Silicon nitride (Si₃N₄) ceramic bearings inevitably contain crack-like defects, yet their compressive capacity degradation and crack-driven failure mechanisms remain unclear. This study proposes a discrete element method (DEM) numerical framework within PFC2D to simulate a bearing containing a single prefabricated crack. First, a bearing DEM model was established and calibrated to reproduce the compressive mechanical response. Then, particle deletion introduced controllable central cracks in the ball and raceway with prescribed inclination angles. Finally, displacement-controlled compression-splitting simulations, serving as a surrogate for a quasi-static overload scenario relevant to quality screening, tracked crack initiation, propagation, and failure modes; under a fixed raceway-crack inclination, crack length was varied to quantify size effects. Results show that a single crack markedly reduces compressive strength. Failure progresses through elastic deformation, crack propagation, and final fracture, with cracks initiating at stress concentrators near crack tips. Crack inclination significantly regulates capacity: raceway cracks are most detrimental near 45°, while ball cracks exhibit an overall decrease in initiation and peak stresses with increasing inclination (with local non-monotonicity). Crack length has a stronger weakening effect than inclination, with accelerated capacity loss beyond 0.3 mm and a pronounced drop in initiation stress beyond 0.6 mm. The framework enables controllable defect parametrization and micro-scale failure interpretation for defect sensitivity assessment under compressive overload. Thus, this study focuses on simulating monotonic fracture events to elucidate fundamental defect–property relationships, which provides a foundation distinct from the prediction of rolling contact fatigue life under cyclic service conditions. Full article

The grinding process of bearing components is a critical step in their manufacturing, as it directly impacts the functional properties of raceways and other critical surfaces. One important failure that arises during the grinding process is the appearance of waviness in the machined surface. This geometrical defect causes vibrations in operation with a consequent impact on power losses, noise and fatigue. The present work proposes an in-line detection system of waviness defects in bearing raceways. For this, the system uses accelerometers installed near the machined part and runs a detection algorithm in a local calculation unit. The results are sent over Ethernet to the central quality control of the line. The embedded algorithm uses the frequency content of the measured signal for predicting the surface quality of the final part. The prediction is performed by learning a non-parametric model describing the correspondence between the surface geometry and the measured vibration content. In order to obtain this model, a calibration process is conducted for each bearing reference, ensuring that the model accounts for the specific geometric and operational characteristics of the parts. By analyzing the correlation between accelerometer signals and harmonics, the algorithm predicts the probability of waviness occurrence. The proposed system has been implemented in a high-precision bearing production line, validating its effectiveness with multiple parts of the same reference. This approach identifies waviness during the machining process without the need for offline tests. This fact represents an improvement in the detection of defects, and it provides higher product quality and reduced operational costs. Full article

In rotating machines, any faults in anti-friction bearings occurring during operation can lead to failures that are unacceptable due to considerable downtime losses and maintenance costs. Hence, early fault detection is essential, and different vibration-based methods (VBMs) are explored to recognise incipient fault signatures. Based on rotordynamics, if a bearing defect causes metal-to-metal (MtM) impacts during shaft rotation, the impacts excite high-frequency resonance responses of the bearing assembly. The defect-related frequencies are modulated with the resonance responses and rely on signal demodulation for fault detection. However, the current study highlights that the bearing fault/faults may not be detected if the defect in a bearing is not causing MtM impacts nor exciting the high-frequency resonance of the bearing assembly. In a roller bearing, a localised defect may maintain persistent contact between rolling elements and raceways, thereby preventing the occurrence of impulse vibration responses. Due to contact persistence, such defects may not generate impact and may not be detected by existing VBMs, and the bearing could behave as healthy. This paper investigates such specific cases by exploring the relationship between roller-bearing defect characteristics and their potential to generate impact loads during operation. Using an experimental bearing rig, different roller and inner-race defects are presented while their fault characteristic frequencies remain undetected by the envelope analysis, fast Kurtogram, cyclic spectral coherence, and tensor decomposition methods. This study highlights the significance of both the dimension and location of defects within bearings on their detectability based on the rotordynamics concept. Further, simple roller-beam experiments are carried out to visualise and validate the reliability of the experimental observations made on the roller bearing dynamics. Full article

