The co-firing of coal and refuse-derived fuel (RDF) from municipal solid waste recycling is gaining support in countries in which energy production is based on solid fuels. It is the result of the rising priority given to renewable energy sources, the circular economy, and effective waste management through sorting, recycling, and thermal conversion. Despite the increasing efficiency of recycling and the ever-lower quantities of waste delivered to waste dumps, the problem of the residual fraction remains unsolved. The portion of mixed municipal waste that cannot be recycled exhibits a high energy value. For this reason, it should be neither stored nor burnt in household boiler rooms, as doing so would constitute an environmental hazard. However, the waste can be used as an additive to fine coal in power boilers, provided that they are equipped with flue gas monitoring and purification systems. Tests involving proportionally prepared compositions of fine coal and refuse-derived fuel burnt in a laboratory boiler revealed a major variability in the flue gas parameters (physicochemical), depending on the applied proportions of the individual components. For instance, when burning a composition of 50% fine coal and 50% refuse-derived fuel, a reduction in CO₂ emissions by about 12% was noted compared with that when burning fine coal exclusively. Furthermore, when burning refuse-derived fuel, an addition of 20% fine coal is enough to produce a 2.8% reduction in CO emission. Meanwhile, a composition of 80% fine coal and 20% refuse-derived fuel would reduce the emissions by 393 ppm. During the measurements, it was also noted that most of the measured parameters indicated a decrease in individual gas contents relative to the emissions obtained when burning fine coal or refuse-derived fuel exclusively. These relationships can be applied to prepare fuel compositions based on refuse-derived fuel and fine coal, depending on the power and flue gas purification capabilities of individual cogeneration systems. Full article

The increasing prevalence of common cold viruses and bacteria in daily life has heightened interest in sterilization lamp technologies. Compared with traditional mercury-based ultraviolet (UV) lamps, modern UV lamps offer advantages including extended operational lifespan, high energy efficiency, compact form factor, and the absence of hazardous materials, rendering them both safer and environmentally sustainable. In particular, UV-C LED lamps, which emit at short wavelengths, are capable of disrupting the molecular structure of DNA or RNA in microbial cells, thereby inhibiting cellular replication and achieving effective disinfection and sterilization. Conventional UV-C LED sterilization lamp driver circuits frequently employ a two-stage architecture, which requires a large number of components, occupies substantial physical space, and exhibits reduced efficiency due to multiple stages of power conversion. To address these limitations, this paper proposes a UV-C LED sterilization lamp driver circuit for an AC voltage supply, employing boundary conduction mode (BCM) control with integrated power factor correction (PFC). The proposed single-stage, single-switch topology combines a buck PFC converter and a flyback converter while recovering transformer leakage energy to further improve efficiency. Compared with conventional two-stage designs, the proposed circuit reduces the number of power switches and components, thereby lowering manufacturing cost and enhancing overall energy conversion efficiency. The operating principles of the proposed driver circuit are analyzed, and a prototype is developed for a 110 V AC input with an output specification of 10.8 W (90 V/0.12 A). Experimental results demonstrate that the prototype achieves an efficiency exceeding 92%, a power factor of 0.91, an output voltage ripple of 1.298%, and an output current ripple of 4.44%. Full article

This paper presents an advanced radio frequency (RF)–direct current (DC) power conversion architecture based on a multistage Cockcroft–Walton topology. The proposed design achieves an enhanced voltage conversion ratio while maintaining superior RF-DC conversion efficiency under low input power conditions. To address the inherent limitations of cascading Cockcroft–Walton topologies with class-F load networks, a novel ground plane isolation technique was developed, which utilizes the reverse-side metallization of the circuit board. A 5.8 GHz two-stage Cockcroft–Walton voltage multiplier rectifier was fabricated and characterized. Measurement results demonstrate that the circuit achieves a maximum output voltage of 7.4 V and a peak conversion efficiency of 70.5% with an input power of only 30 mW, while maintaining stable performance across varying load conditions. A comparison with a two-stage Dickson rectifier reveals that the Cockcroft–Walton rectifier exhibits superior output voltage and conversion efficiency. The proposed architecture delivers significant improvements in power conversion efficiency and voltage multiplication capability compared to conventional designs, establishing a new benchmark for low-power wireless energy harvesting applications. Full article

