensity and horizontal interference scope, respectively. Analysis of the Hilbert curve reveals that corrosion characteristics disrupt energy concentration. Under constant corrosion depth, an increase in area ratio disperses energy toward delayed scattered waves, while under constant area ratio, greater corrosion depth reduces the peak amplitude of the envelope curve. Overall, the energy integral exhibits an increasing trend with the degree of corrosion, whereas the peak-to-peak wave velocity shows a declining trend. The established multivariate nonlinear model accurately describes the coupled influence of corrosion parameters on wave velocity. This stochastic corrosion model overcomes the limitations of traditional simplified models and provides critical theoretical support for parameter calibration and engineering application of ultrasonic guided wave technology in the quantitative assessment of rock bolt corrosion. Full article

To address the challenge of simulating shear failure in anchor bolts within FLAC3D, a shear failure criterion, F_s(i) ≥ F_smax(i), is proposed based on the PILE structural element. Through secondary development using the FISH programming language, a modified mechanical model of the PILE element is established and integrated into the FLAC3D-FISH framework. Comparative analyses are conducted on shear tests of bolt shafts and on anchor bolt support performance under coal–rock interface slip conditions, using both the original PILE model and the modified mechanical model. The results demonstrate that the shear load–displacement curve of the modified PILE model clearly reflects shear failure characteristics, satisfying a quantitative shear failure criterion. Upon failure, both the shear force and axial force of the structural element at the failure point drop abruptly to zero, enabling effective simulation of shear failure in anchor bolts within the FLAC3D environment. Using the modified model, the distribution of principal stress differences in the surrounding rock after roadway excavation is analyzed. Based on this, the concept of a stress-bearing ring in the surrounding rock is introduced. The reinforcing effects of bolt length, spacing, and ultimate load capacity on the stress-bearing ring in weak and fractured surrounding rock are investigated. The findings reveal that: (1) shear failure initiates in bolt shafts near the coal–rock interfaces, occurring earlier near the coal–floor interface than near the coal–roof interface; (2) the stress-bearing ring in weak and fractured surrounding rock shows a discontinuous and uneven distribution. However, with support improvements—such as increasing bolt length, reducing spacing, and enhancing failure load—the surrounding rock gradually forms a continuous stress-bearing ring with more uniform thickness and stress distribution, migrating inward toward the roadway surface. Full article

Fully grouted rock bolts play a vital role in stabilising underground excavations, particularly in corrosive environments where material properties, geometric configuration, and installation conditions influence their load transfer performance. Although the practical importance of fully grouted fibreglass rock bolts is well recognised, quantitative evidence on their axial load transfer mechanisms remains limited. Prior work has primarily centred on steel rock bolts, with few studies on how embedment length, grout stiffness, interface roughness and confining stress govern bond mobilisation in fully grouted fibreglass rock bolts, indicating a clear need for further scientific investigation. This study examines the axial load transfer and shear behaviour of fully grouted fibreglass rock bolts, focusing on the effects of embedment length (EL), grout properties, and boundary conditions. A comprehensive series of laboratory pull-out tests were conducted on two widely used Australian glass fibre reinforced polymer (GFRP) rock bolts, TD22 and TD25, with diameters of 22 mm and 25 mm, respectively, under varying ELs and grout curing times to evaluate their axial performance. Additionally, single shear tests and uniaxial compressive strength (UCS) tests were conducted to assess the shear behaviour of the rock bolts and the mechanical properties of the grout. The results showed that increased EL, bolt diameter, and grout curing time generally enhance axial capacity. With grout curing from day 7 to the day 28, the influence of embedment length became increasingly pronounced, as the axial peak load rose from 35 kN (TD22-50, 7 days) to 116 kN (TD22-150, 28 days) and from 39 kN (TD25-50, 7 days) to 115 kN (TD25-150, 28 days), confirming that both longer bonded lengths and extended curing significantly enhance the axial load-bearing capacity of fully grouted GFRP rock bolts. However, the TD22 rock bolts exhibited superior shear strength and ductility compared to the TD25 rock bolts. Also, a calibrated distinct element model (DEM) was developed in 3DEC to simulate axial load transfer mechanisms and validated against experimental results. Parametric studies revealed that increasing the grout stiffness from 5 e7 N/m to 5 e8 N/m increased the peak load from 45 kN to 205 kN (approximately 350%), while reducing the peak displacement, indicating a shift toward a more brittle response. Similarly, increasing the grout-bolt interface roughness boosted the peak load by 150% (from 60 kN to 150 kN) and enhanced residual stability, raising the residual load from 12 kN to 93.5 kN. In contrast, confining stress (up to 5 MPa) did not affect the 110 kN peak load but reduced the residual load by up to 60% in isotropic conditions. These quantitative findings provide critical insights into the performance of GFRP bolts and support their optimised design for underground reinforcement applications. Full article

Tunnel construction in weak and fractured strata often faces risks such as tunnel face instability and large deformation of surrounding rock, which are difficult to effectively control using conventional support methods. Based on the engineering background of the No. 8# TA Tunnel in the F3 section of Georgia’s E60 Highway, this study employed ADECO-RS and developed a 3D numerical model with finite difference software to simulate full-face tunnel excavation process. The influence of advanced reinforcement measures on the stability of the surrounding rock was systematically investigated. The control effectiveness of different advanced reinforcement schemes was evaluated by comparing the displacement field, stress field, and plastic zone distribution of the surrounding rock under three conditions: no support, advanced pipe roof support, and a combination of pipe roof and glass fiber bolts. A comprehensive quantitative analysis of the synergistic effect of the combined reinforcement was also performed. The results indicated that significant extrusion deformation of the tunnel face and vault settlement occurred after excavation. The pressure arch developed within a range of 17.5 to 22 m above the tunnel vault. The surrounding rock of this tunnel was classified as type B (short-term stable). Deformation primarily occurred within one tunnel diameter ahead of the face, with the deformation rate significantly reduced after support. Advanced pipe roof support effectively restrained surrounding rock deformation, while the combination of advanced pipe roof and glass fiber bolts delivered better performance: reducing final convergence by 73.10%, pre-convergence by 82.69%, and face extrusion by 87.66%. The combined support also contracted the pressure arch boundaries from 17.5 to 22 m to 6–12.5 m, reduced the extent of major principal stress deflection, and significantly shrinks the plastic zone. Glass fiber bolts played a key role in controlling plastic zone expansion and ensuring stability. This study provides theoretical and numerical references for safe construction and advanced support design in tunnels under complex geological conditions. Full article
