Search Results (26)

The increasing atmospheric CO₂ concentration due to anthropogenic activities has led to the development of low-cost, portable, and user-friendly sensing technologies. Non-Dispersive Infrared (NDIR) sensors offer reliable CO₂ detection with high sensitivity, which makes them ideal for citizen scientists. In this context, we designed two low-cost CO₂ monitoring systems: an automatic opening chamber with a lid and a portable device using NDIR sensors. These monitoring systems were calibrated (R² = 0.99) with known CO₂ concentrations. Besides its reliability and accuracy, the Automated CO₂ Monitoring System costs approximately USD 220.77 and portable CO₂ device costs USD 151.43, which makes them suitable for citizen scientists. Due to CO₂ gas monitoring system’s simplicity, structure, and operation, non-expert users can use and actively participate in environmental monitoring data collection. This promotes public engagement in climate and air quality monitoring and enables citizen scientists to have reliable data for CO₂ monitoring and environmental awareness. Full article

The safety of power batteries in the automotive industry is of paramount importance and cannot be emphasized enough. As lithium-ion battery technology continues to evolve, the energy density of these batteries increases, thereby amplifying the potential risks linked to battery failures. This study explores pivotal safety challenges within the electric vehicle sector, with a particular focus on thermal runaway and gas emissions originating from lithium-ion batteries. We offer a non-dispersive infrared (NDIR) gas sensor designed to efficiently monitor battery emissions. Notably, carbon dioxide (CO₂) gas sensors are emphasized for their ability to enhance early-warning systems, facilitating the timely detection of potential issues and, in turn, improving the overall safety standards of electric vehicles. In this study, we introduce a novel CO₂ gas sensor based on the advanced pyroelectric single-crystal lead niobium magnesium titanate (PMNT), which exhibits exceptionally high pyroelectric properties compared to commercially available materials, such as lithium tantalate single crystals and lead zirconate titanate ceramics. The specific detection rate of PMNT single-crystal pyroelectric infrared detectors is more than four times higher than lithium tantalate single-crystal infrared detectors. The PMNT single-crystal NDIR gas detector is used to monitor thermal runaway in lithium-ion batteries, enabling the rapid and highly accurate detection of gases released by the battery. This research offers an in-depth exploration of real-time monitoring for power battery safety, utilizing the cutting-edge pyroelectric single-crystal gas sensor. Beyond providing valuable insights, the study also presents practical recommendations for mitigating the risks of thermal runaway in lithium-ion batteries, with a particular emphasis on the development of effective warning systems. Full article

A carbon dioxide (CO₂) gas sensor based on non-dispersive infrared (NDIR) technology has been developed and is suitable for use in portable devices for high-precision CO₂ detection. The NDIR gas sensor comprises a MEMS infrared emitter, a MEMS thermopile detector with an integrated optical filter, and a compact gas cell with high optical coupling efficiency. A dual-ellipsoid mirror optical system was designed, and based on optical simulation analysis, the structure of the dual-ellipsoid reflective gas chamber was designed and optimized, achieving a coupling efficiency of up to 54%. Optical and thermal simulations were conducted to design the sensor structure, considering thermal management and light analysis. By optimizing the gas cell structure and conditioning circuit, we effectively reduced the sensor’s baseline noise, enhancing the overall reliability and stability of the system. The sensor’s dimensions were 20 mm × 10 mm × 4 mm (L × W × H), only 15% of the size of traditional NDIR gas sensors with equivalent detection resolution. The developed sensor offers high sensitivity and low noise, with a sensitivity of 15 μV/ppm, a detection limit of 90 ppm, and a resolution of 30 ppm. The total power consumption of the whole sensor system is 6.5 mW, with a maximum power consumption of only 90 mW. Full article

