This paper investigates the influence of substrate grain size on the behavior of a multilayer CrN/CrAlN coating, with the bilayer thickness varying across the cross-section in the range of 200–1000 nm. The substrate tools were made of WC-Co sintered carbide with three different grain sizes. The coatings were subjected to mechanical and tribological tests to assess their performance, including nanohardness, scratch resistance, and tribological testing. The coating’s roughness was measured using a 2D profilometer. Additionally, the chemical composition and surface morphology were analyzed using Scanning Electron Microscopy (SEM) and Energy Dispersive X-Ray Spectroscopy (EDX). The durability tests were performed on an industrial CNC machine tool on the particleboard. The results revealed that tools with ultra-fine nano-grain (S) and micro-grain (T) WC-Co substrates exhibited a significant increase in tool durability by 28% and 44%, respectively. Significant differences in the microgeometry of the substrate U, especially in relation to the tool based on substrate S, explain the lack of improvement in its durability despite the use of a multilayer coating. Full article

Graphene exhibits great potential as an anti-friction coating material in MEMS. However, its underlying microscopic friction-reduction mechanism remains unclear. In this paper, the microstructural evolution and nanomechanical behavior of graphene coatings on copper substrates were systematically investigated by AFM friction experiments and MD simulations. MD simulations reveal that the anti-friction properties of graphene coatings primarily stem from microstructural regulation and load-bearing reinforcement of the substrate. The graphene coatings increase indentation diameter by forming transition radii at the indentation edges, and suppress the plowing effect of the substrate by restricting atomic upward movement, both of which enhance the dislocation density and load-bearing capacity of the substrate. Additionally, graphene coatings also reduce the scratch edge angle, weakening the interlocking effect between the substrate and tip, further lowering the friction force. Experimental results indicate that the tribological behavior of graphene coatings exhibits staged characteristics: graphene coatings show excellent ultrafriction properties under intact structural conditions, while showing a higher friction force in wear and tear states. This research provides a theoretical basis and technical guidance for the development of anti-friction and wear-resistant coatings for micro-nano devices. Full article

This study examines the incorporation of chopped glass fiber and nano-silica into epoxy, focusing on their effects on the tribological and mechanical properties. Three reinforcement ratios (1 wt.%, 3 wt.%, and 5 wt.%) were analyzed by scratch tests and profilometric analysis. The coefficient of friction (COF), scratch depth, and scratch width values of the unreinforced epoxy resin were measured as 0.45, 37.73 µm and 479 µm, respectively. The addition of glass fibers contributed to improved scratch performance by restricting material removal and stabilizing groove morphology, although higher fiber ratios caused an increase in COF. The results indicated that nano-silica increased scratch resistance with a COF of 0.42 at 5 wt.%, giving a scratch depth of 19.92 µm and a scratch width of 166 µm. Glass fiber also improved scratch performance, although there were high COF values for higher ratios, which could be due to the aggregation effect of the fibers. Statistical validation of the results was carried out through the Taguchi method and ANOVA analyses. These analyses showed that reinforcement type and ratio played an important role in scratch behavior. SEM analyses of worn surfaces showed that nano-silica can dissipate stress and minimize plastic deformation to yield improved scratch morphology. Overall, the results emphasize the complementary role of glass fiber and nano-silica reinforcements in improving the scratch resistance of epoxy resin for industrial applications. Full article

Hastelloy is widely used in the manufacturing of high-temperature components in the aerospace industry because of its high strength and corrosion-resistant physical properties, as well as its ability to maintain excellent mechanical properties at high temperatures. However, with developments in science and technology, the amount of available components for use in high-temperature and corrosive environments is increasing, their structures are becoming more complex and varied, and requirements with regard to the surface quality of the components has also become more stringent. The integration of cold plasma (CP) and nano-lubricant minimum quantity lubrication (NMQL), within a multi-physics coupling-assisted micro-grinding process (CPNMQL), presents a promising strategy to overcome this bottleneck. In this paper, micro-grinding of Hastelloy C-276 was performed under dry, CP, NMQL, and CPNMQL conditions, respectively. Contact angle testing, X-ray photoelectron spectroscopy (XPS) analysis, and nano-scratch experiments were used to investigate the mechanism of CPNMQL and to compare the micro-milling performance under different cooling and lubrication conditions employing various characteristics such as grinding temperature, surface roughness, and 3D surface profile. The results showed that at different micro-grinding depths, the micro-grinding temperature and surface roughness were significantly reduced under CP, NMQL, and CPNMQL conditions compared to dry friction. Among them, CPNMQL showed the best performance, with 53.4% and 54.7% reductions in temperature and surface roughness, respectively, compared to the dry condition. Full article

