Search Results (20)

In recent years, non-pneumatic tires have been gaining popularity, which can be seen in the increase in research results and proposals from world-class tire manufacturers (mainly as technology demonstrators). The possibility of eliminating the need to maintain compressed air is a major factor in the development of non-pneumatic tires and their usage in vehicles. Articles and patents were reviewed in relation to the load transfer mechanism, the design of non-pneumatic tire components, and recommendations for materials. Non-pneumatic tire top loaders are a desirable type of this type of wheel compared to bottom loaders, because they transfer loads over a larger part of the wheel, which increases their load capacity. Most non-pneumatic tires consist of a rim, an elastic structure, and a shear beam/band with a tread. The rim is used to secure the elastic structure and can be fitted with vibration dampers in the form of circumferential rubber rings. The gradient elastic structure, in comparison with the homogeneous structure (same thickness or dimensions of the elements), allows the range of axle displacements to be adjusted to the desired level without the need to increase the size of the wheel, and also influences the change in the location of the maximum stresses. The shear beam/ band mimics the properties of compressed air used in pneumatic tires. The shear beam/ band made as a webbing geometry ensures uniform pressure in the contact patch. The reinforced composite shear beam/ band ensures adequate bending strength with low energy losses and a small thickness of the beam/ band. Materials commonly used in the tire industry are used as reinforcement for the shear beam/ band, which was illustrated by the results of our own research. Full article

This paper investigates the use of glass and carbon fiber-reinforced polymer composites with epoxy matrices for non-pneumatic tires (NPTs), as an alternative to conventional elastomer-based designs. A novel NPT design approach was developed in three steps: (i) a finite element model with isotropic material properties was constructed to identify suitable spoke geometries; (ii) an anisotropic parametric study quantified key parameters influencing the load-bearing capability of two selected concepts from step (i); and (iii) a preferred version was chosen from step (ii) and evaluated under multiple load cases to ensure it met all requirements. The final tire design incorporates thick spiral spokes superimposed with a cosine-like function, showcasing the strengths and limitations of non-elastomeric reinforced polymers for NPT design. This study provides innovative insights into reducing the mass of NPTs and demonstrates the potential of fiber-reinforced polymer composites to achieve more lightweight, durable, and efficient NPT designs in comparison to pneumatic ones. Full article

Non-pneumatic tires (NPTs) have garnered significant attention due to their advantages, such as energy efficiency, safety, versatile applications, and superior performance, compared to traditional rubber-based pneumatic tires (PTs). This mini review provides a concise overview of NPTs, beginning with their definition, structural design, and classification based on structural variations. The review then examines recent advancements in the materials used for NPTs, including those for the tread, elastic support structure, skeleton, and adhesives, with a focus on their specific properties. Furthermore, it summarizes various manufacturing techniques such as compression molding, centrifugal casting, injection molding, 3D printing, and mechanical assembly. Lastly, the review outlines the general manufacturing procedures of NPTs, discusses the challenges currently faced by the technology, and offers insights into future development directions. This mini review aims to support NPT researchers and practitioners, particularly in the fields of process and materials engineering, in advancing their work on NPTs. Full article

This study explores the development of a terramechanics-based model for non-pneumatic tire–terrain interaction, focusing on different spoke designs. The research investigates how four spoke shapes (honeycomb, modified honeycomb, re-entrant honeycomb, and straight spokes) affect non-pneumatic tire performance in off-road conditions. Using the finite element method (FEM) to model non-pneumatic tires, and smoothed-particle hydrodynamics (SPH) to model dry, loose soil, simulations were conducted to replicate real-world loading conditions. This study utilizes virtual environment solution finite element analysis software to examine the interaction between a non-pneumatic tire and dry, loose soil, with a focus on calculating longitudinal and vertical forces. These forces play a pivotal role in determining the motion resistance coefficient. The results show distinct variations in the motion-resistance coefficients among the spoke designs on dry, loose soil. This analysis helps to identify the spoke configurations that optimize energy efficiency and fuel consumption. By comparing and evaluating the four spoke designs, this study shows the effect of spoke design on tire motion resistance. This study concluded that the modified honeycomb spoke design is the most stable and the least sensitive to operating conditions. Full article