This review investigates the ship emission measurements using multirotor unmanned aerial vehicles (UAVs). The monitoring of emissions from shipping is a priority globally, because of the necessity to reduce air pollution and greenhouse gas emissions. Moreover, there is widespread global effort to extensively measure vessel fuel sulfur content (FSC). The majority of studies indicate that more commonly used methods for measuring ship emission with UAVs is the sniffing method. Most of the research is concerned with determining the fuel sulfur content. Fuel sulfur content can be determined by the ratio of CO₂ and SO₂ concentration in the exhaust gas plume. For CO₂, the non-dispersive infrared (NDIR) method is used, the most common measuring range reaches 0–2000 ppm, the overall measuring range 0–10,000 ppm, and detection accuracy is ±5–300 ppm. For SO₂, the electrochemical (EC) method is used, the measuring range reaches 0–100 ppm, and the detection accuracy is ±5 ppm. Common UAV characteristics, used in measurement with ships, involve the following: 8–10 m/s of wind resistance, 5–6 kg maximum payload, and a flight distance ranging from 5 to 10 km. This can change in the near future, since a variety of emission measuring devices that can be mounted on UAVs are available on the market. The range of available elements differs from device to device, but available ranges are allowed and the accuracy provides good possibilities for wider research into ship emissions. Full article

Increasing concerns about air quality due to fossil fuel combustion, especially nitrogen oxides (NO_x) from marine and diesel engines, necessitate advanced monitoring systems due to the significant health and environmental impacts of nitrogen dioxide (NO₂). In this study, a gas detection system based on the principle of the non-dispersive infrared (NDIR) technique is proposed. Firstly, the pyroelectric detector was developed by employing an ultra-thin LiTaO₃ (LT) layer as the sensitive element, integrated with nanoscale carbon material prepared by wafer-level graphics technology as the infrared absorption layer. Then, the sensor was hermetically sealed using inert gas through energy storage welding technology, exhibiting a high detectivity (D*) value of 4.19 × 10⁸ cm·√Hz/W. Subsequently, a NO₂ gas sensor was engineered based on the NDIR principle employing a Micro Electro Mechanical System (MEMS) infrared (IR) emitter, featuring a light path chamber length of 1.5 m, along with integrated signal processing and software calibration algorithms. This gas sensor was capable of detecting NO₂ concentrations within the range of 0–500 ppm. Initial tests indicated that the gas sensor exhibited a full-scale relative error of less than 0.46%, a limit of 2.8 ppm, a linearity of −1.09%, a repeatability of 0.47% at a concentration of 500 ppm, and a stability of 2% at a concentration of 500 ppm. The developed gas sensor demonstrated significant potential for application in areas such as industrial monitoring and analytical instrumentation. Full article

Nowadays, indoor air pollution is a major problem that affects human health. For that reason, measuring indoor air quality has an increasing interest. Electronic noses are low-cost instruments (compared with reference methods) capable of measuring air components and pollutants at different concentrations. In this paper, an electro-optical nose (electronic nose that includes optical sensors) with non-dispersive infrared sensors and metal oxide semiconductor sensors is used to measure gases that affect indoor air quality. To validate the developed prototype, different gas mixtures (CH₄ and CO₂) with variable concentrations and humidity values are generated to confirm the discrimination capabilities of the device. Principal Component Analysis (PCA) was used for dimensionality reduction purposes to show the measurements in a plot. Partial Least Squares Regression (PLS) was also performed to calculate the predictive capabilities of the device. PCA results using all the measurements from all the sensors obtained PC1 = 47% and PC2 = 10%; results are improved using only the relevant information of the sensors obtaining PC1 = 79% and PC2 = 9%. PLS results with CH₄ using only MOX sensors received an RMSE = 118.8. When using NDIR and MOX sensors, RMSE is reduced to 19.868; this tendency is also observed in CO₂ (RMSE = 116.35 with MOX and RMSE = 20.548 with MOX and NDIR). The results confirm that the designed electro-optical nose can detect different gas concentrations and discriminate between different mixtures of gases; also, a better correlation and dispersion is achieved. The addition of NDIR sensors gives better results in measuring specific gases, discrimination, and concentration prediction capabilities in comparison to electronic noses with metal oxide gas sensors. Full article