The aim of the study is a comparative analysis of micromechanical and microtribological properties of the cathodic arc-deposited Mo, Cr, and Ta coatings using nanoindentation and scratch test techniques as well as a microtribological dry sliding test with wear tracks post-examination and worn volume determination using interference profilometry. A new scratch test technique based on the statistical processing of registered sclerograms during a multi-pass scratch test well adopted for the scratch resistance assessment of rough surfaces is suggested. New approaches to microtribological testing based on the indentation tester equipped with an additional precision rotational stage are proposed, which could fill the gap between macro- and nano-scale. X-ray diffraction analysis reveals the structure of the studied coatings and phase compositions of the coating-substrate interface. Full article

TiN thin films are widely used as protective and decorative coatings for tools in industry. Previous studies have focused on the deposition of TiN coatings on substrates by reactive magnetron sputtering, whereas the use of TiN targets avoids problems such as ‘nitrogen contamination’ and ‘target poisoning’. TiN coatings were grown on silicon wafers and cemented carbide substrates by varying the parameters of the magnetron sputtering plasma source, operating Ar pressure and deposition temperature. The experimental results show the better mechanical properties of ceramic materials deposited using radio frequency (RF) magnetron sputtering. During RF magnetron sputtering, the hardness of the coating increased significantly to 17 Gpa when the deposition working pressure was reduced from 1.5 Pa to 0.5 Pa. The coefficient of friction tends to decrease as the deposition temperature increases, and at 400 °C the coefficient of friction between the deposited film and the friction pair made of Al₂O₃ material is only 0.36. The nano-scratch experimental tests concluded that the TiN coatings deposited at 300 °C conditions had the best adhesion to the substrate at an Ar pressure of 0.5 Pa under an RF source. Full article

Anodizing can generate porous wear-resistant layers, which can act as reservoirs for gradually releasing lubricants. Studies on the formation of zinc dialkyl dithiophosphate (ZDDP) tribofilms in non-ferrous metals are relatively rare. Furthermore, adding nanoparticles can improve wear resistance in various applications. This investigation aims to correlate several anodized surfaces using H₂SO₄ (5 or 10%wt. concentration and 45 or 60 min exposition) to tribological outputs, contributing to understanding the friction behavior of non-metallic layers. Three steps were applied on anodized Alumold 500 alloy. Firstly, the scratching test, to select the layers with higher critical loads. The greatest scratch resistance was obtained with the highest H³/E² value and thickest layer. Secondly, lubricated tests with only poly-alpha-olefin oils (PAO6) were performed in a reciprocating test rig using an alumina ball as the counterpart. From that, only the best AAO condition was selected. Finally, three more lubricant compositions were tested, as follows: adding ZDDP to PAO6, alumina nanoparticles (~100 nm) to PAO6, and ZDDP + nanoparticles. The addition of nano-alumina to the PAO6 resulted in the maintenance of COF values with only PAO6 (~0.1), when the most significant drop in the surface roughness was observed along with the tests. Full article

This study aimed to evaluate the effect of a newly formulated Commiphora molmol (CM) nano-irrigant on the morphology, viability, proliferation, migration, and wound healing of human bone marrow-derived mesenchymal stem cells (hBMMSCs). Different concentrations of CM nano-irrigant were prepared. The minimum inhibitory concentration (MIC) and minimal bactericidal concentration (MBC) were determined to be 25 and 30 mg/mL, respectively. The solution was dispersed into liposomes, which were subsequently coated with chitosan-forming chitosomes. Three concentrations of CM chitosomes were evaluated (25, 30, and 35 mg/mL) along with positive (5.25% NaOCl) and negative (basal culture media) control groups. Cellular viability and proliferation were quantified using AlamarBlue, while wound-healing ability was determined using the scratch assay, and 3D cellular migration was evaluated using the transwell migration assay. All tested concentrations induced observable changes in cellular morphology without any detrimental effects. Viability was monitored at 1, 6, and 24 h, with only Group 1 (25 mg/mL) showing no significant effect on cellular viability. Cellular proliferation was observed over 14 days, with Group 3 (35 mg/mL) being the only group that showed a significantly slower proliferative rate. All tested concentrations resulted in significant differences in transwell migration compared to the negative control. Significant differences were observed within each group across different time points (24–48 h). The results confirm the biocompatibility of the newly formulated CM nano-irrigant in terms of hBMMSCs’ viability, proliferation, morphology, migration, and wound healing. Full article

