Search Results (120)

Accurate identification of active-layer compositions in organic photovoltaic (OPV) devices often relies on invasive techniques such as electrical measurements or material extraction, which risk damaging the device. In this study, we propose a non-invasive classification approach based on simulated full-device absorption spectra. To account for fabrication-related variability, the active-layer thickness varied by over ±15% around the optimal value, creating a realistic and diverse training dataset. A multilayer perceptron (MLP) neural network was applied with various activation functions, optimization algorithms, and data split ratios. The optimized model achieved classification accuracies exceeding 99% on both training and testing sets, with minimal sensitivity to random initialization or data partitioning. These results demonstrate the potential of applying deep learning to spectral data for reliable, non-destructive OPV composition classification, paving the way for integration into automated manufacturing diagnostics and quality control workflows. Full article

Organic photovoltaic (OPV) technology, namely, organic solar cells (OSCs), have garnered attention as a sustainable and adaptable substitute for traditional silicon-based solar panels. Their lightweight construction, adaptability with various substrates, and capacity for low-energy production techniques make them formidable contenders for sustainable energy applications. Nonetheless, due to the swift advancement of OPV technology, there is increasing apprehension that existing life cycle assessment (LCA) studies may inadequately reflect their environmental consequences. This review aggregates and assesses LCA research to ascertain the extent to which existing studies accurately represent the genuine sustainability of OPVs. This paper conducts a comprehensive analysis of materials, manufacturing processes, device architecture, and end-of-life pathways, identifying methodological deficiencies, emphasizing critical environmental performance metrics, and examining how conceptual product design can improve environmental results. The results highlight the necessity for standardized, transparent LCA frameworks adapted to the changing OPV landscape. Full article

Conductive polymers play a crucial role in the advancement of modern technologies, particularly in the field of organic photovoltaics (OPVs). Due to advantages such as flexibility, low specific weight, ease of processing, and low production costs, polymeric materials present an attractive alternative to traditional photovoltaic materials. This study investigates the properties of a polymer blend composed of PCPDTBT (donor) and PNDI(2HD)2T (acceptor), used as the active layer in bulk heterojunction (BHJ) solar cells. The motivation behind this research was the search for a novel n-type polymer material with potentially better properties than the commonly used P(NDI2OD-T2). Comprehensive characterization of thin films made from the individual polymers and their blend was conducted using Fourier Transform Infrared Spectroscopy (FTIR), Atomic Force Microscopy (AFM), Scanning Electron Microscopy (SEM), Ultraviolet-Visible Spectroscopy (UV-Vis), four-point probe conductivity measurements, and photovoltaic testing. The prepared films were continuous, uniform, and exhibited low surface roughness (R_a < 2.5 nm). Spectroscopic analysis showed that the blend absorbs light in a broad range of the spectrum, with slight bathochromic shifts compared to individual polymers. Electrical measurements indicated that the blend’s conductivity (9.1 µS/cm) was lower than that of pure PCPDTBT but higher than that of PNDI(2HD)2T, with an optical band gap of 1.34 eV. Photovoltaic devices fabricated using the blend demonstrated an average power conversion efficiency (PCE) of 6.45%, with a short-circuit current of 14.37 mA/cm² and an open-circuit voltage of 0.89 V. These results confirm the feasibility of using PCPDTBT:PNDI(2HD)2T blends as active layers in BHJ solar cells and provide a promising direction for further optimization in terms of polymer ratio and processing conditions. Full article

In recent years, the design and synthesis of high-performing conjugated materials for the application in organic photovoltaics (OPVs) have achieved lab-scale devices with high power conversion efficiency. However, most of the high-performing materials are still synthesised using complex multistep procedures, resulting in high cost. For the upscaling of OPVs, it is also important to focus on conjugated polymers that can be made via fewer simple synthetic steps. Therefore, an easily synthesised amorphous thiophene−quinoxaline donor polymer, TQ1, has attracted our attention. An analogue, TQ-EH that has the same polymer backbone as TQ1 but with short branched side-chains, was previously reported as a donor polymer with increased crystallinity. We have synthesised copolymers with varied ratios between octyloxy and branched (2-ethylhexyl)oxy-substituted quinoxaline units having the same polymer backbone, with the aim to control the aggregation/crystallisation behaviour of the resulting copolymers. The optical properties, glass transition temperatures and degree of crystallinity of the new copolymers were systematically examined in relation to their copolymer composition, revealing that the composition can be used to fine-tune these properties of conjugated polymers. In addition, multiple sub-T_g transitions were found from some of the polymers, which are not commonly or clearly seen in other conjugated polymers. The new copolymers were tested in photovoltaic devices with a fullerene derivative as the acceptor, achieving slightly higher performances compared to the homopolymers. This work demonstrates that side-chain modification by copolymerisation can fine-tune the properties of conjugated polymers without requiring complex organic synthesis, thereby expanding the number of easily synthesised polymers for future upscaling of OPVs. Full article