Power converters are increasingly pushing toward higher switching frequencies, with current designs typically operating between tens of kilohertz and a few megahertz. The commercialization of gallium nitride (GaN) power transistors has opened new possibilities, offering performance far beyond the limitations of conventional silicon devices. Despite this promise, the potential of GaN technology remains underutilized. This paper explores the feasibility of achieving sub-gigahertz switching frequencies using GaN-based switch-mode power converters, a regime currently inaccessible to silicon-based counterparts. To reach such operating speeds, it is essential to understand and quantify the intrinsic frequency limitations imposed by GaN device physics and associated parasitics. Existing power conversion topologies and control techniques are unsuitable at these frequencies due to excessive switching losses and inadequate drive capability. This work presents a detailed, systematic study of GaN transistor behavior at high frequencies, aiming to identify both fundamental and practical switching limits. A compact analytical model is developed to estimate the maximum soft-switching frequency, considering only intrinsic device parameters. Under idealized converter conditions, this upper bound is derived as a function of internal losses and the system’s target efficiency. From this, a soft-switching figure of merit is proposed to guide the design and layout of GaN field-effect transistors for highly integrated power systems. The key contribution of this study lies in its analytical insight into the performance boundaries of GaN transistors, highlighting the roles of parasitic elements and loss mechanisms. These findings provide a foundation for developing next-generation, high-frequency, chip-scale power converters. Full article

This paper presents a novel open-loop modulation and control strategy for bidirectional, multi-source/load parallel AC-link power converters. While these converters offer advantages such as high-frequency operation and flexible power conversion capabilities, their application to complex systems such as nanogrids presents significant control challenges. Traditional control methods often struggle to efficiently manage power flow and charging/discharging processes, especially when dealing with multiple sources and loads of varying characteristics. To address these issues, this paper proposes a new control strategy that enables intelligent source and load selection while maintaining fast charging and discharging times. Simulation results demonstrate the effectiveness of the proposed approach. This research contributes to advancing the state-of-the-art in power electronics by providing a foundation for improved control of complex power conversion systems for renewable energy applications. Full article

In the event of power outages caused by natural disasters, accidents, or other emergencies, outdoor emergency lighting systems play a critical role in providing illumination to maintain spatial orientation, facilitate evacuation procedures, and help individuals avoid hazardous areas or locate safe shelters. Compared to traditional lighting technologies, LED-based outdoor emergency lighting offers several advantages, including compact size, long operational lifespan, low energy consumption, high safety, resistance to breakage, and the absence of chemical residue or pollution. These characteristics align with contemporary trends in environmental sustainability and energy efficiency. This study proposes a novel LED driver circuit architecture for outdoor emergency lighting applications. The primary circuit topology is based on an improved buck-boost converter integrated with a flyback converter, forming a hybrid buck-boost-flyback configuration. The proposed circuit is capable of recycling the energy stored in the transformer’s leakage inductance, thereby enhancing overall power conversion efficiency. A 12 W (20 V/0.6 A) prototype LED driver circuit was designed and implemented to validate the performance of the proposed system. Experimental measurements, including waveform analysis and efficiency evaluation, demonstrate that the driver circuit achieves a high efficiency exceeding 91%. These results confirm the practical feasibility and effectiveness of the proposed electronic driver for LED-based outdoor emergency lighting applications. Full article

Railway turnouts are highly susceptible to snow and ice accumulation during winter, which can cause malfunctions, resulting in train delays or, in extreme cases, derailments with potential casualties. To mitigate these risks, resistive heating (RH) systems using nichrome wires have traditionally been employed. However, these systems suffer from slow heat transfer and high power consumption. To address these limitations, this article proposes an induction heating (IH) system designed for rapid thermal response and improved electrical and thermal efficiency. The proposed system comprises a power conversion unit featuring a boost power factor correction (PFC) stage and a high-frequency resonant inverter, along with an improved IH coil. An experiment in real snowfall demonstrates the IH system’s fast heat-up capability, effective snow cover removal, and enhanced energy efficiency compared to conventional methods. Full article

In this paper, a nonlinear power transfer matrix model is presented for power control of Permanent Magnet Synchronous Generator (PMSG) wind turbines, incorporating the DC link dynamics to account for transient stability, thereby clarifying the technical aspect and purpose. The rising penetration of wind turbines (WTs) into the power grid necessitates that they remain connected during and after faults to ensure system reliability. During voltage dips, the stator and grid-side converter (GSC) of a permanent magnet synchronous generator (PMSG) system are directly impacted by the sudden voltage changes. These disturbances can induce large transient voltages and currents in the stator, which in turn may lead to uncontrolled current flow in the rotor circuit and stress the converter components. Moreover, Low Voltage Ride-Through (LVRT) is a critical requirement for grid connection to Wind Energy Conversion Systems (WECS). It ensures that WTs remain connected and operational during short periods of grid voltage dips (faults), instead of disconnecting immediately. This capability is essential for maintaining grid stability. However, in this paper, the authors propose an LVRT scheme for a grid-connected PMSG-based WECS. A sequence of attempts was performed to validate the effectiveness of the proposed control scheme under fault conditions and to improve its overall performance. Full article

