Search Results (173)

In a multi-point source system, increasing the jamming power can expand the distribution area of the equivalent radiation center, but significantly increases the system exposure risk. Therefore, in order to achieve an optimal balance between the two, this paper proposes a joint optimization method for jamming power and an array of multi-point source systems. First, based on determining the spatial geometric relationship between the triplet antenna and the target, the distribution law of the equivalent radiation center of the triplet antenna under the condition of the target echo is derived. Second, by introducing the angle factor, the jamming power and equivalent radiation center distribution area are combined to construct the joint optimization model of jamming power and array in omnidirectional and non-omnidirectional situations. Third, based on the non-dominated sorting whale optimization algorithm (NSWOA), an adaptive inertia weight based on the cosine function and logistic chaotic map is introduced to obtain the optimal arrangement. The experimental results show that in the omnidirectional case, when the average jamming-to-signal ratio is 13.83 dB, the equilateral triangle array can achieve the goal of protecting the target while avoiding the exposure of the triplet antenna position. In the non-omnidirectional case, when the average jamming-to-signal ratio is 13.90 dB, the equilateral triangle array can achieve the optimal balance between the jamming power and the area of the distribution area of the equivalent radiation center, and control the distribution of the equivalent radiation center to strictly meet the preset angular domain constraints. Furthermore, the optimal JSR value was reduced by an average of 1.14 dB compared with that of the conventional selection scheme. Full article

This work introduces a wine glass-shaped planar ultra-wideband (UWB) antenna. The antenna achieves a compact form factor by reducing lateral width through Bézier curve shaping and a trident feed, while maintaining length for low-frequency operation. The wine-glass-shaped radiator increases shunt capacitance and enhances midband impedance matching, as demonstrated by equivalent circuit analysis, while the trident feed improves matching at higher frequencies. This design yields a 92% fractional bandwidth (3.2–8.7 GHz) within a compact volume of $0.37{\lambda }_0\times 0.13{\lambda }_0\times 0.0013{\lambda }_0$. The prototype is fabricated on two 50-μm-thick polyimide flexible copper-clad laminates (FCCL), and its performance is evaluated in an anechoic chamber. The measured results demonstrate omnidirectional radiation with an efficiency of over 80% across the UWB band. With broad operational range and compactness, the antenna is well-suited for IoT and wearable sensing applications. Full article

This study investigates the design of omnidirectional antennas, using a characteristic mode analysis (CMA), and explores two distinct feeding methods. The first method employs equal-amplitude and in-phase excitation across all ports, whereas the second method utilizes equal-amplitude excitation with a 180° phase difference between adjacent ports. Both designs achieve operating bandwidths of 2.45–2.58 GHz and 2.42–2.45 GHz, respectively, with peak gains of 4.1 dBi and 4.4 dBi at 2.45 GHz. The proposed antennas exhibited high gain and low-profile characteristics, making them well-suited for applications in wireless energy harvesting. Full article

A novel dual-band multi-linear polarization reconfigurable (MLPR) antenna for body-centric wireless communication systems (BWCS) is presented in this paper. The design comprises five symmetrically arranged multi-branch radiating units, each integrating an elliptical patch and curved spring branch for the Medical Implant Communication Service (MICS) band (403–405 MHz), and a pair of orthogonal strip patches for the Industrial, Scientific and Medical (ISM) $2.45$ GHz band (2.40–2.48 GHz). By selectively biasing PIN diodes between each unit and a central pentagonal feed, five distinct LP states with polarization directions of $0^{\circ }$, ${72}^{\circ }$, ${144}^{\circ }$, ${216}^{\circ }$, and ${288}^{\circ }$ are achieved. A dual-line isolation structure is introduced to suppress mutual coupling between radiating units, ensuring cross-polarization levels (XPLs) better than $-15.0$ dB across the operation bands. Prototypes fabricated on a $160\times 160\times 1.5$ mm³ substrate demonstrate measured $|S_{11}|<-10$ dB across 401–409 MHz and 2.34–2.53 GHz and stable omnidirectional patterns despite biasing circuitry perturbations. The compact form and robust dual-band, multi-polarization performance make the proposed antenna a promising candidate for implantable device wake-up signals and on-body data links in dense indoor environments. Full article

