Raceway bioreactors are widely employed for microalgal production owing to their low construction and operational costs, in addition to their scalability benefits. Nonetheless, limited hydrodynamic studies are corroborated by computer models that have been experimentally validated. This paper delineates the methodology and validation of a computational fluid dynamics (CFD) model for a 10 L laboratory-scale Raceway bioreactor operating under abiotic conditions. In ANSYS Fluent, a multiphase technique was used with the RNG k–ε turbulence model, which is good for simulating flows that are curved or rotating in open-channels. Experimental validation was performed using Particle Image Velocimetry (PIV) at paddlewheel velocities of 20, 25, and 30 rpm. The CFD predictions showed a strong match with the experimental data, with a mean relative error of less than 8%. The examination of the flow field revealed the formation and subsequent reduction of low-velocity zones, depending on the intensity of agitation. Based on study on velocity distribution and Reynolds number, it was suggested that the design be changed so that the paddlewheel be moved to improve flow homogeneity without increasing energy use. The validated CFD model provides a reliable basis for improving the hydrodynamics, design, and operation of Raceway bioreactors. Additionally, it serves as a foundation for future research on biomass cultivation and expansion, facilitating the development of more efficient and sustainable microalgal production technologies. Full article

Excavators are critical equipment in mining, construction, and other fields. The four-point contact slewing bearings used in their slewing mechanisms operate under harsh conditions such as heavy loads and impacts. Furthermore, the bearing rings are prone to elliptical deformation after installation, making them susceptible to premature failure. To address this issue, this paper establishes a mechanical bearing model to investigate the load distribution among balls and the fatigue life of the bearing under elliptical deformation of the rings. It systematically analyzes the influence of key design parameters. The research finds that elliptical deformation of the rings leads to contact angle deviation and a reduction in load-bearing balls, resulting in severe degradation of bearing fatigue life; therefore, its occurrence must be strictly controlled. Designing with a groove curvature radius coefficient within the range of 0.51 to 0.52 achieves an optimal balance between fatigue life and the four-point contact geometry of the balls. There exists an “optimal clearance” that maximizes bearing fatigue life; when considering significant elliptical deformation, the clearance design should be appropriately increased. Increasing the design contact angle enhances load capacity and helps mitigate the effects of elliptical deformation. However, an excessively large contact angle can cause ellipse truncation in the raceway contact zone; thus, the contact angle should be designed based on practical conditions. Increasing the number of balls can improve the influence of ovality on load distribution and enhance the bearing’s fatigue life. This study provides a theoretical reference for the design of high-reliability slewing bearings for excavators. Full article

Modern power transmission systems are required to meet increasingly stringent demands, including a wide range of transmission ratios, compact dimensions, high precision, energy efficiency, reliability, and thermal stability under dynamic operating conditions. Among the solutions that satisfy these requirements, cycloidal reducers are particularly prominent, with their application continuously expanding in industrial robotics, computer numerical control (CNC) machines, and military and transportation systems, as well as in the satellite industry. However, as with all mechanical power transmissions, friction in the contact zones of load-carrying elements in cycloidal reducers leads to power losses and an increase in operating temperature, which in turn results in a range of adverse effects. These undesirable phenomena strongly depend on lubrication conditions, namely on the type and properties of the applied lubricant. Although manufacturers’ catalogs provide general recommendations for lubricant selection, they do not address the fundamental tribological mechanisms in the most heavily loaded contact pairs. At the same time, the available scientific literature reveals a significant lack of systematic and experimentally validated studies examining the influence of lubricant type on the energetic and thermal performance of cycloidal reducers. To address this identified research gap, this study presents an analytical and experimental investigation of the effects of different lubricant types—primarily greases and mineral oils—on the thermal stability and efficiency of cycloidal reducers. The results demonstrate that grease lubrication provides lower total power losses and a more stable thermal operating regime compared to oil lubrication, while oil film thickness analyses indicate that the most unfavorable lubrication conditions occur in the contact between the eccentric bearing rollers and the outer raceway. These findings provide valuable guidelines for engineers involved in cycloidal reducer design and lubricant selection under specific operating conditions, as well as deeper insight into the lubricant behavior mechanisms within critical contact zones. Full article