In industrial applications, the operating state of bearings can directly affect the performance of mechanical equipment. Local defects, flexible raceways and lubrication have a great impact on the vibration characteristics of rolling bearings. However, previous works only considered the bearing as a rigid whole or unlubricated state. In order to solve this problem, a flexible–rigid combined bearing dynamics (FRBD) model considering grease lubrication is proposed in this paper. Both the flexible inner race and flexible outer race of a lubricated rolling bearing and a localized defect are formulated in the presented FRBD model. The influence of flexible–rigid combined and grease lubrication on the time- and frequency-domain responses of a rolling bearing with a local fault is analyzed. Based on the constructed model, the root mean square (RMS) value and maximum (MAX) value of time-domain statistical indicators are used to discuss the characteristic changes in acceleration vibration signals under different fault widths, inner-race speeds, and radial forces. In order to verify the accuracy of the FRBD model, the simulation results are compared with the experimental results. These results have a certain guiding role in fault diagnosis for the predictive maintenance of a rolling bearing. Full article

Localized defects are common in gear transmission systems and can sometimes cause serious production problems or even catastrophic accidents. To reveal the failure mechanisms and study the localized defects in gear transmission systems, a 24-degree-of-freedom (DOF) dynamic coupling model is proposed considering shafts, bearings, and gears. The dynamic characteristics of the established model when defects appear on the raceways of bearings and surfaces of gears are analyzed. It can be found in the results that the response of the established model produces periodic shocks when localized defects appear on bearings or gears through numerical analysis. Sidebands generated by fault frequencies can be detected from the frequency spectrum. Especially, bearing-localized defects on the inner race and gear surface are similar in modulation form envelope analysis, and the increase in rotating frequency leads to difficulties in distinguishing defects on bearings and gears. The established coupling dynamic model was validated through experimentation and offers a theoretical basis for the fault diagnosis of gear transmission systems. Full article

Deep groove ball bearings are relatively weak in design for withstanding axial forces, but in practical applications, they may be subject to slight axial impact. Spalling failure may occur at a non-central position on the raceway. In response to this issue, this paper studies the axial impact characteristics generated in the bearing system due to uneven contact on both axial sides of the raceway when the rolling element passes through the defect area. A three-degree-of-freedom kinetic model considering the axial impact is proposed in this paper, simulating the effect of the impact on the rolling bearing when the flaking failure occurs at the non-central position of the roller path. The contact deformation area between the rolling element and raceway under axial forces and the position condition of the spalling fault in the raceway axial direction are introduced, and the impact characteristics of the spalling fault at different axial positions of the inner raceway are simulated by the time-varying energy method. Through comparative analysis of simulation and experiment, the variation characteristics of the vibration intensity in three directions of the bearing system when the spalling fault is at different axial positions of the raceway are obtained, and the correctness of the model is verified. This also provides theoretical support for improving the design and selection of bearings. Full article

High-quality data samples are essential for the early detection of bearing failures and the analysis of bearing behavior. The accurate simulation of bearing fault conditions can provide valuable insights into understanding failure mechanisms. This paper establishes a new numerical simulation method for double-row cylindrical roller bearing (DCRB) faults based on the augmented Lagrange dynamics method, overcoming the limitations of previous models by incorporating fault conditions related to cage fracture. This method accounts for the dynamic behavior of the rollers during the motion cycle and their interactions with other DCRB components. By comparing the characteristic frequencies of the fault components, the model not only replicates the dynamic behavior of faulty DCRBs more accurately but also offers a deeper understanding of fault-induced dynamics. This advancement provides a more comprehensive and realistic tool for bearing fault analysis. Full article

The occurrence of an axlebox bearing ring raceway defect is an inevitable and commonly observed phenomenon in railway wheels. It not only leads to surface damage but also poses the potential threat of further damage and degradation, thereby increasing the risks associated with running safety and maintenance costs. Hence, it becomes imperative to detect raceway defects at an early stage to mitigate safety hazards and reduce maintenance efforts. In this study, the focus lies in investigating the effectiveness of vibration-based detection techniques for identifying raceway defects in high-speed train axlebox bearing systems. To achieve this, a dynamic model that accurately represents the coupling dynamics between the vehicle and the track is developed. This model incorporates various dynamic factors, such as traction transmission, gear transmission, and track geometry irregularities. By using the comprehensive dynamic model, the dynamic responses of the axlebox can be accurately calculated. The proposed methodology primarily revolves around analysing the vertical vibrations of the axlebox caused by raceway defects in both the time and frequency domains. Additionally, an envelope analysis using a developed band-pass filter is also employed. The results obtained from this study clearly demonstrate the successful detection of raceway defects in a more realistic vehicle model, thereby providing an efficient approach for the detection of axlebox bearing raceway defects. Consequently, this research contributes significantly to the field of high-speed train systems and paves the way for enhanced safety and maintenance practices. Full article

