This paper proposes a hybrid steel plate–bolt dry and wet jointing method, where the dry jointing part is a steel plate–bolt connector joint and the wet jointing part is a cast-in-place concrete. The novel precast concrete shear wall (PCW) combines the advantages of both dry and wet connections. A steel plate–bolt dry–wet hybrid connection shear wall model was developed using the finite element method, and a low circumferential reciprocating load was applied to the PCW. By analyzing the force and deformation characteristics of the wall, the results showed that the failure mode of novel PCWs was bending-shear failure. Compared to the concrete wall (CW), the yield load, peak load, and ductile displacement coefficient were 6.55%, 7.56%, and 21.49% higher, respectively, demonstrating excellent seismic performance. By extending the wall parameters, it was found that the increased strength of the novel PCW concrete slightly improved the load-bearing capacity, and the ductility coefficient was greatly reduced. As the axial compression ratio increased from 0.3 to 0.4, the wall ductility decreased by 22.85%. Increasing the reinforcement rate of edge-concealed columns resulted in a severe reduction in ultimate displacement and ductility. By extending the connector parameters, it was found that there was an increased number of steel joints, a severe reduction in ductility, enlarged distribution spacing, weld hole plugging and bolt yielding, reduced anchorage performance, and weakening of the steel plate section, which reduced the load-bearing capacity and initial stiffness of the wall, with little effect on ductility. Full article

As green and low-carbon materials, coir geotextiles have a broad application prospect in soil strengthening. In order to clarify the interface characteristics of coir geotextiles, the pullout test is performed on coir geotextiles by using transparent soil technology. The transparent soil is prepared by using fused quartz as the skeleton particle and the mixture of No. 15 industrial white oil and No. 3 industrial white oil as the pore fluid. The results show that the mechanical response of different pullout tests is basically similar, that is, with the increase in pullout displacement, the pullout force first increases rapidly, then slowly increases to the peak value, and then gradually decreases with the fluctuation. The adhesion of coir-geotextile–soil interface is 5.68 kPa and the internal friction angle is 3.43°. The interfacial friction coefficient of the coir geotextiles is unstable, ranging from 0.2 to 0.6. With the increase in normal stress, anchorage length, and pullout rate, the peak pullout force and the thickness of the shear band increase gradually. Full article

The mechanical properties of fully-grouted bolt support are critical for the safety of support engineering works. To study the influences of factors including the bolt length and diameter, strength of the rock, and fracture angle on the mechanical properties of fully-grouted bolt support, compression tests were conducted on an anchored rock mass, considering the shortcomings of pullout tests on bolts. The discrete element software PFC^2D (4.0) was adopted for numerical simulation and analysis from two aspects, namely, the stress distribution and anchorage force supplied by such bolts. The research found that by increasing the bolt diameter and length as well as the strength of the rock, the maximum anchorage force of bolts increases. Whereas the stress distribution of all bolts increases at first and then decreases along the bolts, and there is only one peak on the stress distribution curves, which also gradually shifts to a greater depth. In a fractured rock mass, the maximum anchorage force of bolts decreases, then increases (and is minimized at a fracture angle of 45°) with the decrease in fracture angle. The influence of fractures with different angles on the stress distribution of bolts is mainly reflected in the fracture zone. The bolt stress decreases abruptly in the zone with a fracture angle of 90°, forming a valley. The bolt stress increases suddenly in the zones with fracture angles of 60° and 45°, thus forming peaks. The bolt stress does not increase or decrease suddenly in the zone with a fracture angle of 30°. Therefore, it necessitates consideration of the influences of fractures on the anchorage force and the selection of bolts of appropriate size during anchorage design. After installation, the bolt stress should be monitored for stability and early warning of anchored rock mass according to changes in the stress provided. Full article

Full-length anchorage rockbolts are widely used in roadway reinforcement and rock controlling in underground mining. This article proposes using an elastic–debonding (ED) model to analyse the axial performance of rockbolts. The advantage of this ED model was that the full force–deformation curve of rockbolts comprised only three phases, which was relatively simpler to calculate. Its effectiveness was compared with experiment tests. Based on the ED model, a series of parameter studies was conducted. Results showed that for cross-section area of rock, there was a critical range. Once the cross-section area of rock was beyond that critical range, external rock had a mild impact on the axial performance of rockbolts. Rockbolt diameter significantly affected the axial performance of rockbolts. When rock diameter increased, the peak force of rockbolts increased linearly, while deformation at the peak force decreased non-linearly. The corresponding calculation equation between the peak force, deformation at the peak force, and rockbolt diameter was obtained. Borehole diameter had a mild impact on the axial performance of rockbolts. Increasing rockbolt length benefits improving the peak force of rockbolts. Rockbolt modulus of elasticity had a more apparent impact on the deformation at peak force. Mechanical properties of the bolt/grout (b/g) face affected the axial performance of rockbolts. Increasing the b/g face strength improved the peak force of rockbolts. Slippage at the ultimate load had a more apparent impact on the turning point between the elastic phase and the elastic–softening phase. Full article