This study designed a novel coherent tuyere device capable of adjusting the core length of the jet flow. Physical experiments were first conducted to investigate how the number of secondary nozzles in the coherent tuyere affects the gas–solid two-phase flow behavior within the raceway during the blasting process. Subsequently, the Computational Fluid Dynamics (CFD) method was employed to examine the influence of structural parameters on jet morphology in coherent tuyere. Finally, computational fluid dynamics and discrete phase method (CFD-DPM) was adopted, and the velocity, temperature, and composition distribution patterns within the raceway were analyzed following the injection of hydrogen-rich gas through the coherent tuyere. The results of the physics experiment indicate that increasing the number of secondary nozzles in the coherent tuyere can significantly enlarge the raceway size and broaden the particle kinematic zone, thereby enhancing particle fluidization at the periphery of the raceway. CFD numerical simulation results indicate that increasing the number of secondary nozzles of the tuyere can effectively extend the length of the velocity jet core region. Compared with conventional tuyeres, a six-nozzle coherent tuyere can increase the core length of the blast velocity by about 40%. When the diameter of the secondary nozzles in the coherent tuyere is doubled, the core length of the blast velocity increases by 10%. The results of the CFD-DPM coupled simulation show that unburned carbon particles flow and combust along the periphery of the raceway with the hot air, leading to the formation of a high-temperature region in this area. After the injection of hydrogen-rich gas through the coherent tuyere, the temperature in the raceway decreased significantly. A high-concentration region of H₂ appeared at the periphery of the raceway, while the high-concentration CO region increased in concentration and gradually extended toward the upper part of the raceway. This research achievement is of significant importance for optimizing blast furnace blast kinetic energy and hydrogen-rich gas injection. Full article

Hydrogen-rich gas (HRG) injection is a promising low-carbon solution for blast furnace ironmaking. This study conducted numerical simulations in the lower part of a blast furnace to analyze the combustion behavior of coinjected coke oven gas (COG) and pulverized coal (PC) within the raceway and the associated thermal load on the tuyere. A three-dimensional computational fluid dynamics model incorporating fluid–thermal–solid coupling and the GRI-Mech 3.0 chemical kinetic mechanism (validated for 300–2500 K) was established to simulate the lance–blowpipe–tuyere–raceway region. The simulation results revealed that moderate COG injection accelerated volatile release from PC and enlarged the high-temperature zone (>2000 K). However, excessive COG injection intensified oxygen competition and shortened the residence time of PC, ultimately decreasing the burnout rate. Notably, although COG has high reactivity, its injection did not cause an increase in tuyere temperature. By contrast, the presence of an unburned gas layer near the upper wall of the tuyere and the existence of a strong convective cooling effect contributed to a reduction in tuyere temperature. An optimized cooling water channel was designed to enhance flow distribution and effectively suppress localized overheating. The findings of this study offer valuable technical insights for ensuring safe COG injection and advancing low-carbon steelmaking practices. Full article

With the electrification of generator sets, electric locomotives, new energy vehicles, and other industries, AC motors subject bearings to an electric field environment, leading to galvanic corrosion due to the use of variable frequency power supply drives. The phenomenon of bearing discharge breakdown in subway traction motors is a critical issue in understanding the relationship between shaft current strength and the extent of bearing damage. This paper analyzes the mechanism of impulse discharge that leads to galvanic corrosion damage in bearings at a microscopic level and conducts electric thermal coupling simulations of the traction motor bearing discharge breakdown process. It examines the temperature rise associated with lubricant film discharge breakdown during the dynamic operation of the bearing and investigates how breakdown channel parameters and operational conditions affect the temperature rise in the micro-region of bearing lubrication. Ultimately, the results of the electric thermal coupling simulation are validated through experimental tests. This study revealed that in an electric field environment, the load-bearing area of the outer ring experiences significantly more severe corrosion damage than the inner ring, whereas non-bearing areas remain unaffected by electrolytic corrosion. When the inner ring reaches a speed of 4500_rpm, the maximum widths of electrolytic corrosion pits for the outer and inner rings are measured at 89 um and 51 um, respectively. Additionally, the highest recorded temperatures for the breakdown channels in the outer and inner rings are 932 °C and 802 °C, respectively. Furthermore, as the inner ring speed increases, both the width of the electrolytic corrosion pits and the temperature of the breakdown channels rise. Specifically, at inner ring speeds of 2500_rpm, 3500_rpm, and 4500_rpm, the widths of the electrolytic pits in the outer ring raceway load zone were measured at 34 um, 56 um, and 89 um, respectively. The highest temperatures of the lubrication film breakdown channels were recorded as 612 °C, 788 °C, and 932 °C, respectively. This study provides a theoretical basis and data support for the protective and maintenance practices of traction motor bearings. Full article

