Breast cancer detection through non-invasive and accurate techniques remains a critical challenge in medical diagnostics. This study introduces a deep learning-based framework that leverages a microwave radar system equipped with an arc-shaped array of six antennas to estimate key tumor parameters, including position, size, and depth. This research begins with the evolutionary design of an ultra-wideband octagram ring patch antenna optimized for enhanced tumor detection sensitivity in directional near-field coupling scenarios. The antenna is fabricated and experimentally evaluated, with its performance validated through S-parameter measurements, far-field radiation characterization, and efficiency analysis to ensure effective signal propagation and interaction with breast tissue. Specific Absorption Rate (SAR) distributions within breast tissues are comprehensively assessed, and power adjustment strategies are implemented to comply with electromagnetic exposure safety limits. The dataset for the deep learning model comprises simulated self and mutual S-parameters capturing tumor-induced variations over a broad frequency spectrum. A core innovation of this work is the development of the Attention-Based Feature Separation (ABFS) model, which dynamically identifies optimal frequency sub-bands and disentangles discriminative features tailored to each tumor parameter. A multi-branch neural network processes these features to achieve precise tumor localization and size estimation. Compared to conventional attention mechanisms, the proposed ABFS architecture demonstrates superior prediction accuracy and interpretability. The proposed approach achieves high estimation accuracy and computational efficiency in simulation studies, underscoring the promise of integrating deep learning with conformal microwave imaging for safe, effective, and non-invasive breast cancer detection. Full article

In this study, a novel improved ultra-wideband (UWB) antipodal Vivaldi antenna suitable for breast cancer detection via microwave imaging was designed. The antenna was made more directional by adding three pairs of nestings to the antenna fins by adding elliptical patches. The frequency operating range of the proposed antenna is UWB 3.6–13 GHz, its directivity is 11 dB, and its gain is 9.27 dB. The antenna is designed with FR4 dielectric material and dimensions of 34.6 mm × 33 mm × 1.6 mm. It was demonstrated that the bandwidth, gain, and directivity of the proposed antenna meet the requirements for UWB radar applications. The Vivaldi antenna was tested on an imaging system developed using the CST Microwave Studio (CST MWS) program. In CST MWS, a hemispherical heterogeneous breast model with a radius of 50 mm was created and a spherical tumor with a diameter of 0.9 mm was placed inside. A Gaussian pulse was sent through Vivaldi antennas and the scattered signals were collected. Then, adaptive Wiener filter and image formation algorithm delay-multiply-sum (DMAS) steps were applied to the reflected signals. Using these steps, the tumor in the breast model was scanned at high resolution. In the simulation application, the tumor in the heterogeneous phantom was detected and imaged in the correct position. A monostatic radar-based system was implemented for scanning a breast phantom in the prone position in an experimental setting. For experimental measurements, homogeneous (fat and tumor) and heterogeneous (skin, fat, glandular, and tumor) breast phantoms were produced according to the electrical properties of the tissues. The phantoms were designed as hemispherical with a diameter of 100 mm. A spherical tumor tissue with a diameter of 16 mm was placed in the phantoms produced in the experimental environment. The dynamic range of the VNA device used allowed us to image a 16 mm diameter tumor in the experimental setting. The developed microwave imaging system shows that it is suitable for the early-stage detection of breast cancer by scanning the tumor in the correct location in breast phantoms. Full article

This systematic literature review investigates microstrip antenna applications in image acquisition, focusing on their design characteristics, reconstruction algorithms, and application areas. We applied the PRISMA methodology for article selection. From selected studies, classifications were identified based on antenna patch geometry, substrate types, and image reconstruction algorithms. According to inclusion criteria, a significant increase in publications on this topic has been observed since 2013. Considering this trend, our study focuses on a 10-year publication range, including articles up to 2023. Results indicate that medical applications, particularly breast cancer detection, dominate this field. However, emerging areas are gaining attention, including stroke detection, bone fracture monitoring, security surveillance, avalanche radars, and weather monitoring. Our study highlights the need for more efficient algorithms, system miniaturization, and improved models to achieve precise medical imaging. Visual tools such as heatmaps and box plots are used to provide a deeper analysis, identify knowledge gaps, and offer valuable insights for future research and development in this versatile technology. Full article

