Search Results (47)

The present work is based on an experimental determination of the mechanical properties of test bodies made using PolyJet technology from the two-component material Digital ABS Plus. The parameters of the 3D printing of the test bodies and their dimensions are presented. The testing methods and equipment for the studied parameters of hardness and roughness are selected. Roughness studies were conducted according to different test body positions and orientations. Hardness studies were carried out according to the Shore D and Rockwell M scales for three types of test bodies: after 3D printing of their surface; inside the test body; and after applying thermal treatment to the test bodies. These indicators are extremely important in the evaluation of details and the possibility of their implementation in the production process. Full article

This publication focuses on the additive technology PolyJet and more specifically the photopolymer Digital ABS Plus. After a thorough analysis, it was concluded that this technology is suitable for both rapid prototyping of parts and rapid small-scale production of various products. The resulting parts can be implemented in a production process with different operating conditions. That is why it is interesting to investigate the Digital ABS Plus material at elevated temperatures. The temperatures at which the tests were performed are consistent with the values for heat deflection temperature (HDT) of the Digital ABS Plus material, described in the manufacturer’s technical data sheet, as well as with the results of high-temperature tests of parts obtained using Fused Deposition Modeling (FDM) technology. The investigated test pieces are subjected to annealing in order to increase their tensile strength and temperature resistance. The process is carried out in an oven with digital temperature control with a thermal profile according to a procedure approved by the manufacturer Stratasys. The obtained data from the mechanical properties before and after annealing of the Digital ABS Plus material are compared and depicted in a diagram. Full article

This study investigates the mechanical behavior and anisotropy of cellular structures fabricated using PolyJet Matrix (PJM) technology from RGD 720 photopolymer resin. Standard ISO 527 specimens were produced at build orientations of 0°, 45°, and 90° to evaluate the influence of printing direction on tensile properties. Based on these results, the optimal 0° orientation was selected for further analysis of cellular structures, including hexagonal, spiral, and quasi-self-similar geometries, manufactured in both unfilled and silicone-filled configurations. Static tensile tests were performed to determine load–displacement characteristics, maximum load, and deformation behavior. The results reveal a strong dependence of mechanical properties on build orientation, with the highest strength observed at 0° and the lowest at 90°, confirming significant material anisotropy. This behavior was further quantified using first- and second-order anisotropy coefficients derived from experimental data. The introduction of silicone filling improved load-bearing capacity, reduced variability, and promoted a more ductile failure mechanism. Among the analyzed geometries, quasi-self-similar structures exhibited the best mechanical performance, while unfilled structures showed lower strength and higher deformation. The findings demonstrate that both build orientation and structural design are critical factors in optimizing the mechanical properties of additively manufactured components and provide a basis for designing tailored cellular structures for engineering applications. Full article

Background: Flexible surgical instruments for Robot-Assisted Minimally Invasive Surgery (RAMIS) face a critical limitation: the inability to rotate the distal head while the instrument is in a bent configuration, which restricts the maneuverability in narrow surgical workspaces. Methods: This paper presents a novel 4-degree-of-freedom (DOF) flexible laparoscopic instrument with a 10 mm diameter, incorporating a 3D-printed flexible element. The design enables independent bending (0–90°), continuous distal head rotation (360°), gripper actuation (0–60°), and rod rotation (180°). A constant-curvature kinematic model was developed. The instrument was manufactured using PolyJet 3D printing technology and integrated with the ATHENA parallel robot for proof-of-concept experimental validation. Results: Experimental tests demonstrated successful independent 360° distal head rotation across the full bending range (0–90°), validated through simulated surgical procedures including stomach retraction. Quantitative characterization using optical motion capture revealed a maximum angular deflection of 79.85° at 670 g applied load, with tip displacements of 74.95 mm (X) and 91.18 mm (Y). The measured grasping force was approximately 2 N, tip position repeatability was ±2.86 mm, and fatigue testing demonstrated no degradation after 500 bending cycles, confirmed by digital microscope inspection. The instrument performed multiple manipulation tasks, including elastic band transfer, wire path navigation, spring manipulation, and tissue grasping. Conclusions: The proposed instrument addresses a significant white spot in surgical robotics by adding an additional functional capability enabling grasper reorientation without repositioning the entire instrument. Full article

