This paper presents the analytical model, feasibility assessment, and testing of a novel synchronous reluctance tubular machine, whose mover is manufactured using additive techniques. This approach enables the maximization of the machine’s saliency. The analytical model traditionally used for rotating machines was adapted to match the geometric characteristics of the innovative tubular design proposed in this work. The analytical results were validated through 2D finite element analysis (FEA). Subsequently, several mock-ups were 3D-printed using iron metal powder to evaluate the manufacturing feasibility of the proposed machine. Finally, the machine was tested to verify the accuracy of the analytical model. Full article

Electric mountain bikes (eMTBs) demand compact, high-torque motors capable of handling steep terrain and variable load conditions. Surface-mounted permanent magnet synchronous motors (SPMSMs) are widely used in this application due to their simple construction, ease of manufacturing, and cost-effectiveness. However, SPMSMs inherently lack reluctance torque, limiting their torque density and performance at high speeds. While interior PMSMs (IPMSMs) can overcome this limitation via reluctance torque, they require complex rotor machining and may compromise mechanical robustness. This paper proposes a surface-inset PMSM topology as a compromise between both approaches—introducing reluctance torque while maintaining a structurally simple rotor. The proposed motor features inset magnets shaped with a tapered outer profile, allowing them to remain flush with the rotor surface. This geometric configuration eliminates the need for a retaining sleeve during high-speed operation while also enabling saliency-based torque contribution. A baseline SPMSM design is first analyzed through finite element analysis (FEA) to establish reference performance. Comparative simulations show that the proposed design achieves a 20% increase in peak torque and a 33% reduction in current density. Experimental validation confirms these findings, with the fabricated prototype achieving a torque density of 30.1 kNm/m³. The results demonstrate that reluctance-assisted torque enhancement can be achieved without compromising mechanical simplicity or manufacturability. This study provides a practical pathway for improving motor performance in eMTB systems while retaining the production advantages of surface-mounted designs. The surface-inset approach offers a scalable and cost-effective solution that bridges the gap between conventional SPMSMs and more complex IPMSMs in high-demand e-mobility applications. Full article

This paper deals with an analysis of the operation of switched reluctance machines with a non-uniform air gap. The main focus was on the analysis of the performance of machines with a linearly decreasing air gap. Intensive field calculations made it possible to provide their accurate characteristics, which were then used in simulations of various dynamic states. On this basis, the advantages and disadvantages of machines with a non-uniform air gap were finally discussed from the point of view of applications in efficient high-speed drive systems. Full article

Switched Reluctance Machines (SRMs) are gaining increasing traction within the industrial sector, primarily due to their inherently simple and robust structure. Nevertheless, SRMs are characterized by two major drawbacks—high torque ripple and strong radial forces—both of which render them less suitable for applications requiring smooth operation, such as Electric Vehicles (EVs). To address these limitations, researchers and designers focus on optimizing these critical performance metrics during the design phase. In recent years, the concept of System-Level Design Optimization (SLDOM) has been introduced and applied to SRM drive systems, where both the machine and the controller are simultaneously considered within the optimization framework. This integrated approach has shown significant improvements in mitigating the aforementioned issues. This paper aims to review the existing literature concerning the SLDOM applied to SRMs, highlighting the key methodologies and findings from studies conducted in recent years. Despite its promising outcomes, the adoption of SLDOM remains limited due to its high computational cost and complexity. In response to these challenges, the paper discusses complementary techniques used to enhance the optimization process, such as search space and computational time reduction strategies, along with the associated challenges and potential solutions. Finally, two critical directions for future research are identified, which are expected to influence the development of the SLDOM and its application to SRMs in the coming years. Full article

An area of study for reluctance motors is the analytical computation of their magnetic field distribution, from which other quantities, such as phase inductances and output torque, may be derived. While numerical or iterative methods exist, analytical derivations of reluctance motor magnetic fields from first principles result in solutions that are less time-consuming to implement while requiring only the motor dimensions, without the need to re-discretize the motor model. A discussion of analytical derivations is scarce in the current literature, whose focus is usually on their direct application in various motor models. This work, then, aims to review and examine the major mathematical techniques and assumptions used to derive the magnetostatic field distribution in reluctance motors. The methods under review are air gap permeance, magnetic potential, and conformal mapping techniques, and they are applied to machines with conventional structures. Other relevant approaches that can extend these techniques are also presented. Segmented motor designs have also emerged given their advantages, so they must be systematically studied. These segmented topologies may require a new set of boundary conditions before these techniques can be applied. Thus, the methods’ possible avenues of application to segmented motors are discussed as well. Full article

