Accurate extraction of transmission towers from Unmanned Aerial Vehicle (UAV) Light Detection and Ranging (LiDAR) point clouds is a prerequisite for overhead transmission line (OTL) acceptance. This task remains challenging because tower points are heavily entangled with ground, vegetation, conductors, and insulators, especially in complex terrain. To address this issue, we propose a shape prior-guided coarse-to-fine framework for tower extraction from UAV LiDAR point clouds. First, candidate tower regions are localized from the scene point cloud through preprocessing, near-ground suppression, and density-based clustering. Second, the least-disturbed central body of each candidate tower is identified in a slice-wise manner and used to estimate the tower orientation and four principal structural axes. Third, side-view and front-view structural envelopes are progressively inferred to suppress non-tower points around the tower body and tower head. Finally, a base-constrained filtering strategy is introduced to remove residual ground and low-vegetation points within the tower footprint. Experiments conducted on multiple OTL datasets acquired in different regions of China, including plains and mountainous areas, demonstrate that the proposed method achieves robust and efficient tower extraction across diverse scenarios. The results indicate that explicit structural priors offer a promising complement to feature-driven and data-intensive approaches, particularly in scenarios with limited annotated data and strict real-time requirements. The proposed method processes scene point clouds containing tens to hundreds of millions of points, with an average extraction time of approximately 100 to 300 s per tower depending on scene density. Full article

To address safety hazards such as line damage and operational instability caused by icing on high-voltage overhead transmission lines, this study conducts numerical simulation research on wire vibration de-icing based on the ANSYS finite element platform. Using a 100 m span transmission line as the research model, 49.8 m ice-covered sections are set on both sides of the line, and the 0.4 m range in the middle is designated as the concentrated excitation force area of the vibration motor. By applying intermittent harmonic loads in the excitation stage, the process of mechanical vibration de-icing is accurately reproduced. At the same time, life and death element technology is introduced to remove ice-covered units with stress exceeding the critical failure threshold, accurately realizing the dynamic simulation of the entire process of ice-covering cracking and detachment. This study selects resonance frequency bands that are suitable for the structural characteristics of the transmission line through static analysis, modal analysis, and harmonic response analysis, and preliminarily locks in candidate excitation frequencies. Combined with transient dynamics simulation, the optimal excitation frequency for vibration de-icing of transmission lines is determined by comprehensively considering the efficiency of de-icing and the safety constraints of conductor dancing. A method for determining the optimal de-icing frequency based on multi-step finite element analysis has been developed, which can provide theoretical support and simulation reference for the structural design, frequency matching, and operational parameter optimization of mechanical vibration de-icing devices for high-voltage transmission lines and overhead cables. Full article

Aiming at the core pain point that in existing object detection models, it is difficult to balance detection accuracy and real-time inference efficiency on edge computing devices in UAV-based intelligent inspection of power transmission lines, this paper proposes a lightweight YOLO-PowerLiteV2 model for anomaly target detection in power transmission lines to address the shortcomings of YOLO-PowerLite. Based on YOLO11n as the baseline, the model achieves compression of model volume while guaranteeing detection performance through four core improvements: the C3k2-UIB lightweight backbone module, the MCA (Multi-scale Cross-Axis) attention mechanism, the MBConv lightweight detection head, and the MFM (Modulation Feature Fusion) module. Experiments were conducted on a dataset constructed from 5563 aerial images of transmission lines containing three types of targets: bird nests, defective insulators, and balloons. The results show that YOLO-PowerLiteV2 achieves a mAP@50 of 95.2%, with only 0.97 M parameters and 2.8 G floating point operations (FLOPs). Compared with the baseline model, the number of parameters is reduced by 62.5%, and FLOPs are decreased by 56.25%. On the NVIDIA Jetson Xavier NX edge platform, the model achieves 59.5 FPS with only 16.8 ms latency, outperforming the baseline by 31% in frame rate. Its comprehensive performance outperforms mainstream lightweight detection models. The model demonstrates excellent adaptability to UAV edge-terminal deployment requirements, thereby providing technical support for real-time intelligent inspection of power transmission lines. Full article