In the ever-evolving landscape of tomographic imaging algorithms, this literature review explores a diverse array of themes shaping the field’s progress. It encompasses foundational principles, special innovative approaches, tomographic implementation algorithms, and applications of tomography in medicine, natural sciences, remote sensing, and seismology. This choice is to show off the diversity of tomographic applications and simultaneously the new trends in tomography in recent years. Accordingly, the evaluation of backprojection methods for breast tomographic reconstruction is highlighted. After that, multi-slice fusion takes center stage, promising real-time insights into dynamic processes and advanced diagnosis. Computational efficiency, especially in methods for accelerating tomographic reconstruction algorithms on commodity PC graphics hardware, is also presented. In geophysics, a deep learning-based approach to ground-penetrating radar (GPR) data inversion propels us into the future of geological and environmental sciences. We venture into Earth sciences with global seismic tomography: the inverse problem and beyond, understanding the Earth’s subsurface through advanced inverse problem solutions and pushing boundaries. Lastly, optical coherence tomography is reviewed in basic applications for revealing tiny biological tissue structures. This review presents the main categories of applications of tomography, providing a deep insight into the methods and algorithms that have been developed so far so that the reader who wants to deal with the subject is fully informed. Full article

Novel techniques, such as microwave imaging, have been implemented in different prototypes and are under clinical validation, especially for breast cancer detection, due to their harmless technology and possible clinical advantages over conventional imaging techniques. In the prospective study presented in this work, we aim to investigate through a multicentric European clinical trial (ClinicalTrials.gov Identifier NCT05300464) the effectiveness of the MammoWave microwave imaging device, which uses a Huygens-principle-based radar algorithm for image reconstruction and comprises dedicated image analysis software. A detailed clinical protocol has been prepared outlining all aspects of this study, which will involve adult females having a radiologist study output obtained using conventional exams (mammography and/or ultrasound and/or magnetic resonance imaging) within the previous month. A maximum number of 600 volunteers will be recruited at three centres in Italy and Spain, where they will be asked to sign an informed consent form prior to the MammoWave scan. Conductivity weighted microwave images, representing the homogeneity of the tissues’ dielectric properties, will be created for each breast, using a conductivity = 0.3 S/m. Subsequently, several microwave image parameters (features) will be used to quantify the images’ non-homogenous behaviour. A selection of these features is expected to allow for distinction between breasts with lesions (either benign or malignant) and those without radiological findings. For all the selected features, we will use Welch’s t-test to verify the statistical significance, using the gold standard output of the radiological study review. Full article

In this study, neurocomputational models are proposed for the acquisition of radar-based microwave images of breast tumors using deep neural networks (DNNs) and convolutional neural networks (CNNs). The circular synthetic aperture radar (CSAR) technique for radar-based microwave imaging (MWI) was utilized to generate 1000 numerical simulations for randomly generated scenarios. The scenarios contain information such as the number, size, and location of tumors for each simulation. Then, a dataset of 1000 distinct simulations with complex values based on the scenarios was built. Consequently, a real-valued DNN (RV-DNN) with five hidden layers, a real-valued CNN (RV-CNN) with seven convolutional layers, and a real-valued combined model (RV-MWINet) consisting of CNN and U-Net sub-models were built and trained to generate the radar-based microwave images. While the proposed RV-DNN, RV-CNN, and RV-MWINet models are real-valued, the MWINet model is restructured with complex-valued layers (CV-MWINet), resulting in a total of four models. For the RV-DNN model, the training and test errors in terms of mean squared error (MSE) are found to be 103.400 and 96.395, respectively, whereas for the RV-CNN model, the training and test errors are obtained to be 45.283 and 153.818. Due to the fact that the RV-MWINet model is a combined U-Net model, the accuracy metric is analyzed. The proposed RV-MWINet model has training and testing accuracy of 0.9135 and 0.8635, whereas the CV-MWINet model has training and testing accuracy of 0.991 and 1.000, respectively. The peak signal-to-noise ratio (PSNR), universal quality index (UQI), and structural similarity index (SSIM) metrics were also evaluated for the images generated by the proposed neurocomputational models. The generated images demonstrate that the proposed neurocomputational models can be successfully utilized for radar-based microwave imaging, especially for breast imaging. Full article