This paper proposes a novel nine-phase ferrite-assisted synchronous reluctance machine (FA-SynRM) featuring skewed stator slots to address challenges related to harmonic distortion, torque ripple, and material sustainability which are prevalent in conventional permanent magnet-assisted synchronous reluctance motors (PMa-SynRMs). Existing PMa-SynRMs often suffer from increased torque ripples and harmonic distortion, while reliance on rare-earth materials raises cost and sustainability concerns. To address these issues, the proposed design incorporates low-cost ferrite magnets embedded within the rotor flux barriers to achieve a flux-concentrated effect and enhanced torque production. The nine-phase winding configuration is utilized to improve fault tolerance, reduce harmonic distortion, and enable smoother torque output compared with conventional three-phase counterparts. In addition, the skewed stator slot design further minimizes harmonic components, reducing overall distortion. The proposed machine is validated through finite element analysis (FEA), and experimental verification is obtained by measuring the inductance characteristics and back-EMF of the nine-phase winding, confirming the feasibility of the electromagnetic design. The results demonstrate significant reductions in harmonic distortion and torque ripples, verifying the potential of this design. Full article

Currently, electric machines predominantly rely on costly rare-earth NdFeB magnets, which pose both economic and environmental challenges due to rising demand. This research explores recent advancements in machine topologies and magnetic materials to identify and assess promising solutions to this issue. The study investigates two alternative machine topologies to the conventional permanent magnet synchronous machine (PMSM): the permanent magnet-assisted synchronous reluctance machine (PMaSynRM), which reduces magnet usage, and the wound-field synchronous machine (WFSM), which eliminates magnets entirely. Additionally, the potential of ferrite and recycled NdFeB magnets as substitutes for primary NdFeB magnets is evaluated. Through detailed simulations, the study compares the performance and cost-effectiveness of these solutions against a reference permanent magnet synchronous machine (PMSM). Given their promising performance characteristics and potential to reduce or eliminate the use of rare-earth materials in next-generation electric machines, it is recommended that future research should focus on novel topologies like hybrid-excitation, axial-flux, and switched reluctance machines with an emphasis on manufacturability and also novel magnetic materials such as FeN and MnBi that are currently seeing synthesis challenges. Full article

In this paper, an improved online torque compensation strategy considering phase torque-generation capability is proposed to enhance the conventional torque-sharing function (TSF), thus reducing torque ripple for switched reluctance machines (SRMs). The improvements are mainly attributed to two aspects: First, the phase turn-on angle and TSF starting angle are separated. Thus, the phase turn-on angle can be advanced independently to enhance the torque-generation capability of the incoming phase. Second, to generate the desired torque with minimum current, the torque per ampere (TPA) characteristic is considered for commutation region separation. This can ensure that in each separated region, the phase with a stronger torque-tracking ability is utilized for torque error compensation. Accordingly, efficiency is not sacrificed. In addition to improving the TSF, a direct instantaneous torque control (DITC) method combined with a PWM regulator is proposed to reduce large torque increments due to the limited control frequency. As a result, the torque ripple can be further suppressed. Finally, an experimental setup is established, and tests are conducted under different working conditions. The results demonstrate the effectiveness of the proposed method. Full article

This study proposes a rotational speed measurement machine based on the flux-switching principle with a 6-stator-slot/19-rotor-pole (6s/19p) topology. With a rotor shape similar to a variable reluctance sensor (VRS), the proposed machine features a simple and robust structure while ensuring the same output frequency as VRS. Additionally, compared to the conventional 12s/10p topology, the 6s/19p configuration reduces permanent magnet (PM) consumption by half while maintaining high induced voltage characteristics. A nonlinear analytical model (NAM), which incorporates the harmonic modeling (HM) technique and an iterative process, is presented. This model more accurately captures the rectangular shape of the PM and stator teeth while accounting for core saturation effects. Based on this model, the optimal dimensions of the proposed machine are investigated to achieve the best performance for speed measurement applications. A coupling FEA simulation between Ansys Maxwell and Twin Builder further analyzes the machine’s performance. Compared to a commercial product of the same size, the proposed machine achieves 31.5% higher output voltage while ensuring lower linearity errors. Moreover, superior load characteristics are observed, with a voltage drop of only 1.58% at 1500 rpm and 30 mA. The proposed machine and NAM provide an improved solution and analytical tool for speed measurement applications. Full article