The increasing technical and economic viability of photovoltaic solar energy technologies includes modules with organic photovoltaic (OPV) cells, which have shown significant efficiency increases, reaching 20% for research devices. This study investigated the photodegradation and associated loss mechanisms in OPV devices under tropical conditions in Brazil. The electrical and optical characteristics of the modules were correlated with chemical and structural changes when exposed to sunlight. Electrical parameters were monitored over time on external test benches and measured in solar simulators, while changes in the optical transmission and absorption of the films were analyzed. Scanning electron microscopy, energy-dispersive spectroscopy, and Fourier-transform infrared spectroscopy were used to study the physical and chemical properties of the materials. We found that photodegradation causes bound breakage in the active layer, altering the carbon structure and consequently reducing the module’s output power. The primary reasons for the activation and progression of this mechanism are high temperature and elevated solar irradiance. Therefore, we demonstrate that understanding these mechanisms is essential for the development of more sustainable OPVs in tropical climates. Full article

Nowadays, the development of devices based on organic materials is an interesting research challenge. The performance of such devices is strongly influenced by material selection, material properties, design, and the manufacturing process. Usually, buckminsterfullerene (C60) is employed as electron transport material in organic photovoltaic (OPV) devices due to its high mobility. However, considering its low solubility, there have been many attempts to replace it with more soluble non-fullerene compounds. In this study, bulk heterojunction thin films with various compositions of zinc phthalocyanine (ZnPc), a perylene diimide derivative, or C60 were prepared by matrix-assisted pulsed laser evaporation (MAPLE) technique to assess the influence of C60 replacement on fabricated heterostructure properties. The investigations revealed that the optical features and the electrical parameters of the organic heterostructures based on this perylene diimide derivative used as an organic acceptor were improved. An increase in the J_SC value (4.3 × 10⁻⁴ A/cm²) was obtained for the structures where the perylene diimide derivative acceptor entirely replaced C60 compared to the J_SC value (7.5 × 10⁻⁸ A/cm²) for the heterostructure fabricated only with fullerene. These results are encouraging, demonstrating the potential of non-fullerene compounds as electron transport material in OPV devices. Full article

In recent years, third-generation solar cells have experienced a remarkable growth in efficiency, making them a highly promising alternative energy solution. Currently, high-efficiency solar cells often use top electrodes fabricated by thermal evaporation, which rely on high-cost and high energy-consumption vacuum equipment, raising significant concerns for mass production. This study develops a method for fabricating silver electrodes using the screen-printing process, aiming to achieve solar cell production through an all-solution coating process. By selecting appropriate blocking-layer materials and optimizing the process, we have achieved device efficiencies for organic photovoltaics (OPVs) with screen-printed silver electrodes comparable to those with silver electrodes fabricated by thermal evaporation. Furthermore, we developed a method to cure the silver ink using near-infrared (NIR) annealing, significantly reducing the curing time from 30 min with hot air annealing to just 5 s. Additionally, by employing sheet-to-sheet (S2S) slot-die coating, we scaled up the device area and completed module development, successfully verifying stability in ambient air. We have also extended the application of screen-printed silver electrodes to perovskite solar cells (PSCs). Full article

This paper investigates TiN for its potential to enhance light-harvesting efficiency as an alternative material to Au for nanoscale plasmonic light trapping in thin-film solar cells. Using nanosphere lithography (NSL), plasmonic arrays of both Au and TiN are fabricated and characterized. Later, the fabricated TiN and Au arrays are integrated into a thin-film organic photovoltaic (OPV) device with a PBDB-T:ITIC-M bulk heterojunction (BHJ) active layer. A comparative study between these Au and TiN nanostructured arrays evaluates their fabrication process and plasmonic response, highlighting the advantages and disadvantages of TiN compared to a conventional plasmonic material such as Au. The effect of the fabricated arrays when integrated into an OPV is presented and compared to understand the viability of TiN. As one of the first experimental studies utilizing TiN arrays for the plasmonic enhancement of photovoltaics, the results offer valuable insight that can guide future applications and decisions in design. Full article

