Search Results (45)

Against the backdrop of an urgent energy crisis, solar energy has attracted sufficient attention as one of the most inexhaustible and friendly types of environmental energy. Faced with long service and harsh environment, the poor performance ratios of photovoltaic arrays and safety hazards are frequently boosted worldwide. In particular, the hot spot effect plays a vital role in weakening the power generation performance and reduces the lifetime of photovoltaic (PV) modules. Here, our research reports a spatial–temporal hot spot management system integrated with fiber Bragg grating (FBG) temperature sensor arrays and cooling hydrogels. Through finite element simulations and indoor experiments in laboratory conditions, a superior cooling effect of hydrogels and photoelectric conversion efficiency improvement have been demonstrated. On this basis, field tests were carried out in which the FBG arrays detected the surface temperature of the PV module first, and then a classifier based on an optimized artificial neural network (ANN) recognized hot spots with an accuracy of 99.1%. The implementation of cooling hydrogels as a feedback mechanism achieved a 7.7 °C reduction in temperature, resulting in a 5.6% enhancement in power generation efficiency. The proposed strategy offers valuable insights for conducting predictive maintenance of PV power plants in the case of hot spots. Full article

Solar energy has become a vital renewable energy source (RES), and photovoltaic (PV) systems play a key role in its utilization. However, the performance of these systems can be compromised by faulty panels. This paper proposes an innovative framework that combines the deep neural network VGG19 with the Jellyfish Optimization Search Algorithm (JFOSA) for efficient fault detection using aerial images. VGG19 excels in automatic feature extraction, while JFOSA optimizes feature selection and significantly improves classification performance. The new framework achieves impressive results, including 98.34% accuracy, 98.71% sensitivity, 98.69% specificity, and 94.03% AUC. These results outperform baseline models and various optimization techniques, including ant colony optimization (ACO), genetic algorithm (GA), and particle swarm optimization (PSO). The system demonstrated superior performance in detecting solar panel defects such as cracks, hot spots, and shadow defects, providing a robust, scalable, and automated solution for PV monitoring. This approach provides an efficient and reliable way to maintain energy efficiency and system reliability in solar energy applications. Full article

The performance of photovoltaic modules determines the lifetime of solar cells; however, accurate detection remains a challenge when facing smaller defects. To address this problem, in this paper, we propose a YOLO-WAD model based on YOLOv10n. Firstly, we replace C2f (CSP bottleneck with two convolutions) with C2f-WTConv (CSP bottleneck with two convolutions–wavelet transform convolution) in the backbone network to enlarge the receptive field and better extract the features of small-target defects (hot spots). Secondly, an ASF structure is introduced in the neck, which effectively fuses the different levels of output features extracted by the backbone network and enhances the model’s ability to detect small objects. Subsequently, an additional detection layer is added to the neck, and C2f is replaced by C2f-EMA (CSP bottleneck with two convolutions–efficient multi-scale attention mechanism), which can redistribute feature weights and prioritize relevant features and spatial details across image channels to improve feature extraction. Finally, the DyHead (dynamic head) detection head is introduced, which enables comprehensive scale, spatial, and channel awareness. This greatly enhances the model’s ability to classify and localize small-target defects. The experimental results show that YOLO-WAD detects our dataset with an overall accuracy of 95.6%, with the small-target defect detection accuracy reaching 86.3%, which is 4.1% and 9.5% higher than YOLOv10n and current mainstream models, verifying the feasibility of our algorithm. Full article

Solar energy plays a major role in the transition to renewable energy. To ensure that large-scale photovoltaic (PV) power plants operate at their full potential, their monitoring is essential. It is common practice to utilize drones equipped with infrared thermography (IRT) cameras to detect defects in modules, as the latter can lead to deviating thermal behavior. However, IRT images can also show temperature hot-spots caused by inhomogeneous soiling on the module’s surface. Hence, the method does not differentiate between defective and soiled modules, which may cause false identification and economic and resource loss when replacing soiled but intact modules. To avoid this, we propose to detect spatially inhomogeneous soiling losses and model temperature variations explained by soiling. The spatially resolved soiling information can be obtained, for example, using aerial images captured with ordinary RGB cameras during drone flights. This paper presents an electrothermal model that translates the spatially resolved soiling losses of PV modules into temperature maps. By comparing such temperature maps with IRT images, it can be determined whether the module is soiled or defective. The proposed solution consists of an electrical model and a thermal model which influence each other. The electrical model of Bishop is used which is based on the single-diode model and replicates the power output or consumption of each cell, whereas the thermal model calculates the individual cell temperatures. Both models consider the given soiling and weather conditions. The developed model is capable of calculating the module temperature for a variety of different weather conditions. Furthermore, the model is capable of predicting which soiling pattern can cause critical hot-spots. Full article