The present paper proposes a new Maximum Torque Per Ampere (MTPA) algorithm applied to sensorless speed control for the Synchronous Reluctance Machine (SynRM). The SynRM mathematical model is suitably modified and expressed in the γδ estimated reference frame, which could be applied in sensorless implementations. In the controller–observer scheme, an MTPA controller is coupled with a sliding mode observer (SMO) of first order. The provided equivalent control inputs are directly utilized by a modified EMF observer to estimate the rotor speed and position. Also, the MTPA control, SMO, and modified EMF observer are accordingly expressed in the γδ reference frame. In the duration of the SynRM operation, the developed MTPA algorithm succeeds in adjusting both stator current components in the γ-axis and δ-axis to the maximum torque point, while the SMO converges rapidly, achieving the coincidence between the γδ and dq reference frames. In addition, a simple torque decoupling technique is used to determine the γ-axis and δ-axis reference currents connected with the Anti-Windup Controller (AWC) for stator current control. Despite conventional MTPA methods, the proposed MTPA control strategy is designed to be robust in a wide speed range, exhibiting a high dynamic performance, regardless of the presence of external torque disturbances, reference speed variation, and even current measurement noise. The performance of the overall observer–control system is examined and evaluated using MATLAB/Simulink and considering noisy current feedback. Simulation results demonstrate the robustness and effectiveness of the proposed MTPA-based control method. Full article

This study explores the speed adjustment characteristics of the adaptive control of estimated single-layer Bi-channel neural networks (NNs) for Variable Reluctance Motor (VRM) drives. The innovative algorithm incorporates an estimation method to manage the nonlinear behavior of a VRM through a collection of Bi-channel NNs nodes. Each node acts as a single-layer Bi-channel NNs controller at a local linear operating point extending across the nonlinear surface of the system. Although this algorithm demonstrates strong tracking performance, a significant challenge arises from the motor speed being integrated into the machine model, which means that the controller is directly influenced by speed variations. This results in a sluggish speed adjustment response due to the learning process involved. To address this challenge, a grid of NNs must update the NNs-matrices whenever rotational speed changes. Finally, a simulation of the proposed novel speed control has been conducted to illustrate the speed adjustment behavior of the VRM under various operating conditions and to validate the effectiveness of the control approach. Full article

Several studies have focused on modeling and analyzing the impact of rotor faults in conventional low-pole-count machines, while related research on low-speed high-torque (LSHT) machines with a high pole count remains limited. In these machines, the combination of low speed, high inertia, and high torque levels presents a critical application for advanced diagnosis techniques. The present paper aims to describe and quantify the impact of rotor faults on the performance of LSHT machine types during the design stage. Specifically, 10-pole and 16-pole synchronous reluctance machines (SynRMs), permanent magnet synchronous machines (PMSMs), and squirrel-cage induction machines (SCIMs) are assessed by means of detailed 2D simulations. The effects of eccentricity, broken rotor bars, and partial demagnetization are studied, with a focus on performance variations. The results show that LSHT PMSMs are not significantly affected by the partial demagnetization of a few magnets, and the same holds true for common faults in SynRMs and SCIMs. Nonetheless, a significant increase in torque ripple was observed for all evaluated faults, with different origins and diverse effects on the torque waveform, which could be hard or invasive to analyze. Furthermore, it was concluded that specialized diagnosis techniques are effectively required for detecting the usual faults in LSHT machines, as their effect on major performance indicators is mostly minimal. Full article