Background: The aim of this study was to evaluate the influence of acidic beverages on the mechanical properties of various dental resin-based materials. Methods: A total number of 160 samples were prepared using four types of resin-based materials—Group A (n = 40): flowable composite, Group B (n = 40): heavy-flow composite, Group C (n = 40): resin-based sealant and Group D (n = 40): nano-hybrid composite. Then, the samples were distributed into four subgroups according to the submersion solution: a (n = 10): artificial saliva, b (n = 10): coffee, c (n = 10): cola and d (n = 10): red wine. The Vickers microhardness, Young’s modulus of elasticity and scratch resistance were assessed using a CETR UMT-2 tribometer. Results: The obtained results showed that 14-day submersion of the resin-based materials in coffee, cola and red wine solutions significantly (p < 0.05) decreased the microhardness values (VHN), Young’s modulus of elasticity and scratch resistance. Fourteen days of storage in coffee decreased the microhardness values of flow resin from 117.5 to 81.59 VHN (p < 0.001) whereas the values of the nanohybrid resin decreased from 125.5 to 89.4 (p < 0.001). The elasticity modulus of the heavy flow resin showed a decline from 15.57 to 10.50 GPa after 14 days’ submersion in coffee (p < 0.001), and from 21.29 to 13.10 GPa for the nanohybrid resin after immersion in cola (p < 0.001). For the scratch test, the resin-based sealant showed a significant decrease after 14 days of storage in coffee, from 0.34 to 0.02 units. Conclusions: The submersion of conventional nanohybrid, flowable, heavy-flow composite resins and resin-based sealants in coffee, cola and red wine solutions changes the mechanical properties (Young’s modulus of elasticity, Vickers microhardness and scratch resistance). The most resistant resin-based material to acid attack was the conventional nanohybrid composite resin, followed by heavy flow resin, flowable resin and resin-based sealant. Full article

Background: Hereditary Hemorrhagic Telangiectasia (HHT) is a genetic disorder leading to frequent bleeding in several organs. As HHT diagnosis is demanding and depends on clinical criteria, liquid biopsy would be beneficial. Exosomes from biofluids are nano-sized vesicles for intercellular communication. Their cargo and characteristics represent biomarkers for many diseases. Here, exosomes of HHT patients were examined regarding their biosignature. Methods: Exosomes were isolated from the plasma of 20 HHT patients and 17 healthy donors (HDs). The total exosomal protein was quantified, and specific proteins were analyzed using Western blot and antibody arrays. Human umbilical vein endothelial cells (HUVECs) co-incubated with exosomes were functionally examined via immunofluorescence, proliferation, and scratch assay. Results: The levels of the angiogenesis-regulating protein Thrombospondin-1 were significantly higher in HHT compared to HD exosomes. Among HHT, but not HD exosomes, a negative correlation between total exosomal protein and soluble Endoglin (sENG) levels was found. Other exosomal proteins (ALK1, ALK5) and the particle concentration significantly correlated with disease severity parameters (total consultations/interventions, epistaxis severity score) in HHT patients. Functionally, HUVECs were able to internalize both HD and HHT exosomes, inducing a similar change in the F-Actin structure and a reduction in migration and proliferation. Conclusions: This study provided first insights into the protein cargo and function of HHT-derived exosomes. The data indicate changes in sENG secretion via exosomes and reveal exosomal Thrombospondin-1 as a potential biomarker for HHT. Several exosomal characteristics were pointed out as potential liquid biomarkers for disease severity, revealing a possible new way of diagnosis and prognosis of HHT. Full article

The simulation of nano-scratching on metallic substrates using smooth particle hydrodynamics (SPH) has been attempted by researchers in recent years. From a review of the existing SPH simulations of nano-scratching processes, it was found that mainly two different material constitutive models (i.e., the Johnson–Cook model and the elasto-plastic model) were employed to describe the material flow. In the majority of these investigations, the Johnson–Cook model was employed to characterise the stress flow of the material subjected to scratching. A natural question remains as to which material constitutive model is preferable for the SPH modelling of nano-scratching when quantitatively predicting the process outcomes. In this paper, a quantitative comparison of material responses during the nano-scratching of copper is reported when the process is simulated using SPH with two different constitutive material models, namely the Johnson–Cook and the elasto-plastic models. In particular, the simulated cutting and normal forces as well as the machined topography using both approaches are compared with the experimental work reported in the literature. The SPH-based simulation results in this paper are investigated based on the following three aspects: (a) cutting and normal forces with different material models and depths of the cut, (b) the effect of the cutting speed on forces and its dependence on adopted material models, and (c) the effect of adopted material models on the surface topography of machined nano-grooves. The SPH simulation results showed that using the Johnson–Cook material model, cutting and normal forces were closer to the experimental data compared to the results obtained with the elasto-plastic model. The results also showed that the cross-sectional profile of simulated nano-grooves using the Johnson–Cook model was closer to the experimental results. Overall, this paper shows that the selection of the Johnson–Cook model is preferable for the SPH modelling of the nano-scratching process. Full article