The development of reconfigurable photonic integrated circuits (PICs) demands photonic devices with high-efficiency tuning capabilities, yet conventional thermo-optic and electro-optic methods suffer from limited index modulation and excessive power consumption. To overcome these limitations, we propose an etchless and tunable silicon nitride waveguide mode converter based on low-loss phase change material, antimony triselenide (Sb₂Se₃). By depositing an Sb₂Se₃ layer on the silicon nitride wafer and using a laser-induced phase transition technique, we can write and erase the waveguide structure in the phase change wafer without waveguide etching, where the input/output waveguide is a strip waveguide and the conversion region is built using a tilted subwavelength grating structure. From the results, the obtained TE₀-TE₁ mode conversion efficiency, crosstalk, and insertion loss are higher than 96%, lower than −16 dB, and lower than 0.4 dB at a wavelength of 1.55 µm, respectively. The proposed device enables post-fabrication tuning of the grating duty cycle, allowing working wavelength adjustment for the same device. Furthermore, the device exhibits scalability to other higher-order mode conversions (e.g., TE₀-TE₂). Consequently, we expect that such devices could have important uses in programmable and multifunctional PICs. Full article

Due to its high heat transfer property, microchannel heat sink has been widely applied in thermal management, microelectronic cooling and energy conversion. To develop a microchannel heat sink featuring low pressure drop ΔP and a high heat transfer property, a V-shaped wavy microchannel (VWM) is designed and CFD simulation is carried out. Subsequently, the influences of wave amplitude A, wave length λ and inlet velocity u on the Nusselt number Nu_ave, the Dean Vortexes and ΔP are studied. Furthermore, based on the performance evaluation criteria (PEC), the optimal parameters of A, λ and u are chosen. Next, the influence of microchannel number N is studied at the same pump power. Eventually, the optimal VWM heat sink is compared with the V-shaped straight microchannel (VSM) heat sink and the rectangular-shaped straight microchannel (RSM) heat sink. The results show that many Dean Vortexes periodically emerge in the V-shaped wavy microchannel, particularly at the wave peak and valley. These Dean Vortexes are capable of thinning the thermal boundary layer, which significantly strengthens heat transfer. As A and u increase while λ decreases, the area, number and severity of the Dean Vortexes increase, and thus both Nu_ave and ΔP also increase. In the present study, the PEC first increases and then decreases, reaching its maximum value when A = 0.3 mm, λ = 5 m and u = 1.0 m/s. At the same pump power, both the heat transfer area and the total Dean Vortex number increase with the increase in N, leading to a decrease in the thermal resistance R and the maximum temperature T_max. Compared to the VSM and RSM heat sinks, the optimal VWM heat sink decreases T_max by 29.93 K and 38.03 K, decreases R by 50.46% and 56.68%, increases h_ave by 156.42% and 155.43% and increases PEC by 137% and 130.78%, respectively. Full article

We fabricated dye-sensitized solar cells (DSSCs) co-sensitized with the organic dye YD2 and a spiropyran derivative (SPNO₂), a photochromic molecule capable of reversible isomerization under light irradiation. Upon UV exposure, SPNO₂ converts from its closed spiropyran (SP) form to the open photomerocyanine (PMC) form, which absorbs visible light and changes the optical properties of the photoelectrode. Spectroscopic analysis showed an 18% decrease in transmittance at 540 nm after UV irradiation and a 10% increase following visible light exposure. These changes were accompanied by a 0.5% increase in power conversion efficiency (η) after 5 min of UV irradiation, and a 0.83% decrease after 10 min of visible light. Although direct electron injection from PMC into TiO₂ appears inefficient, the enhanced performance is attributed to Förster resonance energy transfer (FRET) from PMC to YD2. This photoresponsive behavior highlights a co-sensitization strategy that combines dynamic optical control and efficient energy transfer. Our findings demonstrate a promising approach to designing smart DSSCs with externally tunable photovoltaic properties using photochromic sensitizers. Full article