This paper proposes to apply a newly developed Non-Dispersive Infrared Spectroscopy (NDIR) gas sensing system composed of pyroelectric infrared detectors to monitor the thermal runaway (TR) process of lithium-ion batteries in real time and achieve an early warning system for the battery TR process. The new Electrical Vehicle Safety—Global Technical Regulation (EVS-GTR) requires that a warning be provided to passengers at least five minutes before a serious incident. The experimental results indicate that carbon dioxide and methane gas were detected during the overcharge test of the automotive battery, and the target gas was detected 25 s in advance before the battery TR when the battery vent was closed. In order to further explore the battery TR mechanism, an experiment was carried out using the battery sample with the battery vent opened. The target gas was detected about 580 s before the battery temperature reached the common alarm temperature (60 °C) of the battery management system (BMS). In this study, the beneficial effects of NDIR gas sensors in the field of thermal runaway warnings for automotive batteries were demonstrated and showed great application prospects and commercial value. Full article

A multi-gas sensing system was developed based on the detection principle of the non-dispersive infrared (NDIR) method, which used a broad-spectra light source, a tunable Fabry–Pérot (FP) filter detector, and a flexible low-loss infrared waveguide as an absorption cell. CH₄, C₂H₆, and CO₂ gases were detected by the system. The concentration of CO₂ could be detected directly, and the concentrations of CH₄ and C₂H₆ were detected using a PCA-BP neural network algorithm because of the interference of CH₄ and C₂H₆. The detection limits were achieved to be 2.59 ppm, 926 ppb, and 114 ppb for CH₄, C₂H₆, and CO₂ with an averaging time of 429 s, 462 s, and 297 s, respectively. The root mean square error of prediction (RMSEP) of CH₄ and C₂H₆ were 10.97 ppm and 2.00 ppm, respectively. The proposed system and method take full advantage of the multi-component gas measurement capability of the mid-infrared broadband source and achieve a compromise between performance and system cost. Full article

We report on a novel, cost-effective non-dispersive infrared (NDIR) multi-gas sensor aimed at environmental air pollution monitoring. The rugged design of the K96 sensor core combines highest compactness and low-power consumption with our unique multi-channel cell design, featuring the detection of up to three different gases simultaneously, including CO₂, CH₄, N₂O, and H₂O. Our sensing platform allows the selection of the target gases as well as the concentration ranges, thus providing highly customizable gas sensor systems targeting application-specific gas monitoring settings. The sensor core comes with an implemented calibration model, and can address in real time any cross-sensitivity between the NDIR gas-sensing channels. We provide an immensely versatile sensing system while ensuring high sensing stability combined with high precision (<0.1 ppm for both CO₂ and N₂O, <0.5 ppm for CH₄). The K96 multi-gas sensor core offers a resilient sensor solution for the increasing demand of compact monitoring systems in the field of environmental monitoring at reasonable costs for medium-to-high volumes. Full article

Road transport contributes significantly to air pollution in cities. Regulations across the globe continuously reduce the limits that vehicles need to respect during their lifetimes. Furthermore, more pollutants are being subject to control with new regulations and, most important, testing tends to be done under real-world conditions on the road. In this study, various portable systems were compared with laboratory-grade equipment with a wide range of emissions, focusing on the lower end, where the measurement uncertainty of the instruments is crucial for the determination of emission limits. The engines were diesel- and compressed natural gas (CNG)-fueled. The results were promising, with relatively small differences between portable emissions measurement systems (PEMSs), portable Fourier transform infrared (FTIR) and quantum cascade laser infrared (QCL-IR) spectrometers, and the respective laboratory-grade analyzers based on chemiluminescence detection (CLD), non-dispersive infrared (NDIR), and FTIR principles. The results also highlighted the need for strict technical regulations regarding accuracy and drift for low emission limits in future. Full article

Aluminum Carbide (Al₄C₃) is a main source of corrosion problems in metal matrix composites as well as refractory products. Hydrolysis to methane happening at room temperature leads to various structural problems. As methods to quantify Al₄C₃ are scarce, this paper proposes a method to measure Al₄C₃ containing analyte powders in mg areas by combining a robust autoclave system with non-dispersive infrared (NDIR) process analytics. The method uses only water as reagent, making it easy and safe to handle. The used materials were characterized by thermogravimetric analysis coupled with fourier-transformation infrared detection (TGA-IR), LECO-C analysis, and X-ray diffraction (XRD) before and after autoclave treatment. 90–90.8% recovery of 100 mg Al₄C₃ with small standard deviations (<1% at n = 3) in 240, 205, and 165 min at 60, 70, and 80 °C, respectively, were achieved. XRD analysis showed the total conversion of Al₄C₃ to Bayerite (Al(OH)₃) and Boehmite (AlO(OH)) at 70 °C. Comparison with shrinking core models showed that the reaction is neither purely reaction nor purely ash diffusion controlled. The findings indicate possibilities for further acceleration of reaction speeds by increasing temperature. The 200 mL reactor volume of the autoclave enables the analysis of bigger sample sizes at temperatures above 100 °C by separating reaction and analysis procedure. This provides an extension to gas chromatographic methods for industrial quality control of bulk materials in rougher environments. Full article