This study aimed to identify the optimal printing orientation (X, Y, or Z axis) and positioning of a mandibular molar presenting an isthmus using PolyJet™ technology. The influence of these parameters on dimensional accuracy and on the behavior of 3D-printed teeth (3DPT) during endodontic preparation with ProTaper Gold^® system was evaluated. Six groups (XA, XB, YA, YB, ZA, ZB; n = 10) were printed with different axis orientations and distinct isthmus positions relative to the build platform. All samples underwent micro-computed tomography scanning before and after endodontic preparation. Regarding preoperative analyses—canal volume, centroids, and total tooth volume and area—no significant differences were found between groups XA–YA or XB–YB (p > 0.05), supporting their comparability. In contrast, groups ZA and ZB differed significantly from all others (p < 0.05), failing to meet equivalence required for further comparison, and were therefore excluded. Postoperative evaluation—volume change, centroid displacement, transportation, and unprepared areas—revealed no significant differences between XA–YA and XB–YB. Within the limitations of this study, both printing orientation and position affected the accuracy and repeatability of 3DPT, with positioning exerting the greatest influence, while their behavior towards endodontic preparation remained consistent across orientations. Full article

The research methodology involved creating a 3D sample model that featured both flat and cylindrical surfaces inclined at angles ranging from 0° to 90° relative to the XY plane. The study investigated the surface topography of additively manufactured samples produced using various technologies, including Fused Filament Fabrication (FFF), masked Stereolithography (mSLA), PolyJet (PJ), and Selective Laser Sintering (SLS). The focus was on how material type, print angle, and measurement location influenced the results. The materials used in the study included PLA, PETG, acrylic resins, PA2200, and VeroClear. Due to the optical properties of the materials used, measurements were carried out on replicas that were prepared using a RepliSet F5 silicone compound from Struers. Consequently, a methodology was developed for measuring surface roughness using the Alicona microscope based on these replicas. A 10× objective lens was used during the measurements, and the pixel size was 0.88 µm × 0.88 µm. Each time, an area of approximately 1 mm × 4 mm was measured. The lowest roughness values were observed for mSLA samples (Sa = 6.72–8.54 µm, Spk + Sk + Svk = 33.36–42.16 µm), whereas SLS exhibited the highest roughness (Sa = 27.86 µm, Spk + Sk + Svk = 183.79 µm). PJ samples exhibited intermediate roughness with significant anisotropy (Sa = 11.65 µm, Spk + Sk + Svk = 72.1 µm), which was strongly influenced by the print angle. FFF surfaces showed directional patterns and layer-dependent roughness, with the Sa parameter being the same (12.44 µm) for both PETG and PLA materials. The steepest slopes were observed for SLS surfaces (Sdq = 7.67), while mSLA exhibited the flattest microstructure (Sdq = 0.48–0.89). Statistical analysis confirmed that material type significantly influenced topography in mSLA, while print angle strongly affected PJ and FFF (although for FFF, further studies would be beneficial). The results of the research conducted can be used to develop a methodology for optimizing the printing process to achieve the required geometric surface structure. Full article