Among other uses, DC-DC converters are employed in the auxiliary power modules (APMs) of electric vehicles (EVs), connecting the high-voltage traction battery to the low-voltage auxiliary system (AS). Traditionally, the APM is an isolated two-port, two-level (2L) DC-DC converter, and the auxiliary loads are fed at a fixed voltage level, e.g., 12 V in passenger cars. Dual-active-bridge (DAB) converters are commonly used for this application, as they provide galvanic isolation, high power density and efficiency, and bidirectional power flow capability. However, the auxiliary loads do not present a uniform optimum supply voltage, hindering overall efficiency. Thus, a more flexible approach, providing multiple supply voltages, would be more suitable for this application. Multiport DC-DC converters capable of feeding auxiliary loads at different voltage levels are a promising alternative. Multilevel neutral-point-clamped (NPC) DAB converters offer several advantages compared to conventional two-level (2L) ones, such as greater efficiency, reduced voltage stress, and enhanced scalability. The series connection of the NPC DC-link capacitors enables a multiport configuration without additional conversion stages. Moreover, the modular nature of the ML NPC DAB converter enables scalability while using semiconductors with the same voltage rating and without requiring additional passive components, thereby enhancing the converter’s power density and efficiency. This paper proposes a modulation strategy and decoupled closed-loop control strategy for the generalized multiport 2L-NL NPC DAB converter interfacing the EV traction battery with the AS, and its performance is validated through hardware-in-the-loop testing and simulations. The proposed modulation strategy minimizes conduction losses in the converter, and the control strategy effectively regulates the LV battery modules’ states of charge (SoC) by varying the required SoC and the power sunk by the LV loads, with the system stabilizing in less than 0.5 s in both scenarios. Full article

Lead-free perovskite solar cells (PSCs) provide a viable alternative to lead-based versions, thereby reducing significant environmental issues related to toxicity. MASnIBr₂ has emerged as a very attractive lead-free perovskite material due to its environmentally friendly characteristics and advantageous optoelectronic capabilities. However, more tuning is required to achieve superior conversion efficiencies (PCEs). This study uses SCAPS-1D simulations to systematically develop and optimize the electron and hole transport layers (ETLs/HTLs) in MASnIBr₂-based perovskite solar cells (PSCs). Iterative simulations are used to carefully examine and optimize critical parameters, including electron affinity, energy bandgap, layer thickness, and doping density. Additionally, the thickness of the MASnIBr₂ absorber layer is optimized to enhance charge extraction and light absorption. Our findings showed a maximum power conversion efficiency of 20.42%, an open-circuit voltage of 1.38 V, a short-circuit current density of 17.91 mA/cm², and a fill factor of 82.75%. This study establishes a basis for future progress in sustainable photovoltaics and offers essential insights into the design of efficient lead-free perovskite solar cells. Full article

Ultrasonic guided wave interdigital transducers realized with piezoelectric materials are of interest for structural health monitoring systems because of their capability of performing Lamb wave mode selection with respect to single-element transducers. Besides this advantage, the coverage of large areas with a minimum number of elements is an important challenge and the problem of efficient excitation with integrated electronics must be solved. This work proposes an electrical matching network topology made of L and C passive components that can be designed for the trade-off between electrical to mechanical conversion efficiency and bandwidth. The network circuit is analyzed considering the equivalent transducer impedance and the output impedance of the driving electronics. The design rules derived by the transfer function analysis are described and a case study for a piezopolymer IDT is presented. Finally, with the implementation of the integrated matching network with the connector of the IDT, the effect of cable capacitance is minimized. In conclusion this article is a contribution to the study of using IDT efficiently and in a versatile mode for different electronic front-ends that usually operate at low power supply voltage. Full article

We developed dye-sensitized solar cells based on anatase–titanium dioxide (A-TiO₂) nanotubes (TiNTs) and nanocubes (TiNcs) with {001} crystal facets generated using simple and facile electrochemical anodization. We also demonstrated a simple way of developing one-dimensional, two-dimensional, and three-dimensional self-assembled TiO₂ nanostructures via electrochemical anodization, using them as an electron-transporting layer in DSSCs. TiNTs maintain tubular arrays for a limited time before becoming nanocrystals with {001} facets. Using FESEM and TEM, we observed that the TiO₂ nanobundles were transformed into nanocubes with {001} facets and lower fluorine concentrations. Optimizing the reaction approach resulted in better-ordered, crystalline anatase TiNTs/Ncs being formed on the Ti metal foil. The anatase phase of as-grown TiO₂ was confirmed by XRD, with (101) being the predominant intensity and preferred orientation. The nanostructured TiO₂ had lattice values of a = 3.77–3.82 and c = 9.42–9.58. The structure and morphology of these as-grown materials were studied to understand the growth process. The photoconversion efficiency and impedance spectra were explored to analyze the performance of the designed DSSCs, employing N719 dye as a sensitizer and the I⁻/I³⁻ redox pair as electrolytes, sandwiched with a Pt counter-electrode. As a result, we found that self-assembled TiNTs/Ncs presented a more effective photoanode in DSSCs than standard TiO₂ (P25). TiNcs (0.5 and 0.25 NH₄F) and P25 achieved the highest power conversion efficiencies of 3.47, 3.41, and 3.25%, respectively. TiNcs photoanodes have lower charge recombination capability and longer electron lifetimes, leading to higher voltage, photocurrent, and photovoltaic performance. These findings show that electrochemical anodization is an effective method for preparing TiNTs/Ncs and developing low-cost, highly efficient DSSCs by fine-tuning photoanode structures and components. Full article