This article demonstrates that the complex value of S₁₁ of an antenna, acquired in a multi-monostatic configuration, can be used for localization of a dielectric anomaly hidden inside a dielectric background medium when the antenna is placed close (~5 mm) to the geometry. It uses an Inverse Synthetic Aperture Radar (ISAR) imaging framework where data is acquired at multiple frequencies and look-angles. Initially, near-field scattering data are used for simulation to validate this methodology since the basic derivation of the Multiple Signal Classification (MUSIC) algorithm is based on the plain wave assumption. Later on, from an applications perspective, data acquisition is performed using an antipodal Vivaldi antenna that has eight constant-width slots on each arm. This antenna operates in a frequency range of 1 to 8.5 GHz and its S₁₁ is fed to the 2D MUSIC algorithm with spatial smoothing whereas the antenna artifact and background effect are removed by subtracting the average S₁₁ at each antenna location. Measurements reveal that this methodology gives accurate results with both homogeneous and inhomogeneous backgrounds because the size of data sub-arrays trades between the image noise and resolution, hence reducing the effect of inhomogeneity in the background. In addition to near-field ISAR imaging, this study can be used in the ongoing research on breast tumors and brain stroke detection, among others. Full article

In this paper, a compact, flexible Vivaldi antenna is designed, and an array of nine identical antennas of this type is used as a microwave breast imaging model to detect cancerous tumors in the multilayers phantom model presented in this paper. The nine-antenna array is used to measure the backscattering signal of the breast phantom, where one antenna acts as a transmitter and the other eight antennas act as receivers of the scattered signals. Then, the second antenna is used as a transmitter and the other antennas as receivers, and so on till we have gone through all the antennas. These collected backscattered signals are used to reconstruct the image of the breast phantom using software called “Microwave Radar-based Imaging Toolbox (MERIT)”. From the reconstructed image, the tumor inside the breast model can be identified and located. Different tumor sizes in different locations are tested, and it is found that the locations can be determined irrespective of the tumor size. The proposed modified Vivaldi antenna has a very compact size of 25 × 20 × 0.1 mm³ and has a different geometry compared with conventional Vivaldi antennas. The first version of the antenna has two resonant frequencies at 4 and 9.4 GHz, and because we are interested more in the first band, where it gives us sufficient resolution, we have notched the second frequency by etching two slots in the ground plane of the antenna and adding two rectangular parasitic elements on the radiating side of the antenna. This technique is utilized to block the second frequency at 9.4 GHz, and, as a result, the bandwidth of the first resonant frequency is enhanced by 20% compared with the first design bandwidth. The modified antenna is fabricated on Polyimide flexible material 0.1 mm thick with a dielectric constant of 3.5 using a standard PCB manufacturing process. The measured performance of this antenna is compared with the simulated results using the commercially available simulation software Ansoft HFSS, and it is found that the measured results and the simulated results are in good agreement. Full article

