Search Results (18)

Laser-generated structures have a huge potential to induce an alignment of biological cells, which may be important for various fields in medicine and biotechnology. We describe the formation of fs-laser-induced micro- and nanostructures for achieving the directed growth of Schwann cells, a type of glial cell that can support the regeneration of nerve pathways by guiding the neuronal axons in the direction of their alignment. Polymer surfaces, i.e., polycarbonate (PC) or cellulose acetate butyrate (CAB), were exposed to the beam of a 1040 nm Yb-based amplified fs-laser system with a pulse length of about 350 fs. With appropriate parameters, the laser exposure resulted in a surface topography with oriented micro-grooves, which, for PC, were covered with nano-ripples. Schwann cell growth on these substrates was inspected after 3 to 5 days of cultivation by means of scanning electron microscopy (SEM). We show that Schwann cells can grow in a certain direction, predetermined by micro-groove or nano-ripple orientation. In contrast, cells cultivated on randomly oriented nanofibers or unstructured surfaces show an omnidirectional growth behavior. This method may be used in the future to produce nerve conduits for the treatment of injuries to the peripheral nervous system. Full article

Low-energy ion bombardment (IB) has emerged as a promising, maskless nanofabrication tool for quasi-periodic nanoripples, marked by a high throughput and low cost. As templates, these IB-induced, self-organized surface nanoripples have shown potential for applications in diverse fields. However, the challenge of tailoring the ordering of these ripple patterns is preventing the widespread application of IB. Moreover, the enhancement of the ordering of these self-organized nanostructures involves the fundamental academic questions of nanoripple coupling (or superimposition) and guided self-organization. This review first focuses on the experimental progress made in developing representative strategies for the ordering enhancement of IB-induced nanoripples in terms of ion beams and targets. Second, we present our understanding of these developments from the perspectives of ripple superposition and guided self-organization. In particular, the basic conditions for ripple superposition under the non-conservation of mass are deduced based on the common features of the results from rocking bombardments of a single material and the bombardment of bilayer systems, providing insight into the mechanisms at play and deepening our understanding of these experimental observations. Finally, areas for future research are given, with the aim of improving ripple ordering from the viewpoints of ripple superimposition and guided self-organization. All this may re-stimulate interest in this field and will be of importance in advancing the academic research and practical applications of IB-induced nanopatterns. Full article

We demonstrated the linear, radial, and annular ripple formation on the surface of GaAs. The formation of linear ripples was optimized by the number of shots and the fluence of 30 ps, 532 nm pulses. The radial and annular nanoripples were produced under the ablation using doughnut-like beams possessing azimuthal and radial polarizations, respectively. We compare the ripples and grooves formed by a linearly polarized Gaussian beam relative to an annular vector beam. The joint overlap of sub-wavelength grooves with ripples formed by azimuthally and radially polarized beams was reported. The conditions under which the shape of radial and ring-like nano- or micro-relief on the GaAs surface can be modified by modulating the polarization of laser pulse were determined. The resultant surface processing of GaAs using a laser beam with different polarization modes is useful for exploring valuable insights and benefits in different applications. Full article

We investigated the effect of additional continuous functional coatings, which changed the hydrophilic–hydrophobic properties of the surface without heavily influencing the surface topography at the nanoscale, on the antiadhesive properties of bioinspired laser-induced periodic nanostructures. These nanostructures mimic the antiadhesive structures on the silk-combing area on the legs of cribellate spiders, the calamistrum. The thin films were deposited by matrix-assisted laser deposition and characterized by infrared spectroscopy, X-ray photoelectron spectroscopy, water contact angle measurements, and adhesion tests using capture threads from the cribellate spider webs. In all cases, the nanoripples were preserved and these structured surfaces showed lower adhesion forces compared to flat controls, although not significant. However, this effect was totally overwhelmed by the difference between the adhesion forces on surfaces with different chemical compositions. The largest adhesion forces were observed on hydrophilic surfaces and the lowest ones on hydrophobic surfaces. The fact that the antiadhesion between nanofibers and the nano-structured areas depends strongly on the chemical composition of the surface can be explained by the specific adhesion between individual chemical groups due to frequency dependencies in the theory of van der Waals forces. However, explaining these adhesion properties just by the categories “hydrophilic” or “hydrophobic” is oversimplified. Full article