The problem of path following control for underactuated Unmanned Surface Vehicles (USVs) is tackled in this work, and a scheme based on Predicted Adaptive Line-of-Sight (PALOS) is put forward. At the guidance level, prediction techniques and adaptive mechanisms are incorporated to eliminate the inherent assumption of small sideslip angle in the conventional LOS methods, enabling online estimation and dynamic feedforward compensation of time-varying sideslip angles. On the control side, radial basis function neural networks are combined with virtual parameter learning techniques to achieve online approximation of the lumped uncertainties, which include modeling inaccuracies and external disturbances. An adaptive control scheme based on lifelong learning mechanisms is developed, wherein the historical knowledge is constructed and preserved through feedback terms to achieve knowledge retention and on-demand reuse, thereby enhancing control efficiency and mitigating catastrophic forgetting. Additionally, a self-triggered mechanism acts as a knowledge transfer instrument, reducing communication overhead, relaxing transmission conditions, and rigorously precluding Zeno behavior. Through theoretical derivations, one can prove that all closed-loop signals are uniformly ultimately bounded. Comprehensive numerical simulations based on the 1:70 CyberShip II scale-model ship dynamics under complex sea conditions verify the proposed approach to be both effective and practical. Full article

Hybrid transmission corridors combining overhead lines and underground cables introduce impedance discontinuities that significantly modify electromagnetic transient behavior. These discontinuities generate traveling-wave reflections, waveform distortions, and high-frequency components at relay measurement locations during the first microseconds following disturbance inception. This paper presents a waveform-level electromagnetic transient (EMT) analysis of overhead–cable transition effects using detailed EMTP-RV simulations including frequency-dependent line and cable models, tower representations, grounding systems, and instrument transformers within a differential protection measurement framework. The results show that overhead–cable transitions produce transient waveform modifications characterized by reflections, attenuation, dispersion, and temporary current imbalance mechanisms associated with traveling-wave propagation and cable capacitive effects. The analysis also demonstrates the transient evolution of instantaneous waveform-derived (EMT-derived) differential and restraining current quantities, defined as combinations of terminal current signals obtained directly from EMT waveforms. These quantities do not represent final phasor-domain operating values of practical numerical relays, but provide insight into the transient electromagnetic environment preceding conventional filtering and phasor estimation. The study contributes to a clearer physical interpretation of transient phenomena in hybrid transmission systems and supports EMT-based evaluation of signals relevant to differential protection applications. Full article

Galloping of overhead transmission lines is a low-frequency, large-amplitude vibration hazard that poses a severe threat to power grid safety, yet existing monitoring approaches fail to simultaneously provide flexible deployment, quantitative measurement, and robustness under severe weather conditions. This paper makes three primary contributions. First, we propose a novel line-structure center adsorption algorithm that converts a single operator touch-point into a sub-pixel-precision conductor prompt, achieving prompt accuracy above 95% with one round of interactive correction. Second, we introduce—for the first time—SAM2’s streaming memory architecture for continuous zero-shot pixel-level tracking of galloping conductors under complex outdoor backgrounds including snow, ice, and poor illumination, achieving a segmentation IoU of 93.8% and zero identity switches over 500 consecutive frames, outperforming XMem (87.4%) and DeAOT (88.9%). Third, we develop a two-stage spatial correction framework combining vanishing-point-based inverse perspective mapping (IPM) with equidistant linear transformation (ELT), which eliminates perspective distortion inherent in non-orthogonal field imaging and enables quantitative measurement of galloping amplitude (error < 0.5 m), frequency (error < 0.1 Hz), and inter-phase spacing (ranging error < 1 m). The complete pipeline is implemented on a portable, tripod-mounted device (≤15 kg) integrating a monocular camera, laser rangefinder, and high-precision PTZ gimbal. Field validation at three 110/500 kV sites in Jiangsu Province under extreme winter conditions ($-4$ °C, Level 5 wind, continuous snowfall) confirms engineering-grade accuracy and practical robustness, providing a viable technical pathway for real-time non-contact galloping monitoring and disaster early warning. Full article

A condition assessment of a group of field-aged insulators operated for only 6 years on the island of Rhodes after incidents of intense electrical activity is presented in this paper. The investigated insulators were in service in 150 kV overhead transmission lines operating in proximity to the seacoast, exposed to the action of marine pollution. Although the same type of insulator has been widely used in similar conditions, both on the island of Rhodes and on the island of Crete, incidents of intense electrical activity have only been experienced in a specific area on the southwest side of Rhodes. To understand the deterioration mechanism, in addition to a group of failed insulators, a number of insulators from the same area without indication of deterioration were removed to be tested. In total, 40 insulators were examined: 23 with extensive failure, three without any deterioration and 14 with different levels of tracking and erosion traces along the polymeric housing. A series of tests were performed, including visual inspection, hydrophobicity classification, insulation performance through tanδ measurements, an adhesion test between the polymeric housing and the rod and material identification of the housing material through FTIR-ATR. The results indicate that the main failure mechanism is insulator flashunder due to the poor adhesion between the polymeric housing and the rod, as well as the poor sealing of insulators, favoring the ingress of water on the insulator rod and the initiation of electrical discharges. Full article