This study aims to analyze the load-bearing characteristics of non-pneumatic tires with composite spokes using experimental and finite element simulation methods and to establish a mechanical analysis model based on the Timoshenko beam theory. Subsequently, experiments were conducted on carbon fiber-reinforced plastics and rubbers to establish the corresponding constitutive model. A finite element model of the non-pneumatic tires with composite spokes was also developed. The main structural and material parameters were selected, and their correlation with the vertical stiffness of the non-pneumatic tires with composite spokes was studied using response surface methodology. The stiffness characteristics of the composite spokes were simplified, and a load-bearing characteristic analysis model was established. The results indicated that among the parameters of the reinforcement plate structure and rubber, the constitutive parameter C₁₀ of the rubber in the spokes had the greatest impact, with a comprehensive influence value of 319.83 N/mm. Under a load of 5000 N, the load-bearing characteristic analysis model results were consistent with those of the finite element simulation, with a maximum relative error of 7.49%. The proposed load-bearing characteristic analysis model can assist in the rapid design and performance prediction of non-pneumatic tires with composite spokes. Full article

A non-pneumatic tire (NPT) overcomes the shortcomings of a traditional pneumatic tire such as wear, punctures and blowouts. In this respect, it shows great potential in improving driving safety, and has received great attention in recent years. In this paper, a carbon fiber-reinforced polyethylene terephthalate (PET/CF) honeycomb is proposed as a support structure for NPTs, which can be easily prepared using 3D printing technology. The experimental results showed that the PET/CF has high strength and modulus and provides excellent mechanical properties. Then, a finite element (FE) model was established to predict the compression performance of auxetic honeycombs. Good agreement was achieved between the experimental data and FE analysis. The influence of the cell parameters on the compressive performance of the support structure were further analyzed. Both the wall thickness and the vertically inclined angle could modulate the mechanical performance of the NPT. Finally, the application of vertical force is used to analyze the static load of the structure. The PET/CF honeycomb as the support structure of the NPT showed outstanding bearing capacity and stiffness in contrast with elastomer counterparts. Consequently, this study broadens the material selection for NPTs and proposes a strategy for manufacturing a prototype, which provides a reference for the design and development of non-pneumatic tires. Full article

Pneumatic tires are used in diverse industries. However, their design is difficult, as it relies on the knowledge of experienced designers. In this paper, we generate images of non-pneumatic tire designs with patterns based on shapes and lines for different generative adversarial network (GAN) models and test the performance of the models. Using OpenCV, 2000 training images were generated, corresponding to spoke, curve, triangle, and honeycomb non-pneumatic tires. The images created for training were used after removing highly similar images by applying mean squared error (MSE) and structural similarity index (SSIM). To identify the best model for generating patterns of regularly shaped non-pneumatic tires, GAN, deep convolutional generative adversarial network (DCGAN), StarGAN v2, StyleGAN v2-ADA, and ProjectedGAN were compared and analyzed. In the qualitative evaluation, the GAN, DCGAN, StarGAN v2, and StyleGAN v2-ADA models distorted the circle shape and did not maintain a consistent pattern, but ProjectedGAN retained consistency in the circle, and the pattern was less distorted than in the other GAN models. When evaluating quantitative metrics, ProjectedGAN performed the best among several techniques when the difference between the generated and actual image distributions was measured. Full article

Rolling resistance (RR) is key research content for developing low-carbon energy-saving tires, and the resultant change in the tire temperature field exerts a crucial impact on tire performance. Currently, there is no accurate and systematic analysis method for solving the steady-state temperature field (SSTF) and RR of tires with complex patterns and non-pneumatic tires (NPTs), which are characterized by discontinuous structure in the circumferential direction. A solution strategy that entails SSTF and RR based on explicit transient rolling analysis and thermal-mechanical coupling is proposed and its accuracy is verified using the SSTF test pertaining to the low-speed and low-load capacity non-pneumatic tire (LSL-tire), which exhibits a 7.56% and 6.94% average temperature deviation for the outer surface center of the tread and for the outer surface center of spokes, respectively. Uniaxial tensile mechanical property tests and dynamic mechanical analysis (DMA) of the utilized rubber and polyurethane (PU) materials were conducted, and their specific heat capacity, thermal conductivity, and density were tested. Based on three-dimensional nonlinear finite element simulation and considering the characteristics pertaining to the loss factor of viscoelastic materials changing with temperature, the SSTF and RR of the LSL-tire under different loads and velocities were analyzed. The results indicate that the influence of load and speed on the SSTF of LSL-tire is quite significant, whereas the influence of speed on the RR is not apparent. For all conditions, the highest steady-state temperature points of the tread are located in its center, and in the spokes they are located in the joint between spokes and the outer ring; the spokes contribute the most to the RR, followed by the tread. Full article