Nanostructures can be produced on poly(ethylene terephthalate) (PET) foils by using a krypton fluoride (KrF) excimer laser with a wavelength of 248 nm and a pulse duration of about 20 ns. We show that surface nanoripples, nanodots, nanogrids, and hybrid patterns of ripples with dots or finer ripples on top can be fabricated. The effects of a water layer in front of the PET foil and of cooling during laser processing were investigated. For pattern formation, several irradiation parameters (pulse number, pulse energy, and polarization) were varied systematically. The spatial periods of the ripples were changed by adjusting the angle of incidence of the laser beam. All nanostructures were characterized by scanning electron microscopy, and relevant morphological parameters, such as peak-to-peak distances and spatial periods, were assessed. Shapes and heights of some structures were characterized by using focused ion beam cuts to avoid the tip-sample convolution effects typical of atomic force microscopy images. We further demonstrate nanoripple formation on PET foils as thin as 12 µm, 6 µm, and 1.4 µm. The remarkable variety of nanostructures on PET we present here enables customized fabrication for a wide range of applications. Full article

Enhancing the infrared window transmittance of zinc sulfide (ZnS) is important to improve the performance of infrared detector systems. In this work, a new hybrid micro/nanostructure was fabricated by an optimal Bessel femtosecond laser on ZnS substrate. The surface morphologies and profiles of ASS ablated by a 20× microscope objective Bessel beam are described, indicating that the nanoripples on the micropore were formed by the SPP interference and the SPP scattering in a particular direction. Further, the maximum average transmittance of ASS increased by 9.7% and 12.3% in the wavelength ranges of 5~12 μm and 8~12 μm, respectively. Finally, the antireflective mechanism of the hybrid micro/nanostructure is explored using the novel electromagnetic field model based on the FDTD method, and we attribute the stable antireflective performance of ASS in broadband to the interface effective dielectric effect and LLFE. Full article

Ion bombardment (IB) is a promising nanofabrication tool for self-organized nanostructures. When ions bombard a nominally flat solid surface, self-organized nanoripples can be induced on the irradiated target surface, which are called intrinsic nanoripples of the target material. The degree of ordering of nanoripples is an outstanding issue to be overcome, similar to other self-organization methods. In this study, the IB-induced nanoripples on bilayer systems with enhanced quality are revisited from the perspective of guided self-organization. First, power spectral density (PSD) entropy is introduced to evaluate the degree of ordering of the irradiated nanoripples, which is calculated based on the PSD curve of an atomic force microscopy image (i.e., the Fourier transform of the surface height. The PSD entropy can characterize the degree of ordering of nanoripples). The lower the PSD entropy of the nanoripples is, the higher the degree of ordering of the nanoripples. Second, to deepen the understanding of the enhanced quality of nanoripples on bilayer systems, the temporal evolution of the nanoripples on the photoresist (PR)/antireflection coating (ARC) and Au/ARC bilayer systems are compared with those of single PR and ARC layers. Finally, we demonstrate that a series of intrinsic IB-induced nanoripples on the top layer may act as a kind of self-organized template to guide the development of another series of latent IB-induced nanoripples on the underlying layer, aiming at improving the ripple ordering. The template with a self-organized nanostructure may alleviate the critical requirement for periodic templates with a small period of ~100 nm. The work may also provide inspiration for guided self-organization in other fields. Full article