Ultra-thin 304 stainless steel can be used to flexibly display substrates after they have been subjected to chemical mechanical polishing (CMP). The thickness of the chemical oxide layer directly affects the polishing efficiency and surface quality of 304 stainless steel. In the study presented in the following paper, the thickness variation of the chemical oxide layer of 304 stainless steel was analyzed following electrochemical corrosion under different oxidant concentration conditions. Furthermore, the impact of the oxidant concentration on the grooves, chips, and scratch depth–displacement–load curves was investigated during a nano-scratching experiment. Through this process, we were able to reveal the chemical reaction mechanism between 304 stainless steel materials and oxidizers. The corrosion rate was found to be faster at 8% oxidant content. The maximum values of the scratch depth and elastic–plastic critical load were determined to be 2153 nm and 58.47 mN, respectively. Full article

The V-O-N coating set was produced at different relative oxygen concentrations of O₂(x) = O₂/(N₂ +O₂) using cathodic arc evaporation. The aim of the research was to determine the effect of oxygen on coating properties. The coatings’ composition and structural properties (X-ray diffraction (XRD), scanning electron microscopy (SEM), energy dispersive X-ray spectroscopy (EDX)) and mechanical properties—hardness, adhesion, and wear resistance (nano-indenter, scratch tester, ball-on-disc tester)—were extensively investigated. EDX and XRD analyses indicate that in coatings formed with a relative oxygen concentration in the range of 20–30%, the oxygen concentration in the coating increases dramatically from approximately 16 at.%. to 63 at.%, and the nitrogen concentration drops from about 34 at.% up to 3 at.%. This may indicate greater activity of oxygen compared to nitrogen in forming compounds with vanadium. The occurrence of the V5O9 phase belonging to the Magnéli phases was observed. Microscopic observations indicate that the number of surface defects increases with the oxygen concentration in the coating. The opposite effect is characterized by mechanical properties—hardness, adhesion, and wear resistance decrease with increasing oxygen concentration in the coating. Full article

Ceramic–metal nanolaminates (CMNLs) are promising scratch-resistant coatings, but knowledge gaps remain regarding the interactive effects of individual layer thickness and scratch depth. This study employed molecular dynamics simulations to investigate the tribological performance of NbC/Nb CMNLs, systematically varying ceramic and metal layer thicknesses (0.5–7.5 nm) and scratch depths (3, 5 nm). Models were loaded under displacement-controlled indentation followed by scratching. Mechanical outputs like material removal, friction coefficients, normal, and friction forces quantified scratch resistance. Material removal was even below that for NbC alone, demonstrating the multilayer benefit. Thinner layers showed complete penetration by the indenter, with material rolled in front rather than piled up. Thicker layers resisted penetration, enabling pile-up and lower friction coefficients due to higher normal forces. Excessive material removal decreased normal forces and raised friction coefficients. Peak coefficient occurred around 1.5–3 nm layer thicknesses where substantial top layer volumes were removed, minimizing ceramic under the indenter. Layer thickness corresponding to lowest material removal depended on scratch depth, with 3 nm and 7.5 nm layer thickness for 3 and 5 nm depths, respectively. Metallic layers reduced stiffness and drove material downward over piling up. Quantifying scratch resistance versus geometric parameters elucidates fundamental physics to facilitate superior CMNL coating fabrication. Full article

Glassy carbon provides material characteristics that make it a promising candidate for use as a mould material in precision glass moulding. However, to effectively utilize glassy carbon, a thorough investigation into the machining of high-precision optical surfaces is necessary, which has not been thoroughly investigated. This research analyses the process of material removal and its resulting surface integrity through the use of nano-scratching and ultra-precision grinding. The nano-scratching process begins with ductile plastic deformation, then progresses with funnel-shaped breakouts in the contact zone, and finally concludes with brittle conchoidal breakouts when the cutting depth is increased. The influence of process factors and tool-related parameters resulting from grinding has discernible impacts on the ultimate surface roughness and topography. Enhancing the cutting speed during cross-axis kinematic grinding results in improved surface roughness. Increasing the size of diamond grains and feed rates leads to an increase in surface roughness. An achievable surface roughness of Ra < 5 nm together with ductile-regime grinding behaviour meet optical standards, which makes ultra-precision grinding a suitable process for optical surface generation. Full article