Theoretical analysis and numerical simulation are used to study the influence of different parameters of variable diameter borehole pressure relief technology on the surrounding rock and support. A strain-softening model was established to analyze the intrinsic connection between the parameters of variable diameter boreholes and the evolution of surrounding rock stress, deformation law, and support strength. The results show that: (1) With the increase in shallow borehole diameter, it is easy to cause anchor de-anchoring phenomenon. (2) After the deep borehole diameter is more than 250 mm, it transfers the peak of the shallow vertical stress to the deep surrounding rock (about 16 m away from the coal wall). (3) If the position of the variable borehole aperture is set between the anchorage zone and the stress peak of the roadway, the stress transfer effect is better, and the influence and effective binding force on the surrounding rock is smaller. (4) When the spacing is 1.0 m~2.0 m, the vertical stress starts to transfer to the deep surrounding rock, the deformation of the surrounding rock is smaller, and the reduction in the effective binding force of the anchors is smaller. The result can provide a reference for similar production conditions. Full article

Roots anchor plants firmly to the soil, enabling them to effectively resist soil erosion and shear failure. Vegetation restoration has been acknowledged as one of the most useful measures for controlling soil loss; however, which root system characteristics were most beneficial for plant anchoring in the soil remains unclear. In the black soil region of northeastern China, which frequently experiences serious soil erosion, pullout tests were carried out on six species of soil and water conservation woody plants with different growth habits (deciduous shrubs, deciduous trees and evergreen trees), and the root geometry and topology of each species were determined. The results showed that the maximum uprooting force and activation displacement (the displacement at the maximum peak in the relationship curve between pulling force and displacement) of shrubs were significantly greater than those of trees, while deciduous trees were significantly greater than evergreen trees. Therefore, the ability of the whole root system to anchor the soil was the largest for shrubs, followed by deciduous trees, and the smallest for evergreen trees. The uprooting force and activation displacement were mainly affected by the root topological index, total root length and the number of inclined roots. The total root length had the greatest influence on the maximum uprooting force, and the root topology had the greatest influence on the activation displacement, both of which can be used as important predictors of plant root anchorage strength. In addition, the plants with the R-type root structure may have a greater ability to anchor the soi, and can be prioritized for vegetation restoration with black soils. These findings provide references and implications for identifying the effective plant strategies for eroded soil restoration in the black soil region of northeastern China and other areas with similar soil types and bioclimates. Full article

In order to investigate the dynamic response of embankment slopes supported by wooden frame beams and bamboo anchor rods under train loading, this study conducted model tests on embankment slopes supported by wooden frame beams and bamboo anchor rods and carried out three-dimensional numerical simulations of the slopes. This study focused on analyzing the effects of train loading frequency, the peak value difference, and the peak value of the soil pressure on the embankment slopes. This study also analyzed the horizontal displacement of the slope surface, the internal forces in the support structure, and the slope safety factor. The results indicated the following: (1) The increase in loading frequency from 2 Hz to 3 Hz resulted in a significant increase in dynamic soil pressure, with a smaller increase observed upon further frequency increments. Moreover, increasing the load or peak value difference led to an overall increase in the maximum dynamic soil pressure. (2) Under various loading conditions, the axial force in the top anchor rod was significantly greater than that in the middle anchor rod. Additionally, the axial force in the rod body exhibited a pattern of larger forces near the anchorage end and smaller forces near the anchor head. The location of the maximum bending moment in the anchor rod transitioned from the anchor head to the anchorage end as the slope depth increased. The bending moment of the anchor rod increased with the loading frequency but decreased with an increase in the peak value, showing a minor influence from the upper and lower peak values. (3) With the presence of this support system, the slope safety factor increased by 20.13%. A noticeable reduction in the horizontal displacement of the slope surface was observed, with the greatest reduction in the top slope area, followed by the slope angle. Full article

In order to explore the problems of load transfer and anchorage mechanisms of tensile anchors under pull-out load for geotechnical anchoring systems, a step-wise mathematical model is established which considers the linear–nonlinear shear stress and shear displacement of the anchorage segment, using an elasto-plastic constitutive model. The displacement, axial force, and shear stress of the anchorage interface in different stages (elastic, plastic, and debonding) are analyzed and solutions are derived. And the theoretical solutions for the ultimate pull-out load of the anchor at each stage are also presented. Two in situ pull-out tests are used to verify and apply these findings in engineering. The results show that the stepwise composite model could reflect the bonding, softening and residual characteristics of the anchoring interface. In the process of the pull-out load increasing, the pulling end of the anchor initially enters the plastic stage and the debonding stage, respectively, and the failure of the anchor occurs at the pulling end, and as the axial force transfers down deeper, the damage gradually spreads deeper. The axial force distribution of the anchorage section is a monotonically decreasing curve, and the peak point of the shear stress gradually moves deeper. The calculation results of the axial force distribution curve and load–displacement curve of the anchor are in good agreement with the measured values, which verifies the rationality and reliability of the theoretical prediction method. This method can provide a theoretical reference for the load transfer analysis and design of tension anchors for geotechnical anchoring systems. Full article