Various antireflective structures and methods are proposed to solve the optical loss of Si-based absorber devices. Dual-scale structures have received more concern from researchers in recent years. In this study, the finite difference time domain (FDTD) method is employed to investigate deeply the dependence of optical response on the geometric shape and size of structures. The micron cone shows lower reflectivity than other micron structures. Additionally, the lowest reflectivity region moves with the increasing height size of the cone structure. We proposed creatively a nanoripple-cone structure that maintains low reflectivity properties under varying incident angles whether in the visible region or the near-infrared region. Furthermore, the lower reflectivity is obtained with increasing micron cone and decreasing nanoripple. Finally, the dual-scale nanoripple-cone is fabricated directly and cost-effectively by a femtosecond laser instead of a two-step texture-on-texture way. The measured result shows that the high absorption above 98% extends to the mid-infrared region. This study provides directions for the fabrication of wideband Si-based absorber devices to reduce reflectivity, which exhibits a wide application potential and promotes the evolution of multi-laser processing. Full article

SiC ceramics have excellent comprehensive properties and are typical hard and brittle materials that are difficult to process and are widely used in many fields. Laser polishing technology has developed into a new surface processing technology, and femtosecond laser polishing has become an important method for the precision machining of hard and brittle materials. In this paper, SiC ceramics were ablated and polished by infrared femtosecond laser, the laser ablation threshold of SiC ceramics was calculated and the influence of pulse energy and defocus amount on the surface morphology, surface roughness, polishing depth and oxidation degree of femtosecond laser polishing of SiC ceramics were investigated. The results show that when the laser repetition frequency f = 175 kHz, wavelength λ = 1064 nm and ablation time t = 9 s, the laser ablation threshold of SiC ceramics is 0.355 J/cm². With the increase in pulse energy, the surface roughness first decreased and then increased, and the polishing depth showed an overall upward trend. The change of defocus amount will lead to the change of the laser spot diameter. With the increase of the defocus amount, the laser spot irradiated on the workpiece surface becomes larger, and the laser energy density decreases, which results in the decrease of the laser ablation ability and polishing depth and the increase of the polished surface roughness. Periodic nano-ripple structures appeared on the laser-induced surface. Through Energy Dispersive Spectrometer (EDS) elemental analysis, it was found that there was an oxidation phenomenon in SiC ceramics polished by femtosecond laser in an air environment, and the change of pulse energy and defocus amount had insignificant effects on the degree of oxidation. Full article

Bacterial adhesion and biofilm formation on surfaces are associated with persistent microbial contamination, biofouling, and the emergence of resistance, thus, calling for new strategies to impede bacterial surface colonization. Using ns-UV laser treatment (wavelength 248 nm and a pulse duration of 20 ns), laser-induced periodic surface structures (LIPSS) featuring different sub-micrometric periods ranging from ~210 to ~610 nm were processed on commercial poly(ethylene terephthalate) (PET) foils. Bacterial adhesion tests revealed that these nanorippled surfaces exhibit a repellence for E. coli that decisively depends on the spatial periods of the LIPSS with the strongest reduction (~91%) in cell adhesion observed for LIPSS periods of 214 nm. Although chemical and structural analyses indicated a moderate laser-induced surface oxidation, a significant influence on the bacterial adhesion was ruled out. Scanning electron microscopy and additional biofilm studies using a pili-deficient E. coli TG1 strain revealed the role of extracellular appendages in the bacterial repellence observed here. Full article

The presence of surface oxides on the formation of laser-induced periodic surface structures (LIPSS) is regularly advocated to favor or even trigger the formation of high-spatial-frequency LIPSS (HSFL) during ultrafast laser-induced nano-structuring. This paper reports the effect of the laser texturing environment on the resulting surface oxides and its consequence for HSFLs formation. Nanoripples are produced on tungsten samples using a Ti:sapphire femtosecond laser under atmospheres with varying oxygen contents. Specifically, ambient, 10 mbar pressure of air, nitrogen and argon, and 10⁻⁷ mbar vacuum pressure are used. In addition, removal of any native oxide layer is achieved using plasma sputtering prior to laser irradiation. The resulting HSFLs have a sub-100 nm periodicity and sub 20 nm amplitude. The experiments reveal the negligible role of oxygen during the HSFL formation and clarifies the significant role of ambient pressure in the resulting HSFLs period. Full article