In non-pneumatic tires, metamaterial cells could replace the pneumatic part of the tire. In this research, to achieve a metamaterial cell suitable for a non-pneumatic tire with the objective function of increasing compressive strength and bending fatigue lifetime, an optimization was carried out for three types of geometries: a square plane, a rectangular plane, and the entire circumference of the tire, as well as three types of materials: polylactic acid (PLA), thermoplastic polyurethane (TPU), and void. The topology optimization was implemented by the MATLAB code in 2D mode. Finally, to check the quality of cell 3D printing and how the cells were connected, the optimal cell fabricated by the fused deposition modeling (FDM) method was evaluated using field-emission scanning electron microscopy (FE-SEM). The results showed that in the optimization of the square plane, the sample with the minimum remaining weight constraint equal to 40% was selected as the optimal case, while in the optimization of the rectangular plane and the entire circumference of tire, the sample with the minimum remaining weight constraint equal to 60% was selected as the optimal case. From checking the quality of 3D printing of multi-materials, it was concluded that the PLA and TPU materials were completely connected. Full article

A high load capacity non-pneumatic tire (HC tire) was designed and manufactured to solve the problems of air leakage, puncture, blowout, shoulder void, and delamination, which occur in traditional high load capacity tires, as well as significantly increase the unit load of tires. Experiments and numerical simulations were conducted to investigate the static stiffness properties of the HC tire. Additionally, the manufacturing process of the tire was highlighted. The tire mainly comprised polyurethane and silicon manganese steel, and a ‘π’-shaped support substructure was adopted. The tread structure was made up of a built-in spiral steel ring and a non-steel ring. The uniaxial tensile mechanical properties of the used metal and elastomer materials were tested, and the linear elastic constitutive model and Marlow constitutive model, respectively, were used to describe their mechanical characteristics. The stiffness properties of the HC tire, including torsional, longitudinal, vertical, and lateral stiffnesses, were evaluated using a tire comprehensive stiffness tester. Nonlinear finite element models of the HC tire were established, and their accuracies were verified through vertical stiffness tests. The stiffness properties of the HC tire in other directions were simulated as well. An in-depth comparative analysis of the simulation and experimental data was performed. The results demonstrated that the unit load of the unreinforced HC tire was 2.972 times and 1.615 times higher than that of the solid tire and pneumatic tire, respectively. The spiral steel ring embedded in the tread increased the vertical and longitudinal stiffness but reduced the torsional stiffness of the HC tire, thus reversing the variation trend of the lateral stiffness at the 0° and 5° test points. The findings can serve as a reference for theoretical research on, and the structural optimization of, non-pneumatic tires with a high load capacity. Full article

Compared with pneumatic tires, non-pneumatic tires have incomparable performance, in terms of load bearing and safety. In this paper, the static load characteristics and pure longitudinal slip characteristics of the non-pneumatic tire are studied by combining experiments and simulations. The test results show that the radial stiffness of the original structure is nonlinear, the pure longitudinal sliding characteristics are seriously inconsistent, the brakes are very sensitive, and the driving is slightly soft. A series of designs have been carried out from the aspects of load-bearing mode and anti-symmetry of the structure, and numerical simulations have been carried out. The results show that the radial secant stiffness of the optimized structure II is increased by 58.8%, and the radial tangent stiffness is increased by 2.96 times, under the premise of ensuring the mass reduction. Additionally, the R square is 0.9932, and the linearity of the radial stiffness curve is greatly improved. The braking and driving conditions under pure longitudinal sliding characteristics are more antisymmetric, which greatly improves the braking sensitivity, but the driving performance is not as good as the original structure. In addition, this paper establishes the evaluation index of the non-pneumatic tire carrying mode, which lays the foundation for further exploration of the non-pneumatic tire carrying mechanism. Full article