This study numerically investigates the suitability of biomass particles of varying diameters as alternative reducing agents in the blast furnace raceway zone, where harsh conditions can create internal gradients affecting conversion. An internally resolved 1D Lagrangian particle model, fully integrated into the open-source CFD toolbox OpenFOAM^®, is used to model temperature and species gradients within thermally thick particles. The particle model is coupled with the surrounding Eulerian phase and includes drying, pyrolysis, oxidation, and gasification submodels. Results show that only biomass particles smaller than 250 μm fully convert in the raceway, while larger particles carry unconverted material beyond, potentially reducing blast furnace efficiency. Full article

The oxygen blast furnace (OBF) process presents a promising low-carbon pathway for the smelting of vanadium–titanium magnetite (VTM). This study develops an innovative mathematical model based on mass and heat balance principles, specifically tailored to the OBF smelting of VTM. The model systematically investigates the effects of key parameters—including pulverized coal injection ratio, recycling gas volume, hydrogen content in the recycling gas, and charge composition—on furnace productivity, hearth activity, and the tuyere raceway zone. The results show that increasing the pulverized coal injection ratio slightly reduces productivity and theoretical flame temperature: for every 25 kg/tHM increase in the coal ratio, the theoretical flame temperature decreases by 21.95 °C; moreover, indirect reduction is enhanced and the heat distribution within the furnace is significantly improved. A higher recycling gas volume markedly increases productivity and optimizes hearth thermal conditions, accompanied by enhanced blast kinetic energy and an expanded tuyere raceway zone, albeit with a notable drop in combustion temperature. Increased hydrogen content in the recycling gas promotes productivity, but may weaken blast kinetic energy and reduce the stability of the raceway zone. Furthermore, a higher titanium content in the charge increases the difficulty of iron oxide reduction, resulting in lower CO utilization and reduced productivity. Full article

In aerospace technology, angular contact ball bearings are required to exhibit extremely high operational precision, necessitating real-time monitoring of their wear status to conduct pre-failure analysis. Although extensive studies have been conducted on the wear characteristics of angular contact bearings, further in-depth research is still required to enhance the accuracy of bearing life predictions. To address the imprecision in wear life prediction for angular contact ball bearings, this article proposes a refined wear calculation model based on dynamic load distribution. The model calculates the dynamic load distribution between the inner and outer rings and the raceway under mixed lubrication conditions. Integrating the dynamic load distribution methodology with the wear calculation model, the dynamic contact characteristics of angular contact bearings can be more accurately characterized. Building on this foundation, a dynamic analysis model considering dynamic wear in the bearing contact zone is established. The vibration characteristics of bearings under varying loads are analyzed, and vibration experiments under different load conditions are conducted. Through vibration spectrum analysis, the influence patterns of wear characteristic frequency bands in the wear model on the pre-failure state of bearings are further elucidated. This study provides a theoretical basis for bearing wear life prediction analysis. Full article

This study explores the in situ measurement of contact temperature in thermo-elastohydrodynamic lubrication (TEHL) within cylindrical roller thrust bearings (CRTBs) utilizing vapour-deposited resistive thin-film sensors. The sensors, optimized for compactness and high spatial resolution, were strategically embedded on the stationary bearing raceways near the outer, inner, and mean radius. This configuration enabled a precise measurement of temperature variations in both pure rolling and rolling–sliding regions of the CRTBs. The experimental results revealed a consistent decrease in temperature from the inner and outer radius zones towards the mean radius as the slip-to-roll ratio (SRR) decreased in these regions. Temperature profiles showed an early rise in the inlet zone attributed to thermal inlet shear. At higher speeds, a secondary temperature peak indicative of full-film lubrication was observed in the outlet zone immediately following the Hertzian contact. The study further shows the influence of surface pressure, shear rates, sliding friction, and circumferential speed on contact temperature dynamics, offering insights into their complex interplay. Additionally, viscosity variations due to different oil temperatures were found to critically affect the rate of temperature rise and the propensity for mixed friction phenomena. A higher viscosity resulted in an earlier onset of the temperature rise in the contact, while a lower viscosity and higher speeds promote mixed lubrication, leading to reduced contact film temperatures. These findings provide valuable insights into the behaviour of CRTB-lubricated contacts under various operating conditions and serve as crucial validation data for advanced TEHL computational models. Full article

The traction motor is a crucial component of high-speed electric multiple units, and its operational reliability is directly impacted by the temperature increase in the bearings. To accurately predict and simulate the temperature change process of traction motor bearings during operation, a fluid–solid–thermal simulation analysis model of grease-lubricated deep groove ball bearings was constructed. This model aimed to simulate the temperature rise of the bearing and the grease flow process, which was validated through experiments. The results from the simulation analysis and tests indicate that the temperature in the contact zone between the bearing rolling element and the raceway, as well as the ring temperature, initially increases to a peak and then gradually decreases, eventually stabilizing once the bearing’s heat generation power and heat transfer power reach equilibrium. Furthermore, the established fluid–solid–thermal coupling simulation analysis model can accurately predict the amount of grease required for effective lubrication in the bearing cavity, which stabilizes along with the bearing temperature. The findings of this research can serve as a theoretical foundation and technical support for monitoring the health status of high-speed EMU traction motor bearings. Full article