Breast cancer is the most commonly diagnosed cancer type and is the leading cause of cancer-related death among females worldwide. Breast screening and early detection are currently the most successful approaches for the management and treatment of this disease. Several imaging modalities are currently utilized for detecting breast cancer, of which microwave imaging (MWI) is gaining quite a lot of attention as a promising diagnostic tool for early breast cancer detection. MWI is a noninvasive, relatively inexpensive, fast, convenient, and safe screening tool. The purpose of this paper is to provide an up-to-date survey of the principles, developments, and current research status of MWI for breast cancer detection. This paper is structured into two sections; the first is an overview of current MWI techniques used for detecting breast cancer, followed by an explanation of the working principle behind MWI and its various types, namely, microwave tomography and radar-based imaging. In the second section, a review of the initial experiments along with more recent studies on the use of MWI for breast cancer detection is presented. Furthermore, the paper summarizes the challenges facing MWI as a breast cancer detection tool and provides future research directions. On the whole, MWI has proven its potential as a screening tool for breast cancer detection, both as a standalone or complementary technique. However, there are a few challenges that need to be addressed to unlock the full potential of this imaging modality and translate it to clinical settings. Full article

The majority of the aboveground biomass on the Earth’s land surface is stored in forests. Thus, forest biomass plays a critical role in the global carbon cycle. Yet accurate estimate of forest aboveground biomass (FAGB) remains elusive. This study proposed a new conceptual model to map FAGB using remotely sensed data from multiple sensors. The conceptual model, which provides guidance for selecting remotely sensed data, is based on the principle of estimating FAGB on the ground using allometry, which needs species, diameter at breast height (DBH), and tree height as inputs. Based on the conceptual model, we used multiseasonal Landsat images to provide information about species composition for the forests in the study area, LiDAR data for canopy height, and the image texture and image texture ratio at two spatial resolutions for tree crown size, which is related to DBH. Moreover, we added RaDAR data to provide canopy volume information to the model. All the data layers were fed to a Random Forest (RF) regression model. The study was carried out in eastern North Carolina. We used biomass from the USFS Forest Inventory and Analysis plots to train and test the model performance. The best model achieved an R² of 0.625 with a root mean squared error (RMSE) of 18.8 Mg/ha (47.6%) with the “out-of-bag” samples at 30 × 30 m spatial resolution. The top five most important variables include the 95th, 85th, 75th, and 50th percentile heights of the LiDAR points and their standard deviations of 85th heights. Numerous features from multiseasonal Sentinel-1 C-Band SAR, multiseasonal Landsat 8 imagery along with image texture features from very high-resolution imagery were selected. But the importance of the height metrics dwarfed all other variables. More tests of the conceptual model in places with a broader range of biomass and more diverse species composition are needed to evaluate the importance of other input variables. Full article

Purpose: Microwave radar-based breast imaging technology utilizes the principle of radar, in which radio waves reflect at the interface between target and normal tissues, which have different permittivities. This study aims to investigate the feasibility and safety of a portable microwave breast imaging device in clinical practice. Materials and methods: We retrospectively collected the imaging data of ten breast cancers in nine women (median age: 66.0 years; range: 37–78 years) who had undergone microwave imaging examination before surgery. All were Japanese and the tumor sizes were from 4 to 10 cm. Using a five-point scale (1 = very poor; 2 = poor; 3 = fair; 4 = good; and 5 = excellent), a radiologist specialized in breast imaging evaluated the ability of microwave imaging to detect breast cancer and delineate its location and size in comparison with conventional mammography and the pathological findings. Results: Microwave imaging detected 10/10 pathologically proven breast cancers, including non-invasive ductal carcinoma in situ (DCIS) and micro-invasive carcinoma, whereas mammography failed to detect 2/10 breast cancers due to dense breast tissue. In the five-point evaluation, median score of location and size were 4.5 and 4.0, respectively. Conclusion: The results of the evaluation suggest that the microwave imaging device is a safe examination that can be used repeatedly and has the potential to be useful in detecting breast cancer. Full article