Hot-spot generation is critical to the performance and lifespan of photovoltaic (PV) modules; however, the underlying mechanisms of hot-spot formation have not been fully elucidated. This work conducted a localized shading test on a PV module, measured the micro-electrical characteristics and temperature distributions of both the shaded and unshaded cells, calculated the heat-source power densities, and then predicted the occurrence and locations of hot and cold spots via numerical simulations. It was found that, under an irradiance of 750 W/m², when one cell in a PV module is shaded by 1/2, the unshaded area within the shaded cell exhibited a hot spot, with the temperature reaching up to 77.66 °C, approximately 22.5 °C higher than the surrounding cells. The intrinsic mechanism for the occurrence of the hot spot is that, compared with the unshaded cells, the unshaded portion of the shaded cell can generate an extra significantly large Joule heat power density, about 1079.62 W/m². The reason for generating such a large Joule heat power density is that this portion is in a reverse-bias state with a high current density flowing through it, according to our measurements. In contrast, the shaded portion forms a cold spot, about 7.5 °C cooler than the surrounding cells. This is because the shaded portion can only generate a Joule heat power density of about 46.98 W/m² due to the small reverse-bias current density flowing through it and fails to absorb heat from solar irradiance, which is about 645 W/m². Moreover, this work demonstrates that the hot-spot temperature initially rises and then decreases with increasing shading ratio, with the highest temperatures and the most pronounced temperature changes occurring around a shading ratio of 1/2. The presented method can be also used to evaluate the performance and reliability of various other PV modules under local shading conditions. Full article

The development in the fields of clean energy, particularly wind and photovoltaic power, generates a large amount of data streams, and how to mine valuable information from these data to improve the efficiency of power generation has become a hot spot of current research. Traditional classification algorithms cannot cope with dynamically changing data streams, so data stream classification techniques are particularly important. The current data stream classification techniques mainly include decision trees, neural networks, Bayesian networks, and other methods, which have been applied to wind power and photovoltaic power data processing in existing research. However, the data drift problem is gradually highlighted due to the dynamic change in data, which significantly impacts the performance of classification algorithms. This paper reviews the latest research on data stream classification technology in wind power and photovoltaic applications. It provides a detailed introduction to the data drift problem in machine learning, which significantly affects algorithm performance. The discussion covers covariate drift, prior probability drift, and concept drift, analyzing their potential impact on the practical deployment of data stream classification methods in wind and photovoltaic power sectors. Finally, by analyzing examples for addressing data drift in energy-system data stream classification, the article highlights the future prospects of data drift research in this field and suggests areas for improvement. Combined with the systematic knowledge of data stream classification techniques and data drift handling presented, it offers valuable insights for future research. Full article

Currently, fault identification in most photovoltaic systems primarily relies on experienced engineers conducting on-site tests or interpreting data. However, due to limited human resources, it is challenging to meet the vast demands of the solar photovoltaic market. Therefore, we propose to identify fault types through the current–voltage curves of solar arrays, obtaining curves for various conditions (normal, aging faults, shading faults, degradation faults due to potential differences, short-circuit faults, hot-spot faults, and crack faults) as training data for the model. We employ a multi-input model architecture that combines convolutional neural networks with deep neural networks, allowing both the imagery and feature values of the current–voltage curves to be used as input data for fault identification. This study demonstrates that by inputting the current–voltage curves, irradiance, and module specifications of solar string arrays into the trained model, faults can be identified quickly using actual field data. Full article