The advent of digital mining has become a tangible reality in recent years. This digital evolution requires a predictive understanding of key elements, particularly considering the reliable communication infrastructures needed for autonomous machines. The LoRa technology and its underground propagation behavior can make an important contribution to this digitalization. Since LoRa operates with a high signal budget and long ranges in sub-GHz frequencies, its behavior is very promising for underground sensor networks. The aim of the development and series of measurements was to observe LoRa’s applicability and propagation behavior in active salt mines and to detect and identify effects arising from the special environment. The propagation of LoRa was measured via packet loss and signal strength in line-of-sight and non-line-of-sight configurations over entire mining sections. The aim was to analyze the performance of LoRa at the macroscopic level. LoRa operated at 868 MHz in the free band, and units were equipped with omni-directional antennas. The K+S Group’s active salt and potash mine Werra, Germany, was kindly opened as a distinctive experimental setting. The LoRa exhibited characteristics that were highly distinctive in this environment. The presence of the massive salt allowed the signal to bounce along drift edges with near-perfect reflection, which enabled travel over kilometers due to a waveguide-like effect. A packet loss of below $15\%$ showed that LoRa communication was possible over distances exceeding 1000 m with no line-of-sight in room-and-pillar structures. Measured differences of $\Delta 50\mathrm{dBm}$ values confirmed consistent path loss across different materials and tunnel geometries. This effect occurs due to the physical structure of the mining drifts, facilitating the containment and direction of signals, minimizing losses during propagation. Further modeling and measurements are of great interest, as they indicate that LoRa can achieve even better outcomes underground than in urban or indoor environments, as this waveguide effect has been consistently observed. Full article

A Ka-Band, 26.5–40 GHz, omnidirectional metamaterial-inspired antenna was designed, built, and tested to develop a simple printed compact (10.3 mm × 10.3 mm × 0.0787 mm) multiple-point sensor for air pollution monitoring. This Ka-band antenna generated a dual band at 27.49–29.74 GHz and 33.0–34.34 GHz. The VSWR values within the two bands are less than 1.5. The radiation and total efficiency are 97% and 92% in the first band and they are both 96% in the second band. The maximum gain is between 3.26 and 5.50 dBi and between 5.09 and 6.52 dBi in the first and second bands, respectively. The dual band is the key to enhancing the sensor’s detection accuracy. This Omni MTM-inspired antenna/sensor can effectively detect toxic and neurotoxic metal particles, i.e., lead, zinc, copper, and nickel, in evidently polluted living environments, such as factory/industrial environments, with different particle/mass concentrations. This sensor can be adapted to detect metal pollutants in different environments, such as water or other fluid-based matrices, and can also be applied to long-range communication repeaters and 5G harvesting energy devices, to name a few. Full article

This paper presents a novel design of a compact dual-band dual-mode wearable antenna. The antenna is fed through a single coaxial feed probe, which excites TM₀₁ and TM₁₁ modes at 2.45 GHz and 5.8 GHz, respectively. These modes exhibit distinct radiation characteristics. The omnidirectional TM₀₁ mode at 2.45 GHz is suitable for on-body communication, while the directional TM₁₁ mode at 5.8 GHz is more appropriate for off-body communication. The antenna prototype was fabricated and measured. The measured performance is consistent with the simulations. Additionally, further simulations and measurements were conducted to verify the interactions between the proposed antenna and the human body. The results demonstrate that the proposed antenna exhibits significant potential as a candidate for wireless body area network (WBAN) communications. Full article