In this work, a new buffer layer material, a bismuth-indium (Bi-In) alloy, was utilized to improve the quality of large-area, laser-induced periodic ripple structures on silicon. Better-defined ripple structures and larger modification areas were obtained at different scanning speeds by pre-depositing a Bi-In film. The single-spot investigations indicated that ripple structures were much easier to form on silicon coated with the Bi-In film under laser fluences of 2.04 and 2.55 J/cm² at a fixed pulse number of 200 in comparison with on bare silicon. A physical model in terms of the excellent thermal conductivity contributed by the free electrons in the Bi-In film homogenizing the thermal distribution caused by the laser irradiation in the early stage of the formation of laser-induced periodic surface structures was proposed to explain the above phenomena. The results show that the Bi-In film enabled a wider range of laser fluences to generate periodic structures and helped to form regular ripple structures on the silicon. In addition, the modulation effects of the laser fluence and pulse number on surface structures were studied experimentally and are discussed in detail. Full article

The bioactivity and biocompatibility play key roles in the success of dental and orthopaedic implants. Although most commercial implant systems use various surface microstructures, the ideal multi-scale topographies capable of controlling osteointegration have not yielded conclusive results. Inspired by both the isotropic adhesion of the skin structures in tree frog toe pads and the anisotropic adhesion of the corrugated ridges on the scales of Morpho butterfly wings, composite micro/nano-structures, including the array of micro-hexagons and oriented nano-ripples on titanium alloy implants, were respectively fabricated by microsecond laser direct writing and femtosecond laser-induced periodic surface structures, to improve cell adherence, alignment and proliferation on implants. The main differences in both the bioactivity in simulated body fluid and the biocompatibility in osteoblastic cell MC3T3 proliferation were measured and analyzed among Ti-6Al-4V samples with smooth surface, micro-hexagons and composite micro/nano-structures, respectively. Of note, bioinspired micro/nano-structures displayed the best bioactivity and biocompatibility after in vitro experiments, and meanwhile, the nano-ripples were able to induce cellular alignment within the micro-hexagons. The reasons for these differences were found in the topographical cues. An innovative functionalization strategy of controlling the osteointegration on titanium alloy implants is proposed using the composite micro/nano-structures, which is meaningful in various regenerative medicine applications and implant fields. Full article

Surface-enhanced IR absorption (SEIRA) microscopy was used to reveal main chemical and physical interactions between Staphylococcus aureus bacteria and different laser-nanostructured bactericidal Si surfaces via simultaneous chemical enhancement of the corresponding IR-absorption in the intact functional chemical groups. A cleaner, less passivated surface of Si nanoripples, laser-patterned in water, exhibits much stronger enhancement of SEIRA signals compared to the bare Si wafer, the surface coating of oxidized Si nanoparticles and oxidized/carbonized Si (nano) ripples, laser-patterned in air and water. Additional very strong bands emerge in the SEIRA spectra on the clean Si nanoripples, indicating the potential chemical modifications in the bacterial membrane and nucleic acids during the bactericidal effect. Full article

Here, we report on the production of nanoripples on the surface of ZnO bulk substrates by ion beam erosion with 20 keV Ar⁺ ions at an oblique incidence (60°). The ripple patterns, analyzed by atomic force microscopy, follow a power law dependence for both the roughness and the wavelength. At high fluences these ripples show coarsening and asymmetric shapes, which become independent of the beam direction and evidence additional mechanisms for the pattern development. The shallow damaged layer is not fully amorphized by this process, as confirmed by medium energy ion scattering. A detailed study of the damage-induced changes on the optical properties was carried out by means of spectroscopic ellipsometry. Using a 3-layer model based on Tauc-Lorenz and critical point parameter band oscillators, the optical constants of the damaged layer were determined. The results showed a progressive reduction in the refractive index and enhanced absorption below the bandgap with the fluence. Full article