Power Line Communication (PLC) utilizes the existing power line infrastructure for data transmission and offers the advantage of low deployment costs. However, the PLC channel is subject to a highly complex network topology, frequent load variations, and noise as well as impulsive interference introduced by the switching operations of various electrical devices. As a result, it exhibits pronounced frequency-selective fading and time-varying characteristics. Under such challenging channel conditions, existing PLC transmission schemes are no longer sufficient to meet increasing performance requirements. This paper introduces the Chase combining mechanism of Hybrid Automatic Repeat Request (HARQ) into the PLC physical-layer link. At the receiver, soft information from multiple transmissions is accumulated, thereby improving the transmission stability and resource utilization efficiency of PLC under complex channel environments. Simulation results show that Chase combining can significantly reduce the bit error rate in the low signal-to-noise ratio region and enhance link reliability in complex PLC noise environments. Hardware implementation results indicate that the main overhead of this mechanism is concentrated in buffering and accumulation logic, demonstrating its feasibility for Field-Programmable Gate Array (FPGA) implementation. Full article

To address the challenges of insufficient small target recognition, difficulty in edge information extraction, and high computational overhead in insulator defect detection, this paper proposes a lightweight detection method based on the YOLO-MLSL model for transmission line insulator defect detection. First, a C2f-LRFCA module is introduced, effectively enhancing feature interaction through a long-range convolutional attention mechanism, thereby improving the perception of fine-grained defects. Second, an MEUM multi-scale feature enhancement module is designed to achieve more efficient contextual information fusion during upsampling, improving the detection performance for multi-scale targets. Third, the ShapeIoU loss function is employed to improve the bounding box regression accuracy in complex backgrounds, and LAMP pruning technology significantly reduces the model’s computational and storage overhead. Experimental results show that the improved algorithm achieves an mAP@0.5 of 85.4%, a 4.1% improvement compared to the original YOLOv8n, while maintaining a low parameter count and computational complexity, demonstrating both high accuracy and efficiency. This research provides a valuable reference for the design and application of lightweight target detection models in the intelligent inspection of power equipment. Full article

The planning and design of Extra-High Voltage (EHV) overhead power lines require strict adherence to electromagnetic field exposure limits to ensure public safety. This paper presents a comprehensive analysis of the minimum ground clearance required for standard 400 kV transmission towers to comply with international safety guidelines. A review of legislative frameworks across 37 countries indicates a widespread consensus on limiting values of 5 kV/m for the electric field and 100 $\mathsf{\mu }$T for magnetic flux density. Using analytical methods, the electric and magnetic fields were calculated for four common tower geometries (Cat, Portal, Danube, and Barrel) under varying ground clearances and phase configurations. The results demonstrate that the magnetic flux density is not a limiting factor, as it remains well below safety thresholds even at standard technical clearances. Conversely, the electric field intensity proves to be the critical design constraint, often requiring clearances significantly higher than those dictated by insulation coordination. The study identifies that optimizing the phase sequence in double-circuit towers can reduce the required ground clearance by up to 28%, offering a cost-effective mitigation strategy. These findings provide power line designers with essential decision-making data for the preliminary design phase, enabling the optimization of tower geometry and phase arrangement without the need for computationally intensive simulations. Full article

For high-voltage power transmission, the surface voltage gradient (SVG) of the conductor plays a crucial role in meeting corona performance requirements. The SVG is greatly impacted by the smoothness of the conductor’s surface. Under identical conditions, the SVG of smooth, round conductors differs from that of stranded conductors with the same outer radius. This paper uses Finite Element Analysis (FEA) to study the effect of different stranded conductor geometries and three-phase line topologies with stranded conductor bundles on the SVG. Although industry standards and the scientific literature often rely on simplified smooth-cylinder approximations, this research demonstrates that surface irregularities significantly increase electrical stress compared to idealized smooth surfaces. Through simulating various three-phase configurations, the study reveals a nearly constant field enhancement factor across diverse stranded designs. These results enable us to apply formulas developed for smooth conductors to more realistic power line applications involving stranded conductor bundles. Consequently, this FEA approach offers engineers a precise, versatile method for designing high-voltage transmission lines. The findings presented here facilitate a deeper understanding of the SVG surrounding stranded conductors, particularly with regard to its influence on corona phenomena. Full article