Additive manufacturing (AM), commonly known as 3D printing, is revolutionizing modern dentistry, introducing high-precision, patient-specific, and digital-driven workflows across prosthodontics, orthodontics, implantology, and maxillofacial surgery. Extensive analysis explores the leading platforms in 3D printing such as stereolithography (SLA), fused deposition modeling (FDM), selective laser sintering (SLS), digital light processing (DLP), and PolyJet which all achieve superior performance across multiple areas including resolution capabilities, material compatibility options, clinical application readiness, and cost-effectiveness. Additionally, an extensive overview of common materials, including biocompatible polymers (PLA, PMMA, PEEK), metals (titanium, cobalt-chromium), and ceramics (zirconia, alumina, glass-ceramics), sheds light on the critical role of material selection for patient safety, durability, and functional performance. The review explores new advancements such as 4D printing with shape-adaptive smart biomaterials as well as artificial intelligence-enabled digital processes and prosthesis design for the transformation of regenerative dentistry and intraoral drug delivery operations into new domains and the automation of clinical planning. Equally groundbreaking are 3D printing applications in pediatric dentistry, surgical simulation, and dental education. However, full-scale adoption of AM technology is not without challenges, including material toxicity, regulatory hurdles for approval, high initial investments, and the need for extensive digital expertise training. Sustainability concerns are also being addressed, with recycled materials and circular economy models gaining traction. In conclusion, this article advocates for a future where dentistry is shaped by interdisciplinary collaboration, intelligent automation, and hyper-personalized biocompatible solutions, with 3D printing firmly established as the backbone of next-generation dental care. Full article

Background: Jones fractures of the 5th metatarsal are frequently associated with nonunion due to limited vascularization and repetitive mechanical stress. The aim of the study was to compare the biomechanical performance of T-plate and bicortical screw fixation using standardized 3D models. Methods: Three-dimensional models of the 5th metatarsal were generated from CT images and printed using PolyJet technology (Stratasys J5 DentaJet) using a rigid-elastic composite with properties similar to cortical and cancellous bone. Jones fractures were fixed with either a locked T-plate or a bicortical screw. The samples were tested under axial and oblique static loads (α = 0°, 90°, 180°) and for three values of interfragmentary distance (d = 0.1–1 mm), in a 3 × 2 factorial design. Results: The T-plate fixation recorded a maximum yield force (Fmax) of 149.78 ± 8.53 N (138–161 N), significantly higher compared to the bicortical screw −98.56 ± 2.58 N (96–101 N), (p < 0.05). The ductility index was higher for the plate, indicating a progressive transition to yield. The α and d factors significantly influenced the mechanical behavior, with the polynomial model explaining over 95% of the total variation. Discussion: The plate fixation demonstrated greater strength and superior biomechanical tolerance in imperfect reduction scenarios. The main limitation is the lack of fatigue testing and the inability of 3D models to reproduce the structural heterogeneity of human bone. Conclusions: Implant selection should be individualized based on fracture stability. 3D models provide a reproducible platform for comparative evaluation of osteosynthesis methods, but future studies should include cyclic loading and biological validation. Full article

(1) While three-dimensional (3D) printing technology is increasingly being used for the fabrication of high-fidelity, patient-specific aortic models, data on the mechanical properties of polymers are sparse. Therefore, the aim of this study was to identify suitable polymers for this purpose. (2) Methods: Eight flexible polymers, with Shore A hardnesses (ShA) of 27–85, were tested to determine their suitability for PolyJet printing technology. They were tested against porcine aortic and bovine pericardial tissue for suture retention strength, uniaxial stress testing according to ISO 37, and burst pressure in a standardized test setting. (3) Results: The polymers with a ShA of 30–50 showed statistically non-inferior suture retention strength, tensile strength, and burst pressure resistance when compared to pericardial and aortic tissue, respectively. (4) Conclusions: This was the first report to analyze the mechanical properties of eight different flexible PolyJet polymers. We found that the polymers with a Shore A hardness of 30–50 most closely mimicked the mechanical properties of aortic tissue. Therefore, they can be recommended for the additive manufacturing (3D printing) of aortic phantoms for simulation and training purposes. Full article

