To mitigate the issue of high-pitch natural frequency in V-shaped floating offshore wind turbines (FOWTs), a novel semi-submersible floater design, termed NewSemi, is proposed in this study. The structural performance of the NewSemi floater is compared with that of two existing 5 MW FOWTs, namely, the V-shaped and Braceless. Frequency domain analysis demonstrates that the NewSemi floater exhibits the most favorable response amplitude operator (RAO) in the pitch direction, along with superior damping characteristics. The result reveals a 16.44% reduction in pitch natural frequency compared to the V-shaped floater. Time-domain analysis under extreme conditions reveals 14.6% and 65.2% reductions in mean surge and pitch motions compared to Braceless FOWT, demonstrating enhanced stability. In addition, compared with the V-shaped FOWT, it exhibits smaller standards and deviations in surge and pitch motion, with reductions of 11.3% and 31.9%, respectively. To accommodate the trend toward larger FOWTs, an optimization procedure for scaling up floater designs is developed in this study. Using a differential evolution algorithm, the optimization process adjusts column diameter and spacing while considering motion response and steel usage constraints. The NewSemi floater is successfully scaled from 5 MW to 10 MW, and the effects of this scaling on motion and structural dynamics are examined. Numerical analysis indicates that as turbine size increases, the motion response under extreme sea conditions decreases, while structural dynamic responses, including blade root torque, rotor thrust, tower-base-bending moment and axial force, significantly increase. The maximum values of blade root torque and tower-base-bending moment increase by 10.4 times and 3.95 times in different load cases, respectively, while the mooring forces remain stable. This study offers practical engineering guidance for the design and optimization of next-generation floating wind turbines, enhancing their performance and scalability in offshore wind energy applications. Full article

Due to the limited availability of land resources, offshore wind turbines have become a crucial technology for the development of deep-water renewable energy. The multi-floating body platform, characterized by its shallow draft and main body located near the sea surface, is prone to significant motion in marine environments. The proper chamfering of the heave plate can effectively enhance its resistance during wave action, thereby improving the stability of the floating platform. The optimal chamfer angle is 35°. Considering the complexity of the floating body’s motion response, this study focuses on the damping characteristics of the heave plate with 35° chamfered perforations. Using the NREL 5 MW three-column semi-submersible floating wind turbine platform as the research model, the hydrodynamic characteristics of the floating body with a perforated heave plate are systematically studied through theoretical analysis, numerical simulation, and physical tests. The amplitude of vertical force under various working conditions is measured. Through theoretical analysis, the additional mass coefficient and additional damping coefficient for different working conditions and models are determined. The study confirms that the heave plate with 35° chamfered perforations significantly reduces heave in the multi-floating body. Full article

The semi-submersible platform is a widely used structure for supporting floating offshore wind turbines (FOWTs) in deep-sea environments where waves and currents interact. Understanding the impact of wave–current interaction (WCI) on hydrodynamic loading and the resulting platform response is essential for effective platform design. However, many existing ocean engineering software packages assume that wave and current loadings can be linearly superimposed. In this study, computational fluid dynamics (CFD) numerical simulations were performed to examine the dynamic response of a newly proposed triangle semi-submersible platform under various wave–current cases. The research underscores the significant influence of WCI on platform motion and loads, introducing nonlinearities that substantially affect both dynamic response and structural stability. Furthermore, the study reveals that WCI can mitigate vortex-induced motion (VIM), thereby enhancing platform stability by altering the force frequency, which no longer aligns with the platform’s natural frequency, thus preventing resonance. Additionally, the presence of current can intensify wave dynamics, leading to increased wave forces acting on the platform. These findings highlight the necessity of integrating WCI considerations into the design and optimization of floating wind turbine platforms to enhance their structural stability and operational performance. Full article

Floating Offshore Wind Turbines (FOWTs) are gaining traction as a solution for harnessing wind energy in deepwater regions where traditional fixed-bottom turbines may not be viable due to water depth. This paper investigates the feasibility and optimization of a floating wind farm in a tropical cyclone (typhoon) region, using the IEA 15 MW turbine and semi-submersible floaters. Because of the extreme environment, the FOWT’s mooring system requires nine catenary chains in a 3 × 3 pattern, which has a large footprint. One challenge in the wind farm design is fitting the FOWTs in a limited area and minimizing wake effects. This research compares a linear layout and an offset grid layout, focusing on the effects of spacing and wake dynamics. The results show that while the linear layout maintains optimal power generation without energy loss, the offset grid layout, although resulting in 2% energy loss, offers greater spatial efficiency for larger-scale projects. The findings highlight the importance of balancing energy efficiency with spatial optimization, particularly for large offshore wind farms. This study explores the use of the Gauss–Curl hybrid model in wake modeling, and the methodology employed provides insights into FOWT placement and mooring system arrangement. The result concludes that a wind farm containing twelve (12) units of 15 MW wind turbines can achieve the 7.0 MW/km² power generation density required by a regulatory government agency. It proves the technical feasibility of a wind farm congested with large mooring systems in a tropical cyclone region. Full article