The traction behavior in cryogenic solid-lubricated ball bearings (CSLBBs) of liquid rocket engines (LREs) has a significant effect on the dynamic response of the bearing–rotor system. To reveal the fault mechanism of CSLBBs, a tribo-dynamic model is proposed in this paper that considers the solid-lubricated traction, six-DOF motion of the ball and contact collisions between the ball and the cage. The modified traction model uses fan-shaped and arched sections to discretize the contact area to eliminate the meshing error. The newly developed fault model, called ‘geometrical-frictional defects’, can more realistically represent solid-lubrication coating defects. The results show that the frictional excitation can significantly increase bearing vibration by increasing the traction force on the raceway. The change in the amplitude of the bearing vibration and its derivative can be used as a reference to determine the depth of defects. The width of the defect can be diagnosed by monitoring the double-pulse time interval and spectrum of the bearing vibration signal. This research may provide some theoretical guidance for the design and condition monitoring of CSLBBs. Full article

Damage in bearings is closely associated with the presence of microstructural alterations, known as white etching areas (WEAs) and white etching cracks (WECs). One of the main reasons for the creation of these microstructural alterations is the presence of defects in the material, such as non-metallic inclusions. Manganese sulfides and aluminum oxides are widely reported in the literature as the most common types of non-metallic inclusions found in bearing steels. This study classifies 280 non-metallic inclusions in an investigated bearing steel according to several criteria: bonded/debonded with the matrix, size, shape, orientation angle, depth below the raceway surface, and chemical composition. Contrary to the findings in the literature, this investigation reports that the chemical composition of the inclusion (MnS + Al₂O₃) is of secondary importance when considering factors for damage initiation. The orientation of the microstructural alterations is observed to coincide with the high-stress regions, indicating a relation between the formation of butterfly wings and the white etching crack. In our investigation, butterfly wings typically exhibit a 45-degree pattern originating from the non-metallic inclusions. Conversely, the white etching crack starts from the non-metallic inclusion at a shallower angle in correspondence to the raceway. This can be attributed to the stress state, which corresponds to a region where extensive white etching cracks are formed. In conclusion, the microstructural observations demonstrate that the state of non-metallic inclusion—i.e., whether they are bonded or not to the steel matrix—plays an essential role in initiating rolling contact fatigue damage. Full article

The rolling element bearing is a fundamental component of any rotating machinery. During operation, wear debris and lubricant impurities create dents and bumps on the bearing raceway surfaces. Such localized defects produce transient vibration impulses at one of the bearing characteristic frequencies. Having a combination of multiple types of point defects on the raceway results in superimposed vibration patterns, which reduce the ability to recognize these defects’ effects. In this paper, a 6-DOF dynamic model is developed to accurately investigate the vibration characteristic of a ball bearing with a multipoint defect comprising a dent and bump on its raceway surface. The model considers the effects of time-varying contact force produced due to defects, lubricant film damping, bearing preload, and the inertia effect of rolling elements. The simulation results reveal the vibration behavior of multipoint defect bearings. In addition, bearing vibration response is affected by the number of defects, the angle between them, and the type and size of each defect. Furthermore, it is challenging to predict bearing defects parameters such as the numbers, types, sizes, and angles between adjacent defects from acceleration signal analysis without jerk signal analysis. The validation of the model is proved using signals from the Case Western University test setup. Full article