Photovoltaic (PV) panels are prone to experiencing various overlays and faults that can affect their performance and efficiency. The detection of photovoltaic panel overlays and faults is crucial for enhancing the performance and durability of photovoltaic power generation systems. It can minimize energy losses, increase system reliability and lifetime, and lower maintenance costs. Furthermore, it can contribute to the sustainable development of photovoltaic power generation systems, which can reduce our reliance on conventional energy sources and mitigate environmental pollution and greenhouse gas emissions in line with the goals of sustainable energy and environmental protection. In this paper, we provide a comprehensive survey of the existing detection techniques for PV panel overlays and faults from two main aspects. The first aspect is the detection of PV panel overlays, which are mainly caused by dust, snow, or shading. We classify the existing PV panel overlay detection methods into two categories, including image processing and deep learning methods, and analyze their advantages, disadvantages, and influencing factors. We also discuss some other methods for overlay detection that do not process images to detect PV panel overlays. The second aspect is the detection of PV panel faults, which are mainly caused by cracks, hot spots, or partial shading. We categorize existing PV panel fault detection methods into three categories, including electrical parameter detection methods, detection methods based on image processing, and detection methods based on data mining and artificial intelligence, and discusses their advantages and disadvantages. Full article

While solar energy holds great significance as a clean and sustainable energy source, photovoltaic panels serve as the linchpin of this energy conversion process. However, defects in these panels can adversely impact energy production, necessitating the rapid and effective detection of such faults. This study explores the potential of using infrared solar module images for the detection of photovoltaic panel defects through deep learning, which represents a crucial step toward enhancing the efficiency and sustainability of solar energy systems. A dataset comprising 20,000 images, derived from infrared solar modules, was utilized in this study, consisting of 12 classes: cell, cell-multi, cracking, diode, diode-multi, hot spot, hot spot-multi, no-anomaly, offline-module, shadowing, soiling, and vegetation. The methodology employed the exemplar Efficientb0 model. From the exemplar model, 17,000 features were selected using the NCA feature selector. Subsequently, classification was performed using an SVM classifier. The proposed method applied to a dataset consisting of 12 classes has yielded successful results in terms of accuracy, F1-score, precision, and sensitivity metrics. These results indicate average values of 93.93% accuracy, 89.82% F1-score, 91.50% precision, and 88.28% sensitivity, respectively. The proposed method in this study accurately classifies photovoltaic panel defects based on images of infrared solar modules. Full article

Photovoltaic (PV) generation systems that are partially shaded have a non-linear operating curve that is highly dependent on temperature and irradiance conditions. Shading from surrounding objects like clouds, trees, and buildings creates partial shading conditions (PSC) that can cause hot spot formation on PV panels. To prevent this, bypass diodes are installed in parallel across each panel, resulting in a global maximum power point (GMPP) and multiple local maximum power points (LMPPs) on the power-voltage (P-V) curve. Traditional methods for maximum power point tracking (MPPT), such as perturb and observe (P&O) and incremental conductance (INC), converge for LMPPs on the P-V curve, but metaheuristic algorithms can track the GMPP effectively. This paper proposes a new, efficient, and robust GMPP tracking technique based on a nature-inspired algorithm called Ali Baba and the Forty Thieves (AFT). Utilizing the AFT algorithm for MPPT in PV systems has several novel features and advantages, including its adaptability, exploration-exploitation balance, simplicity, efficiency, and innovative approach. These characteristics make AFT a promising choice for enhancing the efficiency of PV systems under varied circumstances. The performance of the proposed method in tracking the GMPP is evaluated using a simulation model under MATLAB/Simulink environment, the achieved simulation results are compared to particle swarm optimization (PSO). The proposed method is also tested in real-time using the Hardware-in-the-loop (HIL) emulator to validate the achieved simulation results. The findings indicate that the proposed AFT-based GMPP tracking method performs better under complex partial irradiance conditions than PSO. Full article

To overcome the deficiencies in segmenting hot spots from thermal infrared images, such as difficulty extracting the edge features, low accuracy, and a high missed detection rate, an improved Mask R-CNN photovoltaic hot spot thermal image segmentation algorithm has been proposed in this paper. Firstly, the edge image features of hot spots were extracted based on residual neural networks. Secondly, by combining the feature pyramid structure, an edge-guided feature pyramid structure was designed, and the hot spot edge features were injected into a Mask R-CNN network. Thirdly, an infrared spatial attention module was introduced into the Mask R-CNN network when feature extraction and the infrared features of the detected hot spots were enhanced. Fourthly, the size ratio of the candidate frames was adjusted self-adaptively according to the structural characteristics of the aspect ratio of the hot spots. Finally, the validation experiments were conducted, and the results demonstrated that the hot spot contours of thermal infrared images were enhanced through the algorithm proposed in this paper, and the segmentation accuracy was significantly improved. Full article