To reduce the cost of offshore wind and wave power, an innovative combined wind–wave energy generation system constituting of a 15 MW semi-submersible floating offshore wind turbine (FOWT) and four torus-type wave energy converters (WECs) is proposed. A wholly coupled numerical model of aero-hydro-elastic-servo-mooring was built to evaluate the mooring line and motion dynamics of this novel combined system. Additionally, a practical mooring optimization framework is proposed with the Latin Hypercube sampling method, Kriging model, and the combined optimization techniques of the Genetic Algorithm and Gradient Algorithm. The optimization results demonstrate that the optimized mooring scheme satisfies all the strict constraints, validating the effectiveness of the optimization method. Moreover, the hydrodynamic characteristics of the combined system and the effects of the WECs on the mooring system under both rated and extreme conditions are discussed, including changes in time-series mooring tension, power spectral density, and statistical characteristics. The research findings provide a reference for the further development and optimization of this novel combined system, contributing to the efficient utilization of offshore renewable energy. Full article

This study integrates offshore wind power and wave power generation technologies to build a multi-energy complementary renewable energy system, which provides references for marine clean energy development and is highly consistent with the global sustainable development goals. The platform consists of a UMaine VolturnUS-S semi-submersible platform and a group of flap-type wave energy converters. A 15 MW wind turbine is installed on the platform. The hydrodynamic model is established using AQWA. Combined with the upper wind load, the fully coupled time domain model of the integrated power generation platform is constructed using the open-source software F2A. The main purpose is to optimize the parameters of the flap-type wave energy device through frequency domain hydrodynamic analysis and then explore the influence of the wave energy device on the platform under the combined action of regular waves and turbulent wind through a series of working conditions. The results show that when the PTO stiffness is 8 × 10⁷ N·m/rad, the PTO damping takes the optimal damping and has a higher power generation capacity. Secondly, the coupled wave energy device induces minimal hydrodynamic interference between multiple bodies, resulting in negligible impact on the natural frequency of the wind-wave combined platform motion. Overall, the wave energy device can effectively suppress the freedom of shaking degree of the floating wind-wave combined platform. Full article

Semisubmersible floating structures are becoming the predominant understructure type for floating offshore wind turbines (FOWTs) worldwide. As FOWTs are erected far away from land and in deep seas, they inevitably suffer violent and complicated sea conditions, including extreme waves and winds. Mooring lines are the representative flexible members of the whole structure and are likely to incur damage due to years of impact, corrosion, or fatigue. To improve mooring redundancy at each azimuth angle around a wind turbine, a group of mooring lines are configured in the same direction instead of just one mooring line. This study focuses on the mooring failure problems that would probably occur in a realistic redundant mooring system of a semisubmersible FOWT, and the worst residual mooring layout is considered. An FOWT numerical model with a 3 × 3 mooring system is established in terms of 3D potential flow and BEM (blade element momentum) theories, and aero-hydro floating-body mooring coupled analyses are performed to discuss the subsequent time histories of dynamic responses after different types of mooring failure. As under extreme failure conditions, the final horizontal offsets of the structure and the layout of the residual mooring system are evaluated under still water, design, and extreme environmental conditions. The results show that the transient tension in up-wave mooring lines can reach more than 12,000 kN under extreme environmental conditions, inducing further failure of the whole chain group. Then, a deflection angle of 60° may occur on the residual laid chain, which may bring about dangerous anchor dragging. Full article