The fabrication of bespoke artificial defects on bearing raceways helps in mimicking incipient faults during real application or for directly validating the diagnostic technology depending on their shapes and sizes. This is particularly useful when run-to-failure experiments are time-consuming and even difficult in some cases. However, there has been limited systematic research on the design and fabrication of artificial defects on bearing raceways, particularly for the purpose of accelerated testing. In this work, micro-EDM is put forward as a potential technique for the fabrication of artificial defects using drilling/milling mode. A methodology is developed, not only to achieve the full control of the dimension and distribution of defects on a bearing element, but also to qualitatively and quantitatively perform the efficient characterization of the defect surface. A linear regression model with the inclusion of two-way interactions based on an analysis of variance (ANOVA) is presented to optimally select the process parameters. The verification experiments show that this mathematical model obtains a good fit for approximately 80% of the observed data. Through a combination of optical microscopy and confocal microscopy, the morphology and topography of the artificial defects was measured and compared. To conclude, micro-EDM evidences its great potential in terms of machining efficiency, e.g., with an MRR of 0.060 ${\mathrm{mm}}^3/\min$, TWR of 0.032 ${\mathrm{mm}}^3/\min$ and dimensional controllability, e.g., the standard deviation of pitting diameter and depth being 0.5 µm and 0.8 µm, respectively, to achieve a desirable feature shape for bearing defects. Full article

In the condition monitoring of bearings using acoustic emission (AE), the restriction to solely instrument one of the two rings is generally considered a limitation for detecting signals originating from defects on the opposing non-instrumented ring or its interface with the rollers due to the signal energy loss. This paper presents an approach to evaluate transmission in low-speed roller bearings for application in passive ultrasound monitoring. An analytical framework to describe the propagation and transmission of ultrasonic waves through the geometry and interfaces of a bearing is presented. This framework has been used to evaluate the transmission of simulated damage signals in an experiment with a static bearing. The results suggest that low- to mid-frequency signals (<200 kHz), when passing through the rollers and their interfaces from one raceway to the other, can retain enough energy to be potentially detected. An average transmission loss in the range of 10–15 dB per interface was experimentally observed. Full article

The impulse response of a rolling bearing and its principal component, the elasto-hydrodynamic lubrication film (EHDL), are analysed. When measuring the vibrations of bearings, we observed that the impulse response was mostly caused by defects (fatigue damage) on the raceways and/or rolling elements. However, this phenomenon can also occur in new defect-free roller bearings, where it is not commonly expected. This study presents an experiment that identifies the conditions of dynamic excitation for the impulse response of the EHDL, the source of which is not defects, but the EHDL itself. The EHDL responds in the form of impulses in case the velocity of its radial deformation is too fast. This is an unfavourable phenomenon that significantly shortens the service life of bearings. To analyse the dynamic excitation conditions, a testing bench at speeds up to 135,000 rpm with a flat belt drive was used. The testing bench enabled the formation of the so-called beat excitation from two harmonic excitation forces close in rotational frequency. The subject of this study is a defect-free high-speed double-row angular contact ball bearing used in the textile industry. We also present other physical conditions for the occurrence of undesired impulse responses that are caused by the EHDL. Full article

Rolling element bearing is a vital component in rotating machinery, such as a wind turbine (WT) system. By accurately monitoring its health condition, the faults can be detected at an early stage, providing sufficient lead time to perform maintenance and hence reducing accidents and economic losses. Bearing usually suffers from various wears and tears, which result in a gradual increase in clearance through its lifetime. Insufficient understanding of vibration characteristics under different clearances brings difficulties for bearing condition monitoring. Thus, this paper presents a nonlinear bearing vibration model with six degrees of freedom (DOF) to investigate the vibration characteristics under different radial clearances and load conditions. Then, a dedicated bearing test is established to verify the reasonability and effectiveness of the vibration model. Furthermore, a comprehensive simulation analysis is conducted to study the vibration characteristics over an extended range of the internal radial clearance and external load. Results show that the dynamic force on each ball presents an impulse whose magnitudes increases whereas the pulse width reduces with clearance increases. Ball pass frequency of outer race (BPFO) is the dominant modulation component and the frequency is in accordance with the number of dynamic force impulses. Two indicators, i.e., root mean square (RMS) value and spectral centroid, are proposed to indicate clearance changes. In general, they show an uptrend with the increase in clearance, which is in line with the dynamic force increasing with clearance, especially the spectral centroid of the low frequency band. However, it should be noted that the RMS value and spectral centroid exhibit a fluctuating behavior due to nonlinear vibration responses. For the first time, this study shows the details of vibration characteristics with clearance variations and provides a foundation for monitoring the bearing conditions before any obvious local defects on raceways. Full article