Fires in photovoltaic modules are caused by hot spots, which are typically monitored by thermal images. This method helps visualize the hot spot, but it is affected by the environment (solar irradiance, wind, ambient temperature) and is not reproducible. Assessing the heat dissipation of the hot cell can be used for alternative assessment of the fire risk. This method was validated by comparing the value measured by the surface potential meter and the module potential measured directly by adding a bypass measurement circuit. The substantial reverse-bias voltage caused by mismatching or partial shading (depending on the operating conditions) leads to local heat consumption of the partially shaded solar cells and potentially causes fire. The fire risk can be assessed in the worst-case conditions (ex. 1380 W/m² solar irradiance) by non-contact measurement of the reverse-bias voltage and calculating the heat dissipation and temperature rise. This work suggested that −13 V is the criterion and was close to the known value of reverse voltage for Si cells. The current technology inspects solar cells before assembly to the module, and there is no way of inspecting in the product test or detecting after degradation that can be covered by the proposed method in this work. Full article

Infrared thermography (IRT) is a technique used to diagnose Photovoltaic (PV) installations to detect sub-optimal conditions. The increase of PV installations in smart cities has generated the search for technology that improves the use of IRT, which requires irradiance conditions to be greater than 700 W/${\mathrm{m}}^2$, making it impossible to use at times when irradiance goes under that value. This project presents an IoT platform working on artificial intelligence (AI) which automatically detects hot spots in PV modules by analyzing the temperature differentials between modules exposed to irradiances greater than 300 W/${\mathrm{m}}^2$. For this purpose, two AI (Deep learning and machine learning) were trained and tested in a real PV installation where hot spots were induced. The system was able to detect hot spots with a sensitivity of 0.995 and an accuracy of 0.923 under dirty, short-circuited, and partially shaded conditions. This project differs from others because it proposes an alternative to facilitate the implementation of diagnostics with IRT and evaluates the real temperatures of PV modules, which represents a potential economic saving for PV installation managers and inspectors. Full article

In contrast to commercial photovoltaic (PV) power plants, PV systems at universities are not actively monitored for PV module failures, which can result in a loss of power generation. In this study, we used thermal imaging with drones to detect rooftop PV module failures at a university campus before comparing reductions in power generation according to the percentage of module failures in each building. Toward this aim, we adjusted the four factors affecting the power generation of the four buildings to have the same values (capacities, degradations due to aging, and the tilts and orientation angles of the PV systems) and calibrated the actual monthly power generation accordingly. Consequently, we detected three types of faults, namely open short-circuits, hot spots, and potential-induced degradation. Furthermore, we found that the higher the percentage of defective modules, the lower the power generation. In particular, the annual power generation of the building with the highest percentage of defective modules (12%) was reduced by approximately 25,042 kWh (32%) compared to the building with the lowest percentage of defective modules (4%). The results of this study can contribute to improving awareness of the importance of detecting and maintaining defective PV modules on university campuses and provide a useful basis for securing the sustainability of green campuses. Full article

Photovoltaic (PV) systems have immense potential to generate clean energy, and their adoption has grown significantly in recent years. A PV fault is a condition of a PV module that is unable to produce optimal power due to environmental factors, such as shading, hot spots, cracks, and other defects. The occurrence of faults in PV systems can present safety risks, shorten system lifespans, and result in waste. Therefore, this paper discusses the importance of accurately classifying faults in PV systems to maintain optimal operating efficiency, thereby increasing the financial return. Previous studies in this area have largely relied on deep learning models, such as transfer learning, with high computational requirements, which are limited by their inability to handle complex image features and unbalanced datasets. The proposed lightweight coupled UdenseNet model shows significant improvements for PV fault classification compared to previous studies, achieving an accuracy of 99.39%, 96.65%, and 95.72% for 2-class, 11-class, and 12-class output, respectively, while also demonstrating greater efficiency in terms of parameter counts, which is particularly important for real-time analysis of large-scale solar farms. Furthermore, geometric transformation and generative adversarial networks (GAN) image augmentation techniques improved the model’s performance on unbalanced datasets. Full article