The global interest in environmental issues and sustainable energy has propelled extensive research in photovoltaic (PV) technologies. Brazil has emerged as one of the top ten solar energy producers and flexible PV suppliers in the world. In this context, organic photovoltaic cells (OPVs) have garnered attention due to their flexibility and ability to integrate into various surfaces, albeit facing challenges regarding lifespan and efficiency compared to silicon cells. This review examines the current state of research on OPVs and thin-film solar technologies, employing the systematic literature review methodology Proknow-C. The review includes an analysis of raw materials such as conductive polymers, fabrication processes including film deposition and encapsulation, and technological advancements that enhance the efficiency and stability of OPVs. Utilizing the Proknow-C methodology, a bibliographic portfolio was constructed to identify the current state of research in this field. Of 268 papers from major scientific databases, only 30 were deemed relevant to the theme, highlighting a significant research gap. This paper is a valuable resource for researchers, providing an updated overview and a foundation for future investigations in organic photovoltaics. The results emphasize the importance of materials such as conductive polymers and donor–acceptor molecules and the role of nanotechnology in advancing OPVs. Innovations in manufacturing techniques, such as inkjet and blade coating-based printing techniques, are shown to increase efficiency by providing precise control over film thickness and uniformity and reducing costs through lower material waste. Overall, this review highlights the necessity of further exploration and collaboration within the scientific community to address the challenges and propel advancements in organic photovoltaic cells. These advancements are crucial for transitioning to cleaner energy sources, reinforcing the ongoing significance of thin-film technologies in energy innovation. Full article

In recent years, two-dimensional (2D) materials have been widely used for various applications due to their low cost, high charge carrier mobility, and tunable electronic structure. Here, in this study, we present the application of molybdenum disulfide (MoS₂) used as a hole transport layer (HTL) material for fullerene (FA) and non-fullerene (NFA)-based organic photovoltaic (OPV) devices. A numerical simulation is carried out for these types of solar cells, and the SCAPS-1D software tool is used. Our study is specifically focused on the impact of thickness, the optimization of interface engineering, and the effect of high-temperature analysis to improve the output characteristics. The influence of interface defects between the HTL/active layer and the active layer/ETL (electron transport layer) is also contemplated. After optimization, the obtained power conversion efficiency (PCE) of these NFA- and FA-based devices is reported as 16.38% and 9.36%, respectively. A reflection coating study is also carried out to improve the power conversion efficiency of these devices. Here, the presented results demonstrate that molybdenum disulfide (MoS₂) as a 2D material can be successfully used as an HTL material for high-efficiency OPV devices, both for fullerene (FA)- and non-fullerene (NFA)-based solar cells. Full article

In this work, layer-by-layer organic photovoltaics (LbL OPVs) were prepared by sequentially spin-coating PM1 and L8-BO solutions. The solvent additive 1,8-diiodooctane (DIO), which has a high boiling point, and solid additive l,3,5-trichlorobenzene (TCB), which has a high volatile, were deliberately selected to incorporate with the L8-BO solutions. The power conversion efficiency (PCE) of LbL OPVs was considerably enhanced from 17.43% to 18.50% by employing TCB as the additive, profiting by the concurrently increased short-circuit current density (J_SC) of 26.74 mA cm⁻² and a fill factor (FF) of 76.88%. The increased J_SCs of LbL OPVs with TCB as additive were ascribed to the tilted-up absorption edge in the long wavelength range and the external quantum-efficiency spectral difference between LbL OPVs with and without TCB as an additive. The molecular arrangement of L8-BO and the PM1 domain was enhanced with TCB as an additive, which was most likely responsible for the increased charge mobilities in the layered films processed with additives. It was indicated that the dynamic film-forming process of the acceptor layers plays a vital role in achieving efficient LbL OPVs by employing additive strategy. Over 6% PCE improvement of the LbL OPVs with PM1/L8-BO as the active layers can be achieved by employing TCB as additive. Full article