To address the inherent contradiction between low-profile design and high gain in traditional omnidirectional antennas, as well as the narrow bandwidth constraints of ENZ antennas, this study presents a dual-mode ENZ-FP collaborative resonant antenna array design utilizing a substrate-integrated waveguide (SIW). Through systematic analysis of ENZ media’s quasi-static field distribution, we innovatively integrated it with Fabry–Perot (F–P) resonance, achieving unprecedented dual-band omnidirectional radiation at 5.18 GHz and 5.72 GHz within a single ENZ antenna configuration for the first time. The directivity of both frequencies reached 12.0 dBi, with a remarkably low profile of only 0.018λ. We then extended this design to an ENZ-FP dual-mode beam-scanning array. By incorporating phase control technology, we achieved wide-angle scanning despite low-profile constraints. The measured 3 dB beam coverage angles at the dual frequencies were ±63° and ±65°, respectively. Moreover, by loading the impedance matching network, the −10 dB impedance bandwidth of the antenna array was further extended to 2.4% and 2.7%, respectively, thus overcoming the narrowband limitations of the ENZ antenna and enhancing practical applicability. The antennas were manufactured using PCB (Printed Circuit Board) technology, offering high integration and cost efficiency. This provides a new paradigm for UAV (Unmanned Aerial Vehicle) communication and radar detection systems featuring multi-band operation, a low-profile design, and flexible beam control capabilities. Full article

A circularly polarized (CP) textile antenna is investigated for concurrent on- and off-body wireless communications in the 2.38 GHz medical body area network and 5.8 GHz industrial, scientific, and medical bands in the wireless body area network. The proposed scheme consists of a square microstrip patch antenna (MPA), in which four shorting pins are employed to tune the two resonate modes of TM₁₀ and TM₀₀. Notably, the slant corners on MPA are cut symmetrically to realize unidirectional CP radiation, enabling off-body communication. Moreover, four rotating L-shaped parasite elements are loaded to excite the horizontal polarization mode (TM_hp), which is combined with the TM₀₀ mode to implement CP omnidirectional radiation along the human body. For verification, a proof-of-concept prototype with the dimensions of 45 mm × 45 mm × 2 mm was fabricated and characterized. The measured −10 dB impedance bandwidths of 2.5% and 6.7%, the 3 dB AR bandwidths of 2.5% and 2.7%, and the maximum realized gains of −2.8 and 6.8 dBic are achieved in dual bands, respectively. The experimental tests, such as human body loading, structural deformation, and humidity variation, were carried out. In addition, the wireless communication capability was measured and the radiation safety is evaluated. These performances show that the proposed antenna is an appropriate choice for multifunctional wearable applications. Full article

This study presents the design of two high-gain omnidirectional antennas with minimal pattern ripple. Antenna I is based on a conventional microstrip patch structure, while Antenna II integrates a modified design with four metal probes. Characteristic mode theory (CMT) was applied to analyze the far-field radiation patterns of both antennas, with a focus on the distinct radiation modes. The analysis revealed that Antenna I operates in the TM₂₂ mode and Antenna II in the quasi-TM₁₁ mode, both exhibiting omnidirectional radiation characteristics. A comparative investigation of four different feeding techniques was conducted to ensure equal amplitude and phase excitation at each port, resulting in a low pattern ripple for both designs. A 1:4 power divider was implemented to validate the designs, and the performance of Antennas I and II was experimentally assessed. The measurement results showed that the −10 dB operating bandwidths of Antennas I and II spanned 2.42–2.50 GHz and 2.34–2.57 GHz, respectively, with corresponding peak gains of 8.0 dBi and 4.55 dBi at a frequency of 2.45 GHz. Full article

In response to the urgent demands of the Internet of Things for precise indoor target positioning and information interaction, this paper proposes a multi-band analog radio-over-fiber mobile fronthaul system. The objective is to obtain the target’s location in indoor environments while integrating remote beamforming capabilities to achieve wireless access to the targets. Vector signals centered at 3, 4, 5, and 6 GHz for indoor positioning and centered at 30 GHz for wireless access are generated centrally in the distributed unit (DU) and fiber-distributed to the active antenna unit (AAU) in the multi-band analog radio-over-fiber mobile fronthaul system. Target positioning is achieved by radiating electromagnetic waves indoors through four omnidirectional antennas in conjunction with a pre-trained neural network, while high-speed wireless communication is realized through a phased array antenna (PAA) comprising four antenna elements. Remote beamforming for the PAA is implemented through the integration of an optical true time delay pool in the multi-band analog radio-over-fiber mobile fronthaul system. This integration decouples the weight control of beamforming from the AAU, enabling centralized control of beam direction at the DU and thereby reducing the complexity and cost of the AAU. Simulation results show that the average accuracy of localization classification can reach 86.92%, and six discrete beam directions are achieved via the optical true time delay pool. In the optical transmission layer, when the received optical power is 10 dBm, the error vector magnitudes (EVMs) of vector signals in all frequency bands remain below 3%. In the wireless transmission layer, two beam directions were selected for verification. Once the beam is aligned with the target device at maximum gain and the received signal is properly processed, the EVM of millimeter-wave vector signals remains below 11%. Full article