PolyJet™ 3D printing is an additive manufacturing (AM) technology from Stratasys^TM. It has been used for applications such as tissue mimicking, printing anatomical models, and surgical planning. The materials available from Stratasys^TM have the inherent capabilities of producing a number of PolyJet™ materials with a range of physical properties that can be utilized for representing realistic tissue behavior mechanically. The preset materials available in the PolyJet™ printing software version 1.92.17.44384 GrabCAD^TM Print allow the user to manufacture materials similar to biological tissue, but the combinations of possibilities are limited and might not represent the broad spectrum of all tissue types. The purpose of this study was to determine the combination of PolyJet™ materials that most accurately mimicked a particular biological tissue mechanically. A detailed Design of Experiment (DOE) methodology was used to determine the combination of material mixtures and printing parameters and to analyze their mechanical properties that best matched the biological tissue properties available in the literature of approximately 50 different tissue types. Uniaxial tensile testing was performed according to the ASTM standard D638-14 of samples printed from Stratasys J850 digital anatomy printer to their determined stress–strain properties. The obtained values were subsequently validated by comparing them with the corresponding mechanical properties of biological tissues available in the literature. The resulting model, developed using the DOE approach, successfully produced artificial tissue analogs that span a wide range of mechanical characteristics, from tough, load-bearing tissues to soft, compliant tissues. The validation confirmed the effectiveness of the model in replicating the diverse mechanical behavior of various human tissues. Overall, this paper provides a detailed methodology of how materials and settings were chosen in GrabCAD^TM Print software and Digital Anatomy Creator^TM (DAC) to achieve an accurate artificial tissue material. Full article

The treatment of maxillofacial defects presents significant challenges due to the complexity of facial anatomy and the diversity of affected tissues. Traditional workflows are labor-intensive, costly, and limited in customization. Recent advancements in fully digital workflows and direct 3D printing technologies offer new possibilities for improving the fit, aesthetics, and efficiency of prosthetic manufacturing. This scoping review aims to evaluate the current state of direct 3D printing for maxillofacial soft prostheses, assess material properties and biocompatibility, and identify challenges and future directions in this field. Methods: A comprehensive search of PubMed and Scopus databases, along with a manual search of relevant journals, was conducted to identify studies published up to December 2024. Articles focusing on direct 3D printing of maxillofacial soft prostheses were included, while studies involving traditional or mold-based workflows, ocular prostheses, and literature reviews were excluded. Data on materials, manufacturing techniques, and clinical outcomes were extracted and analyzed. Results: Out of 898 articles screened, 11 were included, 5 of which were in vivo studies (case reports). The additive manufacturing methods used in these case reports were Drop-on-Demand (DoD) silicone printing and PolyJet technology. Conclusions: Fully digital workflows and direct 3D printing technologies show promise for advancing maxillofacial prosthesis manufacturing. However, the absence of dedicated software, biocompatible materials, and medium- to long-term clinical evaluations highlight significant research gaps. Future research should focus on material development, workflow optimization, and clinical validation to enable widespread clinical adoption. Full article

Accurate implant placement is essential for achieving successful outcomes. To aid in this, digitally designed surgical guides have been introduced. Both closed-sleeve and open-sleeve designs are commonly utilized. However, the closed-sleeve design has limitations with restricted interocclusal distance, interference with irrigation, and limited visibility, while the open-sleeve design is known to be less accurate. To address these limitations, a new slope-sleeve design was introduced. This design reduces the interocclusal distance requirement compared to the closed-sleeve design and provides improved accuracy. A constraint model with a 31 mm interocclusal distance was created, and three types of surgical guides (closed, open, and slope), printed using either a PolyJet or Digital Light Processing (DLP) 3D printer, were tested on resin bone blocks. Horizontal and angular deviations were measured for the accuracy of each guide after drilling, with data analyzed using one-way ANOVA and independent t-tests. The slope-sleeve design showed significantly lower horizontal and angular deviations in wide-sized guides. Additionally, PolyJet-printed guides showed higher accuracy compared to DLP-printed guides. The slope-sleeve guide offers enhanced stability and precision in restricted interarch spaces. When coupled with high-precision 3D printing technologies like PolyJet, the slope-sleeve design provides a reliable solution for improving implant placement accuracy in challenging clinical scenarios. Full article