Non-pneumatic tires (NPTs) have been widely used for their advantages of no run-flat, no need for air maintenance, and unique stiffness characteristics. This study focuses on the design of a spoke of a Fibonacci spiral non-pneumatic tire (FS-NPT) based on its properties of three-dimensional stiffness. Finite element (FE) models, parametric studies, designs of experiments (DOEs), and sensitivity analyses are conducted to study the effect on the three-dimensional stiffness considering three design variables: (a) the thickness of the spokes, (b) the radius of the first Fibonacci spiral of the spoke, and (c) the width of the spokes of the FS-NPT. The results show that variation in all three design parameters had no considerable effect on the lateral stiffness. The results from the DOE are used to create a response surface model (RSM) for the multi-objective function (minimal SSD) and a constraint on the weight of the FS-NPT. The analytical RSM functions are optimized for minimizing the SSD subjected to the given constraint. The results indicate that all three design variables of the spoke had a significant effect on the vertical stiffness. The spoke radius had no potential effect on the longitudinal stiffness of the NPT. Hence, the three-dimensional stiffness of the FS-NPT has a certain independent design. This work demonstrates the advantages of non-pneumatic tires, especially FS-NPTs, in three-dimensional stiffness decoupling. This study guides the industrial production of flexible-spoke bionic NPTs by providing a very simple spoke structure. The optimization results show that FS-NPTs have a large stiffness design range. The different stiffness targets can be achieved by adjusting different combinations of the design variables, and the tire mass does not increase significantly. Full article

Nonpneumatic tires (NPTs) have good safety and a good load-carrying capacity, and they replace the function of air in pneumatic tires with a solid spoke component. The radial stiffness and weight are the important indexes for evaluating the performance of an NPT. In this research, we designed an NPT according to the requirements of vehicle Chery eQ1 based on weight minimization. Taking the radial stiffness related to the bearing-capacity performance as the constraint condition, a topology-optimization algorithm is proposed to find the best thickness distribution of the spokes with the objective of minimizing the mass. First, the mechanical properties of the material were obtained with the test. Then, the FE model of an NPT with a Fibonacci spoke structure was built and validated with a radial-stiffness test on a five rigid test machine. The optimization algorithm was carried out by searching for the best thickness distribution of the spoke after verifying the reliability of the FE model. Finally, the optimized tire was manufactured, and the stiffness test was carried out to verify the feasibility of the optimization results. The results show that the spoke mass can be reduced by 9% by using the proposed optimization algorithm while satisfying the radial-stiffness constraint. Full article

The high load capacity and the harsh working environment of mining dump trucks require suspension structures with good damping properties and simple structures. Hydro-pneumatic suspensions are widely used due to their non-linear stiffness and damping characteristics, which allow them to adapt to changes in external load excitation. To solve the problem of the high stiffness of the vehicle under loading impact conditions, which leads to easy damage to the suspension and tire components, a two-stage pressure hydro-pneumatic suspension system is designed to meet the needs of the new vehicle based on the single-chamber hydro-pneumatic suspension. The 1/4 hydro-pneumatic suspension of a mining dump truck is applied as the research object. By comparing the pressure, dynamic deflection, and acceleration of the two types of suspension cylinders through simulation and experiment, respectively, the damping characteristics of the two-stage pressure hydro-pneumatic suspension system during the loading process are obtained. Full article

The hysteresis of rubber materials due to deformation and viscoelasticity is the main reason for the heat build-up (HBU) and rolling resistance (RR) of the rolling tire. It is important to realize the high precision prediction of HBU and RR of tire for the optimal design of high-performance fuel-saving tire. In this work, a thermo-mechanical coupling method based on Endurica and Abaqus co-simulation was used to predict the steady-state temperature distribution and RR of three finite element models (Lagrangian–Eulerian model, Lagrangian model, and Plane Strain model) of the solid tires under different loads and rotating speeds. The simulation results were compared with the experimental results. The Kraus self-heating model was utilized in the thermo-mechanical coupling method, which realized the quantitative relationship between the dynamic loss modulus of rubber and the loading conditions (temperature, strain, and strain rate). Special attention was paid to the determination of the material parameters in the Kraus self-heating model. The comparison between simulation results and experimental results shows that the Lagrangian model had the highest prediction accuracy, and the average prediction errors of the steady-state surface temperature and RR under three loading conditions were 3.4% and 7.9%, respectively. The Lagrangian–Eulerian model came in the second with average errors of 9.7% and 11.1%, respectively. The Plane Strain model had the worst prediction accuracy, with the average errors of 21.4% and 44.6%, respectively. In terms of the simulation time, the Plane Strain model had the lowest cost, and the average calculation time was 1143 s. The Lagrangian–Eulerian model took the second place, with an average calculation time of 2621 s. The Lagrangian model had the highest computation cost, with an average time of 5597 s. The comparison between the simulation results and the experimental results verified the effectiveness of the thermo-mechanical coupling analysis method. The methods of three finite element models of the solid tires in this work can provide some reference for the optimization design of elastomeric components (Lagrangian model), pneumatic tires (Lagrangian–Eulerian model), and non-pneumatic tires (Plane Strain model). Full article