To research the internal load transfer behavior and failure mechanism of a bird’s nest anchor cable anchoring structure based on a pull-out test, a bond-slip failure model is established on the basis of statistical damage theory, and the distribution formula of shear stress at anchorage agent–rock interface is deduced. Combined with theoretical analysis, bird’s nest anchor cable pulling out test and particle flow code (PFC) numerical simulation test, as well as axial force distribution of the cable and shear stress distribution of its interface, help reveal its load transfer behavior and failure mechanism. Results show that: (1) The established bond-slip model can reflect the internal load transfer behavior and failure process of bird’s nest anchor cable anchorage structure. (2) The shear stress of the anchorage agent interface increases exponentially to the peak value and then decreases exponentially to the residual strength. The process is repeated at every location of the anchorage agent interface. The curve of the axial force and shear stress of the bird’s nest anchor cable is a negative exponential distribution with anchorage depth, and the maximum value occurs at the load end. (3) The crack of the anchorage agent interface extends from the load end to the other end and finally cuts through the whole interface. Rock mass generates radial cracks by the split effects of the bird’s nest. The failure mode is a combination of the debonding slip of the interface and the shear failure of the rock mass. The shear stress distribution and failure mode of the anchor structure are basically consistent according to laboratory tests and simulation tests, and PFC2D better reflects the internal load transfer behavior, failure mechanism, and failure process of the bird’s nest anchor cable under tensile loads. Full article

The short encapsulation pull-out test (SEPT) is extensively used in rockbolting research or engineering. The field SEPT is time-consuming and labor-intensive, and its result is only applicable to the tested in situ. The laboratory SEPT is usually employed in theoretical rockbolting research due to its easily controlled variables. However, the design of laboratory SEPT is quite different, as there is no standard testing method, resulting in the applicability and limitations of each study not being clear. Accordingly, the aim of this paper is to bridge the gap between laboratory SEPT research and field application. On the basis of thick-walled cylinder theory, a mechanical model of a rock bolt subjected to axial load was established under consideration of the deformational behavior of confining materials around the bolt. Plane stress analysis was introduced to derive the analytical relationship between the axial force of the bolt and the deformation of the confining materials. A new approach of laboratory SEPT sample design was established, namely, equivalent radial stiffness theory, to simulate anchorage performance in a specific in-situ geocondition. Consequently, the field SETP could be replaced by laboratory testing using properly designed bolting samples with a certain level of accuracy. In addition, the application scope of previous laboratory SEPT research could be accurately defined. Laboratory SEPT was carried out to study the anchoring performance of right spiral rebar bolts under different confining materials. Poly Vinyl Chloride (PVC) tubes with a thickness of 31 mm, #60 aluminum (Al) tubes with a thickness of 5.8 mm, and #20 steel tubes with a thickness of 5.5, 7.0 mm were used in sample preparation to simulate soft, medium, and hard surrounding rocks in the field. The anchorage performance of the bolt under different geoconditions was systematically proposed, which provides a technical approach for similar research using different anchoring materials. A negative exponential expression formulating the axial load capacity of the right spiral bolts for the full spectrum of the surrounding rocks’ strength was derived on the basis of theoretical analysis and data regression. It can be used for preliminary reinforcement design, as well as the accurate key parameter setting in the numerical calculation of roadway deformation using right spiral bolts. The theoretical prediction is highly consistent with the testing results in the literature, which confirms the validity and reliability of this research. This study contributes to the establishment of a laboratory SEPT standard in rock mechanics. Full article

With the increase of mining depth and strength, the evolution of bolt axial force is increasingly becoming important for ensuring the reliability and safety of support. To improve the problem of the existing coal mine roadway pressure-monitoring method, whereby it is difficult to continuously monitor the axial force of the bolt over a long period of time, a full rod fiber bragg grating (FBG) force-measuring bolt and system were designed based on the principle of fiber grating sensing. It was found that a trapezoidal groove is a relatively better groove. The linearity between the center wavelength offset of the fiber grating and the axial force was more than 0.99, and the conversion formula between the axial force of the bolt rod and the wavelength change of the fiber grating were obtained. The real-time monitoring revealed that the axial force of the bolt obviously changed before and after compression. The axial force distribution curve can be divided into the stable zone, growth zone, and peak zone. The influence of the roadway abutment pressure was approximately 130 m ahead of the working face, and the peak area was within the 25–35 m range of the advance working face. The axial force of the bolt rod at the end of the anchorage linearly increased with the tail end of the bolt, the axial force of the free segment was the largest, and the overall stress was essentially the same. The application results demonstrate the feasibility and effectiveness of the FBG full-length force bolt. Full article