The aim of this study was to investigate whether PolyJet technology, which uses rubber-like materials for printing and is known for its high resolution and performance, could be suitable for producing flexographic printing plates. In our research, we designed test plates that were printed using PolyJet technology with TangoBlackPlus FLX9870-DM resin. These 3D-printed plates were evaluated for their resistance to various flexographic inks and solvents, and their contact angles were measured. Subsequently, the prints were made on a Flexiproof device using water-based ink with both the test plates and traditional photopolymer plates across six different substrates. The print quality was assessed using densitometry and spectrophotometry. Our findings indicate that the 3D-printed plates are suitable for printing solid areas and lines with water-based inks. However, the print quality of the 3D-printed plates is slightly lower than that of the photopolymer plates, with the optical density values for the high-quality prints on coated papers being approximately 10% lower. Additionally, the plates printed with TangoBlack Plus resin appear to be suitable for UV inks due to their high resistance, but they are not resistant to the solvents used in solvent-based inks. Full article

This paper presents the development of the hardware and software architecture of a sixdegrees of freedom (DOF) parallel robot (PARA-SILSROB) by illustrating all the stages undertaken to achieve the experimental model of the robot. Based on the experimental model, the control architecture is also presented, which is primarily based on a master–slave control system through which the surgeon controls the robot using the master console composed of commercial peripheral components (two 3D Space Mouse devices, computer, and keyboard) integrated with the solution developed in this study and presented in this paper. The robot was developed also according to the surgical protocol and surgeon’s requirements, and for the functionality testing of the mechanical structure, two experimental stands were used. The first stand presented several surgical steps, such as manipulation, resection, and suture of experimental tissues (simulating real-life robot-assisted surgical maneuvers) using commercial instruments. The second stand presented a simulation of an esophagectomy for esophageal cancer and digestive reconstruction through a right intercostal approach. For this testing phase, the organs were created using 3D reconstruction, and their simplified models were 3D printed using PolyJet technology. Furthermore, the input trajectory generated using the master console was compared with the robot actuator’s movements and the obtained results were used for validation of the proposed robot control system. Full article

Additive manufacturing (AM) techniques are among the fastest-growing technologies for producing even the most geometrically complex models. Unfortunately, the lack of development of metrology guidelines for these methods, related to dimensional and geometry accuracy and surface roughness, significantly limits the commercialization of finished products manufactured using these methods. This paper aims to evaluate the macro- and micro-geometry of models manufactured using the PolyJet method from three types of photopolymer resins: Digital ABS Plus, RGD 720, and Vero Clear. For this purpose, test parts were designed and then manufactured on an Object 350 Connex3 3D printer. The Atos II Triple Scan optical system and the InfiniteFocusG4 microscope were used to evaluate macro- and micro-geometry, respectively. For both systems, measurement procedures were developed to obtain statistical results for evaluating geometric accuracy and surface roughness parameters. In the case of macro-geometry, for Digital ABS Plus and Vero Clear materials, 50% of the central deviations (between first quartile Q1 and third quartile Q3) lie within the range (−0.06, 0.03 mm) and for RGD 720 material within the range (−0.08, 0.01 mm). For micro-geometry, the arithmetic mean height (Sa) values for the Digital ABS Plus and Vero Clear samples were approximately 1.6 and 2.0 µm, respectively, while for RGD 720, it was 15.9 µm. The total roughness height expressed by reduced peak height (Spk) + core height (Sk) + reduced dale depth (Svk) for the Digital ABS Plus and Vero Clear samples was approximately 9.1 and 10.5 µm, respectively, while for the RGD 720, it was 101.9 µm. Full article