This review comprehensively addresses the developments and applications of polymer materials in optoelectronics. Especially, this review introduces how the materials absorb, emit, and transfer charges, including the exciton–vibrational coupling, nonradiative and radiative processes, Förster Resonance Energy Transfer (FRET), and energy dynamics. Furthermore, it outlines charge trapping and recombination in the materials and draws the corresponding practical implications. The following section focuses on the practical application of organic materials in optoelectronics devices and highlights the detailed structure, operational principle, and performance metrics of organic photovoltaic cells (OPVs), organic light-emitting diodes (OLEDs), organic photodetectors, and organic transistors in detail. Finally, this study underscores the transformative impact of organic materials on the evolution of optoelectronics, providing a comprehensive understanding of their properties, mechanisms, and diverse applications that contribute to advancing innovative technologies in the field. Full article

Organic–inorganic nanocomposites have the potential to be used in photovoltaic materials due to their eco-friendliness, suitable band gaps, and high stability. In this work, we integrated gold and Fe₃O₄ magnetic nanoparticles with poly-m-amino benzene sulfonic (m-ABS) to synthesize Fe₃O₄@Au@poly-(m-aminobenzenesulfonic acid) (Fe₃O₄@Au@m-ABS) magneto-plasmonic nanoparticles (MPNPs) to enhance the performance of the organic photovoltaic (OPV). These MPNPs exhibit broad UV-Vis absorption and a low band gap of 2.878 eV, enhancing their suitability for photovoltaic applications. The MPNPs were introduced into the ZnO electron transporting layer (ETL) and active layer to investigate the influence of MPNPs on the power conversion efficiency (PCE) of the OPVs. When 0.1 vol% MPNPs were incorporated in the ETL, the OPVs achieved a PCE of 14.24% and a fill factor (FF) of 69.10%. On the other hand, when 0.1 vol% MPNPs were incorporated in the active layer, the OPVs showed a PCE of 14.11% and an FF of 68.83%. However, the OPVs without MPNPs only possessed a PCE of 13.15% and an FF of 63.69%. The incorporation of MPNPs increased the PCE by 8.3% in the OPV device. These findings suggest that Fe₃O₄@Au@m-ABS MPNPs are promising nanocomposite materials for enhancing the performance of OPVs. Full article

In this study, we explored the potential of exfoliated transition metal dichalcogenides (TMDs) as innovative spray-coated hole transport layers (HTLs) in organic photovoltaics (OPVs), addressing the need for efficient and stable materials in solar cell technology. This research was motivated by the need for alternative HTLs that can offer enhanced performance under varying lighting conditions, particularly in indoor environments. Employing UV-visible absorption and Raman spectroscopy, we characterized the optical properties of MoS₂, MoSe₂, WS₂, and WSe₂, confirming their distinct excitonic transitions and direct bandgap features. The nanocrystalline nature of these TMDs, revealed through XRD patterns and crystallite size estimation using the Scherrer method, significantly contributes to their enhanced physical properties and operational efficiency as HTLs in OPVs. These TMDs were then integrated into OPV devices and evaluated under standard solar and indoor lighting conditions, to assess their effectiveness as HTLs. The results demonstrated that MoS₂, in particular, displayed remarkable performance, rivalling traditional HTL materials like MoO₃. It maintained high power conversion efficiency across a spectrum of light intensities, illustrating its versatility for both outdoor and indoor applications. Additionally, MoS₂ showed superior stability over extended periods, suggesting its potential for long-term usage in OPVs. This study contributes significantly to the field of photovoltaic materials, presenting TMDs, especially MoS₂, as promising candidates for efficient and stable OPVs in diverse lighting conditions, thereby broadening the scope of solar cell applications. Full article

The increase in demand for electricity due to industrial development and the growing use of electronic equipment has led to the need for new alternative energy sources, such as photovoltaic solar energy conversion. In this context, organic photovoltaic (OPV) stands out as an efficient way of generating energy indoors. An electrical power supply system (EPS) was developed to power a commercial electronic lock, using OPV as the energy source. The system was designed with a charging control to match the panel voltage to a supercapacitor charge accumulator and a boost converter. Tests on the bench and in a real scenario demonstrated the viability and effectiveness of the system, showing that it is capable of operating self-sufficiently with a minimum daily illuminance of 250 lux for 12 h. The results indicate that the system can be applied to various loads with low energy consumption, promoting energy efficiency in different contexts. Full article