Automobile exhaust gases, such as carbon dioxide (CO₂), carbon monoxide (CO), and propane (C₃H₈), cause the greenhouse effect, photochemical smog, and haze, threatening the urban atmosphere and human health. In this study, a non-dispersive infrared (NDIR) multi-gas detection system consisting of a single broadband light source, gas cell, and four-channel pyroelectric detector was developed. The system can be used to economically detect gas concentration in the range of 0–5000 ppm for C₃H₈, 0–14% for CO, and 0–20% for CO₂. According to the experimental data, the concentration inversion model was established using the least squares between the voltage ratio and the concentration. Additionally, the interference coefficient between different gases was tested. Therefore, the interference models between the three gases were established by the least square method. The concentration inversion model was experimentally verified, and it was observed that the full-scale error of the sensor changed less than 3.5%, the detection repeatability error was lower than 4.5%, and the detection stability was less than 2.7%. Therefore, the detection system is economical and energy efficient and it is a promising method for the analysis of automobile exhaust gases. Full article

In this paper, we present a fully integrated Non-dispersive Infrared (NDIR) CO₂ sensor implemented on a silicon chip. The sensor is based on an integrating cylinder with access waveguides. A mid-IR LED is used as the optical source, and two mid-IR photodiodes are used as detectors. The fully integrated sensor is formed by wafer bonding of two silicon substrates. The fabricated sensor was evaluated by performing a CO₂ concentration measurement, showing a limit of detection of ∼750 ppm. The cross-sensitivity of the sensor to water vapor was studied both experimentally and numerically. No notable water interference was observed in the experimental characterizations. Numerical simulations showed that the transmission change induced by water vapor absorption is much smaller than the detection limit of the sensor. A qualitative analysis on the long term stability of the sensor revealed that the long term stability of the sensor is subject to the temperature fluctuations in the laboratory. The use of relatively cheap LED and photodiodes bare chips, together with the wafer-level fabrication process of the sensor provides the potential for a low cost, highly miniaturized NDIR CO₂ sensor. Full article

In this paper, a gas detection system with an environmental compensation algorithm based on nondispersive infrared (NDIR) technology was designed. The prepared infrared pyroelectric detector was a dual-channel type based on the lithium tantalate (LiTaO₃) wafer. The design of the optical gas chamber adopted a combination of two ellipsoids and a spherical top surface, which not only enhanced the coupling efficiency of the light propagation but also facilitated the miniaturization of the sensor module. In addition to this, a temperature and humidity compensation algorithm based on the least square method was proposed to make the measurement accuracy up to ±0.9% full scale (FS). Full article

The market of gas sensors is mainly governed by electrochemical, semiconductor, and non-dispersive infrared absorption (NDIR)-based optical sensors. Despite offering a wide range of detectable gases, unknown gas mixtures can be challenging to these sensor types, as appropriate combinations of sensors need to be chosen beforehand, also reducing cross-talk between them. As an optical alternative, Raman spectroscopy can be used, as, in principle, no prior knowledge is needed, covering nearly all gas compounds. Yet, it has the disadvantage of a low quantum yield through a low scattering cross section for gases. There have been various efforts to circumvent this issue by enhancing the Raman yield through different methods. For gases, in particular, cavity-enhanced Raman spectroscopy shows promising results. Here, cavities can be used to enhance the laser beam power, allowing higher laser beam-analyte interaction lengths, while also providing the opportunity to utilize lower cost equipment. In this work, we review cavity-enhanced Raman spectroscopy, particularly the general research interest into this topic, common setups, and already achieved resolutions. Full article