The increasing deployment of shared transmission corridors for High-Voltage Alternating Current (HVAC) and High-Voltage Direct Current (HVDC) systems has intensified the need to evaluate electromagnetic compatibility in hybrid overhead line configurations. This study presents an analytical methodology to estimate the electric field magnitude and magnetic flux density generated by hybrid HVAC–HVDC transmission lines under steady-state operating conditions. The electric field is determined using the Maxwell potential matrix combined with the image method, while the magnetic field is obtained from a formulation based on the Biot–Savart law. Two representative case studies were analyzed with identical electrical operating conditions but different transverse conductor arrangements to evaluate the influence of geometry on the electromagnetic environment of the corridor. The results show that variations in the spatial configuration of the conductors produce noticeable changes in the location and magnitude of the electric and magnetic field maxima across the right-of-way. These findings demonstrate that conductor geometry plays a key role in the electromagnetic behavior of hybrid corridors and should be considered in the design and assessment of HVAC–HVDC transmission systems. Full article

Typhoon-induced extreme weather poses a severe threat to power systems with high offshore wind penetration. Source-side wind turbine tripping and grid-side transmission line failures are likely to occur simultaneously, which may trigger cascading outages and large-scale load shedding. A multi-level source-grid-load-storage preventive resilience dispatch strategy is proposed. A typhoon spatiotemporal evolution model is first established based on the Batts gradient wind model. Failure probability models for offshore wind turbines and overhead transmission lines are developed while considering strong wind and lightning strike effects. The most probable and severe fault scenario is identified using an entropy-based quantification method. A two-stage robust preventive dispatch model is subsequently formulated. In the day-ahead stage, unit commitment, multi-type reserve allocation, and pumped storage scheduling are optimized at a 1 h resolution. In the real-time stage, combined wind-storage systems are coordinated at a 10 min resolution to accommodate rapid wind power ramps caused by high-wind shutdown events. The model is reformulated through Lagrangian duality and solved by the Benders decomposition algorithm. Case studies on a modified IEEE-RTS 24-bus system with three offshore wind farms demonstrate that the proposed strategy reduces wind curtailment by 66.3%, load shedding by 74.6%, and total cost by 14.8% compared with the case without energy storage. The combined operation cost of storage resources accounts for only 3.1% of the total cost, confirming its favorable cost-effectiveness for resilience enhancement. The proposed strategy contributes to the sustainable integration of offshore wind energy by ensuring a reliable power supply during extreme weather events. Full article

This paper presents an experimental investigation of dynamic line rating (DLR) applied to aluminium conductor steel-reinforced (ACSR) overhead line conductors, with a specific focus on wind speed conditions up to 5 m/s. An experimental system was designed and implemented to provide controlled and repeatable cross-flow air conditions along a tested ACSR conductor, enabling direct measurement of wind speed in the immediate vicinity of the conductor surface. Conductor temperature, electrical current, voltage drop per unit length, the phase angle between them, and relevant meteorological parameters were continuously measured under controlled experimental conditions. Based on the measured data, the conductor heat balance was evaluated and the allowable current-carrying capacity was determined. The experimentally obtained conductor temperatures and ampacity values were compared with results calculated using thermal models and correlations recommended by IEEE, CIGRÉ, and IEC standards. The comparison demonstrates that, under low and moderate wind speed conditions, differences between standard-based predictions and experimental results can be significant, leading to deviations in the estimation of allowable current-carrying capacity. The results confirm the high sensitivity of DLR calculations to wind-related assumptions and provide an experimentally validated basis for assessing the applicability and limitations of existing standard thermal models for ACSR conductors under realistic operating conditions. Full article

To overcome the limitations of existing transmission-line inspection models, including reduced detection precision in complex environments, inadequate performance for small objects and multi-scale targets, and high model complexity, a novel foreign object detection method for transmission lines is proposed in this study, based on an enhanced YOLOv8 architecture. First, the original YOLOv8 backbone is substituted with EfficientNetV2 to achieve model lightweighting while improving detection performance. Second, a Slim-neck module is integrated into the YOLOv8 neck to promote cross-layer information propagation and improve feature perception, which in turn boosts the detection performance on small objects. Meanwhile, an efficient multi-scale attention (EMA) is incorporated to boost multi-scale target detection performance, reduce computational overhead, and strengthen feature representation robustness. Finally, the localization performance of predicted targets is further improved by adopting MPDIoU rather than the original loss function. The experimental results indicate that the proposed method attains 97.7% precision, 95.6% recall, and a 97.5% mAP50, outperforming mainstream detection algorithms in comparative evaluations. Furthermore, relative to the baseline model, the Params and GFLOPs are reduced by 32.1% and 31.6%, respectively, thereby achieving a lightweight design and demonstrating its suitability for transmission-line foreign object detection. Full article