A marine cable-conformal dual-band omnidirectional circularly polarized waveguide slot antenna is proposed for L/S-band (1.59–1.84 GHz/2.48–2.55 GHz) maritime satellite systems. Axially symmetric X-shaped slots enable dual-band operation with 14.6% impedance bandwidth (L-band) and axial ratio < 3 dB. A three-stage tapered coaxial feeding network achieves efficient matching (|S11| < −10 dB) across a BeiDou-1 uplink (1.61–1.6265 GHz) and downlink (2.4835–2.5 GHz), delivering 4.1 dBi peak omnidirectional gain at 1.6 GHz. The compact design (radial dimension ≤ 0.25λ) offers robust performance in harsh marine environments with integrated wideband, high-gain, and conformal capabilities. Full article

In this paper, a conformal UHF antenna with a wide-angle radar cross section (RCS) reduction capability is proposed. The radiator of the design is a planar monopole antenna. Since the large physical size of the antenna in UHF band can generate a scatter beam with a large RCS in the high operating frequency of radars and other sensing applications, i.e., the X band, two types of ITO (Indium Tin Oxide) meta-absorber are proposed and loaded onto the monopole antenna to suppress the scatter. For the incident beam around the direction orthogonal to the radiator plane, the periodical meta-absorber can realize around a 20 dB RCS reduction in the X band. The incident wave around the parallel direction of the radiator is absorbed by the taper meta-absorber, which can greatly suppress the surface and then reduce the RCS in the horizontal plane. The combined effect means the antenna can achieve a wide-angle RCS reduction. It should be noted that the antenna can still produce a high-efficiency omnidirectional beam after the lossy meta-absorber is loaded. In our opinion, the advantages of the proposed antenna design, including good radiation performance in UHF band and high RCS reduction in X band, make it a suitable candidate for airborne and drone applications. Full article

Radome stealth technology is a key research area in aircraft stealth design. Traditional aircraft stealth methods primarily focus on optimizing the shape to scatter radar waves and using absorbing materials to absorb radar waves. However, when these methods are applied to radomes, they can negatively impact antenna performance. By combining Frequency-Selective Surface (FSS) technology with radome design, it is possible to ensure good transmission performance for the antenna within its operating frequency range while simultaneously reducing the radar cross-section outside the operating frequency range, achieving an integrated design for both transmission and stealth. This paper outlines the technical approaches for radome stealth, reviews the research status of scattering stealth radomes and absorbing stealth radomes based on FSS both domestically and internationally, and provides an outlook on the future development of FSS radomes from the perspectives of omnidirectional broadband, conformal design, and intelligent control. Full article

In this article, a small-aperture, low-profile, and omnidirectional conformal antenna is proposed which can be utilized on space-limited equipment platforms such as airplanes, ships, and vehicles. The antenna consists of an open metal cavity, a discone antenna, a parasitic structure, and a radome. The small aperture and low-profile design of the metal cavity result in a rapid narrowing of the bandwidth of the discone antenna. Therefore, we introduce a parasitic structure that not only enlarges the impedance bandwidth by adding a resonant point, but can also be used to adjust the unroundness of the horizontal pattern. Meanwhile, the conformal design of the antenna with four surfaces of different curvatures is presented. The simulation and testing results demonstrate that the antenna can achieve a VSWR of less than 2 within a bandwidth of 1.95–2.62 GHz (29.3%), with a minimum aperture of 0.43 omnidirectional radiation pattern, with a gain exceeding −2.2 dBi in the azimuthal plane. This antenna offers the advantages of a small aperture, low profile, and conformal capability. Furthermore, the resonances of high and low frequencies can be adjusted through two different structures, enhancing the flexibility of antenna design. Full article