In this paper, a new sensorless approach is proposed to address the speed and position estimation of the Synchronous Reluctance Machine (SynRM). The design of the sensorless control algorithm is developed on the basis of the modified SynRM mathematical model employing a simple sliding mode observer (SMO) and a modified EMF observer that are connected in series. All variables of the modified SynRM model are expressed in the arbitrary rotating frame, which is the so-called estimated γδ reference frame. The derived modified rotor flux terms contain angle error information in the form of trigonometric functions. Initially, the modified rotor flux is expressed as a function of saliency and the stator current i_d, including the angular deviation between the dq and γδ reference frames, which are rotating at synchronous and estimated speeds, respectively. A suitably designed SMO is utilized to estimate the modified stator flux components in the γδ reference frame. Once the SMO operates in sliding mode, the derived equivalent control inputs of the flux/current observer are used to obtain the required angular position and speed information of rotor by means of the modified EMF and Speed/Position observer. Only measures of stator voltages and currents are required for the speed and position estimation. In addition, Lyapunov Candidate Functions (LCFs) have been applied to determine the sliding mode existence conditions and the gains of the modified EMF observer. The SynRM observer–controller system is tested and evaluated in a wide speed range, even at very low speeds, in the presence of torque load disturbances. Simulation results demonstrate the overall efficacy and robustness of the proposed sensorless approach. Moreover, simulation tests verify the fast convergence and high performance of the modified EMF/speed/angle observer. Full article

Variable Flux Reluctance Machines (VFRMs) face multiple interconnected challenges that limit their performance, particularly in high-performance applications such as electric vehicles (EVs), where smooth torque output and robust operation are critical. Chief among these challenges are complex inter-axis couplings, including cross-coupling in the dq-axis, differential term coupling in the d0-axis, and disturbances propagating from the 0-axis to the q-axis. Additionally, harmonic disturbances associated with torque ripple exacerbate performance issues, resulting in degraded dynamic behavior. These challenges hinder current loop controllers, preventing effective management of winding impedance voltage drops and inter-axis coupling terms without advanced decoupling strategies. To address these challenges, this paper proposes a novel integrated torque harmonic extended state observer (ITHESO) within a decoupled current control designed to ensure fast and accurate current tracking, system stability, and torque ripple reduction. The ITHESO identifies and compensates for total current disturbances, including harmonic components, through feed-forward compensation within the current loop. Furthermore, the influence of control parameters and the effects of parameter mismatches on stability, torque ripple reduction, and disturbance rejection are thoroughly analyzed. Experimental validations demonstrate that the proposed strategy significantly enhances torque dynamics and reduces torque ripple, outperforming the conventional Active Disturbance Rejection Control (ADRC), which does not explicitly address disturbances associated with torque ripple. These advancements position the VFRM with the ITHESO as a competitive option for high-performance EV propulsion systems, offering smooth operation, noise reduction, and reliable performance under varying speeds and loads. Full article

In this paper, the performance of a Dual-Stator Winding Synchronous Reluctance Generator (SynRG) suitability for off-grid wind power generation is analyzed. The rotor of the SynRG has a slitted-rotor core to improve selected vital performance parameters. The SynRG with a slitted-rotor core was modeled using a two-dimensional (2D) Finite Element Method (FEM) to study the electromagnetic performance of key parameters of interest. To validate the FEA results, a prototype of the SynRG with a slitted rotor was tested in the laboratory for no-load operation and load operation for unity, lagging, and leading power factors. To evaluate the capability of the SynRG with a slitted-rotor core to operate in a wind turbine environment, the machine was modeled and simulated in Matlab/Simulink (R2023a) for dynamic responses. The FEA results reveal that the SynRG with a slitted-rotor core, compared with the conventional SynRG with the same ratings and specifications, reduces the torque ripple by 24.51%, 29.72%, and 13.13% when feeding 8 A to a load with unity, lagging, and leading power factors, respectively. The FEA results also show that the induced voltage on no-load of the SynRG with a slitted-rotor core, compared with the conventional SynRG of the same ratings and specifications, increases by 10.77% when the auxiliary winding is fed by a capacitive excitation current of 6 A. Furthermore, the same results show that with a fixed excitation capacitive current of 6 A, the effect of armature reaction of the SynRG with a slitted-rotor core is demagnetizing when operating with load currents having a lagging power factor, and magnetizing when operating with load currents having unity and leading power factors. The same patterns have been observed in the experimental results for different excitation capacitance values. The Matlab/Simulink results show that the SynRG with a slitted-rotor core has a quicker dynamic response than the conventional SynRG. However, a well-designed pitch-control mechanism for the wind turbine is necessary to account for changes in wind speeds. Full article