The CFD/DEM approach was used for investigating the forces playing a role in a furnace raceway formation and stability. The configuration is an actual pilot-scale hot blast furnace filled only with coke particles. In such a system, the raceway was unstable, with successively a growing phase and a collapse. The CFD/DEM numerical simulations were coupled with a core-shrinking model to mimic coke particle combustion. However, the kinetic reactions and heat transfers were not numerically predicted. Instead, the characteristic combustion timescale of one coke particle was imposed, and the combustion zone was adjusted to match the global combustion measured in the pilot-scale experiment. The results showed that the standard contact model was not enough to resist the pressure exerted by the granular weight on the raceway. However, the addition of a cohesive force, through the Johnson-Kendall-Roberts (JKR) model, allowed the qualitative reproduction of the gas pressure fluctuations and the collapse cycles in accordance with the experiment. A sensitivity analysis of the flow rate showed that CFD/DEM is able to reproduce quantitatively the time between two collapses, as observed in the experiment. Predicted raceway size and shapes are also in agreement with the experimental observations in the range of investigated parameters. Full article

The conditions in the combustion zones, i.e., the raceways, are crucial for the operation of the blast furnace. In recent years, advancements in tuyere cameras and image processing and interpretation techniques have provided a better means by which to obtain information from this region of the furnace. In this study, a comprehensive approach is proposed to visually monitor the status of the pulverized coal cloud at the tuyeres based on a carefully designed processing strategy. Firstly, tuyere images are preprocessed to remove noise and enhance image quality, applying the adaptive Otsu algorithm to detect the edges of the coal cloud, enabling precise delineation of the pulverized coal region. Next, a Swin–Unet model, which combines the strengths of Swin Transformer and U-Net architecture, is employed for accurate segmentation of the coal cloud area. The extracted pulverized coal cloud features are analyzed using RGB super-pixel weighting, which takes into account the variations in color within the cloud region. It is demonstrated that the pulverized coal injection rate shows a correlation with the state of the cloud detected based on the images. The effectiveness of this visual monitoring method is validated using real-world data obtained from a blast furnace of SSAB Europe. The experimental results align with earlier research findings and practical operational experience. Full article

For wind turbine applications, there is a cyclic load-varying process between rolling elements and raceways in pitch bearings. This kind of motion can also lead to radial fretting. However, this is seldom addressed under grease-lubricated conditions in the literature. In this study, grease-lubricated point contact problems have been investigated experimentally under cyclic load-varying conditions. The findings revealed that as the load-varying range diminishes, the variation in grease film distribution becomes more subtle and the rate of discharge of thickener fiber clusters in the stick zone decelerates. This is due to the fact that the rate of change in the Hertz contact radius is reduced and the migration of grease is weakened during the unloading process. Due to the large apparent viscosity of grease with a high soap content, entrapped grease is not easily discharged during loading, and the thickness of the film in the stick zone progressively increases as the soap content of the grease is augmented. This also causes the variable load zone to wear out more easily. As the grease is subjected to repeated loading and unloading, there is a gradual reduction in film thickness, and larger thickener fiber clusters tear, resulting in a flattened form and shear thinning. Grease containing sulphur–phosphorus additives demonstrates a superior effect on reducing fretting wear within the large variable load range but generally proves effective for smaller load-varying ranges. This study may offer insights into the degradation of grease under variable load motion and methods to prevent radial fretting wear. Full article

The oxygen blast furnace (OBF) process with top gas recycling is recognized as a promising ironmaking process, due to its high productivity and low CO₂ emissions. The solid flow plays a crucial role in this process. Therefore, the solid flow in OBF was investigated using a cold experimental OBF model in this paper. The results indicate that the plug flow is the primary solid flow pattern in the upper and middle zones of the OBF. A slight convergence flow and a smaller deadman zone were observed at the bosh. The influence of recycled gas on solid flow was found to be quite limited. Additionally, the raceway size affects the burden structure and deadman zone, but the production rate had little impact. Both the raceway size and production rate have different effects on the repose angle of the deadman zone, and it varies by 14–18°. The findings of this study may have important implications for understanding the structure of solid flow in OBF. The results can be used to optimize the process parameters and equipment design to improve the efficiency of iron production while reducing environmental impact. Full article