Breast cancer diagnosis using radar-based medical MicroWave Imaging (MWI) has been studied in recent years. Realistic numerical and physical models of the breast are needed for simulation and experimental testing of MWI prototypes. We aim to provide the scientific community with an online repository of multiple accurate realistic breast tissue models derived from Magnetic Resonance Imaging (MRI), including benign and malignant tumours. Such models are suitable for 3D printing, leveraging experimental MWI testing. We propose a pre-processing pipeline, which includes image registration, bias field correction, data normalisation, background subtraction, and median filtering. We segmented the fat tissue with the region growing algorithm in fat-weighted Dixon images. Skin, fibroglandular tissue, and the chest wall boundary were segmented from water-weighted Dixon images. Then, we applied a 3D region growing and Hoshen-Kopelman algorithms for tumour segmentation. The developed semi-automatic segmentation procedure is suitable to segment tissues with a varying level of heterogeneity regarding voxel intensity. Two accurate breast models with benign and malignant tumours, with dielectric properties at 3, 6, and 9 GHz frequencies have been made available to the research community. These are suitable for microwave diagnosis, i.e., imaging and classification, and can be easily adapted to other imaging modalities. Full article

Breast microwave sensing (BMS) has been studied as a potential technique for cancer detection due to the observed microwave properties of malignant and healthy breast tissues. This work presents a novel radar-based image reconstruction algorithm for use in BMS that reframes the radar image reconstruction process as an optimization problem. A gradient descent optimizer was used to create an optimization-based radar reconstruction (ORR) algorithm. Two hundred scans of MRI-derived breast phantoms were performed with a preclinical BMS system. These scans were reconstructed using the ORR, delay-and-sum (DAS), and delay-multiply-and-sum (DMAS) beamformers. The ORR was observed to improve both sensitivity and specificity compared to DAS and DMAS. The estimated sensitivity and specificity of the DAS beamformer were 19% and 44%, respectively, while for ORR, they were 27% and 56%, representing a relative increase of 42% and 27%. The DAS reconstructions also exhibited a hot-spot image artifact, where a localized region of high intensity that did not correspond to any physical phantom feature would be present in an image. This artifact appeared like a tumour response within the image and contributed to the lower specificity of the DAS beamformer. This artifact was not observed in the ORR reconstructions. This work demonstrates the potential of an optimization-based conceptualization of the radar image reconstruction problem in BMS. The ORR algorithm implemented in this work showed improved diagnostic performance and fewer image artifacts compared to the widely employed DAS algorithm. Full article

Microwave breast imaging has seen increasing use in clinical investigations in the past decade with over eight systems having being trialled with patients. The majority of systems use radar-based algorithms to reconstruct the image shown to the clinician which requires an estimate of the dielectric properties of the breast to synthetically focus signals to reconstruct the image. Both simulated and experimental studies have shown that, even in simplified scenarios, misestimation of the dielectric properties can impair both the image quality and tumour detection. Many methods have been proposed to address the issue of the estimation of dielectric properties, but few have been tested with patient images. In this work, a leading approach for dielectric properties estimation based on the computation of many candidate images for microwave breast imaging is analysed with patient images for the first time. Using five clinical case studies of both healthy breasts and breasts with abnormalities, the advantages and disadvantages of computational patient-specific microwave breast image reconstruction are highlighted. Full article

Microwave imaging systems are currently being investigated for breast cancer, brain stroke and neurodegenerative disease detection due to their low cost, portable and wearable nature. At present, commonly used radar-based algorithms for microwave imaging are based on the delay and sum algorithm. These algorithms use ultra-wideband signals to reconstruct a 2D image of the targeted object or region. Delay multiply and sum is an extended version of the delay and sum algorithm. However, it is computationally expensive and time-consuming. In this paper, the delay multiply and sum algorithm is parallelised using a big data framework. The algorithm uses the Spark MapReduce programming model to improve its efficiency. The most computational part of the algorithm is pixel value calculation, where signals need to be multiplied in pairs and summed. The proposed algorithm broadcasts the input data and executes it in parallel in a distributed manner. The Spark-based parallel algorithm is compared with sequential and Python multiprocessing library implementation. The experimental results on both a standalone machine and a high-performance cluster show that Spark significantly accelerates the image reconstruction process without affecting its accuracy. Full article