Floating offshore wind turbine (FOWT) platforms are subject to a wide range of hydrodynamic loading and dynamic movement, making hydrodynamic force evaluation difficult. Amongst various floating platforms, submersible platforms are structurally complex, with multiple members held together by cross-braces. The influence of these members on hydrodynamic loading is poorly understood. An investigation of the effect of these members on loads is essential to optimise the design of FOWT platforms, mooring systems, and protective coatings, leading to a reduction in construction and maintenance costs. This paper numerically investigates the effect of structural members on the forces acting on a static semi-submersible platform in a unidirectional current flow of Reynolds number ($Re$) ranging from 2000 to 200,000, based on structural diameter and tidal velocity. The OC4 semi-submersible is chosen as the baseline platform. For each $Re$, this study is divided into three stages, such that in each stage, the number of members increased. These stages are as follows: (1) a finite cylinder (FC), (2) a finite cylinder with a heave plate (FCHP), (3) three cylinders with heave plates (TCHP) in an equilateral triangle arrangement, and (4) the OC4 semi-sub. The drag coefficient (${\overline{C}}_d$) increases with increasing structural members and weakly varies with increasing $Re$. However, the viscous drag coefficient (${\overline{C}}_f$) decreases with increasing $Re$, and a reverse trend is seen in the case of the pressure drag coefficient (${\overline{C}}_p$), with pressure drag dominating over friction drag. Further, the contribution of individual members is observed to vary with $Re$. The contribution of cylinders towards ${\overline{C}}_d$ is higher than heave plates, showing that contributions directly depend on the aspect ratio of members. In the case of TCHP and OC4, the contribution of the rear members is higher than that of the leading members due to the strong wake effect of the former. Also, the braces and pontoons of OC4 have contributed substantially towards total ${\overline{C}}_d$, unlike the central cylinder, which has experienced low drag due to the wake effect of the front cylinder and heave plate. Also, flow visualisation has shown vortex cores, and recirculating flows in the near wake of the cylinders and under the heave plates. Recirculation zones under the heave plates lead to vertical pressure on the structures. This vertical pressure increases with the number of structural members and the vertical pressure coefficient (${\overline{C}}_v$), varying with $Re$ due to three-dimensionality in the wake. Further, this pressure varies across the bottom surfaces of structures. Analyses of the streamwise pressure coefficient have shown it is highest on the front surfaces of cylinders. The highest friction is on the top and sides of the heave plates, and there is considerable friction on the sides of the cylinder. Full article

The objective of this study is to predict the large amplitude motions of floating wind turbine platforms and to emphasize the significance of nonlinear forces when these platforms are subjected to combined wind and wave loads. The analysis utilizes the 5 MW OC4 semi-submersible model. First, we couple the OpenFAST v3.1.0 with SIMDYN, validate the effectiveness of the coupled program, and highlight the considerable impact of nonlinearity on the results, particularly in relation to the heave and pitch motions of offshore wind platforms under extreme environmental conditions. We then discuss the primary reasons for this phenomenon. Ultimately, this study proposes an optimized model aimed at mitigating the nonlinear effects associated with such conditions. Full article

As design options for floating wind farms continue to be explored, shared (or multiline) anchors that secure mooring lines from multiple turbines remain a promising technology that can potentially reduce the number of anchors and overall mooring costs. This study evaluates two methods for analyzing the loads on shared anchors: one in which floating offshore wind turbines are simulated individually (using the software OpenFAST), and one in which an entire floating wind farm is simulated collectively (using the software FAST.Farm). A three-line shared anchor is evaluated for multiple loading scenarios in deep water, using the International Energy Agency 15 MW turbine on the VolturnUS-S semisubmersible platform. While the two methods produce broadly comparable results, the coupled wave loading on platforms within the farm results in wave force cancellations and amplifications that decrease multiline force directional ranges and increase multiline force extreme values (up to 7%) and standard deviations (up to 11%) for wave-driven load cases. The inclusion of wakes in FAST.Farm also reduces the net load on the shared anchor due to the velocity deficit, leading to larger differences between OpenFAST and FAST.Farm (up to 3% difference in mean loads) for load cases with operational turbines. Full article

This study presents the development and comparative analysis of a new Y-type floating offshore wind turbine platform based on the existing T-type model. Utilizing advanced simulation tools, such as MSC, Patran and Nastran 2022.3, FEGate For Ship 5.0, and Ansys AQWA 2021 R2, extensive evaluations are conducted on the structural strength, stability, and dynamic response of both the T-type and the newly proposed Y-type platforms. In this research, the structural optimization algorithm based on the above simulation tools is adopted, and its results are compared with preoptimization results to demonstrate the improvements made in design precision and reliability. Results indicate that the Y-type model achieves a maximum reduction in von Mises stress by 30.21 MPa compared to the T-type model, and its heave and pitch motion amplitudes are reduced by 4.3412 m and 4.9362°, respectively, under extreme sea state conditions. Through structural optimization using the Nastran SOL200 module, the column structure weight is reduced by 11.31%, meeting the strength requirements while enhancing efficiency. These findings highlight the Y-type platform’s improved performance and provide robust design strategies for floating offshore wind turbines in deep-water regions, crucial for advancing global renewable energy solutions. Future research should focus on the impacts of different marine conditions on platform performance and consider integrating new materials or innovative design enhancements to further optimize platform functionality. Additionally, due to potential limitations from model simplification, emphasis on real-world testing and validation under operational conditions is recommended. Overall, this research clarifies the differences in structural performance between the T-type and Y-type floating platforms and introduces an improved platform design approach, offering valuable insights and guidance for the future development of floating offshore wind turbine technology. Full article

The present study aims to carry out a comparative Multi-Objective Optimization (MOO) of a 10 MW FOWT semi-submersible using three different metaheuristic optimization techniques and a sophisticated approach for optimizing a floating platform. This novel framework enables highly efficient 3D plots, an optimization loop, and the automatic and comparative output of solutions. Python, the main interface, integrated PyMAPDL and Pymoo for intricate modeling and simulation tasks. For this case study, the ZJUS10 Floating Offshore Wind Turbine (FOWT) platform, developed by the state key laboratory of mechatronics and fluid power at Zhejiang University, was employed as the basis. Key criteria such as platform stability, overall structural mass, and stress were pivotal in formulating the objective functions. Based on a preliminary study, the three metaheuristic optimization algorithms chosen for optimization were Particle Swarm Optimization (PSO), Simulated Annealing (SA), and Ant Colony Optimization (ACO). Then, the solutions were evaluated based on Pareto dominance, leading to a Pareto front, a curve that represents the best possible trade-offs among the objectives. Each algorithm’s convergence was meticulously evaluated, leading to the selection of the optimal design solution. The results evaluated in simulations elucidate the strengths and limitations of each optimization method, providing valuable insights into their efficacy for complex engineering design challenges. In the post-processing phase, the performances of the optimized FOWT platforms were thoroughly compared both among themselves and with the original model, resulting in validation. Finally, the ACO algorithm delivered a highly effective solution within the framework, achieving reductions of 19.8% in weight, 40.1% in pitch, and 12.7% in stress relative to the original model. Full article

The increasing demand for cost-effective floating offshore wind turbines (FOWTs) necessitates streamlined mass production and efficient assembly strategies. This research investigates the assembly and integration of 15 MW FOWT floaters, utilising a semi-submersible floater equipped with a 15 MW wind turbine. The infrastructure and existing port facilities of Taiwan are used as an example. The effectiveness of various assembly and integration strategies has been evaluated. The study outlines equipment and infrastructure requirements for on-quay floater and turbine assembly, comparing on-quay assembly to construction at remote locations and subsequent towing. Detailed analyses of port operations, crane specifications, and assembly procedures are presented, emphasising the critical role of crane selection and configuration. The findings indicate that on-quay assembly at one major port is feasible and cost-effective, provided that port infrastructure and operational logistics are optimised. This research offers insights and recommendations for implementing large-scale FOWT projects, contributing to advancing offshore wind energy deployment. Full article

This research paper explores an approach to enhancing the economic viability of the heaving wave energy converters (WECs) of both cylinder-shaped and torus-shaped devices, by integrating them with four established, floating offshore wind turbines (FOWTs). Specifically, the approach focused on the wave power performance matrix. This integration of WECs and FOWTs not only offers the potential for shared construction and maintenance costs but also presents synergistic advantages in terms of power generation and platform stability. The study began by conducting a comprehensive review of the current State-of-the-Art in co-locating different types of WECs with various foundation platforms for FOWTs, taking into consideration the semi-submersible, spar and barge platforms commonly employed in the offshore wind industry. The research took a unified approach to investigate more and new WEC arrays, totaling 20 configurations across four distinct FOWTs. The scope of this study’s assumption primarily focused on the hydrodynamic wave power performance matrix, without the inclusion of aerodynamic loads. It then compared their outcomes to determine which array demonstrated superior wave energy under the key metrics of total absorbed power, capture width, and interaction factor. Additionally, the investigation could serve to reinforce the ongoing research and development efforts in the allocation of renewable energy resources. Full article

To advance offshore wind energy technologies in South America, this study addresses the early-stage design challenges of a floating support structure for a 5 MW wind turbine. The aim is to develop a robust and efficient floating structure capable of withstanding the diverse forces imposed by the Valdivian environment. Utilizing SolidWorks, a 3D model based on a comprehensive review of semi-submersible structures with three columns is proposed. The structural model is subjected to a rigorous evaluation using the finite element method, with which linear static and buckling analyses are performed in compliance with the Det Norske Veritas (DNV) classification society. The proposed tri-floater platform design shows a 30% weight reduction when compared with other proposed models. The finite element analysis includes an extreme condition of 13 m waves that suggests the adequate performance of the proposed platform in Chilean waters, and offers a conceptual preliminary step for floating support structure designs in Chile. Full article
